Search Results (27)

Accurate short-term wave forecasting is critical for the safe and efficient operation of marine structures that rely on real-time, phase-resolved ocean wave information for control and monitoring purposes (e.g., digital twins). These systems often depend on environmental sensors (e.g., waverider buoys, wave-sensing LIDAR). Challenges arise when upstream sensor data are missing, sparse, or phase-shifted due to drift. This study investigates the performance of two machine learning models, time-series dense encoder (TiDE) and long short-term memory (LSTM), for forecasting phase-resolved ocean surface elevations under varying degrees of data degradation. We introduce the $\tau$-trimming algorithm, which adapts the prediction horizon based on uncertainty thresholds derived from historical forecasts. Numerical wave tank (NWT) and wave basin experiments are used to benchmark model performance under short- and long-term data masking, spatially coarse sensor grids, and upstream phase shifts. Results show under a 50% probability of upstream data loss, the $\tau$-trimmed TiDE model achieves a 46% reduction in error at the most upstream target, compared to 22% for LSTM. Furthermore, phase misalignment in upstream data introduces a near-linear increase in forecast error. Under moderate model settings, a ±3 s misalignment increases the mean absolute error by approximately 0.5 m, while the same error is accumulated at ±4 s using the more conservative approach. These findings inform the design of resilient, uncertainty-aware wave forecasting systems suited for realistic offshore sensing environments. Full article

This study evaluates the measurement uncertainty of the wave buoy calibration device using a vertical lifting method to ensure the accuracy and reliability of wave buoy measurements for marine research. The calibration device employs a linear motor-driven vertical displacement system, integrating a standard steel tape for wave height measurement and a photoelectric switch-based time calibration module for wave period verification. To address the limitations of traditional instruments, the device utilizes a 0.1 mm laser beam and image processing software to enhance the resolution of the standard steel tape, reducing the smallest division measurement from 1 mm to 0.1 mm. Additionally, a high-precision time calibration method synchronizes the time of the motor’s upper computer software and a frequency meter, minimizing indication error. Key uncertainty sources, including repeatability, environmental temperature effects, and the smallest division measure of instrument, were systematically analyzed. Results demonstrate that the extended measurement uncertainty (k = 2) for wave heights of 0.03 m and 40 m are 0.058 mm and 1.088 mm, respectively, while the uncertainty for a 30 s wave period is 3 ms. These values meet the stringent accuracy requirements (0.5% of measured values) for calibrating advanced wave buoys like the Directional Waverider 4. The proposed device provides a robust solution for validating wave buoy performance, offering significant practical value for oceanographic studies and coastal engineering applications. Full article

The integrated design of waverider forebodies and inlets is considered a critical challenge in high Mach number vehicle development. To facilitate the rapid construction of integrated geometrical models for waverider forebodies and inlets during the conceptual design phase, a method based on discrete point cloud reconstruction has been proposed. In this method, the geometries of the waverider body and inlet are used as inputs and decomposed into the point cloud under discrete rules. This point cloud is refitted to generate new section lines, which are then lofted into an integrated shape under the constraints of guide curves. By modifying the coordinates of the point cloud positions, the geometric configuration of the integrated shape can be rapidly adjusted, providing initial support for subsequent aerodynamic optimization and thermal protection. Using this method, an integrated approach was applied to a waverider forebody and inward-turning inlet in a tandem configuration. This achieved body-inlet matching and integration, resulting in a 15.6% improvement in the inlet’s total pressure recovery coefficient. The integration time was reduced to just 3.18% of the time required for traditional manual adjustments. Additionally, optimization based on the discrete point cloud enhanced the lift-to-drag ratio by 7.83%, demonstrating the feasibility of the proposed method. Full article

This work investigates the aerodynamic performance of a hypersonic waverider designed to operate at Mach 7, focusing on optimizing its design through advanced computational methods. Utilizing the Direct Simulation Monte Carlo (DSMC) method, the three-dimensional flow field around the specifically designed waverider was simulated to understand the shock wave interactions and thermal dynamics at an altitude of 90 km. The computational approach included detailed meshing around the vehicle’s critical leading edges and the use of three-dimensional iso-surfaces of the Q-criterion to map out the shock and vortex structures accurately. Additional simulation results demonstrate that the waverider achieved a lift–drag ratio of 2.18, confirming efficient aerodynamic performance at a zero-degree angle of attack. The study’s findings contribute to the broader understanding of hypersonic flight dynamics, highlighting the importance of precise computational modeling in developing vehicles capable of operating effectively in near-space environments. Full article

