This paper investigates the special phenomenon that the practical immersed depth of a spiral bevel gear as the driving gear under splash lubrication is significantly less than the static depth. To quantify the practical immersion depth, a computational fluid dynamics (CFD) approach integrated with image processing techniques is utilized to determine the dynamic immersion depth and the associated churning power loss. First, a theoretical method is developed to estimate the churning losses of the bevel gear by replacing the static immersion depth with the practical dynamic immersion depth. Subsequently, the CFD method, which incorporates the overset mesh technique and the volume-of-fluid (VOF) method, is employed to simulate the gear churning phenomenon. Meanwhile, the dynamic immersion depth is determined through image processing techniques that analyze the oil distribution characteristics in the splash-lubricated bevel gear. Finally, experimental results obtained from a dedicated lubrication test rig are favorably compared with the numerical results, confirming that the practical dynamic immersion depth is an accurate and effective parameter for calculating power losses. Full article

The toothless oil stirring disk is vital in modern transmission technology, particularly in fields like aviation, aerospace, and nuclear power, significantly impacting equipment performance. Oil-stirring lubrication is widely used in internal systems due to its simplicity and high reliability, but oil-stirring losses during lubrication contribute to increased system temperatures, affecting lifespan and performance. Accurate simulation of the two-phase flow during the lubrication process of high-speed toothless oil stirring disks is crucial for extending the lubrication system service life. This paper proposes a dynamic modeling approach for the lubrication of high-speed toothless oil stirring disks, integrating the volume of fluid (VOF) model and the RNG k-ε turbulence model, alongside spring smoothing and dynamic mesh reconstruction techniques. The model explores fluid flow and oil distribution in high-speed, toothless oil stirring pans, investigating the effects of different stirring pan speeds and oil heights on lubrication performance. Results indicate that stirring pan speed and oil height are key to improving lubrication efficiency. At high speeds, centrifugal force and gravity cause the lubricating oil to detach from the stirring pan surface, continuing to splash due to inertia. At 3200 r/min and an oil level of 20 mm, a stable oil film forms in the gearbox. Higher stirring pan speeds generate greater turbulence, enhancing lubrication effectiveness. The findings offer theoretical insights for dynamic lubrication system modeling and support gearbox design and optimization in aerospace and similar fields. Full article

This paper presents comparable sets of the no-load power loss as a product of windage and churning behaviors of a family of various rotating parts (i.e., disc, spur gear, straight bevel gear, and orthogonal face gear). Experimental measurements were carried out under pure air only and under partial immersion in oil to qualify and quantify the windage and churning effects of no-load power losses of a family of spur, bevel, and face gears along with a representative disc as the baseline. Aiming at exploring the influence of gear teeth on the total no-load power losses, two different theoretical analytical approaches are introduced to account for the churning contributions, by which the total power losses are estimated. Both analytical approaches compare well with the experimental findings. Furthermore, a spatial intersecting cross-axis gear (e.g., straight bevel gear and orthogonal face gear) results in higher no-load power losses than that of a representative disc or a parallel-axes gear. The significance of gear teeth (gear vs. disc) on windage behavior is presented, as well as the gear windage effects on the churning phenomenon in a high-speed splash-lubricated gear. Full article

In order to clarify the effect of mixed lubrication methods on the oil flow and power loss of the gearbox, this study adopts a high-precision moving particle semi-implicit (MPS) method to investigate the lubrication of the gearbox under the joint influence of splash lubrication and oil injection lubrication. The accuracy of the numerical method to calculate the churning torque was verified by the constructed test rig. The effects of rotational speed, immersion depth, injection volume rate, and oil injection angle were analyzed and evaluated for lubrication. The results show that better lubrication can be achieved with relatively small churning torques by using a hybrid lubrication method. This provides some references for engineering applications of gearboxes. Full article

To investigate the lubrication characteristics in high-speed train gearboxes, a two-stage herringbone gearbox with an idle gear was analyzed. The lubricant flow and distribution were shown using the moving particle semi-implicit (MPS) method. A liquid film flow model was brought in to enhance the non-slip wall boundary conditions, enabling MPS to predict the film flow characteristics. This study investigates the influence of gear rotating speed, lubricant volume, and temperature on lubricant flow, liquid film distribution, lubrication state in the meshing zone, and churning power loss. The results indicate that lubrication characteristics depend on the splashing effect of rotating gears and lubricant fluidity. Increasing gear rotating speed and lubricant temperature can improve liquid film distribution on the inner wall, increase lubricant volume, and thus enhance film thickness. The lubricant particles in the meshing zone correlate positively with the gear rotating speed and lubricant volume, correlate negatively with a temperature above 20 °C, and decrease notably at low temperatures. Churning power loss mainly comes from the output gear. As lubricant volume and gear rotating speed increase, churning torque and power loss increase. Above 20 °C, viscosity decreases, reducing power loss; low temperatures lessen lubricant fluidity, reducing churning power loss. Full article

