Search Results (16)

The Ice, Cloud, and land Elevation Satellite-2 has provided unprecedented global surface elevation measurements through photon-counting Lidar (Light detection and ranging), yet its low signal-to-noise ratio (SNR) poses significant challenges for denoising algorithms. Existing methods, relying on fixed parameters, struggle to adapt to dynamic noise distribution in rugged mountain regions where signal and noise change rapidly. This study proposes an adaptive Bayesian denoising algorithm integrating minimum spanning tree (MST) -based slope estimation and probabilistic parameter optimization. First, a simulation framework based on ATL03 data generates point clouds with ground truth labels under varying SNRs, achieving correlation coefficients > 0.9 between simulated and measured distributions. The algorithm then extracts surface profiles via MST and coarse filtering, fits slopes with >0.9 correlation to reference data, and derives the probability distribution function (PDF) of neighborhood photon counts. Bayesian estimation dynamically selects optimal clustering parameters (search radius and threshold), achieving F-scores > 0.9 even at extremely low SNR (1 photon/10 MHz noise). Validation against three benchmark algorithms (OPTICS, quadtree, DRAGANN) on simulated and ATL03 datasets demonstrates superior performance in mountainous terrain, with precision and recall improvements of 10–20% under high noise conditions. This work provides a robust framework for adaptive parameter selection in low-SNR photon-counting Lidar applications. Full article

The Ice, Cloud, and Land Elevation 2 (ICESat-2) mission uses a micropulse photon-counting lidar system for mapping, which provides technical support for capturing forest parameters and carbon stocks over large areas. However, the current algorithm is greatly affected by the slope, and the extraction of the forest canopy height in the area with steep terrain is poor. In this paper, an improved algorithm was provided to reduce the influence of topography on canopy height estimation and obtain higher accuracy of forest canopy height. First, the improved clustering algorithm based on ordering points to identify the clustering structure (OPTICS) algorithm was developed and used to remove the noisy photons, and then the photon points were divided into canopy photons and ground photons based on mean filtering and smooth filtering, and the pseudo-signal photons were removed according to the distance between the two photons. Finally, the photon points were classified and interpolated again to obtain the canopy height. The results show that the improved algorithm was more effective in estimating ground elevation and canopy height, and the result was better in areas with less noise. The root mean square error (RMSE) values of the ground elevation estimates are within the range of 1.15 m for daytime data and 0.67 m for nighttime data. The estimated RMSE values for vegetation height ranged from 3.83 m to 2.29 m. The improved algorithm can provide a good basis for forest height estimation, and its DEM and CHM accuracy improved by 36.48% and 55.93%, respectively. Full article

The photon point clouds collected by the high-sensitivity single-photon detector on the Ice, Cloud, and Land Elevation Satellite-2 (ICESat-2) are utilized in various applications. However, the discretely distributed noise among the signal photons greatly increases the difficulty of signal extraction, especially the edge noise adjacent to signals. To detect signal photons from vegetation coverage areas at different slopes, this paper proposes a density-based multilevel terrain-adaptive noise removal method (MTANR) that identifies noise in a coarse-to-fine strategy based on the distribution of noise photons and is evaluated with high-precision airborne LiDAR data. First, the histogram-based successive denoising method was used as a coarse denoising process to remove distant noise and part of the sparse noise, thereby increasing the fault tolerance of the subsequent steps. Second, a rotatable ellipse that adaptively corrects the direction and shape based on the slope was utilized to search for the optimal filtering direction (OFD). Based on the direction, sparse noise removal was accomplished robustly using the Otsu’s method in conjunction with the ordering points to identify the clustering structure (OPTICS) and provide a nearly noise-free environment for edge searching. Finally, the edge noise was removed by near-ground edge searching, and the signal photons were better preserved by the surface lines. The proposed MTANR was validated in four typical experimental areas: two in Baishan, China, and two in Taranaki, New Zealand. A comparison was made with three other representative methods, namely differential, regressive, and Gaussian adaptive nearest neighbor (DRAGANN), used in ATL08 products, local distance statistics (LDS), and horizontal ellipse-based OPTICS. The results demonstrated that the values of the F1 score for the signal photon identification achieved by the proposed MTANR were 0.9762, 0.9857, 0.9839, and 0.9534, respectively, which were higher than those of the other methods mentioned above. In addition, the qualitative and quantitative results demonstrated that MTANR outperformed in scenes with steep slopes, abrupt terrain changes, and uneven vegetation coverage. Full article

