Search Results (29)

In this paper, results are presented for an on-road measurement campaign for measuring the brake wear particles of disc brakes on a heavy-duty tractor trailer during the EU P012101 Pilot Project funded by the European Parliament. A novel approach was adopted using a fully open sampling system with minimal influence on air flow around the brake and brake disc temperatures. Models for brake disc heating and cooling were developed, as well as a model for the particle number emissions. It was concluded that brake wear emissions per kilometre were the highest on urban roads and the lowest on the motorway. Furthermore, when modelling heating during braking actions, the best results were seen when introducing dependencies on both the braking work and initial brake temperatures. When modelling the brake cooling, a non-linear dependence on the difference between the brake disc temperature and ambient air temperature was empirically observed. For the particle number emissions, a relationship was established between the braking work applied to the disc during the braking action and the particle number emissions of the braking action. Full article

Agricultural tractors are equipped with air braking systems to supply and control the braking systems of towed vehicles. This system’s functional and operational characteristics significantly impact the compatibility and speed of the braking system of the tractor–trailer combination and are therefore checked during approval tests. This paper presents a test methodology and a description of the instrumentation and apparatus used to test the air braking systems of tractors under stationary conditions, as required by EU Regulation 2015/68. Sample test results of the trailer air supply system are included, such as checking the system for leaks, checking the pressure at the coupling heads, checking the compressor flow rate and air reservoir capacity, and checking the response time of the tractor control line. Approval authorities and tractor manufacturers can use the work results for quality control or product qualification tests. Full article

The design and industrial innovation of intelligent agricultural machinery and equipment for saline alkali land are important means for comprehensive management and capacity improvement of saline alkali land. The autonomous and unmanned agricultural tractor is the inevitable trend of the development of intelligent machinery and equipment in saline alkali land. As an underactuated system with non-holonomic constraints, the independent trajectory planning and lateral stability control of the tractor-trailer system (TTS) face challenges in saline alkali land. In this study, based on the nonlinear underactuation characteristics of the TTS and the law of passive trailer steering, a dual-trajectory collaborative control model was designed. By solving the TTS kinematic/dynamic state space, a nonlinear leading system that can generate the reference pose of a tractor-trailer was constructed. Based on the intrinsic property of the lateral deviation of the TTS, a collaborative trajectory prediction algorithm that satisfies the time domain and system constraints is proposed. Combining the dual-trajectory independent offset and lateral stability parameter of the TTS, an energy function optimization control parameter was constructed to balance the system trajectory tracking performance and lateral control stability. The experimental results showed good agreement between the predicted trailer trajectory and the collaborative control trajectory, with an average lateral error not exceeding 0.1 m and an average course angle error not exceeding 0.054 rad. This ensures that the dynamic controller designed around the tractor-trailer underactuation system can guarantee the smoothness of the trailer trajectory and the controlling stability of the tractor in saline alkali land. Full article

Articulated heavy vehicles exhibit poor lateral stability, which may lead to unstable motion modes, e.g., trailer-sway and jackknifing, causing severe accidents. Varying relevant vehicle parameters improves the static stability but degrades the dynamic stability. The past studies focused either on the static or dynamic stability alone. However, little attention has been paid to exploring the trade-off between the static and dynamic stabilities. To gain design insights for active safety systems for AHVs, this article studies this trade-off systematically. To this end, a systematic method is proposed to conduct the linear stability and trade-off analysis. To implement and demonstrate the proposed method, a linear three-degrees-of-freedom yaw-plane model is generated to represent a tractor/semi-trailer. A trade-off analysis is conducted considering two tractor rear-axle configurations and three trailer payload arrangements. In each case, simulation is performed in both steady-state and transient testing maneuvers. To validate the linear stability analysis based on the linear yaw-plane model, two nonlinear TruckSim models are introduced, and the corresponding simulation is conducted. Insightful understanding of the trade-off is gained through analyzing the simulation results, and the linear stability analysis will provide valuable guidelines for the design and development of active safety systems for AHVs. Full article

