Recent Advancements in Multilevel Inverters: Topologies, Modulation Techniques, and Emerging Applications
by Taha Abdulsalam Taha, Mohamed Shalaby, Noor Izzri Abdul Wahab, Hussein Ibzir Zaynal, Mohd Khair Hassan, Sulaiman Al-Sowayan and Mohamad A. Alawad
Symmetry 2025, 17(7), 1010; https://doi.org/10.3390/sym17071010 - 26 Jun 2025
Viewed by 665
Abstract
Multilevel inverters (MLIs) have become fundamental in contemporary power electronics, providing enhanced performance compared to conventional two-level inverters regarding their output voltage quality, efficiency, and scalability. This study comprehensively assesses multilevel inverter technologies, including their topologies, control systems, and various applications. The study [...] Read more.
Multilevel inverters (MLIs) have become fundamental in contemporary power electronics, providing enhanced performance compared to conventional two-level inverters regarding their output voltage quality, efficiency, and scalability. This study comprehensively assesses multilevel inverter technologies, including their topologies, control systems, and various applications. The study starts with a comprehensive examination of the core concepts of MLIs, subsequently embarking on a detailed evaluation of both conventional and innovative topologies, such as diode-clamped, flying capacitor, cascaded H-bridge, and modular multilevel converters. The study further examines the control systems used in MLIs, including Pulse Width Modulation (PWM), space vector modulation (SVM), and Model Predictive Control (MPC), emphasizing their benefits and drawbacks. The applications of MLIs in renewable energy systems, electric cars, industrial drives, and grid integration are comprehensively examined. The study closes by examining growing trends, difficulties, and future research paths, emphasizing the ability of MLIs to transform power conversion systems. Full article
(This article belongs to the Section Engineering and Materials)
Show Figures

Figure 1

24 pages, 7962 KiB
Article
A Novel Multilevel Inverter Topology Generating a 19-Level Output Regulated by the PD-PWM Method
by Sofia Lemssaddak, Abdelhafid Ait Elmahjoub, Mohamed Tabaa, Adnane El-Alami and Mourad Zegrari
Energies 2025, 18(13), 3227; https://doi.org/10.3390/en18133227 - 20 Jun 2025
Cited by 1 | Viewed by 502
Abstract
Traditional multilevel inverter topologies, such FC, NPC, and CHB, have a few significant disadvantages. They need a great number of parts, which raises the complexity, expense, and switching losses. Furthermore, their intricate control schemes make voltage balancing and synchronization challenging. Lastly, under some [...] Read more.
Traditional multilevel inverter topologies, such FC, NPC, and CHB, have a few significant disadvantages. They need a great number of parts, which raises the complexity, expense, and switching losses. Furthermore, their intricate control schemes make voltage balancing and synchronization challenging. Lastly, under some circumstances, they experience severe harmonic distortion, necessitating the inclusion of expensive filters to enhance signal quality. This paper proposes a novel multilevel converter topology that uses the phase-disposition PWM (PD-PWM) technique to control a 19-level output. This new configuration maintains performance comparable to the CHB-MLI reference while using fewer switches, simplifying control, and reducing costs. Our approach is based on extensive simulations conducted in the MATLAB Simulink environment, with results compared to the CHB-MLI. A low-pass filter is added to improve the output voltage quality, reducing the THD% to 1.33%. This strategy offers several advantages, including simpler control, lower costs, increased reliability, and higher-quality output. The system was replicated using MATLAB Simulink and validated through hardware-in-the-loop (HIL) testing. The HIL method ensures real-world testing without causing damage to the hardware. The integrated system includes sensors and necessary hardware for a comprehensive energy management solution. Full article
Show Figures

