Electromagnetic interference (EMI) shielding is essential in modern electronics, telecommunications, and aerospace systems. Graphite-based materials are promising shielding candidates due to their tunable electrical conductivity, low density, corrosion resistance, and thermal stability. However, numerical studies investigating the combined effects of conductivity and thickness on shielding effectiveness (SE) across the X-band remain limited. This study presents a parametric finite element analysis of EMI shielding performance for graphite materials with electrical conductivities of 1, 10, 100, 1000, and 3000 S/m, representing structures ranging from highly porous to dense graphite. Thicknesses from 1 to 10 mm are simulated in a WR90 rectangular waveguide using finite element simulations. The Transition Boundary Condition (TBC) is employed to efficiently model conductive slabs without resolving the skin depth via volumetric meshing. Shielding effectiveness is evaluated from S-parameters and decomposed into total (SET), absorption (SEA), and reflection (SER) components. Results show that SET increases with both conductivity and thickness, and that shielding behavior is strongly dependent on conductivity. Low-conductivity graphite (σ = 1 S/m) exhibits absorption-dominated shielding, reaching an absorbed power fraction of 89% at 5 mm thickness. At σ = 10 S/m, the material enters a transitional regime where absorption and reflection contribute comparably. For highly conductive graphite (σ ≥ 100 S/m), reflection becomes dominant, with the reflected power fraction approaching 0.97 at σ = 3000 S/m. A conductivity-dependent saturation thickness is identified, beyond which additional thickness provides negligible shielding improvement. Dense graphite materials (σ ≥ 1000 S/m) reach saturation at approximately 1 mm thickness. Finally, a conductivity–thickness design heatmap is developed to guide the optimization of graphite-based EMI shielding materials. Full article

A novel microwave biosensor operating in the C-band is developed and characterised for enhanced glucose sensing applications. The sensor is based on a single metamaterial asymmetric split-ring resonator (SASR) and has been investigated in two configurations: a single semi-circular design (SASR-S) and a double semi-circular design (SASR-D). The structural modifications were introduced to enlarge the sensing area by creating two high-field hotspots, thereby increasing the interaction between the electromagnetic (EM) field and the sample, which consequently enhances the overall sensor sensitivity. The sensor is fabricated on a Rogers AD350A substrate and is optimised to detect glucose levels in a 1 µL solution applied within each semi-circle sensing region. To characterise the sensor’s enhanced sensitivity, we performed a 3D electromagnetic simulation of a small droplet positioned within a semicircular sensing region, varying the relative permittivity of the droplet from 45 to 65. The resulting shifts in resonant frequency served as a primary indicator of dielectric sensitivity. The sensor’s response was experimentally validated using a vector network analyser to measure the transmission coefficient (S₂₁) of samples with no glucose and at glucose concentrations of 97 mg/dL to 286 mg/dL. The results demonstrate that the resonator configuration strongly influences the resonance frequency shift and sensitivity, with the SASR-D configuration being the most effective design. This has also been confirmed by measurements demonstrating a sensitivity of approximately 2.4 MHz/(mg/dL), representing an approximately two-fold improvement over the SASR-S sensor (sensitivity: 1.27 MHz/(mg/dL)) and a notable enhancement over previously reported sensors. These findings demonstrate the practical potential of the proposed sensor for blood glucose monitoring applications. Full article

We present FilterForge, a chat-driven VS Code environment that pulls the synthesis, analysis, simulation, and optimization stages of microwave bandpass filter design, normally coordinated by hand across tools written in different languages, into one workflow. A deployed Model Context Protocol (MCP) server exposes deterministic Python implementations of coupling-matrix synthesis, uniform predistortion, topology reconfiguration, a genetic-algorithm transmission-zero selector, a mode-matching engine for H-plane iris-coupled rectangular waveguide geometries, and a skill that generates PyAEDT/HFSS notebooks for various dimensioning design-curves. A language-model orchestrator turns natural-language requests into typed tool calls, while every reported quantity stays inside the deterministic kernels, so the numerics remain reproducible and model-agnostic. We evaluate the call layer on a 45-task benchmark across the five tool categories: gemini-3-flash reaches $96.3\%$ tool-selection and $94.8\%$ full-call accuracy with an $88.9\%$ pass³ rate, which an ablation traces to the curated tool-selection prompt rather than to raw model capability. The mode-matching engine is validated against full-wave HFSS on a six-pole 4 GHz Chebyshev filter tuned from the chat panel, and on an 8 GHz WR-112 counterpart taken end-to-end with no engineer in the loop, where a deterministic critique gates each round until a manufacturable geometry is reached. We then exercise the full workflow on two folded six-pole WR-90 cross-coupled filters at $10\mathrm{GHz}$, a high-selectivity design synthesized against a stop-band mask and a group-delay-equalized variant whose positive cross-coupling uses a pair of side-wall irises, the latter settling to a peak-to-peak in-band group-delay ripple below $1.5\mathrm{ns}$ while recovering the synthesized return loss. Full article

