Search Results (39)

Inter-turn short-circuit faults (ITSC) in the stator winding of large synchronous machines are among the most critical failures in power systems and may lead to severe insulation damage and unplanned outages. At the same time, such faults, due to their nature in critical industrial scenarios, make it difficult to collect sufficiently rich labeled datasets for data-driven and deep-learning-based diagnostic methods. Training diagnostic models purely on simulated signals often results in a severe domain shift between the digital twin and the physical machine due to nonlinearities, mechanical noise, and measurement imperfections, causing a significant degradation of performance when the model is deployed in practice. This paper proposes a hybrid diagnostic framework that combines a nonlinear physics-based digital twin of a synchronous machine, formulated using an extended Park’s transformation model with a dedicated fault loop, with a Domain-Adversarial Neural Network (DANN) driven by a minimal physics-guided feature vector composed of the 100 Hz and 200 Hz harmonic amplitudes of the excitation current. Simulated data from the digital twin are used as a labeled source domain, whereas test-bench measurements of the excitation current form an unlabeled target domain, enabling unsupervised sim-to-real transfer of the stator fault resistance. The proposed architecture achieves accurate regression of the stator fault-loop resistance on a laboratory machine without any labeled measurements of real faults. Experimental results demonstrate Mean Absolute Error (MAE) below 3% across the investigated fault severity range, significantly outperforming baseline approaches that lack domain adaptation. The industrial significance of this approach lies in its potential to facilitate a transition from reactive to predictive maintenance. By enabling early-stage detection, the framework allows power plant operators to avoid catastrophic failures and significantly reduce exceptionally high costs associated with unplanned outages and cascading grid disturbances. Full article

With the capacity of generators continuing to increase, higher demands are placed on the heat dissipation of epoxy resin (EP), the main insulation material used in stator bars and windings. To overcome its low thermal conductivity, a multiscale hybrid filler strategy was adopted to investigate the effects of spherical Al₂O₃ (10 and 1 μm), platelet BN (1 μm), and SiO₂ (50 nm) on the thermal and insulating properties of EP composites. Unlike conventional studies focusing on individual fillers, this work highlights the synergistic design of fillers with different sizes and morphologies. The filler ratios were optimized by finite element simulation, and the composites were prepared by melt blending. The results show that, at a total filler loading of 38.5 wt%, the EP composite filled with spherical Al₂O₃ particles of 10 and 1 μm, platelet BN of 1 μm, and nano-SiO₂ of 50 nm achieves a thermal conductivity of 0.5497 W/(m·K), corresponding to an increase of 158.2% compared with pure EP (0.2129 W/(m·K)). This enhancement is attributed to the synergistic effect of multiscale and multishape fillers, where large Al₂O₃ particles form the main thermally conductive framework, small Al₂O₃ particles fill the gaps, platelet BN acts as a bridging filler, and nano-SiO₂ improves the interfacial region. In addition, the composite exhibits low relative permittivity and dissipation factor tanδ in the frequency range of 10⁻²–10⁶ Hz, and its breakdown strength reaches 65.99 kV/mm. These results demonstrate that simulation-guided multiscale hybrid filler design is an effective strategy for improving the thermal conductivity of EP while maintaining acceptable insulating performance. Full article

Epoxy-glass-mica composite materials are widely used as electrical insulating materials in high-voltage rotating machinery due to their layered structure and excellent dielectric properties. Taking the F-class epoxy glass with a small amount of rubber powder mica tape commonly used as the main insulation of wind turbine stator coils as the research object, 7-day, 14-day, 21-day, and 28-day low-temperature treatment tests were conducted at −50 °C. The surface morphology and chemical structure changes of the materials were characterized by SEM and FTIR, and the influence laws of low-temperature treatment on the electrical properties of the mica tape insulation materials were systematically studied. The experimental results show that the low-temperature environment will induce microcracks and interface delamination and other structural damages, but no obvious change in the chemical structure of the mica tape was observed. With the extension of the low-temperature treatment time, the electrical properties of the mica tape show a deteriorating trend, and after 28 days of low-temperature treatment, the breakdown field strength of the F-class mica tape decreased by approximately 18.5%, and the volume conductivity overall increased by about two orders of magnitude. This indicates that the microcrack defects induced by low-temperature will lead to an enhanced electrical-thermal coupling effect in the insulation structure, thereby accelerating the degradation process of the insulation material. This reveals the degradation mechanism of wind turbine stator main insulation from “structural damage” to “performance degradation” and then to “insulation aging” under low-temperature conditions, providing a theoretical basis for the design and reliability assessment of insulation systems in wind turbine generators in cold regions. Full article

