Search Results (54)

The global push for low-carbon electricity generation has made hydrogen-enriched natural gas an attractive near-term decarbonization option. This paper combines experimental and thermodynamic analyses of H₂–CH₄ combustion in gas turbine combustion chambers. Experiments were conducted on a patented two-stage swirl burner across 240 operating conditions. The effects of hydrogen fraction (γ = 0–40%), swirler vane angle (30°, 45°, 60°), equivalence ratio (φ = 0.17–1.00), and fuel injection strategy were measured against NOx and CO emissions and lean blowout stability. Each 10% increase in hydrogen content raised NOx by 23–24% via the Zel’dovich thermal mechanism, while CO fell by up to 28.5% at φ = 0.3 and 60° due to enhanced OH-radical activity. The minimum recorded NOx was 12.08 ppm (Type 2 injection, 30°, γ = 0%, φ = 0.3). Hydrogen addition improved lean blowout stability by 32–46% per 10% H₂. A parallel thermodynamic analysis showed that integrating an organic Rankine cycle (ORC) and supplementary H₂–CH₄ firing in the heat recovery steam generator cuts specific CO₂ emissions by 7.5–10% and raises net efficiency by 0.79–4.0 percentage points. Critical comparison with 28 published studies identified an optimal operating window: γ = 20–30%, φ = 0.5–0.7, 45° vane angle (SW = 0.8). Full article

This study investigates the emission characteristics and flame behavior of an air-staged swirl burner operating on LPG. The burner is equipped with a 45° vane swirler and an adjustable secondary-air section. Experiments were conducted at air velocities ranging from 20 to 43 m/s using a Testo 350 gas analyzer, while temperature measurements were obtained with thermocouples positioned 90 mm downstream of the burner exit. The results show that increasing the secondary-air opening leads to a monotonic decrease in the mean exit temperature and NO_x formation over the entire velocity range. In contrast, CO concentrations increase at higher air velocities and larger secondary-air fractions due to reduced residence time and partial quenching of the reaction zone. The fully staged configuration (100%) achieved the lowest NO_x levels (≤3 ppm) at 20 m/s, whereas the non-staged case resulted in the highest temperatures and NO emissions. Overall, the experimental results demonstrate that a moderate secondary-air opening provides the best compromise between low NO_x emissions and acceptable CO levels for compact LPG-fired swirl combustors. Full article

Flow resistance is a critical determinant of the efficiency and economics of a slurry pipeline. This study aims to reduce pipeline resistance by integrating a swirler to enhance particle suspension. The variation laws of slurry conveying resistance with and without a swirler under various conveying conditions were investigated. Whether a swirler is present or not, the conveying resistance increases with an increase in the conveying velocity (1~6 m/s), volume concentration (10~50%), particle diameter (0.1~5 mm), particle density (1100~1500 kg/m³), and pipe inclination (0~90°). It decreases with an increase in the pipe diameter (50~200 mm). A moderate swirling intensity reduces the resistance in high-velocity large-particle slurry transport. Considering the swirling flow characteristics in the conveying pipeline, resistance loss calculation models accounting for these characteristics were established for different flow states of the slurry in the pipeline. Taking into account the swirling characteristics in the conveying pipeline, a calculation model for resistance loss of the slurry in different flow states within the pipeline was established. The average error between this model and the experimental results was 9.04%. Full article

Swirl-stabilized combustors are central to gas turbine technology, where the swirl number critically determines flow structure and combustion stability. This work systematically investigates the isothermal flow in a dual-swirl combustor, focusing on two primary objectives: evaluating advanced turbulence models and quantifying the impact of geometric-induced swirl number variations. Large Eddy Simulation (LES), Detached Eddy Simulation (DES), Scale-Adaptive Simulation (SAS), and the k-$\omega$ SST RANS model are compared against experimental data. The results suggest that while all models capture the mean recirculation zones, the scale-resolving approaches (LES, DES, SAS) more accurately predict the unsteady dynamics, such as shear layer fluctuations and the precessing vortex core, which are challenging for the RANS model. Furthermore, a parametric study of vane angles (60° to 70°) reveals a non-monotonic relationship between geometry and the resulting swirl number, attributed to internal flow separation. An intermediate swirl number range (S ≈ 0.79) was found to promote stable and coherent recirculation zones, whereas higher swirl numbers led to more intermittent flow structures. These findings may provide practical guidance for selecting turbulence models and optimizing swirler geometry in the design of modern combustors. Full article

