Search Results (169)

Search Parameters:
Keywords = vertical bending moment

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
28 pages, 4769 KB
Article
Mechanisms of Casing Stress Evolution and Integrity Evaluation in Salt and Non-Salt Interbedded Geological Settings: A Case Study of the Missan Oilfield
by Zhe Zhang, Chuanliang Yan, Yuanfang Cheng, Mingyu Xue and Zhongying Han
Appl. Sci. 2026, 16(12), 6264; https://doi.org/10.3390/app16126264 - 22 Jun 2026
Viewed by 229
Abstract
Salt rock exhibits pronounced viscoelastic creep, continuously imposing radial extrusion loads on casing and threatening long-term well integrity. Field observations in the Missan Oilfield, Iraq, show that casing damage is concentrated near salt–non-salt interfaces, where lithologic contrasts intensify stress redistribution and mechanical coupling. [...] Read more.
Salt rock exhibits pronounced viscoelastic creep, continuously imposing radial extrusion loads on casing and threatening long-term well integrity. Field observations in the Missan Oilfield, Iraq, show that casing damage is concentrated near salt–non-salt interfaces, where lithologic contrasts intensify stress redistribution and mechanical coupling. This study integrates triaxial creep experiments, a calibrated modified Burgers model, UMAT implementation, and three-dimensional finite element simulations to investigate casing stress evolution and failure mechanisms. The calibrated model reproduces salt rock creep with a maximum relative strain error of 16.8%. Results show that post-cementing salt creep amplifies non-uniform radial loading at the interface, causing progressive casing stress concentration. At low inclination, the interface–casing intersection evolves into an elliptical annulus; the circumferential variation in equivalent wall thickness and stress-peak migration jointly weaken local stress concentration. However, when the inclination angle reaches approximately 45° at β = 0°, the peak Mises stress begins to exceed that under the vertical-well condition. When α ≥ 65°, the peak stress no longer decreases monotonically with azimuth but exhibits a decrease–increase trend. This indicates that eccentric loading and the additional bending moment dominate the transition from radial extrusion to coupled bending–shear–extrusion loading. A casing stress risk map and grade-selection chart are developed to support casing design in salt-interbedded formations. Full article
(This article belongs to the Section Energy Science and Technology)
Show Figures

Figure 1

21 pages, 15198 KB
Article
Effects of Slamming-Induced Whipping on Fatigue Damage of an Ultra-Large Container Ship Advancing in Irregular Waves
by Ying Tang, Ziyin Huang, Xiaojun Lv, Yucun Pan, Shili Sun, Huilong Ren and Yiheng Zhang
J. Mar. Sci. Eng. 2026, 14(12), 1125; https://doi.org/10.3390/jmse14121125 - 18 Jun 2026
Viewed by 315
Abstract
Slamming-induced whipping has been recognized as a key contributor to fatigue damage of large ships operating under severe sea states. However, accurate prediction of whipping responses remains challenging because of complex nonlinear fluid–structure interactions. This study aims to investigate the characteristics of slamming-induced [...] Read more.
Slamming-induced whipping has been recognized as a key contributor to fatigue damage of large ships operating under severe sea states. However, accurate prediction of whipping responses remains challenging because of complex nonlinear fluid–structure interactions. This study aims to investigate the characteristics of slamming-induced whipping and quantitatively analyze its influence on the fatigue damage of an ultra-large container ship. A three-dimensional fully nonlinear time-domain hydroelastic method, in which the boundary element model is coupled with a Timoshenko beam model, is employed to predict the slamming-induced whipping responses. Segmented model tests in long-crested irregular waves are conducted to provide wave loads of hull girders under severe sea states. The total and wave-frequency vertical bending moments are separated by the fast Fourier transform, and their statistical characteristics are evaluated through probability distributions. Fatigue damage is assessed on the basis of the rainflow counting method and the Palmgren–Miner cumulative damage rule. The contribution of high-frequency whipping responses to fatigue damage is quantitatively evaluated using a fatigue damage factor. It is demonstrated that slamming-induced whipping can significantly amplify fatigue damage by increasing stress amplitudes and cycle counts, particularly under high forward speeds and severe sea conditions. The findings provide a reliable reference for the fatigue design and safety assessment of ultra-large container ships. Full article
(This article belongs to the Special Issue Advances in Fatigue and Dynamic Response of Marine Structures)
Show Figures

