Search Results (36)

The optical remote sensors carried by the Jilin-1 KF02 series satellites have an imaging resolution better than 0.5 m and a width of 150 km. There are radiometric problems, such as stripe noise, vignetting, and inter-slice chromatic aberration, in their raw images. In this paper, a relative radiometric correction method based on temperature normalization is proposed for the response characteristics of sensors and the structural characteristics of optical splicing of Jilin-1 KF02 series satellites cameras. Firstly, a model of temperature effect on sensor output is established to correct the variation of sensor response output digital number (DN) caused by temperature variation during imaging process, and the image is normalized to a uniform temperature reference. Then, the horizontal stripe noise of the image is eliminated by using the sensor scan line and dark pixel information, and the vertical stripe noise of the image is eliminated by using the method of on-orbit histogram statistics. Finally, the method of superposition compensation is used to correct the vignetting area at the edge of the image due to the lack of energy information received by the sensor so as to ensure the consistency of the image in color and image quality. The proposed method is verified by Jilin-1 KF02A on-orbit images. Experimental results show that the image response is uniform, the color is consistent, the average Streak Metrics (SM) is better than 0.1%, Root-Mean-Square Deviation of the Mean Line (RA) and Generalized Noise (GN) are better than 2%, Relative Average Spectral Error (RASE) and Relative Average Spectral Error (ERGAS) are greatly improved, which are better than 5% and 13, respectively, and the relative radiation quality is obviously improved after relative radiation correction. Full article

Detecting and characterizing continuous changes on Earth’s surface has become critical for planning and development. Since 2016, Planet Labs has launched hundreds of nanosatellites, known as Doves. Despite the advantages of their high spatial and temporal resolution, these nanosatellites’ images still present inconsistencies in radiometric resolution, limiting their broader usability. To address this issue, a model for radiometric normalization of PlanetScope (PS) images was developed using Multispectral Instrument/Sentinel-2 (MSI/S2) sensor images as a reference. An extensive database was compiled, including images from all available versions of the PS sensor (e.g., PS2, PSB.SD, and PS2.SD) from 2017 to 2022, along with data from various weather stations. The sampling process was carried out for each band using two methods: Conditioned Latin Hypercube Sampling (cLHS) and statistical visualization. Five machine learning algorithms were then applied, incorporating both linear and nonlinear models based on rules and decision trees: Multiple Linear Regression (MLR), Model Averaged Neural Network (avNNet), Random Forest (RF), k-Nearest Neighbors (KKNN), and Support Vector Machine with Radial Basis Function (SVM-RBF). A rigorous covariate selection process was performed for model application, and the models’ performance was evaluated using the following statistical indices: Root Mean Squared Error (RMSE), Mean Absolute Error (MAE), Lin’s Concordance Correlation Coefficient (CCC), and Coefficient of Determination (R²). Additionally, Kruskal–Wallis and Dunn tests were applied during model selection to identify the best-performing model. The results indicated that the RF model provided the best fit across all PS sensor bands, with more accurate results in the longer wavelength bands (Band 3 and Band 4). The models achieved RMSE reflectance values of approximately 0.02 and 0.03 in these bands, with R² and CCC ranging from 0.77 to 0.90 and 0.87 to 0.94, respectively. In summary, this study makes a significant contribution to optimizing the use of PS sensor images for various applications by offering a detailed and robust approach to radiometric normalization. These findings have important implications for the efficient monitoring of surface changes on Earth, potentially enhancing the practical and scientific use of these datasets. Full article

