The gyroid minimal surface is one type of triply periodic minimal surface (TPMS). TPMS is a minimal surface replicated in the three main directions of the Cartesian coordinate system. The minimal surface is a surface stretched between two objects, known as the smallest possible area (e.g., a soap bubble with a saddle shape stretched between two parallel circles). The complicated shape of the TPMS makes its production possible only by additive methods (3D printing). This article presents the results of experimental studies on heat transfer and flow resistance in a heat exchanger made of stainless steel. The heat exchange surface, a TPMS gyroid, separates two working media: hot and cold water. The water flow rate was varied in the range from 8 kg/h to 25 kg/h (Re = 246–1171). The water temperature at the inlet to the exchanger was maintained at a constant level of 8.8 ± 0.3 °C and 49.5 ± 0.5 °C for cold and hot water, respectively. The effect of water flow rate on the change in its temperature, the heat output of the exchanger, the average heat transfer coefficient, pressure drop, and overall resistance factor was presented. Full article

This study investigates the capillary performance and wetting behavior of SLA (Stereolithography) 3D-printed porous structures, focusing on TPMS (triply periodic minimal surfaces)-Gyroid, Octet, Diamond, and Isotruss lattice designs. High-speed imaging was used to analyze droplet interactions, including penetration, spreading, and contact angles, with 16 μL water droplets dropping from 30 mm at 0.77 m/s. Results showed variable contact angles, with Isotruss and Octet having higher angles, while Diamond faced measurement challenges due to surface roughness. Numerical simulations of TPMS-Gyroid of 2 mm³ unit cells validated the experimental results, and Diamond, Octet, and Isotruss structures were simulated. Capillary performance was assessed through deionized (DI) water weight–time (w-t) measurements, identifying that the TPMS-Gyroid structure performed adequately. Structures with 4 mm³ unit cells had low capillary performance, excluding them from permeability testing, whereas smaller 2 mm³ structures demonstrated capillary effects but had printability and cleaning issues. Permeability results indicated that Octet performed best, followed by Isotruss, Diamond, and TPMS-Gyroid. Findings emphasize unit cell size, beam thickness, and droplet positioning as key factors in optimizing fluid dynamics for cooling, filtration, and fluid management. Full article

Mycelium is a living material that has gained popularity over the last decade in both architecture and design. Apart from understanding the physical behaviour of novel materials, it is also important to grasp how designers and the general audience perceive them. On the one hand, this study investigated mycelium growth in 3D-printed minimal surface shapes using a wood-based filament, and on the other hand, it examined how both designers and the general public experience interacting with mycelium. Using a material-driven design research method, a workshop with architecture students was conducted where various triply periodic minimal surfaces were designed and 3D printed. These shapes were used as molds and impregnated with mycelium, and the growth of mycelium was analyzed visually and photographically. Data on the experiences of the 30 workshop participants of working with mycelium was collected through a survey and analyzed qualitatively. After exhibiting results of the workshop in a public-facing exhibition, semi-structured interviews with members of the general public about their perceptions of mycelium were conducted. Three-dimensionally printed minimal surfaces with wood-based filaments can function as structural cores for mycelium-based composites, and the density of the minimal surface appears to influence mycelium growth, which binds to wood-based filaments. Students exhibited stronger feelings for living materials compared to non-living ones, displaying both biophilia and, to a lesser extent, biophobia. Introducing hands-on workshops with living and experimental materials in design studio settings can help future generations of designers develop sensibilities for, and a critical approach towards, the impact of their design decisions on the environment and sustainability. The study also contributes empirical data on how members of the general public perceive mycelium as a material for design. Full article

The efficient thermal management of cutting tools is critical for ensuring dimensional accuracy, surface integrity, and tool longevity, especially in the high-speed dry machining process. However, conventional cooling methods often fall short in reaching the heat-intensive zones near the cutting inserts. This study proposes a novel internal cooling strategy that integrates triply periodic minimal surface (TPMS) structures into the toolholder, aiming to enhance localized heat removal from the cutting region. The thermal-fluidic behaviors of four TPMS topologies (Gyroid, Diamond, I-WP, and Fischer–Koch S) were systematically analyzed under varying coolant velocities using computational fluid dynamics (CFD). Several key performance indicators, including the convective heat transfer coefficient, Nusselt number, friction factor, and thermal resistance, were evaluated. The Diamond and Gyroid structures exhibited the most favorable balance between heat transfer enhancement and pressure loss. The experimental validation confirmed the CFD prediction accuracy. The results establish a new design paradigm for integrating TPMS structures into toolholders, offering a promising solution for efficient, compact, and sustainable cooling in advanced cutting applications. Full article

