Search Results (38)

Background: Advances in prosthetic technology, especially microprocessor-controlled knees (MPKs), have helped enhance gait symmetry and reduce fall risks for individuals who have undergone transfemoral amputation. However, challenges remain in walking in constrained situations due to the limitations of passive prosthetic feet, lacking ankle mobility. This study investigates the benefits of SYNSYS^®, a new microprocessor-controlled knee–ankle–foot system (MPKA_NEW), designed to synergize knee and ankle movements. Methods: A randomized crossover trial was conducted on 12 male participants who had undergone transfemoral amputation who tested both the MPKA_NEW and their usual MPK prosthesis. Biomechanical parameters were evaluated using quantitative gait analysis in various walking conditions. Participants also completed self-reported questionnaires on their quality of life, locomotor abilities, and prosthesis satisfaction. Results: The MPKA_NEW showed a significant reduction in the risk of slipping and tripping compared to standard MPK prostheses, as evidenced by increased flat-foot time and minimum toe clearance during gait analysis. The MPKA_NEW also improved physical component scores in quality-of-life assessments (Short-Form 36 General Health Questionnaire), suggesting enhanced stability and reduced cognitive load during walking. Conclusions: The MPKA_NEW offers significant improvements in gait safety and quality of life for people who have undergone TFA, particularly in challenging conditions. Further studies are needed to assess the long-term benefits and adaptability across diverse amputee populations. Full article

Phantom limb pain, a common challenge for amputees, lacks effective treatment options. Vibration therapy is a promising non-pharmacologic intervention for reducing pain intensity, but its efficacy in alleviating phantom limb pain requires further investigation. This study focused on developing prosthesis liners with integrated vibration motors to administer vibration therapy for phantom limb pain. The prototypes developed for this study addressed previous issues with wiring the electronic components. Two transfemoral amputees participated in a four-week at-home trial, during which they used the vibration liner and rated their initial and final pain intensity on a numeric rating scale each time they had phantom pain. Semi-structured interviews were conducted to gather feedback following the at-home trial. Both participants described relaxing and soothing sensations in their residual limb and phantom limb while using vibration therapy. One participant reported a relaxation of his phantom limb sensations, while both participants noted a decrease in the intensity of their phantom limb pain. Participants said the vibration liners were comfortable but suggested that the vibration could be stronger and that aligning the contacts could be easier. The results of this study highlight the potential effectiveness of using vibration therapy to reduce the intensity of phantom limb pain and suggest a vibration liner may be a feasible mode of administering the therapy. Future research should address optimizing the performance of the vibration liners to maximize their therapeutic benefits. Full article

Background/Objectives: This study aimed to evaluate bone mineral density (BMD) discordance and its implications in veterans with unilateral lower-limb amputation, emphasizing the need for comprehensive hip assessments. Methods: Data were collected from 84 male veterans, and BMD was measured using dual-energy X-ray absorptiometry (DXA) at the lumbar spine, intact hip, and amputated hip. Results: The T-scores for the lumbar spine, intact hip, and amputated hip were −0.27 ± 1.69, −0.25 ± 1.20, and −1.07 ± 1.33, respectively. Osteoporosis and osteopenia were present in 19% and 34.6% of patients, respectively. Osteopenia and osteoporosis were most prevalent in the hips on the amputated side (32.1% and 13.1%, respectively), followed by the lumbar spines (22.6% and 8.3%) and the hips on the intact side (17.9% and 2.4%). BMD discordance between the lumbar spine and hip was found in 47.6% of participants, while discordance between both hips was observed in 39.3%. Transfemoral amputees had significantly lower BMD at the amputated hip compared to transtibial amputees (−2.38 ± 1.72 vs. −0.87 ± 1.16, p < 0.001). Conclusions: Veterans with unilateral lower-limb amputation exhibit a high prevalence of osteoporosis and significant BMD discordance, particularly between both hips. These findings underscore the necessity for bilateral hip assessments to ensure the accurate diagnosis and effective management of osteoporosis in this population. Full article