Industrial predictive maintenance programs often rely on SCADA historian signals characterized by low-frequency sampling and asynchronous reporting intervals. These data constraints, specifically non-uniform scan rates and inter-tag time misalignment, limit the applicability of high-resolution or sensor-intensive prognostic models. This study proposes a lightweight, physics-informed health proxy, the temperature-weighted work (TWW) index, designed to monitor motor stator-winding degradation within these industrial limitations. The TWW index accumulates mechanical work derived from torque and speed measurements, weighted by an adaptive exponential temperature-emphasis function that penalizes operation at elevated temperatures. The formulation is inspired by practical thermal-aging heuristics such as Montsinger’s rule in the qualitative sense that higher temperatures are treated as disproportionately more damaging, but it is not intended as a direct implementation of a fixed absolute-temperature life law. Instead, it is designed as a lightweight adaptive index suitable for online SCADA-based implementation. To address SCADA-specific irregularities, the framework incorporates data synchronization and resampling techniques to align heterogeneous tags, alongside power-thresholding to isolate degradation-relevant load periods. The resulting cumulative index is mapped to a normalized health/RUL proxy using failure-referenced thresholds identified from historical events. Validation using field data from industrial three-phase motors demonstrates that the TWW index provides a monotonic degradation profile that is consistent with documented winding-related failures and proactive removals. Case studies confirm that the model enabled proactive maintenance interventions by signaling the terminal phase of insulation life before catastrophic breakdown, offering a hardware-free and scalable solution for real-time asset management. Full article

The windings of aerospace motors are fabricated using enameled wires; with polyimide (PI) serving as the primary material for their insulating enamel coatings, thermal aging is the predominant factor contributing to insulation failure in enameled wires. The prolonged natural aging process of enameled wires, coupled with the complexity and sluggish variation rates of dielectric parameters used for aging monitoring, presents significant challenges in developing a universal method for assessing insulation performance. To address this challenge, our study determined accelerated aging conditions based on the Arrhenius law, fabricated twisted-pair specimens, and implemented a step-stress aging protocol, in order to monitor the insulation capacitance (IC) and dielectric dissipation factor (tan δ) of the sample. Finally, a two-parameter Weibull distribution plot was established to characterize the relationship between service life and failure probability. Initial-value normalization combined with B-spline interpolation was employed to construct IC–life correlation curves. A novel method for monitoring PI-enameled wire insulation life using IC variation rate was proposed and experimentally validated, providing a methodological framework for lifespan prediction of aerospace motor windings. Finally, a two-parameter Weibull distribution plot was established to characterize the relationship between service life and failure probability. Initial-value normalization combined with B-spline interpolation was employed to construct IC–life correlation curves. The rationality of the method using IC change rate to monitor the insulation lifetime of polyimide-enameled wire was verified, the lifetime assessment of aviation motor stator windings was achieved by monitoring corresponding dielectric parameters, and a reference standard for the maintenance and support of aviation equipment was provided. Full article

Grounding insulation is a key component of electric vehicle drive motors, and cracks may appear during the manufacturing process and assembly. In this paper, the novel method of coupling phase field, mechanic field and electric field is proposed to investigate the coupled propagation characteristics of electromechanical damage in stator end-wingding insulation. The crack propagation model is derived by using the phase field method, where the maximum historical variable is introduced to ensure the forward propagation of the crack damage in insulation. According to the crack evolution states, the electric potential distributions in the insulation domain are determined and the electrical damage variable is defined to quantitatively describe the dynamical evolution mechanism of electric damage with the variation in mechanical damage. The results in this research will contribute to understanding the electrical performance degradation and electromechanical failure of the end-winding insulation in electric vehicle drive motors, which also provides the basis for the mechanism of insulation damage, insulation fault diagnosis and residual life prediction of electrical machines. Full article

