It is essential to exercise control over the environmental impact of deep excavation construction in soft soil areas from the perspective of deformation in order to ensure engineering safety. A three-dimensional finite element model of the foundation pit was developed, thereby creating a comparison between the results of the numerical simulation and the actual on-site monitoring data. This process served to validate the precision of the simulations. The focal point of the study pertained to the three-dimensional effects of support structure deformation and ground settlement during excavation. A comprehensive analysis of the spatial distribution and evolutionary patterns of underground diaphragm wall deformation and ground settlement behind the wall at varying excavation depths was conducted. The results demonstrated that both support structure deformation and ground settlement behind the excavated structure exhibited substantial spatial effects. In particular, larger deformations were observed near the symmetrical plane of the excavation centre. Conversely, greatly smaller deformations were observed in the corners of the excavation. The research findings aim to provide useful references for practical engineering projects. Full article

The deep foundation pit excavation of subway will cause horizontal displacement, uneven settlement and other adverse effects on the adjacent shield. The use of servo steel strut has a certain effect on deflection correction, but the current understanding of the influencing factors of deflection correction is not comprehensive. Based on structural and spatial symmetry, the influence of tunnel depth, tunnel and foundation pit clear distance and deformation control quantity of enclosure structure on deflection correction quantity was studied by symmetrically designed model test and numerical simulation, and the prediction formula of deflection correction quantity considering tunnel and foundation pit clear distance and deformation control quantity of enclosure structure was proposed. The results show that with an increase in the tunnel’s burial depth, deflection correction decreases significantly. When the tunnel is near the foundation pit bottom, there is no significant correction effect, and the control law of the tunnel ground pressure under the servo steel strut loading is consistent with the correction law. Deflection correction is negatively correlated with the tunnel and foundation pit clear distance, and positively correlated with the deformation control of the diaphragm wall. The curve of the deformation control of the enclosure structure and the deflection correction is parabolic. The deflection correction is an exponential function of the ratio of the deformation control of the enclosure structure to the clear distance between the tunnel and the foundation pit, and the servo deflection correction follows a normal distribution along the longitudinal axis of the tunnel, showing obvious symmetry characteristics in the foundation pit influence zone. Full article

Rock bursts frequently occur in the fault group area in China, seriously restricting the safe and efficient production of coal mines. Based on field investigation, physical experiments, and numerical simulation, this study investigates the rupture types and spatial evolution of microseismic events during the excavation of working face through fault group areas in the TB Coal Mine, where the hard roof asymmetric is cut by faults. It reveals the cooperative instability mechanism of faults and hard roof, as well as the mechanisms of rock burst. Targeted rock burst prevention measures are proposed, including “roof blasting to cut off dynamic and static load transfer” and “coal blasting to reduce abutment stress”. The results demonstrate the following: (1) during mining in fault group areas, the synchronous activation of faults induces shear-type and high-energy microseismic events and the subsequent movement of hard roof, which has been cut by faults, forms asymmetric parallelograms and symmetric inverted trapezoids, and induces tensile-type and high-energy microseismic events. The synchronous activation of faults and the breaking of the hard roof are identified as the primary reason for high-energy microseismic events. (2) As the fault dip angle approaches 90º, the compressive strength of the fault-segmented hard roof strata decreases. Under synchronous activation of faults, roof failure concentrates in the central, right, and left sections for fault combinations with dip angles of 70° + 70°, 90° + 70°, and 110° + 70°, respectively. (3) Numerical simulations reveal two rock burst mechanisms in faults—hard roof systems: a forward “high dynamic stress and high static stress” type and a rear “low dynamic stress and high static stress “ type, which is consistent with in situ monitoring data. (4) For the three stages in which the 502 working face approaches, passes through, and mines away from the fault group area, a stress relief scheme combining roof blasting and coal blasting is proposed. Compared with the 501 working face, during the mining of the 502 working face, the total microseismic frequency and energy decreased by 71.9% and 87.9%, respectively, and the effectiveness of these measures is verified. Full article

