Search Results (16)

Friction behaviour at the wheel–rail interface is of critical importance for railway operations and maintenance and is generally characterised by creep curves. The V-Track test rig was used in this study to measure both the lateral and longitudinal creep curves with uncontaminated dry interface conditions, utilising contact pressures representative of operational railway wheel–rail systems. The novelties of this study are threefold. 1. With proper representations of train/track components, the V-Track tests revealed the effects of structural dynamics on measuring wheel–rail creep curves in real life. 2. Pure lateral and longitudinal creepage conditions were produced with two distinct experimental principles—displacement- and force-controlled—on the V-Track, i.e., by carefully controlling the angle of attack and the traction/braking torque, respectively, and thus the coefficient of friction from lateral and longitudinal creep curves measured on the same platform could be cross-checked. 3. The uncertainties in the measured creep curves were analysed, which was rarely addressed in previous studies on creep curve measurements. In addition, the measured creep curves were compared against the theoretical creep curves obtained from Kalker’s CONTACT. The influence of wheel rolling speed and torque direction on the creep curve characteristics was then investigated. The measurement results and findings demonstrate the reliability of the V-Track to measure wheel–rail creep curves and study the wheel–rail frictional rolling contact. Full article

This study deals with the problem of uneven wear of brake pads of wagons caused by a set of structural, dynamic, technological and operational factors. It has been found that an uneven distribution of the brake pad pressure force leads to higher maintenance costs and lower braking efficiency. The main causes of uneven wear are worn kinetostatic units, differences in the geometric parameters of pads, and imperfections in the lever transmission design. A method for optimizing the distribution of the pressure force using weight coefficients and the Lagrange function has been developed; it reduces the uneven wear of brake pads to 8–10% compared to that of a typical wagon bogie brake system, which is 20–35%. The experiments conducted have shown that for a mileage of 74,400 km and with the air distributor in empty mode, the wear of the pads is 19.6–28 mm, while in the loaded mode it amounts to 27.53–38.04 mm. The stress state of brake pads was determined with consideration of the weight coefficients. It was found that for abnormal wear of brake pads, their strength is not observed. The strength of the wheel when interacting with an abnormally worn pad has also been assessed. The resulting stresses are 1.5% higher than those that occur when the wheel interacts with the pad with nominal dimensions. The results of the research will contribute to the database of developments to be used for designing of modern structures of tribotechnical pairs of rolling stock and increasing the efficiency of railway transport. Full article

The majority of freight trains are characterized by a braking system that does not guarantee synchronous braking between different wagons. This results in the generation of considerable in-train forces during emergency braking operations, which are sometimes imposed by the railway infrastructure due to certain running speeds being exceeded. The magnitude of in-train forces is contingent upon a number of factors, the most significant ones being the length, mass and load composition of the trainset, in addition to the specific braking imposed. The application of excessive compressive in-train forces has the potential to cause the wagon to derail, particularly if the wagon is lightweight and traversing a small radius curve. Similarly, excessive tensile in-train forces applied to the screw couplers can cause them to fail, typically through fatigue, resulting in train disruption and necessitating the recovery of both portions of the trainset. The objective of this study is to perform a preliminary analysis of the UIC (International Union of Railways) unified screw couplers fatigue phenomenon, employing load spectra computed by the UIC 1.4.6 software TrainDy. A possible future development is developing a maintenance model functional to predict the extent of damage in freight wagon screw couplers during their service life. Full article

When a railway train runs along a curved track with braking, the dynamic behaviors of the vehicle are extremely complex and difficult to accurately reveal due to the coupling effects between the wheel–rail interactions and the disc–pad frictions. Therefore, a rigid–flexible coupled trailer car dynamics model of a railway train is established. In this model, the brake systems and vehicle system are dynamically coupled via the frictions within the braking interface, wheel–rail relationships and suspension systems. Furthermore, the effectiveness of the established model is validated by a comparison with the field test data. Based on this, the dynamic response characteristics of vehicle under curve and straight braking conditions are analyzed and compared, and the influence of the curve geometric parameters on vehicle vibration and operation safety is explored. The results show that braking on a curve track directly affects the vibration characteristics of the vehicle and reduces its operation safety. When the vehicle is braking on a curve track, the lateral vibration of the bogie frame significantly increases compared to the vehicle braking on a straight track, and the vibration intensifies as the curve radius decreases. When the curved track maintains equilibrium superelevation, the differences in primary suspension force, wheel–rail vertical force, and wheel axle lateral force between the inner and outer sides of the first and second wheelsets are relatively minor under both straight and curved braking conditions. Additionally, under these circumstances, the derailment coefficient is minimized. However, when the curve radius is 7000 m, with a superelevation of 40 mm, the maximum dynamic wheel load reduction rate of the inner wheel of the second wheelset is 0.54, which reaches 90% of the allowable limit value of 0.6 for the safety index, and impacts the vehicle running safety. Therefore, it is necessary to focus on the operation safety of railway trains when braking on curved tracks. Full article