Due to atmospheric scattering, solar radiation, and other factors, the Ice, Cloud, and land Elevation Satellite-2 (ICESat-2) product data suffer from a substantial amount of background noise. This poses a significant challenge when attempting to directly utilize the raw data. Consequently, data denoising becomes an indispensable preprocessing step for its subsequent applications, such as the extraction of forest structure parameters and ground elevation data. While the Density-Based Spatial Clustering of Applications with Noise (DBSCAN) algorithm is currently the most widely used method, it remains susceptible to complexities arising from terrain, low signal-to-noise ratio (SNR), and input parameter variations. This paper proposes an efficient Multi-Level Auto-Adaptive Noise Filter (MLANF) algorithm based on photon spatial density. Its purpose is to extract signal photons from ICESat-2 terrestrial data of different ground cover types. The algorithm follows a two-step process. Firstly, random noise photons are removed from the upper and lower regions of the signal photons through a coarse denoising process. Secondly, in the fine denoising step, the K-Nearest Neighbor (KNN) algorithm selects the K photons to calculate the slope along the track. The calculated slope is then used to rotate the direction of the searching neighborhood in the DBSCAN algorithm. The proposed algorithm was tested in eight datasets of four surface types: forest, grassland, desert, and urban, and the extraction results were compared with those from the ATL08 datasets and the DBSCAN algorithm. Based on the ground-truth signal photons obtained by visual inspection, the classification precision, recall, and F-score of our algorithm, as well as two other algorithms, were calculated. The MLANF could achieve a good balance between classification precision (97.48% averaged) and recall (97.96% averaged). Its F-score (97.69% averaged) was higher than that of the other two methods. This demonstrates that the MLANF algorithm successfully obtained a continuous surface profile from ICESat-2 datasets with different surface cover types, significant topographic relief, and low SNR. Full article

The Ice, Cloud, and Land Elevation Satellite-2 (ICESat-2) is equipped with the Advanced Topographic Laser Altimeter System (ATLAS), which can achieve high-precision ground detection. However, due to its low pulse energy and high sensitivity, it is also affected by noise when obtaining data. Therefore, data denoising is critical to the subsequent processing and application. In this study, a multilevel filtering algorithm is proposed to denoise the daytime photon cloud data with high background noise. Firstly, the Random Sample Consensus (RANSAC) algorithm is used to roughly denoise the daytime photon cloud data with high background noise, and a signal point cloud buffer is established to remove most of the noise points. Subsequently, the horizontal continuity parameter is calculated based on the photon cloud data following the rough denoising process. Based on this parameter, the shape and size of the search domain of the results of the subsequent fine denoising algorithm are adaptively improved. Finally, three filtering directions (a horizontal direction, an intra-group unified direction, and an adaptive direction for each photon) are proposed, and a hybrid algorithm combining the Ordering Points to Identify the Clustering Structure (OPTICS) density clustering algorithm and the Relative Neighboring Relationship K-nearest neighbors-based noise removal (RNR−KNNB) algorithm is employed to accurately denoise the photon cloud data in the three filtering directions. Furthermore, the RANSAC algorithm based on a sliding overlap window is used to remove outliers for the weak beam fine denoising photon cloud data. The results indicate that, for the strong beams, the denoising accuracy of the multilevel filtering algorithm in the three filtering directions is comparable (Rs ≥ 0.96, F ≥ 0.67), and they are all better than that of the ATL08 algorithm (Rs/Rn/p/F = 0.85/0.67/0.52/0.65). For weak beams, the denoising accuracy of the multilevel filtering algorithm in the horizontal direction and the intra-group unified direction is similar (Rs = 0.92, F = 0.69), and it is superior to the denoising results in the adaptive direction of each photon and the ATL08 algorithm (Rs/Rn/p/F = 0.94/0.84/0.51/0.65, 0.88/0.87/0.55/0.67, respectively). For strong and weak beams, the p-value and F-value of the denoising results of multilevel filtering algorithms in three different filtering directions increase with the increase of SNR value. It is demonstrated that SNR is an important factor affecting the denoising results of algorithms. The multilevel filtering algorithm proposed in the study can effectively achieve precise denoising of daytime photon cloud data with high background noise, and the three different filtering directions have different effects on the denoising results of strong and weak beam photon cloud data. This can provide technical and methodological guidance for subsequent photon cloud data filtering processing. Full article

