Prestressed steel strands transfer structural loads through complex anchorage systems. During through-anchorage ultrasonic guided-wave inspection, strong reflections generated in the anchorage segment may obscure defect-related echoes and create blind zones in the received signals. This study investigates the generation mechanisms of these anchorage-induced reflections and evaluates the relative roles of stress-induced acoustoelastic impedance variation and load-dependent interfacial contact evolution. An acoustoelastic finite element model is first used to estimate the reflection contribution caused by stress concentration alone. The results show that the stress-induced reflection remains weak, with the reflection coefficient remaining below 0.0125 even at 80% of the ultimate tensile strength. A sensitivity-based equivalent spring-contact model is then employed to examine whether effective strand–wedge and wedge–anchorage interfacial stiffness variations can generate anchorage reflections with comparable order of magnitude and load-dependent trends. The contact-based model produces much stronger reflections, and roughness-sensitivity analysis indicates that the load-dependent trend is not governed by a single nominal roughness assumption. Multi-specimen stepwise tensioning experiments show repeatable load-dependent reflection trends at both 80 kHz and 240 kHz. The results therefore suggest that, within the investigated geometry and loading range, interfacial contact evolution is a more plausible dominant contributor to anchorage-induced guided-wave reflections than stress-induced acoustoelastic impedance variation. This work focuses on the physical origin of anchorage reflections and provides a mechanistic basis for interpreting anchorage-induced interference in future through-anchorage defect detection. Full article

Vibration-based damage detection methods are increasingly recognized as effective tools for monitoring the structural health of bridges. However, their reliability and applicability to various types of structural defects require further study, especially based on experimental tests, to correctly interpretate the results and compare the efficiency of different damage indexes. In the field of Structural Health Monitoring (SHM) by dynamic techniques, operational modal analysis (OMA) is of particular interest because only ambient signals are used, avoiding the service interruption of the infrastructures. However, the key issues of an efficient SHM are the possibility to have a quick alarm if an anomalous response is detected and the capability to localize the defect. Several methods can be applied for the anomaly detection considering machine learning, moving further than global modal parameters like the vibration frequency. Conversely for defect localization, local modal parameters, like modal curvature, can be efficient but also a different application of machine learning can be considered. In this paper, two approaches are compared for level 1 (detection) and 2 (localization) damage detection using acceleration measurements: the modal parameters and an Artificial Intelligence (AI)-based procedure using Variational Autoencoders (VAEs). The case study is a set of post-tensioned prestress concrete (PC) beams that represent a wide stock of existing bridges characterized by defects due to a reduction in the prestressing load, a lack of mortar in ducts, and corrosion of tendons. The results show that both methods can be effective, even if defects in PC beams are difficult to be detect with the dynamic response. Finally, the AI-based approach seems a promising solution because I allows for an earlier alarm, even with few sensors, while the modal curvature approach provides a better explanation of the identified anomaly, although it requires a greater number of sensors. Full article

Ball-end copy-milling is widely used for finishing complex components, yet its influence on surface integrity is generally overlooked and remains insufficiently addressed. Milling often generates tensile residual stresses at the machined surface, which are detrimental to fatigue performance and commonly require costly postprocessing, particularly in fatigue-critical parts such as turbine blades. In this context, the present study evaluates the capability of Prestress-Assisted Machining under uniform bending loads to improve the surface integrity of ball-end copy-milled Aluminium 5083 workpieces. Experimental tests were conducted on slender specimens with different thicknesses and curvature radii while maintaining constant cutting conditions. After machining and unclamping, surface residual stresses were measured by X-ray diffraction, and the effects of prestressing on geometry, cutting forces and surface roughness were also assessed. The results demonstrate that this method markedly increases compressive residual stresses in the prestressing direction, from approximately 30 MPa to about 180 MPa, and that this variation can be accurately described by subtracting the elastic prestressing stress from the residual stresses obtained without external loads applied. Moreover, no relevant adverse effects were observed in cutting forces or roughness, and corrected toolpaths allowed a uniform slot depth. These findings identify bending-based Prestress-Assisted Machining as an effective and predictable strategy for improving surface integrity in ball-end copy-milling and extend its applicability beyond previously reported pocket and slot milling operations. Full article

