Pin arrangement significantly affects rubber-melt mixing and extrusion in pin-barrel cold-feed extruders. However, internal flow details are difficult to observe experimentally, and efficient prediction of flow-field parameters remains unavailable. This study used a finite-element model preliminarily validated against measured temperatures, together with particle tracing, to compare configurations with 0, 2, 4, and 6 pins per group. A dataset of 140 pin arrangements was generated by Latin hypercube sampling and numerical simulation. A mind evolutionary algorithm-optimized back-propagation neural network (MEA-BP) was then developed to predict melt volume-averaged temperature and average shear rate. Pins increased melt velocity and shear heating and improved cross-sectional temperature uniformity. Among the four uniform configurations, the 4-pin-per-group configuration showed the fastest reduction in segregation scale with a moderate residence time, achieving a favorable balance between mixing adequacy and processing efficiency. Particle tracing indicated repeated fluid splitting and recombination, whereas further increases in the number of pins yielded limited benefits. Under identical data partitions, network settings, and evaluation conditions, MEA-BP achieved R² values of 0.957 and 0.872 for temperature and shear-rate prediction, respectively, outperforming GA-BP, PSO-BP, and conventional BP. Full article

Background: Stabilization of surgical guides in fully edentulous patients remains a clinical challenge due to mucosal resilience and potential micromovement, even when fixation pins are used. Guide instability may affect drilling accuracy and overall workflow predictability. This proof-of-concept case series describes a stabilization approach based on pre-placed tripod reference implants with multi-unit coupling, designed to create a mechanically defined prosthetic docking platform for fully guided implant surgery. Methods: Three fully edentulous patients requiring implant-supported rehabilitation were treated using a two-stage protocol. Three temporary reference implants were inserted in a tripod configuration 7–10 days prior to definitive surgery. Multi-unit abutments were mounted on the reference implants, and intraoral scanning was performed to design a surgical guide indexed to the prosthetic interfaces. During implant placement, the guide was screw-retained to the reference implants via the multi-unit connections. Postoperative implant positions were evaluated radiographically by superimposing postoperative datasets onto the preoperative planning model. Intraoperative guide stability, surgical events, and early postoperative outcomes were recorded. Results: Stable guide fixation was achieved in all three cases without detectable intraoperative displacement. Implant placement was completed as planned in each patient, and removal of the temporary reference implants was uneventful. No intraoperative or early postoperative complications were observed. Mean coronal, apical, and angular deviations between planned and achieved implant positions were 0.70 ± 0.16 mm, 0.39 ± 0.13 mm, and 3.30 ± 0.59°, respectively. These preliminary findings, derived from four treated arches, were comparable to ranges reported in selected studies on fully guided implant surgery; however, no direct statistical comparison with previously published datasets was performed. Conclusions: Within the limitations of this proof-of-concept case series, temporary reference implants arranged in a tripod configuration provided a stable and reproducible prosthetic indexing platform for guided implant surgery in fully edentulous patients. Further prospective studies involving larger patient cohorts and controlled comparative designs with conventional mucosa-supported or fixation-pin-supported surgical guides are required to evaluate the reproducibility, clinical performance, and long-term applicability of this stabilization concept. Full article

Dense direct-current (DC) bias routing and numerous radio-frequency (RF) choke inductors pose major challenges to the practical implementation of phase-shifter-free beam steering using PIN-controlled phase switching. To address this issue, a compact vertical DC biasing network is proposed, in which most DC bias lines are routed beneath the ground plane. The DC signals are fed to the PIN diodes through vertical bias lines passing through metallized vias in the dielectric substrate. This arrangement reduces routing congestion and simplifies array-level bias integration. The number of required RF choke inductors is decreased from 112 to 22 per dual-polarized element while preserving the required beam-steering functionality. For experimental validation, a 1 × 3 prototype operating at 3.5 GHz is fabricated and measured. The measured beam directions of −14°, 0°, and +14° agree well with simulations, confirming that the proposed bias network provides the phase control required for beam steering. The proposed network, therefore, offers a compact, low-complexity, and practical solution for scalable phase-shifter-free beam-steering systems. Full article

