Search Results (94)

The dynamic behavior of relaxed steel wire ropes under slowly varying pulse loads is dominated by the geometric wave impedance effect caused by the helical geometric topology. This study proposes a numerical analysis framework based on high-fidelity parametric solid modeling and implicit dynamics to investigate a Seale-type 6×19S-WSC steel wire rope. Under baseline conditions without pretension and friction, the helical structure forces significant modal conversion and geometric scattering of the axially incident waves, producing an energy attenuation effect akin to “geometric filtering”. Parametric analysis varying the core wire diameter reveals that the helical structure causes the axial wave speed to decrease by orders of magnitude compared to the material’s inherent wave speed. Furthermore, changes in core wire size induce a non-monotonic variation in the dynamic response, revealing a competitive mechanism between overall stiffness increase and a “dynamic decoupling” effect caused by interlayer gaps. This study confirms the dominant role of geometric wave impedance in the dynamic performance of relaxed steel wire ropes. Full article

Soil compaction in grassland and agricultural soils reduces water infiltration, root growth and ecosystem services. Conventional deep tillage and coring can alleviate compaction but are energy intensive and strongly disturb the turf. This study proposes an earthworm-inspired subsurface robot as a low-disturbance loosening tool for compacted grassland soils. Design principles are abstracted from earthworm body segmentation, anchoring–propulsion peristaltic locomotion and corrugated body surface, and mapped onto a robotic body with anterior and posterior telescopic units, a flexible mid-body segment, a corrugated outer shell and a brace-wire steering mechanism. Kinematic simulations evaluate the peristaltic actuation mechanism and predict a forward displacement of approximately 15 mm/cycle. Using the finite element method and a Modified Cam–Clay soil model, different linkage layouts and outer-shell geometries are compared in terms of radial soil displacement and drag force in cohesive loam. The optimised corrugated outer shell combining circumferential and longitudinal waves lowers drag by up to 20.1% compared with a smooth cylinder. A 3D-printed prototype demonstrates peristaltic locomotion and steering in bench-top tests. The results indicate the potential of earthworm-inspired subsurface robots to provide low-disturbance loosening in conservation agriculture and grassland management, and highlight the need for field experiments to validate performance in real soils. Full article

Acoustic fire suppression is a novel and environmentally friendly fire-extinguishing method. Electrical wires, as an important material in electrical systems, are a major cause of fires when short-circuited. In this study, we conducted experimental research on the flame spread and extinguishing characteristics of polyethylene-insulated electrical wires under the action of transverse acoustic waves within a frequency range of 50–70 Hz. The study systematically investigated the changes in flame morphology during the spreading process under different acoustic wave conditions. It was found that the flame spread rate first decreases and then increases with the increase in sound pressure, and the higher the acoustic frequency, the higher the spread rate. This study focused on the effect of acoustic frequency and wire inclination angle (0°, 30°, 60°) on the critical sound pressure for flame extinction. The experimental results showed that the critical sound pressure for flame extinction increases with the increase in frequency and inclination angle, with measured values ranging from 0.11 to 0.36 Pa for horizontal wires. An empirical model for predicting the critical sound pressure of flame extinguishment of inclined wires under acoustic waves was established based on an analysis of the strain rate. Full article

With the increasing demand for safety monitoring of offshore engineering structures, traditional single-modality sensing and centralized data processing models face challenges such as insufficient real-time performance and weak anti-interference abilities in complex marine environments. This research proposes an intelligent monitoring system based on multimodal sensor fusion and edge computing, aiming to achieve high-precision real-time diagnosis of offshore structure damage. The research plans to construct multimodal sensors through sensors such as stress change sensors, vibration sensors, ultrasonic sensors, and fiber Bragg grating sensors. A distributed wireless sensor network will be adopted to realize the transmission of sensor data, reduce the complexity of wiring, and meet the requirements of high humidity and strong corrosion in the marine environment. At the edge computing layer, lightweight deep learning models (such as multi-branch Transformer) and D-S evidence theory fusion algorithms will be deployed to achieve real-time feature extraction of multi-source data and damage feature fusion, supporting the intelligent identification of typical damages such as cracks, corrosion, and deformation. Experiments will simulate the coupled working conditions of wave impact, seismic load, and corrosion to verify the real-time performance and accuracy of the system. The expected results can provide a low-latency and highly robust edge-intelligent solution for the health monitoring of offshore engineering structures and promote the deep integration of sensor networks and artificial intelligence in Industry 4.0 scenarios. Full article