This study proposes a novel pneumatically driven mechanically prestressed rhombic bistable composite laminate with asymmetric cylindrical curvature, which exhibits two weakly-coupled cylindrical shapes where each shape is influenced by planform and geometry parameters. A reduced-order analytical model is developed to predict the laminate’s quasi-static equilibrium shapes and snap-through transitions of the laminate under pneumatic work loading, which is triggered by the internal pressure applied to the fluidic channels. A sensitivity study based on the model investigates the influence of key planform and geometric parameters (the internal angle α and aspect ratio E) on the laminate’s out-of-plane deflection and snap-through pressure. The results show that increasing α reduces the critical prestrain required to achieve bistability and amplifies the out-of-plane deflection, while excessive α may lead to monostable curvature. Variations in aspect ratio modify the coupling stiffness between orthogonal PEMC layers, thereby influencing the bistable domain and critical snap-through pressure. These findings provide methods for the design of bistable composite structures. Full article

The prestressed concrete containment structure constitutes the core protective structure of a nuclear power plant. This paper utilises the prestressed concrete containment vessel (PCCV) of the Hualong Pressurised Reactor 1000 (HPR-1000)—a third-generation pressurised water reactor (PWR)—as the primary research prototype. Utilising ANSYS, a finite element model was established, with key points selected at critical locations such as the dome, cylinder, and base slab for stress analysis calculations. Reinforcement quantification derived from the design methodologies and analytical formulations prescribed in ACI 349 and ACI 359 were compared under various loading conditions. This investigation identified the core discrepancies and influencing factors between the two codes in reinforcement design, alongside a sensitivity analysis to identify key parameters affecting reinforcement design in different structural zones. The results indicate that discrepancies in reinforcement requirements stem primarily from the divergent design philosophies and strength assessment formulations, with this influence outweighing variations in load combinations. Furthermore, significant spatial differences exist in the sensitivity of reinforcement designs for key components to parameters such as the height-to-diameter ratio, shutdown seismic actions, accident pressure, and temperature effects. The conclusions of this study establish theoretical foundations and furnish empirical data to enhance the computational efficiency of prestressed concrete containment design for pressurised water reactor (PWR) facilities, while supporting the alignment of national and international regulatory standards. Furthermore, they serve as a technical reference for advancing nuclear power structural design practices. Full article

Early-age cracking is a common issue in the prefabrication of large-scale box girders, and the application of pre-tensioning techniques to introduce pre-compressive stress is an effective measure to mitigate such cracking. To determine an optimal pre-tensioning scheme for the 60 m large-scale box girder used in the Ningbo–Xiangshan intercity railway, friction coefficient tests and field stress monitoring were conducted. A numerical model simulating the pre-tensioning process of the box girder, accounting for the constraint of the steel formwork, was developed using Abaqus 2021. Based on the validated finite element model, a parametric study was performed to investigate the effects of friction coefficient, internal formwork roof, and prestressing tendon arrangement on the pre-compressive stress. The results indicate that the bond force between cast-in-place concrete and steel formwork is approximately 2.1 times the sliding friction force. As the friction coefficient increases, the pre-compressive stress in the box girder exhibits a notable decreasing trend. For the critical midspan section S40, the inclusion of frictional effects results in a more uniform distribution of pre-compressive stress. Compared to the case without the internal formwork roof, its inclusion leads to a 9.2% to 10.4% reduction in pre-compressive stress at section S40. To mitigate prestress losses transmitted from the ends to the midspan section, it is recommended that the internal formwork be completely removed prior to prestressing tensioning. The pre-compressive stress in the box girder varies considerably with different prestressing combinations. The comparative analysis of different prestressing combinations reveals substantial variations in pre-compressive stress distribution. After evaluating multiple schemes, the optimal pre-tensioning sequence for the 60-m railway box girder is determined as follows: sequentially tensioning tendon groups F1-2, F1-4, F1-5, F1-6, and B2-3, with an anchorage stress controlled at 558 MPa. This scheme ensures that all critical sections of the box girder remain in a pre-compressive state. In particular, the pre-compressive stress at the key midspan section S40 ranges from 1.12 to 1.26 MPa, achieving the desired effect and effectively suppressing early-age cracking in the large-scale box girder concrete. Full article

