Search Results (107)

This paper proposes a temperature measurement and system identification method for confined cavity explosions based on an improved type C thermocouple sensor. On the one hand, to address the extreme conditions caused by high-speed fragments and intense shock waves in an enclosed explosive environment, a thermocouple probe structure employing alloy strips of different widths with an alumina insulating layer in between is designed. By optimizing the strip width, the contact issues arising from edge-cutting burrs are effectively suppressed, thereby significantly enhancing the electrical insulation performance and overall reliability of the sensor. Additionally, a wedge-shaped alumina ceramic piece is designed to secure the thermocouple probe, further improving its structural stability under impact conditions. On the other hand, to tackle the highly nonlinear and multi-field coupled characteristics of the post-explosion temperature field, a system identification method based on the least square method is proposed. This method constructs a polynomial function in terms of radial distance and time variables, enabling effective reconstruction of the temperature field from limited measurement points. It provides a useful reference for understanding of the temperature distribution in confined cavity explosions and supports improved estimation of the temperature field. Finally, experimental results demonstrate that the improved sensor exhibits good survivability and measurement reliability under extreme explosive conditions. Meanwhile, the reconstructed temperature field model shows high fitting accuracy and good capability for describing the temperature distribution, confirming the effectiveness of the proposed identification method. Full article

Traveling wave ultrasonic motors (TWUMs) are critical components in precision systems, yet their performance is susceptible to degradation under dynamic disturbances in harsh operating environments. This paper presents a monolithic U-shaped rotor designed to intrinsically achieve quasi-zero stiffness (QZS). Unlike conventional QZS systems that rely on assembling discrete positive and negative stiffness elements, the proposed design generates the target mechanical characteristic through the tailored nonlinear response of a unified U-shaped structure, thereby improving preload stability. Through exploring the critical parameters of the rotor cross-section, the finite element method (FEM) is employed to optimize the geometry configuration and characterize the mechanical performances. The simulation results show the QZS behavior demonstrating a stable force plateau of 320 ± 10 N across a 0.7 mm displacement range. A maximum von Mises stress of 788 MPa is obtained, well within the material’s safety margin, thereby ensuring the structural integrity. Experimental tests validate the effectiveness of the proposed design. This compact, monolithic U-shaped rotor provides a robust and reliable QZS solution, demonstrating significant potential for enhancing the stability of TWUMs in applications prone to harsh environments such as wide-range temperature fluctuations, thermal cycling conditions, and shock environments. Full article

In order to study the damage characteristics of shaped charge jet to multilayer thin targets under water, the damage mechanism of shaped charge jet penetrating into multilayer thin targets underwater was analyzed by combining numerical simulation with experimental verification. By comparing the difference in penetration results between water and air, the mechanism of multi-damage element synergy in the process of penetration was revealed. The research showed that the damage ability of underwater shaped charge jet is significantly enhanced compared with that in air, and its damage process is mainly composed of shaped charge penetrator penetration, shock wave effect and cavity expansion effect. Based on the Held formula, the mathematical model of radial reaming of projectile penetrating into multilayer thin targets under water is established. An underwater damage experiment involving a shaped charge jet was conducted, and the action law of shaped charge projectile penetrating multilayer thin target under water was obtained. The numerical simulation, experimental results and mathematical model are in good agreement, which verifies the mathematical model of radial reaming of shaped charge projectile penetrating into multilayer target under water. The results of this study can provide technical support for the underwater protection of ships. Full article

Mesh-agnostic models have advantages in processing flow field data with various topologies and densities, and they can easily incorporate partial differential equations. Beyond physics-informed neural networks, mesh-agnostic models have been studied for data-driven predictions of simple flows. In this study, a data-driven mesh-agnostic model is proposed to predict the transonic flow field of various supercritical airfoils. The model consists of two subnetworks, i.e., ShapeNet and HyperNet. ShapeNet is an implicit neural representation used to predict spatial bases of the flow field. HyperNet is a simple neural network that determines the weights of these bases. The input of ShapeNet is extended to ensure accurate prediction for different airfoil geometries. To reduce overfitting while capturing shock waves and boundary layers, a multi-resolution ShapeNet combining two activation functions is proposed. Additionally, a physics-guided loss function is proposed to enhance accuracy. The proposed model is trained and tested on various supercritical airfoils under different free-stream conditions. Results show that the model can effectively utilize airfoil samples with different grid sizes and distributions, and it can accurately predict the shock wave and boundary layer velocity profile. The proposed mesh-agnostic model can be used as a decoder in any conventional models, contributing to their application in complex and three-dimensional geometries. Full article