The semi-trailer ECPBS is adopted to achieve coordinated braking between tractor and trailer. Its control strategies are mainly verified through MIL and HIL tests. The correctness of the test results relies on the precision of the models. The dependence on the vehicle simulation models can be greatly reduced through an in-loop testing system, which combines the ECPB hardware test bench with the semi-trailer twin test vehicle. However, due to the long spatial distance between the two, higher requirements are placed on the real-time performance of the testing system. The communication interconnection mode, distributed network architecture, data coupling method and data coupling method of the in-loop testing system were investigated. Moreover, a delay compensation controller based on model prediction was designed and was applied to the motion control of the twin test vehicle. The simulation results have shown that the compensation controller can ensure the stability of vehicle motion with a goodness-of-fit of 0.826 under a delay of 0.7 s. Further experimental verification shows that the instructions issued by the ECPB hardware test bench controller can reach the semi-trailer twin test vehicle within 0.6 s, indicating that the communication interconnection method is feasible and can meet the real-time requirements of the in-loop testing system. Full article

Autonomous tractor–trailer robots possess a broad spectrum of applications but pose significant challenges in control due to their nonlinear and underactuated dynamics. Unlike the tractor, the motion of the trailer cannot be directly actuated, which often results in a deviation from the intended path. In this study, we introduce a novel method for generating and following trajectories that circumvent obstacles, tailored for a tractor–trailer robotic system constrained by multiple factors. Firstly, leveraging the state information of both the obstacles and the desired trajectory, we formulate an improved trajectory for obstacle avoidance using the nonlinear least squares method. Subsequently, we propose an innovative tracking controller that integrates a universal barrier function with a state transformation strategy. This amalgamation facilitates the accurate tracking of the prescribed trajectory. Our theoretical analysis substantiates that the proposed control methodology ensures exponential convergence of the line-of-sight (LOS) distance and angle tracking errors, while enhancing the transient performance. To validate the efficacy of our approach, we present a series of simulation results, which demonstrate the applicability of the developed control strategy in managing the complex dynamics of tractor–trailer robots. Full article

Salt brine is routinely used by transportation agencies to pre-treat critical infrastructure such as bridges, ramps, and underpasses in advance of winter storms. This requires an operator turning on and off brine controls while driving at highway speeds, introducing driver distraction and consistency challenges. In urban areas, such as Indianapolis, a 5500-gallon tractor trailer with a gross vehicle weight of 80,000 pounds is typically used and the driver may have 1200 on/off activations while covering 318 miles during a pre-treatment shift. This study conducted in collaboration with Indiana Department of Transportation has worked with their truck upfitters to adapt geo-fenced agriculture spraying controls to seven trucks that use the Global Positioning System (GPS) position of the truck to activate the sprayer valves when the trucks enter and exit geo-fenced areas that require pre-treatment. This automated brine system enhances safety, reduces driver workload, and ensures the consistent application of brine in designated areas. Furthermore, as additional environmental constraints and reporting requirements evolve, this system has the capability of reducing application rates in sensitive areas and provides a comprehensive geo-coded application history. The Indiana Department of Transportation has scaled deployment for treating interstates and major arterials with brine. This deployment on 5500-gallon tankers, used on I-64/65/69/70/74, and 465, eliminates over 10,000 driver distraction events during every statewide pre-treatment event. Full article

Background: Road transport companies utilize transport capacities as fixed compositions of tractors and semi-trailers, while the possibility of exchanging semi-trailers is considered ad hoc, after some unforeseen circumstances emerge on the route. Such an approach is a limiting factor in achieving optimal utilization of transport capacities, and consequently affects profitability. We proposed a new concept of vehicle fleet management where semi-trailers would not be permanently assigned to the tractors, but could be dynamically reassigned, to utilize optimally the vehicle fleet, on considering the planned itinerary, the driver’s working hours, and traffic conditions. Methods: We set the key performance indicators and developed a prototype application based on the concept of dynamic semi-trailer allocation. We simulated the use of the prototype application on the historical data collected in the case study on one of the leading transport companies in the cold chain, and evaluated the benefits that may be achieved thereof. Results: Simulation showed that implementing the proposed concept enabled the reduction of the vehicle workdays spent on-the-route, the reduction of the number of vehicle compositions needed to handle the transport demand, and improved the quality of service. Conclusions: The proposed concept is beneficial for transport companies that operate large vehicle fleets on long-haul routes, with several transport orders per route. The prototype application may be the basis for developing a fully functional application that can be integrated into the fleet management system. Full article

