This study proposes a multi-objective optimization scheduling method for edible oil transportation in smart manufacturing, focusing on centralized control and addressing challenges such as complex pipelines and shared resource constraints. The method employs the A* and Dijkstra pathfinding algorithm to determine the shortest pipeline route for each task, and estimates pipeline resource usage to derive a node cost weight function. Additionally, the transport time is calculated using the Hagen–Poiseuille law by considering the viscosity coefficients of different oil types. To minimize both cost and time, task execution sequences are optimized based on a Pareto front approach. A 3D digital model of the pipeline system was developed using C#, SolidWorks Professional, and the Helix Toolkit V2.24.0 to simulate a realistic production environment. This model is integrated with a 3D visual human–machine interface(HMI) that displays the status of each task before execution and provides real-time scheduling adjustment and decision-making support. Experimental results show that the proposed method improves scheduling efficiency by over 43% across various scenarios, significantly enhancing overall pipeline transport performance. The proposed method is applicable to pipeline scheduling and transportation management in digital factories, contributing to improved operational efficiency and system integration. Full article

The design of custom abutments (CA) can affect the mechanical reliability of implant-supported restorations. The purpose of the study was to evaluate the influence of design parameters on the fatigue limit of CA and to compare optimized custom designs with the reference abutment (RA). A morse-tapered dental implant, an anatomical abutment, and a connector screw were digitalized using microcomputed tomography. A cone beam computed tomography scan was obtained from one of the authors to virtually place the implant-abutment assembly in the upper central incisor. Ten design parameters were selected according to the structural geometry of the RA and the implant planning. A reverse-engineered RA model was created in SOLIDWORKS and was modified considering a Taguchi orthogonal array to generate 36 CAs with ±20% dimensional variations. Finite element analysis was conducted in ABAQUS, and fatigue limits were estimated using Fe-safe. ANOVA (α = 0.1) identified the most influential parameters. Von Mises stress values ranged from 229 MPa to 302 MPa, and 94.4% of the CAs had a higher fatigue limit than the RA. Three parameters significantly affected the fatigue performance of the implant system. The design process of custom abutments includes critical design parameters that can be optimized for longer lifetimes of implant-abutment restorations. Full article

With the increasing environmental pollution and resource consumption caused by automobiles, a lightweight design of automobiles is the best solution at present. In this paper, the load-bearing frame of pure electric SUVs is taken as the research object. The finite element analysis method is used to analyze the strength, stiffness and modal performance of the load-bearing frame, and the material selection of the frame is optimized according to the analysis results to achieve a lightweight design. First, a three-dimensional model of the pure electric SUV frame is established using SolidWorks software 2019 and then imported into ANSYS 2024 R1 Workbench for meshing and material property definition. Then, through finite element static analysis, the various force conditions of the frame under three typical working conditions of full-load bending, full-load braking and full-load turning are simulated; the stress distribution and deformation of the frame under different working conditions are confirmed; and the strength and stiffness performance of the frame are evaluated. After the above analysis, a modal analysis of the frame is carried out, and the natural frequency and vibration mode of the frame are finally obtained. According to the analysis results, the material replacement method is selected to optimize the lightweight design of the frame. The results show that the weight of the frame is significantly reduced after material optimization, while still meeting the strength, stiffness and modal performance requirements. This article provides a certain reference value for the lightweight design of pure electric SUV frames in the future. Full article

The design of the suspension system affects handling and stability, vibrations of the steered wheels, vehicle ride comfort, and tyre tread wear. One of the most important vibration parameters is acceleration; high acceleration values can have an adverse effect on both the driver and passengers, as well as on the components of the vehicle’s suspension and handling. This paper presents the results of the effects of acceleration on the components of a front-independent MacPherson suspension system. Data on the accelerations were obtained from theoretical and experimental studies. A simulation study was conducted, taking into account the elastic and damping characteristics of the elastic components. The experimental study was conducted under laboratory conditions by using a suspension tester, BEISSBARTH, and a measuring system developed with LabVIEW 2021 SP1 and MATLAB R2022b software. The experiments were conducted with different tyre pressures and by using bushings made from different materials. The experimental tests were conducted with two rubber bushings within the mounting of the arm, as well as a rubber bushing and a polyurethane bushing. The experimental results were compared and analyzed. Two theoretical models were considered: one is a mathematical model, and the other is a simulation model which uses the finite element method. Numerical dynamic analysis of the suspension was performed using the SolidWorks 2023. Full article