This study investigates the effect of the flame tube convergent segment wall configuration on the performance of a High-Temperature-Rise (HTR) triple-swirler main combustor. Three configurations were evaluated: the Vitosinski principle (Scheme A), the equal velocity gradient criterion (Scheme B), and a novel convex-arc flow-facing method (Scheme C). Three-dimensional numerical simulations were conducted using validated RANS equations with the Realizable k-ε turbulence model and a non-premixed PDF combustion model. The results demonstrate that the proposed Scheme C, characterized by an inflection-free convex contour, successfully avoids the localized high-velocity region and achieves a more uniform flow field. A systematic comparison reveals that Scheme C achieves the highest outlet temperature distribution quality (lowest OTDF and RTDF), the highest combustion efficiency, and the lowest total pressure loss (TPL) in the convergent segment among the three designs. In conclusion, the comprehensive analysis confirms that the convex-arc design (Scheme C), by eliminating the geometric discontinuity of an inflection point, provides the best overall performance for the HTR combustor under takeoff conditions. Full article

Unsteady simulations were performed to investigate hot spot migration in an annular recirculation combustor equipped with two different swirler configurations. The Scale-Adaptive Simulation (SAS) turbulence model was applied, using steady-state results as the initial condition. The simulations reveal that (1) in both configurations, high-temperature gases are divided into two regions by the high-velocity jets from the primary holes, forming a primary and a secondary recirculation zone; (2) with Swirler Configuration 1, the hot spot in the primary recirculation zone is more stable, and the hot spot temperature on the combustor liner is lower; (3) with Swirler Configuration 2, the hot spot exhibits a broader axial distribution, with higher temperatures on the wall of exhaust transition piece and at the outlet. Full article

The two-phase flow within a Boiling Water Reactor steam separator is investigated using an interface capturing method. The simulations are focused on resolving the flow around the first pickoff ring which is the highest contributor to steam carryunder phenomenon. Multiple simulations are conducted of varying levels of resolution to evaluate the capabilities of interface capturing technique for this challenging problem. First, high-resolution simulations of the flow using a simplified $30°$ wedge are conducted without a swirling velocity field present in the actual system. In order to understand the flow field generated by the separator swirler, secondary simulations of single-phase flow passing through a swirler model are conducted. Using this information, a coarse simulation of the full $360°$ model was performed, which incorporated the effect of the swirler using a custom inflow boundary condition. Instantaneous carryunder/carryover along with void fraction and film thickness are evaluated at the pickoff ring entrance. Overall, these simulations demonstrate that interface capturing simulations can be an accurate tool for studying full-scale components within nuclear power plants. Full article

The use of additive manufacturing (AM) has seen increased utilization over the last decade, thanks to well-documented advantages such as lower startup costs, reduced wastage, and the ability to rapidly prototype. The poor surface finish of unprocessed AM components is one of the major drawbacks of this technology, with the research literature suggesting a measurable impact on flow characteristics and burner operability. For instance, surface roughness has been shown to potentially increase resistance to boundary layer flashback—an area of high concern, particularly when utilizing fuels with high hydrogen content. A more detailed understanding of the underlying thermophysical mechanisms is, therefore, required. Computational fluid dynamics can help elucidate the impact of these roughness effects by enabling detailed data interrogation in locations not easily accessible experimentally. In this study, roughness effects on a generic gas turbine swirler were numerically modeled using a low-y+ detached eddy simulation (DES) approach. Three DES models were investigated utilizing a smooth reference case and two rough cases, the latter employing a literature-based and novel equivalent sand-grain roughness (k_s) correlation developed for this work. Existing experimental isothermal and CH₄ data were used to validate the numerical simulations. Detailed investigations into the effects of roughness on flow characteristics, such as swirl number and recirculation zone position, were subsequently performed. The results show that literature-based k_s correlations are unsuitable for the current application. The novel correlation yields more promising outcomes, though its effectiveness depends on the chosen turbulence model. Moreover, it was demonstrated that, for identical k_s values, while trends remained consistent, the extent to which they manifested differed under reacting and isothermal conditions. Full article