The second-generation spaceborne LiDAR-Ice, Cloud and Land Elevation Satellite-2 (ICESat-2) carries the Advanced Topographic Laser Altimeter System (ATLAS), which can penetrate a certain depth of water, and is one of the important means to obtain the water depth information of nearshore water. However, due to the influence of the atmospheric environment, water quality and color, the system itself and other factors, the photon point cloud introduces survey noise, which restricts the survey accuracy and reliability of nearshore water depth. Therefore, in this study, we presented a photon denoising algorithm for layered processing of submarine surface. Firstly, rough denoising of the original photon data was completed by smoothing filtering. Then, elevation histogram statistics were carried out on the photon data, two peaks of the histogram were fitted by a double Gaussian function, and the intersection of two curves was then taken to separate the water surface and underwater photons. The surface photons were denoised by the DBSCAN clustering algorithm. Then according to the distribution characteristics of underwater signal photons, a single-photon point cloud filtering bathymetric method was proposed based on improved local distance statistics (LDSBM), which was used for fine denoising of underwater point cloud data. Finally, the Gaussian function was used to fit the frequency histogram, and the signal photons were screened to extract the water depth information. In this study, 13 groups of the ATL03 dataset from the Xisha Islands, the St. Thomas and the Acklins Island were used for denoising. The denoising results were compared with the signal photons manually marked and the signal photons extracted by the official built-in method (OM). The experimental results showed that, compared with the official method results of ATL03, the LDSBM had a higher F value (comprehensive evaluation index), with an average of more than 96.70%. In conclusion, the proposed underwater single-photon point cloud filtering bathymetric method was superior to the traditional algorithm and could recover terrain information accurately. Full article

The Ice, Cloud, and Land Elevation Satellite 2 (ICESat-2) is equipped with an Advanced Terrain Laser Altimeter System (ATLAS) with the capability of penetrating water bodies, making it a widely utilized tool for the bathymetry of various aquatic environments. However, the laser sensor often encounters a significant number of noise photons due to various factors such as sunlight, water quality, and after-pulse effect. These noise photons significantly compromise the accuracy of bathymetry measurements. In an effort to address this issue, this study proposes a two-step method for photon denoising by utilizing a method combining the DBSCAN algorithm and a two-dimensional window filter, achieving an F1 score of 0.94. A robust M-estimation method was employed to estimate the water depth of the denoised and refraction-corrected bathymetric photons, achieving an RMSE of 0.30 m. The method proposed in this paper preserves as much information as possible about signal photons, increases the number of bathymetric points, enhances the resistance to gross error, and guarantees the accuracy of bathymetry measurements while outlining the underwater topography. While the method is not fully automated and requires setting parameters, the fixed parameter values allow for efficient batch denoising of underwater photon points in different environments. Full article

