Long-term ECMOs are expected to be put into practical use in order to prepare for the next emerging severe infectious diseases after the novel coronavirus pandemic in 2019–2023. While polypropylene (PP) and polymethylpentene (PMP) are currently the mainstream materials for the hollow fiber membranes of ECMO, the PP membrane coated with a silicone layer on the outer surface has also been commercialized. In this study, we sought a method to accurately observe the detailed pore morphologies of the PP membrane by suppressing irreversible changes in the morphology in SEM observation, which is a general-purpose observation with higher resolution. As a result, the convex surface morphologies of the PP membrane, which was a non-conductive porous structure, were confirmed in detail by utilizing the lower secondary electron image (LEI) mode (FE-SEM, JSM-7610F, JEOL Ltd., Tokyo, Japan) at low acceleration voltage, low magnification, and long working distance, to minimize morphological alterations caused by osmium (Os) sputtering. On the other hand, although the sputter-coating on non-conductive samples is mandatory for imaging morphologies with SEM, the non-sputtering method is also worthwhile for porous and fragile structures such as this sample to minimize morphological alterations. Furthermore, we propose a method to confirm the morphology of the deep part of the sample by utilizing the secondary electron image (SEI) mode at an appropriate acceleration voltage and high magnification with higher resolution. Full article

Hemodialysis (HD) is a critical treatment for patients with end-stage kidney disease (ESKD). The effectiveness of conventional dialyzers used there could be compromised during extended use due to limited blood compatibility of synthetic polymeric membranes and sub-optimal dialyzer design. In fact, blood flow in the hollow fiber (HF) membrane could trigger inflammatory responses and thrombus formation, leading to reduced filtration efficiency and limiting therapy duration, a consequence of flowing the patients’ blood through the lumen of each fiber while the dialysate passes along the inter-fiber space (IOF, inside-out filtration). This study investigates the development of HF membranes for “outside-in filtration” (OIF) in HD. In OIF, blood flows through the inter-fiber space while dialysate flows within the fiber lumens, reducing the risk of fiber clogging and potentially extending treatment duration. For the OIF mode, the membrane should have a blood-compatible outer selective layer in contact with the patient’s blood. We develop HFs for OIF via liquid-induced phase separation using PES/PVP (polyethersulphone/polyvinylpyrrolidone) blends. The fibers’ surface morphology (SEM, scanning electron microscopy), chemistry (ATR-FTIR—attenuated total reflection-Fourier transform infrared spectroscopy, XPS—X-ray photoelectron spectroscopy), transport properties, and uremic toxin removal from human plasma are evaluated and compared to commercial HFs. These membranes feature a smooth, hydrophilic outer layer, porous lumen, ultrafiltration coefficient of 13–34 mL m² h⁻¹ mmHg⁻¹, adequate mechanical properties, low albumin leakage, and toxin removal performance on par with commercial membranes in IOF and OIF. They offer potential for more efficient long-term HD by reducing clogging and systemic anticoagulation needs and enhancing treatment time and toxin clearance. Full article

The influence of the molecular weight and chemical structure of polyphenylene sulfone (PPSU) end groups on the formation of the porous structure of ultrafiltration (UF) hollow fiber membranes was investigated. Polymers with a molecular weight ranging from 67 to 81 kg/mol and with a hydroxyl-to-chlorine end group ratio ranging from 0.43 to 17.0 were synthesized. The excess of end groups was achieved during polymer synthesis by adding one of the following monomers: hydroxyl (excess DHBP) or chlorine (excess DCDPS). For the first time, it was found that the stability of PPSU solutions is determined not by the molecular weight of the polymer, but by the chemical structure of its end groups. The stability of polymer solutions increases with the increasing proportion of chlorine groups. The SEM method showed that with the increasing molar fraction of chlorine end groups in the polymer, a more open porous structure forms on the outer surface of the hollow fiber membranes derived from it. The maximum UF permeance of the hollow fiber membranes for water was achieved with the PPSU sample containing the highest chlorine end group content, amounting to 136 L/(m²·h·bar), with a high rejection of the model substance Blue Dextran (at 94.7%). This represents the best result currently reported among unmodified PPSU hollow fiber membranes. Full article

