Remote Sensing

15 pages, 4088 KiB

Open AccessArticle

Improving the Performance of Multi-GNSS (Global Navigation Satellite System) Ambiguity Fixing for Airborne Kinematic Positioning over Antarctica

by Min Li, Tianhe Xu, Frank Flechtner, Christoph Förste, Biao Lu and Kaifei He

Remote Sens. 2019, 11(8), 992; https://doi.org/10.3390/rs11080992 - 25 Apr 2019

Cited by 9 | Viewed by 4921

Abstract

Conventional relative kinematic positioning is difficult to be applied in the polar region of Earth since there is a very sparse distribution of reference stations, while precise point positioning (PPP), using data of a stand-alone receiver, is recognized as a promising tool for [...] Read more.

Conventional relative kinematic positioning is difficult to be applied in the polar region of Earth since there is a very sparse distribution of reference stations, while precise point positioning (PPP), using data of a stand-alone receiver, is recognized as a promising tool for obtaining reliable and accurate trajectories of moving platforms. However, PPP and its integer ambiguity fixing performance could be much degraded by satellite orbits and clocks of poor quality, such as those of the geostationary Earth orbit (GEO) satellites of the BeiDou navigation satellite system (BDS), because temporal variation of orbit errors cannot be fully absorbed by ambiguities. To overcome such problems, a network-based processing, referred to as precise orbit positioning (POP), in which the satellite clock offsets are estimated with fixed precise orbits, is implemented in this study. The POP approach is validated in comparison with PPP in terms of integer ambiguity fixing and trajectory accuracy. In a simulation test, multi-GNSS (global navigation satellite system) observations over 14 days from 136 globally distributed MGEX (the multi-GNSS Experiment) receivers are used and four of them on the coast of Antarctica are processed in kinematic mode as moving stations. The results show that POP can improve the ambiguity fixing of all system combinations and significant improvement is found in the solution with BDS, since its large orbit errors are reduced in an integrated adjustment with satellite clock offsets. The four-system GPS+GLONASS+Galileo+BDS (GREC) fixed solution enables the highest 3D position accuracy of about 3.0 cm compared to 4.3 cm of the GPS-only solution. Through a real flight experiment over Antarctica, it is also confirmed that POP ambiguity fixing performs better and thus can considerably speed up (re-)convergence and reduce most of the fluctuations in PPP solutions, since the continuous tracking time is short compared to that in other regions. Full article

(This article belongs to the Special Issue Global Navigation Satellite Systems for Earth Observing System)

► Show Figures

Graphical abstract

19 pages, 831 KiB

Open AccessArticle

Increasing Precision for French Forest Inventory Estimates using the k-NN Technique with Optical and Photogrammetric Data and Model-Assisted Estimators

by Dinesh Babu Irulappa-Pillai-Vijayakumar, Jean-Pierre Renaud, François Morneau, Ronald E. McRoberts and Cédric Vega

Remote Sens. 2019, 11(8), 991; https://doi.org/10.3390/rs11080991 - 25 Apr 2019

Cited by 28 | Viewed by 4683

Abstract

Multisource forest inventory methods were developed to improve the precision of national forest inventory estimates. These methods rely on the combination of inventory data and auxiliary information correlated with forest attributes of interest. As these methods have been predominantly tested over coniferous forests, [...] Read more.

Multisource forest inventory methods were developed to improve the precision of national forest inventory estimates. These methods rely on the combination of inventory data and auxiliary information correlated with forest attributes of interest. As these methods have been predominantly tested over coniferous forests, the present study used this approach for heterogeneous and complex deciduous forests in the center of France. The auxiliary data considered included a forest type map, Landsat 8 spectral bands and derived vegetation indexes, and 3D variables derived from photogrammetric canopy height models. On a subset area, changes in canopy height estimated from two successive photogrammetric models were also used. A model-assisted inference framework, using a k nearest-neighbors approach, was used to predict 11 field inventory variables simultaneously. The results showed that among the auxiliary variables tested, 3D metrics improved the precision of dendrometric estimates more than other auxiliary variables. Relative efficiencies (RE) varying from 2.15 for volume to 1.04 for stand density were obtained using all auxiliary variables. Canopy height changes also increased RE from 3% to 26%. Our results confirmed the importance of 3D metrics as auxiliary variables and demonstrated the value of canopy change variables for increasing the precision of estimates of forest structural attributes such as density and quadratic mean diameter. Full article

(This article belongs to the Special Issue Data Fusion for Improved Forest Inventories and Planning)

► Show Figures

Figure 1

18 pages, 4844 KiB

Open AccessArticle

A Novel Spatio-Temporal FCN-LSTM Network for Recognizing Various Crop Types Using Multi-Temporal Radar Images

by Nima Teimouri, Mads Dyrmann and Rasmus Nyholm Jørgensen

Remote Sens. 2019, 11(8), 990; https://doi.org/10.3390/rs11080990 - 25 Apr 2019

Cited by 60 | Viewed by 9118

Abstract

In recent years, analyzing Synthetic Aperture Radar (SAR) data has turned into one of the challenging and interesting topics in remote sensing. Radar sensors are capable of imaging Earth’s surface independently of the weather conditions, local time of day, penetrating of waves through [...] Read more.

In recent years, analyzing Synthetic Aperture Radar (SAR) data has turned into one of the challenging and interesting topics in remote sensing. Radar sensors are capable of imaging Earth’s surface independently of the weather conditions, local time of day, penetrating of waves through clouds, and containing spatial information on agricultural crop types. Based on these characteristics, the main goal sought in this research is to reveal the SAR imaging data capability in recognizing various agricultural crops in the main growth season in a more clarified and detailed way by using a deep-learning-based method. In the present research, the multi-temporal C-band Sentinel 1 images were used to classify 14 major classes of agricultural crops plus background in Denmark. By considering the capability of a deep learning method in analyzing satellite images, a novel, optimal, and lightweight network structure was developed and implemented based on a combination of a fully convolutional network (FCN) and a convolutional long short-term memory (ConvLSTM) network. The average pixel-based accuracy and Intersection over Union obtained from the proposed network were 86% and 0.64, respectively. Winter rapeseed, winter barley, winter wheat, spring barley, and sugar beet had the highest pixel-based accuracies of 95%, 94%, 93%, 90%, and 90%; respectively. The pixel-based accuracies for eight crop types and the background class were more than 84%. The network prediction showed that in field borders the classification confidence was lower than the center regions of the fields. However, the proposed structure has been able to identify different crops in multi-temporal Sentinel 1 data of a large area of around 254 thousand hectares with high performance. Full article

(This article belongs to the Special Issue Time Series Analysis Based on SAR Images)

► Show Figures

Graphical abstract

21 pages, 4645 KiB

Open AccessArticle

Assessment of Different Stochastic Models for Inter-System Bias between GPS and BDS

by Nan Jiang, Tianhe Xu, Yan Xu, Guochang Xu and Harald Schuh

Remote Sens. 2019, 11(8), 989; https://doi.org/10.3390/rs11080989 - 25 Apr 2019

Cited by 18 | Viewed by 3499

Abstract

Inter-system bias (ISB) will affect accuracy and processing time in integrated precise point positioning (PPP), and ISB stochastic models will largely determine the quality of ISB estimation. Thus, the impacts of four different stochastic models of ISB processing will be assessed and studied [...] Read more.