In suspension bridges employing spatial cables, the main cables undergo torsion during the construction process. Clarifying the distribution pattern of the main cable torsional angle can guide the positioning and installation of cable clamps and mitigate issues such as wire waving. This paper provides a theoretical calculation method for the distribution law of the torsion angle of the main cable. Firstly, it is assumed that the load form that causes the torsion of the main cable is the uniform load along the cable length and the span length. The theoretical calculation formulas of the torsion angle are derived, respectively, and the two formulas are compared. Analysis shows that under a uniformly distributed load, when the main cable is deflected at a certain angle, the torque is non-uniformly distributed along the cable, and the torsional angle follows a fourth-order parabolic curve along the span. A model test on spatial cable deflection was conducted, and the measured torsional angles were compared with theoretical results. The findings indicate that the measured torsional angle variation along the span is generally consistent with theoretical calculations. When the deflection angle of the spatial cable is large, the theoretical value exceeds the measured value. Furthermore, a finite element model was employed to calculate the torsional angle, torque, and bending moment during cable deflection. The results reveal that the distribution of the torsional angle depends on the ratio of the moment of inertia and the polar moment of inertia of the main cable section. The smaller the polar moment of inertia relative to the moment of inertia, the closer the torsional angle is to the spatial deflection angle. When the polar moment of inertia is relatively small, except in the end regions, the distribution of torque obtained from simulations is largely consistent with the theoretical values. Full article

To address the issues of traditional mooring lines, such as high self-weight, low strength, and poor durability, Carbon-Fiber-Reinforced Polymer (CFRP) was investigated as a material for mooring lines of offshore floating wind turbines, aiming to achieve high performance, lightweight design, and long service life for mooring systems. Based on a “chain–cable–chain” configuration, a CFRP mooring line design is proposed in this study. Taking a 5 MW offshore floating wind turbine as the research object, the dynamic performance of offshore floating wind turbines with steel chains, steel cables, polyester ropes, and CFRP mooring lines under combined wind, wave, and current loads was compared and analyzed to demonstrate the feasibility of applying CFRP mooring lines by combining the potential flow theory and the rigid–flexible coupling multi-body model. The research results indicate that, compared to traditional mooring systems such as steel chains, steel cables, and polyester ropes, (1) under static water, the CFRP mooring system exhibits a larger static water free decay response and longer free decay duration; (2) under operating sea conditions, the motion response and mooring tension of the offshore floating wind turbine with CFRP mooring lines are smaller than those with steel cables and steel chains but greater than those with polyester ropes; and (3) under extreme sea conditions, the motion responses of the offshore floating wind turbine with CFRP mooring lines are smaller than those with steel wire ropes and steel chains but close to the displacement responses of the polyester rope system, while the increase in mooring tension is relatively moderate and the safety factor is the highest. Full article

This article addresses the multifaceted challenges inherent in the development of the novel REEFS (Renewable Electric Energy From Sea) wave energy converter (WEC). Building on the submerged pressure differential principle, it frames similar WECs before focusing on REEFS that combines renewable energy generation with coastal protection, functioning as an artificial reef. The review follows chronological criteria, encompassing experimental proof-of-concept, small-scale laboratory modeling, simplified and advanced computational fluid dynamics (CFD) simulations, and the design of a forthcoming real-sea model deployment. Key milestones include the validation of a passive variable porosity system, demonstration of wave-to-wire energy conversion, and quantification of wave attenuation for coastal defense. Additionally, the study introduces a second patent-protected REEFS configuration, isolating internal components from seawater via an elastic enveloping membrane. Challenges related to scaling, numerical modeling, and funding are thoroughly examined. The results highlight the importance of the proof-of-concept as the keystone of the development process, underscore the relevance of mixed laboratory-computational approaches and emphasize the need for a balanced equilibrium between intellectual property safeguard and scientific publishing. The REEFS development trajectory offers interesting insights for researchers and developers navigating the complex innovation seas of emerging wave energy technologies. Full article