Figure 1

18 pages, 38884 KB
Article
Mesoscale Mechanism Study of Geocell-Reinforced Foundation Under Strip Footing Using PFC3D
by Juan Hou, Jingxuan Ouyang and Xuelei Xie
Buildings 2026, 16(12), 2371; https://doi.org/10.3390/buildings16122371 - 13 Jun 2026
Viewed by 306
Abstract
Optimizing the structural stability of foundations is challenging in modern geotechnical engineering. This study investigated the mechanism of geocell-reinforced foundations through discrete element modeling based on transparent soil model tests. A three-dimensional particle flow code (PFC3D) model was developed to investigate [...] Read more.
Optimizing the structural stability of foundations is challenging in modern geotechnical engineering. This study investigated the mechanism of geocell-reinforced foundations through discrete element modeling based on transparent soil model tests. A three-dimensional particle flow code (PFC3D) model was developed to investigate the micromechanical soil–geocell interactions in both unreinforced and geocell-reinforced foundations under strip loading. Particle displacement, contact force distribution, and structural deformation within the foundation system were analyzed to quantify the performance of geocell reinforcement. The results show that geocell inclusion enhances structural performance by 2.1 times compared to an unreinforced foundation, increasing the bearing capacity from 60.6 to 126.8 kPa at a defined bearing capacity criterion. The geocell walls act as rigid physical boundaries that microscopically intercept the lateral migration and horizontal extrusion of soil particles. The kinematic trajectories of soil particles beneath the loading plate are forced into a downward realignment, decreasing the displacement vector rotation angle from 42° in the unreinforced soil to 27° in the reinforced soil and effectively mitigating the heave of adjacent surfaces. Furthermore, the quasi-rigid three-dimensional network completely interrupts the continuous steep contact force chains inherent in unreinforced foundations. Concentrated vertical stresses are converted into horizontal components through interfacial friction and mechanical interlocking, resulting in the lateral redistribution of the applied load by a distance of approximately 0.06 m. The geocell–soil composite considered as a flexible raft foundation extends load dispersion and reduces average subsoil pressure. A coupled tension and compression stress state in the horizontal plane is developed within the geocell structure. Forces are channeled along rigid paths by elevated bending moments and stress concentrations at the cell junctions. These findings provide micromechanical insights into the performance of geocell-reinforced-foundation systems. Full article
(This article belongs to the Section Building Structures)
Show Figures

Figure 1

17 pages, 3769 KB
Article
Analytical and Numerical Analysis of Mechanical Response of Ultra-Large-Diameter Shield Tunnel with the Nonuniform Convergence of Axial Symmetry
by Weitao Chen, Kaihang Han and Jun Zhou
Symmetry 2026, 18(6), 991; https://doi.org/10.3390/sym18060991 - 9 Jun 2026
Viewed by 225
Abstract
In this paper, analytical and numerical analyses of the mechanical response of an ultra-large-diameter shield tunnel with a nonuniform convergence of axial symmetry are conducted. A nonuniform convergence of axial symmetry around the tunnel boundary is adopted. The bending moment and axial force [...] Read more.
In this paper, analytical and numerical analyses of the mechanical response of an ultra-large-diameter shield tunnel with a nonuniform convergence of axial symmetry are conducted. A nonuniform convergence of axial symmetry around the tunnel boundary is adopted. The bending moment and axial force of the tunnel liner with different diameters from 6 to 18 m are obtained and compared in detail. The theoretical analysis results show that at the same buried depth of the tunnel crown, both the maximum absolute bending moment and axial force of the shield tunnel liner grow as the diameter of the tunnel increases. Moreover, the distributions of the bending moments of the tunnel liner along the tunnel boundary present a “8” shape and are axially symmetric along the vertical axis, where the upper and lower parts are positive and the left and right sides are negative. The maximum absolute bending moment of the tunnel liner is at the axis of 280°. Furthermore, the axial force of the shield tunnel liner is always negative, and the maximum absolute axial forces of the tunnel liner are at the axis of 0° and 180°. Finally, it is worth pointing out that the maximum bending moment and axial force increase 26.99 times and 8.99 times, respectively, when the diameter increases only three times from 6 m to 18 m, which is of great guiding significance for the rational design of ultra-large-diameter shield tunnels. The results of the analytical solution are verified by a numerical analysis, which shows that the analytical solution has a higher computational efficiency than the numerical simulation while ensuring accuracy. Full article
Show Figures