The Ice, Cloud, and Land Elevation Satellite-2 (ICESat-2) with its land and vegetation height data product (ATL08), and Global Ecosystem Dynamics Investigation (GEDI) with its terrain elevation and height metrics data product (GEDI Level 2A) missions have great potential to globally map ground and canopy heights. Canopy height is a key factor in estimating above-ground biomass and its seasonal changes; these satellite missions can also improve estimated above-ground carbon stocks. This study presents a novel Sparse Vegetation Detection Algorithm (SVDA) which uses ICESat-2 (ATL03, geolocated photons) data to map tree and vegetation heights in a sparsely vegetated savanna ecosystem. The SVDA consists of three main steps: First, noise photons are filtered using the signal confidence flag from ATL03 data and local point statistics. Second, we classify ground photons based on photon height percentiles. Third, tree and grass photons are classified based on the number of neighbors. We validated tree heights with field measurements (n = 55), finding a root-mean-square error (RMSE) of 1.82 m using SVDA, GEDI Level 2A (Geolocated Elevation and Height Metrics product): 1.33 m, and ATL08: 5.59 m. Our results indicate that the SVDA is effective in identifying canopy photons in savanna ecosystems, where ATL08 performs poorly. We further identify seasonal vegetation height changes with an emphasis on vegetation below 3 m; widespread height changes in this class from two wet-dry cycles show maximum seasonal changes of 1 m, possibly related to seasonal grass-height differences. Our study shows the difficulties of vegetation measurements in savanna ecosystems but provides the first estimates of seasonal biomass changes. Full article

The Ice, Cloud, and Land Elevation Satellite-2 (ICESat-2) was successfully launched. Due to its small spot size, multibeam configuration, high sampling rate, and strong immunity to terrain slopes, it has been regarded as a powerful tool for forest resources surveying and managing. However, the ICESat-2 photon cloud data contain considerable background photons, which discretely distribute in the background space of signal photons. Therefore, it is necessary to filter these noise photons. In this study, photons are divided into three categories: signal photons, noise photons far away from signal photons, and noise photons adjacent to signal photons. Based on the existing research, forward and backward elliptical distances were used to express the spatial relationship between two photons, and backward local density (BLD) was used to describe the density distribution of the photons. However, the single statistical parameter cannot clearly distinguish three types of photon cloud. Therefore, forward local density (FLD) and neighboring forward local density difference (NFLDD) also were defined to describe the density distribution of the photons. Finally, by combining the support vector machine (SVM), the above three density parameters were used to classify the photons by signal and noise photons. The proposed method was validated with photon cloud data acquired by the Simulated Advanced Terrain Laser Altimeter System (MATLAS), the Multiple Altimeter Beam Experimental Lidar (MABEL), and the ICESat-2 systems over different forested areas. The results demonstrated that the proposed method can well remove the noise photons and retain the signal photons without depending on any statistical assumptions or thresholds. The comprehensive accuracy of the three test sites was 0.99, 0.98, and 0.99, respectively, which was higher than those of the existing method. In addition, the total errors corresponding to the three test sites were about 0.4%, 0.5%, and 1.0% respectively, which were lower than those of the existing method. Full article

Accurate and reliable bathymetric data are needed for a wide diversity of marine research and management applications. Satellite-derived bathymetry represents a time saving method to map large shallow waters of remote regions compared to the current costly in situ measurement techniques. This study aims to create very high-resolution (VHR) bathymetry and habitat mapping in Mayotte island waters (Indian Ocean) by fusing 0.5 m Pleiades-1 passive multispectral imagery and active ICESat-2 LiDAR bathymetry. ICESat-2 georeferenced photons were filtered to remove noise and corrected for water column refraction. The bathymetric point clouds were validated using the French naval hydrographic and oceanographic service Litto3D^® dataset and then used to calibrate the multispectral image to produce a digital depth model (DDM). The latter enabled the creation of a digital albedo model used to classify benthic habitats. ICESat-2 provided bathymetry down to 15 m depth with a vertical accuracy of bathymetry estimates reaching 0.89 m. The benthic habitats map produced using the maximum likelihood supervised classification provided an overall accuracy of 96.62%. This study successfully produced a VHR DDM solely from satellite data. Digital models of higher accuracy were further discussed in the light of the recent and near-future launch of higher spectral and spatial resolution satellites. Full article