The transient lubrication conditions of rolling bearings are different in gearboxes and bearing testers. It has been observed that samples of qualified rolling bearings tested in rolling bearing testers often fail and do not meet lifespan requirements when employed in other lubrication conditions. This may be caused by different factors affecting the bearing in testing and applying lubrication. Needle roller bearings were selected for this study to investigate the causes of this phenomenon in terms of lubrication. Based on the computational fluid dynamics (CFD) method, fluid domain models for the same type of rolling bearings with different lubrication conditions were established. The transient flow fields of rolling bearings with oil jet lubrication in a tester and splash lubrication in a planetary gearbox were simulated. The air–oil transient distribution of rolling bearings in two kinds of lubrication was analyzed. The results indicate that the rotational speed significantly affected the oil jet lubrication of the needle roller bearing. The average oil volume fraction rose by 0.2 with the increase in the bearing speed from 1200 r/min to 6000 r/min and by 0.06 with the increase in the oil jet velocity from 8 m/s to 16 m/s. The splash lubrication of the bearings in the planetary gearbox was directly related to the immersion depth of the rolling bearings in the initial position. Meanwhile, the splash lubrication of the bearings was also affected by other factors, including the initial layout of the planetary gears. The increase in speed from 1200 r/min to 6000 r/min made the average oil volume fraction of splash lubrication decrease by 4.4%. The average oil volume fraction of the bearings with splash lubrication was better than that with oil jet lubrication by an average of 41.9% when the bearing speed was in the low-speed stage, ranging from 1200 r/min to 3600 r/min. On the contrary, the bearings with oil jet lubrication were better than those with splash lubrication by an average of 31.8% when the bearing speed was in the high-speed stage, ranging from 4800 r/min to 6000 r/min. Full article

In order to accurately and efficiently analyze the distribution law and motion status of lubricating oil in the spiral bevel gearbox of the electric multiple unit (EMU), a high-fidelity 3D CFD model of the spiral bevel gearbox of the EMU was established for the first time. The moving particle semi-implicit method was used to visualize the lubricating-oil flow field distribution characteristics of the gearbox. The distribution characteristics of lubricating oil in the gearbox with varying gear rotation speeds, initial lubricating-oil volume levels and oil temperatures were analyzed. It was found that the initial lubricating-oil volume is the factor with the largest influence, while the influences of gear rotation speed and oil temperature are relatively small. By analyzing the churning loss under various simulation conditions, it was found that the churning loss is positively correlated with the gear rotation speed and initial oil volume, and is more affected by the initial oil volume. The churning loss is negatively correlated with the oil temperature, and both are nonlinear relationships. The proportion of churning loss related to the driven gear is higher compared to that of the driving gear. These results can provide a theoretical basis for the subsequent optimization of the gearbox. Full article

Lubricating oil flow characteristics are the primary concern in the main reducer of light helicopters. To improve the lubricating performance of the main reducer, a special lubrication system is innovatively constructed by adding two oil-guiding tubes to the hub of the output gear, and the influence of the oil-guiding tubes is investigated through CFD (computational fluid dynamics) techniques. A CFD model of the gearbox integrated with the VOF (volume of fluid) technique was established to explore the flow characteristics of the oil–air two-phase flow inside the gearing system. To validate the proposed CFD model, a specialized testing rig is devised and manufactured to examine the features of oil distribution. The effects of the structure parameters of the oil-guiding tubes and operating conditions on the lubrication performance are explored. Comparing experimental and numerical findings reveals that the inner diameter of the oil-guiding tube and the rotational speed of the driven gear have a significant influence on the lubrication performance. In contrast, the length of the installation end of the oil-guiding tube, its angle, and the oil-immersion depth show little impact. Full article

Among ever-increasing demands for low power consumption, low weight, and compact reducer systems, an oil-guiding splash lubrication method integrating the oil-guiding cylinder and pipes is suggested to be more suitable for light helicopters, instead of conventional splash or oil jet lubrication. Aiming at improving the lubrication and cooling performance of this special lubrication method, this paper introduces an oil-guiding channel to increase oil quantity reaching the driving gear, bearings, and spline. Firstly, the lubrication and cooling effect of the oil-guiding channel in the main gearbox is investigated at various speeds and oil depths by leveraging with a computational fluid dynamics (CFD) technique. Then, a specialized test bench is set up and utilized for experiments to verify the CFD study. These results show that the numerical results are very satisfactory with the data of experimentation, and the maximum value of relative errors is no more than 15%. What is more, the oil flow rate passing through the monitoring plane with the oil-guiding channel is much greater than that without the channel by about three orders of magnitude. It also suggests that the oil-guiding channel could dramatically increase the lubricating oil in the meshing gear pair, and significantly improve the lubrication and cooling effect. Full article