Permanent magnet synchronous generators (PMSGs) are suitable for offshore applications due to their high efficiency and power density. Inter-turn short circuits (ITSCs) stand as one of the most critical faults in these machines due to their rapid evolution in phase or ground short circuits. It is therefore necessary to detect ITSCs at an early stage. In the literature, ITSC detection is often based on current signal processing methods. One of the challenges that these methods face is the presence of imperfections in the stator coils, which also affects the three-phase symmetry. Moreover, when the stator coils are connected in parallel, this type of fault becomes important, as circulating currents will flow between the parallel windings. This, in turn, increases the thermal stress on the insulation and the permanent magnets, while also exacerbating the vibrations of the generator. In this study, a finite-element analysis (FEA) model has been developed to simulate a dual-rotor PMSG under conditions of coil asymmetry. To further investigate the impact of this asymmetry, mathematical modeling has been conducted. For fault detection, negative-sequence current (NSC) analysis and torque monitoring have been used to distinguish coil asymmetry from ITSCs. While both methods demonstrate potential for fault identification, NSC induced small amplitudes and the torque analysis was unable to detect ITSCs under low-severity conditions, thereby underscoring the importance of developing advanced strategies for early-stage ITSC detection. The innovative aspect of this work is that, despite these limitations, the combined use of NSC phase-angle tracking and torque harmonic analysis provides, for the first time in a core-less PMSG with parallel-connected coils, a practical way to distinguish ITSC from coil asymmetry, even though both faults produce almost identical signatures in conventional current-based indices. Full article

Tracking the state of the health of electrical insulation in high-power electric machines has always been a topic of great interest due to the high cost of downtime associated with unexpected failures. Over the years, there have been continuous efforts to develop and improve upon methods for testing and categorizing the health and expected lifetime of stator insulation. Methods such as partial discharge, surge, and dissipation factor testing are common examples. With the increasing use of high-specific-power electric machines in new applications such as traction and wind power generation, coupled with the increasing use of wide-bandgap semiconductor device-based inverters, some traditional methods for insulation health tracking may need adjustments or be combined with newer methods to remain accurate and useful. This paper outlines a review of the traditional insulation health tracking methods and newer methods and improvements that have been proposed to address the concerns and shortcomings of traditional methods. Full article

Accurate diagnosis of the insulation condition of stator windings in pumped storage generator-motor units is crucial for ensuring the safe and stable operation of power systems. Time domain dielectric response testing is an effective method for rapidly diagnosing the insulation condition of capacitive devices, such as those in pumped storage generator-motors. To precisely identify the conductivity and relaxation process parameters of the insulating medium and accurately diagnose the insulation condition of the stator windings, this paper proposes a method for identifying the insulation dielectric response parameters of stator windings based on sparsity-enhanced dynamic mode decomposition of the depolarization current. First, the measured depolarization current time series is processed through dynamic mode decomposition (DMD). An iterative reweighted L1 (IRL1)-based method is proposed to formulate a reconstruction error minimization problem, which is solved using the ADMM algorithm. Based on the computed modal amplitudes, the dominant modes—representing the main insulation relaxation characteristics—are separated from spurious modes caused by noise. The parameters of the extended Debye model (EDM) are then calculated from the dominant modes, enabling precise identification of the relaxation characteristic parameters. Finally, the accuracy and feasibility of the proposed method are verified through a combination of simulation experiments and laboratory tests. Full article

This study investigates the critical issue of arc-induced partial discharge in high-voltage motor stator windings and proposes a cost-effective, targeted maintenance approach to mitigate these effects. Diagnostic techniques, including insulation resistance tests, tan δ measurements, partial discharge analyses, and UV camera inspections, were employed to identify and assess fault points. A novel partial maintenance method involving felt-pad insulation reinforcement was implemented to address the arc discharge issues. Post-maintenance diagnostics confirmed a significant reduction in partial discharge levels, with an average decrease of over 80%, demonstrating the effectiveness of the proposed approach. Compared to traditional rewinding methods, this technique offers substantial savings in time and cost while enhancing motor reliability. The findings underscore the importance of precise diagnostics and tailored interventions in extending the lifespan and operational stability of high-voltage motors, providing practical insights for industrial maintenance strategies. Full article

Superconducting dynamic synchronous condensers (SDSCs) exhibit significant potential for replacing traditional dynamic synchronous condensers (DSCs) due to their powerful reactive power output capability and low thermal losses, which are attributed to their large short-circuit capacity, high air-gap magnetic density, and low synchronous reactance. This study comprehensively reviews the development trajectory and current research status of SDSC, both domestically and internationally, and conducts an in-depth analysis of their advantages. Based on this, this paper highlights three typical cases of SDSC and summarizes the key technologies of SDSC from the perspectives of the excitation winding, stator structure, rotor magnet, and cooling system. Finally, it proposes that cooling and insulation technology, quench issues of AC windings under magnetic fields, and torque tube transmission technology will be the key technical challenges for future research and resolution in SDSC. Full article

