As the core component of ultra-precision machine tools, the manufacturing errors of aerostatic spindles are inevitable due to the limitations of machining and assembly processes, and these errors significantly affect the spindle’s static and dynamic performance. To address this issue, a force model of the unbalanced air film, considering the straightness errors of the rotor’s radial and thrust surfaces, was constructed. Unlike conventional studies that rely solely on idealized error assumptions, this research integrates actual straightness measurement data into the simulation process, enabling a more realistic and precise prediction of bearing performance. Rotors with different tolerance specifications were fabricated, and static performance simulations were carried out based on the measured geometry data. An experimental setup was built to evaluate the performance of the aerostatic spindle assembled with these rotors. The experimental results were compared with the simulation outcomes, confirming the validity of the proposed model. To further quantify the influence of straightness errors on the static characteristics of aerostatic spindles, ideal functions were used to define representative manufacturing error profiles. The results show that a barrel-shaped error on the radial bearing surface can cause a load capacity variation of up to 46.6%, and its positive effect on air film load capacity is more significant than that of taper or drum shapes. For the thrust bearing surface, a concave-shaped error can lead to a load capacity variation of up to 13.4%, and its enhancement effect is superior to those of the two taper and convex-shaped errors. The results demonstrate that the straightness errors on the radial and thrust bearing surfaces are key factors affecting the radial and axial load capacities of the spindle. Full article

In this study, the combined influence of vibration direction, feature selection strategy, and the support vector machine (SVM) kernel on the classification accuracy of unbalance faults was investigated. Experiments were carried out on a Jeffcott rotor test rig at a constant speed and under three operating conditions. The overlapping sliding window method was used for raw sample expansion. Features extracted from time domain signals and from the order and power spectra obtained in the frequency domain were ranked using the Kruskal–Wallis algorithm. Based on the feature-ranking results, the three most discriminative features for each domain–axis combination, as well as all nine most discriminative features for each axis in a hybrid manner, were fed into SVM classifiers with different kernels, and their performance was evaluated using ten-fold cross-validation. Classification using vibration signals in the vertical direction had higher accuracy rates than those using signals in the horizontal direction for the feature sets obtained in the same domains. According to the statistical results, feature set selection had a much greater impact on classification accuracy than SVM kernel choice. Power spectrum-based features allowed higher classification accuracies in all SVM algorithms compared to both the time domain features and the order spectrum-based features for detecting unbalance faults. Increasing the number of features or employing hybrid feature selection did not result in a consistent or significant enhancement in overall classification performance. Selecting the right SVM kernel shapes both the model’s flexibility and its fit to the chosen feature space; when this fit is inadequate, classification accuracy may decrease. Consequently, by selecting the appropriate vibration direction, feature set, and SVM kernel, an improvement of up to 67% in unbalance fault classification accuracy was achieved. Full article

Electric mountain bikes (eMTBs) demand compact, high-torque motors capable of handling steep terrain and variable load conditions. Surface-mounted permanent magnet synchronous motors (SPMSMs) are widely used in this application due to their simple construction, ease of manufacturing, and cost-effectiveness. However, SPMSMs inherently lack reluctance torque, limiting their torque density and performance at high speeds. While interior PMSMs (IPMSMs) can overcome this limitation via reluctance torque, they require complex rotor machining and may compromise mechanical robustness. This paper proposes a surface-inset PMSM topology as a compromise between both approaches—introducing reluctance torque while maintaining a structurally simple rotor. The proposed motor features inset magnets shaped with a tapered outer profile, allowing them to remain flush with the rotor surface. This geometric configuration eliminates the need for a retaining sleeve during high-speed operation while also enabling saliency-based torque contribution. A baseline SPMSM design is first analyzed through finite element analysis (FEA) to establish reference performance. Comparative simulations show that the proposed design achieves a 20% increase in peak torque and a 33% reduction in current density. Experimental validation confirms these findings, with the fabricated prototype achieving a torque density of 30.1 kNm/m³. The results demonstrate that reluctance-assisted torque enhancement can be achieved without compromising mechanical simplicity or manufacturability. This study provides a practical pathway for improving motor performance in eMTB systems while retaining the production advantages of surface-mounted designs. The surface-inset approach offers a scalable and cost-effective solution that bridges the gap between conventional SPMSMs and more complex IPMSMs in high-demand e-mobility applications. Full article