Objective: To train a machine-learning (ML) algorithm to classify stumbling in transfemoral amputee gait. Methods: Three subjects completed gait trials in which they were induced to stumble via three different means. Several iterations of ML algorithms were developed to ultimately classify whether individual steps were stumbles or normal gait using leave-one-out methodology. Data cleaning and hyperparameter tuning were applied. Results: One hundred thirty individual stumbles were marked and collected during the trials. Single-layer networks including Long-Short Term Memory (LSTM), Simple Recurrent Neural Network (SimpleRNN), and Gradient Recurrent Unit (GRU) were evaluated at 76% accuracy (LSTM and GRU). A four-layer LSTM achieved an 88.7% classic accuracy, with 66.9% step-specific accuracy. Conclusion: This initial trial demonstrated the ML capabilities of the gathered dataset. Though further data collection and exploration would likely improve results, the initial findings demonstrate that three forms of induced stumble can be learned with some accuracy. Significance: Other datasets and studies, such as that of Chereshnev et al. with HuGaDB, demonstrate the cataloging of human gait activities and classifying them for activity prediction. This study suggests that the integration of stumble data with such datasets would allow a knee prosthesis to detect stumbles and adapt to gait activities with some accuracy without depending on state-based recognition. Full article

Facing above-knee amputation poses a significant hurdle due to its profound impact on walking ability. To overcome this challenge, a complex adaptation strategy is necessary at the neuromuscular level to facilitate safe movement with a prosthesis. Prior research conducted on lower-limb amputees has shown a comparable amount of intricacy exhibited by the neurological system, regardless of the level of amputation and state of walking. This research investigated the differences in muscle synergies among individuals with unilateral transfemoral amputations during walking at three different speeds of transient-state gait. Surface electromyography was recorded from eleven male transfemoral amputees’ intact limbs (TFA), and the concatenated non-negative matrix factorization technique was used to identify muscle synergy components, synergy vectors (S), and activation coefficient profiles (C). Results showed varying levels of correlation across paired-speed comparisons in TFA, categorized as poor (S1), moderate (S3 and S4), and strong (S2). Statistically significant differences were observed in all activation coefficients except C3, particularly during the stance phase. This study can assist therapists in understanding muscle coordination in TFA during unsteady gait, contributing to rehabilitation programs for balance and mobility improvement, and designing myoelectric prosthetic systems to enhance their responsiveness to trips or falls. Full article

For amputees, amputation is a devastating experience. Transfemoral amputees require an artificial lower limb prosthesis as a replacement for regaining their gait functions after amputation. Microprocessor-based transfemoral prosthesis has gained significant importance in the last two decades for the rehabilitation of lower limb amputees by assisting them in performing activities of daily living. Commercially available microprocessor-based knee joints have the needed features but are costly, making them beyond the reach of most amputees. The excessive cost of these devices can be attributed to custom sensing and actuating mechanisms, which require significant development cost, making them beyond the reach of most amputees. This research contributes to developing a cost-effective microprocessor-based transfemoral prosthesis by integrating off-the-shelf sensing and actuating mechanisms. Accordingly, a three-level control architecture consisting of top, middle, and low-level controllers was developed for the proposed prosthesis. The top-level controller is responsible for identifying the amputee intent and mode of activity. The mid-level controller determines distinct phases in the activity mode, and the low-level controller was designed to modulate the damping across distinct phases. The developed prosthesis was evaluated on unilateral transfemoral amputees. Since off-the-shelf sensors and actuators are used in i-Inspire, various trials were conducted to evaluate the repeatability of the sensory data. Accordingly, the mean coefficients of correlation for knee angle, force, and inclination were computed at slow and medium walking speeds. The obtained values were, respectively, 0.982 and 0.946 for knee angle, 0.942 and 0.928 for knee force, and 0.825 and 0.758 for knee inclination. These results confirmed that the data are highly correlated with minimum covariance. Accordingly, the sensors provide reliable and repeatable data to the controller for mode detection and intent recognition. Furthermore, the knee angles at self-selected walking speeds were recorded, and it was observed that the i-Inspire Knee maintains a maximum flexion angle between 50° and 60°, which is in accordance with state-of-the-art microprocessor-based transfemoral prosthesis. Full article