Given that freeze–thaw damage of prestressed concrete significantly threatens structural service life and that existing conventional simulation techniques fail to capture prestress time series, this paper proposes a deep learning prediction model based on the Transformer model. The model integrates a multi-head self-attention mechanism and positional encoding to effectively capture long-range dependencies in prestressed time series. It enhances temporal modeling capability through a 128-dimensional high-dimensional feature space (chosen to balance representation capacity and computational efficiency for the dataset scale) and a 4-layer encoder stacking structure. A dataset was constructed using time-series data from three prestressed concrete components subjected to 50 freeze–thaw cycles. The F-a component was used as the training set, while F-b and F-c served as the testing sets. During the training phase, a Noam learning rate scheduler, gradient clipping, and an early stopping strategy were employed. The results indicate that the training strategy enables the loss function to converge quickly without overfitting, demonstrating good generalization performance. The prediction model performs well on the F-a and F-c datasets, with determination coefficients (R²) of 0.8404 and 0.8425, and corresponding Mean Absolute Error (MAE) of 61.71 MPa and 57.41 MPa, respectively. It can accurately track the periodic variation trend of prestress, demonstrating the model’s effectiveness in prestress prediction. This model provides a new technical tool for the health monitoring and performance prediction of prestressed concrete structures in freeze–thaw environments. Full article

Prestressed concrete (PSC) beams are widely used in bridges and large structures due to their high load-bearing capacity and crack resistance. However, owing to their complex construction process, they are highly sensitive to temperature variations. Implementing temperature monitoring at this stage helps assess the actual mechanical behavior and effective prestress of the beam, providing a reliable basis for construction control and prestress adjustment. This study aims to investigate the mechanical performance of a bidirectionally stiffened composite tensioning and anchoring system developed earlier by the research team during the construction phase and to elucidate the effect of temperature on the mechanical behavior of pretensioned prestressed concrete beams. By deploying a monitoring system integrated with high-precision sensors, synchronized temperature and displacement data during tensioning, pouring, and curing stages were obtained. Field-measured data were used to validate finite element models under different thermal load conditions. The results indicate that the heat of hydration of concrete causes a temperature difference of 12.0 °C at the end form, leading to a maximum displacement of 0.2 mm at the top of the anchor plate. Notably, a temperature change of 22 °C induces a prestress fluctuation of 0.12% to 0.3%. The numerical model demonstrates strong accuracy, with the highest agreement with experimental data and an error of less than 7.5%. These findings provide a scientific basis for compensating prestress losses and controlling the deformation of prestressed concrete beam structures, playing a critical role in ensuring the long-term safety and performance of structures under complex working conditions. Full article

The accurate measurement of dynamic forces is pivotal for advancing manufacturing process monitoring and enhancing equipment intelligence. To address the challenges of contact interface force field nonlinearity in existing PVDF piezoelectric film force sensors and the inability of a monolithic PVDF piezoelectric film to measure multi-dimensional forces, this study designs a uniform-load double-bossed elastic force-transmitting diaphragm to achieve contact interface force field reconstruction between the sensor’s elastic sensing structure and the sensitive element group. Building upon the load-bearing surface domain segmentation technique, the silver ink electrode on the front surface of a complete circular PVDF piezoelectric film is segmented into four independent sector-shaped rings. Each sector ring, together with its underlying PVDF piezoelectric film, constitutes a sensitive element, and these four sensitive elements are integrated to form the sensitive element group. The three-dimensional force measurement method of this sensitive element group in the Cartesian coordinate system is investigated. The measurement of three-dimensional force is realized by leveraging the tensile-compressive piezoelectric effect of each sensitive element in conjunction with a pre-stressed assembly structure. Quasi-static calibration test results indicate that the charge sensitivities of the force sensor in the X-, Y-, and Z-directions are 52.63 pC/N, 55.96 pC/N, and 9.02 pC/N, respectively, with a linearity ≤4.6%. Dynamic calibration test results reveal that the force measurement module exhibits a natural frequency of 4675.5 Hz. Experimental investigations into the response of triaxial cutting forces to variations in cutting speed, feed rate, and cutting depth were conducted, which verified the sensor’s ability to capture dynamic three-dimensional cutting forces. This study provides an effective solution for the structural design and three-dimensional force measurement methodology of PVDF piezoelectric film force sensors. Full article