Inter-system bias (ISB) will affect accuracy and processing time in integrated precise point positioning (PPP), and ISB stochastic models will largely determine the quality of ISB estimation. Thus, the impacts of four different stochastic models of ISB processing will be assessed and studied in detail to further reveal the influence of ISB in positioning. They are ISB-PW considering ISB as a piece-wise constant, ISB-RW considering ISB as random walk, ISB-AD considering ISB as an arc-dependent constant, and ISB-WN considering ISB as white noise. Together with the model without introducing ISB called ISB-OFF, i.e., five different schemes, ISB-OFF, ISB-PW, ISB-RW, ISB-AD, and ISB-WN, will be designed and tested in this study. From the results of pseudorange residuals, it can be noticed that when considering ISB, the Root-Mean-Square (RMS) of ionosphere-free combined pseudorange residuals are much smaller than without ISB (ISB-OFF). The results of convergence time and positioning accuracy analysis show that PPP performance with ISB-AD is even worse than ISB-OFF, when using the precise products from the German Research Centre for Geosciences (GFZ) named as GBM products here; while the strategies of ISB-RW, and ISB-WN achieve the best results. For the products from Wuhan University called WUM products, a completely different result is achieved. PPP with the stochastic models of ISB-PW and ISB-AD perform best. The most likely reason is the ISB stochastic models applied by the analysis centers are consistent with those used in the PPP on the user side. So, ISB-RW, or ISB-WN is recommended when GBM products are used, and for the WUM products, ISB-PW, or ISB-AD is chosen. From the statistics of PPP precision during the convergence period, it can be concluded that considering ISB also has a great improvement on combined PPP accuracy during the initialization phase. Full article

(This article belongs to the Special Issue Global Navigation Satellite Systems for Earth Observing System)

► Show Figures

Graphical abstract

27 pages, 7152 KiB

Open AccessArticle

Integration of Corner Reflectors for the Monitoring of Mountain Glacier Areas with Sentinel-1 Time Series

by Matthias Jauvin, Yajing Yan, Emmanuel Trouvé, Bénédicte Fruneau, Michel Gay and Blaise Girard

Remote Sens. 2019, 11(8), 988; https://doi.org/10.3390/rs11080988 - 25 Apr 2019

Cited by 42 | Viewed by 8660

Abstract

Glacier flow and slope instabilities in Alpine mountain areas represent a hazard issue. Sentinel-1 satellites provide regular Synthetic Aperture Radar (SAR) acquisitions that are potentially useful to monitor these areas, but they can be affected by temporal decorrelation due to rapid changes in [...] Read more.

Glacier flow and slope instabilities in Alpine mountain areas represent a hazard issue. Sentinel-1 satellites provide regular Synthetic Aperture Radar (SAR) acquisitions that are potentially useful to monitor these areas, but they can be affected by temporal decorrelation due to rapid changes in the surface. The application of interferometric synthetic aperture radar (InSAR) therefore seems difficult due to loss of coherence. On the other hand, Corner Reflectors (CR) can be used as coherent targets in SAR images for accurate displacement measurement thanks to their strong backscattering property and temporal stability. The use of CRs in multi-temporal InSAR analysis in Alpine mountain areas can thus be beneficial. In this study, we present a comparison between triangular and rectangular CRs, based on Radar Cross Section (RCS) measurements in an anechoic chamber and on long-term experiments over the Argentière glacier and the surrounding slopes and moraine. The visibility in both summer and winter of 10 CRs installed on the test site was investigated. As this area is exposed to heavy precipitation including snow falls, two perforated CRs were tested. The amplitude stability and the phase error of each CR were estimated. A precise tracking of two CRs installed at the glacier surface was also able to measure the displacement of the Argentière glacier, giving results close to previous GPS measurements. Furthermore, a Persistent Scatterer Interferometry (PSI) study was conducted, using the most stable CR as reference point to estimate slope instabilities, which led to the identification of an area corresponding to a tectonic fault called “Faille de l’angle”. The precise absolute locations of the CRs were successfully estimated and PS heights were compared with a LiDAR-based (Light Detection And Ranging) digital elevation model (DEM) and GPS measurements. Full article

(This article belongs to the Section Remote Sensing Image Processing)

► Show Figures

Graphical abstract

17 pages, 9506 KiB

Open AccessArticle

An Improved GrabCut Method Based on a Visual Attention Model for Rare-Earth Ore Mining Area Recognition with High-Resolution Remote Sensing Images

by Yan Peng, Zhaoming Zhang, Guojin He and Mingyue Wei

Remote Sens. 2019, 11(8), 987; https://doi.org/10.3390/rs11080987 - 25 Apr 2019

Cited by 18 | Viewed by 4648

Abstract

An improved GrabCut method based on a visual attention model is proposed to extract rare-earth ore mining area information using high-resolution remote sensing images. The proposed method makes use of advantages of both the visual attention model and GrabCut method, and the visual [...] Read more.

An improved GrabCut method based on a visual attention model is proposed to extract rare-earth ore mining area information using high-resolution remote sensing images. The proposed method makes use of advantages of both the visual attention model and GrabCut method, and the visual attention model was referenced to generate a saliency map as the initial of the GrabCut method instead of manual initialization. Normalized Difference Vegetation Index (NDVI) was designed as a bound term added into the Energy Function of GrabCut to further improve the accuracy of the segmentation result. The proposed approach was employed to extract rare-earth ore mining areas in Dingnan County and Xunwu County, China, using GF-1 (GaoFen No.1 satellite launched by China) and ALOS (Advanced Land Observation Satellite) high-resolution remotely-sensed satellite data, and experimental results showed that FPR (False Positive Rate) and FNR (False Negative Rate) were, respectively, lower than 12.5% and 6.5%, and PA (Pixel Accuracy), MPA (Mean Pixel Accuracy), MIoU (Mean Intersection over Union), and FWIoU (frequency weighted intersection over union) all reached up to 90% in four experiments. Comparison results with traditional classification methods (such as Object-oriented CART (Classification and Regression Tree) and Object-oriented SVM (Support Vector Machine)) indicated the proposed method performed better for object boundary identification. The proposed method could be useful for accurate and automatic information extraction for rare-earth ore mining areas. Full article

(This article belongs to the Special Issue Innovative Remote Sensing for Monitoring and Assessment of Natural Resources)

► Show Figures

Graphical abstract

21 pages, 2670 KiB

Open AccessArticle

Ten Priority Science Gaps in Assessing Climate Data Record Quality

by Joanne Nightingale, Jonathan P.D. Mittaz, Sarah Douglas, Dick Dee, James Ryder, Michael Taylor, Christopher Old, Catherine Dieval, Celine Fouron, Guillaume Duveau and Christopher Merchant

Remote Sens. 2019, 11(8), 986; https://doi.org/10.3390/rs11080986 - 25 Apr 2019

Cited by 18 | Viewed by 6531

Abstract

Decision makers need accessible robust evidence to introduce new policies to mitigate and adapt to climate change. There is an increasing amount of environmental information available to policy makers concerning observations and trends relating to the climate. However, this data is hosted across [...] Read more.

Decision makers need accessible robust evidence to introduce new policies to mitigate and adapt to climate change. There is an increasing amount of environmental information available to policy makers concerning observations and trends relating to the climate. However, this data is hosted across a multitude of websites often with inconsistent metadata and sparse information relating to the quality, accuracy and validity of the data. Subsequently, the task of comparing datasets to decide which is the most appropriate for a certain purpose is very complex and often infeasible. In support of the European Union’s Copernicus Climate Change Service (C3S) mission to provide authoritative information about the past, present and future climate in Europe and the rest of the world, each dataset to be provided through this service must undergo an evaluation of its climate relevance and scientific quality to help with data comparisons. This paper presents the framework for Evaluation and Quality Control (EQC) of climate data products derived from satellite and in situ observations to be catalogued within the C3S Climate Data Store (CDS). The EQC framework will be implemented by C3S as part of their operational quality assurance programme. It builds on past and present international investment in Quality Assurance for Earth Observation initiatives, extensive user requirements gathering exercises, as well as a broad evaluation of over 250 data products and a more in-depth evaluation of a selection of 24 individual data products derived from satellite and in situ observations across the land, ocean and atmosphere Essential Climate Variable (ECV) domains. A prototype Content Management System (CMS) to facilitate the process of collating, evaluating and presenting the quality aspects and status of each data product to data users is also described. The development of the EQC framework has highlighted cross-domain as well as ECV specific science knowledge gaps in relation to addressing the quality of climate data sets derived from satellite and in situ observations. We discuss 10 common priority science knowledge gaps that will require further research investment to ensure all quality aspects of climate data sets can be ascertained and provide users with the range of information necessary to confidently select relevant products for their specific application. Full article

(This article belongs to the Special Issue Assessment of Quality and Usability of Climate Data Records)

► Show Figures

Figure 1

21 pages, 10540 KiB

Open AccessArticle

High Temporal Resolution Monitoring of Suspended Matter Changes from GOCI Measurements in Lake Taihu

by Yifan Xu, Boqiang Qin, Guangwei Zhu, Yunlin Zhang, Kun Shi, Yunmei Li, Yong Shi and Liangang Chen

Remote Sens. 2019, 11(8), 985; https://doi.org/10.3390/rs11080985 - 25 Apr 2019

Cited by 18 | Viewed by 4039

Abstract

The Tiaoxi River is the main source of water for Lake Taihu and can result in plumes in the lake after heavy precipitation events. These plumes have played a crucial role in the water quality changes within the lake. High temporal resolution GOCI [...] Read more.

