Search Results (67)

The present study aims to conduct a comprehensive comparative analysis of international standards (DNV, ABS, BV, etc.) that regulate the design of mooring systems for floating offshore wind turbines. The comparative analysis focuses on the safety factors applied to the line tension of mooring systems. Firstly, an extensive literature review of the most-used floating platforms in the offshore wind industry and their corresponding mooring configurations is presented. Afterwards, a case study is presented using the VolturnUS floating substructure as a reference for analyzing the coupled dynamic response of mooring analysis through OrcaFlex 11.4, where the numerical model used for the coupled dynamic response of moorings is validated by benchmarking against the OC3 Hywind platform model. Within the scope of the comparative analysis, all-chain and semi-taut hybrid systems under various operational and survival load conditions are considered. The results demonstrate the similarities and discrepancies in line tension utilization among the standards, highlighting the comparative conservatism in different environmental conditions. Furthermore, the study underscores the need for tailored safety factors in mooring designs, given the variability in assessment methods across design guidelines, thereby making the design more flexible and encouraging innovative mooring system solutions. Full article

This article presents the design and optimization of the mooring system for a floating wind platform inspired by W2Power, which incorporates two wind turbines on a semi-submersible structure that weathervanes using a single-point mooring (SPM) system. Although several industrial concepts have adopted SPM configurations, research on their performance remains limited. This work addresses that gap by developing and applying a set of optimization strategies for the mooring system of such a platform using OrcaFlex, with the objective of minimizing the capital expenditure while satisfying Ultimate Limit State (ULS) and Fatigue Limit State (FLS) cases. The methodology was tested across two distinct marine environments: the Atlantic (Gran Canaria, GC-1) and the Mediterranean (Catalonia, LEBA-1), both characterized by their irregular bathymetry. In Catalonia, the environmental conditions are almost omnidirectional, while the platform in Gran Canaria is exposed to highly unidirectional loads. The article presents the most cost-effective solution for single-point moorings with three, four, and five lines in each case. Results demonstrate the viability of SPM-based floating wind systems with twin-turbines under diverse site conditions. Full article

Floating offshore wind turbines (FOWTs) face significant challenges in maintaining reliable power generation while mitigating structural loads, which are critical for reducing maintenance costs and extending service life. To address these issues, this study evaluates the effectiveness of a Soft Power Limitation Control (SPLC) strategy through numerical simulations in DNV Bladed. Two representative design load cases were considered, with design load case (DLC) 1.1 representing normal turbulence and DLC 2.3 representing an extreme operating gust. Under DLC 1.1, SPLC substantially reduced tower fatigue loads, lowering the damage equivalent loads (DELs) of side-to-side and fore–aft bending moments by 21 percent and 15.2 percent, respectively, while blade and mooring loads remained nearly unchanged. Platform motions exhibited modest improvements, including a 6.5 percent reduction in surge peak-to-peak, 2.2 percent in surge RMS, and 2.6 percent in pitch peak-to-peak. Under DLC 2.3, SPLC effectively alleviated extreme responses, decreasing the maximum tower side-to-side bending moment by 30.7 percent and the blade flap-wise bending moment by 15.6 percent, without adverse effects on six-degrees-of-freedom (6-DOFs) platform motions. Overall, the results confirm that SPLC enhances both fatigue and extreme load performance while maintaining stability, highlighting its potential as a practical and cost-effective control strategy to improve the reliability, durability, and commercial viability of FOWTs. Full article

This paper presents a 16 MW typhoon-resistant Tension Leg Platform floating offshore wind turbine (TLP FOWT) designed for the South China Sea. The survivability of the TLP FOWT under extreme environmental conditions is investigated through an integrated time-domain coupled analysis numerical model. The accuracy of the numerical model is calibrated by comparing its results with experimental data. In comparisons of mooring system static stiffness tests and white noise tests, the results from the calibrated numerical model show good agreement with the experimental data. Regarding the free decay tests and the statistical time-domain response results, the most significant discrepancies are only 1.17% and 6.91%, respectively. Subsequently, the time-domain response of the numerical model was investigated under extreme South China Sea conditions, configured according to the IEC 61400-3-2 design load conditions. The safety of the design was then evaluated against ABS specifications. The analysis yielded maximum platform motion amplitudes and inclinations of 34.99 m (less than 30% of water depth) and below 1°, respectively. Under both 50-year and 500-year return period conditions, the platform maintained stable TLP motion characteristics with no tendon slackness, evidenced by a minimum tendon tension of 107.23 kN. All motion responses and tendon tensions complied with the ABS safety factors, confirming the design’s capability to ensure safe operation throughout its service life. The present work provides valuable insights for the design and risk assessment of future large-scale TLP FOWTs. Full article