Relative radiometric normalization (RRN) is a critical pre-processing step that enables accurate comparisons of multitemporal remote-sensing (RS) images through unsupervised change detection. Although existing RRN methods generally have promising results in most cases, their effectiveness depends on specific conditions, especially in scenarios with land cover/land use (LULC) in image pairs in different locations. These methods often overlook these complexities, potentially introducing biases to RRN results, mainly because of the use of spatially aligned pseudo-invariant features (PIFs) for modeling. To address this, we introduce a location-independent RRN (LIRRN) method in this study that can automatically identify non-spatially matched PIFs based on brightness characteristics. Additionally, as a fast and coregistration-free model, LIRRN complements keypoint-based RRN for more accurate results in applications where coregistration is crucial. The LIRRN process starts with segmenting reference and subject images into dark, gray, and bright zones using the multi-Otsu threshold technique. PIFs are then efficiently extracted from each zone using nearest-distance-based image content matching without any spatial constraints. These PIFs construct a linear model during subject–image calibration on a band-by-band basis. The performance evaluation involved tests on five registered/unregistered bitemporal satellite images, comparing results from three conventional methods: histogram matching (HM), blockwise KAZE, and keypoint-based RRN algorithms. Experimental results consistently demonstrated LIRRN’s superior performance, particularly in handling unregistered datasets. LIRRN also exhibited faster execution times than blockwise KAZE and keypoint-based approaches while yielding results comparable to those of HM in estimating normalization coefficients. Combining LIRRN and keypoint-based RRN models resulted in even more accurate and reliable results, albeit with a slight lengthening of the computational time. To investigate and further develop LIRRN, its code, and some sample datasets are available at link in Data Availability Statement. Full article

The Ice Pathfinder satellite (code: BNU-1) is the first Chinese microsatellite, designed for monitoring polar climate and environmental changes. The major payload of BNU-1 is the wide-field camera which provides multispectral satellite images with a 73.69 m spatial resolution and a 739 km swath width. However, the color misrepresentation issue can be observed as the BUN-1 image appears yellowish as it gets farther towards the center field of view (FOV). The blue band of the image appears to be higher near the center FOV and declines generously towards both the edge areas of the image, which may cause the color misrepresentation issue. In this study, we develop a relative sensor normalization method to reduce the radiance errors of the blue band of BNU-1 images. This method uses the radiometric probability density distribution of the BNU-1 panchromatic band as a reference, correcting the probability density distribution of the blue band radiance first. Then, the mean adjustment is used to correct the mean of the blue band radiance after probability density function (PDF) correction, obtaining the corrected radiance in the blue band. Comparisons with the ground measurements and the Landsat8 image reveal the following: (1) The radiances of snow surfaces also have good consistency with ground observations and Landsat-8 images in the red, green, and blue bands. (2) The radiance errors of the uncorrected BNU-1 images are eliminated. The RMSE decreases from 80.30 to 32.54 W/m²/μm/sr. All these results indicate that the on-orbit relative correction method proposed in this study can effectively reduce the radiance errors of the BNU-1 images. Full article

Two MODIS sensors onboard the Terra and Aqua spacecraft have been successfully operating for over twenty-three and twenty-one years, respectively, providing the worldwide user community with high-quality imagery and radiometric Earth observations of the land, atmosphere, cryosphere, and oceans. This study provides an assessment of the radiometric calibration stability and consistency of Terra and Aqua MODIS RSB using the L1B from the upcoming Collection 7 release. Several independent vicarious approaches based on measurements from the Libya-4 desert, Dome C, DCC, and SNO are used to assess the calibration stability at the beginning of scan, nadir, and end of scan. Results indicate that both Terra and Aqua RSB are stable to within 1% over their mission periods. Comparison of the normalized reflectances with either a BRDF model or a common reference sensor provides a radiometric assessment of Terra and Aqua calibration consistency. Comparison results show the VIS/NIR bands are in good agreement around the nadir and at the beginning of the scan for all the approaches. For cases at the end of the scan, the agreement varies depending on the approach but is typically within ±2%. The differences observed in the SWIR bands are slightly larger than the VIS/NIR bands, which are likely due to their high sensitivity to atmospheric conditions and relatively larger electronic crosstalk impact on the Terra instrument. Full article