The relevance of the hemodialysis procedure is increasing worldwide due to the growing number of patients suffering from chronic kidney disease. Taking into account the structure of dialysis polymer membranes is an important aspect in their development to achieve the required performance of hemodialyzers. We propose a new mathematical model of mass transfer that allows hollow-fiber membrane structural parameters to be taken into account in simulating the clearance (CL) of hemodialyzers in a way that does not require difficult to achieve close approximation to the exact geometry of the membrane porous structure. The model was verified by a comparison of calculations with experimental data on $CL$ obtained using a lab-made dialyzer as well as commercially available ones. The simulations by the model show the non-trivial behavior of the dialyzer clearance as a function of membrane porosity ($f_p$) and the arrangement of pores ($\alpha$). The analysis of this behavior allows one to consider two strategies for increasing the $CL$ of the dialyzer by optimizing the polymer membrane structure: (1) creating a membrane with a well-structured pore system (where $\alpha$ → 1) since doubling $\alpha$ at a high enough $f_p$ can lead to an almost tenfold increase in $CL$; (2) increasing the porosity of the membrane characterized by a random arrangement of pores ($\alpha$ → 0), where, at a relatively low $\alpha$, a sharp increase in $CL$ is observed with a small increase in $f_p$ over a certain threshold value. Full article

This study explores the layer-by-layer (LBL) modification of polyacrylonitrile (PAN) hollow fibers for effective Mg²⁺/Li⁺ separation. It employs an LBL method of surface modification using polyelectrolytes, specifically aiming to enhance ion selectivity and improve the efficiency of lithium extraction from brines or lithium battery wastes, which is critical for battery recycling and other industrial applications. The modification process involves coating the hydrolyzed PAN fibers with alternating layers of positively charged polyelectrolytes, such as poly(allylamine hydrochloride) (PAH), polyethyleneimine (PEI), or poly(diallyldimethylammonium chloride) (PDADMAC) and negatively charged polyelectrolytes, such as poly(styrene sulfonate) (PSS), to form polyelectrolyte multilayers (PEMs). This study evaluates the modified membranes in Mg²⁺ and Li⁺ salt solutions, demonstrating significant improvements in selectivity for Mg²⁺/Li⁺ separation. PAH was identified as the optimal positively charged polyelectrolyte. PAN hollow fibers modified with ten bilayers of PAH/PSS achieved rejection rates of 95.4% for Mg²⁺ ions and 34.8% for Li⁺ ions, and a permeance of 0.39 LMH/bar. This highlights the potential of LBL techniques for effectively addressing the challenges of ion separation across a variety of applications. Full article

A membrane condenser (MC) is a novel membrane separation technology that utilizes the hydrophobic nature of porous membranes to capture water vapor from humid gas. Factors such as temperature, pressure, flow rate, and gas composition entering the membrane condenser play a crucial role in water recovery efficiency. This study utilized hydrophobic polytetrafluoroethylene (PTFE) hollow fiber membranes to create multiple identical membrane modules. This research investigated the impact of temperature, flow rate, pressure on the intake side, gas flow on the cooling side, membrane area, and other variables on the performance of the membrane condenser process. This study compared water extraction efficiency under different conditions, focusing on feed flow temperature and sweeping flow. Results showed that at a temperature of 60 °C, the water recovery rate was 24.7%, while a sweep gas flow rate of 4 L/min resulted in a recovery rate of 22.7%. The efficiency of the membrane condenser decreased with higher feed flow rates but increased with larger membrane areas. A proportional relationship between inlet flow and membrane area was observed, suggesting an optimal range of 0.51–0.67 cm/s for both parameters. These findings offer valuable insights for the practical implementation of hydrophobic membrane-based membrane condenser technology. Full article

To solve the problem of water carryover in the supercritical CO₂ separation and mining process in the CO₂ plume geothermal system, a three-dimensional shell-tube hollow fiber membrane absorption separator is designed in this study. A coupled species transport model, a porous medium model, and an absorption mathematical model are established, and the flow field and separation characteristics in the circular and flat tubes are analyzed using numerical simulation. The results show that the membrane separation efficiency increases with an increase in the flatness and membrane tube length. When the inlet velocity of the mixture is 0.1 m/s, the separation efficiency can reach 75.92%. Selecting a smaller flow Reynolds number and a more significant membrane tube flatness will reduce the water mass fraction at the outlet. When adding baffles of different shapes to the membrane tube, the mixture fluid in the membrane tube meanders forward and flows in the shape of “Z” under the blocking effect of the arcuate baffles. With an increase in the number of arcuate baffles in the membrane tube, the membrane separation efficiency of the separator increases continuously. The mixture fluid flows in the membrane tube with the built-in torsional baffles in a spiral manner, and the separation efficiency of the membrane separator increases with a torsion ratio reduction in the membrane tube. Full article

An extracorporeal blood purification method called continuous renal replacement therapy uses a porous hollow-fiber polymeric membrane that is exposed to prolonged contact with blood. In that condition, like with any other submerged filtration membrane, the hemofilter loses its properties over time and use resulting in a rapid decline in flux. The most significant reason for this loss is the formation of a biofilm. Protein, blood cells and bacterial cells attach to the membrane surface in complex and fluctuating processes. Anticoagulation allows for longer patency of vascular access and a longer lifespan of the membrane. Other preventive measures include the modification of the membrane itself. In this article, we focused on the role of nanoadditives in the mitigation of biofouling. Nanoparticles such as graphene, carbon nanotubes, and silica effectively change surface properties towards more hydrophilic, affect pore size and distribution, decrease protein adsorption and damage bacteria cells. As a result, membranes modified with nanoparticles show better flow parameters, longer lifespan and increased hemocompatibility. Full article