The Tiaoxi River is the main source of water for Lake Taihu and can result in plumes in the lake after heavy precipitation events. These plumes have played a crucial role in the water quality changes within the lake. High temporal resolution GOCI (Geostationary Ocean Color Imager) data were used to study the spatial distribution of the total suspended matter concentration in Lake Taihu after heavy precipitation events in the Tiaoxi River Basin via an empirical model. The plumes were analyzed after two heavy precipitation events in 2011 and 2013 using 16 GOCI images, which indicated that the Tiaoxi River had a great influence on the spatial distributions of total suspended matter and algal blooms. It was concluded that the main factors affecting the plumes in the Tiaoxi River were precipitation intensity, runoff, and total suspended matter concentration. Human activity, such as sand excavation also played a crucial role in sediment discharge. The results of this study demonstrate that the visualization of GOCI data makes it possible to use remote sensing technology to continuously monitor an inland water environment on an hourly scale, which is of great significance for studying the diffusion and evolution of river plumes. Full article

(This article belongs to the Special Issue Remote Sensing of Inland Waters and Their Catchments)

► Show Figures

Graphical abstract

19 pages, 2886 KiB

Open AccessArticle

GPR Antipersonnel Mine Detection Based on Tensor Robust Principal Analysis

by Xiaoji Song, Tao Liu, Deliang Xiang and Yi Su

Remote Sens. 2019, 11(8), 984; https://doi.org/10.3390/rs11080984 - 24 Apr 2019

Cited by 20 | Viewed by 3839

Abstract

The ground Penetrating Radar (GPR) is a promising remote sensing modality for Antipersonnel Mine (APM) detection. However, detection of the buried APMs are impaired by strong clutter, especially the reflection caused by rough ground surfaces. In this paper, we propose a novel clutter [...] Read more.

The ground Penetrating Radar (GPR) is a promising remote sensing modality for Antipersonnel Mine (APM) detection. However, detection of the buried APMs are impaired by strong clutter, especially the reflection caused by rough ground surfaces. In this paper, we propose a novel clutter suppression method taking advantage of the low-rank and sparse structure in multidimensional data, based on which an efficient target detection can be accomplished. We firstly created a multidimensional image tensor using sub-band GPR images that are computed from the band-pass filtered GPR signals, such that differences of the target response between sub-bands can be captured. Then, exploiting the low-rank and sparse property of the image tensor, we use the recently proposed Tensor Robust Principal Analysis to remove clutter by decomposing the image tensor into three components: a low-rank component containing clutter, a sparse component capturing target response, and noise. Finally, target detection is accomplished by applying thresholds to the extracted target image. Numerical simulations and experiments with different GPR systems are conducted. The results show that the proposed method effectively improves signal-to-clutter ratio by more than 20 dB and yields satisfactory results with high probability of detection and low false alarm rates. Full article

► Show Figures

Figure 1

24 pages, 2598 KiB

Open AccessArticle

Remote Sensing of Pigment Content at a Leaf Scale: Comparison among Some Specular Removal and Specular Resistance Methods

by Yingying Li and Jingfeng Huang

Remote Sens. 2019, 11(8), 983; https://doi.org/10.3390/rs11080983 - 24 Apr 2019

Cited by 63 | Viewed by 3867

Abstract

Leaf pigment content retrieval is negatively affected by specular reflectance. To alleviate this effect, some specific techniques that take specular reflectance or specular effects into account have been proposed. In this study, continuous wavelet transform (CWT) and specific techniques including some vegetation indices [...] Read more.

Leaf pigment content retrieval is negatively affected by specular reflectance. To alleviate this effect, some specific techniques that take specular reflectance or specular effects into account have been proposed. In this study, continuous wavelet transform (CWT) and specific techniques including some vegetation indices (VIs), radiative transfer (RT), and hybrid models, were examined and compared in the nadir and near the mirror-like direction, with a 30° incident zenith angle. Results show that the RT and hybrid models appeared to be ill-posed, and they were not applicable at this high-incident zenith angle (>20°). Most VIs effectively alleviated the specular disturbance in the forward 35° direction, and comparable accuracy was obtained between the two viewing directions. Multiple linear regression (MLR), derivative transformation, and CWT were effective for specular interference alleviation. The MLR-based methods (reflectance, derivatives, etc., as the independent variables and pigment content as the response) generally obtained higher retrieval accuracies than the VIs. With MLR-based methods, the retrieval was more accurate for chlorophylls than for carotenoids. CWT plus MLR (MLR on wavelet coefficients) was the most prominent among all the methods, and it generally obtained the highest accuracy. The results are 2.68 and 0.88 μg/cm² for chlorophylls and carotenoids, respectively, in the nadir direction, and 2.42 and 0.86 μg/cm² in the forward 35° direction, with reflectance or the first derivative input for CWT. In the retrieval, wavelet coefficients at the optimal decomposition scale may achieve a balance in corresponding to fine, and broad absorption features, and the overall reflectance properties. Full article

(This article belongs to the Section Remote Sensing in Agriculture and Vegetation)

► Show Figures

Graphical abstract

12 pages, 2628 KiB

Open AccessArticle

Rapid Mapping of Small-Scale River-Floodplain Environments Using UAV SfM Supports Classical Theory

by Guy J.-P. Schumann, Joseph Muhlhausen and Konstantinos M. Andreadis

Remote Sens. 2019, 11(8), 982; https://doi.org/10.3390/rs11080982 - 24 Apr 2019

Cited by 29 | Viewed by 5540

Abstract

Unmanned Aerial Vehicle (UAV) platforms have rapidly developed as tools for remote mapping at very high spatial resolutions. They have recently gained in popularity in many application fields owing to the versatility of platforms and sensors, ease of deployment, and a steady increase [...] Read more.

Unmanned Aerial Vehicle (UAV) platforms have rapidly developed as tools for remote mapping at very high spatial resolutions. They have recently gained in popularity in many application fields owing to the versatility of platforms and sensors, ease of deployment, and a steady increase in computational power. Obtaining highly detailed topography data over very small scales is one of the more typical application domains. Here, we demonstrate this application using Structure from Motion (SfM) processing over a small river floodplain in Howard County (Maryland, USA). Evaluation of the derived bare-earth terrain model with state-of-the art LiDAR shows a trivial bias of 1.6 cm and a root mean square deviation (RMSD) of 39 cm. We then applied this terrain model to extract floodplain and river cross-section geometries of a small stream, important during high-magnitude urban flash flood events, with the aim to assess its value for floodplain inundation mapping and first order characterization of in-channel hydraulics. Initial findings agree with traditional stream and floodplain classification theory and thus show very promising results for this type of UAV usage. We expect this type of application to gain more momentum in the near future with the ever-growing importance of more detailed data in order to increase resilience to flood risk, especially in urban areas. Full article

(This article belongs to the Special Issue Unmanned Aerial Systems for Surface Hydrology)

► Show Figures

Graphical abstract

23 pages, 5637 KiB

Open AccessArticle

Observing System Experiments with an Arctic Mesoscale Numerical Weather Prediction Model

by Roger Randriamampianina, Harald Schyberg and Máté Mile

Remote Sens. 2019, 11(8), 981; https://doi.org/10.3390/rs11080981 - 24 Apr 2019

Cited by 42 | Viewed by 4372

Abstract

In the Arctic, weather forecasting is one element of risk mitigation, helping operators to have knowledge on weather-related risk in advance through forecasting capabilities at time ranges from a few hours to days ahead. The operational numerical weather prediction is an initial value [...] Read more.

In the Arctic, weather forecasting is one element of risk mitigation, helping operators to have knowledge on weather-related risk in advance through forecasting capabilities at time ranges from a few hours to days ahead. The operational numerical weather prediction is an initial value problem where the forecast quality depends both on the quality of the forecast model itself and on the quality of the specified initial state. The initial states are regularly updated using environmental observations through data assimilation. This paper assesses the impact of observations, which are accessible through the global telecommunication and the EUMETCast dissemination systems on analyses and forecasts of an Arctic limited area AROME (Application of Research to Operations at Mesoscale) model (AROME-Arctic). An assessment through the computation of degrees of freedom for signals on the analysis, the utilization of an energy norm-based approach applied to the forecasts, verifications against observations, and a case study showed similar impacts of the studied observations on the AROME-Arctic analysis and forecast systems. The AROME-Arctic assimilation system showed a relatively high sensitivity to the humidity or humidity-sensitive observations. The more radiance data were assimilated, the lower was the estimated relative sensitivity of the assimilation system to different conventional observations. Data assimilation, at least for surface parameters, is needed to produce accurate forecasts from a few hours up to days ahead over the studied Arctic region. Upper-air conventional observations are not enough to improve the forecasting capability over the AROME-Arctic domain compared to those already produced by the ECMWF (European Centre for Medium-range Weather Forecast). Each added radiance data showed a relatively positive impact on the analyses and forecasts of the AROME-Arctic. The humidity-sensitive microwave (AMSU-B/MHS) radiances, assimilated together with the conventional observations and the Infrared Atmospheric Sounding Interferometer (IASI)-assimilated on top of conventional and microwave radiances produced enough accurate one-day-ahead forecasts of polar low. Full article

(This article belongs to the Special Issue Weather Forecasting and Modeling Using Satellite Data)

► Show Figures

Figure 1

20 pages, 7230 KiB

Open AccessArticle

Particle Swarm Optimization-Based Noise Filtering Algorithm for Photon Cloud Data in Forest Area

by Jiapeng Huang, Yanqiu Xing, Haotian You, Lei Qin, Jing Tian and Jianming Ma

Remote Sens. 2019, 11(8), 980; https://doi.org/10.3390/rs11080980 - 24 Apr 2019

Cited by 37 | Viewed by 4375

Abstract

The Ice, Cloud, and land Elevation Satellite-2 (ICESat-2), which is equipped with the Advanced Topographic Laser Altimeter System (ATLAS), was launched successfully in 15 September 2018. The ATLAS represents a micro-pulse photon-counting laser system, which is expected to provide more comprehensive and scientific [...] Read more.