Offshore wind turbines (OWTs) are being developed with larger capacities for deeper waters, facing complex environmental loads that challenge structural safety. In contrast to onshore turbines, OWT foundations must withstand combined hydrodynamic forces (waves and currents), leading to substantially higher construction costs. For floating offshore wind turbines (FOWTs), additional considerations include radiation hydrodynamic loads and additional hydrodynamic damping effects caused by platform motion. Dynamic analysis of these foundations remains a critical bottleneck, presenting new challenges for offshore wind power advancement. This article first introduces the main structural types of OWT foundations, with case studies predominantly from China. The remaining part of the article proceeds as follows: dynamics of fixed OWT foundations, dynamics of FOWT foundations, and conclusions. Next, it covers several important topics related to fixed offshore wind turbines, including pile–soil interaction, wave loads, and seismic analysis. It then discusses support platform motion analysis, hydroelastic analysis, and mooring system characteristics of floating offshore wind turbines. Finally, it presents some insights to improve design and optimization methods for enhancing the safety and reliability of offshore wind turbines. This research clarifies OWT foundation dynamics, helping researchers address challenges and optimize designs. Full article

To address the current lack of specialized equipment for offshore wind platform installation and the unresolved challenges in deploying large offshore converter stations, this paper proposes a novel T–U-shaped barge for large offshore wind structures. First, a hydrodynamic model of the T–U-shaped barge is constructed and analyzed in ANSYS-AQWA. The influence of resonance occurring in the gap at the U-shaped stern on the frequency-domain model of the T–U-shaped barge is investigated. Subsequently, two installation configurations are examined: loading at the bow and loading at the stern of the T–U-shaped barge. This study comprehensively considers key components of the float-over installation system, including leg mating units (LMUs), deck support units (DSUs), fenders, and mooring cables. The results show that, for both installation schemes, the dynamic load distribution on each LMU evolves as the load-transfer stage progresses, and the sensitivity to wave period varies across different load-transfer stages, even under the same operating condition. This study evaluates the performance of the proposed T–U-shaped barge in the float-over installation of large offshore converter stations, demonstrating that its distinctive configuration endows it with strong functionality and provides valuable references for optimizing offshore wind-structure installation methods, as well as for the design and manufacturing of installation equipment. Full article

As one of the mooring foundation types for floating wind turbine platforms, research on the anchor pullout bearing characteristics of mooring pile foundations remains insufficient, and the underlying mechanism of anchor pullout bearing capacity needs further investigation and clarification. This paper conducts a numerical study on the bearing characteristics of mooring pile foundations under tensile anchoring forces with loading angles ranging from 0° to 90° and loading point depths of 0.2L, 0.4L, 0.6L, and 0.8L (where L is the pile length). The research findings indicate that the anchor pullout bearing capacity decreases as the loading angle increases from 0° to 90°, and exhibits a trend of first increasing and then decreasing with the increase in loading point depth. For rigid pile-anchors, the maximum anchor pullout bearing capacity occurs at a loading point depth of 0.6–0.8L, while for flexible piles, it appears at 0.4–0.6L. Both the bending moment and shear force of the pile shaft show abrupt changes at the loading point, where their maximum values also occur. This implies that the structural design at the loading point of the mooring pile foundation requires reinforcement. Meanwhile, the bending moment and shear force of the pile shaft gradually decrease with the increase in the loading angle, which is attributed to the gradual reduction of the horizontal load component. The axial force of the pile shaft also undergoes an abrupt change at the loading point, presenting characteristics where the upper section of the pile is under compression, the lower section is in tension, and both the pile top and pile tip are subjected to zero axial force. The depth of the loading point significantly influences the movement mode of the pile shaft. Shallow loading (0.2–0.4L) induces clockwise rotation, and the soil pressure around the pile is concentrated in the counterclockwise direction (90–270°). In the case of deep loading, counterclockwise rotation or pure translation of the pile shaft results in a more uniform stress distribution in the surrounding foundation soil, with the maximum soil pressure concentrated near the loading point. Full article