This study aims to evaluate the feasibility and accuracy of 3D printing-guided endodontics in the maxillary teeth of dogs. CT data from a Beagle dog were processed to create a 3D model of the maxilla, and virtual root canal pathways were established using SOLIDWORKS software (version 29.0.0.5028). Guided endodontic templates were 3D printed and tested in vitro on 20 maxillary teeth (excluding the third molars), with 36 root canals treated using both guided and conventional methods. Results indicated that 3D printing-guided endodontics provided accurate root canal pathways, with minimal deviations in length (average 3.08 ± 1.75%) and angular alignment (average 2.06° ± 0.5°) compared to conventional methods. This research represents a significant step forward in the application of 3D printing technology in veterinary endodontics, offering a promising alternative to traditional methods for treating complex dental conditions in dogs. Full article

The piston, as one of the main components of the crankshaft mechanism, is subjected to significant mechanical and thermal loads. The mechanical properties of the alloy from which it is made and the technology of its manufacture are related to the maximum allowable value of the combustion pressure. The purpose of this paper is to determine the maximum value of the boost pressure of an existing gasoline engine, without causing damage to its piston. To achieve this goal, the stress and strain state of the piston was determined using finite element analysis (FEA) with consideration of the influence of temperature at different values of the boost (intake) pressure. The temperature distribution of the piston was determined using transient thermal analysis. The analyses were performed using SolidWorks Simulation. The obtained results were compared and analyzed. Full article

Mid-altitude sounding rockets are essential for atmospheric research and suborbital experimentation, where aerodynamic optimization and structural integrity are crucial for achieving targeted apogees. This study uses OpenRocket v23.09 for preliminary flight performance prediction and SolidWorks 2024 to integrate aerodynamic and structural analyses through Computational Fluid Dynamics (CFD) and Finite Element Analysis (FEA). SolidWorks Flow Simulation and SolidWorks Simulation are used to assess how nose cone and fin geometries, as well as thermal deformation, influence flight performance. Among nine tested configurations, the ogive nose cone with trapezoidal fins achieved the highest simulated apogee of 2639 m, with drag coefficients of 0.480 (OpenRocket) and 0.401 (SolidWorks Flow Simulation). Thermal–structural analysis revealed a maximum nose tip displacement of 0.7249 mm for the rocket with the ogive nose cone, leading to an increasing drag coefficient of 0.404. However, thermal deformation of the ellipsoid nose cone led to a reduction in the drag coefficient from 0.419 to 0.399, even though it exhibited a slightly higher maximum displacement of 0.7443 mm. Mesh independence was confirmed with outlet velocity deviations below 1% across refinements. These results highlight the importance of integrated CFD–FEA approaches, geometric optimization, and material resilience for enhancing the aerodynamic performance of subsonic sounding rockets. Full article

This study consisted of the injection molding simulation of polycaprolactone (PCL)-based nanocomposites reinforced with multi-walled carbon nanotubes (MWCNTs) for biomedical implant manufacturing. The simulation was additionally supported by experimental validation. The influence of varying MWCNT concentrations (0.5%, 5%, and 10% by weight) on key injection molding parameters, i.e., melt flow behavior, pressure distribution, temperature profiles, and fiber orientation, was analyzed with SolidWorks Plastics software. The results proved the low CNT content (0.5 wt.%) to be endowed with stable filling times, complete mold cavity filling, and minimal frozen regions. Thus, this formulation produced defect-free modular filament sticks suitable for subsequent 3D printing. In contrast, higher CNT loadings (particularly 10 wt.%) led to longer fill times, incomplete cavity filling, and early solidification due to increased melt viscosity and thermal conductivity. Experimental molding trials with the 0.5 wt.% CNT composites confirmed the simulation findings. Following minor adjustments to processing parameters, high-quality, defect-free sticks were produced. Overall, the PCL/MWCNT composites with 0.5 wt.% nanotube content exhibited optimal injection molding performance and functional properties, supporting their application in modular, patient-specific biomedical 3D printing. Full article