With the escalating proliferation of wind power plants, the imperative focus on system robustness and stability intensifies. Doubly fed induction machines (DFIMs) are extensively employed in land-based wind power plants due to their performance advantages. While the stator windings are directly connected to the power system, the rotor windings are connected via power converters, making these units vulnerable to voltage disturbances. During faults, voltage drops at the stator terminals lead to elevated voltages and currents on the rotor side due to electromagnetic coupling between stator and rotor, potentially damaging rotor insulation and costly power electronics. Historically, wind power plants employing DFIMs were disconnected from the grid during faults—an unsatisfactory solution given the burgeoning number of these installations. Consequently, grid operators and IEEE standard 2800 mandate fault ride-through (FRT) capabilities to maintain system stability during disturbances. This paper provides a short review of the existing techniques for protecting DFIMs during faults, focusing on both passive and active protection methods. Additionally, a simple calculation is presented to compare two different protection strategies, illustrating the differences in their effectiveness. The review emphasizes the necessity for developing models that represent all protection methods for DFIMs, due to the clear differences in the results obtained. Full article

In electric powertrain traction applications, the adopted trend to improve the performance and efficiency of electromechanical power conversion systems is to increase supply voltages and inverter switching frequencies. As a result, electrical machine conductors are subjected to ever-increasing electrical stresses, leading to premature insulation degradation and eventual short-circuits. Winding condition monitoring is crucial to prevent such critical failures. Based on the scientific literature, several methods can be used for early identification of aging. A first solution is to monitor partial discharges. This method requires the use of a specific measurement device and an undisturbed test environment. A second solution is to monitor the inter-turn winding capacitance, which is directly related to the condition of the insulation and can cause a change in the stator impedance behavior. Several approaches can be used to estimate or characterize this impedance behavior. They must be performed on a machine at standstill, which limits their application. In this paper, a new characterization method is proposed to monitor the high-frequency stator impedance evolution of voltage source inverter-fed machines. This method can be applied at any time without removing the machine from its operating environment. The range and accuracy of the proposed frequency characterization depend in particular on the supply voltage level and the bandwidth of the measurement probes. The effects of parameters such as temperature, switching frequency, and DC voltage amplitude on the impedance characteristic were also studied and will be presented. Tests carried out on an automotive traction machine have shown that the first two series and parallel resonances of the high-frequency impedance can be accurately identified using the proposed technique. Therefore, by monitoring these resonances, it is possible to predict the aging rate of the conductor. Full article

In the variable frequency motor drive system, because the cable impedance does not match the motor impedance, the reflection wave of the voltage wave will be generated. The superposition of reflected voltage waves can lead to overvoltage at the motor ends, which can damage the insulation structure. In this paper, the equivalent circuit models of cable and stator winding are established, respectively. The overvoltage distribution under different power supply frequencies and cable lengths is simulated and analyzed. The influence mechanism of power supply frequency and cable length on the overvoltage distribution of stator winding are studied. The simulation results show that the overvoltage of the first pulse falling edge will be superimposed on the overvoltage of the second pulse rising edge under high-frequency conditions, resulting in a further increase in the overvoltage. The voltage appears in all coils after the middle of the winding. The ground voltage is up to 1.32 times the input voltage, and the inter-turn voltage is up to 9.2 times the average voltage. The increase in cable length will lead to an increase in ground voltage, but the increase in speed will slow down after exceeding the critical length of 300 m. The maximum ground voltage can reach 1.93 times of the input voltage, which is 3.6% different from the calculation result under ideal conditions. The inter-turn voltage changes with the cable length in an N-shaped manner, up to 185 V. The results of this paper are of great significance to further study the insulation design of generator end input. Full article

Inverter-fed machines are widely used in electric vehicle drive systems and have shown a trend toward high voltage and frequency in recent years. They are subjected to multiple types of stress during operation, causing potential short-circuit fault damage to the stator winding insulation. Online condition monitoring of the insulation before or in the early stage of the short circuit fault can effectively reduce maintenance costs and ensure its health. This paper reviews and summarizes the deterioration mechanism and the recent online electrical monitoring techniques. First, four types of failure stress and each type’s failure factors and mechanisms are analyzed. The coupling effect and overall process of multi-physical fields on stator insulation failure are considered. Secondly, the latest online electrical monitoring technologies are summarized. Each technique’s principles, methods, advantages, and disadvantages are analyzed. Finally, existing problems and possible directions for improvement in current research are discussed, focusing on their feasibility and accuracy in practical applications. Full article
