Time-series Interferometric Synthetic Aperture Radar (InSAR) techniques encounter substantial reliability challenges, primarily due to the presence of gross errors arising from phase unwrapping failures. These errors propagate through the processing chain and adversely affect displacement estimation accuracy, particularly in the case of a small number of SAR datasets. This study presents a unified data fusion framework designed to enhance the detection of gross errors in multi-source InSAR observations, incorporating a robust Least Squares Adjustment (LSA) methodology. The proposed framework develops a comprehensive mathematical model that integrates the fusion of multi-source InSAR data with robust LSA analysis, thereby establishing a theoretical foundation for the integration of heterogeneous datasets. Then, a systematic, reliability-driven data fusion workflow with robust LSA is developed, which synergistically combines Multi-Temporal InSAR (MT-InSAR) processing, homonymous Persistent Scatterer (PS) set generation, and iterative Baarda’s data snooping based on statistical hypothesis testing. This workflow facilitates the concurrent localization of gross errors and optimization of displacement parameters within the fusion process. Finally, the framework is rigorously evaluated using datasets from Radarsat-2 and two Sentinel-1 acquisition campaigns over the Tianjin Binhai New Area, China. Experimental results indicate that gross errors were successfully identified and removed from 11.1% of the homonymous PS sets. Following the robust LSA application, vertical displacement estimates exhibited a Root Mean Square Error (RMSE) of 5.7 mm/yr when compared to high-precision leveling data. Furthermore, a localized analysis incorporating both leveling validation and time series comparison was conducted in the Airport Economic Zone, revealing a substantial 42.5% improvement in accuracy compared to traditional Ordinary Least Squares (OLS) methodologies. Reliability assessments further demonstrate that the integration of multiple InSAR datasets significantly enhances both internal and external reliability metrics compared to single-source analyses. This study underscores the efficacy of the proposed framework in mitigating errors induced by phase unwrapping inaccuracies, thereby enhancing the robustness and credibility of InSAR-derived displacement measurements. Full article

Reclamation is an effective strategy for alleviating land scarcity in coastal areas, thereby providing additional arable land and opportunities for marine ranching. Monitoring the safety of artificial reclamation embankments is crucial for protecting these reclaimed areas. This study employed synthetic aperture radar interferometry (InSAR) using 224 Sentinel-1A data, spanning from 9 January 2016 to 8 April 2024, to investigate the deformation characteristics of the coastal reclamation embankment in Funing Bay, China. We optimized the phase-unwrapping network by employing ambiguity-detection and redundant-observation methods to facilitate the multitemporal InSAR phase-unwrapping process. The deformation results indicated that the maximum observed land subsidence rate exceeded 50 mm per year. The Funing Bay embankment exhibited a higher level of internal deformation than areas closer to the sea. Time-series analysis revealed a gradual deceleration in the deformation rate. Furthermore, a geotechnical model was utilized to predict future deformation trends. Understanding the spatial dynamics of deformation characteristics in the Funing Bay reclamation embankment will be beneficial for ensuring the safe operation of future coastal reclamation projects. Full article

Multi-temporal Interferometric Synthetic Aperture Radar technique (MTInSAR) has emerged as a valuable tool for measuring ground motion in a wide area. However, interpreting displacement time series and identifying dangerous signals from millions of InSAR coherent targets is challenging. In this study, we propose a method combining stacked autoencoder (SAE) and convolutional neural network (CNN) to classify InSAR time series and ease the interpretation of movements. The InSAR time series are classified into five categories, including stable, linear, accelerating, deceleration, and phase unwrapping error (PUE). The accuracy of labeled samples reaches 95.1%, reflecting the performance of the proposed method. This method was applied to the InSAR results for Kunming extracted from 171 ascending Sentinel-1 images from January 2017 to September 2022. The classification map of the InSAR time series shows that stable coherent points dominate around 79.28% of the area, with linear patterns at 10.70%, decelerating at 5.30%, accelerating at 4.72%, and PUE patterns at 3.60%. The results demonstrate that this method can distinguish different ground motion features and detect nonlinear deformation signals on a large scale without human intervention. Full article

