Railway cable-stayed bridge construction is characterized by high complexity and substantial safety risk. Deficiencies in safety control may result in serious accidents (e.g., collapse and falls), causing significant casualties and economic losses; therefore, clarifying risk interactions and accident-causing mechanisms is essential. This study proposes a fuzzy DEMATEL–ISM approach in which fuzzy sets capture uncertainty in experts’ linguistic assessments. DEMATEL quantifies influence strengths and causal relationships among factors, and ISM constructs a multi-level hierarchy to explain accident causation. Twenty safety influencing factors are identified and grouped into five categories: management, human, material and equipment, construction technology, and environmental conditions. The obtained accident-causing mechanism comprises seven hierarchical levels: L₁: collapse and fall accidents, L₂: direct factors, L₃–L₅: indirect factors, and L₆–L₇: root factors. This mechanism is a chain of events that leads to an accident, with the nodes improper prestressing, structural deformation and differential settlement. These key nodes can be avoided by reinforcing safety management system implementation, daily supervision and inspection, and education and training on the subject of safety to ensure the safety of railway cable-stayed bridge construction. Full article

Foundation constraints are commonly defined according to the deformation characteristics of the supporting system; however, structural deformation is also strongly affected by external loads. Compared with inland bridges, sea-crossing bridges experience much larger horizontal loads under combined wind–wave actions, and whether foundations in hard-soil conditions can be simplified as rigidly fixed still requires verification. In this study, the m-method is used to determine the equivalent spring stiffness of each soil layer from soil parameters, and a spring-based soil–foundation interaction model is established. This spring-based model is taken as the reference to evaluate the applicability of the rigidly fixed foundation assumption. Using the Qiongzhou Strait highway–railway combined cable-stayed bridge as the engineering background, both rigidly fixed and spring-based foundation models are developed to simulate foundation constraints. The dynamic responses of a single bridge tower and of the entire bridge system under combined wind–wave loading are computed. The influences of foundation constraints on tower-top displacement, foundation reaction forces, and bending moments are investigated. The maximum discrepancy between the two approaches reaches 7.83%, providing a rational basis for selecting foundation constraint conditions in dynamic analysis and design of sea-crossing bridges. Full article

In this work, the deformation behavior of a long-span steel–concrete composite girder cable-stayed bridge under temperature loads and its subsequent impact on ballastless track systems were investigated. An integrated finite element model (FEM) of the bridge–track system was developed by taking the Taiziping Wujiang River Bridge (with a main span of 300 m) in Chongqing, China, as a case study. The model incorporates composite girders, pylons, stay cables, rails, and double-block slab tracks. Then, the integrated FEM systematically analyzed structural responses to various temperature loading scenario, namely uniform temperature change, differential temperatures among key components (girder, deck, pylons, and cables), and deck–girder temperature difference. The results show that the girder’s maximum vertical displacement linearly correlates with the temperature variations of the composite girder, upper pylon, and cables, with corresponding temperature sensitivity coefficients of 2.3 mm/°C, 2.78 mm/°C, and −5.8 mm/°C. While the ballastless track coordinates well with the composite girder in vertical deformation, the maximum longitudinal relative displacement occurs between rail and track at the ends of the bridge. Moreover, field monitoring data were used to establish a high-precision relationship between ambient temperature and structural temperatures of key components, enabling successful prediction of girder’s vertical deformation. The findings provide a theoretical basis for the control of thermal deformation during the operation and maintenance of similar long-span composite girder cable-stayed bridges. Full article

Large-span bridges with bluff body girders are susceptible to vortex-induced vibration (VIV) due to their low frequency, light mass, and relatively low damping ratio, affecting fatigue life and serviceability. While research progress has been made on VIV mechanisms and control measures, systematic investigations on the application of vortex generators (VGs) to narrow Π-shaped railway girders remain scarce, and the potential synergistic effect of combining VGs with conventional aerodynamic measures has not been explored. To address this gap, wind tunnel tests were conducted on a 1:50 scale sectional model of a narrow Π-shaped steel girder for a railway cable-stayed bridge. The experimental program systematically investigated the VIV response of the original girder and evaluated the suppression effectiveness of conventional aerodynamic measures (vertical stabilizers, deflectors, modified fairings) and spanwise control using VGs. Parametric optimization of VG height (0.1 H–0.2 H, where H is the girder height), spacing (2/3 L₀ and L₀, where L₀ = 12.5 m is the standard segment length), and installation position (upper fairing, lower fairing, girder bottom) was performed. Results show that under wind angles of attack from −5° to +5° and a damping ratio of 0.36%, the original girder exhibits pronounced vertical VIV with a maximum RMS amplitude of 0.025 m, approximately 3.15 times the code limit. Conventional measures alone fail to adequately suppress VIV. However, the optimal combination of VGs (height 0.2 H, spacing L₀, installed on the lower fairing) with a 0.5 m wide, 15° inclined deflector effectively suppresses VIV under wind AOAs of 0°, ±3°, and –5°, achieving suppression below the measurable threshold. This study contributes the first comprehensive parametric investigation of VGs for narrow Π-shaped railway girders, reveals a synergistic effect when combining VGs with deflectors, and incorporates practical engineering constraints (such as aesthetic requirements) into the optimization process. Full article