The coupling mechanism involving high-pressure seepage and soil degradation regarding the face stability in water-rich silty sand environment remains to be comprehensively elucidated. This paper employs 3D fluid–solid coupling simulations to investigate these interactions taking the Jingu-Haihe Tunnel as a case study, and the dry and saturated hydraulic environments alongside three softening scenarios are set. Results indicate that hydro-mechanical coupling significantly compromises face stability, elevating the limit support pressure from 140 kPa in dry mechanical state to 231 kPa. The failure mechanism transitions from localized “horn-like” shear bands in dry states to global quasi-symmetric “bulb-like” visco-plastic diffusion in saturated seepage field scenarios. Softening effects cause stress-dependent stiffness degradation, increasing the deformation rate by 53.8% under low support pressure, and inducing uneven deformation where the crown displacement increases by 32.8 times, exceeding the 11.8-fold increase at the center as the support pressure drops from 600 kPa to 100 kPa. Moreover, the fluid–solid coupling effect amplifies the stratum’s sensitivity to shear strength parameters by up to 26 times at the face center compared to the dry condition. These findings may offer theoretical insights for optimizing support pressure determination in deep-buried saturated excavations. Full article

Dense and complex underground structures impose stringent requirements on shield tunneling. In the close-proximity construction of super-large-diameter shield tunnels, challenges may arise, including adverse impacts on the normal operation of existing structures, as well as difficulties in ensuring the bearing capacity and deformation control of these structures during excavation. This study, based on the stratigraphic conditions of the Chengdu area, employs FLAC3D 7.0 version software to simulate the section where the Shuanghua Road Tunnel underpasses both Metro Line 10 and the Chengdu-Guiyang High-Speed Railway. The main conclusions are as follows: (1) Tunnel underpassing induces uneven settlement in the metro tunnel, with a maximum settlement reaching 47.7 mm. The settlement trough exhibits a twin-peak morphology during dual-line construction. When a single super-large-diameter tunnel line crosses the existing structural cluster, the maximum settlement is located directly above the crossing point. During dual-line crossing, the maximum settlement shifts towards the midpoint between the two new tunnel lines. (2) As the left line of the new tunnel approaches the existing structure, the cross-sectional deformation of the existing structure is “pulled” towards the direction of the excavated new tunnel. After the new left line moves away, the cross-sectional deformation gradually recovers to a bilaterally symmetrical state. (3) The tunnel cross-section undergoes dynamic “compression-tension” convergence changes during the construction process, with a maximum longitudinal tensile convergence of −1.28 mm. (4) During the underpassing of the existing structural cluster by the super-large-diameter tunnel, the maximum torsion angle is approximately −0.016°, occurring at the moment when the shield machine head first passes directly beneath, located directly above the new tunnel. The torsion angle of the existing structure is greatest during the first underpassing event, and the maximum torsion angle during the second underpassing is lower than that during the first. This study reveals the composite deformation mode of “settlement-convergence-torsion” during the underpassing of existing structural clusters by super-large-diameter shield tunnels, providing a theoretical basis for risk control in similar adjacent engineering projects. Full article

This paper addresses the issue of stress redistribution in surrounding soil during the construction of shallow-buried, large-section loess tunnels. Using the Luochuan Tunnel as a case study, we employ the FLAC 3D numerical simulation method to investigate the effects of advanced pipe roof support on the stability of the surrounding soil. The results demonstrate that advanced pipe umbrella reduces the stress release amplitude at the vault by 50% compared to the unsupported condition, due to a “pre-support-load bearing mechanism”, while promoting orderly stress recovery. The “longitudinal beam effect” and “transverse arch effect” of soils effectively suppress the plastic zone area of the surrounding soil from 413.3 m² (unsupported) to 95.0 m², achieving a reduction exceeding 77%. Furthermore, the pipe umbrella support facilitates the formation of a more efficient “active soil arch”, which exhibits distinct symmetrical characteristics. The arch’s stress distribution and spatial structure both follow symmetrical patterns, significantly enhancing the self-stabilizing capacity of the surrounding soil. As a result, the height of the stress release zone at the tunnel excavation face and the surrounding soil stability areas is reduced by 45.9% and 63.3%, respectively, compared to the unsupported condition. This study also establishes a Pasternak elastic foundation beam model that accounts for the spatiotemporal effects of support, elucidating the mechanism of pipe umbrella support and providing a theoretical foundation for the design and construction risk control of shallow large-section loess tunnels. Full article