A compact dual-polarized beam-steerable patch antennas with filtering characteristics is proposed in this paper. By digging two orthogonal coupling slots on the ground plate, dual polarization is achieved while ensuring the isolation between the ports. By constructing properly arranged parallel microstrip resonators and open-circuited stubs, the effect of suppressing a broad stopband is produced. The beam steering characteristic is accomplished through the integration of a driven patch antenna with two dual-element metallic walls, each incorporating PIN diodes for electronic tuning. A prototype antenna has been fabricated to substantiate the efficacy of the proposed methodology. The simulated and measured results agree well, demonstrating good performance in terms of impedance bandwidth, stopband suppression, isolation and beam-steering capability. Under six radiation states, the proposed antenna operates from 2.3 GHz to 2.5 GHz with isolation exceeding 20 dB. Additionally, the antenna gain remains below −10 dBi over the 2.6 GHz to 10 GHz band, achieving out-of-band suppression greater than 15.8 dB within the wide stopband. When port 1 is excited, the antenna generates three distinct radiation patterns, enabling beam scanning at 0° and ±30° in the yoz plane. Similarly, exciting port 2 yields three radiation patterns, allowing beam scanning at 0° and ±30° in the xoz plane. This work presents the first integration of dual-polarized, beam-steering, and filtering characteristics into a single compact antenna. Full article

The Support System with Vertical Retractable Mechanism (SSVRS) is an advancement in telescopic technology that replaces continuous threaded or fluid-dependent interfaces with an internal stepped mechanism based on geometric mechanical interference. This coaxial design uses an integrated pin that engages with discrete grooves, enabling rapid height adjustments and positioning speeds that are significantly faster than those of traditional mechanisms. Unlike friction-based systems that are prone to slipping under dynamic loads, the SSVRS provides millimeter-level precision and exceptional stability, even in vibrational environments. The SSVRS’s versatility stems from its parametric modular design, which scales from lightweight domestic fixtures to heavy-duty industrial machinery by customizing material selection—ranging from high-strength steel to glass fiber-reinforced nylon—and slot configuration. Specifically, vertical slot arrangements facilitate rapid movement, and spiral geometries allow for high-precision alignment. Furthermore, the SSVRS optimizes long-term operational efficiency and sustainability through low maintenance requirements, minimal moving parts, and the use of recyclable materials. By combining high-speed positioning, robust structural integrity, and adaptive modularity, the SSVRS provides a high-performance, concrete alternative to current mainstream linear modules and traditional support structures. Full article

This paper proposes a frequency-reconfigurable and active beam-switching antenna based on an X-shaped slot array integrated with a diode-based switching network. The proposed antenna features four slots arranged at 90° intervals around the feed point. Each slot is integrated with two PIN diodes and one varactor diode. By selectively activating a specific slot through the PIN diodes, the radiation pattern can be switched in four directions at 90° intervals. Dual-band operation is achieved using varactor diodes, and by controlling their equivalent capacitance, the antenna covers two operating bands: a low-frequency band with a 29.51% bandwidth (2.6–3.5 GHz) and a high-frequency band with a 24.52% bandwidth (3.65–4.67 GHz). These frequency ranges include the 5G sub-6 GHz bands, specifically n77 and n78. Experimental results confirm stable beam-switching performance across the entire operating frequency range. Full article

To reduce mold costs in composite forming, multi-point tooling technology has been integrated into the hot diaphragm forming process. However, this approach still faces several challenges, including time-consuming prepreg layup, high energy consumption, and poor surface quality. This study proposes a heating pad-assisted multi-point thermoforming process: the prepreg is embedded in the thermal functional layers, placed on the lower mold, and formed via the downward movement of the upper mold to accomplish mold closure. Instead of the conventional rectangular array, this study adopted multi-point tooling with a hexagonal pin arrangement. Compared to traditional configurations, this hexagonal layout increases the punch support area by 9.8%, while its dense punch arrangement improves the accuracy of the molded curved surface. Taking a saddle-shaped surface as the target, a prototype part was fabricated. Subsequent analysis of the part’s surface quality identified three defects: dimples, fiber distortion, and ridge protrusions. The surface dimples were eliminated by adjusting the distance between the upper and lower molds. Notably, ridge protrusion is a defect unique to the hexagonal pin arrangement. We conducted a detailed analysis of its causes and solutions, finding that this defect arises from the combined effect of the pin arrangement and the saddle-shaped surface. Through a series of height compensation experiments, the maximum deviation at the ridges was reduced from 0.46 mm to approximately 0.35 mm, which is consistent with the deviation of defect-free areas. This work demonstrates that the multi-point hot-pressing process provides a potential, efficient, and low-cost method for manufacturing double-curvature composite components, whose effectiveness has been verified through the saddle-shaped case study. Full article