We present a single-slab metasurface that converts a normally incidental linearly polarized wave into either right- or left-handed circular polarization (RHCP/LHCP) through a simple ${90}^{\circ }$ mechanical rotation. Each unit cell comprises two L-shaped metallic resonators placed on the opposite faces of a low-permittivity substrate. Operating in transmission mode, the linear-to-circular (LTC) converter does not require any active electronic components. The geometry is optimized by using full-wave simulations to maximize the conversion up to 26% relative bandwidth with polarization conversion efficiency up to 65%, and insertion loss below 1.3 dB. Power balance analysis confirms low-loss, impedance-matched behavior. A scaled prototype fabricated from AWG-25 steel wires validates the model: experimental measurements closely reproduce the simulated bandwidth and demonstrate robust handedness switching. Because the resonance frequency depends primarily on resonator length and unit-cell pitch and thickness, the design can be retuned across the microwave spectrum through straightforward geometrical scaling. These results suggest that mechanical rotation could provide a simple and reliable alternative to electronic tuning in reconfigurable circular polarizers. Full article

Aiming to address the seismic vulnerability of long-span continuous rigid-frame bridges in high-intensity seismic zones, this study proposes to use a novel annular steel wire rope damper spherical bearing (SWD-SB) to dissipate the input earthquake energy and reduce the seismic responses. Firstly, the structural configuration and mechanical model of the new isolation bearing are introduced. Then, based on the dynamic finite element formulation, the equation of motion of a continuous rigid-frame bridge with the new isolation bearings is established, where the soil-structure interaction is considered. In a practical engineering case, the dynamic responses of the Pingchuan Yellow river bridge with the SWD-SB bearings are calculated and analyzed under multi-level earthquakes including the E1 and E2 waves. The results show that, compared with the bidirectional movable pot bearings, the SWD-SB significantly reduces the internal forces and displacement responses at the critical locations of the bridge. Under the E2 earthquake, the peak bending moments at the basement of main piers and at the pile caps are reduced by up to 72.6% and 44.7%, respectively, while the maximum displacement at the top of the main piers decreases by about 34.6%. The overall structural performance remains elastic except the SWD-SB bearings, meeting the two-stage seismic design objective. This paper further analyzes the hysteretic energy dissipation characteristics of the SWD-SB, highlighting its advantages in energy dissipation, deformation coordination, and self-centering capability. The research results demonstrate that the steel wire rope isolation bearings can offer an efficient and durable seismic protection for long-span continuous rigid-frame bridges in high-intensity seismic regions. Full article

The traditional research methods of the notch frequency phenomenon are mainly discussed by experimental observation or the semi-analytical finite element method. In this paper, the notch frequency characteristics of ultrasonic guided waves are simulated by the general finite element method. Firstly, the theoretical dispersion curve of the longitudinal mode in the axially loaded rod is derived by the acoustic elasticity theory, and the finite element simulation is carried out by ABAQUS/Explicit 6.14 to simulate the wave propagation in the seven-wire steel strand. In order to verify the model, laboratory experiments are carried out on three types of prestressed steel strands with diameters of 12.7 mm, 15.2 mm, and 17.8 mm, respectively. Each specimen is gradually loaded from 50 kN to 110 kN in increments of 30 kN. At each loading level, the ultrasonic signal is obtained, and the corresponding notch frequency is extracted from the spectrum. The experimental results confirm the accuracy of the model, and the maximum deviation between the predicted notch frequency and the measured value is 3%. The results show that the proposed method provides a robust and non-destructive means for structural health monitoring in civil engineering applications, and has the potential to be more widely used in complex waveguide structures. Full article

Despite its success in measuring air–sea exchange, the Woods Hole Oceanographic Institution’s (WHOI) X-Spar Buoy faces operational limitations due to energy constraints, motivating the integration of an energy harvesting apparatus to improve its deployment duration and capabilities. This work explores the feasibility of an augmented, self-powered system in two parts. Part 1 presents the collaborative design between X-Spar developers and wave energy researchers translating user needs into specific functional requirements. Based on requirements like desired power levels, deployability, survivability, and minimal interference with environmental data collection, unsuitable concepts are pre-eliminated from further feasibility study consideration. In part 2, we focus on one of the promising concepts: an internal rigid body wave energy converter. We apply control co-design methods to consider commercial of the shelf hardware components in the dynamic models and investigate the concept’s power conversion capabilities using linear 2-port wave-to-wire models with concurrently optimized control algorithms that are distinct for every considered hardware configuration. During this feasibility study we utilize two different control algorithms, the numerically optimal (but acausal) benchmark and the optimized damping feedback. We assess the sensitivity of average power to variations in drive-train friction, a parameter with high uncertainty, and analyze stroke limitations to ensure operational constraints are met. Our results indicate that a well-designed power take-off (PTO) system could significantly extend the WEC-Spar’s mission by providing additional electrical power without compromising data quality. Full article