A compact, low-profile dual-band feed network operating at 37–40 GHz (Ka-band) and 70–86 GHz (E-band) is presented for millimeter-wave backhaul applications. The proposed network integrates a quad-ridged orthomode transducer (OMT) and four ridge-waveguide diplexers into a three-layer all-metal stacked architecture, eliminating the cascaded inter-stage flanges of conventional feed chains and yielding a monolithic-like assembly that is mechanically robust and CNC-friendly for mass production. Stepped-impedance matching stubs in the OMT junction provide broadband matching across the widely separated bands, while compact ridge-waveguide T-junction diplexers, comprising stepped-impedance low-pass filters and rectangular high-pass paths, perform the spectral separation. Back-to-back measurements of the fabricated prototype demonstrate an insertion loss below 0.6 dB across both bands. The measured VSWR at the four output ports remains below 1.5 across both bands, and the port-to-port isolation exceeds 32 dB at the Ka-band and 45 dB at the E-band. The proposed network thus offers a highly integrated, low-loss solution for next-generation dual-band mmWave links. Full article

The practical implementation of terahertz technologies is hindered by the lack of universal, low-loss waveguide platforms that deliver guided mode accessibility and multifunctional integration. The two-wire plasmonic waveguide offers a promising path toward cost-effective terahertz systems. However, waveguide circuits based on this platform still suffer from high insertion loss and limitations in coupling with other platforms. Herein, to overcome these fundamental bottlenecks, we propose novel two-wire plasmonic waveguide designs that introduce an additional degree of freedom for manipulating the guided wave. We propose waveguides with elliptical wire cross-sections and demonstrate two optimal configurations, i.e., one for minimal transmission loss (1.21 m⁻¹) and another for a high-power coupling coefficient with rectangular waveguides at 140 GHz. Improvements in these designs over conventional cylindrical wire ones have been experimentally validated. Subsequently, we propose tapered two-wire waveguide components with gradually varying cross-sections to enable seamless integration between distinct waveguide designs, thereby permitting decoupled optimization of individual functional elements in waveguide circuits. A low-loss three-segment two-wire circuit configuration for interfacing with rectangular waveguides is demonstrated. We believe that the proposed customized wire profiles open prospects for tailoring terahertz guided waves with ease and flexibility, and their integration into plasmonic circuits facilitates global optimization of multiple functionalities, thereby offering a promising path toward practical, versatile terahertz systems, pending further optimization of coupling interfaces and fabrication processes. Full article

Rectangular waveguides, serving as a standardized versatile platform for manipulating terahertz radiation within controlled environments, have been extensively employed across a broad range of terahertz systems. However, conventional fabrication methods encounter significant challenges in realizing such submillimeter-scale structures within a monolithic integration, particularly when subwavelength features or intricate geometries are incorporated for advanced functionalities. In this work, we propose a fabrication route integrating stereolithography 3D printing and electroless plating, and demonstrate its broad applicability, intrinsic benefits and limitations through the realization of various high-performance D-band terahertz rectangular waveguides and antennas. The resulting rectangular waveguides achieve an insertion loss below 0.3 dB and a return loss above 15 dB across the D-band, while remaining stable across extreme temperatures (−50 °C to 150 °C) and offering a weight reduction of over 60%. A monolithically fabricated smooth-walled conical horn antenna exhibits beam-shaping characteristics that closely align with theoretical expectations. Attempts on corrugated horn antennas in conventional design reveal degraded performance, primarily arising from the inherent staircase effect associated with 3D printing. A novel design featuring obliquely oriented corrugations is developed, effectively mitigating uncontrolled deformation in periodic subwavelength features. Compared with the classical corrugated design (θ = 90°), the proposed obliquely oriented corrugations (θ = 30°) improve the agreement between experimental and theoretical radiation patterns, reducing the gain deviation from 1.45 dB to less than 0.5 Db—a quantitative improvement of over 60% in pattern fidelity. We believe that this fabrication route together with the process-adaptive design paradigm establishes a robust technical foundation for realizing high-performance, lightweight, and design-flexible terahertz waveguide components and holds significant promise for advancing the development of next-generation integrated terahertz systems. Full article