Confinement with a rectangular cross-section is commonly used to simulate the role of a swirl combustor, yet its effect on swirling flows remains poorly understood. This study investigates the influence of confinement on the isothermal flow field of a counter-rotating swirler. A particle image velocimetry (PIV) system was employed to measure the swirling flow field under varying confinement ratios at an air pressure drop equivalent to 3% of atmospheric pressure. The results reveal two distinct flow patterns, delineated by a critical confinement ratio of approximately 8.92. Detailed analyses of the velocity components, contour distributions, and Reynolds shear stresses were conducted. The two flow patterns are attributed to the wall attachment effect and swirling intensity, respectively. Furthermore, the results confirm that the swirling flow field is primarily governed by the confinement ratio. Full article

This article reviews the physical and chemical mechanisms associated with unsteady swirl-stabilized partially or fully lean premixed combustion. The processes of flame stabilization, mode conversion, swirl number oscillation, equivalence ratio oscillation, and vortex rollup are described. The key challenges associated with flow-flame dynamics for several sources of perturbations are presented and discussed. The Rayleigh criterion is discussed. This article summarizes the scientific knowledge gained on swirling flames dynamics in terms of modeling, theoretical analysis, and transient measurements with advanced diagnostics. The following are specifically documented: (i) the effect of the swirler on swirling flames; (ii) the analytical results, computational modeling, and experimental measurements of swirling flame dynamics; (iii) the influence of flow features on flame response of swirling flames for combustion instabilities studies; and (iv) the identification and description of the combustion dynamics mechanisms responsible for swirl-stabilized combustion instabilities. Relevant elements from the literature in this context for hydrogen fuel are included. Full article

In order to explore the influence of pilot structure on the lean ignition characteristics in a certain type of internally staged combustor, the current study was conducted on the effects of the auxiliary fuel nozzle diameter, the rotating direction of the pilot swirler, and the swirl number on the lean ignition fuel–gas ratio limit, combining numerical simulation and experimental validation. The optimization potential of the mixing structure of this type of internally staged combustor was further explored. It indicated that the lean ignition fuel–gas ratio limit was significantly influenced by the diameter of the auxiliary fuel nozzles the swirl number of the pilot swirler and the combination of the same rotating direction for both pilot swirlers, while the mass flow rate of air was constant. Increasing the diameter of the auxiliary fuel path nozzles (0.4~0.6 mm) and having excessively higher or lower swirl numbers of the pilot module primary swirlers are not conducive to broadening the lean ignition boundary. Compared with the two-stage pilot swirler with the same rotation combination, the fuel–gas ignition performance of the two-stage pilot swirler with the opposite rotation combination is better. Under the typical working conditions (the air mass flow rate is 46.7 g/s and the ignition energy is 4 J), for a pilot swirler with a rotating direction opposite to the main swirler, the diameter of the auxiliary fuel nozzles is 0.2 mm, the swirl number of first-stage of pilot swirler is 1.4, and the lean ignition fuel–air ratio was reduced to 0.0121, which is 32.78% lower than the baseline scheme, which further broadens the lean ignition boundary of the centrally staged combustion chamber. Full article