The Ice, Cloud, and land Elevation Satellite-2 (ICESat-2), which is equipped with the Advanced Topographic Laser Altimeter System (ATLAS), was launched successfully in 15 September 2018. The ATLAS represents a micro-pulse photon-counting laser system, which is expected to provide more comprehensive and scientific data for carbon storage. However, the ATLAS system is sensitive to the background noise, which poses a tremendous challenge to the photon cloud noise filtering. Moreover, the Density Based Spatial Clustering of Applications with Noise (DBSCAN) is a commonly used algorithm for noise removal from the photon cloud but there has not been an in-depth study on its parameter selection yet. This paper presents an automatic photon cloud filtering algorithm based on the Particle Swarm Optimization (PSO) algorithm, which can be used to optimize the two key parameters of the DBSCAN algorithm instead of using the manual parameter adjustment. The Particle Swarm Optimization Density Based Spatial Clustering of Applications with Noise (PSODBSCAN) algorithm was tested at different laser intensities and laser pointing types using the MATLAS dataset of the forests located in Virginia, East Coast, and the West Coast, USA. The results showed that the PSODBSCAN algorithm and the localized statistical algorithm were effective in identifying the background noise and preserving the signal photons in the raw MATLAS data. Namely, the PSODBSCAN achieved the mean F value of 0.9759, and the localized statistical algorithm achieved the mean F value of 0.6978. For both laser pointing types and laser intensities, the proposed algorithm achieved better results than the localized statistical algorithm. Therefore, the PSODBSCAN algorithm could support the MATLAS photon cloud data noise filtering applicably without manually selecting parameters. Full article

(This article belongs to the Special Issue Advances in Active Remote Sensing of Forests)

► Show Figures

Figure 1

20 pages, 13807 KiB

Open AccessArticle

Evaluation of Sentinel-1 and 2 Time Series for Land Cover Classification of Forest–Agriculture Mosaics in Temperate and Tropical Landscapes

by Audrey Mercier, Julie Betbeder, Florent Rumiano, Jacques Baudry, Valéry Gond, Lilian Blanc, Clément Bourgoin, Guillaume Cornu, Carlos Ciudad, Miguel Marchamalo, René Poccard-Chapuis and Laurence Hubert-Moy

Remote Sens. 2019, 11(8), 979; https://doi.org/10.3390/rs11080979 - 24 Apr 2019

Cited by 78 | Viewed by 8477

Abstract

Monitoring forest–agriculture mosaics is crucial for understanding landscape heterogeneity and managing biodiversity. Mapping these mosaics from remotely sensed imagery remains challenging, since ecological gradients from forested to agricultural areas make characterizing vegetation more difficult. The recent synthetic aperture radar (SAR) Sentinel-1 (S-1) and [...] Read more.

Monitoring forest–agriculture mosaics is crucial for understanding landscape heterogeneity and managing biodiversity. Mapping these mosaics from remotely sensed imagery remains challenging, since ecological gradients from forested to agricultural areas make characterizing vegetation more difficult. The recent synthetic aperture radar (SAR) Sentinel-1 (S-1) and optical Sentinel-2 (S-2) time series provide a great opportunity to monitor forest–agriculture mosaics due to their high spatial and temporal resolutions. However, while a few studies have used the temporal resolution of S-2 time series alone to map land cover and land use in cropland and/or forested areas, S-1 time series have not yet been investigated alone for this purpose. The combined use of S-1 & S-2 time series has been assessed for only one or a few land cover classes. In this study, we assessed the potential of S-1 data alone, S-2 data alone, and their combined use for mapping forest–agriculture mosaics over two study areas: a temperate mountainous landscape in the Cantabrian Range (Spain) and a tropical forested landscape in Paragominas (Brazil). Satellite images were classified using an incremental procedure based on an importance rank of the input features. The classifications obtained with S-2 data alone (mean kappa index = 0.59–0.83) were more accurate than those obtained with S-1 data alone (mean kappa index = 0.28–0.72). Accuracy increased when combining S-1 and 2 data (mean kappa index = 0.55–0.85). The method enables defining the number and type of features that discriminate land cover classes in an optimal manner according to the type of landscape considered. The best configuration for the Spanish and Brazilian study areas included 5 and 10 features, respectively, for S-2 data alone and 10 and 20 features, respectively, for S-1 data alone. Short-wave infrared and VV and VH polarizations were key features of S-2 and S-1 data, respectively. In addition, the method enables defining key periods that discriminate land cover classes according to the type of images used. For example, in the Cantabrian Range, winter and summer were key for S-2 time series, while spring and winter were key for S-1 time series. Full article

(This article belongs to the Special Issue Remote Sensing of Tropical Environmental Change)

► Show Figures

Figure 1

23 pages, 14721 KiB

Open AccessArticle

Planet Image-Based Inventorying and Machine Learning-Based Susceptibility Mapping for the Landslides Triggered by the 2018 Mw6.6 Tomakomai, Japan Earthquake

by Xiaoyi Shao, Siyuan Ma, Chong Xu, Pengfei Zhang, Boyu Wen, Yingying Tian, Qing Zhou and Yulong Cui

Remote Sens. 2019, 11(8), 978; https://doi.org/10.3390/rs11080978 - 24 Apr 2019

Cited by 67 | Viewed by 6238

Abstract

The 5 September 2018 (UTC time) Mw6.6 earthquake of Tomakomai, Japan has triggered about 10,000 landslides with high density, causing widespread concern. We attempted to establish a detailed inventory of this slope failure and use proper methods to assess landslide susceptibility in the [...] Read more.

The 5 September 2018 (UTC time) Mw6.6 earthquake of Tomakomai, Japan has triggered about 10,000 landslides with high density, causing widespread concern. We attempted to establish a detailed inventory of this slope failure and use proper methods to assess landslide susceptibility in the entire affected area. To this end we applied the logistic regression (LR) and the support vector machine (SVM) for this study. Based on high-resolution (3 m) optical satellite images (planet image) before and after the earthquake, we delineated 9295 individual landslides triggered by the earthquake, occupying an area of 30.96 km². Ten controlling factors were selected for susceptibility analysis, including elevation, slope angle, aspect, curvature, distances to faults, distances to the epicenter, Peak ground acceleration (PGA), distance to rivers, distances to roads and lithology. Using the LR and SVM, two landslide susceptibility maps were produced for the study area. The results show that in the LR model, the success rate is 84.7% between the landslide susceptibility map and the training dataset, and the prediction rate is 83.9% shown by comparing the test dataset and the landslide susceptibility map. In the SVM model, a success rate of 90.9% exists between the susceptibility map and the test samples, and a prediction rate of 87.1% from comparison of the test dataset and the landslides susceptibility map. In comparison, the performance of the SVM is slightly better than the LR model. Full article

(This article belongs to the Special Issue Remote Sensing of Earthquakes and Earthquake-Triggered Landslides)

► Show Figures

Graphical abstract

21 pages, 7397 KiB

Open AccessArticle

Development of a Snow Depth Estimation Algorithm over China for the FY-3D/MWRI

by Jianwei Yang, Lingmei Jiang, Shengli Wu, Gongxue Wang, Jian Wang and Xiaojing Liu

Remote Sens. 2019, 11(8), 977; https://doi.org/10.3390/rs11080977 - 24 Apr 2019

Cited by 26 | Viewed by 4831

Abstract

Launched on 15 November 2017, China’s FengYun-3D (FY-3D) has taken over prime operational weather service from the aging FengYun-3B (FY-3B). Rather than directly implementing an FY-3B operational snow depth retrieval algorithm on FY-3D, we investigated this and four other well-known snow depth algorithms [...] Read more.