Amputees typically experience changes in residual limb volume in their daily lives. It causes an uncomfortable fit of the socket by applying high pressure on the sensitive area of the residual limb or by loosening the socket. In this study, we developed a transfemoral prosthetic socket for above-the-knee amputees that ensures a good socket fit by maintaining uniform and constant contact pressure despite volume changes in the residual limb. The socket has two air bladders in the posterior femoral region, and the pneumatic controller is located on the tibia of the prosthesis. The pneumatic system aims to minimize unstable fitting of the socket and improve walking performance by inflating or deflating the air bladder. The developed socket autonomously maintains the air pressure inside the prosthetic socket at a steady-state error of 3 mmHg or less by adjusting the amount of air in the air bladder via closed-loop control. In the clinical trial, amputee participants walked on flat and inclined surfaces. The displacement between the residual limb and socket during the gait cycle was reduced by up to 33.4% after air injection into the socket. The inflatable bladder increased the knee flexion angle on the affected side, resulting in increased stride length and gait velocity. The pneumatic socket provides a stable and comfortable walking experience not only when walking on flat ground but also on slopes. Full article

Microprocessor-controlled prosthetic knees (MPKs) improve the safety and functional capabilities of transfemoral amputees, but there is a lack of information on plantar pressure distribution and effects among individuals who have undergone transfemoral amputation of the sound limb. (1) Background: The aim of this study was to determine possible compensatory mechanisms in gait by evaluating intact extremity foot plantar pressure distribution in young MPK prosthesis users. Twenty-one patients with unilateral transfemoral amputation (TFA) and twenty-four healthy individuals were selected for the study. (2) Methods: The WalkinSense system was used to assess different foot plantar pressure distribution parameters as the participants walked at their chosen walking speed. Plantar pressure peaks and activation percentages in the eight foot regions were measured during the gait cycle. (3) Results: The pressure peaks and activation percentages in the sound limb with TFA patients and healthy subjects were measured, and statistically significant differences between the two groups were identified. The 1-, 2-, 3-, 4-, and 6-point sensor activation percentages significantly increased, whereas the 7- and 8-point sensor activation percentages decreased in the sound limb TFA participants compared with the healthy subjects. Peak plantar pressure sensor points 1, 3, 4, and 6 increased in the TFA sound limb foot in relation to healthy individuals, while they decreased in point 8. (4) Conclusion: In this study, with the use of a microprocessor knee joint TF prosthesis, in the evaluation of the underfoot pressure of intact legs, the maximum pressure point shifted to the forefoot, and it was observed that the forefoot and midfoot were more active during walking compared with the control group. This may indicate that gait compensation and plantar flexion in the sound limb are used more forcefully in the gait cycle. Full article

The soft tissues of residual limb amputees are subject to large volume fluctuations over the course of a day. Volume fluctuations in residual limbs can lead to local pressure marks, causing discomfort, pain and rejection of prostheses. Existing methods for measuring interface stress encounter several limitations. A major problem is that the measurement instrumentation is applied in the sensitive interface between the prosthesis and residual limb. This paper presents the principle investigation of a non-intrusive technique to evaluate the fit of orthopaedic prosthesis sockets in transfemoral amputees based on experimentally obtained vibrational data. The proposed approach is based on changes in the dynamical behaviour detectable at the outer surface of prostheses; thus, the described interface is not affected. Based on the experimental investigations shown and the derived results, it can be concluded that structural dynamic measurements are a promising non-intrusive technique to evaluate the fit of orthopaedic prosthesis sockets in transfemoral amputee patients. The obtained resonance frequency changes of 2% are a good indicator of successful applicabilityas these changes can be detected without the need for complex measurement devices. Full article

