Search Results (82)

Deep mining of geologically challenging deposits, such as narrow, steeply dipping orebodies, is increasingly pursued to meet the rising demand for mineral resources. However, the geotechnical stability of operations in such environments remains a persistent challenge. A paramount concern is the insufficiently understood mechanisms governing the surface subsidence and stability of underground excavations, which diverge significantly from those in flat or gently dipping deposits. This study bridges this gap through an integrated methodology applied to a deep cut-and-fill gold mine in China. We combined nine years (2016–2025) of SBAS-InSAR monitoring, utilizing 120 Sentinel-1 images corrected with precise orbit and atmospheric correction data, with a comprehensive three-dimensional (3D) numerical simulation. The results reveal a unique subsidence pattern: surface subsidence is highly localized, forming an elliptical basin directly above the orebodies, with a footwall movement angle exceeding 90°. Furthermore, the subsidence magnitude showed minimal progression despite increasing mining depth, with a maximum cumulative subsidence of only 9.3 mm. Numerical simulation confirmed these findings and demonstrated that underground shafts and tunnels remained stable under the sequential extraction of multiple orebody levels. This exceptional geotechnical response is attributed to a synergistic mechanism involving the intrinsic geomechanical advantages of the steeply dipping geometry, the low-disturbance nature of narrow-vein mining, and the crucial structural support provided by the backfilling. This study demonstrates the efficacy of cut-and-fill mining for ensuring operational safety and minimizing surface environmental impact in the deep mining of narrow, steeply dipping orebodies, providing critical insights for the sustainable exploitation of deep mineral resources. Full article

Deep-buried tunnels in urban environments require careful evaluation of their long-term interactions with the surrounding ground to ensure structural safety and sustainability. Taking the Beijing Eastern Sixth Ring Road renovation project as a case study, this research employs a fully coupled fluid–solid numerical approach to elucidate the long-term disturbance mechanisms associated with deep-buried shield tunneling. Specifically, the research quantifies spatio-temporal ground responses and characterizes the consolidation settlement mechanisms exacerbated by potential tunnel leakage. The results indicate that ground deformation is primarily governed by the intensity of tunnel leakage. When the waterproofing grade of the tunnel meets Grade I or II, leakage and surface settlement remain negligible. However, when a tunnel’s waterproofing grade deteriorates to Grade IV or lower, consolidation settlement increases significantly, becoming the dominant deformation mode. In addition, both the extent and severity of ground movement are highly sensitive to the geometrical boundaries of the strata and the relative depth of the tunnel. Larger permeable domains and deeper tunnels lead to wider pore pressure and stress disturbance zones, ultimately leading to more pronounced long-term settlement. Furthermore, soil permeability dictates the temporal evolution of the ground response, with poorly permeable layers exhibiting delayed fluid–solid re-equilibration. A critical threshold is observed when leakage rates align with or exceed the soil’s permeability, leading to a significant escalation in both the amplitude of subsidence and the time required to reach equilibrium. These findings offer valuable insights for the design, waterproofing, and long-term management of deep urban tunnels. Full article

Monitoring small water body coverage spatiotemporal evolution in karst areas of complex hydrogeology is pivotal for water resource management and disaster assessment. With recent infrastructure expansion, intensive tunnel excavation has occurred in Chongqing’s Geleshan, a typical karst region with fragile aquifers. It has disrupted hydrogeological systems, triggering ground subsidence, groundwater leakage, and subsequent reservoir desiccation, as well as threatening regional water security and ecology. Thus, monitoring reservoir coverage evolution is critical to clarify dynamics and driving mechanisms. Synthetic Aperture Radar (SAR) is ideal for water body mapping, enabling data acquisition independent of illumination and weather. However, traditional SAR-based water extraction methods are hampered by low-scatter noise and poor adaptability to hydrological fluctuations. To address this, a two-stage dual-polarization SAR clustering algorithm (TSDPS-Clus) was developed using 452 time-series Sentinel-1 images (7 February 2017–24 August 2025). Specifically, the Kolmogorov–Smirnov test via pixel-wise time-series statistics screened core water areas, built candidate regions, and mitigated noise. Subsequently, dual-polarization and positional features were fused via singular value decomposition (SVD) to generate a high-discrimination low-dimensional feature set, followed by the Iterative Self-Organizing Data Analysis Techniques Algorithm (ISODATA) clustering for high-precision extraction. Results demonstrate that the algorithm suits reservoir storage-desiccation dynamics; dual-polarization complementarity boosts accuracy and clarifies six reservoirs’ spatiotemporal evolution. Notably, post-2023, tunnel excavation-induced land subsidence increased drying frequency and duration, with a 24-month maximum cumulative desiccation period. Full article