Designing high-speed aircraft for wide-speed-range operation remains a major aerodynamic challenge. This study investigates the unsteady aerodynamics of a continuously morphing airfoil from transonic to hypersonic regimes. A smooth morphing trajectory is constructed among transonic, supersonic, and hypersonic baseline shapes, and analyzed via high-fidelity unsteady Reynolds-averaged Navier–Stokes (URANS) simulations with a radial basis function (RBF) dynamic mesh. Two processes are examined: pure geometric morphing at fixed Mach numbers (Ma), and morphing coupled with flight acceleration. Key findings reveal two distinct adaptation features: (1) Transonic flow is highly sensitive to morphing (28.8% drop in lift-to-drag ratio), while supersonic flow is robust (<5% variation). (2) During coupled acceleration, the flow transitions smoothly—the shock evolves from a detached bow wave to an attached oblique structure, and the adaptive airfoil maintains a lift-to-drag ratio above 4 across Ma = 0.8–6. Additionally, wake vorticity transitions from organized shear layers to multi-scale clusters. These results elucidate the flow physics mechanism of continuous morphing and provide a framework for designing adaptive wide-speed-range aircraft. Full article

As an active flow-control technology, the counterflowing jet can reduce drag by reconstructing the flow field structure during the re-entry of a vehicle, thereby mitigating the adverse effects of high overload on personnel. However, variations in the angle of attack (AoA) and nozzle mass flow rate tend to induce transitions in its flow field modes and fluctuations in drag reduction performance. To further investigate the aerodynamic interference characteristics of the counterflowing jet during the re-entry process, this study focused on a 2.6% subscale model of the Apollo return capsule. The Reynolds-averaged Navier–Stokes (RANS) equations turbulence model was employed to numerically analyze the effects of different mass flow rates and freestream AoAs on the flow field modes and the drag behavior. The results indicate that with an increase in AoA, the flow field structure of the long penetration mode (LPM) is likely to be destroyed, and the shock wave shape exhibits significant asymmetric distortion. In contrast, the flow field structure of the short penetration mode (SPM) remains relatively stable; however, the bow shock and Mach disk exhibit two typical offset patterns, whose offset characteristics are jointly regulated by the mass flow rate and AoA. In terms of drag characteristics, the AoA significantly weakens the drag reduction effect of the LPM. In contrast, the SPM can maintain a stable drag reduction efficiency of approximately 50% within a certain AoA range. Nevertheless, as the AoA further increases, the drag reduction effect of the SPM gradually diminishes. Full article

This work investigates how the vehicle-to-tube suspension gap governs compressible flow physics and operating margins in Hyperloop-class transport at 10 kPa. To our knowledge, this is the first study to apply adjoint aerodynamic optimization to mitigate gap-induced choking and shock formation in a full pod–tube configuration. Using a steady, pressure-based Reynolds-averaged Navier-Stokes (RANS) framework with the GEnerlaized K-Omega (GEKO) turbulence model, a simulation for the cruise conditions was performed at M = 0.5–0.7 with a mesh-verified analysis (medium grid within 0.59% of fine) to quantify gap effects on forces and wave propagation. For small gaps, the baseline pod triggers oblique shocks and a near-Kantrowitz condition with elevated drag and lift. An adjoint shape update—primarily refining the aft geometry under a thrust-equilibrium constraint—achieves 27.5% drag reduction, delays the onset of choking by ~70%, and reduces the critical gap from d/D ≈ 0.025 to ≈0.008 at M = 0.7. The optimized configuration restores a largely subcritical passage, suppressing normal-shock formation and improving gap tolerance. Because propulsive power at fixed cruise scales with drag, these aerodynamic gains directly translate into operating-power reductions while enabling smaller gaps that can relax tube-diameter and suspension mass requirements. The results provide a gap-aware optimization pathway for Hyperloop pods and a compact design rule-of-thumb to avoid choking while minimizing power. Full article

The tip leakage flow at both sides of the nozzle vane is an important factor for the reduction in turbine aerothermal performance. A strong shock wave is generated at the trailing edge of the nozzle vane under transonic condition, which can interfere with the tip leakage vortex and further aggravate the complexity of the flow field. The primary purpose of this study is to obtain a deeper understanding of the interference mechanism of shock waves on the leakage vortex. Three-dimensional Reynolds averaged Navier–Stokes calculations were performed to investigate the transonic flow fields in the nozzle vane cascade. The flow structure of the tip leakage flow, interference of the shock wave on the tip leakage vortex, and influence of the expansion ratio on the interference effect were analyzed and discussed. The authors found that the tip leakage vortex expanded and broke owing to the reverse pressure gradient under the interference of the shock wave, resulting in a significant increase in flow losses. As the expansion ratio increased, the expansion position of the tip leakage vortex shifted to the trailing edge, and the size of the tip leakage vortex significantly increased initially but remained unchanged at the vane rear part. Additionally, the schematic diagram of a model for interference between the shock wave and leakage vortex is presented to describe the shape of the shock wave and leakage vortex. The numerical results provide a better understanding of the complex flow field phenomena in variable nozzle turbines. Full article