Polysulfone (PSF) is one of the most used polymers for water treatment membranes, but its intrinsic hydrophobicity can be detrimental to the membranes’ performances. By modifying a membrane’s surface, it is possible to adapt its physicochemical properties and thus tune the membrane’s hydrophilicity or porosity, which can achieve improved permeability and antifouling efficiency. Atomic layer deposition (ALD) stands as a distinctive technology offering exceedingly even and uniform layers of coatings, like oxides that cover the surfaces of objects with three-dimensional (3D) shapes, porous structures, and particles. In the context of this study, the focus was on titanium dioxide (TiO2), zinc oxide (ZnO), and alumina (Al₂O₃), which were deposited on polysulfone hollow fiber (HF) membranes via ALD using TiCl₄, diethyl zinc (DEZ), and trimethylamine (TMA), respectively, and H₂O as precursors. The morphology and mechanical properties of membranes were changed without damaging their performances. The deposition was confirmed mainly by energy-dispersive X-ray spectroscopy (EDX). All depositions offered great performances with a maintained permeability and BSA retention and a 20 to 40° lower water contact angle (WCA) than the raw PSF HF membrane. The deposition of TiO₂ offered the best results, showing an enhancement of 50% for the water permeability and 20% for the fouling resistance of the PSF HF membranes. Full article

Patients with end-stage kidney disease (ESKD) suffer from high levels of protein-bound uremic toxins (PBUTs) that contribute to various comorbidities. Conventional dialysis methods are ineffective in removing these PBUTs. A potential solution could be offered by a bioartificial kidney (BAK) composed of porous membranes covered by proximal tubule epithelial cells (PTECs) that actively secrete PBUTs. However, BAK development is currently being hampered by a lack of knowledge regarding the cytocompatibility of the dialysis fluid (DF) that comes in contact with the PTECs. Here, we conducted a comprehensive functional assessment of the DF on human conditionally immortalized PTECs (ciPTECs) cultured as monolayers in well plates, on Transwell^® inserts, or on hollow fiber membranes (HFMs) that form functional units of a BAK. We evaluated cell viability markers, monolayer integrity, and PBUT clearance. Our results show that exposure to DF did not affect ciPTECs’ viability, membrane integrity, or function. Seven anionic PBUTs were efficiently cleared from the perfusion fluid containing a PBUTs cocktail or uremic plasma, an effect which was enhanced in the presence of albumin. Overall, our findings support that the DF is cytocompatible and does not compromise ciPTECs function, paving the way for further advancements in BAK development and its potential clinical application. Full article

The first commercial hollow fiber and flat sheet gas separation membranes were produced in the late 1970s from the glassy polymers polysulfone and poly(vinyltrimethyl silane), respectively, and the first industrial application was hydrogen recovery from ammonia purge gas in the ammonia synthesis loop. Membranes based on glassy polymers (polysulfone, cellulose acetate, polyimides, substituted polycarbonate, and poly(phenylene oxide)) are currently used in various industrial processes, such as hydrogen purification, nitrogen production, and natural gas treatment. However, the glassy polymers are in a non-equilibrium state; therefore, these polymers undergo a process of physical aging, which is accompanied by the spontaneous reduction of free volume and gas permeability over time. The high free volume glassy polymers, such as poly(1-trimethylgermyl-1-propyne), polymers of intrinsic microporosity PIMs, and fluoropolymers Teflon^® AF and Hyflon^® AD, undergo significant physical aging. Herein, we outline the latest progress in the field of increasing durability and mitigating the physical aging of glassy polymer membrane materials and thin-film composite membranes for gas separation. Special attention is paid to such approaches as the addition of porous nanoparticles (via mixed matrix membranes), polymer crosslinking, and a combination of crosslinking and addition of nanoparticles. Full article

For the first time, polysulfones (PSFs) were synthesized with chlorine and hydroxyl terminal groups and studied for the task of producing porous hollow fiber membranes. The synthesis was carried out in dimethylacetamide (DMAc) at various excesses of 2,2-bis(4-hydroxyphenyl)propane (Bisphenol A) and 4,4′-dichlorodiphenylsulfone, as well as at an equimolar ratio of monomers in various aprotic solvents. The synthesized polymers were studied by nuclear magnetic resonance (NMR), differential scanning calorimetry, gel permeation chromatography (GPC), and the coagulation values of 2 wt.% PSF polymer solutions in N-methyl-2-pyrollidone were determined. According to GPC data, PSFs were obtained in a wide range of molecular weights M_w from 22 to 128 kg/mol. NMR analysis confirmed the presence of terminal groups of a certain type in accordance with the use of the corresponding monomer excess in the synthesis process. Based on the obtained results on the dynamic viscosity of dope solutions, promising samples of the synthesized PSF were selected to produce porous hollow fiber membranes. The selected polymers had predominantly –OH terminal groups and their molecular weight was in the range of 55–79 kg/mol. It was found that porous hollow fiber membrane from PSF with M_w 65 kg/mol (synthesized in DMAc with an excess of Bisphenol A 1%) has a high helium permeability of 45 m³/m²∙h∙bar and selectivity α (He/N₂) = 2.3. This membrane is a good candidate to be used as a porous support for thin-film composite hollow fiber membrane fabrication. Full article