The normalized operation of 30,000-ton heavy-haul trains is of significant importance for enhancing the transportation capacity of heavy-haul railways. However, with the increase in train formation size, traditional braking strategies result in excessive longitudinal impulse when combined pneumatic and electric braking is applied on long, steep gradients. This presents a serious challenge to the braking safety of the train. To this end, this paper establishes a longitudinal dynamic model of a 30,000-ton heavy-haul train based on vehicle system dynamics theory, and validates the model’s effectiveness through line test data. On this basis, the influence of two braking parameters, namely, the distribution of the magnitude of the electric braking force and the matching time of pneumatic braking and electric braking, on the longitudinal dynamic behavior of heavy-haul trains is studied. Thereby, an optimized combined pneumatic and electric braking strategy is formulated to reduce the longitudinal impulse of the trains. The results show that setting reasonable braking parameters can effectively reduce the longitudinal impulse, with the braking matching time having a significant impact on the longitudinal impulse. Specifically, when using a strategy where the electric braking forces of three locomotives are set to 90 kN, 300 kN, and 300 kN, with a 30 s delay in applying the electric braking force, a better optimization effect is achieved. The two proposed braking strategies reduce the maximum longitudinal forces by 20.27% and 47.83%, respectively, compared to conventional approaches. The research results provide effective methods and theoretical guidance for optimizing the braking strategy and ensuring the operational safety of 30,000-ton heavy-haul trains. Full article

This study aims to comprehensively assess the lubrication effect of leaves on wheel–rail contact dynamics using the Virginia Tech-Federal Railroad Administration (VT-FRA) Roller Rig, which closely simulates field conditions with precision and repeatability. Railway operators grapple with the seasonally recurring challenge of leaf contamination, which can cause partial loss of braking and lead to undesired events such as station overruns. Better understanding the adhesion-reducing impact of leaf contamination significantly improves railway engineering practices to counter their effects on train braking and traction. This experimental study evaluates the reduction in traction and braking forces (collectively called “adhesion”) as a function of leaf volume, using two leaf species that commonly grow along U.S. railroad tracks. The test methods rely on the chosen leaves’ transpiration characteristics while ensuring the result’s reproducibility. Leaves were symmetrically positioned on the wheel surface, centered around the mid-rib area within the wear band, and taped on the edges far from the wear band. The critical test parameters (i.e., wheel load, wheel velocity, and percentage creepage) are kept constant among the tests. At the same time, leaf volume is reduced from a maximum amount that covers the entire wheel surface (100% coverage) to no leaves (0%). The latter is used as the baseline. The percentage creepage is kept constant at an exaggerated amount of 2% to accelerate the test time. The results indicate a nonlinear relationship between leaf volume and the loss of braking. Even a small amount of leaf contamination causes a significant reduction in adhesion by as much as 50% compared with no contamination (i.e., baseline). Increasing leaf volume results in contact saturation, beyond which adhesion is not reduced. The minimum adhesion observed in this study is 20% of the maximum adhesion that occurs when no leaf contamination is present. Full article

The electro-mechanical brake is a new advancement in railway train braking. Ball-screws are important components of electro-mechanical braking units (EMBUs), and their wear can cause EMBUs to degrade in performance or even fail to function. In this paper, we present a framework for prediction of ball-screw wear with discrete operating conditions as inputs, taking into account the time-varying characteristics of EMBUs. The framework includes determining the contact type, analyzing relative motion, calculating contact deformations, and estimating wear. The contact type is determined based on the quasi-static approach of Hertz theory. A dynamics model using multiple coordinate systems is established to analyze how balls and raceways move in relation to each other. The contact deformations of the ball–raceway contact are determined using numerical calculation. Then, the wear depth increment is calculated using the Archard model. The results of the calculation and the endurance test indicate that the wear on the screw raceway is greater than that on the nut raceway. The effect of velocity is greater than the effect of axial force. The presented calculation framework is reasonable and can be used for predicting EMBU ball-screw wear. Full article