Monitoring construction-phase settlement of estuary-crossing tunnels founded on coastal soft soils is critical for risk management, yet dense in situ measurements are often unavailable along linear corridors. This study uses Sentinel-1A ascending SAR imagery (65 scenes, September 2022–August 2025) to retrieve time-series deformation along the Sanya Estuary Channel tunnel (China) using Permanent Scatterer InSAR (PS-InSAR) and Small Baseline Subset InSAR (SBAS-InSAR). The two approaches reveal a consistent subsidence hotspot at Tunnel Section D (DK0+000–DK0+330), while most of the corridor remains within ±5 mm/a. The line-of-sight deformation rates range from −24 to 17.7 mm/year (PS-InSAR) and −29.9 to 18.7 mm/a (SBAS-InSAR). Time-series analysis at representative points in Section D indicates a maximum cumulative settlement of −75.7 mm and a clear acceleration after May 2023. By integrating the deformation results with geological reports, construction logs and rainfall records, we infer that compressible marine clays and interbedded sand/aquifer zones control the hotspot, whereas excavation/dewatering and rainfall-related groundwater fluctuations further promote consolidation. The results provide a practical basis for subsidence risk screening and monitoring prioritization for estuary-crossing infrastructure in coastal soft-soil settings. From a sustainability perspective, the proposed joint PS–SBAS InSAR framework provides a scalable and cost-effective tool for continuous deformation surveillance, supporting preventive maintenance and risk-informed management of urban underground infrastructure. Full article

The drainage of groundwater in mountainous tunnel projects always leads to substantial decline of the regional water table, which may induce numerous environmental issues, such as spring depletion, surface subsidence, vegetation degradation, and impacts on local water supplies, especially in the enclosed karst aquifers of anticlines in the area, such as the Jura mountain type. A systematic hydrological monitoring was conducted during the excavation of the Wufu Tunnel in Chongqing, China. The monitoring data includes discharge rate and water level collected from tunnels, boreholes, coal mines, springs, and ponds, respectively. Hydrological responses of karst aquifers and surface water bodies to tunnel drainage and precipitation were investigated by statistical analysis, Mann–Kendall test, heat map, and wavelet analysis. Results show that the enclosed karst water system has strong hydraulic connections and good water storage conditions. Tunnel drainage is the dominant factor causing dynamic changes at monitoring points, while the influence of rainfall is relatively limited. Borehole water levels and coal mine drainage have a close correlation with tunnel inflow, while springs are influenced by both rainfall and tunnel drainage. Few pond monitoring points are related to rainfall. Tunnel drainage has transformed the regional groundwater dynamic conditions, causing local groundwater flow direction reversal and reconstructing the groundwater recharge-flow-discharge pattern. Full article

To investigate the soil displacement rule caused by shield tunneling in soil–rock composite strata, the convergence mode of the shield excavation surface was analyzed. The research accounts for the variations in the slopes of the tunnel and the rock–soil interface along the excavation direction. Based on the stochastic medium theory, the calculation formula of soil displacement under different depths is derived. Surface subsidence was computed and evaluated using three engineering case studies. The results show that the calculated surface subsidence curves exhibit strong symmetry and are similar to the distribution pattern of the measured data. When tunneling through composite strata, the segments are prone to an upward floating motion, leading to a convergence pattern in the cross-section that tends toward a non-equal radial convergence mode with top tangency. Within the same project context, the grouting filling rate (δ) diminishes as the hard rock ratio (B) increases, exhibiting an approximate linear correlation. An increase in the hard rock ratio results in reduced values for lateral and longitudinal subsidence, the width of the lateral subsidence trough, and the main impact zone of the shield tunneling operations. Full article