In recent years, there has been a surge in the extrusion-based 3D printing of materials for various biomedical applications. This work presents a novel methodology for optimizing extrusion-based 3D bioprinting of a gelatin/siloxane hybrid material for biomedical applications. A systematic approach integrating rheological characterization, computational fluid dynamics simulation (CFD), and machine-learning-based image analysis, was employed. Rheological tests revealed a shear stress of 50 Pa, a maximum viscosity of 3 × 10⁵ Pa·s, a minimum viscosity of 0.089 Pa·s, and a shear rate of 15 rad/s (27G nozzle, 180 kPa pressure, 32 °C temperature, 30 mm/s velocity) for a BIO X bioprinter. While these parameters yielded constructs with 54.5% similarity to the CAD design, a multi-faceted optimization strategy was implemented to enhance fidelity, computational fluid dynamics simulations in SolidWorks, coupled with a custom-develop a binary classifier convolutional neuronal network for post-printing image analysis, facilitated targeted parameter refinement. Subsequent printing optimized parameters (25G nozzle, 170 kPa, 32 °C, 20 mm/s) achieved a significantly improved similarity of 92.35% CAD, demonstrating efficacy. The synergistic combination of simulation and machine learning ultimately enabled the fabrication of complex 3D constructs with a high fidelity of 94.13% CAD similarity, demonstrating the efficacy and potential of this integrated approach for advanced biofabrication. Full article

This study addresses the urgent demand for high-precision manufacturing of curved components by developing a fully servo-driven multi-axis controlled four-roll bending machine. By integrating a modular symmetric roller system design with a distributed hierarchical motion control architecture, we achieved substantial enhancements in scalability, forming stability, and machining accuracy. The mechanical system underwent static simulation optimization using SolidWorks Simulation, ensuring maximum stress in the guiding mechanism was controlled below $7.118\times {10}^3$ N/m². ABAQUS-based roll-bending dynamic simulations validated the geometric adaptability and process feasibility of the proposed mechanical configuration. A master-slave dual-core control architecture was implemented in the control system, enabling synchronized error ≤ 0.05 mm, dynamic response time ≤ 10 ms, and positioning accuracy of ±0.01 mm through collaborative control of the master controller and servo drives. Experimental validation demonstrated that the machine achieves bending errors within 1%, with an average forming error of 0.798% across various radii profiles. The arc integrity significantly outperforms conventional equipment, while residual straight edge length was reduced by 86.67%. By adopting fully servo-electric cylinder actuation and integrating a C#-developed human–machine interface with real-time feedback control, this research effectively enhances roll-bending precision, minimizes residual straight edges, and exhibits broad industrial applicability. Full article

To address the frequent failure of anti-falling devices in inclined shaft tunnel boring machines caused by cyclic loading and fatigue during construction, this study proposes an optimized self-responsive anti-falling device design. Based on the operational conditions of the “Tianyue” tunnel boring machine, a three-dimensional model was constructed using SolidWorks. Finite element static analysis was employed to validate structural integrity, revealing a maximum stress of 461.19 MPa with a safety factor of 1.71. Explicit dynamic simulations further demonstrated the dynamic penetration process of propellant-driven telescopic columns through concrete lining walls, achieving a penetration depth exceeding 500 mm. The results demonstrate that the device can respond to falling signals within 12 ms and activate mechanical locking. The Q690D steel structure exhibits a deformation of 5.543 mm with favorable stress distribution, meeting engineering safety requirements. The energy release characteristics of trinitrotoluene propellant and material compatibility were systematically verified. Compared to conventional hydraulic support systems, this design offers significant improvements in response speed, maintenance cost reduction, and environmental adaptability, providing an innovative solution for fall protection in complex geological environments. Full article

Lightweight, layered wood-based panels are gaining attention due to favorable mechanical and physical properties. This study examined numerical modeling as a method to predict the strength of innovative three-layer sandwich panels with thermoplastic cores containing wood particles as the filler. Two core geometries (F and S) and two material formulations (60% HDPE + 40% sawdust, and 40% HDPE + 60% sawdust) were tested. The panels were produced without additional adhesives; bonding with high-density fiberboard (HDF) facings was achieved through the thermoplastic properties of the core. Mechanical properties such as bending strength (MOR), modulus of elasticity (MOE), and compressive strength perpendicular to the surface were measured. Results showed that both core geometry and material composition significantly influenced structural performance. Panels with the F profile showed better bending strength and stiffness (MOR—13.2 N/mm², MOE—2017 N/mm²), while the S profile had higher compressive strength (0.62 N/mm²). Numerical simulations using SolidWorks Simulation confirmed the experimental data, with stress and displacement distributions matching laboratory results. These findings demonstrate the potential of thermoplastically formed cores for creating lightweight, recyclable wood-based composites with tailored mechanical properties. Full article