The proliferation of electromagnetic wave applications has accentuated electromagnetic pollution concerns, highlighting the critical importance of electromagnetic wave absorbers (EMA). This study proposes innovative I-Wrapped Package Lattice electromagnetic wave absorbers (IWP–EMA) based on the triply periodic minimal surface (TPMS) lattice structure. Through a rational design of porous gradient structures, broadband wave absorption was achieved while maintaining lightweight characteristics and mechanical robustness. The optimized three-dimensional configuration features a 20 mm thick gradient structure with a progressive relative density transition from 10% to 30%. Under normal incidence conditions, this gradient IWP–EMA basically achieves broadband absorption with a reflection loss below −10 dB across the 2–40 GHz frequency band, with absorption peaks below −19 dB, demonstrating good impedance-matching characteristics. Additionally, due to the complex interactions of electromagnetic waves within the structure, the proposed IWP–EMA achieves a wide-angle absorption range of 70° under Transverse Electric (TE) polarization and 70° under Transverse Magnetic (TM) polarization. The synergistic integration of the TPMS design and additive manufacturing technology employed in this study significantly expands the design space and application potential of electromagnetic absorption structures. Full article

This study presents a multi-objective optimization framework for designing cylindrical triply periodic minimal surface (TPMS) lattices tailored for bone implant applications. Using an artificial neural network (ANN) as a surrogate model trained on simulated data, four key properties—ultimate stress (U), energy absorption (EA), surface area-to-volume ratio (SA/VR), and relative density (RD)—were predicted from seven lattice design parameters. To address anatomical variability, a novel implant size-based categorization (small, medium, and large) was introduced, and separate optimization runs were conducted for each group. The optimization was performed via the NSGA-II algorithm to maximize mechanical performance (U and EA) and surface efficiency (SA/VR), while filtering for biologically relevant RD values (20–40%). Separate optimization runs were conducted for small, medium, and large implant size groups. A total of 105 Pareto-optimal designs were identified, with 75 designs retained after RD filtering. SHapley Additive exPlanations (SHAP) analysis revealed the dominant influence of thickness and unit cell size on target properties. Kernel density and boxplot comparisons confirmed distinct performance trends across size groups. The framework effectively balances competing design goals and enables the selection of size-specific lattices. The proposed approach provides a reproducible pathway for optimizing bioarchitectures, with the potential to accelerate the development of lattice-based implants in personalized medicine. Full article

Interpenetrating phase composites (IPCs) have demonstrated tremendous potential across various fields, particularly those based on triply periodic minimal surface (TPMS) structures, whose uniquely interwoven lattice architectures have attracted widespread attention. However, current research on the dynamic mechanical properties of such IPC remains limited, and their impact resistance and damage mechanisms are yet to be thoroughly understood. In this study, a novel design of two volume fractions of IPCs based on the TPMS IWP configuration is developed using Python-based parametric modeling, with the Ti6Al4V alloy TPMS scaffolds fabricated via selective laser melting (SLM) and the AlSi12 reinforcing phase through infiltration casting. The influence of Ti alloy volume fraction and strain rate on the dynamic mechanical behavior of the Ti/Al IPC is systematically investigated using a split Hopkinson pressure bar (SHPB) experimental setup. Microscopic characterization validates the effectiveness and reliability of the proposed IPC fabrication method. Results show that the increasing Ti alloy volume fraction significantly affects the dynamic mechanical properties of the IPC, and IPCs with different Ti alloy volume fractions exhibit contrasting mechanical behaviors under increasing strain rates, attributed to the dominance of different constituent phases. This study enhances the understanding of the dynamic behavior of TPMS-based IPCs and offers a promising route for the development of high-performance energy-absorbing materials. Full article

As the demand for advanced cooling solutions increases with the rise in artificial intelligence and high-performance computing, efficient thermal management becomes critical, particularly for data centers and electronic systems. Triply Periodic Minimal Surface (TPMS) heat sinks have shown superior thermal performance over conventional designs by enhancing heat transfer efficiency. In this study, a novel Fischer–Koch-S (FKS) TPMS heat sink was experimentally tested with four porosity configurations, 0.6 (identified as P6), 0.7 (identified as P7), 0.8 (identified as P8), and a gradient porosity ranging from 0.6 to 0.8 (identified as P678) along the flow direction, under a mass flow rate range of 0.012 to 0.019 kg/s. Key thermal parameters including surface temperature, thermal resistance, heat transfer coefficient, and Nusselt number were analyzed and compared to the conventional straight-channel heat sink (SCHS) using numerical modeling. Among all configurations, the P6 design demonstrated the best performance, with surface temperature differences ranging from 13.1 to 14.2 °C at 0.019 kg/s and a 54.46% higher heat transfer coefficient compared to the P8 design at the lowest mass flow rate. Thermal resistance decreased consistently with an increasing mass flow rate, with P6 achieving a 31.8% reduction compared to P8 at 0.019 kg/s. The P678 gradient design offered improved temperature uniformity and performance at higher mass flow rates. Nusselt number ratios confirmed that low-porosity and gradient TPMS designs outperform the SCHS, with performance advantages increasing as the mass flow rate rises. To further enhance the experimental process, a deep learning model based on a Temporal Convolutional Network (TCN) was developed to predict steady-state surface temperatures using early-stage time-series data, to reduce test time and enable efficient validation. Full article