The objects presented in synthetic-aperture radar (SAR) images are the products of the joint actions of ground objects and SAR sensors in specific geospatial contexts. With the accumulation of massive time-domain SAR data, scholars have the opportunity to better understand ground-object targets and sensor systems, providing some useful feedback for SAR-data processing. Aiming at normalized and low-cost SAR radiometric monitoring, this paper proposes a new hyper-pixel concept for handling multi-pixel ensembles of semantic ground targets. The special hyper-pixel in this study refers to low-rise single-family residential areas, and its radiation reference is highly stable in the time domain when the other dimensions are fixed. The stability of its radiometric data can reach the level of 0.3 dB (1$\sigma$), as verified by the multi-temporal data from Sentinel-1. A comparison with tropical-rainforest data verified its availability for SAR radiometric monitoring, and possible radiation variations and radiation-intensity shifts in the Sentinel-1B SAR products ere experimentally monitored. In this paper, the effects of seasonal climate and of the relative geometrical states observed on the intensity of the hyper-pixel’s radiation are investigated. This paper proposes a novel hyper-pixel concept for processing and interpreting SAR-image data. The proposed residential hyper-pixel is shown to be useful in multi-temporal-data observations for normalized radiometric monitoring and has the potential to be used for cross-calibration, in addition to other applications. Full article

The Polarization CrossFire (PCF) suite onboard the Chinese GaoFen-5(02) satellite has been sophisticatedly composed by the Particulate Observing Scanning Polarimeter (POSP) and the Directional Polarimetric Camera (DPC). Among them, DPC is a multi-angle sequential measurement polarization imager, while POSP is a cross-track scanning simultaneous polarimeter with corresponding radiometric and polarimetric calibrators, which can theoretically be used for cross comparison and calibration with DPC. After the data preprocessing of these two sensors, we first select local homogeneous cluster scenes by calculating the local variance-to-mean ratio in DPC’s Level 1 product projection grids to reduce the influence of scale differences and geometry misalignment between DPC and POSP. Then, taking the observation results after POSP data quality assurance as the abscissa and taking the DPC observation results under the same wavelength band and geometric conditions as the same ordinate, a two-dimensional radiation/polarization feature space is established. Results show that the normalized top of the atmosphere (TOA) radiances of DPC and POSP processed data at the nadir are linearly correlated. The normalized TOA radiance root mean square errors (RMSEs) look reasonable in all common bands. The DPC and POSP normalized radiance ratios in different viewing zenith angle ranges at different times reveal the temporal drift of the DPC relative radiation response. The RMSEs, mean absolute errors (MAEs), relative errors (REs), and scatter percentage of DPC degree of linear polarization (DoLP) falling within the expected error (EE = ±0.02) of POSP measured DoLP are better than 0.012, 0.009, 0.066, and 91%, respectively. Full article

As sensor parameters and atmospheric conditions create uncertainties for at−sensor radiation detection, radiometric consistency among satellite images is difficult to achieve. Relative radiometric normalization is a method that can improve multi−image consistency with accurate pseudo−invariant features (PIFs), especially over large areas or long time series satellite images. Although there are algorithms that manually or automatically select PIFs, the spatial mismatch of satellite images can affect PIF extraction, particularly with artificial pixels. To alleviate this problem, we proposed to use Landsat−8 OLI as the reference image and Sentinel−2A as the subject image, to apply pseudo−invariant features−based algorithms with polygon features through the single−band and multiple−band regression. Compared to pseudo−invariant point features, hyperspectral library, and histogram matching approaches, the results demonstrate the superiority of the proposed algorithms with correlation coefficients of 0.9948 and 0.9945, and an RMSE of 0.0097 and 0.0095 with multiple− and single−band regression, respectively. We also found more accurate linear fitting and better shape matching through band scattering and reflectance frequency analysis. The proposed algorithms are a significant improvement in radiometric normalization, within artificial pixels, achieving spectral signature consistency. Full article

