With the evolution of hydroelectric generators toward larger capacity and higher rotational speeds, the significa++nt increase in power density has rendered rotor cooling technology a critical bottleneck restricting performance enhancement. Addressing the need for feasibility verification and thermodynamic characteristic analysis of evaporative cooling applied to rotors, this study innovatively proposes an internal-cooling-based evaporative cooling architecture for rotor windings. By establishing a single-channel experimental platform for a rotor evaporative cooling system, the key parameters of the system circulation flow under varying centrifugal accelerations and thermal loads are obtained, revealing the flow mechanism of the cooling system. The experimental results demonstrate that the novel architecture has outstanding heat dissipation performance. Furthermore, the experimental findings reveal that the flow characteristics of the medium are governed by the coupled effect of centrifugal acceleration and thermal load; the flow rate decreases with increasing centrifugal acceleration and increases with rising thermal load. Centrifugal acceleration reduces frictional losses in the heating pipe, leading to a decrease in the inlet–outlet pressure difference. Through the integration of experimental data with classic formulas, this study refines the friction factor model, with the modified formula showing a discrepancy of −10% to +5% compared with the experimental results. Finally, the experiment was rerun to verify the universality of the modified friction factor. Full article

Aerospace engines ingest small particles when operating in a particulate-rich environment, such as sandstorms, atmospheric pollution, and volcanic ash clouds. These micron particles enter their cooling channels, leading to film-cooling hole blockage and thus thermal damage to turbine blades made of nickel-based single-crystal superalloy materials. This work studied the collision and deposition mechanisms between the micron particles and structure surface. A combined theoretical and numerical study was conducted to investigate the effect of deposits on particle collision and deposition. Finite element models of deposits with flat and rough surfaces were generated and analyzed for comparison. The results show that the normal restitution coefficient is much lower when a micron particle impacts a deposit compared to that of particle collisions with DD3 nickel-based single-crystal wall surfaces. The critical deposition velocity of a micron particle is much higher for particle–deposit collisions than for particle–wall collision. The critical deposition velocity decreases with the increase in particle size. When micron particles deposit on the wall surface of the structure, early-stage particle–wall collision becomes particle–deposit collision when the height of the deposits is greater than twice the particle diameter. For contact between particles and rough surface deposits, surfaces with a shorter correlation length, representing a higher density of asperities and a steeper surface, have a much longer contact time but a lower contact area. The coefficient of restitution of the particle reduces as the surface roughness of the deposits increase. The characteristic length of the roughness has little effect on the rebounding rotation velocity of the particle. Full article

Power generation is an important part of air vehicle energy management when developing long-endurance and reusable hypersonic aircraft. In order to utilize an air turbine power generation system on board, fuel-based rotating cooling has been researched to cool the turbine’s rotor blades. For fuel-cooling air turbines, each blade corresponds to a separate cooling channel. All the separate cooling channels cross together and form a distributary cavity and a confluence cavity in the center of the disk. In order to determine the flow characteristics in the distributary and confluence cavities, computational fluid dynamics (CFD) simulations using the shear–stress–transport turbulence model were carried out under the conditions of different rotating speeds and different mass flow rates. The results showed great differences between non-rotating flow and rotating flow conditions in the distributary and confluence cavities. The flow in the distributary and confluence cavities has rotational velocity, with obvious layering distribution regularity. Moreover, a high-speed rotational flow surface is formed in the confluence cavity of the original structure, due to the combined functions of centrifugal force, inertia, and the Coriolis force. Great pressure loss occurs when fluid passes through the high-speed rotational flow surface. This pressure loss increases with the increase in rotating speed and mass flow rate. Finally, four structures were compared, and an optimal structure with a separated outlet channel was identified as the best structure to eliminate this great pressure loss. Full article