High-speed trains operating in windy areas may accelerate and decelerate frequently to maintain safe travel, especially when passing curves. During acceleration and deceleration, the role of inter-vehicle suspension (IVS) cannot be ignored. The present study aims to evaluate the effect of IVS on the variable speed curve running of trains under crosswinds. To achieve this purpose, a multibody model of a China Railways High-speed 2 (CRH2) high-speed train considering the IVS is established. By inputting the crosswind loads and traction or braking forces to the model and setting curved tracks with different radii and the unloading factor set as safety criterion, the safe running speeds of the train under different crosswind speeds and different track radii were obtained. The difference in the vehicle dynamics considering the IVS and the fixed connection under traction and braking conditions is analyzed. The radius of the curve track significantly affects the safety characteristics of a train under crosswinds, but its impact diminishes for radii greater than 7000 m. The lateral acceleration, movement angle, unloading factor, and derailment coefficient in both acceleration and deceleration cases of car bodies are affected by the IVS. As a consequence, the IVS will lead to lower safe speeds than fixed connections, but it will also convey more realistic and credible train dynamics. Full article

Defective wheels pose a significant challenge in railway transportation, impacting operational performance and safety. Excessive traction and braking forces give rise to deviations from the intended conical tread shape, resulting in amplified vibrations and noise. Moreover, these deviations contribute to the accelerated damage of track components. Detecting wheel defects at an early stage is crucial to ensure safe and comfortable operation, as well as to minimize maintenance costs. However, the presence of various vibrations, such as those induced by the track, traction motors, and other rolling stock subsystems, poses a significant challenge for onboard detection techniques. These vibrations create difficulties in accurately identifying wheel defects in real-time during operational activities, often resulting in false alarms. This research paper aims to address this issue by using a hybrid deep learning-based approach for the accurate detection of various types of wheel defects using accelerometer data. The proposed approach aims to enhance wheel defect detection accuracy while considering onboard techniques’ cost-effectiveness and efficiency. A realistic simulation model of the railway wheelset is developed to generate a comprehensive dataset. To generate vibration data in various scenarios, the model is simulated for 20 s under different conditions, including one non-faulty scenario and six faulty scenarios. The simulations are conducted at different speeds and track conditions to capture a wide range of operating conditions. Within each simulation iteration, a total of 200,000 data points are generated, providing a comprehensive dataset for analysis and evaluation. The generated data are then utilized to train and evaluate a hybrid deep learning model, employing a multi-layer perceptron (MLP) as a feature extractor and multiple machine learning models (support vector machine, random forest, decision tree, and k-nearest neighbors) for performance comparison. The results demonstrate that the MLP-RF (multi-layer perceptron with random forest) model achieved an accuracy of 99%, while the MLP-DT (multi-layer perceptron with decision tree) model achieved an accuracy of 98%. These high accuracy values indicate the effectiveness of the models in accurately classifying and predicting the outcomes. The contributions of this research work include the development of a realistic simulation model, the evaluation of sensor layout effectiveness, and the application of deep learning techniques for improved wheel flat detections. Full article

The dynamic response of a vehicle during braking is influenced by the tangential forces developed at the wheel-rail’s contact surface. The friction coefficient affects the load transfer from the wheel’s tread to the vehicle. In this work, the vibrations of a scale-down railway vehicle are monitored during braking and their relationship with the friction coefficient between wheel and rail is found out. The vehicle is instrumented with encoders, accelerometers, and is controlled via Bluetooth. The tests are carried out with clean and friction-modified rails. The tangential forces transmitted from the wheel to the railcar’s body are visualized in time and frequency using a proposed correlation algorithm based on the outputs of the Continuous Wavelet Transform (CWT). The results demonstrate that tangential forces have a significant impact on railway vehicles under conditions of high friction coefficients and large creep values. Full article

An urban railway train is a braking power-distributed system consisting of multiple carriages, which is becoming a powerful transportation tool to alleviate traffic congestion within cities as well as across cities. It is critical to control an urban railway train synchronously for improving braking performances, but challenging to be achieved due to strong coupling, unknown dynamics, and disturbances. This paper proposes an observer-driven distributed consensus braking control method for an urban railway train. Specifically, according to the data intersection among carriages, a distributed consensus braking controller is designed to make the velocity of each carriage converge to the desired braking curve. A sliding mode disturbance observer is then developed to estimate the non-linear coupling force and disturbances. The estimation value is utilized to compensate for the distributed consensus braking control law. Moreover, the potential fields are introduced to guarantee that the distances between any two neighbouring carriages are stabilized in a safe range. The effectiveness of the developed control strategy is firstly authenticated via the Lyapunov stability theory and then validated via numerical comparative simulations. Full article