Figure 1

36 pages, 2975 KiB
Review
A Review of Hybrid Three-Level ANPC Inverters: Topologies, Comparison, Challenges and Improvements in Applications
by Xiaobin Mu, Hao Chen, Xiang Wang, Weimin Wu, Houqing Wang, Liang Yuan, Henry Shu-Hung Chung and Frede Blaabjerg
Energies 2025, 18(10), 2613; https://doi.org/10.3390/en18102613 - 19 May 2025
Viewed by 1230
Abstract
Considering the cost, efficiency, power density, and other issues of the power electronic system, many papers have mixed the wide-bandgap (WBG) power devices, mainly SiC MOSFET and GaN FET/HEMT, with Si IGBT/MOSFET in the three-level active neutral-point clamped (T-ANPC) topology, forming the hybrid [...] Read more.
Considering the cost, efficiency, power density, and other issues of the power electronic system, many papers have mixed the wide-bandgap (WBG) power devices, mainly SiC MOSFET and GaN FET/HEMT, with Si IGBT/MOSFET in the three-level active neutral-point clamped (T-ANPC) topology, forming the hybrid T-ANPC (HT-ANPC) topology. This paper reviews these latest HT-ANPC topologies from the perspective of the material types of switching devices and compares the advantages and disadvantages of various topologies. The potential challenges of HT-ANPC inverters in several mainstream applications are reviewed, and their improvements are compared and discussed in detail. Next, a brief topology selection and design process are provided based on analyzing various typical topologies. In addition, some future research trends on this topic are discussed. The paper will help researchers to select appropriate HT-ANPC topologies in different applications and have a better understanding of the critical issues to be considered during system design. Full article
(This article belongs to the Section F3: Power Electronics)
Show Figures

Figure 1

25 pages, 12348 KiB
Article
A Novel Modified Delta-Connected CHB Multilevel Inverter with Improved Line–Line Voltage Levels
by Abdullah M. Noman
Electronics 2025, 14(9), 1711; https://doi.org/10.3390/electronics14091711 - 23 Apr 2025
Viewed by 518
Abstract
Numerous cascaded inverter configurations have been developed to generate higher voltage levels, thereby improving performance and lowering costs. Comparing conventional delta-connected cascaded H-bridge (CHB) multilevel inverters to star-connected CHB multilevel inverters reveals a disadvantage. In conventional delta-connected CHB multilevel inverters, more switches are [...] Read more.
Numerous cascaded inverter configurations have been developed to generate higher voltage levels, thereby improving performance and lowering costs. Comparing conventional delta-connected cascaded H-bridge (CHB) multilevel inverters to star-connected CHB multilevel inverters reveals a disadvantage. In conventional delta-connected CHB multilevel inverters, more switches are unavoidably needed to achieve the same line-to-line grid voltage, since more H-bridges cascaded in series are required than in a star-connected CHB. This paper presents a modified topology based on the delta-connected CHB multilevel configuration to provide the same number of line-to-line voltage levels as a star-connected CHB, using an equivalent number of switches. The number of switches in the proposed multilevel inverter is decreased compared to conventional delta-connected CHB MLIs at the same voltage levels. The mathematical modeling of the proposed topology and the simulation results using a fixed load and a PV-grid connection are provided to validate the efficacy and dependability of the proposed topology. To validate the usefulness of the proposed configuration, it was practically implemented in the laboratory. Data acquisition and generation of gating signals to fire the switches were implemented using a MicroLabBox real-time controller. The prototype was examined under a resistive–inductive load and tested under different modulation indices. To demonstrate the effectiveness and the functionality of the topology, the experimental results are also provided. Full article
(This article belongs to the Special Issue Power Electronics in Renewable Systems)
Show Figures