Accurate and continuous monitoring of crop growth is vital for the development of precision agriculture. Unmanned aerial vehicle (UAV) and satellite platforms have considerable complementarity in high spatial resolution (centimeter-scale) and fixed revisit cycle. It is meaningful to optimize the cross-platform synergy for agricultural applications. Considering the characteristics of UAV and satellite platforms, a spatio-temporal fusion (STF) framework of UAV and satellite imagery is developed. It includes registration, radiometric normalization, preliminary fusion, and reflectance reconstruction. The proposed STF framework significantly improves the fusion accuracy with both better quantitative metrics and visualized results compared with four existing STF methods with different fusion strategies. Especially for the prediction of object boundary and spatial texture, the absolute values of Robert’s edge (EDGE) and local binary pattern (LBP) decreased by a maximum of more than 0.25 and 0.10, respectively, compared with the spatial and temporal adaptive reflectance fusion model (STARFM). Moreover, the STF framework enhances the temporal resolution to daily, although the satellite imagery is discontinuous. Further, its application potential for winter wheat growth monitoring is explored. The daily synthetic imagery with UAV spatial resolution describes the seasonal dynamics of winter wheat well. The synthetic Normalized Difference Vegetation Index (NDVI) and Enhanced Vegetation Index 2 (EVI2) are consistent with the observations. However, the error in NDVI and EVI2 at boundary changes is relatively large, which needs further exploration. This research provides an STF framework to generate very dense and high-spatial-resolution remote sensing data at a low cost. It not only contributes to precision agriculture applications, but also is valuable for land-surface dynamic monitoring. Full article

The knowledge of the solar irradiation components is required by most solar applications. When only the global horizontal irradiance is measured, this one is typically broken down into its fundamental components, beam and diffuse, by applying an empirical separation model. This study proposes a semi-analytical model for diffuse fraction, defined as the ratio of diffuse to global solar irradiance. Starting from basic knowledge, a general equation for diffuse fraction is derived. Clearness index, relative sunshine, and the clear-sky atmospheric transmittance are highlighted as robust predictors. Thus, the model equation implicitly provides hints for developing accurate empirical separation models. The proposed equation is quasi-universal, allowing for temporal (from 1-min to 1-day) and spatial (site specificity) customization. As a proof of theory, the separation quality is discussed in detail on the basis of radiometric data retrieved from Baseline Surface Radiation Network (BSRN), station Magurele, Romania. For temperate continental climate, overall results show for the diffuse fraction estimation a maximum possible accuracy around 7%, measured in terms of normalized root mean square error. One of the many options of implementing the semi-analytical model is illustrated in a case study. Full article

Relative radiometric normalization (RRN) is important for pre-processing and analyzing multitemporal remote sensing (RS) images. Multitemporal RS images usually include different land use/land cover (LULC) types; therefore, considering an identical linear relationship during RRN modeling may result in potential errors in the RRN results. To resolve this issue, we proposed a new automatic RRN technique that efficiently selects the clustered pseudo-invariant features (PIFs) through a coarse-to-fine strategy and uses them in a fusion-based RRN modeling approach. In the coarse stage, an efficient difference index was first generated from the down-sampled reference and target images by combining the spectral correlation, spectral angle mapper (SAM), and Chebyshev distance. This index was then categorized into three groups of changed, unchanged, and uncertain classes using a fast multiple thresholding technique. In the fine stage, the subject image was first segmented into different clusters by the histogram-based fuzzy c-means (HFCM) algorithm. The optimal PIFs were then selected from unchanged and uncertain regions using each cluster’s bivariate joint distribution analysis. In the RRN modeling step, two normalized subject images were first produced using the robust linear regression (RLR) and cluster-wise-RLR (CRLR) methods based on the clustered PIFs. Finally, the normalized images were fused using the Choquet fuzzy integral fusion strategy for overwhelming the discontinuity between clusters in the final results and keeping the radiometric rectification optimal. Several experiments were implemented on four different bi-temporal satellite images and a simulated dataset to demonstrate the efficiency of the proposed method. The results showed that the proposed method yielded superior RRN results and outperformed other considered well-known RRN algorithms in terms of both accuracy level and execution time. Full article