In the past few years, there has been a growing interest among researchers in developing control systems for autonomous vehicles, specifically for tractor-trailer systems. This newfound interest is driven by the potential benefits of enhancing safety, reducing costs, and addressing labor shortages in the industry. Two industries that could reap the rewards of these systems’ advancements are cargo and agriculture transportation. One of the challenging tasks for the truck trailer vehicle is driving in reverse. Backward path tracking of tractor-trailers is a complex control problem with practical applications. The difficulty in controlling the vehicle arises due to its unstable internal dynamics, coupled nonlinear terms, and the under-actuated nature of the system. There is also a limit to the angle at which the steering can be turned before the risk of a jackknife accident increases significantly. In response to these challenges, this paper introduces a robust sliding mode controller designed for path tracking in reverse-driving tractor-trailer systems. The novelty of our work lies in addressing these challenges, which have not been extensively studied in the past. The proposed controller is analyzed, and its performance is tested and verified using different scenarios. The simulation examples show superior control performance, and we anticipate that this novel controller holds the potential to be widely adopted as a fundamental component in the path-tracking algorithms of autonomous truck trailer systems. Full article

Vehicular incidents, especially those involving tractor trailers, are increasing in number every year. These events are extremely costly for fleets, in terms of damage or loss of property, loss of efficiency, and certainly in terms of loss of life. Although the U.S. Department of Transportation (DOT) is responsible for performing inspections, and fleet managers are encouraged to maintain their fleet and participate in regular inspections, it is uncertain whether these inspections are occurring at a frequency that is necessary to prevent incidents. The Federal Motor Carrier Safety Administration (FMCSA) of the DOT manages and maintains the Motor Carrier Management Information System (MCMIS) dataset, which contains all incident and inspection data regarding commercial vehicles in the U.S. The purpose of this preliminary analysis was to explore the MCMIS dataset through spatiotemporal analyses, to uncover findings that may hint at potential improvements in the DOT inspection process and highlight location-specific trends in the dataset. These analyses are novel, as previous research using the MCMIS dataset only examined the data at the state or county level, not at a national scale. The results from the analyses pinpointed specific major metropolitan areas, namely Harris County (Houston), Texas, and three of the New York boroughs (Kings, Queens, and the Bronx), which were found to have increasing incident rates during the study period (2016–2020). An overview of potential causal factors contributing to this increase are provided as well as an overview of the inspection process, and suggestions for improvement relative to the highlighted locations in Texas and New York are also provided. Ultimately, it is suggested that the incorporation of advanced technology and automation may prove beneficial in reducing the occurrence of events that lead to incidents and may also help in the inspection process. Full article

With the continuous development of road transport of goods, the issue of safety risks related to the movement of trucks and road trains remains an essential element of the overall road safety system. One of the persistent problems is the braking of such kits, especially in emergencies on the road. The work aims to show how typical changes in operating conditions can affect the basic indicators illustrating the safety of braking (effectiveness indicators, stability symptoms). A simulation method was applied for the analysis, which used a relatively simple (quasi-static) model of the tractor-semitrailer set’s rectilinear motion and models of the braking system and the longitudinal forces in the tyre-road surface contact. Calculations were made for the selected truck-trailer set in nominal condition and for several deviations from the nominal state, such as loading the trailer (load value, location of the semi-trailer’s centre of gravity), reduced surface adhesion, and selected faults of the semitrailer braking system. The results were compared for several qualitative and quantitative criteria for the evaluation of braking safety. Attention was drawn to the problem of the forces in the coupling (which determine the possibility of jack-knifing phenomena), the order of axle locking, and the braking distance. The presented results show that the change of operating conditions as above compared to the nominal condition visibly deteriorates the effectiveness of the braking process. The greatest threat, both related to the braking efficiency and the increase in the force in the coupling, is associated with the lack of braking of the semitrailer axle or a significant reduction in its load. The weight and location of the load’s centre of gravity considerably impact braking safety. In addition to the negative impact on the braking distance or increase in the horizontal force in the coupling, it changes the order of locking the axle. ABS reduces the risk associated with braking safety but does not eliminate it. At the same time, it has been shown that using relatively simple calculation tools makes it possible to indicate the risks related to the braking safety of such articulated vehicles. Full article

This paper discusses the robust trajectory tracking control of an autonomous tractor-trailer in agricultural applications. Firstly, considering the model parameter uncertainties and various disturbances, the kinematic and dynamic models of the autonomous tractor-trailer system are established. Moreover, the coordinate transformation is adopted to convert the trajectory tracking error into a new unconstrained error state space model. On this basis, the prescribed performance control (PPC) technique is designed to ensure the convergence speed and final tracking control accuracy of the tractor-trailer control system. Then, this paper designs a double closed-loop control structure. The posture control level adopts the model predictive control (MPC) method, and the dynamic level adopts the sliding mode control (SMC) method. At the same time, it is worth mentioning that the nonlinear disturbance observer (NDO) is designed to estimate all kinds of system disturbances and compensate for the tracking control system to improve the system’s robustness. Finally, the proposed control strategy is validated through comparative simulations, demonstrating its effectiveness in achieving robust trajectory tracking of the autonomous tractor-trailer system. Full article