National Aeronautics and Space Administration’s (NASA’s) Ice, Cloud, and land Elevation Satellite-2 (ICESat-2) provides rich insights over the Earth’s surface through elevation data collected by its Advanced Topographic Laser Altimeter System (ATLAS) since its launch in September 2018. While this mission is primarily aimed at capturing ice measurements, ICESat-2 also provides data over vegetated areas, offering the capability to gain insights into ecosystem structure and the potential to contribute to the sustainable management of forests. This study involved an examination of the utility of ICESat-2 for estimating forest aboveground biomass (AGB). The objectives of this study were to: (1) investigate the use of canopy metrics for estimating AGB, using data extracted from an ICESat-2 transect over forests in south-east Texas; (2) compare the accuracy for estimating AGB using data from the strong beam and weak beam; and (3) upscale predicted AGB estimates using variables from Landsat multispectral imagery and land cover and canopy cover maps, to generate a 30 m spatial resolution AGB map. Methods previously developed with simulated ICESat-2 data over Sam Houston National Forest (SHNF) in southeast Texas were adapted using actual data from an adjacent ICESat-2 transect over similar vegetation conditions. Custom noise filtering and photon classification algorithms were applied to ICESat-2’s geolocated photon data (ATL03) for one beam pair, consisting of a strong and weak beam, and canopy height estimates were retrieved. Canopy height parameters were extracted from 100 m segments in the along-track direction for estimating AGB, using regression analysis. ICESat-2-derived AGB estimates were then extrapolated to develop a 30 m AGB map for the study area, using vegetation indices from Landsat 8 Operational Land Imager (OLI), National Land Cover Database (NLCD) landcover and canopy cover, with random forests (RF). The AGB estimation models used few canopy parameters and suggest the possibility for applying well-developed methods for modeling AGB with airborne light detection and ranging (lidar) data, using processed ICESat-2 data. The final regression model achieved a R² and root mean square error (RMSE) value of 0.62 and 24.63 Mg/ha for estimating AGB and RF model evaluation with a separate test set yielded a R² of 0.58 and RMSE of 23.89 Mg/ha. Findings provide an initial look at the ability of ICESat-2 to estimate AGB and serve as a basis for further upscaling efforts. Full article

The Ice, Cloud, and land Elevation Satellite-2 (ICESat-2), which is equipped with the Advanced Topographic Laser Altimeter System (ATLAS), was launched successfully in 15 September 2018. The ATLAS represents a micro-pulse photon-counting laser system, which is expected to provide more comprehensive and scientific data for carbon storage. However, the ATLAS system is sensitive to the background noise, which poses a tremendous challenge to the photon cloud noise filtering. Moreover, the Density Based Spatial Clustering of Applications with Noise (DBSCAN) is a commonly used algorithm for noise removal from the photon cloud but there has not been an in-depth study on its parameter selection yet. This paper presents an automatic photon cloud filtering algorithm based on the Particle Swarm Optimization (PSO) algorithm, which can be used to optimize the two key parameters of the DBSCAN algorithm instead of using the manual parameter adjustment. The Particle Swarm Optimization Density Based Spatial Clustering of Applications with Noise (PSODBSCAN) algorithm was tested at different laser intensities and laser pointing types using the MATLAS dataset of the forests located in Virginia, East Coast, and the West Coast, USA. The results showed that the PSODBSCAN algorithm and the localized statistical algorithm were effective in identifying the background noise and preserving the signal photons in the raw MATLAS data. Namely, the PSODBSCAN achieved the mean F value of 0.9759, and the localized statistical algorithm achieved the mean F value of 0.6978. For both laser pointing types and laser intensities, the proposed algorithm achieved better results than the localized statistical algorithm. Therefore, the PSODBSCAN algorithm could support the MATLAS photon cloud data noise filtering applicably without manually selecting parameters. Full article