Microfluidics is a powerful tool with extensive applications, including chemical synthesis and biological detection. However, the limited channel size and high viscosity of samples/reagents make it difficult to fully mix liquids and improve the reaction efficiency inside microfluidic chips. Active mixing by rotors has been proven to be an effective method to promote mixing efficiency via a magnetic field. Here, we numerically investigated the mixing performance of rotors with different shapes (bar-shaped, Y-shaped, and cross-shaped). We systematically studied the influence of the arrangement of multiple cross-rotors and the rotation rate on mixing performance. The results are promising for instructing the design and manipulation of rotors for in-channel mixing. Full article

Bioinspired morphing offers a powerful route to higher aerodynamic and hydrodynamic efficiency. Birds reposition feathers, bats extend compliant membrane wings, and fish modulate fin stiffness, tailoring lift, drag, and thrust in real time. To capture these advantages, engineers are developing airfoils, rotor blades, and hydrofoils that actively change shape, reducing drag, improving maneuverability, and harvesting energy from unsteady flows. This review surveys over 296 studies, with primary emphasis on literature published between 2015 and 2025, distilling four biological archetypes—avian wing morphing, bat-wing elasticity, fish-fin compliance, and tubercled marine flippers—and tracing their translation into morphing aircraft, ornithopters, rotorcraft, unmanned aerial vehicles, and tidal or wave-energy converters. We compare experimental demonstrations and numerical simulations, identify consensus performance gains (up to 30% increase in lift-to-drag ratio, 4 dB noise reduction, and 15% boost in propulsive or power-capture efficiency), and analyze materials, actuation, control strategies, certification, and durability as the main barriers to deployment. Advances in multifunctional composites, electroactive polymers, and model-based adaptive control have moved prototypes from laboratory proof-of-concept toward field testing. Continued collaboration among biology, materials science, control engineering, and fluid dynamics is essential to unlock robust, scalable morphing technologies that meet future efficiency and sustainability targets. Full article

This study investigated the performance of Savonius hydrokinetic turbine blades through three-dimensional computational fluid dynamics simulations conducted at a fixed tip speed ratio of 0.87. A multi-factor experimental design was employed to construct 45 V-shaped rotor blade models, systematically examining the effects of a V-angle (30–140°) and straight-edge length (0.24 L–0.62 L) on hydrodynamic performance, where L = 25.46 mm (the baseline length of the straight edge). The results indicate that, as the V-angle and the straight-edge length vary independently, the performance of each blade first increases and then decreases. At TSR = 0.87, the maximum power coefficient (C_P) of 0.2345 is achieved by the blade with a 70° V-Angle and a straight edge length of 0.335 L. Pressure and velocity field analyses reveal that appropriate geometric adjustments can optimize the high-pressure zone on the advancing blade and suppress negative torque on the returning blade, thereby increasing net output. The influence mechanisms of the V-angle and straight-edge length variations on blade performance were further explored and summarized through a comparative analysis of the vorticity characteristics. This study established a detailed performance dataset, providing theoretical and empirical support for V-shaped rotor blade design studies and offering engineering guidance for the effective use of low-flow hydropower. Full article

This study examined the design and optimization of low-speed external frame motors featuring Halbach-type and olive-shaped magnet structures to improve performance in spacecraft control moment gyroscopes (CMGs). Our research was driven by the urgent need for precise, high-torque, low-speed motors in CMGs, where conventional designs, including Halbach-type and traditional radial magnet configurations, are hindered by manufacturing complexity and excessive torque pulsation. This study focused on optimizing rotor pole configurations to enhance efficiency and torque stability. An olive-shaped magnet structure provides a more uniform magnetic field distribution in the air gap, substantially reducing magnetic field harmonics and minimizing cogging torque and torque pulsation—critical performance factors for low-speed applications. Comparative analysis reveals that the olive-shaped motor achieves a peak torque of 0.312 N·m with a torque pulsation of 0.9 mN·m, maintaining an amplitude below 0.3%. This demonstrates a 20% improvement compared to the Halbach-type motor’s torque pulsation of 1.15 mN·m. Moreover, the olive-shaped motor exhibits superior stability in air-gap magnetization under different loads, ensuring high efficiency and robust operation. By streamlining magnet assembly while enhancing electromagnetic performance, this study offers a cost-effective, high-precision solution for CMG systems. These findings underscore the olive-shaped magnet motor’s potential to advance motor technology for aerospace applications. Full article