The use of high-performance concrete is a common practice in the construction of large-span bridges, where creep deformation may exert a considerable influence. This article puts forth a practical calculation method for long-term creep deformation of concrete bridges, based on short-term laboratory creep tests and multi-factor modification methods. A case study of a large-span railway concrete cable-stayed bridge examines the prediction results in conjunction with the monitoring data derived from digital image correlation (DIC) and compares these with the existing specifications. The results demonstrate that the mid-span deflection predicted by the proposed model shows a high degree of agreement with the short-term measurements. Over a monitoring period of 247 days, the mean mid-span deflection is found to be 2.948 mm and the predicted value is 3.343 mm, giving a relative error of 11.8% relative to the measured mean, which is deemed acceptable in engineering practice. The deflection values at various long-term time nodes indicate that the existing specifications generally overestimate the effect of creep when the concrete types are not taken into account. Although the predictions of the CEB90 model are closest to the model proposed in this paper, they are still 56.8%, 75.4% and 82.2% higher in the mid-span deflection at 3, 10 and 20 years after completion, respectively. Full article

This study aims to analyze the wind-induced effects and vibration control of a long-span cable-stayed bridge with a steel truss girder under strong marine wind conditions during its maximum single-cantilever state. During the cantilever construction stage of cable-stayed bridges, the reduction in structural stiffness and damping may lead to excessive wind-induced responses, affecting construction accuracy and safety. Focusing on a newly constructed sea-crossing railway cable-stayed bridge with a steel truss girder and a main span of 364 m, this research utilizes field-measured data and finite element simulations to analyze the buffeting responses of the bridge in the maximum single-cantilever state during construction. The vibration suppression effects of different wind-resistant measures are compared, and we propose an economical and efficient vibration mitigation solution. The results indicate that using the turbulent field parameters and unit aerodynamic admittance function recommended in JTG/T 3360-01—2018 Wind-resistant Design Specification for Highway Bridges leads to conservative in predictions regarding the buffeting responses, and this approach can be used in the preliminary design of large-span bridges. The measured turbulent field parameters can effectively estimate the bridge buffeting responses, especially in the transverse direction. Measuring wind speeds at the bridge site is crucial for the rational design and construction of cable-stayed bridges in strong marine wind environments. The effectiveness of vibration reduction decreases in the order of temporary piers, inclined struts, tuned mass dampers, and wind-resistant cables. The inclined strut scheme achieved vibration reductions of 84.45% in the transverse direction and 68.17% in the vertical direction, slightly lower than those of the auxiliary pier scheme (89.04% and 85.47%). However, the installation of temporary piers during the construction of a sea-crossing bridge would significantly increase construction costs, whereas the inclined strut scheme requires only temporary steel structures near the main tower and piers without substantially increasing the construction workload. Therefore, the inclined strut scheme is recommended as an effective and economical vibration control measure for large-span sea-crossing cable-stayed bridges. Full article

Prefabricated ballastless tracks are increasingly applied on long-span bridges, necessitating special attention to driving safety and comfort at weak connection areas like beam-end expansion joints. This study, based on the Ningbo-Xiangshan urban railway’s Xiangshangang sea-crossing bridge, establishes a refined train–track–bridge dynamic interaction model incorporating the beam-end expansion joint zone. The dynamic response characteristics of the train under temperature-induced deformation in beam-end expansion area conditions were explored. The research results show that the temperature-induced deformation of the end area of the long-span cable-stayed bridge has a greater impact on the vertical dynamic response of the train, but has a small impact on the lateral dynamic response of the train. Among them, the overall temperature rise and fall state of the long-span cable-stayed bridge has a significant impact on the dynamic response of the train. When a train passes through the beam-end expansion area, compared with the prefabricated track, the beam end area has a more obvious impact on the dynamic response of the train, but its scope of influence is only limited to the telescopic transition within the segment range. The temperature-induced deformation in the beam end area will have a greater impact on the dynamic response of the train, but the dynamic response of the train can still be controlled according to the relevant limits in the current standard. The results of this research can provide technical support for laying prefabricated tracks on large-span urban railway bridges, and provide technical reference for the optimization of expansion joints in the beam end area. Full article