The aim of this review article is to appraise the design and functionality of above-knee prosthetic legs. So far, various transfemoral prosthetic legs are found to offer a stable gait to amputees but are limited to laboratories. The commercially available prosthetic legs are not reliable and comfortable enough to satisfy amputees. There is a dire need for creating a powered prosthetic knee joint that could address amputees’ requirements. To pinpoint the gap in transfemoral prosthetic legs, prosthetic knee unit model designs, control frameworks, kinematics, and gait evaluations are concentrated. Ambulation exercises, ground-level walking, running, and slope walking are considered to help identify research gaps and areas where existing prostheses can be ameliorated. The results show that above-knee amputees can more effectively manage their issues with the aid of an active prosthesis, capable of reliable gait. To accomplish the necessary control, closed loop controllers and volitional control are integral parts. Future studies should consider designing a transfemoral electromechanical prosthesis based on electromyographic (EMG) signals to better predict the amputee’s intent and control in accordance with that intent. Full article

The aim of the present case report was to provide a longitudinal functional assessment of a patient with transfemoral amputation from the preoperative status with socket-type prosthesis to one year after the osseointegration surgery. A 44 years-old male patient was scheduled for osseointegration surgery 17 years after transfemoral amputation. Gait analysis was performed through 15 wearable inertial sensors (MTw Awinda, Xsens) before surgery (patient wearing his standard socket-type prosthesis) and at 3-, 6-, and 12-month follow-ups after osseointegration. ANOVA in Statistical Parametric Mapping was used to assess the changes in amputee and sound limb hip and pelvis kinematics. The gait symmetry index progressively improved from the pre-op with socket-type (1.14) to the last follow-up (1.04). Step width after osseointegration surgery was half of the pre-op. Hip flexion-extension range significantly improved at follow-ups while frontal and transverse plane rotations decreased (p < 0.001). Pelvis anteversion, obliquity, and rotation also decreased over time (p < 0.001). Spatiotemporal and gait kinematics improved after osseointegration surgery. One year after surgery, symmetry indices were close to non-pathological gait and gait compensation was sensibly decreased. From a functional point of view, osseointegration surgery could be a valid solution in patients with transfemoral amputation facing issues with traditional socket-type prosthesis. Full article

Significant advances have been made in prostheses with the aim of enhancing the quality of life for transfemoral amputees. While commercially available transfemoral prostheses mainly focus on the developing passive prostheses that act only as dampers, academic research is centered round powered prostheses that can provide net-positive knee torque. Although recent active-powered prostheses have made excellent progress in terms of weight and battery life, it remains unclear if these prostheses can be effectively used in everyday life. This study presents a rotary hybrid prosthesis based on the combination of a multifunctional rotary hydraulic cylinder that is designed to operate as a brake, clutch, and damper with a 100 W active motor system. This prosthesis enables long-term level ground walking while supplying active power as needed. The passive and active components of this hybrid prosthesis are designed such that they can be decoupled when operated independently, allowing for quick switching between passive and active modes in 50–100 ms. The study outlines the aims and procedures for the design of rotary hybrid prostheses, as well as the feasibility tests for each module and the amputee’s clinical test on the developed knee prosthesis. Full article