Figure 1

20 pages, 2484 KiB
Review
The Role of Multilevel Inverters in Mitigating Harmonics and Improving Power Quality in Renewable-Powered Smart Grids: A Comprehensive Review
by Shanikumar Vaidya, Krishnamachar Prasad and Jeff Kilby
Energies 2025, 18(8), 2065; https://doi.org/10.3390/en18082065 - 17 Apr 2025
Cited by 1 | Viewed by 1527
Abstract
The world is increasingly turning to renewable energy sources (RES) to address climate change issues and achieve net-zero carbon emissions. Integrating RES into existing power grids is necessary for sustainability because the unpredictability and irregularity of the RES can affect grid stability and [...] Read more.
The world is increasingly turning to renewable energy sources (RES) to address climate change issues and achieve net-zero carbon emissions. Integrating RES into existing power grids is necessary for sustainability because the unpredictability and irregularity of the RES can affect grid stability and generate power quality issues, leading to equipment damage and increasing operational costs. As a result, the importance of RES is severely compromised. To tackle these challenges, traditional power systems (TPS) will have to become more innovative. Smart grids use advanced technology such as two-way communication between consumers and service providers, automated control, and real-time monitoring to manage power flow effectively. Inverters are effective tools for solving power quality problems in renewable-powered smart grids. However, their effectiveness depends on topology, control method and design. This review paper focuses on the role of multilevel inverters (MLIs) in mitigating power quality issues such as voltage sag, swell and total harmonics distortion (THD). The results shown here are through simulation studies using DC sources but can be extended to RES-integrated smart grids. The comprehensive review also examines the drawbacks of TPS to understand the importance and necessity of developing a smart power system. Finally, the paper discusses future trends in MLI control technology, addressing power quality problems in smart grid environments. Full article
(This article belongs to the Section F3: Power Electronics)
Show Figures

Figure 1

19 pages, 16474 KiB
Article
13-Level Single-Source Switched-Capacitor Boost Multilevel Inverter
by Kah Haw Law, Yew Wei Sia, Raymond Choo Wee Chiong, Swee Peng Ang, Kenneth Siok Kiam Yeo and Sy Yi Sim
Energies 2025, 18(7), 1664; https://doi.org/10.3390/en18071664 - 27 Mar 2025
Cited by 2 | Viewed by 497
Abstract
Transformerless inverters (TIs) are becoming increasingly popular in solar photovoltaic (PV) applications due to their enhanced efficiency and cost-effectiveness. Unlike transformer-based inverters, TIs, which lack transformers and additional components, offer significant advantages in terms of reduced weight, compactness, and lower costs. Research studies [...] Read more.
Transformerless inverters (TIs) are becoming increasingly popular in solar photovoltaic (PV) applications due to their enhanced efficiency and cost-effectiveness. Unlike transformer-based inverters, TIs, which lack transformers and additional components, offer significant advantages in terms of reduced weight, compactness, and lower costs. Research studies have demonstrated that multilevel TIs can achieve lower total harmonic distortion (THD), reduced switching stresses, and higher AC output voltage levels suitable for high voltage applications. However, achieving these outcomes simultaneously with maximum power ratings and the lowest switching frequencies poses a challenge for TI topologies. In light of these challenges, this research proposes the implementation of a 13-level single-source switched-capacitor boost multilevel inverter (SSCBMLI) designed for solar PV systems. The SSCBMLI consists of a single DC power source, switched-capacitor (SC) units, and a full H-bridge. Compared to other existing 13-level multilevel inverter (MLI) configurations, the proposed SSCBMLI utilizes the fewest components to minimize development costs. Moreover, the SSCBMLI offers voltage boosting and can drive high inductive loads, self-voltage-balanced capacitors, an adaptable topology structure, and reliable system performance. Simulations and experimental tests are conducted using PLECS 4.5 and SIMULINK to assess the performance of the proposed SSCBMLI under varying modulation indices, source powers, and loads. A comparative analysis is then conducted to evaluate the SSCBMLI against existing inverter topologies. Full article
(This article belongs to the Section F3: Power Electronics)
Show Figures