The hybrid cable-stayed suspension bridge is used to combine the advantages of cable-stayed and suspension bridges and hence has a broad prospect for application. The conventional simplified analytical models of the hybrid bridge are usually developed based on a schematic with the cable-stayed and suspension systems working separately without any overlapping zone, which cannot represent the modern hybrid bridge system. In this study, a novel analytical model is proposed based on the modified suspension–elastic foundation beam theory to estimate the mechanical performance and deflection of the hybrid bridge system with the consideration of the overlapped section between the suspension and stayed cables. The governing equations of the hybrid bridge system are developed based on the elastic foundation beam theory and the deflection theory, which are derived separately in the hybrid section, the pure suspension section and the cable-stayed section. The general solution of each section is presented. The Transfer Matrix Method is then employed to solve the unknowns from one end to the other, which are in turn used to solve the internal forces of the hybrid bridge system caused by the concentrated load. In addition, in view of no variation in the unstressed length of the main cable, the compatibility equation of the main cable is established with consideration of the longitudinal displacement of the main tower, which is used to derive the formulas for the internal force and deflection of the hybrid system. The model can be easily complied in any programming platform, such as Matlab, with simple input parameters, which can eliminate the complex finite element modeling process. Hence, it can be easily used in the preliminary design stage to determine the optimal size and layout of the bridge. Then, a case study is presented for the verification of the proposed model under a vertical load, which is simplified from the Xihoumen Bridge, a combined highway and railway bridge with a main span of 1488 m. Good agreement is obtained between the proposed model and the finite element method. Meanwhile, it is found that there exists a negative deflection zone for the main beam at a distance from the concentrated vertical load, which is mainly caused by the deflection of the main cables, leading to the cambering of the beam. Full article

Aiming at the problems of large capacity, narrow transverse width, large excitation, high safety level, and difficulty in accurately grasping the working state of the cable-stayed bridge for the long-span track, this research obtains the structural response data in real time by establishing a health monitoring system. The adaptive filtering method was employed to separate the train load response and the temperature load response. Then, a train load effect analysis method based on the influence line and a temperature load effect analysis method based on the correlation were proposed to assess the operational status of the bridge in real time and objectively. The Chongqing Nanjimen Railway Track Bridge (hereinafter Chongqing Nanjimen track bridge) project was utilized as a case study to demonstrate the application of these methods. The results show that the adaptive filtering method can effectively separate the response of train and temperature loads. The normalized cross-correlation (NCC) results of the measured train load response and the influence line’s finite element calculation show a high degree of fit between the measured values and the theory, proving that no significant anomalies are found in the bridge. There is a strong correlation between the ambient temperature difference and the Pearson correlation coefficient of structural response, which indicates that the Chongqing Nanjimen track bridge is currently in normal working condition. Full article

Aiming at the shortcomings of traditional contact cable force monitoring technology in accuracy, efficiency, and applicability, an assessment method based on microwave radar measurements is proposed to measure a sloping cable with a damper for lengths greater than 200 m in this study. A formula for calculating the cable-stayed force with a damper is derived, and an intelligent cable force monitoring platform is developed based on cloud technology. Based on the Chongqing Nanjimen Railway Bridge, a real bridge test was carried out. It was indicated that the microwave radar method could be used to freely adjust the measurement angle and possessed high applicability and penetration. It significantly improved the measurement accuracy and efficiency of cables with a damper for lengths greater than 200 m. It has good application value for the solution of the problems of complicated operation and high costs in the monitoring of cables with a damper. The formula for calculating the cable force with a damper was proven to be reliable and accurate when compared to the results of direct calculation and the equivalent cable length method. It was able to significantly reduce the calculation error of the cable force caused by the influence of the damper. Additionally, the intelligent cable force monitoring platform was utilized to enhance the level of digitization, providing technical support for the scientific management and maintenance of bridges. Full article

This paper presents an experimental study on the box girder of a low-tower cable-stayed railway bridge with a W-shaped section that consists of prestressed concrete diagonal braces. A 1:6 scale test model was designed and constructed for the experiment. The mechanical behavior of the test model was investigated under two loading conditions: a double-track train symmetrical load and a single-track train unsymmetrical load. The experimental results were validated against a finite element model. Furthermore, the torsional performance of the box girder section was analyzed and discussed. Full article