Shield tunneling beneath existing railways remains a critical challenge in urban infrastructure development, as it risks destabilizing overlying soil structures and compromising railway safety. This study presents an integrated methodology combining physical model tests and three-dimensional numerical simulation, validated by their mutual agreement, to capture the settlement and deformation induced by twin shield tunneling beneath an operational railway under the complex geological conditions of the Qingdao Metro. A parametric study was subsequently conducted to systematically evaluate the influence of critical construction parameters, including grouting pressure, grout stiffness, and chamber pressure, on railhead settlement. Additionally, a comparative analysis assessed the effectiveness of settlement control measures, including D-type beam reinforcement, deep-hole grouting reinforcement, and their combined application. Results show that railhead deformation primarily manifests as settlement, with cumulative effects from sequential tunneling of the left and right lines. Proximity to fault zones intensifies crown subsidence, while tunneling induces significant soil stress relaxation, particularly in geologically weaker strata. Within optimal ranges, increased grouting pressure, chamber pressure, and grout stiffness effectively reduce railhead settlement; however, their efficacy diminishes beyond specific thresholds. The combined D-type beam and deep-hole grouting reinforcement scheme proved most effective in controlling settlement, ensuring railway operational safety and construction stability. These findings provide essential theoretical and practical guidance for optimizing shield tunneling strategies in complex urban environments, enhancing the safety and reliability of critical railway infrastructure. Full article

With the rapid advancement of urban underground space development, shield tunnel construction has seen a significant increase. However, at the initial launching stage of shield tunnels in shallow-buried weak strata, engineering risks such as face instability and sudden surface settlement frequently occur. At present, there are relatively few studies on the reinforcement technology of the initial section of shield tunnel in shallow soft ground and the evolution law of ground disturbance. This study takes the launching section of the Guanggang New City depot access tunnel on Guangzhou Metro Line 10 as the engineering background. By applying MIDAS/GTS numerical simulation, settlement monitoring, and theoretical analysis, the reinforcement technology at the tunnel face, the spatiotemporal evolution of ground settlement, and the mechanism of soil disturbance transmission during the launching process in muddy soil layer are revealed. The results show that: (1) the reinforcement scheme combining replacement filling, high-pressure jet grouting piles, and soil overburden counterpressure significantly improves surface settlement control. The primary influence zone is concentrated directly above the shield machine and in the forward excavation area. (2) When the shield machine reaches the junction between the reinforced and unreinforced zones, a large settlement area forms, with the maximum ground settlement reaching −26.94 mm. During excavation in the unreinforced zone, ground deformation mainly occurs beneath the rear reinforced section, with subsidence at the crown and uplift at the invert. (3) The transverse settlement trough exhibits a typical Gaussian distribution and the discrepancy between the measured maximum settlement and the numerical and theoretical values is only 3.33% and 1.76%, respectively. (4) The longitudinal settlement follows a trend of initial increase, subsequent decrease, and gradual stabilization, reaching a maximum when the excavation passes directly beneath the monitoring point. The findings can provide theoretical reference and engineering guidance for similar projects. Full article

Pipeline leakage can induce ground surface settlements and structural responses in existing tunnels. A thorough understanding of pipeline–tunnel interactions is crucial for optimizing urban underground design and establishing construction guidelines. As urban underground spaces undergo rapid, large-scale development, their layouts have grown increasingly complex. Previous studies have mainly focused on the leakage propagation range and the resulting strata instability during tunnel excavation, while paying limited attention to the effects of pipeline leakage on existing tunnels. This study systematically investigated the mechanical response of existing tunnel structures to pipeline leakage under different layout configuration conditions using numerical modeling. A two-dimensional numerical model was developed to simulate the pipeline leakage process and its impact on adjacent tunnels. The research established a correlation between surrounding rock strength parameters and the saturation degree while examining the evolution patterns of leakage effects in various tunnel–pipeline arrangements. The analysis specifically focused on the mechanical influence of horizontal pipeline–tunnel distance, quantitatively determining the relationships among pipeline–tunnel spacing, leakage duration, and structural internal force. The horizontal pipeline–tunnel distance did not influence the development of the leakage zone above the tunnel vault but significantly altered the seepage path length and interface contact area. The complete encapsulation of the tunnel periphery by the leakage zone required progressively longer durations with increasing horizontal offsets: 16 days (0 m), 20 days (3 m), and 33 days (6 m). Corresponding circumferential contact ratios at 10 days were measured at 68.9%, 56.4%, and 30.6%, respectively. Furthermore, prolonged seepage duration led to increased ground subsidence with expanded affected areas, while the maximum settlement decreased proportionally with greater horizontal separation from the tunnel. These findings provide valuable insights for planning, designing, and maintaining “old tunnel-new pipeline” systems in urban underground development. Full article