Graphical abstract

22 pages, 9823 KiB
Article
HIL-Based Fault-Tolerant Vector Space Decomposition Control for a Six-Phase PMSM Fed by a Five-Level CHB Converter
by Mona Shayeghan, Marco Di Benedetto, Alessandro Lidozzi and Luca Solero
Energies 2025, 18(3), 507; https://doi.org/10.3390/en18030507 - 23 Jan 2025
Cited by 2 | Viewed by 1338
Abstract
The growing demand for higher reliability and efficiency in modern electric drives, coupled with the increasing adoption of multi-phase machines, has necessitated advancements in fault-tolerant control strategies. This paper presents a fault tolerance analysis for a six-phase permanent magnet synchronous machine (PMSM) connected [...] Read more.
The growing demand for higher reliability and efficiency in modern electric drives, coupled with the increasing adoption of multi-phase machines, has necessitated advancements in fault-tolerant control strategies. This paper presents a fault tolerance analysis for a six-phase permanent magnet synchronous machine (PMSM) connected to a five-level cascaded H-bridge converter, employing a level-shift pulse width modulation (LSPWM) technique. Unlike existing strategies, this work integrates a unique combination of three key innovations: first, a fault detection mechanism capable of identifying faults in both machine phases and inverter legs with high precision; second, an open-circuit fault compensation strategy that dynamically reconfigures the faulty inverter phase leg into a two-level topology to reduce losses and preserve healthy switches; and third, a modified closed-loop control method designed specifically to mitigate the adverse effects of short-circuit faults while maintaining system stability. The proposed approach is validated through rigorous simulations in Simulink and Hardware-in-the-Loop (HIL) tests, demonstrating its robustness and applicability in high-reliability applications. Full article
Show Figures

Figure 1

24 pages, 28280 KiB
Article
Improved Genetic Algorithm-Based Harmonic Mitigation Control of an Asymmetrical Dual-Source 13-Level Switched-Capacitor Multilevel Inverter
by Hasan Iqbal and Arif Sarwat
Energies 2025, 18(1), 35; https://doi.org/10.3390/en18010035 - 25 Dec 2024
Cited by 2 | Viewed by 1051
Abstract
A single-phase multilevel inverter with a switched-capacitor multilevel (SC-MLI) configuration is developed to provide 13-level output voltages. An improved genetic algorithm (GA) with adaptive mutation and crossover rates is employed to achieve robust harmonic mitigation by avoiding local optima and ensuring optimal performance. [...] Read more.
A single-phase multilevel inverter with a switched-capacitor multilevel (SC-MLI) configuration is developed to provide 13-level output voltages. An improved genetic algorithm (GA) with adaptive mutation and crossover rates is employed to achieve robust harmonic mitigation by avoiding local optima and ensuring optimal performance. The topology introduces an SC-MLI that generates AC output voltage at desired levels using only two capacitors, two asymmetrical DC sources, one diode, and 11 switches. This allows the inverter to use fewer gate drivers and, hence, increases the power density of the converter. A significant challenge in the normal operation of SC-MLI circuits relates to the self-voltage balance of the capacitors, which easily becomes unstable, particularly at low modulation indices. The proposed design addresses this issue without the need for ancillary devices or complex control schemes, ensuring stable self-balanced operation across the entire spectrum of the modulation index. In this context, the harmonic mitigation technique optimized through GA applied in this inverter ensures low harmonic distortion, achieving a total harmonic distortion (THD) of 6.73%, thereby enhancing power quality even at low modulation indices. The performance of this SC-MLI is modeled under various loading scenarios using MATLAB/Simulink® 2023b with validation performed through an Opal-RT real-time emulator. Additionally, the inverter’s overall power losses and individual switch losses, along with the efficiency, are analyzed using the simulation tool PLEXIM-PLECS. Efficiency is found to be 96.62%. Full article
Show Figures