Satellite-based interferometric synthetic aperture radar (InSAR) is an invaluable technique in the detection and monitoring of changes on the surface of the earth. Its high spatial coverage, weather friendly and remote nature are among the advantages of the tool. The multi-temporal differential InSAR (DInSAR) methods in particular estimate the spatio-temporal evolution of deformation by incorporating information from multiple SAR images. Moreover, opportunities from the DInSAR techniques are accompanied by challenges that affect the final outputs. Resolving the inherent ambiguities of interferometric phases, especially in areas with a high spatio-temporal deformation gradient, represents the main challenge. This brings the necessity of quality indices as important DInSAR data processing tools in achieving ultimate processing outcomes. Often such indices are not provided with the deformation products. In this work, we propose four scores associated with (i) measurement points, (ii) dates of time series, (iii) interferograms and (iv) images involved in the processing. These scores are derived from a redundant set of interferograms and are calculated based on the consistency of the unwrapped interferometric phases in the frame of a least-squares adjustment. The scores reflect the occurrence of phase unwrapping errors and represent valuable input for the analysis and exploitation of the DInSAR results. The proposed tools were tested on 432,311 points, 1795 interferograms and 263 Sentinel-1 single look complex images by employing the small baseline technique in the PSI processing chain, PSIG of the geomatics division of the Centre Tecnològic de Telecomunicacions de Catalunya (CTTC). The results illustrate the importance of the scores—mainly in the interpretation of the DInSAR outputs. Full article

Multi-temporal interferometric synthetic aperture radar (MT-InSAR) techniques are well recognized as useful tools for detecting and monitoring Earth’s surface temporal changes. In this work, the fundamentals of error noise propagation and perturbation theories are applied to derive the ground displacement products’ theoretical error bounds of the small baseline (SB) differential interferometric synthetic aperture radar algorithms. A general formulation of the least-squares (LS) optimization problem, representing the SB methods implementation’s core, was adopted in this research study. A particular emphasis was placed on the effects of time-uncorrelated phase unwrapping mistakes and time-inconsistent phase disturbances in sets of SB interferograms, leading to artefacts in the attainable InSAR products. Moreover, this study created the theoretical basis for further developments aimed at quantifying the error budget of the time-uncorrelated phase unwrapping mistakes and studying time-inconsistent phase artefacts for the generation of InSAR data products. Some experiments, performed by considering a sequence of synthetic aperture radar (SAR) images collected by the ASAR sensor onboard the ENVISAT satellite, supported the developed theoretical framework. Full article

Underground mining is one of the human activities with the highest impact in terms of induced ground motion. The excavation of the mining levels creates pillars, rooms and cavities that can evolve in chimney collapses and sinkholes. This is a major threat where the mining activity is carried out in an urban context. Thus, there is a clear need for tools and instruments able to precisely quantify mining-induced deformation. Topographic measurements certainly offer very high spatial accuracy and temporal repeatability, but they lack in spatial distribution of measurement points. In the past decades, Multi-Temporal Satellite Interferometry (MTInSAR) has become one of the most reliable techniques for monitoring ground motion, including mining-induced deformation. Although with well-known limitations when high deformation rates and frequently changing land surfaces are involved, MTInSAR has been exploited to evaluate the surface motion in several mining area worldwide. In this paper, a detailed scale MTInSAR approach was designed to characterize ground deformation in the salt solution mining area of Saline di Volterra (Tuscany Region, central Italy). This mining activity has a relevant environmental impact, depleting the water resource and inducing ground motion; sinkholes are a common consequence. The MTInSAR processing approach is based on the direct integration of interferograms derived from Sentinel-1 images and on the phase splitting between low (LF) and high (HF) frequency components. Phase unwrapping is performed for the LF and HF components on a set of points selected through a “triplets closure” method. The final deformation map is derived by combining again the components to avoid error accumulation and by applying a classical atmospheric phase filtering to remove the remaining low frequency signal. The results obtained reveal the presence of several subsidence bowls, sometimes corresponding to sinkholes formed in the recent past. Very high deformation rates, up to −250 mm/yr, and time series with clear trend changes are registered. In addition, the spatial and temporal distribution of velocities and time series is analyzed, with a focus on the correlation with sinkhole occurrence. Full article

One of the most critical steps in a multitemporal D-InSAR analysis is the resolution of the phase ambiguities in the context of phase unwrapping. The Extended Minimum Cost Flow approach is one of the potential phase unwrapping algorithms used in the Small Baseline Subset analysis. In a first step, each phase gradient is unwrapped in time using a linear motion model and, in a second step, the spatial phase unwrapping is individually performed for each interferogram. Exploiting the temporal and spatial information is a proven method, but the two-step procedure is not optimal. In this paper, a method is presented which solves both the temporal and spatial phase unwrapping in one single step. This requires some modifications regarding the estimation of the motion model and the choice of the weights. Furthermore, the problem of temporal inconsistency of the data, which occurs with spatially filtered interferograms, must be considered. For this purpose, so called slack variables are inserted. To verify the method, both simulated and real data are used. The test region is the Lower-Rhine-Embayment in the southwest of North Rhine-Westphalia, a very rural region with noisy data. The studies show that the new approach leads to more consistent results, so that the deformation time series of the analyzed pixels can be improved. Full article