This work proposes a mid-fidelity load-mapping method for the structural analysis of semisubmersible floating offshore wind turbine substructures. Building on a hybrid linear potential flow and strip-theory dynamic analysis, the method maps hydrodynamic, current, hydrostatic, gravitational, inertial, mooring, and turbine loads onto a shell-based finite element (FE) model. The functionality of the proposed method is demonstrated through two case studies involving ultimate limit state analysis of a structurally reinforced OC4 DeepCwind semisubmersible platform. The analyses were conducted for two design load cases (DLCs) formulated to represent the metocean conditions at the Utsira Nord site, located off the coast of Norway. The accuracy of the mapped hydrostatic and potential flow loads is validated against dynamic simulation data, while a mesh convergence study is used to ensure reliable FE model performance. Results show that the highest von Mises stresses occur at unsupported heave-plate regions, internal stiffeners, and welded joints, with peak stresses safely below the steel’s yield strength. The more severe conditions of DLC 6.1 lead to a broader distribution of high-stress locations compared to DLC 1.6 but only a modest increase in peak stress. Full article

This study explores virtual sensing techniques for the Eolink floating offshore wind turbine (FOWT), which features a pyramidal platform and a single-point mooring system that enables weathervaning to maximize power production and reduce structural loads. To address the challenges and costs associated with monitoring submerged components, virtual sensors are investigated as an alternative to physical instrumentation. The main objective is to design a virtual sensor of mooring hawser loads using a reduced set of input features from GPS, anemometer, and inertial measurement unit (IMU) data. A virtual sensor is also proposed to estimate the bending moment at the joint of the pyramid masts. The FOWT is modeled in OrcaFlex, and a range of load cases is simulated for training and testing. Under defined sensor sampling conditions, both supervised and physics-informed machine learning algorithms are evaluated. The models are tested under aligned and misaligned environmental conditions, as well as across operating regimes below- and above-rated conditions. Results show that mooring tensions can be estimated with high accuracy, while bending moment predictions also perform well, though with lower precision. These findings support the use of virtual sensing to reduce instrumentation requirements in critical areas of the floating wind platform. Full article

This study analyzes the dynamic response of a floating dual vertical-axis tidal turbine platform under extreme environmental loads, focusing on two different mooring systems as follows: taut and catenary. The analysis assumes a non-operational turbine state where power generation is stopped, and the vertical turbines are lifted for structural protection. Using time-domain simulations via OrcaFlex 11.4, the floating platform’s motion and mooring line effective tensions are evaluated under high waves, strong wind, and current loads. The results reveal that sway and heave motions are significantly influenced by wave excitation, with the catenary system exhibiting larger responses due to mooring system features, while the taut system experiences higher mooring effective tension but shows more restrained motion. Notably, in the roll direction, both systems exhibit peak frequencies unrelated to the wave spectrum, attributed instead to resonance with the system’s natural frequencies—0.12438 Hz for taut and 0.07332 Hz for catenary. Additionally, the failure scenario of ML02 (Mooring Line 02) and the application of dynamic power cables to the floating platform are analyzed. The results demonstrate that under non-operational and extreme load conditions, mooring system type plays a main role in determining platform stability and structural safety. This comparative analysis offers valuable insights for selecting and designing mooring configurations optimized for reliability in extreme environmental conditions. Full article

Extreme sea conditions, particularly extreme operation gusts (EOGs), present a substantial threat to structures like floating offshore wind turbines (FOWTs) due to the intense loads they exert. In this work, we simulate EOGs and analyze the dynamic response of floating wind turbines. We conduct separate analyses of the operational state under the rated wind speed, the operational state, and the shutdown state under the EOG, focusing on the motion of the floating platform and the tension of the mooring lines of the FOWT. The results of our study indicate that under the influence of EOGs, the response of the FOWT changes significantly, especially in terms of the range of response variations. After the passage of an EOG, there are notable differences in the average response of each component of the wind turbine under the shutdown strategy. When compared to normal operation during EOGs, the shutdown strategy enables the FOWT to reach the extreme response value more rapidly. Subsequently, it also recovers response stability more quickly. However, a FOWT operating under normal conditions exhibits a larger extreme response value. Regarding pitch motion, the maximum response can reach 10.52 deg, which may lead to overall instability of the structure. Implementing a stall strategy can effectively reduce the swing amplitude to 6.09 deg. Under the action of EOGs, the maximum mooring tension reaches 1376.60 kN, yet no failure or fracture occurs in the mooring system. Full article