This paper presents the concept of a 2D m × n waveguide-based power combiner (PC) that is scalable with respect to the operating frequency band and number of input ports. To our knowledge, this work reports the first planar (2D) power combiner, where the input waveguide ports are distributed in two spatial dimensions to form an array, rather than arranged along a single linear (1D) axis as in conventional corporate or cascaded waveguide combiners. The novelty of the approach relies on using H-plane rectangular waveguide T-junctions and low-loss polarization twisters in between vertically stacked T-junctions to facilitate scalability. The work is motivated by the aim to coherently combine the output power of multiple modified uni-traveling carrier (MUTC) terahertz (THz) waveguide photodiodes (PDs) in a 2D array configuration. In the manuscript, the design of a 2 × 2 planar waveguide power combiner for the WR3 band (220–320 GHz) is reported, and it is also shown that this block can be further extended to m × n input ports. Full-wave numerical analysis of the proposed 2 × 2 power combiner shows a return loss of 11 dB at the output port and an average transmission coefficient of about −6.5 dB, i.e., an overall power combining efficiency of ~90%. Furthermore, to enable 2D photodiode array integration, the manuscript presents a new slot-bow tie antenna integrated MUTC photodiode for radiating the optically generated THz power from each PD vertically into the rectangular waveguide. The simulation results of reflection loss and insertion loss for the slot bow-tie antenna are shown to be better than 10 dB and 1.4 dB over the full WR3 band, respectively. To prove scalability of the power combiner concept w.r.t. the number of input ports, a 2 × 4 power combiner is also analyzed. Results reveal a return loss better than 10 dB from 225 to 318 GHz and a transmission coefficient of approximately −9.7 dB at 300 GHz, i.e., a power combining efficiency of ~85%. Full article

This work presents a compact microwave sensor for noninvasive blood glucose monitoring based on a substrate-integrated waveguide loaded with a complementary split-ring resonator on RO4350. The sensing principle uses shifts in resonance frequency and changes in S-parameters to track the dielectric dispersion of glucose-containing tissue. The resonator is constructed using Substrate-Integrated Waveguide (SIW) technology, which mimics the propagation characteristics of a conventional rectangular waveguide. To validate its versatility, the sensor implements three practical sample delivery modes: direct liquid contact with the sensing surface, a glass tube holder mounted over the active region, and a non-invasive fingertip interface. Electromagnetic simulations and benchtop measurements confirm clear glucose-dependent frequency shifts with stable matching and insertion levels. Across the physiological range of 20 to 200 mg·dL⁻¹, the sensor exhibits clear glucose-dependent resonance shifts in all configurations. In direct contact mode, the resonance frequency shifts from 10.83 GHz to 10.45 GHz with sensitivities up to 2.47 MHz per mg·dL⁻¹. The tube configuration shows a shift from 10.49 GHz to 10.38 GHz with sensitivity up to 0.80 MHz per mg·dL⁻¹, while reducing contamination. In the non-invasive fingertip mode, the resonance shifts from 2.56 GHz to 2.52 GHz with sensitivities up to 0.25 MHz per mg·dL⁻¹. These results confirm the sensor’s compactness, reliability, and suitability for portable, low-cost glucose monitoring. The results indicate that the proposed sensor can support practical continuous or spot monitoring and offers a clear path toward portable and low-cost glucose assessment. Full article

This paper reports a magnetically tunable U-band metallic waveguide isolator based on the ferromagnetic resonance (FMR) absorption effect. The device features a BaFe₁₂O₁₉ (BaM) single-crystal array integrated into a rectangular waveguide. By leveraging the high intrinsic magnetocrystalline anisotropy and narrow FMR linewidth of the single-crystal material, the isolator achieves high-frequency operation with a significantly reduced external bias field. Experimental results demonstrate a broad continuous tuning range from 50 GHz to 66 GHz. The device exhibits exceptional efficiency, with a typical insertion loss of less than 0.5 dB (minimum 0.24 dB) and an isolation exceeding 15 dB across the operating band. The cascaded array configuration ensures uniform magnetization and stable performance. This combination of ultra-low insertion loss and frequency agility makes the proposed isolator an ideal candidate for next-generation adaptive millimeter-wave communication and radar systems. Full article

This paper presents a nanoscale sensor based on a metal–insulator–metal (MIM) waveguide coupled with a composite resonant cavity, where the ring resonator is embedded with triangular, semicircular, and rectangular structural elements. The transmission characteristics and sensing performance of the structure were systematically analyzed using the finite element method. The results indicate that the interference between the continuous mode in the waveguide and the discrete mode in the resonant cavity generates a distinct asymmetric Fano resonance. The optimized sensor achieves a sensitivity of 2960 nm/RIU and a figure of merit (FOM) of 59.79. Experimental verification confirms that the structure exhibits high responsiveness in temperature sensing, providing an effective solution for integrated photonic devices. Full article