This paper concentrates on the study of the Weighted Least-squares (WLS) approaches for the generation of ground displacement time-series through Differential Interferometric SAR (DInSAR) methods. Usually, within the DInSAR framework, the Weighted Least-squares (WLS) techniques have principally been applied for improving the performance of the phase unwrapping operations as well as for better conveying the inversion of sequences of unwrapped interferograms to generate ground displacement maps. In both cases, the identification of low-coherent areas, where the standard deviation of the phase is high, is requested. In this paper, a WLS method that extends the usability of the Multi-Temporal InSAR (MT-InSAR) Small Baseline Subset (SBAS) algorithm in regions with medium-to-low coherence is presented. In particular, the proposed method relies on the adaptive selection and exploitation, pixel-by-pixel, of the medium-to-high coherent interferograms, only, so as to discard the noisy phase measurements. The selected interferometric phase values are then inverted by solving a WLS optimization problem. Noteworthy, the adopted, pixel-dependent selection of the “good” interferograms to be inverted may lead the available SAR data to be grouped into several disjointed subsets, which are then connected, exploiting the Weighted Singular Value Decomposition (WSVD) method. However, in some critical noisy regions, it may also happen that discarding of the incoherent interferograms may lead to rejecting some SAR acquisitions from the generated ground displacement time-series, at the cost of the reduced temporal sampling of the data measurements. Thus, variable-length ground displacement time-series are generated. The mathematical framework of the developed technique, which is named Weighted Adaptive Variable-lEngth (WAVE), is detailed in the manuscript. The presented experiments have been carried out by applying the WAVE technique to a SAR dataset acquired by the COSMO-SkyMed (CSK) sensors over the Basilicata region, Southern Italy. A cross-comparison analysis between the conventional and the WAVE method has also been provided. Full article

This paper analyses the critical phase unwrapping step in a differential interferometric phase (D-InSAR) stack where both the solving of conventional methods and alternative approaches are discussed. It can be shown that including the temporal relationship between interferograms in the phase unwrapping step improves the results. This leads to the three-dimensional extended minimum cost flow algorithm. To unwrap the phase in a multitemporal way a motion model has to be considered. The estimation of these parameters is an important step. By default, the parameters are estimated in an iterative search process, where in each step, a linear program has to be solved. The best parameters are defined by the minimal costs. Often the choice of this search space is not straightforward. Furthermore, with this discrete optimization function, the solution is often not unique. This paper presents an alternative way to estimate the motion model parameters by maximizing a continuous function, the ensemble phase coherence. With the help of a closed-loop simulation and real data, both methods, the standard and the alternative way, are numerically compared and analyzed. Consequently, it is shown that maximizing the ensemble phase coherence is a good alternative to the established iterative procedure. It offers the advantage that the run time can be reduced considerably and is thus well suited in the processing of large data sets. Full article

In this work, the statistical fundaments of the recently proposed enhanced, multi-temporal interferometric synthetic aperture radar (InSAR) noise-filtering (E-MTInSAR) technique is addressed. The adopted noise-filtering algorithm is incorporated into the improved extended Minimum Cost Flow (EMCF) Small Baseline Subset (SBAS) differential interferometric SAR (InSAR) processing chain, which has extensively been used for the generation of Earth’s surface displacement time-series in several different contexts. Originally, the input of the InSAR EMCF-SBAS processing toolbox consisted of a sequence of multi-looked, small baseline interferograms, which were unwrapped using the space-time EMCF phase unwrapping algorithm. Subsequently, the unwrapped interferograms were inverted through the SBAS algorithm to retrieve the expected InSAR deformation products. The improved processing chain has complemented the original codes with two additional steps. In particular, a new multi-temporal noise-filtering algorithm for sequences of time-redundant multi-looked DInSAR interferograms, followed by a proper interferogram selection step, has been proposed. This research study is aimed at primarily assessing the performance of the E-MTInSAR noise-filtering algorithm from a theoretical perspective. To this aim, the principles of directional statistics and errors propagation are exploited. Experimental results, carried out by applying the E-MTInSAR algorithm to a sequence of SAR data collected over the Los Angeles bay area, have been used to corroborate the academic outcome of this research. Full article