Advanced gas turbine cooling technologies are required to bridge the gap between turbine inlet temperatures and component thermal limits. Transpiration cooling has emerged as a promising method, leveraging porous structures to enhance cooling effectiveness. Recent advancements in additive manufacturing (AM) enable precise fabrication of complex transpiration cooling architectures, such as triply periodic minimal surface (TPMS) and biomimetic designs. This review analyzes AM-enabled transpiration cooling for gas turbines, elucidating key parameters, heat transfer mechanisms, and flow characteristics of AM-fabricated designs through experimental and numerical studies. Previous research has concluded that well-designed transpiration cooling achieves cooling effectiveness up to five times higher than the traditional film cooling methods, minimizes jet lift-off, improves temperature uniformity, and reduces coolant requirements. Optimized coolant controls, graded porosity designs, complex topologies, and hybrid cooling architectures further enhance the flow uniformity and cooling effectiveness in AM transpiration cooling. However, challenges remain, including 4–77% porosity shrinkage in perforated transpiration cooling for 0.5–0.06 mm holes, 15% permeability loss from defects, and 10% strength reduction in AM models. Emerging solutions include experimental validations using advanced diagnostics, high-fidelity multiphysics simulations, AI-driven and topology optimizations, and novel AM techniques, which aim at revolutionizing transpiration cooling for next-generation gas turbines operating under extreme conditions. Full article

This study explores the mechanical performance of triply periodic minimal surface (TPMS) and stochastic lattice structures subjected to low-velocity impact. Two structurally promising geometries—one TPMS-based and one stochastic—were tested and compared with the well-established gyroid. Specimens were fabricated using stereolithography (SLA) and subjected to impact energies of 30 J and 40 J to assess the structural response and energy absorption capabilities. Experimental results show that the proposed TPMS structure exhibits higher impact forces compared with the gyroid, which are associated with significant impactor displacement and deep indentation. These samples demonstrated extensive damage, with cracking propagating through the entire core at higher energies, highlighting their susceptibility to structural failure despite their high initial strength. On the contrary, the stochastic structures allowed localized deformation in the impacted region, thus successfully avoiding catastrophic failure. The impact force efficiency was higher for both gyroid and stochastic geometries, with values ranging between 0.6 and 0.7, indicating effective energy absorption with reduced internal stress gradients. Furthermore, the evaluation of damping performance showed that most structures displayed high damping, as minimal energy was transferred back to the impactor. This work highlights the feasibility and functional versatility of TPMS and stochastic geometries for use in impact mitigation, vibration control, and related engineering applications. Full article

Critical-sized bone defects or CSDs result from bone loss due to trauma, tumor removal, congenital defects, or degenerative diseases. Though autologous bone transplantation is the current gold standard in treating CSDs, its limitations include donor-site morbidity, unavailability of donor bone tissues, risk of infection, and mismatch between the bone geometry and the defect site. Customized scaffolds fabricated using 3D printing and biocompatible materials can provide mechanical integrity and facilitate osseointegration. Ti-6Al-4V (Ti64) is one of the most widely used commercial alloys in orthopedics. To avoid elastic modulus mismatch between bones and Ti64, it is imperative to use porous lattice structures. Ti64 scaffolds with diamond, cubic, and triply periodic minimal surface (TPMS) gyroid lattice architectures were fabricated using selective laser melting (SLM)with pore sizes ranging from 300 to 900 μm using selective laser melting and evaluated for mechanical and biological performance. Increasing pore size led to higher porosity (up to 90.54%) and reduced mechanical properties. Young’s modulus ranged from 13.18 GPa to 1.01 GPa, while yield stress decreased from 478.16 MPa to 14.86 MPa. Diamond and cubic scaffolds with 300–600 μm pores exhibited stiffness within the cortical bone range, while the 900 μm diamond scaffold approached trabecular stiffness. Gyroid scaffolds (600–900 μm) also showed modulus and yield strength within the cortical bone range but were not suitable for trabecular applications due to their higher stiffness. Cytocompatibility was confirmed through leachate analysis and DAPI-stained osteoblast nuclei. The biological evaluation reported maximum cell adherence in lower pore sizes, with gyroid scaffolds showing a statistically significant (p < 0.01) increase in cell proliferation. These findings suggest that 300–600 μm lattice scaffolds offer an optimal balance between mechanical integrity and biological response for load-bearing bone repair. Full article