Launched on 15 November 2017, China’s FengYun-3D (FY-3D) has taken over prime operational weather service from the aging FengYun-3B (FY-3B). Rather than directly implementing an FY-3B operational snow depth retrieval algorithm on FY-3D, we investigated this and four other well-known snow depth algorithms with respect to regional uncertainties in China. Applicable to various passive microwave sensors, these four snow depth algorithms are the Environmental and Ecological Science Data Centre of Western China (WESTDC) algorithm, the Advanced Microwave Scanning Radiometer for Earth Observing System (AMSR-E) algorithm, the Chang algorithm, and the Foster algorithm. Among these algorithms, validation results indicate that FY-3B and WESTDC perform better than the others. However, these two algorithms often result in considerable underestimation for deep snowpack (greater than 20 cm), while the other three persistently overestimate snow depth, probably because of their poor representation of snowpack characteristics in China. To overcome the retrieval errors that occur under deep snowpack conditions without sacrificing performance under relatively thin snowpack conditions, we developed an empirical snow depth retrieval algorithm suite for the FY-3D satellite. Independent evaluation using weather station observations in 2014 and 2015 demonstrates that the FY-3D snow depth algorithm’s root mean square error (RMSE) and bias are 6.6 cm and 0.2 cm, respectively, and it has advantages over other similar algorithms. Full article

(This article belongs to the Special Issue Remote Sensing of Environmental Changes in Cold Regions)

► Show Figures

Figure 1

24 pages, 5003 KiB

Open AccessArticle

Modeling Barrier Island Habitats Using Landscape Position Information

by Nicholas M. Enwright, Lei Wang, Hongqing Wang, Michael J. Osland, Laura C. Feher, Sinéad M. Borchert and Richard H. Day

Remote Sens. 2019, 11(8), 976; https://doi.org/10.3390/rs11080976 - 24 Apr 2019

Cited by 30 | Viewed by 4497

Abstract

Barrier islands are dynamic environments because of their position along the marine–estuarine interface. Geomorphology influences habitat distribution on barrier islands by regulating exposure to harsh abiotic conditions. Researchers have identified linkages between habitat and landscape position, such as elevation and distance from shore, [...] Read more.

Barrier islands are dynamic environments because of their position along the marine–estuarine interface. Geomorphology influences habitat distribution on barrier islands by regulating exposure to harsh abiotic conditions. Researchers have identified linkages between habitat and landscape position, such as elevation and distance from shore, yet these linkages have not been fully leveraged to develop predictive models. Our aim was to evaluate the performance of commonly used machine learning algorithms, including K-nearest neighbor, support vector machine, and random forest, for predicting barrier island habitats using landscape position for Dauphin Island, Alabama, USA. Landscape position predictors were extracted from topobathymetric data. Models were developed for three tidal zones: subtidal, intertidal, and supratidal/upland. We used a contemporary habitat map to identify landscape position linkages for habitats, such as beach, dune, woody vegetation, and marsh. Deterministic accuracy, fuzzy accuracy, and hindcasting were used for validation. The random forest algorithm performed best for intertidal and supratidal/upland habitats, while the K-nearest neighbor algorithm performed best for subtidal habitats. A posteriori application of expert rules based on theoretical understanding of barrier island habitats enhanced model results. For the contemporary model, deterministic overall accuracy was nearly 70%, and fuzzy overall accuracy was over 80%. For the hindcast model, deterministic overall accuracy was nearly 80%, and fuzzy overall accuracy was over 90%. We found machine learning algorithms were well-suited for predicting barrier island habitats using landscape position. Our model framework could be coupled with hydrodynamic geomorphologic models for forecasting habitats with accelerated sea-level rise, simulated storms, and restoration actions. Full article

(This article belongs to the Special Issue Applications of RS and GIS Integration in Natural Resources and Environmental Science)

► Show Figures

Graphical abstract

18 pages, 3456 KiB

Open AccessArticle

SPICE-Based SAR Tomography over Forest Areas Using a Small Number of P-Band Airborne F-SAR Images Characterized by Non-Uniformly Distributed Baselines

by Xing Peng, Xinwu Li, Changcheng Wang, Jianjun Zhu, Lei Liang, Haiqiang Fu, Yanan Du, Zefa Yang and Qinghua Xie

Remote Sens. 2019, 11(8), 975; https://doi.org/10.3390/rs11080975 - 23 Apr 2019

Cited by 82 | Viewed by 3692

Abstract

Synthetic aperture radar tomography (TomoSAR) has been proven to be a useful way to reconstruct vertical structure over forest areas with P-band images, on account of its three-dimensional imaging ability. In the case of a small number of non-uniformly distributed acquisitions, compressive sensing [...] Read more.

Synthetic aperture radar tomography (TomoSAR) has been proven to be a useful way to reconstruct vertical structure over forest areas with P-band images, on account of its three-dimensional imaging ability. In the case of a small number of non-uniformly distributed acquisitions, compressive sensing (CS) is generally adopted in TomoSAR. However, the performance of CS depends on the selected hyperparameter, which is closely related to the noise of a pixel. In this paper, to overcome this limitation, we propose a sparse iterative covariance-based estimation (SPICE) approach based on the wavelet and orthogonal sparse basis (W&O-SPICE) for application over forest areas. SPICE is a sparse spectral estimation method that achieves a high vertical resolution, and takes account of the noise adaptively for each resolution cell. Thus, it does not require the user to select a hyperparameter. Furthermore, the used sparse basis not only ensures the sparsity of the forest canopy scattering contribution, but it can also keep the original sparse information of the ground contribution. The proposed method was tested in simulated experiments and the results demonstrated that W&O-SPICE can successfully reconstruct the vertical structure of a forest. Moreover, three P-band fully polarimetric airborne SAR images with non-uniformly distributed baselines were applied to reconstruct the vertical structure of a tropical forest in Mabounie, Gabon. The underlying topography and forest height were estimated, and the root-mean-square errors (RMSEs) were 6.40 m and 4.50 m with respect to the LiDAR digital terrain model (DTM) and canopy height model (CHM), respectively. In addition, W&O-SPICE showed a better performance than W&O-CS, beamforming, Capon, and the iterative adaptive approach (IAA). Full article

(This article belongs to the Section Forest Remote Sensing)

► Show Figures

Graphical abstract

18 pages, 6174 KiB

Open AccessArticle

A New Integrated Vegetation Index for the Estimation of Winter Wheat Leaf Chlorophyll Content

by Bei Cui, Qianjun Zhao, Wenjiang Huang, Xiaoyu Song, Huichun Ye and Xianfeng Zhou

Remote Sens. 2019, 11(8), 974; https://doi.org/10.3390/rs11080974 - 23 Apr 2019

Cited by 62 | Viewed by 10660

Abstract

Leaf chlorophyll content (LCC) provides valuable information about the nutrition and photosynthesis statuses of crops. Vegetation index-based methods have been widely used in crop management studies for the non-destructive estimation of LCC using remote sensing technology. However, many published vegetation indices are sensitive [...] Read more.