Figure 1

34 pages, 5665 KB
Article
Calculation Method for Torsional Moment of Inertia of Half-Through Truss Bridges
by Zixiang Yue, Siyuan Lin, Rui Zhao and Bin Zhang
Buildings 2026, 16(11), 2108; https://doi.org/10.3390/buildings16112108 - 25 May 2026
Viewed by 232
Abstract
Half-through truss bridges exhibit significantly different mechanical characteristics due to their open tops, necessitating special treatment for calculating their free torsional moment of inertia. This study proposes a novel method: considering the constraints of vertical web members and crossbeams on the top chord, [...] Read more.
Half-through truss bridges exhibit significantly different mechanical characteristics due to their open tops, necessitating special treatment for calculating their free torsional moment of inertia. This study proposes a novel method: considering the constraints of vertical web members and crossbeams on the top chord, the top chord is equivalently modeled as a continuous beam on elastic supports. An equivalent horizontal bending moment of inertia of the top chord is derived by converting the top chord to the height of the top crossbeam while maintaining equivalent stiffness based on the equivalence principle. According to the analytical formula for the torsional moment of inertia and detailed parametric analysis, the main dimensional parameters affecting the torsional stiffness of half-through truss bridges include bridge length, bridge width, and main truss height. These parameters primarily enhance the bridge’s torsional stiffness by influencing the constrained torsional moment of inertia. However, due to scale limitations and aesthetic requirements, these dimensions cannot be increased indefinitely. In such cases, besides considering weight and aesthetics, increasing the size of the chords may be considered to enhance torsional stiffness. The interactions among the various factors affecting torsional behavior are relatively complex, and more systematic research is recommended for future study. Full article
(This article belongs to the Section Building Structures)
Show Figures

Figure 1

25 pages, 7466 KB
Article
Influence of Existing Pile Group and Strata Induced by Excavation of the Adjacent Twin Tunnels with Small Clearance
by Caixia Guo, Lin Ji, Mingshe Sun, Houting Jiang and Wenzheng Wang
Buildings 2026, 16(8), 1618; https://doi.org/10.3390/buildings16081618 - 20 Apr 2026
Viewed by 473
Abstract
In urban subway construction, shield tunneling inevitably passes in close proximity to existing pile foundations, inducing adverse effects on their internal forces and deformations. Taking the twin shield tunnels with small clearance adjacent to the bridge piles as the engineering background, this study [...] Read more.
In urban subway construction, shield tunneling inevitably passes in close proximity to existing pile foundations, inducing adverse effects on their internal forces and deformations. Taking the twin shield tunnels with small clearance adjacent to the bridge piles as the engineering background, this study establishes a three-dimensional finite element numerical model to investigate the deformation and internal force responses of the adjacent pile foundations under different pile lengths, twin-tunnel construction sequences, and tunnel face pressure conditions. The findings indicate that the primary influence zone affected by twin-tunnel excavation extends approximately twice the tunnel diameter (2D) before and after the pile foundation location. Compared with short piles, longer piles exhibit smaller vertical displacements. Meanwhile, the lateral displacements, additional axial forces and bending moments of medium and long piles increase, with their maximum values occurring near the tunnel centerline. For the near pile, when the right tunnel is excavated first, compared with the condition of the left-tunnel-first excavation, the lateral and vertical displacements slightly increase. In addition, the maximum additional axial force increases by 38.8%, while the maximum additional bending moment decreases by approximately 21%. Tunnel face pressure exerts a moderate influence on the vertical displacement of both the surrounding soil and pile foundation, while its effect on lateral displacement and internal forces is relatively insignificant. The tunnel face pressure within the range of 200 kPa to 300 kPa provides optimal control over pile foundation deformation. Full article
(This article belongs to the Section Building Structures)
Show Figures