The top beam of a hydraulic support, serving as the central component of the hydraulic support assembly, directly withstands the impact loads generated by the subsidence of overlying rock strata. The structural strength and design rationality of the top beam directly determine the support effectiveness of the hydraulic support. In response to this issue, this study focuses on newly developed hydraulic combined supports for tunneling operations. Transient dynamic simulations were conducted at various positions on the top beams of individual supports under different working conditions, yielding stress and displacement changes in various regions of the support canopy when subjected to impact. We obtained the dynamic characteristics of the key parts of the hydraulic unit support during load bearing stress. Future work will explore the hydraulic system model and the interaction between mechanical and hydraulic subsystems. Full article

The thrust system, an important subsystem of a tunnel boring machine (TBM), primarily provides thrust force and adjusts TBM’s attitude in real time. In the tunneling process, only controlling the thrust speed causes pressure oscillations, increases soil deformation, and leads to surface subsidence or upheaval. Conversely, solely relying on pressure control causes fluctuations in speed, making it difficult to ensure that the deviation between the designed tunneling axis (DTA) and the actual tunneling axis (ATA) remains within the permissible range. Due to the increase in geological complexity and higher construction quality standards, primarily relying on single-mode speed or pressure control has become inadequate to meet operational demands. Therefore, to realize higher safety and precise trajectory tracking, it is necessary to ensure speed and pressure compound control for thrust systems. This paper proposes a novel adaptive sliding mode control (ASMC) strategy for thrust systems, which is composed of a proportional pressure relief valve (PPRV) and a proportional flow control valve (PFCV). Firstly, PPRV and PFCV are modeled as a second-order system and an ASMC is employed to control the pressure and speed. Next, to assess the performance of the ASMC controller, simulation experiments were conducted under various conditions, including speed regulation, sudden changed load, and disturbed load. The simulation results indicate that compared to the Proportion–Integral–Differential (PID) controller, the ASMC controller shows almost no overshoot in speed and pressure control during the initial stages, with the response time reduced by approximately 70%. During speed regulation process and sudden changed load process, the response time for both speed and pressure control is shortened by about 80%. In the disturbed load process, the ASMC controller maintains pressure stability. In conclusion, the ASMC controller significantly improves the response speed and stability of the thrust system, exhibiting better control performance under various operating conditions. Full article

Construction-induced mutual disturbance exerts a substantial influence on the ground settlement of double-line tunnels, and the ground settlement of double-line tunnels differs under varying excavation conditions. This study deeply analyzes the ground subsidence of a near-buried double-line tunnel when excavating in a complex geological environment. This study provides a framework for the design and construction of double-line shield tunnels and makes up for an important gap in the existing research. The findings indicate that the construction of post-excavation tunnels leads to secondary disturbances in the soil, resulting in increased ground settlement. The influence of tunnel lateral spacing on ground subsidence is greater than that of longitudinal excavation spacing. The ground settlement of a double-line tunnel excavated concurrently exhibits an initial increase, subsequently reaching a stable state as excavation progresses. For double-line tunnels with different excavation intervals, the settlement curves exhibit three stages. The maximum horizontal deformation of double-line tunnels decreases with increasing tunnel space, and the horizontal deformation of continuously excavated double-line tunnels is greater than that of synchronously excavated double-line tunnels. The incorporation of the settlement ratio, S’, unveils a linear correlation between the settlement and the tunnel space. Full article

In recent years, the rapid expansion of subway construction has brought increasing challenges related to the crossing of new and existing subway lines. This study focuses on the Nanjing Metro line 11 project, where the new line crosses the existing line 3. A numerical simulation analysis of the tunnel intersection area is conducted using ABAQUS software to investigate the deformation mechanism of shield segments when a new tunnel is constructed at a close distance and oblique angle to an existing tunnel. During the construction of a new tunnel, the existing tunnel segments experience the greatest settlement at the intersection point, with the deformation pattern gradually evolving from a V-shape to a W-shape. The majority of the deformation in the existing tunnel occurs during the close-crossing stage of the new tunnel. An ultra-high-performance grouting (UHPG) material is proposed, and the optimal reinforcement material ratio is determined through tests. The UHPG material is applied to the underside of the existing tunnels in the crossover section for local reinforcement. The results demonstrated the effectiveness of the proposed reinforcement method. Specifically, the deformation of the left line and right line of the existing tunnel is reduced by 35.0% and 33.1%, respectively, the segmental stress decreased by 10.1%, and the ground subsidence was reduced by 13.2%. Full article