The study focuses on the T-shaped tunnel scenario with protective doors, performs explosion tests using aluminized explosives, and investigates the propagation patterns and loading characteristics of explosion shock waves in the straight tunnel, at the T-shaped junction, and within the semi-enclosed space in front of the protective door. It was observed that, in comparison to TNT explosives, the overpressure curve of aluminized explosives in the near-explosion zone exhibited a two- batch characteristic. The second batch presented the maximum overpressure peak. In contrast, in the far zone, the curve displayed a stable triangular waveform. In the main tunnel of the T-shaped opening with protective doors, it was found that the back blast surface located in front of the entrance to the main tunnel experienced the maximum momentum, which could be as high as 12 times greater than that of the reflection area on the blast-facing surface at the entrance of the main tunnel and the shock-wave pressure wave pattern can be divided into four batch. The regularities of each measurement point in multiple tests show consistency, highlighting the influence laws of the geometric structure on the wave pattern and load distribution. In addition, this paper integrates LS-DYNA numerical simulation with aerodynamics theory to reveal that shock waves generate expansion waves and oblique shock waves as they pass through the T-shaped opening. After two reflections off the main tunnel wall and the door, a stable propagation waveform is established. In addition, through dimensional analysis and in combination with the experimental results, the momentum at key positions was analyzed and predicted. This study offers a reference for the design of relevant engineering protection measures. Full article

Although laser cavitation was discovered half a century ago, novel geometries and regimes to excite this effect have been vigorously explored during the past few decades. This research is driven by a variety of applications of laser cavitation in demanding branches of science and technology, such as microfabrication, synthesis of nanoparticles, manipulation of cells, surgery, and lithotripsy. In this work, we combine experimental studies using high-repetition-rate imaging and numerical simulations to uncover a novel regime of the laser cavitation observed upon excitation of a liquid by a train of laser pulses with the pulse energy of 140 mJ and duration of 1.2 μs delivered through a quartz optical fiber. Once the lifetime of the initial cavitation bubble (excited by the first laser pulse) is larger than the period between pulses, which is 34.3 μs, the secondary pulses in the train pass the gas in a bubble and evaporate additional liquid. This results in the formation of a cascaded cavitation bubble of larger volume and elongated shape of $4.6$ mm length compared to $3.8$ mm in case of excitation by a single laser pulse. In addition, the results of acoustic measurements confirm the presence of shock waves in the applied liquid. Finally, potential applications of the uncovered laser cavitation regime are discussed. Full article

The integration of three-dimensional inward-turning inlets with airframes has broad application prospects. This paper develops an integrated design method for the inlet forebody with a controllable incident shock wave shape, aiming at the three-dimensional inward-turning inlet with a circular entrance, and it is applied to the forebody design of a given inward-turning inlet to obtain a three-dimensional inward-turning inlet/forebody matching scheme. Numerical simulation and wind tunnel experiment were carried out to investigate the aerodynamic performance of the inlet. The results show that the inlet/forebody matching scheme successfully realizes both geometric and aerodynamic matching between the inlet and forebody, resulting in a shock-on-lip condition at the design point, with only a 2% reduction in mass flow rate. This indicates that the forebody design and matching method are highly effective. It should be noted that after the forebody matching is achieved, the overall compression effect of the inlet on the airflow is weakened, and both the Mach number and total pressure at the inlet outlet increase slightly. Full article