This article focuses on the analysis of a direct air-cooled rotor winding of a wound field synchronous machine, the innovation of which lies in the increase in the internal cooling surface, the cooling of the winding compared to the conventional inter-pole cooling, and the development of a CHT evaluation model accordingly. Conjugate heat transfer (CHT) analysis is used to explore the cooling efficacy of a parallel-cooled hollow-conductor winding of a salient-pole rotor and to identify a cooling performance map. The use of high current densities of 15–20 Arms/mm² in directly cooled windings requires high cooling intensity, which in the case of air cooling results not only in flow velocities above 15 m/s to ensure permissible operating temperatures, but also the need for coolant distribution and heat transfer studies. The experiments and calculations are based on a non-rotating machine and a wind tunnel using the same rotor coil(s). CHT-based thermal calculations provide not only reliable results compared to experimental work and lumped parameter thermal circuits with adjusted aggregate parameters, but also insight related to pressure and cooling flow distribution, thermal loads, and cooling integration issues that are necessary for the development of high power density and reliable electrical machines. The results of the air-cooling integration show that the desired high current density is achievable at the expense of high cooling intensity, where the air velocity ranges from 15 to 30 m/s and 30 to 55 m/s, distinguishing the air velocity of the hollow conductor and bypass channel, compared to the same coil in an electric machine and a wind tunnel at the similar thermal load and limit. Since the hot spot location depends on cooling integration and cooling intensity, modeling and estimating the cooling flow is essential in the development of wound-field synchronous machines. Full article

Flow boiling heat transfer in micro-channels under hypergravity conditions is a crucial research area for developing efficient cooling systems in aerospace applications. This experimental study investigated the flow boiling heat transfer characteristics of deionized water in a tube with a 2 mm diameter under various gravitational conditions ranging from normal gravity (1 g) to hypergravity (up to 5.1 g) by employing a centrifugal rotating platform. The study systematically analyzes the effects of gravity level, vapor quality, mass flux, and heat flux on the flow boiling heat transfer coefficient (HTC) of deionized water. Experimental results reveal that hypergravity significantly influenced the HTC at a higher vapor quality with up to a 40% deviation and was less pronounced at lower values with an approximately 10% deviation. This deterioration is attributed to the complex interplay of centrifugal force, the Coriolis force, buoyancy, and the specific properties of water, leading to vapor–liquid stratification and hindering effective heat transfer. Meanwhile, critical heat flux was found to increase with increasing gravity acceleration at high vapor qualities. This enhancement is attributed to improved buoyancy effects, liquid replenishment, and altered flow patterns under hypergravity conditions. Furthermore, five existing correlations for predicting flow boiling HTCs were evaluated against the experimental data, and all the correlations showed overestimated results. The consistent over-prediction by these correlations highlights the need for modifications to better capture heat transfer mechanisms under hypergravity conditions. Full article

The market share of blade batteries is rising rapidly due to their high energy density, efficient space utilization, and low cost. Nevertheless, effective cooling solutions for blade batteries are crucial to ensure the safe operation of electric vehicles, especially in extreme high-temperature environments. This paper numerically investigates the effects of a cooling plate and the blade battery parameters on maximum battery temperature, maximum temperature difference, and cooling water pressure drop. Additionally, the energy efficiency of these solutions under various cooling demands is analyzed. The numerical results show that increasing the channel number and changing the flow direction does not significantly improve the cooling performance of the cooling plate. Moreover, the effect of cooling water temperature on the maximum temperature difference in blade batteries is negligible. Furthermore, increasing the cooling water mass flow rate and the rotational speed of the cooling fan is preferred when T_max − T_a > 6 K, while reducing the cooling water temperature is more energy-efficient when T_max − T_a < 6 K. These results are expected to offer theoretical guidance and data support for designing cooling systems for blade batteries in extreme high-temperature environments. Full article

Turbine blades for modern turbomachinery applications often exhibit complex twisted designs that aim to reduce aerodynamic losses, thereby improving the overall machine performance. This results in intricate internal cooling configurations that change their spanwise orientation with respect to the rotational axis. In the present study, the local heat transfer in a generic two-pass turbine cooling channel is investigated under engine-similar rotating conditions ($Ro=\{0\dots 0.50\}$) through the transient Thermochromic Liquid Crystal (TLC) measurement technique. Three different angles of attack ($\alpha =\{-{18.5}^{°};+8^{°};+{46.5}^{°}\}$) are investigated to emulate the heat transfer characteristics in an internal cooling channel of a real turbine blade application at different spanwise positions. A numerical approach based on steady-state Reynolds-averaged Navier–Stokes (RANS) simulations in ANSYS CFX is validated against the experimental method, showing generally good agreement and, thus, qualifying for future heat transfer predictions. Experimental and numerical data clearly demonstrate the substantial impact of the angle of attack on the local heat transfer structure, especially for the radially outward flow of the first passage, owing to the particular Coriolis force direction at each angle of attack. Furthermore, results underscore the strong influence of the rotational speed on the overall heat transfer level, with an enhancement effect for the radially outward flow (first passage) and a reduction effect for the radially inward flow (second passage). Full article