This paper proposes a fixed-time backstepping control method based on a disturbance observer for a hypersonic morphing waverider (HMW). Firstly, considering the disturbance of attitude channels, a dynamic model of a variable-span-wing HMW considering additional forces and moments is established, and an aerodynamic model of the aircraft is constructed using the polynomial fitting method. Secondly, the fixed-time stability theory and backstepping control method are combined to design an HMW fixed-time attitude controller. Based on the fixed-time convergence theory, a fixed-time disturbance observer is designed to achieve an accurate online estimation of disturbance and to compensate for the control law. In order to solve the problem of the “explosion of terms”, a nonlinear first-order filter is used instead of a traditional linear first-order filter to obtain the differential signal, ensuring the overall fixed-time stability of the system. The fixed-time stability of the closed-loop system is strictly proven via Lyapunov analysis. The simulation results show that the proposed method has good adaptability under different initial conditions, morphing speeds, and asymmetric morphing rates of the HMW. Full article

Over the past two decades, there has been a renewed interest in the development of a new generation of supersonic aircraft for civil purposes that could potentially succeed Concorde. However, the noise annoyance is still considered one of the hampering factors to meet public consensus. This paper aims at revealing the potential of numerical simulations to predict sonic boom signature in Near Field at early design stages. In particular, the paper further demonstrates the applicability of the numerical approach proposed by NASA and other partners during the Sonic Boom Prediction Workshops held between 2014 and 2021, to compute the pressure signature of aircraft in the zone close to it. The results highlight the suitability of the approach (1) to capture the impact of aircraft flight condition variations on the sonic boom signature, (2) to enable the characterization of novel aircraft layout, including Mach 5 waverider configuration, (3) to provide near-field shock wave noise predictions that can be used to evaluate shock propagation, on-ground signature analyses, and annoyance assessment. Full article

The parametric design method is widely utilized in the preliminary design stage for hypersonic vehicles; it ensures the fast iteration of configuration, generation, and optimization. This study proposes a novel parametric method for a wide-range, wing-morphing glide vehicle. The whole configuration, including a waverider fuselage, a rotating wing, a blunt leading edge, rudders, etc., can be easily described using 27 key parameters. In contrast to the typical parametric method, the new method takes internal payloads into consideration during the shape optimization process. That is, the vehicle configuration can be flexibly adjusted depending on the internal payloads; these payloads may be of random amounts and have different shapes. The code for the new parametric design method is developed using the secondary development tools of UG (UG 10.0) commercial software. The lift and drag characteristics over a wide operational range (H = 6–25 km, M = 2.5–8.5, AOA = 0–10°) were numerically investigated, as was the influence of the retracting angle of the morphing wings. It was found that, for the mode of the fully deployed wings, the lift-to-drag ratio (L/D) remained at a high level (≥4.7) over a Mach range of 4.0–8.5 and an AOA range of 4–7°. For the mode of the fully retracted wings, the drag coefficient remained smaller than 0.02 over a Mach range of 4.0–8.5 and an AOA range of 0–5°. A wide L/D of 0.3–4.7 could be achieved by controlling the retracting angle of the wings, thus demonstrating a good potential for flight maneuverability. The flexible change in L/D proved to be a combined result of varying pressure distribution and edge-flow spillage. This will aid in the further optimization of lift/drag characteristics. Full article