This study investigates the excavation stability of vertical shafts using the Raise Boring Machine (RBM) method in karst strata with multiple cavities, based on the ventilation shaft project of the Zimuyan Tunnel along the Wudao Expressway. A three-dimensional numerical model was established using ABAQUS (version 6.14) to simulate the RBM excavation process and to analyze the effects of cavity positions and depths on the stability of the surrounding rock during excavation. The results show that (1) when the cavities are located at the same position and depth, the radial displacement of the surrounding rock during the reverse reaming stage is reduced by approximately 60% on average compared to that during the forward reaming stage, and the radial stress is also significantly lower during the reverse reaming process; (2) when the cavities are at the same depth, symmetrically distributed cavities cause the surrounding rock displacement to increase by 15–20% compared to vertically aligned cavities, and the stress distribution becomes more complex; and (3) when the cavities are at the same horizontal position but located on different planes, the stability of the surrounding rock improves as the distance between the two cavities increases. Full article

Natural rock materials, containing micro-cracks and pore defects, significantly alter their mechanical behavior. This study investigated fracture interactions of red sandstone containing double close-round holes (diameter: 10 mm; bridge angle: 30°, 45°, 60°, 90°) using acoustic emission (AE) monitoring and the discrete element simulations method (DEM), which was a novel methodology for revealing dynamic failure mechanisms. The uniaxial compression tests showed that hole geometry critically controlled failure modes: specimens with 0° bridge exhibited elastic–brittle failure with intense AE energy releases and large fractures, while 45° arrangements displayed elastic–plastic behaviors with stable AE signal responses until collapse. The quantitative AE analysis revealed that the fracture-type coefficient k had a distinct temporal clustering characteristic, demonstrating the spatiotemporal synchronization of tensile and shear crack initiation and propagation. Furthermore, numerical simulations identified a critical stress redistribution phenomenon, that axial compressive force chains concentrated along the loading axis, forming continuous longitudinal compression zones, while radial tensile dispersion dominated hole peripheries. Crucially, specimens with 45° and 90° bridges induced prominently symmetric tensile fractures (85° to horizontal direction) and shear-dominated failure near junctions. These findings can advance damage prediction in discontinuous geological media and offer direct insights for optimizing excavation sequences and support design in cavern engineering. Full article

With the rapid urbanization and increasing development of underground spaces, foundation pit groups in complex geological environments encounter considerable challenges in deformation control. These challenges are especially prominent in cases of adjacent constructions, complex geology, and environmentally sensitive areas. Nevertheless, existing research is lacking in systematic analysis of construction sequencing and the interaction mechanisms between foundation pit groups. This results in gaps in comprehending stress redistribution and optimal excavation strategies for such configurations. To address these gaps, this study integrates physical model tests and PLAXIS 3D numerical simulations to explore the Nanjing Jiangbei New District Phase II pit groups. It concentrates on deformations in segmented and adjacent configurations under varying excavation sequences and spacing conditions. Key findings reveal that simultaneous excavation in segmented pit groups optimizes deformation control through symmetrical stress relief via bilateral unloading, reducing shared diaphragm wall displacement by 18–25% compared to sequential methods. Sequential excavations induce complex soil stress redistribution from asymmetric unloading, with deep-to-shallow sequencing minimizing exterior wall deformation (≤0.12%He). For adjacent foundation pit groups, simultaneous excavation achieves minimum displacement interference, while phased construction requires prioritizing large-section excavation first to mitigate cumulative deformations through optimized stress transfer. When the spacing-to-depth ratio (B/He) is below 1, horizontal displacements of retaining structures increase by 43% due to spacing effects. This study quantifies the effects of excavation sequences and spacing configurations on pit group deformation, establishing a theoretical framework for optimizing construction strategies and enhancing retaining structure stability. The findings are highly significant for underground engineering design and construction in complex urban geological settings, especially in high-density areas with spatial and geotechnical constraints. Full article

