This paper presents the analysis, design, and experimental validation of a Partial Power Processing (PPP) Single-Ended Primary Inductor Converter (SEPIC) for photovoltaic (PV) applications. The proposed topology limits the fraction of processed power through the active switching stage, thereby reducing MOSFET RMS current and associated conduction losses and improving overall conversion efficiency. A complete analytical framework is developed, including steady-state modeling, state-space formulation, and small-signal analysis. The theoretical results are validated through MATLAB/Simulink simulations and laboratory-scale experimental tests under multiple loading conditions. Comparative analysis against a conventional Full Power Processing (FPP) SEPIC converter demonstrates that the proposed PPP configuration achieves efficiencies up to 95% in simulation and up to 93% experimentally, compared to 87% for the FPP counterpart under identical nominal conditions ($V_{\mathrm{in}}=18$ V, $f_{\mathrm{s}}=70$ kHz). Additionally, the PPP approach reduces the MOSFET RMS current by more than 50%, which directly translates into lower conduction losses and reduced device power dissipation. The results confirm that the proposed PPP-SEPIC converter constitutes a technically viable and energy-efficient solution for photovoltaic DC–DC power conversion systems. Full article

The integration of photovoltaic (PV) systems into global energy production is rapidly expanding. However, achieving maximum power extraction remains a significant challenge due to the nonlinear electrical characteristics of PV modules, which are highly sensitive to environmental variations such as temperature fluctuations and irradiance changes. This study presents a structured design, testing, and quasi-experimental validation methodology for robust Maximum Power Point Tracking (MPPT) control in PV systems. We propose two advanced AI-based nonlinear control strategies: an Adaptive Neuro-Fuzzy Inference System combined with Fast Terminal Synergetic Control (ANFIS-FTSC) for a boost converter and ANFIS with Backstepping (ANFIS-BS) for a Single-Ended Primary Inductor Converter (SEPIC), both of which have demonstrated tracking efficiencies exceeding 99.6%. To evaluate real-time performance, a Processor-in-the-Loop (PIL) validation is conducted using an ARM-based STM32F407VG microcontroller. The methodology adheres to a Model-Based Design (MBD) framework, ensuring systematic development, implementation, and verification of the MPPT algorithms in an embedded environment. Experimental results demonstrate that the proposed controllers achieve high efficiency, rapid convergence, and robust maximum power point tracking under varying operating conditions. The successful PIL-based validation confirms the feasibility of these intelligent control techniques for real-world deployment in PV energy systems, paving the way for more efficient and adaptive renewable energy solutions. Full article

A constant current constant voltage charging scheme based on a single-ended primary inductive converter is proposed to address the key issues of wireless power transfer (WPT) technology for charging devices in seawater environments. The scheme can effectively adapt to the complex transmission conditions of a WPT system in a seawater environment by using the advantages of single-ended primary inductor converter (SEPIC) topology, such as adjustable voltage, wide input range, and the same polarity as output; its regulating effect on charging current and voltage is modeled and analyzed. An underwater experimental platform is built to test the charging performance of the system under different transmission distances, radial offsets, and deflection angles (1 A is set for the constant current stage and 5 V for the constant voltage stage). The experimental results show that when the distance is 2 cm, the maximum fluctuation amplitude of the current is 0.04 A. When the transmission distance is increased to 6 cm, and a radial offset of 5 cm is introduced, the fluctuation amplitude increases to 0.13 A. Under the condition of dynamic charging, the maximum fluctuation range of current is 0.15 A, and the fluctuation rate reaches 16.7%. It shows that the system has good applicability and application prospects in seawater environments. Full article

This work presents a sensorless brushless DC motor (BLDCM) drive control, optimized for solar photovoltaic (PV)- and battery-fed light electric vehicles (LEVs). A back-electromotive force (EMF) observer integrated with an enhanced quadrature-phase-locked-loop (QPLL) structure is proposed for accurate rotor position estimation, addressing limitations of existing control methods at low speeds and under dynamic conditions. The study replaces the conventional arc-tangent technique with a QPLL-based approach, eliminating low-pass filters to enhance system adaptability and reduce delays. The experimental results demonstrate a significant reduction in commutation error, with a nearly flat value at 0 degrees during steady-state and less than 8 degrees under dynamic conditions. Furthermore, the performance of a modified single-ended primary-inductor converter (SEPIC) for maximum power point tracking (MPPT) in solar-powered LEVs is verified, minimizing current ripple and ensuring smooth motor operation. The system also incorporates a regenerative braking mechanism, extending the vehicle’s range by efficiently recovering kinetic energy through the battery with 30.60% efficiency. The improved performance of the proposed method and system over conventional approaches contributes to the advancement of efficient and sustainable solar-powered BLDC motor-based EV technologies. Full article