ICESat-2 is the new generation of NASA’s ICESat (Ice, Cloud and land Elevation Satellite) mission launched in September 2018. We investigate the potential of forest parameter estimation using metrics from photon counting LiDAR data, using an integrated dataset including photon counting LiDAR data from SIMPL (the Slope Imaging Multi-polarization Photon-counting LiDAR), airborne small footprint LiDAR data from G-LiHT and a stem map in Howland Research Forest, USA. First, we propose a noise filtering method based on a local outlier factor (LOF) with elliptical search area to separate the ground and canopy surfaces from noise photons. Next, a co-registration technique based on moving profiling is applied between SIMPL and G-LiHT data to correct geolocation error. Then, we calculate height metrics from both SIMPL and G-LiHT. Finally, we investigate the relationship between the two sets of metrics, using a stem map from field measurement to validate the results. Results of the ground and canopy surface extraction show that our methods can detect the potential signal photons effectively from a quite high noise rate environment in relatively rough terrain. In addition, results from co-registration between SIMPL and G-LiHT data indicate that the moving profiling technique to correct the geolocation error between these two datasets achieves favorable results from both visual and statistical indicators validated by the stem map. Tree height retrieval using SIMPL showed error of less than 3 m. We find good consistency between the metrics derived from the photon counting LiDAR from SIMPL and airborne small footprint LiDAR from G-LiHT, especially for those metrics related to the mean tree height and forest fraction cover, with mean $R^2$ value of 0.54 and 0.6 respectively. The quantitative analyses and validation with field measurements prove that these metrics can describe the relevant forest parameters and contribute to possible operational products from ICESat-2. Full article

The Ice, Cloud and Land Elevation Satellite-2 (ICESat-2) mission employs a micro-pulse photon-counting LiDAR system for mapping and monitoring the biomass and carbon of terrestrial ecosystems over large areas. In preparation for ICESat-2 data processing and applications, this paper aimed to develop and validate an effective algorithm for better estimating ground elevation and vegetation height from photon-counting LiDAR data. Our new proposed algorithm consists of three key steps. Firstly, the noise photons were filtered out using a noise removal algorithm based on localized statistical analysis. Secondly, we classified the signal photons into canopy photons and ground photons by conducting a series of operations, including elevation frequency histogram building, empirical mode decomposition (EMD), and progressive densification. At the same time, we also identified the top of canopy (TOC) photons from canopy photons by percentile statistics method. Thereafter, the ground and TOC surfaces were generated from ground photons and TOC photons by cubic spline interpolation, respectively. Finally, the ground elevation and vegetation height were estimated by retrieved ground and TOC surfaces. The results indicate that the noise removal algorithm is effective in identifying background noise and preserving signal photons. The retrieved ground elevation is more accurate than the retrieved vegetation height, and the results of nighttime data are better than those of the corresponding daytime data. Specifically, the root-mean-square error (RMSE) values of ground elevation estimates range from 2.25 to 6.45 m for daytime data and 2.03 to 6.03 m for nighttime data. The RMSE values of vegetation height estimates range from 4.63 to 8.92 m for daytime data and 4.55 to 8.65 m for nighttime data. Our algorithm performs better than the previous algorithms in estimating ground elevation and vegetation height due to lower RMSE values. Additionally, the results also illuminate that the photon classification algorithm effectively reduces the negative effects of slope and vegetation coverage. Overall, our paper provides an effective solution for estimating ground elevation and vegetation height from micro-pulse photon-counting LiDAR data. Full article

Single photon lidar (SPL) systems have great potential to be an effective tool for mapping due to their high data collection efficiency. However, the large number of false returns in SPL point clouds represents a huge challenge for the extraction of weak signal targets with low reflectivity or small cross sections. Numerous filtering methods have been proposed that attempt to effectively remove these noise points from the final point cloud model. However, weak signal points have similar characteristics to noise returns, and thus can be incorrectly eliminated as noise points during the filtering process. Herein, a novel voxel-spherical adaptive ellipsoid searching (VSAES) method is proposed, by which weak signal returns can be successfully retained while still removing a majority of the noise points. By employing this voxel-spherical (VS) model, our proposed method can simultaneously process a combined SPL dataset containing multiple flightlines, in which the noise density is unevenly distributed throughout the whole dataset. In addition, an improved adaptive ellipsoid searching (AES) method based on hypothesis testing is able to remove noise points more robustly than the originally described version. The experimental results show that the proposed method retains 89.1% of the weak signal point returns from electric power lines, which is a significant improvement over the performance of either to the original AES method (25.9%) or a histogram filtering based method (13.4%). Full article