Figure 1

23 pages, 3433 KB
Article
Vehicle–Bridge Interaction Characteristics for a Beam–Arch Composite Continuous Rigid-Frame Bridge
by Lingbo Wang, Yifan Li, Kang Shi, Ke Wu, Yushan Ye, Junyong Zhou, Xiliang Sun and Bing Yao
Buildings 2026, 16(8), 1611; https://doi.org/10.3390/buildings16081611 - 19 Apr 2026
Cited by 1 | Viewed by 656
Abstract
This study investigates the influence of key parameters—vehicle speed, weight, loading lane, and pavement roughness—on the Dynamic Amplification Factor (DAF) and ride comfort of a beam–arch composite continuous rigid-frame bridge under vehicle–bridge coupling. A six-span bridge is analyzed using a spatial beam-element model [...] Read more.
This study investigates the influence of key parameters—vehicle speed, weight, loading lane, and pavement roughness—on the Dynamic Amplification Factor (DAF) and ride comfort of a beam–arch composite continuous rigid-frame bridge under vehicle–bridge coupling. A six-span bridge is analyzed using a spatial beam-element model in ANSYS and a typical three-axle vehicle model is adopted to conduct the coupled dynamic response analysis. Based on the modal and structural characteristics of this bridge, key response indices are selected, including vertical displacement and bending moment at midspan, longitudinal displacement and bending moment at pier top, arch crown displacement, and tensile force in the long hanger. Control sections are identified in Span 4 (midspan, arch crown, long hanger) and at the top of Pier 16. The results demonstrate that pavement roughness significantly influences ride comfort, with the root mean square (RMS) value varying up to 107%, whereas the loading lane shows a negligible effect. Vehicle speed effects are divided into two distinct regimes: at 60 km/h and within 70–90 km/h, with dynamic responses in the higher speed range approximately 22% greater. Increasing vehicle weight raises the peak dynamic response by up to 77.68%, but does not lead to a proportional increase in DAF. Transverse loading eccentricity has a more pronounced impact on vertical bridge responses (>20% change) than on longitudinal responses (<10% change). Deterioration in pavement roughness elevates both dynamic response and DAF, with maximum increases reaching 27.97% and 28%, respectively. Full article
Show Figures

Figure 1

35 pages, 16289 KB
Article
Large-Scale Model Tests on the Performance and Mechanism of Vertical–Inclined Pile Wall (VIPW) Structures in Excavation
by Haozhen Yue, Yapeng Zhang, Chaoyi Sun, Yun Zheng and Demin Xue
Buildings 2026, 16(8), 1588; https://doi.org/10.3390/buildings16081588 - 17 Apr 2026
Viewed by 440
Abstract
With the acceleration of urbanization, deep and large foundation pit projects have become increasingly common, posing challenges for retaining structural performance. This study investigates the mechanism of the recently proposed vertical–inclined pile wall (VIPW) through physical model tests. Six sets of large-scale model [...] Read more.
With the acceleration of urbanization, deep and large foundation pit projects have become increasingly common, posing challenges for retaining structural performance. This study investigates the mechanism of the recently proposed vertical–inclined pile wall (VIPW) through physical model tests. Six sets of large-scale model tests of foundation pit excavation under 1 g gravity conditions were carried out. Among these tests, one employed the soldier pile wall (SPW) as the support system, while the remaining five adopted the VIPW. By monitoring and analyzing the distribution and variation in the vertical pile deformation, surface settlement, pile bending moment, and inclined pile top axial force during the excavation process, the action mechanism of the VIPW was revealed, and it was verified that VIPWs exhibit better support performance than SPWs. Furthermore, four key parameters, including the embedded depth, the inclination angle, the support position of the inclined piles, and the embedded depth of the vertical piles, were varied to study their influence on the deformation and force characteristics of the VIPW, providing a theoretical basis for structural optimization design. Moreover, by comparing the instability and failure characteristics of the foundation pit, it was proved that the VIPW can effectively ensure the stability of the foundation pit. Full article
Show Figures