This study explores the underground structure and soil retention capabilities of a large-scale circular diaphragm wall (93.5 m in diameter) utilized as a soil retention strategy in deep excavation projects. The symmetrical design of the wall facilitates the use of an unsupported construction method, effectively resisting soil and water pressures. Using PLAXIS 3D 2017 software, this study simulates wall deformation and ground settlement, employing three different soil models to assess behavior under standard and emergency water gushing scenarios. The results show that the hardening soil (HS) model most accurately reflects the actual deformations and settlements. This study also finds that adjusting Young’s modulus for clay significantly impacts the accuracy of soil behavior predictions, while changes in the properties of sand have minimal effects. This research highlights the challenges posed by water gushing and suggests the need for model improvements to capture better the dynamic interactions between soil and water pressure, which could lead to wall tilting. Overall, this study offers innovative and practical value, providing crucial insights for designing and mitigating strategies in large-scale circular deep excavation projects, especially in regions such as Taiwan, where such constructions are rare and face unique challenges. Full article

Rockfalls are an important factor affecting underground engineering safety. However, there has been limited progress in understanding and predicting these disasters in the past few years. Therefore, a large-scale three-dimensional experimental simulation apparatus to study failure mechanisms of rockfalls occurring during underground engineering was developed. This apparatus, measuring 4 m × 4 m × 3.3 m in size, can achieve vertical and horizontal symmetric loading. It not only simulates the structure and stress environment of a rock mass but also simulates the stepwise excavation processes involved in underground engineering. A complete simulation experiment of rockfalls in an underground engineering context was performed using this apparatus. Dynamic evolution characteristics of block displacement, temperature, natural vibration frequency, and acoustic emissions occurring during rockfalls were studied during the simulation. These data indicate there are several indicators that could be used to predict rockfalls in underground engineering contexts, leading to better prevention and control. Full article

In view of the complex asymmetric deformation characteristics of inclined coal seam roadways and the tensed shear failure of anchor cable supports, the asymmetric support scheme of an anchor cable with a C-shaped tube is proposed. In order to study its supporting effect on an inclined coal seam roadway, this paper first explores the difference in shear performance between an anchor cable with a C-shaped tube and an anchor cable through double shear tests. Then, based on the asymmetric deformation characteristics of an inclined coal seam roadway in the Pangpangta Mine, a numerical simulation is used to study the asymmetric support effect of an anchor cable with a C-shaped tube in an inclined coal seam roadway. The results of the double shear test show that the anchor cable with the C-shaped tube has stronger resistance to shear load than that of the anchor cable. Through the results of the numerical simulation, the original stress field distribution on both sides of the roadway was found to be uneven due to the influence of the coal seam dip angle, and after the excavation of the inclined coal seam roadway, the displacement and plastic zone distribution on both sides showed obvious asymmetric characteristics. Compared with the symmetric support, the asymmetric support can obviously alleviate the asymmetric deformation characteristics of the two sides and effectively control the deformation and plastic failure zone of the roadway. The anchor cable with the C-shaped tube has better resistance to shear deformation than that of the anchor cable. The anchor cable with the C-shaped tube can reduce the deformation and plastic area of the roadway more effectively. Full article

