As renewable energy sources (RES) continue to expand and the use of power inverters has surged, inverters have become crucial for converting direct current (DC) from RES into alternating current (AC) for the grid, and their security is vital for maintaining stable grid operations. This paper investigates the security vulnerabilities of photovoltaic (PV) inverters, specifically focusing on their internal sensors, which are critical for reliable power conversion. It is found that both current and voltage sensors are susceptible to intentional electromagnetic interference (IEMI) at frequencies of 1 GHz or higher, even with electromagnetic compatibility (EMC) protections in place. These vulnerabilities can lead to incorrect sensor readings, disrupting control algorithms. We propose an IEMI attack that results in three potential outcomes: Denial of Service (DoS), physical damage to the inverter, and power output reduction. These effects were demonstrated on six commercial single-phase and three-phase PV inverters, as well as in a real-world microgrid, by emitting IEMI signals from 100 to 150 cm away with up to 20 W of power. This study highlights the growing security risks of power electronics in RES, which represent an emerging target for cyber-physical attacks in future RES-dominated grids. Finally, to cope with such threats, three detection methods that are adaptable to diverse threat scenarios are proposed and their advantages and disadvantages are discussed. Full article

This paper deals with the mitigation of magnetic field levels produced by a wireless power transfer (WPT) system to recharge the battery of an electric vehicle (EV). In this work, an array of active coils surrounding the WPT coils is proposed as a mitigation technique. The theory and new methodological aspects are the focus of the paper. Magnetic field levels in the environment are calculated numerically without and with the presence of an array of active coils in a stationary WPT system for automotive applications. By the proposed mitigation method, the field levels beside the vehicle are significantly reduced and comply with the reference levels (RLs) of the ICNIRP 2010 guidelines for human exposure to electromagnetic fields and the magnetic flux density limits proposed by ISO 14117 for electromagnetic interference (EMI) in cardiac implantable electronic devices (CIEDs). Full article

Flexible flat cables (FFCs) are a typical form of interconnect in modern electrical and electronic systems that facilitate signal transmission between components while minimizing harness volume. FFCs offer a practical connectivity solution in energy management applications, where sensors and displays are essential for monitoring power consumption and performing advanced digital control. In FFCs, signal lines run parallel to each other, and the proximity between lines can cause interference among adjacent signals. Therefore, the arrangement of signals along different lines can significantly influence the overall transmission performance. In this paper, the order of signals within the FFC is optimized to ensure optimal transmission performance, avoiding electromagnetic compatibility (EMC) and signal integrity (SI) issues. The problem is tackled by implementing a multi-objective optimization (MOO) approach, whose aim is to minimize near-end and far-end crosstalk, namely NEXT and FEXT. The effectiveness of the proposed approach is verified by considering a minimized interconnection system involving an FFC. The Pareto-optimal solutions are identified, and worst-case and best-case conditions are highlighted. The results show improvements in EMC and SI, underlining the relevance of the proposed optimization strategy. The proposed strategy provides a valuable tool for designing high-performance interconnections in electrical and electronic systems. Full article

The surge in electric vehicle adoption has resulted in a significant rise in end-of-life batteries, which are unsuitable for demanding EV applications. Repurposing these batteries for secondary applications presents a promising avenue to tackle environmental and economic challenges associated with their disposal. The second-life battery (SLB) approach emerges as a mechanism to manage this massive amount of retired EV batteries. However, this approach poses significant challenges in determining and monitoring battery degradation and performance. After evaluating different scenarios for reusing or recycling retired EV batteries, this paper examines the main challenges associated with SLBs, including techno-economic aspects, uncertainty from first life, safety, characterization and screening, battery-management systems, and secondary applications. A comprehensive review of current state-of-the-art SLB research and implementations is provided, particularly emphasizing battery characterization and the requisite evaluation processes for SLB eligibility. This paper explores diverse measurement techniques for assessing SLB performance, evaluating them based on accuracy, complexity, and time consumption, which are essential for achieving cost-effective SLB applications. The overarching objective is to thoroughly understand the principal challenges associated with repurposing EV batteries and delineate the research imperatives necessary for their successful implementation and prolonged lifespan. Full article

With the development of vehicular communication technology, the electromagnetic compatibility requirements of vehicular communication systems are becoming more demanding. The traditional four-level electromagnetic compatibility evaluation model is widely applied in many scenarios. However, this model neglects the mutual interference of electronic devices inside a vehicle, and it cannot evaluate whether reduced radio receiver sensitivity, antenna isolation, and communication distance satisfy the system requirements for vehicular communication, thus making it unsuitable for digital communication systems. With the development of remote sensing technology, high-precision digital maps are easy to acquire and thus widely used. In this work, a modified five-level evaluation model based on digital maps is proposed, where digital maps are employed to support receiver sensitivity, antenna isolation, and communication performance evaluation. Through remote sensing technology and digital maps, a terrain profile is obtained, and a more accurate vehicle communication propagation model is established. In the experiment, an actual armored vehicular communication system example is applied to verify the performance of the proposed five-level evaluation model. Compared with the free-space propagation model, the error of the actual power received by the receiver is reduced by 0.97%, and the error of the communication distance where the sensitivity of the receiver is reduced by more than the system EMC threshold is reduced by 16.78%. The calculated antenna isolation degree is basically consistent with the actual measurement data. The model is able to evaluate the electromagnetic compatibility of an armored vehicular communication system more quickly, accurately, and comprehensively compared to previous evaluation models. Full article