To achieve higher thermal efficiency in a gas turbine, increasing the turbine inlet temperature is necessary. The rotor blade at the first stage tolerates the highest temperature, and the serpentine internal channel located in the middle chord of the rotor blade is vital in guaranteeing the blade’s service life. Therefore, it is essential to illustrate the evolution of the rotating internal channel in a gas turbine blade. In the paper, the influence of the Coriolis force, including its mechanisms, on the conventional rotating channel are reviewed and analyzed. A way to utilize the positive heat transfer effect of the Coriolis force is proposed. Recent investigations on corresponding novel rotating channels with a channel orientation angle of 90° (called bilaterally enhanced U-channels) are illustrated. Moreover, numerical investigations about the Re effects on bilaterally enhanced smooth U-channels were carried out in the study. The results indicated that bilaterally enhanced U-channels can utilize the Coriolis force positive heat transfer effect on the leading and the trailing walls at the same time. Re and Ro are vital non-dimensional numbers that influence the performance of bilaterally enhanced U-channels. Re and Ro have an independent influence on the heat transfer performance of the bilaterally enhanced U-channel. Ro is good for the heat transfer of the bilaterally enhanced U-channel on both the leading and the trailing walls. Therefore, the bilaterally enhanced U-channel is suitable for application in the middle chord region of a turbine blade, since it can utilize the rotation effect of the rotating blade to improve the heat transfer ability of the blade and thus reduced the blade temperature. At the same Ro, Re positively affects the Nu on the leading and the trailing walls of the Coriolis-utilization rotating smooth U-channel, but plays a negligible role on Nu/Nu₀. Full article

Blowers are widely used in tasks such as ventilation, exhaust, drying, cooling, heat dissipation, or conveying medium, and they usually consume a lot of energy. There is an inevitable gap between the rotating impeller and static volute casing due to manufacturing tolerance and thermal deformation. The circulating flow in the gap has an important effect on the performance of the blower. In this study, computational fluid dynamics (CFD) was used to investigate the performance of the blower under different flow conditions and gaps, and the accuracy of the numerical simulation was verified by performance experiments. The results show that the flow separation under low flow conditions in the impeller channel can be suppressed by the circulating flow. However, the efficiency of the blower is decreased because a part of the power is used to maintain the circulating flow. Under design conditions, efficiency is reduced by 5.3~8.2%, depending on the gap sizes. Due to the increased flow rate in the impeller channel caused by the gap circulating flow, the net flow rate of the impeller under design conditions is about 12% higher than the inlet flow rate of the blower. Therefore, it leads to an increase of about 12% in impeller efficiency calculated by the net flow rate compared with the inlet flow rate. Finally, the flow field distribution on the impeller channel under different gap conditions was compared, and the effects of the gap on the blower performance were analyzed from the perspective of flow field structure. Full article

Improving the engineering properties of A356 alloy is an appealing option for the automotive industry. This study aimed at refining and redistributing Si particles and the eutectic phase by applying T6 heat treatment to a semi-solid A356 alloy, followed by severe plastic deformation (SPD). Using a cooling-slope technique, the as-cast and rheocast samples were subjected to heat treatment prior to being processed using equal-channel angular pressing (ECAP) and high-pressure torsion (HPT) at room temperature. The results show that the brittle Si particles were effectively fragmented and redistributed in the homogenous microstructure. The grain size reduced from 170 μm to 23 μm in the as-cast sample after combining heat treatment and the cooling-slope. This was followed by the ECAP sample after six passes through route A (where the sample is not rotated between each pass), while it reduced to 160 nm after five turns of the HPT process in a heat-treated cooling-slope sample. The hardness of the heat-treated cooling-slope casting samples increased with the ECAP process; there was an increase from 61 HV to 134 HV for the as-cast alloy after six passes through route A. The hardness of the heat-treated cooling-slope sample improved with the HPT process to 211 HV after five turns. Full article