Due to current EU regulations, constant-speed testing on test tracks is used for aerodynamic certification of heavy-duty vehicles (HDV). However, the aerodynamic development of HDVs is performed using wind tunnels and computational fluid dynamics (CFD). Both techniques commonly neglect the rotational aerodynamic losses of the wheels—the so-called ventilation drag—that are present when driving on the road. This is due to the fact that there is no full-scale wind tunnel for this type of vehicle with a suitable belt system for the simulation of the wheel rotation. Furthermore, the ventilation drag of HDV wheels has been neglected in CFD due to their almost completely closed rim design. These constraints lead to an underprediction of the aerodynamic forces in comparison to the results under on-road conditions when performing constant-speed tests. In order to investigate the ventilation drag of HDV wheels, measurements were carried out on a 1:4.5 scale generic tractor-trailer model in the Model Scale Wind Tunnel of the University of Stuttgart. The measured aerodynamic forces as well as the measured flow field data provide the basis for the definition and validation of a procedure for analyzing the ventilation drag in CFD. Accordingly, the ventilation drag of a full scale HDV was investigated in CFD. The results show that the tire treading and rim geometry have a significant influence on ventilation drag that contributes to the total aerodynamic drag of the HDV. The present work shows that the ventilation drag has a relevant impact on the total aerodynamic drag of HDVs and should therefore not be neglected. The presented CFD approach thus allows to assess the aerodynamic drag under real on-road conditions in an early stage of the vehicle development. Full article

In this paper, a semi-Markov model for determining the optimal time for preventive replacements according to the age of technical objects is presented. In the analyzed system of transportation, due to its specific characteristics, the basic type of renewal process carried out is minimal repair. Minimal repairs of technical objects in semi-Markov models have been analyzed in the literature to date. In the system studied, the technical objects (sets of agricultural tractors with trailers), due to the continuous operation of combine harvesters, should carry out the assigned tasks of transporting agricultural crops without interruption. The damage to agricultural tractors that arises during the implementation of transport tasks should be repaired in the shortest possible time. The repairs to damaged tractors are carried out primarily by the Technical Emergency Service and, due to their purpose and scope, may be considered minimal repairs. The effectiveness of the function of the tested technical objects is analyzed by two criteria functions, which are very important for the system managers. These are profit per unit of time and availability. In the analyzed case, it is the availability to carry out the assigned transport tasks. The conditions for the existence of a maximum of criterion functions have been written for the assumptions. The analyzes carried out, which are presented in the work, are illustrated with sample calculations. It has been proven that, under general assumptions, the criterion functions considered in the paper have exactly one maximum. On the basis of the conducted analysis, sufficient conditions for the existence of a maximum of these functions were formulated. In the analyzed transport system, it is possible to increase the efficiency of the function of the technical facilities in use as a result of planning additional preventive replacements (increasing the frequency of these replacements). This is especially important for a system where transport units must have high availability. Full article

The performance of agricultural tires varies with the characteristics of both the terrain and the tractors on which they are mounted, which differently affect the rolling resistance, the traction capacity, and the slip. To reduce the variability of test conditions, CREA developed an original mobile test (MTB) bench which consists of a dynamometric single axle trailer pulled by a tractor and can be used both in traction performance tests (driving wheels) and in rolling resistance tests (driven wheels). A control system alternatively operates the adjustment of traction force or slip, so that each test is performed maintaining constant the desired values. The MTB underwent tests under different conditions (type of surface, pre-set values of force of traction and slip) aimed at verifying its accuracy and reliability. In a final test, two pairs of identical new tires were simultaneously mounted on the MTB and on the rear axle of the 2WD tractor that pulled it, to discover information on the different interactions occurring, under the same traction conditions, between the soil surface and each pair of tires, with reference to the relationship between the slips and the load transfers observed on the MTB and on the tractor rear axle. The results evidenced the capability of the MTB to guarantee repeatable test conditions, including field conditions, allowing comparison among the performance of different tires. Full article