The employment of input filters in modern DC–DC converters is mandatory in order to ensure EMC (Electro-Magnetic Compatibility), provide power electronics with decent voltage and minimize the converter influence on the power grid. The LC type input filters bring also a possibility of voltage and current oscillation that may occur in the system. This oscillation may rise to a certain level that affects system stability. A wide range of methods are employed in order to attenuate these oscillations and allow appropriate system transient response. In this paper, the sliding mode control (SMC) strategy is proposed to reduce the input LC filter voltage and current oscillation and allow DC (Direct Current) output voltage control for both resistive and constant power load. The proposed control algorithm is intended for use in railway, tram and trolleybus DC/DC converters. For the proposed scheme of control simulation, a model is developed using Simulink software. Furthermore, laboratory stand experiments are carried out to verify simulation results. Full article

As diseases caused by solar radiation have gained great prominence, several methods to prevent them have been developed. Among the most common, the use of sunscreens is customary and accessible. The application of theoretical methods has helped to design new compounds with therapeutic and protective functions. Natural compounds with described photoprotective potential properties (3-O-methylquercetin, gallic acid, aloin, catechin, quercetin, and resveratrol) were selected to perform theoretical studies. Computational methods were applied to predict their absorption spectra, using DFT and TD-DFT methods with functional B3LYP/6−311+g(d,p) basis sets and methanol (IEFPCM) as a solvent. The main electronic transitions of the compounds were evaluated by observing whether the differences in HOMO and LUMO energies that absorb in the UV range are UVA (320–400 nm), UVB (290–320 nm), or UVC (100–290 nm). Experimental validation was carried out for EMC, quercetin, and resveratrol, demonstrating the consistency of the computational method. Results obtained suggest that resveratrol is a candidate for use in sunscreens. The study provided relevant information about the in silico predictive power of natural molecules with the potential for use as photoprotective adjuvants, which may result in fewer time and resource expenditures in the search for photoprotective compounds. Full article

Energy efficiency is becoming one of the most important topics in electronics. Among others, wide band-gap semiconductors can raise efficiency and lead to shrinking volumes in power conversion systems. As different markets have regulations that require different designs, it is necessary to cope with a large variety of similar designs. By using effective modeling and simulation strategies, the efforts of building these variants can be diminished, and re-designs can be avoided. In this paper, we present a universally valid way to come to reasonable simulation results for conducted emissions of a power electronic system in the frequency range from 150 kHz up to 400 MHz. After giving an overview of the state-of-the-art, the authors show how to implement and set up a simulation environment for a gallium-nitride (GaN) power converter. It shows how to differentiate between important and not that important components for Electromagnetic Compatibility (EMC), how to model these components, the printed circuit board, the load, and the setup, including the Line Impedance Stabilization Networks (LISNs), etc. Multiport S-parameter strategies as well as vector fitting methods are employed. Computational costs are kept low, and all simulations are verified with measurements; thus, this model is valid up to 400 MHz. Full article

High power electromagnetics (HPEMs) pose a potential threatening risk to the wireless communication system, especially according to the main coupling path of the RF front-end channel. SPICE modeling of the responses coupled on the RF channel is crucial for the EM risk assessment, which helps us learn more about how the pulse conducts on the RF channel. A simplified linear RF channel with pyramid horn antenna is taken as an example by the selection of the key electronic modules of the actual wireless system. This paper proposes a system-level SPICE circuit model for the simplified RF channel according to the hybrid methods of the antenna electromagnetic simulation and SPICE modeling of the RF circuit. The equivalent circuits of the horn antenna illuminated by HPEMs are established with the Vector Fitting method based on Thevenin and Norton theorems. The short current response as the excitation files for the SPICE models are obtained by the commercial electromagnetic simulation of the horn antenna illuminated by Multiple HPEM environments. Equivalent circuits of a micro-strip bandpass filter are also derived with $\pi$ type circuit structure based on the measured admittance data. Then we analyze the HPEM risk faced by the RF channel by considering multiple HPEM environments. The norm theory is utilized to analyze the waveform characteristics from electric fields of HPEMs to the responses of the RF channel. The ratios of the responses versus electric field for each norm are computed and the EM risk degree is ranked based on those results. The results demonstrate that high power microwave is the highest threatening risk for the linear RF channel compared to the other two HPEMs such as ultra-wide band, high altitude electromagnetic pulse. Finally, the flowchart of EM risk assessment is presented based on a previous analysis, which will benefit the EMC design in engineering. Full article