This paper presents a deep neural network-based online trajectory generation method for the aerodynamic characteristic description and terminal-area energy management of wave-rider aircrafts. First, the flight dynamics equations in the energy domain are linearized and discretized to generate numerous aircraft trajectory samples with sequential convex optimization (SCO) methods. Then, an optimization objective function is designed to promote the smoothness of the control variables and improve the trajectory similarity. Compared to the nonlinear programming (NLP), the proposed trajectory sample generation method is more suitable for the training of deep neural networks (DNNs). Finally, deep neural networks are formulated and trained for the control variables and state variables, using the generated obtained trajectory samples, so that the reference trajectories can be obtained online during the energy management process of the wave-rider’s terminal phase. Numerical simulations validate the high accuracy of the trajectories generated with the deep neural network. Meanwhile, this proposed method enables smaller storage usage, which is highly suitable for integration into on-board flight control systems. Full article

Quantum radar is a novel detection method that combines radar and quantum technologies. It exceeds the detection threshold and poses a threat to conventional stealth targets. This work aims to derive the expression of the quantum radar cross-section of a new complex target. The calculation formula of QRCS was derived after introducing the relative photon parameters and vector dot product. Subsequently, a comprehensive optimization model of quantum stealth and lift–drag ratio based on a genetic algorithm was proposed for the waverider warhead. During the optimization process, we proposed an optimization method with the objective function of the QRCS pioneering design value and achieved better outcomes than the optimization method using the average value in terms of QRCS performance and lift–drag ratio in the important azimuths of the waverider. By changing the design variables of the waverider warhead and using this new optimization method, the QRCS of the waverider in the forward and lateral angles were minimized, remarkably improving the aerodynamic performance of the waverider. Similarly, the optimization results show that the proposed design value optimization method is feasible. Full article

Recent studies have revealed that control surface deflection can cause a reduction in the aerodynamic efficiency of a hypersonic aircraft of up to 30%. In fact, the characterization of the Flight Control System is essential for the estimation of the consistent aerodynamic characteristics of the vehicle in different phases, considering the contribution of control surfaces to stability and trim. In terms of the sizing process, traditional methodologies have been demonstrated to be no longer applicable to estimations of the actuation power required for the control surfaces of a high-speed aircraft, due to their peculiar working conditions and to the characteristics of the flow to which they are exposed. In turn, numerical simulation approaches based on computational fluid dynamics or panel methods may require considerable time resources, which do not fit with the needs of the quick and reliable estimates that are typical of the early design phases. Therefore, this paper is aimed at describing a methodology to show how to anticipate the Flight Control System design for high-speed vehicles at the conceptual design stage, properly considering the interactions at vehicle level and predicting the behavior of the system throughout an entire mission. It is also a core part of the work to provide designers with an example of how neglecting the effect of trim drag can be detrimental to a reliable estimation of overall aircraft performance. The analysis, mainly focused on the longitudinal plane of the vehicle, is presented step-by-step on a specific case study, namely the STRATOFLY MR3 vehicle, a Mach 8 waverider concept for civil antipodal flights. The application of the methodology, conceived as an initial step towards an iterative Flight Control System design process, also shows that the most power-demanding phases are take-off, low supersonic acceleration, and approach, where peaks of over 130 kW are reached, while an average of 20 kW is sufficient to support deflections in a hypersonic cruise. Full article

The waverider is widely used in hypersonic vehicles with its high aerodynamic performance, but due to the serious aerothermal environment, its sharp leading edge should be blunted. Circular blunt is one of the commonly used aerothermal characteristic protection methods. Circular blunt with larger diameter can reduce peak heat flux, but at the same time, it will lead to larger drag. The existing research shows that under the same blunt diameter in two-dimensions, the non-uniform blunt can reduce the peak heat flux by 20%, and the difference of drag is small. In this paper, the non-uniform blunt profile is applied to the three-dimensional waverider, and the influence of the non-uniform blunt profile on the aerothermal characteristic performance and aerodynamic performance of the waverider is studied, and the results are compared with those of circular blunt. The numerical simulation is used to compare and analyze the waverider under different angles of attack, flight altitudes, and Mach number. The results show that the peak heat flux of the waverider with non-uniform blunt reduces by about 17% compared with that with circular blunt under a small angle of attack range, Mach 2-10, and a flight altitude of 15–35 km. Meanwhile, when the blunt height/diameter is 20 mm, the aerodynamic performance difference between the two different blunt profiles does not exceed 3% within a 15 degrees angle of attack, Mach 2-10, and flight altitude of 15–35 km. The non-uniform blunt profile can be applied to the design of the three-dimensional waverider. Full article