Background and Objectives: The treatment of transfemoral amputees using osseointegrated implants for prosthetic anchorage requires accurate implant positioning when using threaded bone-anchoring implants due to the curvature of the femur and the risk of cortical penetration in misaligned implants. This study investigated the accuracy and precision in implant positioning using additively manufactured case-specific positioning guides. Materials and Methods: The geometry and density distribution of twenty anatomic specimens of human femora were assessed in quantitative computed tomography (QCT) scanning. The imaging series were used to create digital 3D specimen models, preoperatively plan the optimal implant position and manufacture specimen-specific positioning guides. Following the surgical bone preparation and insertion of the fixture (threaded bone-anchoring element) (OPRA; Integrum AB, Mölndal, Sweden), a second QCT imaging series and 3D model design were conducted to assess the operatively achieved implant position. The 3D models were registered and the deviations of the intraoperatively achieved implant position from the preoperatively planned implant position were analyzed as follows. The achieved, compared to the planned implant position, was presented as resulting mean hip abduction or adduction (A/A) and extension or flexion (E/F) and mean implant axis offset in medial or lateral (M/L) and anterior or posterior (A/P) direction measured at the most distal implant axis point. Results: The achieved implant position deviated from the preoperative plan by 0.33 ± 0.33° (A/A) and 0.68 ± 0.66° (E/F) and 0.62 ± 0.55 mm (M/L) and 0.68 ± 0.56 mm (A/P), respectively. Conclusions: Using case-specific guides, it was feasible to achieve not only accurate but also precise positioning of the implants compared to the preoperative plan. Thus, their design and application in the clinical routine should be considered, especially in absence of viable alternatives. Full article

Individuals with lower-limb amputations may have a significant strength deficit. This deficit may be related to the stump length and can lead to changes in gait, reduced energy efficiency, walking resistance, altered joint load, and increased risk of osteoarthritis and chronic low back pain. This systematic review used the Preferred Reporting Items for Systematic Reviews and Meta-Analyzes (PRISMA) guidelines to examine the effects of resistance training in lower limb amputees. Interventions with resistance training and other training methods were sufficient to achieve muscle strength gain in muscles of the lower limbs, improved balance, and improvements in gait pattern and speed when walking. However, it was impossible to determine from the results whether resistance training was mainly responsible for these benefits or even whether the positive effects presented would be observed with only this training method. When combined with other exercises, interventions with resistance training made possible gains for this population. Accordingly, it is noteworthy that the main finding of this systematic review is that the effects may be different according to the level of amputation, with mainly transtibial and transfemoral amputations studied. Full article

Many people struggle with mobility impairments due to lower limb amputations. To participate in society, they need to be able to walk on a wide variety of terrains, such as stairs, ramps, and level ground. Current lower limb powered prostheses require different control strategies for varying ambulation modes, and use data from mechanical sensors within the prosthesis to determine which ambulation mode the user is in. However, it can be challenging to distinguish between ambulation modes. Efforts have been made to improve classification accuracy by adding electromyography information, but this requires a large number of sensors, has a low signal-to-noise ratio, and cannot distinguish between superficial and deep muscle activations. An alternative sensing modality, A-mode ultrasound, can detect and distinguish between changes in superficial and deep muscles. It has also shown promising results in upper limb gesture classification. Despite these advantages, A-mode ultrasound has yet to be employed for lower limb activity classification. Here we show that A- mode ultrasound can classify ambulation mode with comparable, and in some cases, superior accuracy to mechanical sensing. In this study, seven transfemoral amputee subjects walked on an ambulation circuit while wearing A-mode ultrasound transducers, IMU sensors, and their passive prosthesis. The circuit consisted of sitting, standing, level-ground walking, ramp ascent, ramp descent, stair ascent, and stair descent, and a spatial–temporal convolutional network was trained to continuously classify these seven activities. Offline continuous classification with A-mode ultrasound alone was able to achieve an accuracy of $91.8\pm 3.4\%$, compared with $93.8\pm 3.0\%$, when using kinematic data alone. Combined kinematic and ultrasound produced $95.8\pm 2.3\%$ accuracy. This suggests that A-mode ultrasound provides additional useful information about the user’s gait beyond what is provided by mechanical sensors, and that it may be able to improve ambulation mode classification. By incorporating these sensors into powered prostheses, users may enjoy higher reliability for their prostheses, and more seamless transitions between ambulation modes. Full article