Due to their tense mining succession relationship, gob-side roadways may undergo significant deformation under multi-mining pressure. In this article, many methods, such as on-site research, a theoretical analysis, a numerical simulation and an industrial experiment, are used to research the mechanism of asymmetric floor heave in a gob-side coal roadway affected by mining pressure during the mining of extra-thick coal seams. Our main research is as follows: (1) By monitoring the floor deformation in the roadway on site, it is concluded that the roadway floor shows asymmetry, indicating that the floor displacement near the coal pillar side is relatively large. (2) Based on a lateral overburden structure model of the roadway, the calculation formulas of the horizontal vertical stress caused by the roadway excavation and the excavation of the upper working face are derived separately, and the vertical stress coupling curves on both sides of the roadway during the mining of the upper working face are obtained through a numerical simulation. It is concluded that the cause of the asymmetric floor heave in the roadway is an uneven distribution of vertical stress. (3) The numerical simulation shows a symmetrical distribution of the floor displacement curve during the roadway excavation with a max. displacement of 49.5 mm. The floor displacement curve during the mining of the upper working face is asymmetric with a max. displacement of 873 mm at a distance of 1 m from the central axis near the coal pillar side. The range of the plastic zone in the roadway gradually expands with the mining of the upper working face, and the maximum depth of floor failure is 5.5 m. (4) According to the cooperative control principle of “roof + two sides + floor”, an asymmetric floor heave joint control scheme of “floor leveling + anchor cable support + concrete hardening” is proposed. The floor deformation monitoring results indicate that the max. floor heave at the measurement point near the coal pillar in the roadway is 167 mm, and the floor heave is effectively controlled. Full article

Compared with single or twin tunnels, the pressure arch effect of deeply buried, symmetrically distributed triple tunnels are more complex and less studied. In this paper, the arching responses are in-situ measured in the deeply buried, symmetrically distributed triple tunnels of Badaling Great Wall station. Numerical research is subsequently conducted to investigate the formation and development of the pressure arch of triple tunnels. Then, the influencing law of buried depth on pressure arch behavior is systematically studied. Based on monitoring data, the rock pressure distribution is asymmetric about the axis of the triple tunnels, and the arching response of the middle tunnels is more significant than that of the left and right tunnels. According to numerical analysis, a combined large pressure arch may be easily formed across the triple tunnels. The pre-arching and double-arching effects are also numerically observed during triple tunnel excavations. The inner boundary of the pressure arch of the middle tunnel is 14.0 m, nearly two times higher than those of the left and right tunnels. This simulation result indicates that the mechanical state of the middle tunnel is the least desirable. Moreover, the critical arching depth of closely spaced tunnels is 1.75 times that of a single tunnel. Compared with a single tunnel, the support of triple tunnels should be additionally strengthened. Full article

During underground space exploitation in the urbanization process, numerous foundation pits were constructed where a diaphragm wall was often used as a retaining structure and waterproof curtain. Due to complicated engineering geological conditions or improper construction, diaphragm walls and wall joints often exhibit quality defects. Groundwater leaked from these quality defects to foundation pits during excavation, endangering the safety of the pit and surrounding facilities. The current leakage identification of the underground retaining structure was performed by artificial visual detection, which cannot satisfy the engineering requirement. The temperature field in the leakage area of the diaphragm wall was different from other areas. The leakage wall imaging system using a thermal imager was efficient in visualizing leaking, which was not visible to the naked eye. In this study, infrared thermal imaging technology was introduced in potential leakage detection for the diaphragm wall of a foundation pit. The infrared radiation characteristics of the diaphragm wall leakage and the potential leakage parts were studied through laboratory simulation tests and on-site detection methods. The maximum temperature appeared at the water outlet and the surface of the defect with hidden defect, and the temperature field was symmetrically distributed along the cross-section direction. In the potential leakage area, the temperature difference at the penetration point was 23.4 °C when the initial water pressure was 10 kPa. The temperature difference at the penetration point was 21.8 °C when the initial water pressure was 30 kPa. In the field test, the maximum temperature difference between the leakage area and the surrounding wall was 4.5 °C. The study can provide a reference for similar engineering. Full article