This paper proposes a high-efficiency design for an external rotor interior permanent magnet synchronous motor (IPMSM) that eliminates the magnetic leakage flux path. The conventional model based on an external rotor surface-mounted permanent magnet synchronous motor (SPMSM) is analyzed using a statistical method. Design directions are derived by comparing efficiencies at two major operating points with different motor characteristics. A V-shaped IPMSM is then proposed to increase the permanent magnet volume and reduce magnetic leakage. Design optimization is conducted using Gaussian process models (GPMs) constructed with a Latin hypercube design (LHD), and the optimal design is determined using a gradient descent algorithm. A prototype is fabricated to confirm manufacturability, and the improved efficiency of the proposed design is experimentally verified. The results demonstrate that the proposed IPMSM significantly outperforms the conventional SPMSM in terms of efficiency across both operating points. Full article

Triaxial shapes in even–even nuclei have been considered since the early days of the nuclear collective model. Although many theoretical approaches have been used over the years for their description, no effort appears to have been made for grouping them together and identifying regions on the nuclear chart where the appearance of triaxiality might be favored. In addition, over the last few years, discussion has started on the appearance of small triaxiality in nuclei considered so far as purely axial rotors. In the present work, we collect the predictions made by various theoretical approaches and show that pronounced triaxiality appears to be favored within specific stripes on the nuclear chart, with low triaxiality being present in the regions between these stripes, in agreement with parameter-free predictions made by the proxy-SU(3) approximation to the shell model, based on the Pauli principle and the short-range nature of the nucleon–nucleon interaction. The robustness of triaxiality within these stripes is supported by global calculations made in the framework of the Finite-Range Droplet Model (FRDM), which is based on completely different assumptions and possesses parameters fitted in order to reproduce fundamental nuclear properties. Full article

To mitigate the issue of high-pitch natural frequency in V-shaped floating offshore wind turbines (FOWTs), a novel semi-submersible floater design, termed NewSemi, is proposed in this study. The structural performance of the NewSemi floater is compared with that of two existing 5 MW FOWTs, namely, the V-shaped and Braceless. Frequency domain analysis demonstrates that the NewSemi floater exhibits the most favorable response amplitude operator (RAO) in the pitch direction, along with superior damping characteristics. The result reveals a 16.44% reduction in pitch natural frequency compared to the V-shaped floater. Time-domain analysis under extreme conditions reveals 14.6% and 65.2% reductions in mean surge and pitch motions compared to Braceless FOWT, demonstrating enhanced stability. In addition, compared with the V-shaped FOWT, it exhibits smaller standards and deviations in surge and pitch motion, with reductions of 11.3% and 31.9%, respectively. To accommodate the trend toward larger FOWTs, an optimization procedure for scaling up floater designs is developed in this study. Using a differential evolution algorithm, the optimization process adjusts column diameter and spacing while considering motion response and steel usage constraints. The NewSemi floater is successfully scaled from 5 MW to 10 MW, and the effects of this scaling on motion and structural dynamics are examined. Numerical analysis indicates that as turbine size increases, the motion response under extreme sea conditions decreases, while structural dynamic responses, including blade root torque, rotor thrust, tower-base-bending moment and axial force, significantly increase. The maximum values of blade root torque and tower-base-bending moment increase by 10.4 times and 3.95 times in different load cases, respectively, while the mooring forces remain stable. This study offers practical engineering guidance for the design and optimization of next-generation floating wind turbines, enhancing their performance and scalability in offshore wind energy applications. Full article

This research examines the magnet structure’s effect on the performance of permanent magnet generators. The permanent magnet generator’s cogging torque (CT) is one of the characteristics that this article examines. In an electrical machine or permanent magnet generator, CT is a characteristic that can cause unwanted phenomena like vibration and noise. The permanent magnet generator’s magnetic flux density in the core is another crucial factor affecting the machine’s efficiency. The present study introduces this parameter. This study used the finite element method for magnetics to investigate and compare the values of the tangential and normal magnetic flux densities in air gaps. Using the magnet edge slotting technique might decrease the magnetic flux density, the total magnetic flux pouring into the air gap of the permanent magnet generator, and the CT reduction. It is demonstrated that using the two processes of slotting at the magnet edge can result in improved permanent magnet generator performance. The numerical calculation software FEMM 4.2, based on the finite element method, it was used to validate the CT of the permanent magnet generators under examination. It was discovered that the cogging torque of the proposed permanent magnet generator can be significantly increased—by about 99.3%—compared to the original design of the permanent magnet generators being studied. To retrieve the power that was lost when the magnet was cut, the authors improved the convex shape next to the rotor core. This made the magnet volume bigger, similar to the magnet design in the baseline model. The cogging torque was evaluated using FEMM and contrasted with the cogging torque of the baseline model. It was determined that the cogging torque diminished by 99.2% relative to that of the baseline model. This result is marginally lower than the reduction in the cogging torque value observed without employing convex magnets, which stands at 99.3%. Full article