Battery charging systems are crucial for energy storage in off-grid photovoltaic (PV) installations. Since the power generated by a PV panel is conditioned by climatic conditions and load characteristics, a maximum power point tracking (MPPT) technique is required to maximize PV power and accelerate battery charging. On the other hand, a battery must be carefully charged, ensuring that its charging current and voltage limits are not exceeded, thereby preventing premature degradation. However, the voltage generated by the PV panel during MPPT operation fluctuates, which can harm the battery, particularly during periods of intense radiation when overvoltages are likely to occur. To address these issues, the design and construction of an enhanced solar battery charger utilizing a single-ended primary-inductor converter (SEPIC) and soft computing (SC)-based control is presented. A control strategy is employed that integrates voltage stabilization and MPPT functions through two dedicated fuzzy logic controllers (FLCs), which manage battery charging using a three-mode scheme: MPPT, Absorption, and Float. This approach optimizes available PV power while guaranteeing fast and safe battery charging. The developed charger leverages the SEPIC’s notable features for PV applications, including a wide input voltage range, minimal input current ripple, and an easy-to-drive switch. Moreover, unlike most PV charger control strategies in the literature that combine improved traditional MPPT methods with classical proportional integral (PI)-based control loops, the proposed control adopts a fully SC-based strategy, effectively addressing common drawbacks of conventional methods, such as slowness and inaccuracy during sudden atmospheric fluctuations. Simulations in MATLAB/Simulink compared the FLCs’ performance with conventional methods (P&O, IncCond, and PID). Additionally, a low-power hardware prototype using an Arduino Due microcontroller was built to evaluate the battery charger’s behavior under real weather conditions. The simulated and experimental results both demonstrate the robustness and effectiveness of the solar charger. Full article

A novel ac/dc LED driver with power factor correction and soft-switching functions is proposed. The circuit topology mainly consists of two modified single-ended primary inductance converters (SEPIC) with interleaved operation. The first half stage of SEPIC operates like a boost converter and the second half stage operates like a buck–boost converter. Each boost converter is designed to operate in discontinuous current mode (DCM) to function as a power factor corrector (PFC). The two buck–boost converters that share a commonly coupled inductor are designed to operate at near boundary conduction mode (BCM). Without using any active clamping circuit, auxiliary switch or snubber circuit, the active switches can achieve zero-voltage switching on, and all diodes achieve zero-current switching off. First, operation modes in steady state are analyzed, and the mathematical equations for design component parameters are derived. Finally, a prototype circuit of 180 W rated power was built and tested. Experimental results show satisfactory performance of the proposed circuit. Full article

This paper introduces a Linear Quadratic Gaussian (LQG) controller for a Single-Ended Primary Inductor Converter (SEPIC). The LQG design is based on merging an integral Linear Quadratic Regulator (LQR) with an offline Kalman Filter (commonly referred to as a Linear Quadratic Estimator (LQE)). The robustness of the LQG controller is guaranteed based on the separation principle. This manuscript addresses the need to use observer-based systems for the fourth-order SEPIC, which needs a sensor reduction as an essential requirement. This paper provides a comprehensive, yet systematic, approach to designing the LQG system. The work validates the convergences of the states in an LQG system to an actual value. Furthermore, it compares the performance of an LQG system with a benchmark Type-II industrial controller by means of a simulation of the switched converter model in the Simulink/MATLAB 2023a environment. Full article