Figure 1

23 pages, 8323 KiB
Article
A New Cascaded Multilevel Inverter for Modular Structure and Reduced Passive Components
by Durbanjali Das, Bidyut Mahato, Bikramaditya Chandan, Hitesh Joshi, Kailash Kumar Mahto, Priyanath Das, Georgios Fotis, Vasiliki Vita and Michael Mann
Electronics 2024, 13(17), 3566; https://doi.org/10.3390/electronics13173566 - 8 Sep 2024
Cited by 2 | Viewed by 1576
Abstract
In high-power applications, achieving adequate power quality in power converter design is accomplished by utilizing multilevel inverters instead of using two-level and three-level inverters. The device generates a sinusoidal output voltage, which results in reduced total harmonic distortion and lower voltage stress on [...] Read more.
In high-power applications, achieving adequate power quality in power converter design is accomplished by utilizing multilevel inverters instead of using two-level and three-level inverters. The device generates a sinusoidal output voltage, which results in reduced total harmonic distortion and lower voltage stress on the switches and leads to lower electromagnetic interference, making it suitable for use in renewable energy applications. However, to illustrate the advantages mentioned above, a significant number of switching devices and DC sources are necessary while raising the voltage levels. This article proposes an asymmetrical voltage generation method, which operates in a ratio of 1:5 and generates 25 levels using 11 power switches. The topology is modular in structure, and each module has a lower component count, which significantly reduces the overall cost. The proposed topology is capable of generating negative output voltage levels without the use of an H-bridge configuration, where only three switches are used to generate any voltage levels. The functionality of the developed module is amended by fixing different voltage values in DC sources. This article also presents a comprehensive examination of the circuit and the functioning of various voltage levels. The advantages of the proposed inverter have been demonstrated by comparative research with the currently existing MLI topologies. Ultimately, both the simulation and experimental findings validated the practical capabilities. Full article
(This article belongs to the Section Power Electronics)
Show Figures

Figure 1

18 pages, 11335 KiB
Article
Self-Balanced Switched-Capacitor Common-Grounding Boost Multilevel Inverter
by Kaibalya Prasad Panda, Sumant Kumar Dalai, Gayadhar Panda, Ramasamy T. Naayagi and Sze Sing Lee
Electronics 2024, 13(13), 2608; https://doi.org/10.3390/electronics13132608 - 3 Jul 2024
Viewed by 1466
Abstract
Transformerless inverters have been extensively deployed in photovoltaic (PV) applications, owing to features such as high efficiency, high power quality, and low cost. However, the leakage current in such inverters due to the absence of galvanic isolation has resulted in several topological modifications. [...] Read more.
Transformerless inverters have been extensively deployed in photovoltaic (PV) applications, owing to features such as high efficiency, high power quality, and low cost. However, the leakage current in such inverters due to the absence of galvanic isolation has resulted in several topological modifications. This paper introduces a single-input switched-capacitor (SC)-based multilevel inverter (MLI) that is capable of eliminating the leakage current due to its common-ground structure. Also, the proposed inverter has the capability of single-stage voltage boosting, which is essential in PV systems. The series–parallel switching facilitates the self-balancing of SCs, which, in turn, assists in voltage boosting. Moreover, the proposed MLI synthesizes a seven-level output using only eight switches. Following an in-depth analysis of the circuit operation, modulation scheme, and power losses, a detailed comparison among recently developed seven-level MLIs is carried out, which verifies the design's superiority. Extensive simulation and experimental results are presented to validate the prominent features of the seven-level MLI under dynamic operating conditions. Full article
Show Figures

Figure 1

13 pages, 5825 KiB
Article
A Modified Criss-Cross-Based T-Type MLI with Reduced Power Components
by Kailash Kumar Mahto, Bidyut Mahato, Bikramaditya Chandan, Durbanjali Das, Priyanath Das, Swati Kumari, Vasiliki Vita, Christos Pavlatos and Georgios Fotis
Technologies 2024, 12(6), 90; https://doi.org/10.3390/technologies12060090 - 18 Jun 2024
Cited by 2 | Viewed by 2102
Abstract
Significant advancements in the field of power electronics have created an ideal opportunity to introduce various topologies of multilevel inverters. These multilevel inverter topologies comprise different notable characteristics, such as staircase sinusoidal output voltage with high quality, a lowered number of power switches, [...] Read more.
Significant advancements in the field of power electronics have created an ideal opportunity to introduce various topologies of multilevel inverters. These multilevel inverter topologies comprise different notable characteristics, such as staircase sinusoidal output voltage with high quality, a lowered number of power switches, no filter requirement, etc. In this literature, a new asymmetrical MLI topology is proposed to reduce the number of components of the inverter with admirable voltage-step creation. The proposed topology provides a 17-level, staircase-type, nearly sinusoidal output voltage waveform. The number of switches required for the proposed multilevel inverter topology is fewer compared to the existing topology for the same level. A carrier-based sinusoidal pulse-width modulation technique is used for the proposed topology at a switching frequency of 3 kHz. The functioning of the proposed inverter topology is thoroughly examined. A 17-level asymmetrical inverter is executed; both the MATLAB/SIMULINK as well as the experimental results using dSPACE-1103 controller. The simulation results are verified using the experimental results for the proposed 17-level multilevel inverter for modulation indexes of 1 and 0.6. Full article
(This article belongs to the Collection Electrical Technologies)
Show Figures