Leaf chlorophyll content (LCC) provides valuable information about the nutrition and photosynthesis statuses of crops. Vegetation index-based methods have been widely used in crop management studies for the non-destructive estimation of LCC using remote sensing technology. However, many published vegetation indices are sensitive to crop canopy structure, especially the leaf area index (LAI), when crop canopy spectra are used. Herein, to address this issue, we propose four new spectral indices (The red-edge-chlorophyll absorption index (RECAI), the red-edge-chlorophyll absorption index/optimized soil-adjusted vegetation index (RECAI/OSAVI), the red-edge-chlorophyll absorption index/ the triangular vegetation index (RECAI/TVI), and the red-edge-chlorophyll absorption index/the modified triangular vegetation index(RECAI/MTVI2)) and evaluate their performance for LCC retrieval by comparing their results with those of eight published spectral indices that are commonly used to estimate LCC. A total of 456 winter wheat canopy spectral data corresponding to physiological parameters in a wide range of species, growth stages, stress treatments, and growing seasons were collected. Five regression models (linear, power, exponential, polynomial, and logarithmic) were built to estimate LCC in this study. The results indicated that the newly proposed integrated RECAI/TVI exhibited the highest LCC predictive accuracy among all indices, where R² values increased by more than 13.09% and RMSE values reduced by more than 6.22%. While this index exhibited the best association with LCC (0.708** ≤ r ≤ 0.819**) among all indices, RECAI/TVI exhibited no significant relationship with LAI (0.029 ≤ r ≤ 0.167), making it largely insensitive to LAI changes. In terms of the effects of different field management measures, the LCC predictive accuracy by RECAI/TVI can be influenced by erective winter wheat varieties, low N fertilizer application density, no water application, and early sowing dates. In general, the newly developed integrated RECAI/TVI was sensitive to winter wheat LCC with a reduction in the influence of LAI. This index has strong potential for monitoring winter wheat nitrogen status and precision nitrogen management. However, further studies are required to test this index with more diverse datasets and different crops. Full article

(This article belongs to the Special Issue Remote Sensing for Precision Nitrogen Management)

► Show Figures

Figure 1

21 pages, 11441 KiB

Open AccessArticle

Impact of Assimilating China Precipitation Analysis Data Merging with Remote Sensing Products Using the 4DVar Method on the Prediction of Heavy Rainfall

by Yuanbing Wang, Yaodeng Chen and Jinzhong Min

Remote Sens. 2019, 11(8), 973; https://doi.org/10.3390/rs11080973 - 23 Apr 2019

Cited by 29 | Viewed by 3290

Abstract

In this study, the China Hourly Merged Precipitation Analysis (CHMPA) data which combines the satellite-retrieved Climate Prediction Center Morphing (CMORPH) with the automatic weather station precipitation observations is firstly assimilated into the Weather Research and Forecasting (WRF) model using the Four-Dimensional Variational (4DVar) [...] Read more.

In this study, the China Hourly Merged Precipitation Analysis (CHMPA) data which combines the satellite-retrieved Climate Prediction Center Morphing (CMORPH) with the automatic weather station precipitation observations is firstly assimilated into the Weather Research and Forecasting (WRF) model using the Four-Dimensional Variational (4DVar) method. The analyses and subsequent forecasts of heavy rainfall during Meiyu season occurred in July 2013 over eastern China is evaluated. Besides, the sensitivity of rainfall forecast skill of assimilating the CHMPA data to the rainfall error, the rainfall thinning distance, and the rainfall accumulation time within assimilation window are investigated in this study. Then, the impact of 4DVar data assimilation with and without CHMPA rainfall data is evaluated to show how the assimilation of CHMPA impacts the precipitation simulations. It is found that assimilation of the CHMPA data helps to produce a better short-range precipitation forecast in this study. The rainfall fields after assimilation of CHMPA is closer to observations in terms of quantity and pattern. However, the leading time of improved forecast is limited to about 18 hours. It is also found that CHMPA data assimilation produces stronger realistic moisture divergence, precipitabale water field and the vertical wind field in the forecasting fields, which eventually contributes to the improved forecast of heavy rainfall. This study can provide references for the assimilation of CHMPA data into the WRF model using 4DVar, which is valuable for limited-area numerical weather prediction and hydrological applications. Full article

(This article belongs to the Section Atmospheric Remote Sensing)

► Show Figures

Figure 1

17 pages, 3467 KiB

Open AccessArticle

Determination of Bathing Water Quality Using Thermal Images Landsat 8 on the West Coast of Tangier: Preliminary Results

by El Khalil Cherif, Farida Salmoun and Francisco Javier Mesas-Carrascosa

Remote Sens. 2019, 11(8), 972; https://doi.org/10.3390/rs11080972 - 23 Apr 2019

Cited by 24 | Viewed by 5480

Abstract

Bathing water quality has been monitored in the west coast of Tangier, Morocco due to increased urban and industrial discharge through the Boukhalef river, using in-situ bacteriological measurements which demand high economical and temporal costs. In this study, Landsat 8 Thermal Infrared Sensor [...] Read more.

Bathing water quality has been monitored in the west coast of Tangier, Morocco due to increased urban and industrial discharge through the Boukhalef river, using in-situ bacteriological measurements which demand high economical and temporal costs. In this study, Landsat 8 Thermal Infrared Sensor (TIRS) images were used as an alternative to the classical method, for determining bathing water quality to help decision makers obtain up-to-date and cost-effective information for coastal environment protection. For this purpose, during spring and summer 2017, seven sampling points were examined in terms of bacteriological parameters: Total Coliforms (TC), Faecal Coliforms (FC), Intestinal Enterococci (IE) and Escherichia coli (E. coli). Also, a spatial-temporal analysis was performed in this temporal window to detect temperature anomalies and their spatial distribution along the coastal bathing area. In addition, a relationship between in-situ bacteriological parameter measurements and temperature from satellite images was analyzed. The results of the water temperature distribution showed the highest values next to the Boukhalef river mouth, as well as the poorest water quality according to in-situ measurements, while lower values and better water quality status were observed moving away from the Boukhalef river mouth. The relationship between water temperature and bacterial concentration showed a high correlation coefficient (R² = 0.85). Consequently, the model development approaches used may be useful in estimating bacterial concentration in coastal bathing areas and can serve to create a monitoring system to support decision makers in the protection actions of the coast. Full article

► Show Figures

Graphical abstract

14 pages, 2656 KiB

Open AccessArticle

Heat and Drought Stress Advanced Global Wheat Harvest Timing from 1981–2014

by Shilong Ren, Qiming Qin, Huazhong Ren, Juan Sui and Yao Zhang

Remote Sens. 2019, 11(8), 971; https://doi.org/10.3390/rs11080971 - 23 Apr 2019

Cited by 10 | Viewed by 4466

Abstract

Studying wheat phenology can greatly enhance our understanding of how wheat growth responds to climate change, and guide us to reasonably confront its influence. However, comprehensive global-scale wheat phenology–climate analysis is still lacking. In this study, we extracted the wheat harvest date (WHD) [...] Read more.

Studying wheat phenology can greatly enhance our understanding of how wheat growth responds to climate change, and guide us to reasonably confront its influence. However, comprehensive global-scale wheat phenology–climate analysis is still lacking. In this study, we extracted the wheat harvest date (WHD) from 1981–2014 from satellite data using threshold-, logistic-, and shape-based methods. Then, we analyzed the effects of heat and drought stress on WHD based on gridded daily temperature and monthly drought data (the Palmer drought severity index (PDSI) and the standardized precipitation evapotranspiration index (SPEI)) over global wheat-growing areas. The results show that WHD was generally delayed from the low to mid latitudes. With respect to variation trends, we detected a significant advancement of WHD in 32.1% of the world’s wheat-growing areas since 1981, with an average changing rate of −0.25 days/yr. A significant negative correlation was identified between WHD and the prior three months’ normal-growing-degree-days across 50.4% of the study region, which implies that greater preseason effective temperature accumulation may cause WHD to occur earlier. Meanwhile, WHD was also found to be significantly and negatively correlated with the prior three months’ extreme-growing-degree-days across only 9.6% of the study region (mainly located in northern South Asia and north Central-West Asia). The effects of extreme heat stress were weaker than those of normal thermal conditions. When extreme drought (measured by PDSI/SPEI) occurred in the current month, in the month prior to WHD, and in the second month prior to WHD, it forced WHD to advance by about 9.0/8.1 days, 13.8/12.2 days, and 10.8/5.3 days compared to normal conditions, respectively. In conclusion, we highlight the effects that heat and drought stress have on advancing wheat harvest timing, which should be a research focus under future climate change. Full article

(This article belongs to the Special Issue Monitoring Vegetation Phenology: Trends and Anomalies)

► Show Figures

Figure 1

17 pages, 1648 KiB

Open AccessArticle

Multiple Flights or Single Flight Instrument Fusion of Hyperspectral and ALS Data? A Comparison of their Performance for Vegetation Mapping

by Łukasz Sławik, Jan Niedzielko, Adam Kania, Hubert Piórkowski and Dominik Kopeć

Remote Sens. 2019, 11(8), 970; https://doi.org/10.3390/rs11080970 - 23 Apr 2019

Cited by 27 | Viewed by 4330

Abstract

Fusion of remote sensing data often improves vegetation mapping, compared to using data from only a single source. The effectiveness of this fusion is subject to many factors, including the type of data, collection method, and purpose of the analysis. In this study, [...] Read more.