This article presents the development and execution of a Single-Ended Primary-Inductor Converter (SEPIC) multiplier within a Hardware-in-the-Loop (HIL) emulation environment tailored for photovoltaic (PV) applications. Utilizing the advanced capabilities of the dSPACE 1104 platform, this work establishes a dynamic data exchange mechanism between a variable voltage power supply and the SEPIC multiplier converter, enhancing the efficiency of solar energy harnessing. The proposed emulation model was crafted to simulate real-world solar energy capture, facilitating the evaluation of control strategies under laboratory conditions. By emulating realistic operational scenarios, this approach significantly accelerates the innovation cycle for PV system technologies, enabling faster validation and refinement of emerging solutions. The SEPIC multiplier converter is a new topology based on the traditional SEPIC with the capability of producing a larger output voltage in a scalable manner. This initiative sets a new benchmark for conducting PV system research, offering a blend of precision and flexibility in testing supervisory strategies, thereby streamlining the path toward technological advancements in solar energy utilization. Full article

A smart ultrasound scanner plays an important role in the transition to point-of-care imaging. DC–DC bipolar converters are essential in the generation of the ultrasound burst signal as they power the piezoelectric transducer. The conventional bipolar converter has minimal output gain and high-voltage stress, and the longer duty cycle on the semiconductors produces high conduction losses and reduces the efficiency of the system. The transmitter supply voltage is minimal, necessitating the use of high-gain bipolar converters. This proposed study is concerned with the development of an improved high-output voltage gain symmetric bipolar DC–DC converter topology which may be suitable for applications such as powering a smart ultrasound scanner transmitter. The proposed converter combines the conventional single-ended primary inductor converter (SEPIC) with a voltage multiplier cell (VMC) to improve voltage gain, transistor duty cycle, efficiency, and reliability. The present study describes the working principle of the proposed converter. The analysis of the voltage gain is carried out in continuous current mode (CCM) and discontinuous current mode (DCM), taking into account the nonidealities of the device. The simulation of the proposed system is carried out in the numerical environment Matlab/Simulink in order to verify its characteristics. A prototype model is realized and the experimental study presented validates the theoretical arguments and simulations. Due to the advantages of continuous input current, self-balancing bipolar outputs, and small component size, the proposed converter is a suitable choice for smart ultrasound transmitters. Full article

This paper presents a novel topology of a modified isolated single-ended-primary-inductance converter (SEPIC) with a model predictive control (MPC) approach applied to direct current (DC) electronic loads. The proposed converter uses an actual transformer rather than a coupled inductor for isolation between the source and the load. The transformer allows the proposed converter to operate at a higher switching frequency, ultimately reducing the passive components’ size. A low-power hardware prototype is developed and tested with a model predictive control algorithm under variable input voltages and load conditions. The performance of the proposed converter is demonstrated to be satisfactory under steady state, as well as sudden input voltage transients. The proposed converter utilizes a switched capacitor technique to generate alternating current in both windings of the transformer. As the coupled inductor is eliminated from the circuit, the problem of high voltage spikes occurring due to leakage inductances is also eliminated for the proposed converter. Therefore, the proposed converter can be used for isolated medium power applications. The experimental results show that the efficiency of the proposed converter reached 96%. The MPC allows this converter’s DC voltage level to remain stable even as the input voltage and output terminal load change. Lastly, this converter with an MPC approach can be applied to different DC electronic loads, improving DC power quality and DC electronic load life. Full article

Small-scale wind turbines play an important role in distributed generation since customers can use their houses, farms, and business to produce electric energy. The development of the power electronics system that processes the electric energy from small-scale wind turbines is a concern due to cost, simplicity, efficiency, and performance trade-offs. This paper presents the results of applying a three-phase phase-modular single-ended primary-inductance converter rectifier to processing the energy of a small-scale wind turbine system. The rectifier was designed according to the specifications of a commercial small-scale wind turbine system and tested in an emulator workbench, providing experimental data on the operation of the rectifier in this application. The rectifier can process the energy of a non-sinusoidal three-phase system since the permanent magnet synchronous generator has trapezoidal waveforms. The results show that the rectifier has the advantages of (i) using the inductance of the generator as the input filter inductor of the rectifier, (ii) providing input currents with the same shape as the voltages and in phase without the use of a current control system, (iii) simplicity of control of the DC output voltage and PWM modulation, and (iv) phase-modular characteristics that allow operating with phase fault without any additional control techniques. Due to the operation in discontinuous conduction mode, low efficiency in high power and/or low input voltage specifications are disadvantages. Full article