As a low-carbon and lightweight material, glulam is increasingly being used in spatial gridshells. However, these glulam gridshells are prone to instability owing to the material properties of glulam. In this study, to enhance the overall stability behaviour, a prestressed cable system was introduced to the ordinary glulam gridshell to form a novel prestressed cable-braced glulam gridshell. Extensive finite element simulations were conducted to examine the mechanical performance of these novel gridshells. This paper analyses how variations in structural parameters impact the stability performance of the shell. Furthermore, an approximate formula is developed to assess the load carrying capacity. This formula is established by integrating theoretical derivations with numerical simulations. We have thus demonstrated that the stability behaviour of traditional glulam gridshells can be significantly improved by the introduction of prestressed cable systems, and the proposed evaluation formula is accurate enough for the load carrying capacity prediction of prestressed cable-braced glulam gridshell. Full article

The fire performance of existing reinforced concrete (RC) bridge decks strengthened by external prestressing systems is investigated, with particular attention to the vulnerability of externally applied tendons under realistic fire scenarios. Fire exposure represents a critical condition for such retrofitted structures, as the structural response is strongly influenced by load level, prestressing effectiveness, and thermal degradation of the strengthening system. A comprehensive assessment framework is proposed, combining thermal and mechanical analyses applied to representative highway overpass bridges. The thermal input adopted for the analyses is first validated through computational fluid dynamics (CFD) simulations, aimed at evaluating temperature development in typical RC beam–girder grillage decks subjected to fire from below. The CFD study considers variations in clearance height and span length and confirms that, in the case of hydrocarbon tanker accidents with fuel spilled on the roadway, conventional fire curves commonly adopted in the literature provide a reliable and conservative representation of both the temperature levels reached and their rate of increase within structural elements, thus supporting their use for rapid and simplified assessments. The validated thermal input is then employed in an analytical fire safety procedure applied to several realistic bridge case-studies. A parametric investigation is carried out by varying deck geometry, span length, reinforcement layout, and the presence of external prestressing retrofit, allowing the evaluation of the reduction in bending capacity and the time-dependent degradation of mechanical properties under fire exposure. The results highlight the critical role of external prestressing in fire scenarios, showing that significant loss of prestressing effectiveness may occur within the first minutes of fire, potentially leading to critical conditions even at service load levels. Finally, a multi-hazard assessment is performed by combining fire effects with pre-existing aging-related deterioration, such as reinforcement corrosion and long-term prestressing losses, demonstrating a marked increase in failure risk and, in the most severe cases, the possibility of premature collapse under dead loads. Full article

Research on the configuration and mechanical performance of arch-column-tie beam joints, which combine features of arch-tie beam joints and tubular joints, remains limited, particularly for long-span structures subjected to heavy loads at high building stories. This study focuses on a joint in an engineering structure comprising a circular arch beam, a square-section inclined column, and a tie beam, where both the arch and the inclined column are concrete-filled steel tube (CFST) members. A novel joint configuration was proposed, then a refined finite element model was established. The joint’s mechanical mechanism and failure mode under axial compression in the arch beam were investigated, considering two conditions: the presence of prestressed high-strength rods and the failure of the rods. Subsequently, a parametric study was conducted to investigate the influence of variations in the web thickness of the tie beam, the steel tube wall thickness of the arched beam, the steel tube wall thickness of the supporting inclined column, and the strength grades of steel and concrete on the bearing capacity behavior and failure modes. Numerical simulation results indicate that the joint remains elastic under the design load for both conditions, meeting the design requirements. The joint reaches its ultimate capacity when extensive yielding occurs in the tie beam along the junction region with the circular arch beam, as well as in the steel tube of the arch beam. At this stage, the steel plates and concrete within the joint zone remain elastic, ensuring reliable load transfer. The maximum computed load of the model with prestressed rods was 2.28 times the design load. The absence of prestressed rods could lead to a significant increase in the high-stress area within the web of the tie beam, decreasing the joint’s stiffness by 12.4% at yielding, but have a limited effect on its maximum bearing capacity. Gradually increasing the wall thickness of the arch beam’s steel tube shifts the failure mode from arch-beam-dominated yielding to tie-beam-dominated yielding along the junction region. Increasing the steel strength grade is more efficient in enhancing the bearing capacity than increasing the concrete strength grade. Finally, a design methodology for the joint zone was established based on three aspects: local stress transfer at the bottom of the arch beam, force equilibrium between the arch beam and the tie beam, and the biaxial compression state of the concrete in the joint zone. Furthermore, the construction process and mechanical analysis methods for various construction stages were proposed. Full article