Fusion of remote sensing data often improves vegetation mapping, compared to using data from only a single source. The effectiveness of this fusion is subject to many factors, including the type of data, collection method, and purpose of the analysis. In this study, we compare the usefulness of hyperspectral (HS) and Airborne Laser System (ALS) data fusion acquired in separate flights, Multiple Flights Data Fusion (MFDF), and during a single flight through Instrument Fusion (IF) for the classification of non-forest vegetation. An area of 6.75 km² was selected, where hyperspectral and ALS data was collected during two flights in 2015 and one flight in 2017. This data was used to classify three non-forest Natura 2000 habitats i.e., Xeric sand calcareous grasslands (code 6120), alluvial meadows of river valleys of the Cnidion dubii (code 6440), species-rich Nardus grasslands (code 6230) using a Random Forest classifier. Our findings show that it is not possible to determine which sensor, HS, or ALS used independently leads to a higher classification accuracy for investigated Natura 2000 habitats. Concurrently, increased stability and consistency of classification results was confirmed, regardless of the type of fusion used; IF, MFDF and varied information relevance of single sensor data. The research shows that the manner of data collection, using MFDF or IF, does not determine the level of relevance of ALS or HS data. The analysis of fusion effectiveness, gauged as the accuracy of the classification result and time consumed for data collection, has shown a superiority of IF over MFDF. IF delivered classification results that are more accurate compared to MFDF. IF is always cheaper than MFDF and the difference in effectiveness of both methods becomes more pronounced when the area of aerial data collection becomes larger. Full article

► Show Figures

Graphical abstract

16 pages, 5915 KiB

Open AccessArticle

Dam Leakage Detection by Borehole Radar: A Case-History Study

by Sixin Liu, Xudong Wang, Qi Lu, Honqing Li, Yuanxin Wang and Li Deng

Remote Sens. 2019, 11(8), 969; https://doi.org/10.3390/rs11080969 - 23 Apr 2019

Cited by 14 | Viewed by 5549

Abstract

A borehole radar investigation was performed at the Sanzuodian reservoir, Chifeng, China to assess possible leakage paths located in the deep dam foundation. The key methodologies used include both single-hole reflection and cross-hole radar tomography, which make a high-resolution identification of the hydraulic [...] Read more.

A borehole radar investigation was performed at the Sanzuodian reservoir, Chifeng, China to assess possible leakage paths located in the deep dam foundation. The key methodologies used include both single-hole reflection and cross-hole radar tomography, which make a high-resolution identification of the hydraulic connection paths between upstream and downstream sides possible. The leakage paths are characterized by direct wave loss due to high electromagnetic attenuation in the single-hole reflection profile and the nearly horizontal-banded low-velocity zone in the cross-hole velocity tomography due to possible large internal erosion. Meanwhile, some small structures inside the dam, including the core wall thickness changing point, the connecting point between asphalt and concrete walls, and the contacting interface between the dry and the water-saturated formations can be identified from the single-hole reflection profile clearly. Interpreted leakage paths are proven by the water flow measurement. Borehole radar is a useful high-resolution tool, suitable for deep leakage detection and evaluation. Full article

(This article belongs to the Special Issue Recent Progress in Ground Penetrating Radar Remote Sensing)

► Show Figures

Graphical abstract

24 pages, 12161 KiB

Open AccessArticle

Potential of High-Resolution Pléiades Imagery to Monitor Salt Marsh Evolution After Spartina Invasion

by Bárbara Proença, Frédéric Frappart, Bertrand Lubac, Vincent Marieu, Bertrand Ygorra, Lionel Bombrun, Richard Michalet and Aldo Sottolichio

Remote Sens. 2019, 11(8), 968; https://doi.org/10.3390/rs11080968 - 23 Apr 2019

Cited by 26 | Viewed by 4773

Abstract

An early assessment of biological invasions is important for initiating conservation strategies. Instrumental progress in high spatial resolution (HSR) multispectral satellite sensors greatly facilitates ecosystems’ monitoring capability at an increasingly smaller scale. However, species detection is still challenging in environments characterized by a [...] Read more.

An early assessment of biological invasions is important for initiating conservation strategies. Instrumental progress in high spatial resolution (HSR) multispectral satellite sensors greatly facilitates ecosystems’ monitoring capability at an increasingly smaller scale. However, species detection is still challenging in environments characterized by a high variability of vegetation mixing along with other elements, such as water, sediment, and biofilm. In this study, we explore the potential of Pléiades HSR multispectral images to detect and monitor changes in the salt marshes of the Bay of Arcachon (SW France), after the invasion of Spartina anglica. Due to the small size of Spartina patches, the spatial and temporal monitoring of Spartina species focuses on the analysis of five multispectral images at a spatial resolution of 2 m, acquired at the study site between 2013 and 2017. To distinguish between the different types of vegetation, various techniques for land use classification were evaluated. A description and interpretation of the results are based on a set of ground truth data, including field reflectance, a drone flight, historical aerial photographs, GNSS and photographic surveys. A preliminary qualitative analysis of NDVI maps showed that a multi-temporal approach, taking into account a delayed development of species, could be successfully used to discriminate Spartina species (sp.). Then, supervised and unsupervised classifications, used for the identification of Spartina sp., were evaluated. The performance of the species identification was highly dependent on the degree of environmental noise present in the image, which is season-dependent. The accurate identification of the native Spartina was higher than 75%, a result strongly affected by intra-patch variability and, specifically, by the presence of areas with a low vegetation density. Further, for the invasive Spartina anglica, when using a supervised classifier, rather than an unsupervised one, the accuracy of the classification increases from 10% to 90%. However, both algorithms highly overestimate the areas assigned to this species. Finally, the results highlight that the identification of the invasive species is highly dependent both on the seasonal presence of itinerant biological features and the size of vegetation patches. Further, we believe that the results could be strongly improved by a coupled approach, which combines spectral and spatial information, i.e., pattern-recognition techniques. Full article

(This article belongs to the Special Issue Remote Sensing of Estuarine, Lagoon and Delta Environments)

► Show Figures

Graphical abstract

23 pages, 5091 KiB

Open AccessArticle

SPA-Based Methods for the Quantitative Estimation of the Soil Salt Content in Saline-Alkali Land from Field Spectroscopy Data: A Case Study from the Yellow River Irrigation Regions

by Sijia Wang, Yunhao Chen, Mingguo Wang, Yifei Zhao and Jing Li

Remote Sens. 2019, 11(8), 967; https://doi.org/10.3390/rs11080967 - 23 Apr 2019

Cited by 31 | Viewed by 4477

Abstract

The problem of soil salinization has always been a global problem involving resource, environmental, and ecological issues, and is closely related to the sustainable development of the social economy. Remote sensing provides an effective technical means for soil salinity identification and quantification research. [...] Read more.

The problem of soil salinization has always been a global problem involving resource, environmental, and ecological issues, and is closely related to the sustainable development of the social economy. Remote sensing provides an effective technical means for soil salinity identification and quantification research. This study focused on the estimation of the soil salt content in saline-alkali soils and applied the Successive Projections Algorithm (SPA) method to the estimation model; twelve spectral forms were applied in the estimation model of the spectra and soil salt content. Regression modeling was performed using the Partial Least Squares Regression (PLSR) method. Proximal-field spectral measurements data and soil samples were collected in the Yellow River Irrigation regions of Shizuishan City. A total of 60 samples were collected. The results showed that application of the SPA method improved the modeled determination coefficient (R²) and the ratio of performance to deviation (RPD), and reduced the modeled root mean square error (RMSE) and the percentage root mean square error (RMSE%); the maximum value of R² increased by 0.22, the maximum value of RPD increased by 0.97, the maximum value of the RMSE decreased by 0.098 and the maximum value of the RMSE% decreased by 8.52%. The SPA–PLSR model, based on the first derivative of reflectivity (FD), the FD–SPA–PLSR model, showed the best results, with an R² value of 0.89, an RPD value of 2.72, an RMSE value of 0.177, and RMSE% value of 11.81%. The results of this study demonstrated the applicability of the SPA method in the estimation of soil salinity, by using field spectroscopy data. The study provided a reference for a subsequent study of the hyperspectral estimation of soil salinity, and the proximal sensing data from a low distance, in this study, could provide detailed data for use in future remote sensing studies. Full article

(This article belongs to the Special Issue Applications of Spectroscopy in Agriculture and Vegetation Research)

► Show Figures

Figure 1

14 pages, 3536 KiB

Open AccessArticle

Neural Network Approach to Forecast Hourly Intense Rainfall Using GNSS Precipitable Water Vapor and Meteorological Sensors

by Pedro Benevides, Joao Catalao and Giovanni Nico

Remote Sens. 2019, 11(8), 966; https://doi.org/10.3390/rs11080966 - 23 Apr 2019

Cited by 64 | Viewed by 5681

Abstract

This work presents a methodology for the short-term forecast of intense rainfall based on a neural network and the integration of Global Navigation and Positioning System (GNSS) and meteorological data. Precipitable water vapor (PWV) derived from GNSS is combined with surface pressure, surface [...] Read more.