This paper presents a numerical investigation on the lift augmentation at subsonic speeds by using lateral jets for a hypersonic aircraft equipped with a waverider-type lifting body, which consists of three main parts. The jet slots were arranged along the side edges of the lifting body to study the effect of lateral blowing on the lift augmentation at a freestream Mach number of 0.3. The numerical results based on solving the Reynolds-averaged Navier–Stokes equation indicate that a well-designed lateral blowing can produce a significant lift rise. Then, further work was carried out to investigate the effects of jet parameters, including the jet location, the blowing strength and the blowing direction on lift augmentation, and to provide insights into the associated flow physics. It was found that blowing on the middle and rear parts of the lifting body achieves the maximum lift augmentation among the chosen configurations. Additionally, it was confirmed that the lift augmentation increases as the jet momentum increases, and blowing in the direction of ${\theta }_{jet}$ = −45°, which means the jet blows slightly towards the lower surface of the lifting body, produces a larger lift rise than other directions. The lift augmentation can be explained by the fact that a well-designed lateral blowing can amplify the effectiveness of the vortices shedding from the side edges of the lifting body, resulting in an increase in the vortex lift. Full article

Ocean wave design criteria are required for the design of offshore platforms and floating systems, which are derived using in situ measurements. However, there is uncertainty regarding the performance of the instruments used for the in situ measurements. The main instruments used by the offshore industry are the Datawell Directional Waverider buoy and Rosemount WaveRadar, with Laser instruments also having been used for specific studies. Recent reports indicate measurements from these three instruments differ in the order of 10% but given the quite disparate nature of the measurements made by these instruments, it is far from clear what the source of this difference is. This paper investigates the wave measurement principles of Radar and Laser instruments using linear wave field simulations to better understand how the instruments perform. The Radar and Laser simulations include modeling electromagnetic signal beam reflections from water surfaces of an area equal to their footprint sizes, considering their beam characteristics and antenna pattern. The study confirms that the Radar underestimates spectral levels at frequencies above 0.5 Hz due to its significantly larger footprint at the water sea surface compared to the Laser (5.25 m vs. 0.15 m). The Laser performs well for almost the entire frequency range for all the cases considered. Full article

Rocket-sleds belong to a category of large-scale test platforms running on the ground which are mainly used for launching tests of weapon equipment and performance tests of airborne equipment. In the present study, a dynamic grid method was used to simulate the running process of an axisymmetric slender rocket-sled (ASRS) and a reversed waverider rocket-sled (RWRRS). The aerodynamic characteristics were studied and the ability of the waverider to control the shockwave with the ground effect was confirmed. In addition to reducing shockwave oscillation, the RWRRS was also able to increase lift and reduce drag. By means of power spectral density analysis, the characteristic frequencies of shockwave oscillations related to shock-wave/rail-fastener interaction were analyzed and a harmonic phenomenon was observed. Furthermore, the ability of the waverider rocket-sled to reduce pressure oscillation was confirmed by comparing the sound pressure level value. Full article

Waverider is a hypersonic vehicle that improves the lift-to-drag ratio using the shockwave attached to the leading edge of the lifting surface. Owing to its superior aerodynamic performance, it exhibits a viable external configuration in hypersonic flight conditions. Most of the existing studies on waverider employ the inverse design method to generate vehicle configuration. However, the waverider inverse design method exhibits two limitations; inaccurate definition of design space and unfeasible performance estimation during the design process. To address these issues, a novel framework to directly optimize the waverider is proposed in this paper. The osculating cone theory is adopted as a waverider inverse design method. A general methodology to define the design space is suggested by analyzing the design curves of the osculating cone theory. The performance of the waverider is estimated accurately and rapidly via combining a high-fidelity computational fluid dynamics solver and a surrogate model. A comparison study shows that the proposed direct optimization framework enables a more accurate design space and efficient performance estimation. The framework is applied to the multi-objective optimization problem, which maximizes internal volume and minimizes aerodynamic drag. Finally, general characteristics for waverider are presented by analyzing the optimized results with data mining methods such as K-means. Full article