Figure 1

19 pages, 7072 KB
Article
Research on Tail Rotor Load Test Flight Technology for Helicopters Based on Strain Sensor Measurement
by Shuaike Jiao, Jiahong Zheng, Kang Li and Xiaoqing Hu
Sensors 2026, 26(8), 2287; https://doi.org/10.3390/s26082287 - 8 Apr 2026
Viewed by 410
Abstract
The load characteristics of the helicopter tail rotor system are critical to flight safety and handling performance, and flight testing remains the most direct and reliable means to obtain authentic load data. In this paper, the well-established Wheatstone bridge strain measurement method is [...] Read more.
The load characteristics of the helicopter tail rotor system are critical to flight safety and handling performance, and flight testing remains the most direct and reliable means to obtain authentic load data. In this paper, the well-established Wheatstone bridge strain measurement method is adopted to carry out accurate load testing on the helicopter tail rotor system. The tail rotor assembly mainly consists of the tail rotor shaft, pitch link, and tail rotor blades, which undertake different load transfer tasks during flight. Under actual operating conditions, the tail rotor shaft bears significant axial tension as well as combined lateral and vertical bending moments; the pitch link is primarily subjected to alternating axial tension and compression; and the tail rotor blades withstand complex loads including flapping bending, lagwise bending, and torsional moments. According to the distinct stress characteristics and force transmission paths of each component, targeted flight test maneuvers are reasonably designed. These maneuvers include steady-level flight at low, medium, and high speeds, zigzag climbing flight, near-ground side-rear flight, as well as deceleration-to-sprint and obstacle slope maneuvers specified in ADS-33E. Key flight parameters are selected for in-depth analysis to reveal the load distribution and dynamic variation patterns of the tail rotor under typical operating conditions. On this basis, a helicopter load risk test point matrix is established to identify high-risk working conditions and key monitoring positions. This study provides a solid theoretical and data foundation for subsequent flight test monitoring and structural strength verification. It effectively reduces flight test risks, improves monitoring efficiency and accuracy, and helps cut down the human, material, and financial costs associated with flight test monitoring. The research results can also provide important references for the design optimization and safety evaluation of helicopter tail rotor systems. Full article
(This article belongs to the Collection Sensors and Sensing Technology for Industry 4.0)
Show Figures

Figure 1

18 pages, 1672 KB
Article
Theoretical Research on Eccentrically Braced Composite Frames with Vertical Shear Links
by Yan-Kai Huang, Liang-Dong Zhuang, Hong-Yu Wang, Yan Li and Li-Long Fan
Buildings 2026, 16(6), 1166; https://doi.org/10.3390/buildings16061166 - 16 Mar 2026
Viewed by 304
Abstract
This paper presents a theoretical study on the seismic behavior and working mechanisms of eccentrically braced composite frames with vertical shear links. A theoretical model is established based on structural mechanics principles to analyze the internal force distribution and deformation patterns under lateral [...] Read more.
This paper presents a theoretical study on the seismic behavior and working mechanisms of eccentrically braced composite frames with vertical shear links. A theoretical model is established based on structural mechanics principles to analyze the internal force distribution and deformation patterns under lateral loading. Formulas for the lateral stiffness, bending moments in beams and columns, and joint rotations are derived. A multi-stage theoretical skeleton curve model is proposed, identifying key points such as cracking, yielding, peak strength, and failure, along with corresponding methods for calculating load and displacement values. The theoretical results show good agreement with experimental data, effectively predicting the structural stiffness, load-bearing capacity, and deformation behavior. Key design parameters affecting structural performance are identified, including the beam–column linear stiffness ratio, geometric properties of the shear link, and brace stiffness. The study provides a theoretical basis and practical methodology for the seismic design of such structures. Full article
(This article belongs to the Section Building Structures)
Show Figures

Figure 1

27 pages, 12460 KB
Article
Vertical Bending Moment in Extreme Regular Waves—Benchmarking of Numerical Codes Against Model Tests
by Ole Andreas Hermundstad, Guillaume de Hauteclocque, Sopheak Seng, Masayoshi Oka, Chong Ma, Benjamin Bouscasse, Roberto Vettor, Shan Wang, Ivan Sulovsky, Jasna Prpic-Orsic, Kei Sugimoto and Tormod R. Landet
J. Mar. Sci. Eng. 2026, 14(5), 481; https://doi.org/10.3390/jmse14050481 - 2 Mar 2026
Cited by 1 | Viewed by 795
Abstract
A benchmark study of 10 different numerical methods for ship motion and load assessment is presented. Pitch motions and midship vertical bending moments are compared to model test results for a containership at zero speed in head regular waves. The wave steepness is [...] Read more.
A benchmark study of 10 different numerical methods for ship motion and load assessment is presented. Pitch motions and midship vertical bending moments are compared to model test results for a containership at zero speed in head regular waves. The wave steepness is varied from 2.1% to 10.5%. The model tests show that pitch and the vertical bending moment (VBM) display nonlinear behavior even for low-steepness waves. It is demonstrated that computational fluid dynamics (CFD) methods can reproduce the ship responses with good accuracy, even in very steep waves, involving green water and parts of the ship going in and out of water. Weakly nonlinear potential-theory methods tend to overestimate the pitch motions and the sagging moments as the wave steepness increases. For the vertical bending moment in steep waves, the 3D panel methods did not give significantly better results than those obtained with the nonlinear strip theories. Full article
Show Figures