A simple self-decoupling approach using only a shorting pin is proposed to effectively reduce mutual coupling in multiple-input multiple-output patch antennas. By loading a shorting pin along the polarization direction on one side of the patch antenna, the equivalent inductance of the corresponding source is altered, thereby changing the initial phase of the slot source. This modification, in conjunction with the path effect, creates a mutual coupling null by counteracting the electric fields at the adjacent patch’s feeding position, achieving a reduced mutual coupling level. The simplicity of this decoupling method enables flexibility in practical applications, facilitating adaptation to diverse packaging environments and substrates. Furthermore, the proposed method effectively suppresses mutual coupling between adjacent and non-adjacent elements in multi-element linear arrays, as well as between elements arranged along E-planes and H-planes in planar arrays. To validate the effectiveness of this self-decoupling technique, a two-element decoupled antenna was fabricated and measured. Experimental results demonstrate a decrease in mutual coupling from −22 dB to below −40 dB across the effective frequency range of 4.809 GHz to 4.984 GHz. Full article

The measurement accuracy and equipment stability of superposition-type force sensors are primarily influenced by the layout and number of individual force sensors. Analyzing this impact effect through experimental testing for each configuration would consume significant manpower, material resources, and financial costs. To efficiently analyze the influence of the number of paralleled individual sensors and their layout within a superposition-type force measurement instrument on overall device stability and force measurement accuracy, this paper employs SolidWorks to establish models of force instruments based on common superposition schemes. Subsequently, ANSYS is utilized to perform finite element analysis on models of different schemes, obtaining corresponding data on total deformation, stress, and simulated force values. The analysis results indicate that a relatively sparse sensor layout with symmetric arrangement around the center point of the base plate enhances overall stability, and the force measurement error can be controlled within several ten-thousandths. Furthermore, the more stable and higher-accuracy schemes identified through simulation analysis were compared with practical experimental results to analyze theoretical versus actual errors. The test results showed that when the three single force sensors are placed in a “Pin font” shape, the sum of the forces measured by each individual sensor differs from the sum of the forces measured by the superimposed sensors by only a few ten-thousandths, which is within the acceptable range. Full article

This paper presents the design and development of a reconfigurable circular array antenna capable of producing ten distinct radiation beams, intended for wireless systems in the sub-6 GHz frequency band. The antenna structure is based on four pentagon-shaped radiating elements arranged symmetrically around a central circular patch, which is excited through a coaxial feed. These radiating elements are linked by four circular segments, ensuring mutual coupling for effective operation. A systematic dimensional analysis has been conducted to optimize electromagnetic performance, resulting in a compact and efficient architecture. The beam reconfiguration is achieved through the control of four PIN diodes, which allow the main radiation beam to switch among ten different orientations in the azimuth plane. Specifically, the antenna supports eight directional states, oriented at 45° intervals, and two additional bidirectional states covering opposite directions. A prototype has been fabricated and experimentally validated, confirming the steering capability of ±40° in both the XZ and YZ planes. Performance evaluation shows a maximum gain of 9.29 dBi and efficiency levels ranging from 91% to 97%. Bandwidth varies across states, with 9.72% for S1–S7, 7.45% for S2–S8, and 4.61% for S9–S10. Overall, the proposed design demonstrates optimized bandwidth, gain, efficiency, and complete azimuthal coverage. Full article

In recent years, replacing the scarce and expensive rare earth element Nd with the more abundant and lower cost Ce in the production of Nd-Ce-Fe-B permanent magnets has become a focus of both industrial and academic research. A critical challenge is how to design the crystal structure of Nd-Ce-Fe-B magnets to compensate for the decline in magnetic performance caused by the Ce substitution. In this study, based on micromagnetic theory, Nd-Ce-Fe-B magnets with perpendicularly oriented easy axes—in which the two main phases, Nd₂Fe₁₄B and Ce₂Fe₁₄B, have a volume ratio of 1:1 but different spatial arrangements—are modeled and simulated using the MuMax3.11 software. The model is either cubic or spherical. The results from the demagnetization curve analysis indicate that the coercivity mechanism of all magnets is pinning. When the magnet volume is constant but the phase distribution differs, the Nd₂Fe₁₄B/Ce₂Fe₁₄B structure exhibits a higher coercivity and maximum energy product than the Ce₂Fe₁₄B/Nd₂Fe₁₄B structure. Furthermore, for both structural models with the same phase distribution, the coercivity and the maximum energy product decrease with the increasing volume of the main phase. Notably, the coercivity is similar when the magnet volume is very small and stabilizes after reaching a certain threshold. This qualitative conclusion was also observed in Nd-Dy-Fe-B magnets with the same structure and equal volume ratio of the two main phases. This general finding indicates that, in biphasic magnets with equal phase volumes, the phase with the larger anisotropy field located at the grain periphery can achieve a higher coercivity and maximum magnetic energy product. The analysis of the angular distribution reveals that the number of magnetic domains remains fixed at six in the Nd₂Fe₁₄B/Ce₂Fe₁₄B structure and two in the Ce₂Fe₁₄B/Nd₂Fe₁₄B structure. The in-plane magnetic moment analysis of the Ce₂Fe₁₄B/Nd₂Fe₁₄B magnet shows that the magnetic moments at the edges of the Ce₂Fe₁₄B begin to deflect first. Even at the pinning stage, the magnetic moments within the Nd₂Fe₁₄B remain unrotated. Nevertheless, the surface magnetic moments of Ce₂Fe₁₄B, through exchange coupling, drive the deflection of the interfacial and interior moments, completing the entire demagnetization process. These computational results provide theoretical guidance for related experimental studies and industrial applications. Full article