Figure 1

22 pages, 10511 KiB
Article
A Three-Phase Multilevel Inverter Synthesized with 31 Levels and Optimal Gating Angles Based on the GA and GWO to Supply a Three-Phase Induction Motor
by Taha Ahmad Hussein, Dahaman Ishak and Mohamad Tarnini
Energies 2024, 17(5), 1267; https://doi.org/10.3390/en17051267 - 6 Mar 2024
Cited by 1 | Viewed by 1869
Abstract
A three-phase multilevel inverter (MLI), synthesized with 31 levels in regard to its output voltage, is used to provide the AC supply to a three-phase, squirrel cage induction motor. The gating angles required for the 30 power switches on the MLI are optimized [...] Read more.
A three-phase multilevel inverter (MLI), synthesized with 31 levels in regard to its output voltage, is used to provide the AC supply to a three-phase, squirrel cage induction motor. The gating angles required for the 30 power switches on the MLI are optimized using both the genetic algorithm (GA) and the grey wolf optimizer (GWO), in which the optimal angles are determined through solving the trigonometric equations taken from Fourier analysis to target the minimum total harmonic distortion (THD) at the MLI output. A simulation model and an experimental prototype are developed for performance analysis and validation. The results demonstrate that the MLI is effectively able to produce 31 levels of three-phase AC output voltage, with the THD not exceeding 5% when loaded with a resistive load and a three-phase induction motor. The voltage and current are measured and recorded for different loads and operating conditions, including the amount of energy consumed by the load. The results of the frequency analysis demonstrate that most of the triple harmonics, which can harm the efficiency of the inverter, are cancelled. Full article
(This article belongs to the Section F: Electrical Engineering)
Show Figures

Figure 1

33 pages, 8053 KiB
Review
A Comprehensive Review on Space Vector Based-PWM Techniques for Common Mode Voltage Mitigation in Photovoltaic Multi-Level Inverters
by Zouhaira Ben Mahmoud and Adel Khedher
Energies 2024, 17(4), 916; https://doi.org/10.3390/en17040916 - 15 Feb 2024
Cited by 5 | Viewed by 2509
Abstract
Nowadays, transformer-less photovoltaic (PV) multi-level inverters (MLIs) are commonly employed in both industrial and residential settings. This structure has attracted increased attention due to its unique advantages, such as higher efficiency, lower cost and size, better waveform quality, and inherent fault tolerance. However, [...] Read more.
Nowadays, transformer-less photovoltaic (PV) multi-level inverters (MLIs) are commonly employed in both industrial and residential settings. This structure has attracted increased attention due to its unique advantages, such as higher efficiency, lower cost and size, better waveform quality, and inherent fault tolerance. However, due to the removal of the transformer, the common mode voltage (CMV) becomes one of the crucial issues in transformer-less PV MLIs. The high-frequency variation in CMV results in a leakage current that deteriorates the line current quality, increases the PV power system losses, leads to severe electromagnetic emissions (EMI), reduces the PV array lifespan, and causes personal safety problems. In this regard, this paper presents a review of the existing and recent research on modulation techniques based on space vector pulse width modulation (SVPWMs) that overcome this issue in transformer-less three-level NPC-MLIs (3L-NPC-MLIs). The reduced CMV-SVPWM (RCMV-SVPWM) can be mainly categorized as an RCMV-SVPWM based on the vector type, based on virtual vectors, and based on the two-level SVPWM (2L-SVPWM). Their features and their limitations in terms of several main criteria are discussed. In the final section of this paper, some challenges and future trends for this research area are projected. Full article
(This article belongs to the Special Issue Experimental and Numerical Analysis of Photovoltaic Inverters)
Show Figures