The design of scaffolds and prostheses benefits from the opportunities provided by additive manufacturing technologies. Specifically, scaffold design using cellular structures based on lattices has become a significant focus. These lattice-based scaffolds exhibit intricate and complex shapes with controlled macro-porosity. In this study, a method is presented that enables the modeling of a graded-density lattice structure for material extrusion additive manufacturing, without relying on a geometric lattice model. The methodology utilizes computed tomography (CT) scans as inputs to obtaining a 3D scalar field and a surface model. The lattice structure is designed and generated within the computer-aided manufacturing (CAM) software, ensuring consistent machine toolpaths. The 3D scalar field, representing a relative density map derived from CT Hounsfield units, drives the variation of the extrusion parameters generated by the CAM, achieving a graded-density lattice. To demonstrate the effectiveness of the method, a section of a human femur bone with a lattice with a triply periodic minimal surface (TPMS) gyroid pattern was designed and 3D-printed, replicating the relative density of the target tissue. Full article

Polymer heat exchangers (HXs) are lightweight and cost-effective due to the affordability of raw polymer materials. However, the inherently low thermal conductivity (TC) of polymers limits their application in HXs. To enhance thermal conductivity polymer composites, two types of diamond powders, with particle sizes of 0.25 µm and 16.7 µm, were used as fillers, while Acrylonitrile Butadiene Styrene (ABS) served as the matrix. Composite polymer samples were fabricated, and their density and thermal conductivity were tested and compared. The results indicate that fillers with larger particle sizes tend to exhibit higher thermal conductivity. A polymer HX based on a Triply Periodic Minimal Surface (TPMS) structure was designed. The factors influencing the efficiency of polymer HXs were analyzed and compared with those of metal HXs. In polymer HXs, the polymer wall is the primary source of heat resistance. Additionally, the mechanical strength of 3D-printed polymer parts was evaluated. Finally, an HX was successfully fabricated using a polymer composite containing 50 wt% diamond powder via 3D printing. Full article

We review the connections between condensed matter physics, symmetry, and topology. Physics goes back to at least the time of Galileo, but condensed matter physics, or solid-state physics, is a much newer, emerging only as a separate subject in the 1940s. The subject of symmetry, which is the mathematics of groups and representations, only came to the fore with the advent of quantum mechanics. Early applications to crystalline solids include Bloch’s theorem, the symmetry of electronic and phononic energy bands, and selection rules. Topology, on the other hand, did not exist as a mathematical subject before the twentieth century, but has had a profound influence on physics in general, and on condensed matter physics in particular. The quantum Hall effect is recognized as the first solid-state topological phenomenon and, along with the Berry phase, led to the development of topological materials. This, in turn, led to the topological description of energy bands and to the development of topological quantum chemistry and the energy band representation. Topology has also led to the description of martensitic transformations and the shape memory effect in terms of topological transformations. Apart from a concise statement of martensitic transformations, topology provides a fast-screening method for the discovery of new shape-memory materials. We review these phenomena, providing background material in topology and differential geometry to enable the reader to understand applications to topological materials and to materials physics. Full article

This paper proposes two compact, efficient, and lightweight heat exchangers based on triply periodic minimal surfaces (TPMSs). Designed in an annular configuration, the heat exchangers meet the requirements of micro gas turbines for compactness. Two prototypes of Diamond and Gyroid modular TPMS heat exchangers were fabricated using selective laser melting (SLM) with stainless steel. The flow and heat transfer experimental results indicate that, within a Reynolds number range of 200 to 800, the effectiveness of both heat exchangers remained above 0.62, and the average Nusselt numbers of the Diamond and Gyroid structures reached 3.60 and 4.06 times that of the printed circuit heat exchanger (PCHE), respectively. Although both heat exchangers exhibited relatively high friction factors, their overall performance surpassed that of conventional heat exchangers. Additionally, performance comparisons with existing TPMS heat exchangers revealed that smaller lattice sizes contribute to improved volume-based power density, although they result in increased pressure loss. Simulation results indicated that the “merge–split” effect present in both structures enhances heat transfer between the fluid and the wall. Furthermore, the complex channels of the TPMS structures ensure that the fluid maintains strong turbulence intensity throughout the heat exchanger. This study demonstrates that stainless steel TPMS structures can serve as excellent candidates for applications in micro gas turbines. Full article