Family structure has long been regarded as an important determinant of household saving, yet the empirical evidence for developing economies remains limited. Using the 2018–2022 panels of the China Family Panel Studies (CFPS), a nationwide survey that follows 16,519 households across three waves, the present study investigates how family size, the elderly share, and the child share jointly shape saving behavior. A household fixed effects framework is employed to control for time-invariant heterogeneity, followed by a sequential endogeneity strategy: external-shock instruments are tested and rejected, lagged two-stage least squares implement internal instruments, and a dynamic System-GMM model is estimated to capture saving persistence. Robustness checks include province-by-year fixed effects, inverse probability weighting for attrition, balanced-panel replication, alternative variable definitions, lag structures, and sample filters. Family size raises the saving rate by 4.6 percentage points in the preferred dynamic specification (p < 0.01). The elderly ratio remains insignificant throughout, whereas the child ratio exerts a negative but model-sensitive association. A three-path mediation analysis indicates that approximately 26 percent of the total family size effect operates through scale economy savings on quasi-fixed expenses, 19 percent is offset by resource dilution pressure, and less than 1 percent flows through a precautionary saving channel linked to income volatility. These findings extend the resource dilution literature by quantifying the relative strength of competing mechanisms in a middle-income context and showing that cost-sharing economies dominate child-related dilution for most households. Policy discussion highlights the importance of public childcare subsidies and targeted credit access for rural parents, whose saving capacity is the most constrained by additional children. The study also demonstrates that fixed effects estimates of family structure can be upward-biased unless dynamic saving behavior and internal instruments are considered. Full article

Pressure relief devices are critical for the safe release of pressurized hydrogen. To address the risk of spontaneous ignition during a high-pressure release, three-dimensional (3D) numerical simulations are systematically conducted to investigate the effects of burst conditions on spontaneous ignition behavior. Eight simulation cases are considered, involving two opening processes (instantaneous and 10-step-like), three burst disk shapes (flat, conventional domed, and reverse domed), and five opening ratios (1, 0.8, 0.6, 0.4, and 0.2). The 10-step-like opening enhances jet turbulence and promotes flame merging between the boundary layer and jet front, intensifying combustion. Domed structures cause a high-velocity region behind the leading shock wave, altering jet front evolution. Compared with reverse-domed disks, flat and conventional domed disks generate stronger vortices and a larger shock-heated area, resulting in more severe combustion and elevated fire risk. As the opening ratio decreases, both shock wave strength and propagation velocity drop significantly, and spontaneous ignition does not occur. The opening ratio has minimal influence on the distance traveled by shock-induced heating. These findings offer meaningful guidance for the design and manufacture of pressure relief devices for the safe emergency release of hydrogen. Full article

Shockwaves induce considerable flow separation loss; it is essential to reduce this using the flow control method. In this manuscript, a method for suppressing flow separation in turbomachinery through a constant adverse-pressure gradient was investigated. The first-passage shock was split into a compression wave system of the vane suction surface. The aim of this was to reduce loss from shockwave/boundary layer interactions (SWBLIs). This method promotes the performance parameters of the supersonic compressor cascade. The investigation targets were a baseline cascade and the improved system. Both cascades were numerically studied with the aid of the Reynolds-averaged Navier–Stokes (RANS) method. The simulation results of the baseline cascade were also validated through experimentation, and a further physical flow analysis of the two cascades was conducted. The results show that the first-passage shockwave was a foot above the initial suction surface, with a weaker incident shock along with a clustering of the compression wave corresponding to the modified cascade. It was also concluded that the first-passage shockwave foot of the baseline cascade was replaced with a weak incident shock, and a series of compression waves emanated from the adopted negative-curvature profile. The shock-induced boundary layer separation bubble disappeared, and much smaller boundary layer shape factors over the SWBLI region were obtained for the improved cascade compared to the baseline cascade. This improvement led to a high level of stability in the boundary layer state. Sensitivity analyses were performed through different simulations on both cascades, unveiling that the loss in total pressure was lower in the case of the updated cascade as compared to the baseline. Full article

Airfoil aerodynamic design represents an essential domain in aircraft development, where the pursuit of advanced and intelligent optimization strategies is important for achieving significant advancements. In this paper, we demonstrate the effectiveness and versatility of reinforcement learning (RL)-based optimization methods in enhancing aerodynamic performance for both transonic and supersonic airfoils. We introduced a novel methodology using RL to optimize airfoil designs, leveraging ADflow as the aerodynamic solver and constructing an RL environment where Class-Shape Transformation (CST) parameters describe the airfoil geometry, transforming it into a finite state variable. Key flow field features, especially shock waves, were incorporated to guide the optimization process, enabling the RL model to iteratively improve designs based on real-time feedback from simulations. Applied to transonic airfoils, this method yielded remarkable results, including a 70.20% increase in the lift-to-drag ratio for one airfoil, with consistent improvements across various initial geometries and flight conditions. Extending to the NASA SC(2)-0404 supersonic airfoil, the optimized design achieved significant geometric changes that resulted in a 6.25% increase in the lift-to-drag ratio, with improvements ranging from 4.90% to 25.46% across different lift coefficients. These findings highlight the robustness and adaptability of RL techniques in addressing the unique challenges of both transonic and supersonic aerodynamics while maintaining structural integrity. Full article