Figure 1

18 pages, 12068 KB
Article
Research on the Bearing Performance of Suction Pile–Gravity Hybrid Foundation in Sand Under Multi-Directional Loading
by Yangming Chen, Maolin Li, Zhechen Hou, Fengwei Yang and Dengfeng Fu
J. Mar. Sci. Eng. 2026, 14(5), 457; https://doi.org/10.3390/jmse14050457 - 27 Feb 2026
Viewed by 508
Abstract
The suction pile–gravity hybrid foundation (SPGH) has emerged as a novel foundation for floating wind turbines (FWTs) due to its superior bearing mechanism. In harsh marine environments, offshore wind turbine structures endure multidirectional wave–wind current loads, which are transmitted through mooring systems as [...] Read more.
The suction pile–gravity hybrid foundation (SPGH) has emerged as a novel foundation for floating wind turbines (FWTs) due to its superior bearing mechanism. In harsh marine environments, offshore wind turbine structures endure multidirectional wave–wind current loads, which are transmitted through mooring systems as complex multidirectional coupled loads (horizontal, vertical, bending moments, and torque), imposing severe challenges to the bearing capacity. Therefore, this study carries out 3D finite element simulations, utilizing the Hardening Soil–Small Strain constitutive model to simulate the stress–strain behavior of sand, to systematically investigate the failure modes and bearing capacity of SPGH foundations. The method underlying the failure envelope theory is proposed, applicable to tension-leg mooring systems (dominated by uplift and lateral loads) and catenary mooring systems (dominated by compression and lateral loads). Results indicate that under pure vertical uplift or torque loading, both SPGH and traditional SP foundations exhibit typical interfacial shear failure modes. Under pure horizontal or bending moment loading, SPGH and SP foundations exhibit rotational instability failure. The direction of vertical load has a significant impact on the bearing performance of SPGH foundations. In addition, horizontal load can increase its vertical uplift-bearing capacity by 46% and torque capacity by 48%. The enhancement effect of the bending moment load is more significant, and can increase the vertical uplift-bearing capacity by 115% and the torque-bearing capacity by 112%, respectively, while vertical downward loads within a certain range significantly improve horizontal and bending-bearing performance. Full article
Show Figures

Figure 1

18 pages, 5967 KB
Article
Collapse Behavior of Onshore and Spar-Floating Wind Turbine Towers During Blade Pitch Malfunction
by Sharath Srinivasamurthy, Amiya Pandit and Shigeo Yoshida
J. Mar. Sci. Eng. 2026, 14(4), 378; https://doi.org/10.3390/jmse14040378 - 16 Feb 2026
Viewed by 565
Abstract
Blade pitch control is one of the most important control systems for a wind turbine: blade pitch controller malfunction can lead to increased vertical bending moment at the tower base, which may result in structural failure. This study investigated the collapse behavior mechanism [...] Read more.
Blade pitch control is one of the most important control systems for a wind turbine: blade pitch controller malfunction can lead to increased vertical bending moment at the tower base, which may result in structural failure. This study investigated the collapse behavior mechanism at the tower root due to an extreme event of blade pitch malfunction for onshore and spar-floating wind turbines. An aero-hydro-elastoplastic coupled analysis tool previously developed and validated by one of the authors was utilized to capture the structural response at the tower root in elastic and plastic regions. Three strength models—(i) SM-01, (ii) SM-02, and (iii) SM-03—were selected to demonstrate the collapse behavior mechanism of onshore and spar-floating 5 MW wind turbines in a time-series simulation. The damage in the plastic region, termed the collapse extent, was evaluated at the collapsing section. Moment–rotational angle relationships are discussed under the same wind conditions. The tower vibrations were found to dominate the structural response of the onshore wind turbine, whereas the tower vibrations and floater response dominate the spar-floating wind turbine response during the failure event. The collapse extent of the spar-floating wind turbine was found to be 8 times larger than the onshore wind turbine under the same wind conditions. Furthermore, simulations were carried out for the spar-floating wind turbine to understand the effect of incoming waves on the collapse behavior: the collapse extent increases as the wave amplitude and period increase under the same wind conditions. Full article
(This article belongs to the Special Issue Numerical Analysis and Modeling of Floating Structures)
Show Figures