With the strengthening of international motor efficiency regulations, the new line-start synchronous reluctance motor (LS-SynRM), which does not require magnets or control units, is being studied to improve the efficiency of motors in industrial applications. However, the LS-SynRM features a complex structure with numerous design parameters, requiring the consideration of various factors such as electromagnetic performance, mechanical strength, starting capability, and ease of manufacturing. Additionally, starting capability analysis consumes a large amount of transient calculation time. The prototype stage typically comes after all simulation resources have been exhausted. The aim of this paper is to optimize the LS-SynRM by splitting the starting analysis and steady-state analysis, using a metamodel-based optimization method to quickly identify rotors of varying complexity (magnetic barriers and ribs) that meet steady-state efficiency and mechanical strength requirements. Finally, the rotor slot structure for starting is optimized within the magnetic barrier space. This approach significantly reduces the total optimization time from several weeks to just a few days. The final model obtained through the design process is analyzed using finite element analysis (FEA), and the results indicate that the target performance is achieved. To verify the FEA results, the final model is manufactured, and experiments are conducted. Full article

The new algorithm presented in this paper determines the multi-mode blade vibration components when the time of blade arrival is known from an experiment. The validation of the algorithm is presented in a numerical simulation, which assumes the blade vibration parameters. This shows the accuracy of the calculated vibration velocity amplitude and phase, as well as the good agreement between the calculated and assumed velocities. The accuracy of the calculations increased with the number of rotations up to N = 50. Therefore, N = 50 was used in further calculations. SO-3 engine 1st-stage compressor rotor blades were analyzed for the nominal 15,000 rpm and the non-nominal 12,130 rpm regimes using the proposed Least Squares algorithm over the tip-timing method/data collection/procedure. The 1st-stage compressor rotor blades of SO-3 engine were analyzed using tip-timing and the Least Squares algorithm for nominal 15,000 rpm and non-nominal 12,130 rpm. Two sensors in the casing and a once-per-revolution sensor below were used. The rotor blade was found to vibrate predominantly with one-mode shapes, but the second mode was also visible Full article

The shape parameters and energy spectra of the decoupled ${\mathrm{h}}_{11/2}$ bands in isotopes ${}^{99,101,103}\mathrm{Ru}$, ^{101,103,105,107}Pd and ^{101,103,105,107}Cd are analyzed using the particle-plus-rotor model and cranked shell model calculations. The quasiparticle-plus-rotor (PRM) model calculations are performed, considering both soft and rigid triaxial cores, using the constant-moment-of-inertia (CMI) and variable-moment-of-inertia (VMI) approaches. The asymmetry parameter $\gamma$ obtained from the PRM model calculations is found to be consistent with the results obtained from the cranked shell model calculations when the core exhibited CMI behavior. Full article

The focus of this paper is to seek means of increasing induction motor efficiency to a comparable level to a permanent magnet motor. Harmonic and high-frequency losses increase the rotor core and copper loss, often limiting IM efficiency. The research in this study focuses on reducing rotor core and copper losses for this purpose. An accurate finite element model of a prototype motor is developed. The accuracy of this model in predicting the performance and losses of the prototype motor is verified with experiments over a 32 Hz–125 Hz supply frequency range. The verified model of the motor is used to identify the causes of the rotor core and copper losses of the motor. It is found that the air gap flux density of the motor contains many harmonics, and the slot harmonics are dominant. The distribution of the core loss and the copper loss is investigated on the rotor side. It is discovered that up to 35% of the rotor copper losses and 90% rotor core losses occur in the regions up to 4 mm from the airgap where the harmonics penetrate. To reduce these losses, one solution is to reduce the magnitude of the air gap flux density harmonics. For this purpose, placing a sleeve to cover the slot openings is investigated. The FEA indicates that this measure reduces the harmonic magnitudes and reduces the core and bar losses. However, its effect on efficiency is observed to be limited. This is attributed to the penetration depth of flux density harmonics inside the rotor conductors. To remedy this problem, several FEA-based modifications to the rotor slot shape are investigated to place rotor bars deeper than the harmonic penetration. It is found that placing the bars further away from the rotor surface is very effective. Using a 1 mm sleeve across the stator’s open slots combined with a rotor tapered slot lip positions the bars slightly deeper than the major harmonic penetration depth, making it the optimal solution. This reduces the bar loss by 70% and increases the motor efficiency by 1%. Similar loss reduction is observed over the tested supply frequency range. Full article