The feeder terminal unit (FTU) is a critical component of any electric power system that works in a complex electromagnetic environment. However, innovative research of theoretical analysis of electromagnetic–thermal practices inside the FTU system is missing in the literature. This work presents the theoretical methodologies for calculating and analyzing the electromagnetic–thermal influence of FTUs in a high-power electromagnetic (HPEM) environment. The numerical outcomes reveal that the surface of the FTU and connecting cables under powerful electromagnetic pulses (EMP) induce significant electromagnetic fields and high temperatures. Significantly, the electromagnetic pulse and injection of heat through the wires into the FTU may cause interference and possibly damage to the FTU’s circuits and electronics. This work serves as a reference for electromagnetic compatibility (EMC) design of FTUs and provides numerical analysis for ensuring the normal operation of FTU devices under harsh electromagnetic environments. Full article

Newly constructed devices must meet a number of requirements in terms of the level of generated disturbances. To achieve an acceptable level in such devices, filters are installed—one of the cheapest ways to reduce interference in devices. One of the key elements of the filter that is responsible for the effectiveness of noise reduction are ferrites. Unfortunately, for various devices, an individual approach should be used in the selection of filters and, accordingly, ferrites. Due to the fact that ferrites from different manufacturers do not have standardized characteristics and information on their effectiveness, the selection of the right ferrite is a very time-consuming process. Therefore, this article will present the possibilities of quickly determining selected ferrite parameters in order to ensure the necessary level of noise reduction. For this purpose, assumptions from the CISPR 17 standard will be used. For selected types of ferrites, a large number of measurements were carried out in order to determine the optimal computational algorithm for adjusting ferrite characteristics to the designed conditions. The performance of these tests will be the basis for conducting tests on a larger number of ferrites, as well as for the development of possible standardization procedures. Full article

Random Pulse Width Modulation (RPWM) allows controlling the switching signal of power converters in order to reduce the harmonic peaks by spreading the noise spectrum. Currently, many manufacturers of power converters are deploying this modulation scheme in order to comply with Electromagnetic Compatibility (EMC) test requirements. However, when the converters coexist with Power Line Communication (PLC) systems, such as in Smart Grid (SG) applications, resorting to RPWM needs further investigations since it potentially affects the communication channel by increasing the bit error rate. This possible detrimental effect is investigated in this work, by considering a PLC system for automatic meter reading (AMR) implemented in a SG application. To this end, the model of a complete PLC system is implemented in SIMULINK, and Quadrature Phase Shift Keying (QPSK) modulation is used to model the PLC modems in the communication channel. Results show that, even if the deployment of RPWM techniques may lead to an appreciable reduction/spreading of the peaks in the noise spectrum, it may also lead to an increase of the bit error rate on the PLC system. Full article

Common mode (CM) electromagnetic interference (EMI) has been a difficult subject in electromagnetic compatibility (EMC) analysis and design of power converters for electric vehicles (EV) because of its complex formation mechanism and hidden propagation path. This paper studies a new mechanism of CM conducted emission caused by the leakage flux of a toroidal inductor in the main circuit of a boost DC/DC converter. The stray magnetic source and the CM inducted loops are firstly identified out by simulation analysis and experiments. Then a comprehensive conducted emission circuit model including magnetic coupling parameters is built to explain this CM EMI formation mechanism. Finally, several effective magnetic coupling suppression methods are proposed and verified, such as changing the installation angle of the inductor and the shape of the magnetic core. The research results are helpful to the EMC understanding and design of power electronic converters. Full article

Power Factor Correction (PFC) single-phase AC/DC converters are used in several power electronics applications as full wave control rectifiers improving power quality and providing high standards of efficiency. Many papers dealing with the description or use of such topologies have been published in recent years; however, a review that describes and organizes their specific details has not been reported in the technical literature. Therefore, this paper presents an extensive review of PFC single-phase AC/DC converters operating with the Boost converter topology for low and medium voltage as well as and power appliances. A categorization of bridge, semi-bridgeless, and bridgeless, in accordance with the construction characteristics, was carried out in order to unify the technical terminology. Benefits and disadvantages are described and analyzed in detail. Furthermore, a comparison performance in terms of PFC, Total Harmonic Distortion (THD), power capacity, electromagnetic compatibility (EMC), number of elements, and efficiency is included. Full article

In this work, we analyze the impact of output filter design techniques aimed to reduce conducted emissions at the output of a DCDC power converter. A thorough analysis, based on high-frequency circuit models of the converter, is performed to assess expected improvements offered by different design strategies. This analysis is then confronted with measurements of conducted emissions at the output of a 300 W 48 V to 12 V Phase Shift Full Bridge (PSFB) prototype. Those experimental results demonstrate that a symmetric arrangement of the output LC filter and a direct bonding of the return output terminal of the converter to chassis are effective to reduce common mode conducted emissions at the output. Those results also demonstrate that the symmetry of the output LC filter can reduce conducted emissions in differential mode at high frequencies, where common mode to differential mode conversion is the predominant contribution to differential mode noise. However, direct bonding to chassis of the return output terminal may be ineffective at high frequencies due to the parasitic inductance associated with this connection. Main conclusions drawn for this analysis are applicable in general for isolated converters with a high voltage step between high and low voltage sides. Since the techniques of reduction of conducted emissions studied here do not increase the number of filter components, they are especially suitable for applications where high power density is an important requirement, e.g., aerospace or automotive applications. Full article