The elastic cushion is mostly used between the layers of ballastless tracks laid on a large-span cable-stayed bridge with a main span of more than 300 m. The rubber material is easy to harden and age, the geotextile has good acid-alkali resistance and antiwear performance, and the feasibility of geotextile application on the large-span cable-stayed bridge can be explored. The coupling model of a long-span cable-stayed bridge and the ballastless track was established to analyze the longitudinal mechanical characteristics of the seamless line, the deformation of the track structure, and the separation of the track plate and base plate under different loads. The results show that the application of geotextile or elastic cushion has little effect on the longitudinal mechanical properties of seamless lines. Compared to the elastic cushion, laying the geotextile increases the longitudinal stress of the slab by 0.13 Mpa, 0.025 Mpa, and 0.06 Mpa under different types of loads. The strength calculation of the seamless track is within the safety range. Laying elastic cushion can restrain the generation of separation under vertical loads, but there is no effect laying elastic cushion under temperature loads and braking loads, and the height of separation was less than 0.4 mm. The stress and deformation of the ballastless track do not exceed the standard when applying geotextile; it is feasible to apply geotextile on ballastless tracks on a large-span cable-stayed bridge. The next step is to study the vehicle–bridge–track dynamic response when elastic cushion and geotextile are laid. Full article

To study the life-cycle seismic reliability analysis (SRA) of cable-stayed bridges (CSBs) taking into account chloride-induced corrosion and degradation of components, an actual railway CSB with uncertainties in structural geometry and material corrosion coefficients was employed in this investigation, and time-dependent models of CSB components at different service times were studied. Based on the OpenSees batch program, we adapted a mass numerical computation to obtain time-dependent non-linear seismic response and probability density function (PDF) of response via the multiplier dimensional-reduction method (MDRM) and the maximum entropy method with fractional moments (FM-MEM). Next, the time-dependent failure possibility of every component and the association coefficient between the failure modes of different parts were acquired. In the end, the product of the conditional marginal (PCM) approach was employed to obtain the life-cycle failure possibility of the CSB system. The results showed that the system failure possibility of the CSB in a corrosive environment increases significantly with increasing servicing time. Full article

Cable-stayed bridges have been commonly used on high-speed railways. The design, construction, and maintenance of cable-stayed bridges necessitate an accurate assessment of the cable temperature field. However, the temperature fields of cables have not been well established. Therefore, this research aims to investigate the distribution of the temperature field, the time variability of temperatures, and the representative value of temperature actions in stayed cables. A cable segment experiment, spanning over one year, is conducted near the bridge site. Based on the monitoring temperatures and meteorological data, the distribution of the temperature field is studied, and the time variability of cable temperatures is investigated. The findings show that the temperature distribution is generally uniform along the cross-section without a significant temperature gradient, while the amplitudes of the annual cycle variation and daily cycle variation in temperatures are significant. To accurately determine the temperature deformation of a cable, it is necessary to consider both the daily temperature fluctuations and the annual cycle of uniform temperatures. Then, using the gradient boosted regression trees method, the relationship between the cable temperature and multiple environmental variables is explored, and representative cable uniform temperatures for design are obtained by the extreme value analysis. The presented data and results provide a good basis for the operation and maintenance of in-service long-span cable-stayed bridges. Full article

It is known that the extradosed cable-stayed bridge, a hybrid bridge, possesses the virtues of both classic cable-stayed bridges and girder bridges in mechanical behaviors. In this paper, the sensitivity of seismic fragility demand parameters (SFDP) of a high-speed railway extradosed cable-stayed bridge is studied systematically along with the consideration of structural parameter uncertainty. Based on the probability distribution and correlation of random parameters, the Latin hypercube sampling method is adopted herein. The dynamic 3D finite element model of the employed bridge is established by using powerful and attractive OpenSEES nonlinear software. A nonlinear incremental dynamic analysis is performed to consider the randomness of structural parameters using sampling analysis. Some important conclusions are drawn indicating that the structural design parameter uncertainty predominantly has influence on the SFDP for fragility analysis of bridge structures. The design parameters of extradosed cable-stayed bridges are categorized and identified as primary, secondary and insensitive parameters. The high sensitivity parameters of extradosed cable-stayed bridges for fragility analysis include friction coefficient of bearing, concrete bulk density, damping ratio, peak compressive strength of confined concrete, component size and peak strain of confined concrete. Additionally, the strength and strain of unconfined concrete cannot be ignored. Furthermore, the uncertainty of structural design parameters fails to be responsible for the cable force responses due to larger girder stiffness. The structural design parameter uncertainty has a significant influence on the responses of extradosed cable-stayed bridges for seismic fragility analysis. Full article