Multitemporal very-high-resolution (VHR) satellite images are used as core data in the field of remote sensing because they express the topography and features of the region of interest in detail. However, geometric misalignment and radiometric dissimilarity occur when acquiring multitemporal VHR satellite images owing to external environmental factors, and these errors cause various inaccuracies, thereby hindering the effective use of multitemporal VHR satellite images. Such errors can be minimized by applying preprocessing methods such as image registration and relative radiometric normalization (RRN). However, as the data used in image registration and RRN differ, data consistency and computational efficiency are impaired, particularly when processing large amounts of data, such as a large volume of multitemporal VHR satellite images. To resolve these issues, we proposed an integrated preprocessing method by extracting pseudo-invariant features (PIFs), used for RRN, based on the conjugate points (CPs) extracted for image registration. To this end, the image registration was performed using CPs extracted using the speeded-up robust feature algorithm. Then, PIFs were extracted based on the CPs by removing vegetation areas followed by application of the region growing algorithm. Experiments were conducted on two sites constructed under different acquisition conditions to confirm the robustness of the proposed method. Various analyses based on visual and quantitative evaluation of the experimental results were performed from geometric and radiometric perspectives. The results evidence the successful integration of the image registration and RRN preprocessing steps by achieving a reasonable and stable performance. Full article

As the number of cross-sensor images increases continuously, the surface reflectance of these images is inconsistent at the same ground objects due to different revisit periods and swaths. The surface reflectance consistency between cross-sensor images determines the accuracy of change detection, classification, and land surface parameter inversion, which is the most widespread application. We proposed a relative radiometric normalization (RRN) method to improve the surface reflectance consistency based on the change detection and chi-square test. The main contribution was that a novel chi-square test automatically extracts the stably unchanged samples between the reference and subject images from the unchanged regions detected by the change-detection method. We used the cross-senor optical images of Gaofen-1 and Gaofen-2 to test this method and four metrics to quantitatively evaluate the RRN performance, including the Root Mean Square Error (RMSE), spectral angle cosine, structural similarity, and CIEDE2000 color difference. Four metrics demonstrate the effectiveness of our proposed RRN method, especially the reduced percentage of RMSE after normalization was more than 80%. Comparing the radiometric differences of five ground features, the surface reflectance curve of two Gaofen images showed more minor differences after normalization, and the RMSE was smaller than 50 with the reduced percentages of about 50–80%. Moreover, the unchanged feature regions are detected by the change-detection method from the bitemporal Sentinel-2 images, which can be used for RRN without detecting changes in subject images. In addition, extracting samples with the chi-square test can effectively improve the surface reflectance consistency. Full article

Fengyun-4A (FY-4A) is the first satellite of the Chinese second-generation geostationary orbit meteorological satellites (FY-4). The Advanced Geostationary Radiation Imager (AGRI), onboard FY-4A does not load with high-precision calibration facility in visible and near infrared (VNIR) channel. As a consequence, it is necessary to comprehensively evaluate its radiometric performance and quantitatively describe the attenuation while using its VNIR data. In this paper, the radiometric performance at VNIR channels of FY-4A/AGRI is evaluated based on Aqua/MODIS data using the deep convective cloud (DCC) target. In order to reduce the influence of view angle and spectral response difference, the bi-directional reflectance distribution function (BRDF) correction and spectral matching have been performed. The evaluation result shows the radiometric performance of FY-4A/AGRI: (1) is less stable and with obvious fluctuations; (2) has a lower radiation level because of 24.99% lower compared with Aqua/MODIS; 3) has a high attenuation with 9.11% total attenuation over 2 years and 4.0% average annual attenuation rate. After the evaluation, relative radiometric normalization between AGRI and MODIS in VNIR channel is performed and the procedure is proved effective. This paper proposed a more reliable reference for the quantitative applications of FY-4A data. Full article
