A 3D Faraday Shield for Interdigitated Dielectrometry Sensors and Its Effect on Capacitance
Abstract
:1. Introduction
2. Materials and Methods
2.1. Theoretical Approach via Green’s Function
2.2. Experimental Setup and Used IDS
3. Results
3.1. Capacitance with Shield Distance
3.2. Choosing a Shield Distance
3.3. Difference Between Experiment and Theory
3.4. Validation Test of Shield’s Impact on Noise Reduction
4. Summary and Conclusions
Acknowledgments
Author Contributions
Conflicts of Interest
References