We investigated the electrochemical properties of and conducted an electromechanical analysis on a stacked polyvinyl chloride (PVC) gel actuator, comprising a PVC gel plasticized with dibutyl adipate (DBA) sandwiched between a metal mesh and a metal disk electrode. In this study, we examined the electrochemical impedance, displacement, and electric current responses to square-wave voltage inputs. The linear motion of PVC gel actuators with and without ionic liquid (IL) additives was analyzed in relation to the mesh size and metal composition of the mesh electrode. The displacement increased with decreasing mesh numbers, indicating that displacement increases with increasing wire diameter and space length. The linear motion of the stacked PVC gel actuators with and without IL additives depended on the metal species of the mesh electrodes. The electrochemical impedance of the stacked PVC gel actuators under DC voltage application was analyzed with and without the IL. Based on the electromechanical and electrochemical results, a deformation model was developed to describe the linear motion of stacked PVC gel actuators in response to the applied voltage. The model attributed this motion to the deformation induced by Maxwell stress in the solvent-rich layer, successfully accounting for the experimental observations. Full article

Detecting power transformer winding degradations at an early stage is very important for the safe operation of nuclear power plants. Most transformer failures are caused by insulation breakdown; the winding turn-to-turn short circuit fault is frequently encountered. Experience has shown that routine testing techniques, e.g., winding resistance, leakage inductance, and sweep frequency response analysis (SFRA), are not sensitive enough to identify minor turn-to-turn short defects. The SFRA technique is effective only if the fault is in such a condition that the flux distribution in the core is prominently distorted. This paper proposes the frequency domain reflectometry (FDR) technique for detecting and locating transformer winding defects. FDR measures the wave impedance and its change along the measured windings. The wire over a plane model is selected as the transmission line model for the transformer winding. The effectiveness is verified through lab experiments on a twist pair cable simulating the transformer winding and field testing on a real transformer. The FDR technique successfully identified and located the turn-to-turn short fault that was not detected by other testing techniques. Using FDR as a complementary tool for winding condition assessment will be beneficial. Full article

For non-destructive testing (NDT) of defects in aluminum alloy plates, traditional ultrasonic contact methods face challenges from high temperatures and liquid couplant contamination. Using electromagnetic acoustic transducers (EMATs), a key issue is that longitudinal waves (L-waves) excited by the butterfly-coil EMATs interfere with the desired shear waves (S-waves) reflected by internal defects. To solve this problem, a simulation–experiment approach optimized the butterfly coil parameters. An FE model visualized the electromagnetic acoustic transducer (EMAT) acoustic field and predicted signals. Orthogonal simulations tested three main parameters: excitation frequency, wire diameter, and effective coil width. Tests on aluminum specimens with artificial defects used the optimized EMAT. Simulated and measured signals showed strong correlation, validating optimal parameters. The results confirmed suppressed L-wave interference and improved defect detection sensitivity, enabling detection of a 3 mm diameter flat-bottomed hole buried 37 mm deep. Full article

Offshore cranes are widely used in important fields such as wind power construction and ship replenishment. However, large payloads such as wind turbine blades are hoisted by multiple steel wire ropes, which makes it difficult to directly control their movements; that is, the number of input degrees of freedom is less than that of the output degrees of freedom. In addition, compared with land cranes, offshore cranes are inevitably affected by waves, wind, etc. The transition from a fixed base to a dynamic base brings severe challenges to their oscillation suppression and precise positioning. At the same time, to improve operational efficiency, the hoisting operation of offshore cranes usually adopts velocity input control patterns that fit the habits of manual operation, and most of them are in the form of dual-axis linkage for pitch and hoisting. Therefore, this paper proposes a fast terminal sliding mode control method for double-pendulum offshore cranes with distributed-mass payloads (DMPs). First, a nonlinear dynamic model of offshore cranes considering DMPs is established, and a dynamic model based on acceleration input control patterns is acquired. Based on this, considering the variation in hoisting rope lengths, a novel adaptive control method is proposed. Finally, simulation results verify the effectiveness of the proposed method, and the robustness of the proposed method to DMP mass parameter uncertainty and disturbances is demonstrated. Full article