Power factor correction (PFC) can be achieved by a single-ended primary inductor converter (SEPIC) operating in boundary conduction mode (BCM) with conventional constant on-time (COT) control, but it is challenging to achieve low total harmonic distortion (THD) and high-power factor (PF), particularly at high input voltage. A variable on-time (VOT) control strategy for BCM SEPIC PFC converter without input voltage feedforward and multiplier circuits is proposed to realize unity PF in this paper. By using a variable slope sawtooth generator whose slope is controlled by the duty cycle of the main switch to adjust the conduction time of the main power switch of the converter, the proposed VOT control scheme can use a simple and easy-to-implement circuit to enhance the PF and decrease the THD significantly, especially at high input voltage. The simulation model and 100W experimental prototype are built to verify the feasibility of the suggested control method. Simulation and experiment results demonstrated that the novel VOT control scheme remarkably enhances PF and decreases THD without affecting the efficiency by contrast with the conventional COT control. Full article

In recent years, researchers have focused on improving the efficiency of photovoltaic systems, as they have an extremely low efficiency compared to fossil fuels. An obvious issue associated with photovoltaic systems (PVS) is the interruption of power generation caused by changes in solar radiation and temperature. As a means of improving the energy efficiency performance of such a system, it is necessary to predict the meteorological conditions that affect PV modules. As part of the proposed research, artificial neural networks (ANNs) will be used for the purpose of predicting the PV system’s current and voltage by predicting the PV system’s operating temperature and radiation, as well as using JAYA-SMC hybrid control in the search for the MPP and duty cycle single-ended primary-inductor converter (SEPIC) that supplies a DC motor. Data sets of size 60538 were used to predict temperature and solar radiation. The data set had been collected from the Department of Systems Engineering and Automation at the Vitoria School of Engineering of the University of the Basque Country. Analyses and numerical simulations showed that the technique was highly effective. In combination with JAYA-SMC hybrid control, the proposed method enabled an accurate estimation of maximum power and robustness with reasonable generality and accuracy (regression (R) = 0.971, mean squared error (MSE) = 0.003). Consequently, this study provides support for energy monitoring and control. Full article

There are some challenges involved in the design of a multicolor LED driver, such as the precise control of color consistency, i.e., maintaining the correlated color temperature (CCT) and luminous intensity. CCT deviation causes a color shift of composite light. This paper approaches the method of nonlinear optimization of the LED currents of two LED sources to achieve the desired CCT. A bicolor blended-shade white LED system is formed by using a warm color LED source of 1000 K CCT and a cool color LED source of 6500 K CCT. By using a nonlinear optimization methodology, the reduced deviation of the blended CCT and optimum LED currents are obtained. The optimized currents in the two LED strings are maintained by the control circuit of the single-ended primary inductor converter (SEPIC). The obtained reduced deviation of the CCT is 43 K, and the precision is 99.15%. Again, harmonics in the input current hamper power quality, i.e., reduce the power factor and increase power loss. This paper proposes the harmonic reduction technique to achieve the lowest value of total harmonic distortion (THD) through the nonlinear parametric optimization of the SEPIC. Measured THD = 4.37%; PF = 0.96; and efficiency = 92.8%. The system stability was determined and found to be satisfactory. Full article

In the domain of passivity theory, there were major contributions in the last decade, the most recent notion of passivity being the so-called Krasovskii passivity. This framework offers the possibility of designing a controller which ensures the passivity of the resulting closed-loop system. The current paper proposes a solution to design the parameters of Krasovskii passivity-based controllers (K-PBCs) in order to ensure small sensitivity of the closed-loop systems. As such, after the initial construction of the passivity output, the controller parameters are designed in order to impose the dominant eigenvalues of the Jacobian of the resulting closed-loop system with the smallest deviation around the given forced equilibrium point which is, additionally, smaller than a prescribed stability margin. The resulting optimization problem is non-convex by nature, and a metaheuristic approach is proposed to design these parameters. Moreover, in order to impose an extra set of performances, the control system contains an outer loop where dynamical path planning is used to impose the additional requirements. All mentioned results are developed for processes modeled as bilinear systems. In order to illustrate the proposed control method, a numerical example consisting of a single-ended primary inductor DC-DC converter (SEPIC) process is presented. Full article