Coal mining-induced ground subsidence is a severe hazard that can damage property, infrastructure, and the environment in the vicinity when the deformation is not negligible. The boundary of a mining-induced subsidence-affected zone refers to the area beyond which the ground subsidence is less concerned. Accurately measuring mining-induced ground deformation is essential for delineating the irregular boundary of the impacted area. This study employs multitemporal interferometric synthetic aperture radar (MT-InSAR) techniques, including differential InSAR (DInSAR), InSAR stacking, and interferometric point target analysis (IPTA), to analyze coal mine subsidence and delineate the boundaries of the mining-impacted zones. DInSAR accurately reconstructs, locates, and detects the trend in mining-induced subsidence and correlates well with documented mining operations. The InSAR stacking method maps the spatial variation of the ground’s average line-of-sight (LOS) velocity over the mining area, delineating the boundary of the impacted zone. IPTA analysis combining multilook and single-pixel phases achieves millimeter-level surface measurement above tunnel alignments and measures unevenly distributed deformation fields. This study considers an average of 4 cm per year of surface deformation in the LOS direction as the subsidence threshold value for delineating the boundary of the mining-induced subsidence-affected (MISA) zone during the active coal mining stage. Interestingly, there are twin transportation tunnels near the mining area. The twin tunnels completed before the coal mining activities started were functioning well, but damage was observed after the mining began. Our study reveals the tunnels are located within the InSAR-derived MISA zone, although the tunnels approach the MISA boundary. As direct signs of subsidence, ground fissures have been identified near the tunnels via field investigations and UAV photogrammetry. Furthermore, the derived distribution of ground fissures validates and verifies InSAR measurements. The integrated approach of MT-InSAR, UVA photogrammetry, and field investigation developed in this study can be applied to delineate the irregular boundary of the MISA zone and study the accumulating effects of mining-induced subsidence on the performance of infrastructure in areas proximate to coal mining activities. Full article

So as to efficiently address the distortion of surrounding rock in tunnels constructed utilizing ADECO-RS, it is crucial to define suitable parameters for advanced support systems. This study took the 8 # tunnel in the F3 portion of the E60 Expressway in Georgia as an engineering case. Initially, the original support scheme underwent systematic monitoring and analysis in the field. Subsequently, the FLAC3D 6.0 software was employed to examine the influence of the advanced pipe roof and tunnel face fiberglass bolts on the steady state of the surrounding rock. Optimization of the support parameters was also proposed. Further, the sensitivity of different parameters to the distortion of the rock surrounding the tunnel was analyzed and ranked via an orthogonal experiment. Ultimately, the effectiveness of the optimization scheme was evaluated by numerical methods and field observations. The findings of the research indicate the following: (1) The monitoring results of the original support parameters show that the irrational design of the support parameters can bring about deformation non-convergence in the tunnel’s surrounding rock. Support parameters must be optimized. (2) The spacing of the pipe roof is positively correlated with the distortion of the surrounding rock. In contrast, the length and the grouting strength are negatively correlated with the distortion of the surrounding rock. The reinforcement density, length, and lap length of glass fiber bolts exhibit an inverse relationship with the distortion of the surrounding rock. (3) The efficacy of pipe shed grouting in mitigating subsidence and deformation of the vault is superior, followed by the spacing of the supports. In contrast, the length of the supports demonstrates comparatively lesser effectiveness. Under optimal parameters, the vault subsidence was reduced by 23.2%, 10.2%, and 2.0%, respectively. The most significant factor controlling the extrusion deformation of the tunnel face is bolt lap length, followed by reinforcement density and then reinforcement length. Extrusion displacement was reduced by 52.5%, 40.3%, and 9.3%, respectively, under the optimal parameters. (4) In comparison to the primordial support system, the optimized support scheme reduces the subsidence of the vault by about one time and the convergence deformation around the cave by about two times. The research findings offer guidance for analogous engineering support design and parameter optimization. Full article