Limited by the space and weight of the reducer, it is difficult to use traditional oil-jet lubrication and splash lubrication for a light helicopter, so an oil-guiding splash lubrication method is adopted as a research object in this paper. Firstly, the lubrication performance of the oil-guiding cylinder in the main reducer under different rotating speeds, oil levels, and flight attitudes is investigated based on the computational fluid dynamics (CFD) method. Then, a specific test rig is developed, and lubrication tests are carried out to verify the feasibility and correctness of the simulation. These results show that oil level, rotating speed, and flight attitude have a great influence on splash lubrication performance. Full article

The porous oil-containing cage achieves the storage, spillage, and suction of lubricating oil by its micro-pore structure, thus ensuring the self-lubricating performance of the bearing. Carrying out fast and accurate modeling of the cage microscopic pore structure is the key to the analysis of the self-lubricating mechanism of bearings. In response to the issues where current modeling methods of porous materials have a low similarity of pore distribution, morphology, structure, and size characteristics, and the transition of pore surfaces is sharp, this paper proposed a modeling method of a highly similar micro-pore structure based on the idea of median filtering, the quartet structure generation set (QSGS), and the slice method. By extracting and analyzing the pore characteristics of the porous model and comparing them with the experimental results of CT scanning, the advantages of the modeling method in terms of morphology and pore connectivity were verified. Finally, by carrying out simulation analysis of the centrifugal force of oil splashing and capillary oil absorption on the constructed model by combining the parameters of porous structures such as porosity and tortuosity, the advantages of the modeling method in the construction of the porous model and multi-physical field analysis were further verified. Full article

In this study, we propose a computational fluid dynamics (CFD)-based method to study the lubrication and temperature characteristics of an intermediate gearbox with splash lubrication. A volume of fluid (VOF) multiphase model was used to track the interface between oil and air. A multiple reference frame (MRF) model was adopted to accurately simulate the movement characteristics of the gears, bearings, and the surrounding flow field. The thermal-fluid coupling computational model of an intermediate gearbox with splash lubrication was then established. Combined with experimental results, we verified that the lubricating oil temperature was below the limit requirement (<110 °C). The numerical results revealed that large amounts of lubricating oil were splashed onto the tooth surfaces near the gear meshing area. A large convective heat transfer coefficient corresponds to a low gear tooth surface temperature. The tooth surface temperature of the driving gear is higher than that of the driven gear. The distribution law of oil volume fraction of the bearing roller was jointly affected by the roller rotation direction and gravity. The convective heat transfer coefficient of the roller wall was largely related to the lubrication environment of the roller, including the oil distribution inside the bearing cavity and the flow rate. Full article

The research of oil/air two-phase flow and heat transfer is the fundamental work of the design of lubrication and heat transfer in aero-engine bearing chamber. The determination of impact state criterion of the moving oil droplets with the wall and the analysis of oil droplet deposition characteristics are important components. In this paper, the numerical analysis model of the impact between the moving oil droplet and the wall is established by using the finite volume method, and the simulation of oil droplet impingement on the wall is carried out. Then the effects of oil droplet diameter, impact velocity, and incident angle on the characteristic parameters of impact state are discussed. The characteristic parameters include the maximum spreading length, the maximum spreading width, and the number of splashing oil droplets. Lastly the calculation results are verified through comparing with the experimental results in the literature. The results show as follows: (1) The maximum spreading width of oil droplet firstly increases and then slows down with the incident angle and the oil droplet diameter increasing; (2) when the oil droplet diameter becomes small, the influence of the incident angle on the maximum spreading length of oil droplet is obvious and vice versa; (3) with the impact velocity and diameter of oil droplet increasing, the maximum spreading width of oil droplet increases firstly and then slows down, and the maximum spreading length increased gradually; (4) the number of splashing oil droplets increases with the incident angle and impact velocity increasing; and (5) compared with the experimental data in literature, the critical dimensionless splashing coefficient $Kc$ proposed in this paper can better distinguish the impact state of oil droplet. Full article

To investigate the influence of the dynamic motion of a gearbox on lubricating flow field and churning power losses under splash lubrication, a computational fluid dynamics (CFD) method based on a combination of the fluid of volume (VOF) method and turbulence model is presented in this paper. A non-inertial coordinate system was employed to simulate the motion of the gearbox, and the feasibility and accuracy of the method was validated by the available experimental results. Numerical models of the gearbox with a spur gear pair under no load operation condition were established, and sinusoidal motions with different frequencies and amplitudes were implemented in the gearbox. The effects of the rotational speed of gears, oil immersion depth, and the frequency and amplitude of sinusoidal motions were studied. The results showed that the dynamic motion of the gearbox can exert a significant influence on churning losses and the oil supply of the gear contacting zone, and the gear pair may be in a loss-of-lubrication state. Full article