For the problem of power generation turbine blade ablation in hypersonic vehicles, hydrocarbon fuel carried by the vehicle is used to cool the turbine blades. In order to fully utilize the cooling capacity of hydrocarbon fuel, the structure of the cooling channels needs to be optimized. In this study, a variable clearance hydrocarbon fuel cooling channel is applied for the first time to the rotating turbine blades of a hypersonic vehicle to enhance the heat transfer ability of hydrocarbon fuel. The effect of clearance size on the heat transfer performance of hydrocarbon fuel under rotating conditions is investigated. The accuracy of the calculations is verified by comparison with experimental data. The results of the study show that the heat transfer performance can be significantly improved by changing the clearance of the turning section. The clearance size 2.5 D channel has the highest thermal performance with a maximum improvement of 1.8 times. The law of change of thermal performance is affected by crossing the critical temperature point, as it is different before and after the crossing. Thermal performance changes from decreasing then increasing to increasing then decreasing as the clearance size increases for high rotation speed conditions as the temperature of the entrance straddles the critical temperature. The Nusselt number first increases and then decreases for all channels with different clearance sizes with an increasing rotational speed. The friction factor changes from first increasing and then decreasing to decreasing and then increasing as the clearance size increases for high rotation speed conditions as the temperature of the entrance straddles the critical temperature. Full article

Ram air turbines are used in the power generation systems of hypersonic vehicles, which can address the problem of the high power consumption of weapon systems. However, high incoming air temperatures can cause the turbine blades of power generation to ablate. At this point, the incoming air can no longer be used as a cooling source to cool the turbine blades. To prevent the ablation of the turbine blades of the hypersonic vehicle power generation, hydrocarbon fuel carried by the hypersonic vehicle itself is used to cool the turbine blades. Hence, hydrocarbon fuels under rotating conditions are investigated. The results show that the rotation leads to a strong pressure gradient that causes the density and dynamic viscosity of hydrocarbon fuel to increase dramatically. Compared to the static condition, the density and dynamic viscosity of the hydrocarbon fuel increase by a maximum of 65.1% and 405%, respectively, under the rotating condition. This leads to an obvious reduction in velocity. The comprehensive influence of the physical properties of the fuel, centrifugal force, and Coriolis force causes the convective heat transfer coefficient and Nusselt number of the channel to first increase and then decrease with the increase in the rotational speed. Compared to the static condition, the convective heat transfer coefficient and Nusselt number increase by a maximum of 69.7% and 45.6%, respectively, under the rotating condition. The critical rotational speed of the Nusselt number from rise to fall is 20,000 rpm for different inlet temperature conditions. Full article

Herein, 50 articles published over the past 20 years on using large eddy simulation (LES) for the internal cooling passage of a gas turbine, especially the mid-chord ribbed channel, are reviewed for the first time. First, the numerical challenges of performing LES on a ribbed channel and experimental verification are summarized. Next, LES data and the major engineering findings that are difficult to obtain experimentally or using Reynolds-averaged Navier–Stokes simulation (RANS) are covered, and heat transfer on and inside the rib, and the effects of rotation and buoyancy are discussed. Next, recent LES studies related to the shape of the ribbed channel are reviewed, and finally, the contribution of using LES for research on the internal cooling of gas turbines in the future, including those with ribbed channels, is anticipated. Full article

Considered are: (i) separation of gaseous molecules of different weight by the Ultra Centrifuge with application to large scale uranium enrichment to fuel nuclear power plants; (ii) separation of micron-sized particulate matter from fluids in mechanical devices in which use is made of inertial and centrifugal forces; (iii) separation of gaseous mixtures by fast expansion and cooling such that one of the gaseous components forms a mist of micron-sized droplets which are separated by centrifugation; and (iv) separation of components from gases by absorbing liquid films in small sized rotating channels. For each of these technologies we consider: physics of the separation process, assessment of the influence of fluid flow in the separation device, identification of leading parameters and their effect on design, experimental evidence, status of development, areas of application, position compared to other technologies, and economic value. Full article

In this study, a lightweight fiber-reinforced plastic (FRP) helical gear was fabricated to investigate the potential application of FRP in automobile parts that require high loads and reduced noise. High-performance aramid FRP processed using the wet-laid method was used in the tooth region, and SCR420 steel was used in the inner hub region. A hot-forming system that combines rapid induction heating and water channel cooling methods was developed to reduce the cycle time. The cooling water flow conditions were analyzed to precisely control the mold temperature. Additionally, a rotating extraction system was developed to mitigate the extraction difficulty owing to the helix angle to the extraction direction. Using the innovative hot-forming system developed in this study, a helical gear without any process-induced defects was fabricated with a significantly reduced cycle time. The performance of the gear was successfully estimated using gear durability, torsional strength, and motion noise tests. The use of FRP materials offers significant potential to realize lightweight components; however, certain challenges related to their properties that may limit their application must be addressed on a case-by-case basis. Full article