The supersonic swirling device is a new apparatus that can be used for natural-gas liquefaction. The structure of the supersonic swirling device has an important impact on the liquefaction efficiency. Therefore, this study presents a structural design method for supersonic cyclones based on CFD theory. Using the production parameters of a liquefied natural gas (LNG) peak-shaving station as the study case, a detailed design and design comparison of each part of the supersonic swirling separator are carried out. An optimum LNG supersonic swirling separator design was obtained. To ensure that the designed supersonic swirling separator achieved better liquefaction effectiveness, it was ascertained that no large shockwaves were generated in the de Laval nozzle, the pressure loss on the swirler was small, and the swirler was able to produce a large centripetal acceleration. The opening angle of the diffuser and the length of the straight tube were designed considering the location at which normal shockwaves were generated. The location at which shockwaves are generated and the friction effect are important parameters that determine the gap size. With this design guidance, the optimal structural dimensions of the supersonic swirling device for a given processing capacity were determined as follows: a swirler with six vanes and an 8 mm wide channel; a 10D-long straight tube, an opening angle of 20° between the straight tube and the divergent section, and a gap size of 2 mm. Compared with “Twister II”, the new device has better liquefaction efficiency. Full article

The computational and experimental study results of swirling single-phase coolant motion and heat transfer for the standard operation parameters of a nuclear power plant are presented. The experimental model is a vertical heat exchanger of a “pipe in a pipe” type with the countercurrent movement of coolants. Six different swirlers (three with a constant twist pitch and three with a variable pitch) were considered. The heat exchanger temperature field was measured at various combinations of coolant flow rates, and a channel pressure drop for each swirl was determined. Computational studies were performed using the Omega-based Reynolds stress model and SST model with a correction for curvature streamlines. A good agreement between numerical and experimental data was obtained. Based on the velocity and temperature fields, swirling flow motion features in channels with a variable swirl pitch were discovered. For each intensifier, the effectiveness criterion in comparison with a pipe channel was determined. Full article

Ammonia stands out as a promising zero-carbon fuel and an efficient hydrogen carrier, offering great promise for industrial applications in gas turbines and boilers. However, different combustion modes significantly influence the flame structure and combustion characteristics of ammonia. In this study, two distinct fuel injection strategies were employed in a model combustor: ammonia and methane, under fully premixed and dual-flame combustion modes. Numerical simulations were performed to analyze the flame structure, velocity fields, and temperature distribution, complemented by planar flow field, flame OH* chemiluminescence, and NO emission measurements. Findings reveal that with an increasing NH₃ ratio, the flame front becomes more elongated with more pronounced temperature fluctuations at the swirler exit. Particularly, at 50% NH₃, a significant reduction in flame temperature is observed, notably at a height of 30 mm from the burner. For dual flames, the reaction NH₂ + O ↔ HNO + H was less significant compared to its effect in premixed flames, whereas the H + O₂ ↔ O + OH reaction demonstrated the highest sensitivity coefficient. An increase in the NH₃ ratio correspondingly led to a reduction in NO consumption reaction rates, heightening the sensitivity coefficient for NO inhibition, and providing critical insights into ammonia combustion optimization. Full article

Because of the need for low pollutant emissions, industrial gas turbines typically use partially premixed gases for combustion. However, the nonlinear dynamic characteristics of partially premixed flames have not been studied sufficiently. Therefore, this study focuses on the dynamics of a partially premixed flame generated by a swirler with fuel holes on its surface and designs a flame describing function (FDF) identification method based on the parallel subsystem model. This method can separate the flame dynamic characteristics into a parallel connection of the nonlinear and linear models. The nonlinear model is related to the disturbance frequency and velocity perturbation amplitude, whereas the linear model depends only on the disturbance frequency. This method is verified using a simulation. Finally, experimental research on partially premixed flames is conducted. Based on the experimental data, the identification method successfully separates the FDF into a nonlinear model with saturation characteristics and a linear model with Gaussian distribution characteristics. The flame model obtained by the identification method is the foundation for the analysis of combustion thermoacoustic stability and active/passive control strategy. Full article