For the first time, we have successfully fabricated microfiltration (MF) hollow fiber membranes by the thermally induced phase separation (TIPS) and non-solvent induced phase separation (NIPS) methods using cellulose acetate benzoate (CBzOH), which is a cellulose derivative with considerable chemical resistance. To obtain an appropriate CBzOH TIPS membrane, a comprehensive solvent screening was performed to choose the appropriate solvent to obtain a membrane with a porous structure. In parallel, the CBzOH membrane was prepared by the NIPS method to compare and evaluate the effect of membrane structure using the same polymer material. Prepared CBzOH membrane by TIPS method showed high porosity, pore size around 100 nm or larger and high pure water permeability (PWP) with slightly low rection performance compared to that by NIPS. On the contrary, CBzOH membranes prepared with the NIPS method showed three times lower PWP with higher rejection. The chemical resistance of the prepared CBzOH membranes was compared with that of cellulose triacetate (CTA) hollow fiber membrane, which is a typical cellulose derivative as a control membrane, using a 2000 ppm sodium hypochlorite (NaClO) solution. CBzOH membranes prepared with TIPS and NIPS methods showed considerable resistance against the NaClO solution regardless of the membrane structure, porosity and pore size. On the other hand, when the CTA membrane, as the control membrane, was subjected to the NaClO solution, membrane mechanical strength sharply decreased over the exposure time to NaClO. It is interesting that although the CBzOH TIPS membrane showed three times higher pure water permeability than other membranes with slightly lower rejection and considerably higher NaClO resistance, the mechanical strength of this membrane is more than two times higher than other membranes. While CBzOH samples showed no change in chemical structure and contact angle, CTA showed considerable change in chemical structure and a sharp decrease in contact angle after treatment with NaClO. Thus, CBzOH TIPS hollow fiber membrane is noticeably interesting considering membrane performance in terms of filtration performance, mechanical strength and chemical resistance on the cost of slightly losing rejection performance. Full article

In this work, PPSUs with different molecular weights were synthesized for the development of highly permeable ultrafiltration hollow fiber membranes for the first time. The M_W of the synthesized polymers was controlled by varying the monomers molar ratio within 1:1–1.15 under the same synthesis conditions. Based on the study of the rheological properties of polymer solutions, a high molecular weight PPSU (M_W = 102,000 g/mol) was chosen for the formation of hollow fiber membranes. The addition of PEG400 to the spinning solution led to an increase in viscosity, which makes it possible to work in the region of lower PPSU concentrations (18–20 wt. %) and to form membranes with a less dense porous structure. With the addition of PEG400 to the spinning solution, the membrane permeance increased sharply by more than two orders of magnitude (from 0.2 to 96 L/m²·h bar). At the same time, the membranes had high rejection coefficients (99.9%) of Blue Dextran model filtered substance (M_W = 69,000 g/mol). Full article

Due to its greater physical–chemical stability, ceramic nanofiltration (NF) membranes were used in a number of industrial applications. In this study, a novel NF membrane was prepared by co-depositing a titanium dioxide (TiO₂) and graphene oxide (GO) composite layer directly onto a porous α-Al₂O₃ hollow fiber (HF) support. An 8 µm-thick TiO₂/GO layer was deposited to the surface of α-Al2O3 HF support by vacuum deposition method to produce advanced TiO₂/GO-Al₂O₃ HF NF membrane. Scanning electron microscope (SEM) micrographs, energy dispersive spectrometer (EDS), X-ray powder diffraction (XRD), thermogravimetric analyzer (TGA), porosity, 3-point bending strength, zeta potential analysis, and hydrophilic properties by water contact angle are used for TiO₂/GO-Al₂O₃ HF NF membrane characterization. The results show that the developed membrane’s MWCO ranged from 600 to 800 Da. The water flux, rejection of lignin, and sodium ions were 5.6 L/m² h·bar, ~92.1%, and ~5.5%, respectively. In a five-day NF process, the TiO₂/GO-Al₂O₃ HF NF membrane exhibits good lignin permeation stability of about 14.5 L/m² h. Full article