In this paper, a flower-shaped spoof surface plasmon polaritons (SSPPs) unit with strong slow-wave effect is proposed to construct bandpass filters (BPFs). Benefiting from extended current path induced by addition of rotated stubs around rectangular unit, the proposed SSPPs unit exhibits reduced asymptotic frequency. Following this, a single-band filter boasting multiple transmission zeros (TZs) in its upper stopband is developed by embedding the unit into half-mode substrate integrated waveguide (HMSIW). To improve suppression of the lower stopband, a pair of open circuited stubs are loaded to produce TZs and enhance its frequency selectivity. Consequently, the single-band BPF realizes an impressive roll-off rate of 0.116 dB/MHz. Subsequently, geometric dimensions of the open-circuited stubs are modified to dispose the TZs into passband and acquire dual-band operation. In addition, defected ground structures (DGSs) are loaded to broaden the bandwidth of notch between two passbands. Finally, a dual-band filter with a wide suppression band of 0.50 GHz is developed. With roll-off rates of 0.096 and 0.119 dB/MHz, the filter demonstrates good selectivity as well. Full article

In this paper, low-pass corrugated filters based on half-mode groove gap waveguide (HMGGW) technology are proposed for the first time. The design process starts from the equivalent classical low-pass implementation in corrugated rectangular waveguide. Then, the final response is achieved after a slight re-optimization of groove widths and lengths. As a proof of concept, two corrugated low-pass filters with upper cutoff frequencies at 27 and 29.5 GHz, and maximum attenuation rejection at 34.5 and 39 GHz, respectively, have been designed and manufactured. In spite of the frequency range of operation, the return losses are better than 19.5 dB for both tuning-less filter prototypes, while measured insertion losses are lower than 0.25 dB and 0.3 dB, respectively, in almost the entire passband. The very good agreement between simulations and measurements fully validates the use of this new emerging technology for the implementation of low-pass filters at high frequency bands. Full article

This paper presents a novel asymmetric U-shaped refractive index sensor, which is based on a MIM waveguide and coupled with a U-shaped resonator, which integrates a ring, a circular cavity, and two rectangular cavities (URRCTR), in addition to an inverted rectangular nanostructure. The efficiency of the proposed sensor was investigated and optimized through the FEM. Simulation results indicate that the interaction between the broadband mode supported by the inverted square-shaped structure on the primary waveguide and the confined narrowband mode of the URRCTR resonator generates a distinct asymmetric feature in the transmission profile, a characteristic indicative of Fano resonance. The geometric parameters of the structure are crucial for tuning the Fano resonance features. Through systematic optimization, the sensor achieves a sensitivity of 3480 nm/RIU and a figure of merit (FOM) of 55.23. Due to its high sensitivity, compact footprint, and favorable temperature-dependent properties, the presented sensor reveals considerable promise for various applications in integrated photonic sensing. Full article

This paper presents a novel 1-to-N power division architecture combining overmoded ${\mathrm{TE}}_{10}$ mode waveguides and modular N-way waveguide-to-microstrip mode converters. By decomposing the ${\mathrm{TE}}_{10}$ mode field distribution along the narrow wall of a rectangular waveguide, the proposed design enables flexible power splitting into arbitrary output ports (even or odd numbers) through uniform sub-${\mathrm{TE}}_{10}$-mode waveguide pathways. To achieve the above function using microwave transmission lines, a tapered transition structure ensures wideband excitation of the overmoded waveguide, while linearly tapered slot antennas (LTSAs) serve as N-way mode converters. Prototypes with two-, three-, and four-channel outputs demonstrate excellent amplitude-phase uniformity (≤0.5 dB amplitude imbalance and ≤$5^{\circ }$ phase deviation) across 6.5–12 GHz, with return loss <−10 dB. The modular 1-to-N power divider enables the rapid reconfiguration of output channels by simply replacing the mode converter module. Full article

Although epsilon-near-zero (ENZ) media have emerged as a promising platform for power dividers, the majority of existing designs are confined to fixed power splitting. In this work, two dynamically tunable power dividers using waveguide ENZ media are proposed by precisely modulating the internal magnetic field and the widths of the output waveguides. The first approach features a mechanically reconfigurable ring-shaped ENZ waveguide. By continuously re-distributing the magnetic field within the ENZ tunneling channels utilizing rotatable copper plates, arbitrary power division among multiple output ports is constructed. The second design integrates a rectangular-loop ENZ cavity into a substrate-integrated waveguide, with four positive–intrinsic–negative diodes embedded to dynamically activate specific output ports. This configuration steers electromagnetic energy toward output ports with varying cross-sectional areas, enabling on-demand control over both the power division and the number of output ports. Both analytical and full-wave simulation results confirm dynamic power division, with transmission efficiencies exceeding 93%. Despite differences in structure and actuation mechanisms, both designs exhibit flexible field control, high reconfigurability, and excellent transmission performance, highlighting their potential in advanced applications such as real-time wireless communications, multi-input–multi-output systems, and reconfigurable antennas. Full article