Figure 1

18 pages, 5775 KiB
Article
A New Asymmetric H-6 Structured Multilevel Inverter with Reduced Power Components
by Annadurai Radhakrishnan, Elankurisil S. Arasan, Balamurugan C. Ramalingam and Kannan Chandrasekaran
Symmetry 2024, 16(1), 72; https://doi.org/10.3390/sym16010072 - 5 Jan 2024
Cited by 3 | Viewed by 2081
Abstract
Multilevel inverters play a key role in improving the power quality for industrial, domestic, and renewable energy sectors due to sinusoidal output voltage through small voltage steps, lesser THD (total harmonic distortion), and EMI (electromagnetic interference). There are several variants in MLI structures [...] Read more.
Multilevel inverters play a key role in improving the power quality for industrial, domestic, and renewable energy sectors due to sinusoidal output voltage through small voltage steps, lesser THD (total harmonic distortion), and EMI (electromagnetic interference). There are several variants in MLI structures to generate a stepped voltage with their own operating characteristics, which flaws in switching devices with gate drivers, current conducting switches varied with varied voltage levels, and switches with different abilities in blocking voltagesto overcome increases in implementation costs and restrict its usage in high-power applications. Therefore, this article paves a solution for the above problem, which orients a new structure for asymmetric operation to propel large voltage levels with small values of switches in parallel with conventional topologies. The subtlety of the proposed topology is governed by a multicarrier pulse width modulation scheme, and ten different voltage magnitude algorithms are developed and compared foreffectiveness.Hitherto, many existing MLI topologies with reduced power switches have beendeveloped; among these, the H6 structure attempts to curtail the reduced conduction path. The operation of the suggested topology is confirmed in a Matlab/Simulink environment, and real-time performance is investigated using a laboratory prototype to accord the simulated results. Full article
(This article belongs to the Section Engineering and Materials)
Show Figures

Figure 1

10 pages, 6033 KiB
Proceeding Paper
Total Harmonic Distortion Analysis of a Seven-Level Inverter for Fuel Cell Applications
by A. S. Veerendra, Punya Sekhar Chavali, R. Shivarudraswamy, C. H. Nagaraja Kumari and Varaprasad Janamala
Eng. Proc. 2023, 59(1), 130; https://doi.org/10.3390/engproc2023059130 - 29 Dec 2023
Cited by 3 | Viewed by 1644
Abstract
This paper focuses on the total harmonic distortion (THD) analysis of a multi-level inverter (MLI) for fuel cell applications. Furthermore, a 50 kW 625 V proton exchange membrane fuel cell (PEMFC) stack was employed for this analysis. The various modes of operation of [...] Read more.
This paper focuses on the total harmonic distortion (THD) analysis of a multi-level inverter (MLI) for fuel cell applications. Furthermore, a 50 kW 625 V proton exchange membrane fuel cell (PEMFC) stack was employed for this analysis. The various modes of operation of the suggested inverter are presented accordingly, along with its switching combinations. Also, a sinusoidal pulse-width modulation (SPWM) controller was employed to drive the power electronic switches in the suggested topology. The suggested inverter can produce sinusoidal voltage with only fundamental frequency switching. Moreover, the number of components and voltage stress of the suggested topology are compared with the conventional topologies presented. In addition, the THD was analyzed with and without the LC filter. Finally, the validity of the system was verified through MATLAB/Simulink software R2022b. Full article
(This article belongs to the Proceedings of Eng. Proc., 2023, RAiSE-2023)
Show Figures

Figure 1