Figure 1

22 pages, 5622 KB
Article
Research on the Mechanical Model of the Tunnel Supporting Structure Shell Based on the Modified Ellipsoid Theory
by Yang Sun, Yitian Yu, Haibin Ding and Tao Fang
Appl. Sci. 2026, 16(3), 1567; https://doi.org/10.3390/app16031567 - 4 Feb 2026
Viewed by 492
Abstract
Accurate assessment of tunnel lining deformations and stress distributions critically governs structural integrity, while miscalculations may trigger construction delays and budget overruns. A mechanical shell model for tunnel supports was developed, integrating the modified ellipsoid theory to analytically resolve vertical displacements and internal [...] Read more.
Accurate assessment of tunnel lining deformations and stress distributions critically governs structural integrity, while miscalculations may trigger construction delays and budget overruns. A mechanical shell model for tunnel supports was developed, integrating the modified ellipsoid theory to analytically resolve vertical displacements and internal stresses. Numerical validation through finite element simulations confirmed model efficacy. The influence of key geometric and material parameters encompassing height-to-width ratio, burial depth, lining thickness, and elastic modulus on tunnel support displacement and stress distributions was systematically investigated. Parametric analysis revealed that vertical displacement exhibited greater sensitivity to height-to-width ratio variations compared to burial depth. Longitudinal distributions demonstrated similar trends axial force and vertical displacement, with bending moments and shear forces exhibiting analogous behavioral patterns. Transver sely, axial forces and vertical displacements adopted a symmetrical trough (U-shaped) profile, while bending moments and shear forces formed a bimodal (M-shaped) distribution with attenuated gradients near the crown region. This computational model establishes a practical analytical tool for evaluating post-support tunnel deformation and structural load distributions. Full article
Show Figures

Figure 1

21 pages, 12991 KB
Article
Numerical Simulation on Deformation and Damage Mechanism of Existing Underground Structures Induced by Adjacent Construction of Super-Large-Diameter Tunnels
by Zhiyuan Zhai and Kaihang Han
Appl. Sci. 2026, 16(3), 1398; https://doi.org/10.3390/app16031398 - 29 Jan 2026
Viewed by 610
Abstract
The development of urban underground spaces has led to an increasing number of projects involving super-large-diameter shield tunnels, making research on their impact on existing structures particularly significant. This paper investigated the numerical simulation on deformation and damage mechanism of existing underground structures [...] Read more.
The development of urban underground spaces has led to an increasing number of projects involving super-large-diameter shield tunnels, making research on their impact on existing structures particularly significant. This paper investigated the numerical simulation on deformation and damage mechanism of existing underground structures induced by adjacent construction of super-large-diameter tunnels. A 3D finite element model using ABAQUS (version 2022) software incorporating the Concrete Damaged Plasticity (CDP) constitutive model was established, and this paper was used to systematically analyze the deformation, internal force response, and damage evolution of existing tunnels. The results showed the following: (1) The double-line tunnel excavation intensified settlement superposition, increasing the maximum settlement from −19.70 mm (single-line) to −24.51 mm (double-line) and transforming the settlement trough from a V shape to a W shape. (2) The vertical bending moment evolved from a single peak to double peaks being the dominant loading mode, with the maximum horizontal moment only about 1/8 of the vertical value. (3) During the construction, the peak tensile stress at the tunnel bottom reached 2.655 MPa, exceeding the C50 concrete tensile strength, but later decreased to 2.097 MPa. Damage was primarily caused by bending-induced tension. (4) Tunnel damage was triggered by the historical peak stress and accumulated irreversibly, resulting in a final state of low-stress and high-damage, with a maximum tensile damage of 92.4%. This research can provide a theoretical basis for safety control in similar adjacent engineering projects. Full article
(This article belongs to the Special Issue Advances in Tunnelling and Underground Space Technology—2nd Edition)
Show Figures

Figure 1