Monitoring, assessing, and understanding the structural health of large infrastructures, such as buildings, bridges, dams, tunnels, and highways, is important for urban development and management, as the gradual deterioration of such structures may result in catastrophic structural failure leading to high personal and economic losses. With a higher spatial resolution and a shorter revisit period, interferometric synthetic aperture radar (InSAR) plays an increasing role in the deformation monitoring and height extraction of structures. As a focal point of the InSAR data processing chain, phase unwrapping has a direct impact on the accuracy of the results. In complex urban areas, large elevation differences between the top and bottom parts of a large structure combined with a long interferometric baseline can result in a serious phase-wrapping problem. Here, with no accurate digital surface model (DSM) available, we handle the large phase gradients of arcs in multitemporal InSAR processing using a long–short baseline iteration method. Specifically, groups of interferometric pairs with short baselines are processed to obtain the rough initial elevation estimations of the persistent scatterers (PSs). The baseline threshold is then loosened in subsequent iterations to improve the accuracy of the elevation estimates step by step. The LLL lattice reduction algorithm (by Lenstra, Lenstra, and Lovász) is applied in the InSAR phase unwrapping process to rapidly reduce the search radius, compress the search space, and improve the success rate in resolving the phase ambiguities. Once the elevations of the selected PSs are determined, they are used in the following two-dimensional phase regression involving both elevations and deformations. A case study of Lupu Bridge in Shanghai is carried out for the algorithm’s verification. The estimated PS elevations agree well (within 1 m) with the official Lupu Bridge model data, while the PS deformation time series confirms that the bridge exhibits some symmetric progressive deformation, at 4–7 mm per year on both arches and 4–9 mm per year on the bridge deck during the SAR image acquisition period. Full article

Okmok, a ~10-km wide caldera that occupies most of the northeastern end of Umnak Island, is one of the most active volcanoes in the Aleutian arc. The most recent eruption at Okmok during July–August 2008 was by far its largest and most explosive since at least the early 19th century. We investigate post-eruptive magma supply and storage at the volcano during 2008–2014 by analyzing all available synthetic aperture radar (SAR) images of Okmok acquired during that time period using the multi-temporal InSAR technique. Data from the C-band Envisat and X-band TerraSAR-X satellites indicate that Okmok started inflating very soon after the end of 2008 eruption at a time-variable rate of 48–130 mm/y, consistent with GPS measurements. The “model-assisted” phase unwrapping method is applied to improve the phase unwrapping operation for long temporal baseline pairs. The InSAR time-series is used as input for deformation source modeling, which suggests magma accumulating at variable rates in a shallow storage zone at ~3.9 km below sea level beneath the summit caldera, consistent with previous studies. The modeled volume accumulation in the six years following the 2008 eruption is ~75% of the 1997 eruption volume and ~25% of the 2008 eruption volume. Full article

Interferometric Synthetic Aperture Radar (InSAR) capability to detect slow deformation over terrain areas is limited by temporal decorrelation, geometric decorrelation and atmospheric artefacts. Multitemporal InSAR methods such as Persistent Scatterer (PS-InSAR) and Small Baseline Subset (SBAS) have been developed to deal with various aspects of decorrelation and atmospheric problems affecting InSAR observations. Nevertheless, the applicability of both PS-InSAR and SBAS in mountainous regions is still challenging. Correct phase unwrapping in both methods is hampered due to geometric decorrelation in particular when using C-band SAR data for deformation analysis. In this paper, we build upon the SBAS method implemented in StaMPS software and improved the technique, here called ISBAS, to assess tectonic and volcanic deformation in the center of the Alborz Mountains in Iran using both Envisat and ALOS SAR data. We modify several aspects within the chain of the processing including: filtering prior to phase unwrapping, topographic correction within three-dimensional phase unwrapping, reducing the atmospheric noise with the help of additional GPS data, and removing the ramp caused by ionosphere turbulence and/or orbit errors to better estimate crustal deformation in this tectonically active region. Topographic correction is done within the three-dimensional unwrapping in order to improve the phase unwrapping process, which is in contrast to previous methods in which DEM error is estimated before/after phase unwrapping. Our experiments show that our improved SBAS approach is able to better characterize the tectonic and volcanic deformation in the center of the Alborz region than the classical SBAS. In particular, Damavand volcano shows an average uplift rate of about 3 mm/year in the year 2003–2010. The Mosha fault illustrates left-lateral motion that could be explained with a fault that is locked up to 17–18 km depths and slips with 2–4 mm/year below that depth. Full article

Owing to the development of spaceborne synthetic aperture radar (SAR) platforms, and in particular the increase in the availability of multi-source (multi-band and multi-resolution) data, it is now feasible to design a surface displacement monitoring application using multi-temporal SAR interferometry (MT-InSAR). Landslides have high socio-economic impacts in many countries because of potential geo-hazards and heavy casualties. In this study, taking into account the merits of ALOS PALSAR (L-band, good coherence preservation) and TerraSAR (X-band, high resolution and short revisit times) data, we applied an improved small baseline InSAR (SB-InSAR) with 3-D phase unwrapping approach, to monitor slope superficial displacement in Hong Kong, China, a mountainous subtropical zone city influenced by over-urbanization and heavy monsoonal rains. Results revealed that the synergistic use of PALSAR and TerraSAR data produces different outcomes in relation to data reliability and spatial-temporal resolution, and hence could be of significant value for a comprehensive understanding and monitoring of unstable slopes. Full article