To address the limitation of using experimental parameters in the macroscopic strength criterion, a micromechanical strength criterion for root-reinforced soil is developed. In this model, a micromechanical model for a three-phase composite (“root—cemented soil matrix—frictional element”) is constructed, and the novel combination of energy equivalence principles with the M-T method is used to determine the meso-scale prestress and strength criterion for root-reinforced soil under freeze–thaw cycles. The representative volume element (RVE) of root-reinforced soil is conceptualized as a composite material consisting of a bonded element (a cemented-soil matrix with root inclusions) and frictional inclusions. By applying micromechanics, along with the Mori–Tanaka method, the LCC method, limit analysis theory, and macro–micro energy equivalence principles (incorporating both strain and dissipated energy), a micromechanical strength criterion is formulated, revealing failure mechanisms at the microscale. The previously used stepwise procedure for deriving the stationary function is improved, and the microscale prestress is determined through the Mori–Tanaka method combined with macro–micro strain-energy equivalence. The proposed micromechanical strength criterion effectively models the primary strength variation in root-reinforced soil under freeze–thaw cycles, extending the existing shear criterion for soil. Full article

This paper proposes a hybrid rigid–flexible wing design that enables large-area folding and reconfiguration. Based on elasticity theory and fabric constitutive equations, a surface-outward mechanical model incorporating mesoscale weave structures was developed for plain-woven wing membranes. To address the degradation of the model under low-prestress conditions, a more accurate second-order nonlinear model for the out-of-plane mechanics of wing membranes was further developed. This paper developed a dual-axis tensile fixture and, through conducting load-bearing performance experiments on wing membrane elements, verified that the improved theoretical model possesses a certain degree of predictive accuracy. A dual-axis tensile fixture was designed, and load-bearing tests on membrane elements were conducted to verify that the improved theoretical model provides reasonable predictive accuracy. To investigate how pre-tensioning regulates membrane stiffness, the variation in out-of-plane stiffness under symmetric and asymmetric prestress conditions was analysed. A prestressing strategy prioritising the principal-modulus direction is proposed, providing theoretical guidance for prestress application in wing membranes. Based on these findings, a prototype rigid–flexible composite wing with a “membrane-scaffold” structure was fabricated and tested. Full article

Compared to traditional single/double-row concrete cast-in-place piles or concrete walls commonly used in foundation pit engineering, pre-tensioned prestressed hollow concrete-filled steel tube piles (referred to as prestressed Steel Cylinder Piles, or prestressed SC piles) demonstrate superior advantages including high bearing capacity, light weight, enhanced stiffness, excellent crack resistance, and cost-effectiveness, indicating a promising future in foundation pit engineering. However, current research has paid limited attention to such piles. Only a few experimental studies have focused on their flexural performance. No studies have presented bearing behavior investigations considering soil–pile interactions and the differences between these kinds of piles and traditional piles. To address this gap, this paper conducts a systematic investigation into the bearing performance of prestressed SC piles. A refined finite element analysis model capable of accurately characterizing pile–soil interactions is developed to analyze the mechanical behavior. Subsequently, the elastic foundation beam method recommended by design codes is employed to analyze the internal forces and displacement variations of these piles during excavation. Finally, the predictions by the design code are compared against those from the refined model. Results shows that the established finite element model presents reasonable predictions on monitoring data and experimental results, with deviations in bending moments and deformations within the range of 10–15%; a comparative analysis of different pile types reveals that prestressed SC piles exhibit smaller horizontal displacements and higher bearing capacities; the bending moments and deformations predicted by design methods (elastic foundation beam method) are conservative, with the predicted values significantly higher than those predicted by the refined model. Full article