This work presents a methodology for the short-term forecast of intense rainfall based on a neural network and the integration of Global Navigation and Positioning System (GNSS) and meteorological data. Precipitable water vapor (PWV) derived from GNSS is combined with surface pressure, surface temperature and relative humidity obtained continuously from a ground-based meteorological station. Five years of GNSS data from one station in Lisbon, Portugal, are processed. Data for precipitation forecast are also collected from the meteorological station. Spaceborne Spinning Enhanced Visible and Infrared Imager (SEVIRI) data of cloud top measurements are also gathered, providing collocated information on an hourly basis. In previous studies it was found that the time-varying PWV is correlated with rainfall and can be used to detected heavy rain. However, a significant number of false positives were found, meaning that the evolution of PWV does not contain enough information to infer future rain. In this work, a nonlinear autoregressive exogenous neural network model (NARX) is used to process the GNSS and meteorological data to forecast the hourly precipitation. The proposed methodology improves the detection of intense rainfall events and reduces the number of false positives, with a good classification score varying from 63% up to 72% and a false positive rate of 36% down to 21%, for the tested years in the dataset. A score of 64% for intense rain events classification with 22% false positive rate is obtained for the most recent years. The method also achieves an almost 100% hit rate for the rain vs no rain detection, with close to no false alarms. Full article

(This article belongs to the Special Issue GPS/GNSS Contemporary Applications)

► Show Figures

Graphical abstract

17 pages, 4899 KiB

Open AccessFeature PaperArticle

Bounding Surfaces in a Barchan Dune: Annual Cycles of Deposition? Seasonality or Erosion by Superimposed Bedforms?

by Charles S. Bristow

Remote Sens. 2019, 11(8), 965; https://doi.org/10.3390/rs11080965 - 23 Apr 2019

Cited by 23 | Viewed by 5340

Abstract

A barchan dune near Tarfaya in Morocco has been surveyed using ground-penetrating radar (GPR) revealing packages of dipping strata within the dune that are truncated by bounding surfaces. The bounding surfaces dip in the downwind direction, truncate sets of cross-stratification, and are themselves [...] Read more.

A barchan dune near Tarfaya in Morocco has been surveyed using ground-penetrating radar (GPR) revealing packages of dipping strata within the dune that are truncated by bounding surfaces. The bounding surfaces dip in the downwind direction, truncate sets of cross-stratification, and are themselves downlapped by dipping strata. Models of aeolian strata suggest that the bounding surfaces could be reactivation surfaces, an erosion surface formed when a dune is reshaped by a change in wind. Alternatively, they could be superposition surfaces formed by smaller bedforms migration over the dune surface. These two hypotheses are tested using a combination of field and satellite observations. The average annual migration rate for the barchan dune derived from satellite images, gives an annual migration rate of 21.4 m·yr⁻¹. The number of reactivation surfaces imaged within the dune by GPR appears to scale with the annual migrating rate and dune turnover time suggesting that at this location, annual cycles in the wind regime are a potential control on dune stratigraphy with reactivation surfaces generated by changes in the wind direction, including wind reversals in the winter months. Alternatively, it is hypothesized that erosion in the lee of small superimposed bedforms as they pass the dune crest and approach the brink at the top of the slipface will create superposition surfaces. The migration rate of superimposed bedforms with a wavelength of 20 m has been measured at 2 m·day⁻¹. This suggests that small superimposed bedforms will arrive at the dune crest approximately every 10 days. Thus, bounding surface created by erosion in the lee of superimposed dunes will be very common. Given that the turnover time of the barchan dune is estimated at 4.3 years, the number of superposition surfaces produced by the faster bedforms could be more than 100. The number of bounding surface imaged by a GPR profile along the length of the dune appears to support the wind-driven reactivation hypothesis. However, a GPR profile across the dune images many small trough sets, instead of a single slipface, suggesting that superimposed dunes play an important role in the stratigraphy of a relatively simple barchan dune. Full article

(This article belongs to the Special Issue Remote Sensing in Support of Aeolian Research)

► Show Figures

Graphical abstract

16 pages, 5696 KiB

Open AccessArticle

Increase of Atmospheric Methane Observed from Space-Borne and Ground-Based Measurements

by Mingmin Zou, Xiaozhen Xiong, Zhaohua Wu, Shenshen Li, Ying Zhang and Liangfu Chen

Remote Sens. 2019, 11(8), 964; https://doi.org/10.3390/rs11080964 - 23 Apr 2019

Cited by 15 | Viewed by 6350

Abstract

It has been found that the concentration of atmospheric methane (CH₄) has rapidly increased since 2007 after a decade of nearly constant concentration in the atmosphere. As an important greenhouse gas, such an increase could enhance the threat of global warming. [...] Read more.

It has been found that the concentration of atmospheric methane (CH₄) has rapidly increased since 2007 after a decade of nearly constant concentration in the atmosphere. As an important greenhouse gas, such an increase could enhance the threat of global warming. To better quantify this increasing trend, a novel statistic method, i.e. the Ensemble Empirical Mode Decomposition (EEMD) method, was used to analyze the CH₄ trends from three different measurements: the mid–upper tropospheric CH₄ (MUT) from the space-borne measurements by the Atmospheric Infrared Sounder (AIRS), the CH₄ in the marine boundary layer (MBL) from NOAA ground-based in-situ measurements, and the column-averaged CH₄ in the atmosphere (X_CH4) from the ground-based up-looking Fourier Transform Spectrometers at Total Carbon Column Observing Network (TCCON) and the Network for the Detection of Atmospheric Composition Change (NDACC). Comparison of the CH₄ trends in the mid–upper troposphere, lower troposphere, and the column average from these three data sets shows that, overall, these trends agree well in capturing the abrupt CH₄ increase in 2007 (the first peak) and an even faster increase after 2013 (the second peak) over the globe. The increased rates of CH₄ in the MUT, as observed by AIRS, are overall smaller than CH₄ in MBL and the column-average CH₄. During 2009–2011, there was a dip in the increase rate for CH₄ in MBL, and the MUT-CH₄ increase rate was almost negligible in the mid-high latitude regions. The increase of the column-average CH₄ also reached the minimum during 2009–2011 accordingly, suggesting that the trends of CH₄ are not only impacted by the surface emission, however that they also may be impacted by other processes like transport and chemical reaction loss associated with [OH]. One advantage of the EEMD analysis is to derive the monthly rate and the results show that the frequency of the variability of CH₄ increase rates in the mid–high northern latitude regions is larger than those in the tropics and southern hemisphere. Full article

(This article belongs to the Special Issue Remote Sensing of Carbon Dioxide and Methane in Earth’s Atmosphere)

► Show Figures

Graphical abstract

18 pages, 2162 KiB

Open AccessArticle

Spectral-Spatial Attention Networks for Hyperspectral Image Classification

by Xiaoguang Mei, Erting Pan, Yong Ma, Xiaobing Dai, Jun Huang, Fan Fan, Qinglei Du, Hong Zheng and Jiayi Ma

Remote Sens. 2019, 11(8), 963; https://doi.org/10.3390/rs11080963 - 23 Apr 2019

Cited by 209 | Viewed by 13984

Abstract

Many deep learning models, such as convolutional neural network (CNN) and recurrent neural network (RNN), have been successfully applied to extracting deep features for hyperspectral tasks. Hyperspectral image classification allows distinguishing the characterization of land covers by utilizing their abundant information. Motivated by [...] Read more.

Many deep learning models, such as convolutional neural network (CNN) and recurrent neural network (RNN), have been successfully applied to extracting deep features for hyperspectral tasks. Hyperspectral image classification allows distinguishing the characterization of land covers by utilizing their abundant information. Motivated by the attention mechanism of the human visual system, in this study, we propose a spectral-spatial attention network for hyperspectral image classification. In our method, RNN with attention can learn inner spectral correlations within a continuous spectrum, while CNN with attention is designed to focus on saliency features and spatial relevance between neighboring pixels in the spatial dimension. Experimental results demonstrate that our method can fully utilize the spectral and spatial information to obtain competitive performance. Full article

(This article belongs to the Special Issue Robust Multispectral/Hyperspectral Image Analysis and Classification)

► Show Figures

Graphical abstract

Journal Menu

Journal Browser

Remote Sens., Volume 11, Issue 8 (April-2 2019) – 102 articles

Further Information

Guidelines

MDPI Initiatives

Follow MDPI