This paper presents a highly linear one-bit loaded-line phase shifter that leverages PIN diodes in combination with a coupler-based impedance transformer. The proposed phase shifter adopts a loaded-line topology, where PIN diodes are configured in a parallel-to-ground arrangement to improve linearity performance. To further enhance linearity, a coupler-based impedance transformer is employed to reduce the impedance seen by each PIN diode, thereby minimizing nonlinear behavior. To demonstrate the effectiveness of this design, a one-bit digital phase shifter is developed, simulated, and fabricated to achieve a 45-degree phase shift at 2 GHz. Experimental measurements confirm an input third-order intercept point (IIP3) exceeding 100 dBm under a range of test conditions, validating the proposed architecture’s linearity advantages. Full article

A novel dual-band multi-linear polarization reconfigurable (MLPR) antenna for body-centric wireless communication systems (BWCS) is presented in this paper. The design comprises five symmetrically arranged multi-branch radiating units, each integrating an elliptical patch and curved spring branch for the Medical Implant Communication Service (MICS) band (403–405 MHz), and a pair of orthogonal strip patches for the Industrial, Scientific and Medical (ISM) $2.45$ GHz band (2.40–2.48 GHz). By selectively biasing PIN diodes between each unit and a central pentagonal feed, five distinct LP states with polarization directions of $0^{\circ }$, ${72}^{\circ }$, ${144}^{\circ }$, ${216}^{\circ }$, and ${288}^{\circ }$ are achieved. A dual-line isolation structure is introduced to suppress mutual coupling between radiating units, ensuring cross-polarization levels (XPLs) better than $-15.0$ dB across the operation bands. Prototypes fabricated on a $160\times 160\times 1.5$ mm³ substrate demonstrate measured $|S_{11}|<-10$ dB across 401–409 MHz and 2.34–2.53 GHz and stable omnidirectional patterns despite biasing circuitry perturbations. The compact form and robust dual-band, multi-polarization performance make the proposed antenna a promising candidate for implantable device wake-up signals and on-body data links in dense indoor environments. Full article

Despite advancements in surgical techniques, including the utilization of intra-operative fluoroscopy and custom surgical guides, intra-articular implant placement during the pinning of capital physeal fractures can occur and may result in catastrophic complications. Our objective in this study was to compare the epiphyseal purchase afforded by a linear and triangular pattern of Kirschner wires for stabilizing femoral capital physeal fractures. Archived pelvic limb computed tomography scans of 16 skeletally immature dogs were obtained, from which virtual femoral models were created. Separate linear and triangular arrangements of three virtual 1.6 mm Kirschner wires were centered on the thickest region of the proximal epiphysis. The length of each Kirschner wire implanted within the proximal femoral epiphysis was measured. Kirschner wire placement in triangular and linear patterns resulted in a mean epiphyseal purchase for each wire of 8.4 mm and 8.0 mm, respectively. The cumulative Kirschner wire purchase was greater with the triangular pattern (p = 0.004). The mean difference in the cumulative wire purchase was 1.3 mm. The use of a triangular Kirschner wire pattern resulted in greater implant purchase within the epiphysis compared to the linear pattern. The triangular Kirschner wire pattern may reduce the risk of intra-articular implant placement by more closely centering the wires within the thickest region of the epiphysis. Full article

In order to meet new real-world emissions standards and reduce particulates emitted by GDI engines, automakers are increasingly adopting gasoline particulate filters (GPFs). The uniformity of axial permeation velocity through porous medium in GPFs significantly impacts filtration efficiency. Consequently, a three-dimensional single-channel GPF–CFD model is developed to investigate the impact of partition coatings and pins on flow characteristics. Different coating amounts are compared by adjusting porosity using a single-channel GPF model, with pins strategically placed along the upper and lower sides of the inlet channel. Simulation results indicate that optimizing porosity and length across different coated sections enhances the consistency of axial permeation velocity, particularly when the ratio of coated length falls within the range of 30–40%. Pins reduce the axial variance by increasing permeation velocity near the inlet surface, with a symmetrical arrangement of four pairs and a height of 0.3 mm yielding optimal performance. Moreover, the combination of partitions and pins shows potential to improve maximum homogeneity by approximately 75%. Full article