This paper focuses on the formidable challenges that underwater robots encounter in complex marine environments. To address these issues, inspired by the cownose ray, an innovative scheme is proposed, utilizing four six-bar mechanisms to mimic its pectoral fin movement. Subsequently, the paper elaborates on the design, computation, and simulation of the bionic pectoral fin mechanism. A Watt-type six-bar mechanism is adopted, and by axially overlaying two scaled-identical mechanisms and setting a phase difference, the pectoral fin waving of the cownose rays is simulated. SolidWorks and ADAMS are employed for precise modeling and simulation. Following this, an experimental prototype is constructed, with the rod assembly produced by subtractive machining. Motion capture and six-dimensional force experiments are then conducted to evaluate its motion dynamics and propulsion efficacy. The experimental results demonstrate that when the two pectoral fins on either side flap synchronously or inversely, the robot can generate varying thrust, lift, and lateral forces, enabling smooth advancement and turning. These findings validate the feasibility and efficacy of bionic design, offering innovative concepts and methodologies for underwater robot development. Full article

This study investigates the structural integrity and dynamic behavior of symmetry-optimized battery pack systems for new energy vehicles through advanced finite element analysis. It examines symmetry-optimized battery pack systems with mechanically stable and thermally adaptive potentials. Leveraging geometric symmetry principles, a high-fidelity three-dimensional (3D) model was constructed in SolidWorks 2023 and subjected to symmetry-constrained static analysis on ANSYS Workbench 2021 R1 platform. The structural performance was systematically evaluated under three critical asymmetric loading scenarios: emergency left/right turns and braking conditions, with particular attention to symmetric stress distribution patterns. The numerical results confirmed the initial design’s compliance with mechanical requirements while revealing symmetric deformation characteristics in dominant mode shapes. Building upon symmetry-enhanced topology configuration, a novel lightweight strategy was implemented by substituting Q235 steel with ZL104 aluminum alloy. While mechanical symmetry has been widely studied, thermal gradients in battery packs can induce asymmetric expansions. For example, uneven cooling may cause localized warping in aluminum alloy shells. This multiphysics effect must be integrated into symmetry constraints to ensure true stability. Symmetric material distribution optimization reduced the mass by 19% while maintaining structural stability, as validated through comparative static and modal analyses. Notably, the symmetric eigenfrequency arrangement in optimized modules effectively avoids common vehicle excitation bands (8–12 Hz/25–35 Hz), demonstrating significant resonance risk reduction through frequency redistribution. This research establishes a symmetry-driven design paradigm that systematically coordinates structural efficiency with dynamic reliability, providing critical insights for developing next-generation battery systems with balanced performance characteristics. Full article

The combustion chamber is a critical component of turbojet engines, and airflow distribution plays an essential role in ensuring flame stability and optimizing combustion efficiency. This study investigates a miniature annular combustion chamber by employing SolidWorks 2022 software to model an evaporative tube combustion chamber. A dedicated combustion test platform was constructed for the proposed miniature combustion chamber. By adjusting the air and fuel flow ratios entering the evaporative tube, the temperature at the flame tube outlet was measured, and the combustion efficiency was subsequently calculated. In addition, numerical analysis was conducted using ANSYS/CFX software to simulate the flow field in the combustion chamber. The following conclusions were drawn from an analysis of the variations in the flow field and temperature field during the simulation process: When the flow rates in the ignition and dilution zones of the miniature annular combustion chamber remained constant, modifying the air-fuel flow ratio within the evaporative tube significantly enhanced the combustion characteristics within the chamber. Specifically, the combustion efficiency is closely related to the ratio of the air mass flow rate to the fuel mass flow rate within the evaporation tube. The highest combustion efficiency was achieved when the ratio fell within the range of 4.20 to 4.96. Furthermore, the area-averaged velocity at the combustion chamber outlet was independent of the air-fuel flow ratio but exhibited a positive correlation with the fuel flow entering the combustion chamber. Full article