In high-speed magnetic railways, it is necessary to create the forces that lift the train. This effect is achieved by using active (EMS) or passive (EDS) magnetic systems. In a passive system, suspension systems with permanent magnets arranged in a Halbach array can be used. In this paper, an original Halbach array with various alternately arranged horizontally and vertically magnetized magnets is proposed. Correctly selected geometry allows us to obtain higher values of levitation forces and lower braking forces in relation to a system with identical horizontally and vertically magnetized elements. The effect of such a shape of the magnetic arrangement is the reduction of instantaneous power consumption while traveling due to the occurrence of lower braking forces. In order to perform a comparative analysis of the various geometries of the Halbach array, a simulation model was developed in the ANSYS Maxwell program. The performed calculations made it possible to determine the optimal dimensions of horizontally and vertically magnetized elements. The results of calculations of instantaneous power savings for various cruising speeds are also included. Full article

The article presented the issue of securing semi-trailer trucks and trailers during their transport using intermodal railway wagons as a part of combined transport. This issue was analysed in different operational conditions related to loading level, cross-winds influence, inertia forces due to the emergency braking, and track curvature. According to general rules of loading and securing cargo, described in the internal and UIC regulations, the transported load should be positioned and secured with minimised risk of undesirable displacement or rolling over during transport. Basic analysis showed that adverse conditions such as strong winds or emergency braking may require adequate additional cargo protection. The lack thereof may result in a severe accident or damage to the transported vehicle or the nearby structures. The presented results for generic road and railway freight vehicles showed that the required anti-rollover torque for a semi-trailer mounted on the railway wagon platform may differ considerably (almost four times at the same maximum tested airflow speed) depending on the conditions related to aerodynamic and inertia influence. The potential weaknesses of the analysis relate to the impracticality of experimental tests for roll-over (or derailment) events under high levels of cross-wind, due to economic and safety reasons. The analysis can be extended in the future by including unsteady aerodynamic forces and a full-vehicle model based on the multi-body method for a specific design solution. Full article

The regenerative braking of railway vehicles is widely used in DC railway systems all over the world. This mode of operation provides an opportunity to reuse part of the energy consumed by vehicles, and makes the railway system more energy efficient. During regenerative braking, not only energy management is an issue, but also Electromagnetic Compatibility EMC issues, such as interference of generated current harmonics with a railway signaling system. In this paper, the selective harmonic elimination modulation technique (SHE-PWM) was introduced to the traction drive with a three-level inverter to reduce specific catenary current harmonics generated during regenerative braking. The simulation model of a traction drive appropriate for harmonics analysis was proposed and verified by the measurements in the low-power laboratory drive system. The model was re-scaled to the 3 kV DC system for further study. The model of an induction motor with electromotive force and the method of its calculation was proposed. Furthermore, an analysis of the braking chopper operation was carried out. The asymmetric control of braking chopper was proposed to reduce the current harmonics below limits during chopper operation. Full article

The bogie frame is an important structure of railway vehicles, transmitting the traction, braking force, lateral force, and vertical force during the traction operation. With the development of high speeds and heavy loads, the appearance of fatigue cracks in the bogie frames is increasing, which reduces the driving life of railway vehicles and even causes serious traffic accidents. Real-time monitoring on the integrity of the bogie is an inevitable requirement for ensuring the safe operation of railway vehicles. In this paper, ultrasonic guided wave-based active structural health monitoring (SHM) was developed to identify the fatigue crack of the bogie frame. Experiments were conducted on a welded T-shape specimen with a thickness of 12 mm. A total of 10 piezoelectric lead zirconate titanate (PZT) disks were mounted around the weld zone of the specimen, five of which were used as actuators, and the other five were used as sensors. Five-peak modulation narrow-band sine waves were input into the actuators to excite the specimen. From the sensor signals, the advanced damage index (DI) was calculated to identify the propagation of the crack. The experimental results demonstrate that crack damage as small as 2 mm in the weld zone of the bogie frame can be successfully detected. Some practical issues for implementing the SHM in real applications, such as crack quantification and environmental compensation, were also discussed. Full article