A barrier to the adoption of floating offshore wind turbines is their high cost relative to conventional fixed-bottom wind turbines. The largest contributor to this cost disparity is generally the floating substructure, due to its large size and complexity. Typically, a primary driver of the geometry and size of a floating substructure is the extreme environmental load case of Region 4, where platform loads are the greatest due to the impact of extreme wind and waves. To address this cost issue, a new concept for a floating offshore wind turbine’s substructure, its moorings, and anchors was optimized for a reference 10-MW turbine under extreme load conditions using OpenFAST. The levelized cost of energy was minimized by fixing the above-water turbine design and minimizing the equivalent substructure mass, which is based on the mass of all substructure components (stem, legs, buoyancy cans, mooring, and anchoring system) and associated costs of their materials, manufacturing, and installation. A stepped optimization scheme was used to allow an understanding of their influence on both the system cost and system dynamic responses for the extreme parked load case. The design variables investigated include the length and tautness ratio of the mooring lines, length and draft of the cans, and lengths of the legs and the stem. The dynamic responses investigated include the platform pitch, platform roll, nacelle horizontal acceleration, and can submergence. Some constraints were imposed on the dynamic responses of interest, and the metacentric height of the floating system was used to ensure static stability. The results offer insight into the parametric influence on turbine motion and on the potential savings that can be achieved through optimization of individual substructure components. A 36% reduction in substructure costs was achieved while slightly improving the hydrodynamic stability in pitch and yielding a somewhat large surge motion and slight roll increase. Full article

Floating offshore wind turbines present peculiar characteristics that make them particularly interesting for the implementation of wind farm control strategies such as wake mixing to increase the overall power production. Wake mixing is achieved by generating an unsteady cyclical load on the blades of upwind turbines to decrease the wind deficit on downwind turbines. The possibility of exploiting the yaw motion of a floating offshore wind turbine allows for amplified wake mixing or a reduction in the workload of the control mechanism. To amplify the yaw motion of the system at a selected excitation frequency, a multi-disciplinary optimization framework was developed to modify selected properties of the floating platform and mooring line configuration of the DTU 10 MW turbine on the Triple Spar platform. At the same time, operational and structural constraints were taken into account. A simulation-based approach was chosen to design a floating platform and mooring line configuration that were optimized to integrate with the new control strategy based on wake mixing in floating offshore wind farms. Modifying the floating platform spar arrangement and mooring line properties allowed us to tune the yaw natural frequency of the system in accordance with the excitation frequency of the wake control technique and amplify the yaw motion while controlling the deviations of the operational constraints and costs from the baseline configuration. Full article

The effects of wave and current on floating offshore wind turbines (FOWTs) are usually treated separately without considering their inherent interaction. In this study, the coupling effect of wave and current on the dynamic responses of a semi-submerged FOWT carrying a 5-MW NREL turbine is investigated. A numerical model considering the wave–current interaction is introduced, which accounts for the frequency shifts and surface profile changes for waves traveling over currents. The dynamic structural model of the semi-submerged FOWT is established in ANSYS AQWA, where the aero-servo-structural loadings on tower and turbine were obtained from the FAST platform by using the FAST-to-AQWA coding program. Irregular waves with 1- and 50-year return periods, in conjunction with a uniform current, were adopted to evaluate the coupling interaction effects. Waves traveling on positive and on opposite currents are examined in different cases with waves and currents propagating along the surge or sway direction. Waves consistently propagate along positive surge or sway direction. Waves interacting with positive or opposite currents have dramatically different modifications on the wave spectrum. Differences of up to 22% are recorded by comparing both the main motions and mooring tension when the interaction of waves and currents is considered or not. The coupling interaction between waves and currents has a limited influence on the tower base shear forces and bending moments. It was found that a straightforward superposition approach to evaluate the effect of the waves and the currents may underestimate the dynamic motions and mooring tension of FOWTs. Full article

Floating offshore wind turbine (FOWT) platforms are subject to a wide range of hydrodynamic loading and dynamic movement, making hydrodynamic force evaluation difficult. Amongst various floating platforms, submersible platforms are structurally complex, with multiple members held together by cross-braces. The influence of these members on hydrodynamic loading is poorly understood. An investigation of the effect of these members on loads is essential to optimise the design of FOWT platforms, mooring systems, and protective coatings, leading to a reduction in construction and maintenance costs. This paper numerically investigates the effect of structural members on the forces acting on a static semi-submersible platform in a unidirectional current flow of Reynolds number ($Re$) ranging from 2000 to 200,000, based on structural diameter and tidal velocity. The OC4 semi-submersible is chosen as the baseline platform. For each $Re$, this study is divided into three stages, such that in each stage, the number of members increased. These stages are as follows: (1) a finite cylinder (FC), (2) a finite cylinder with a heave plate (FCHP), (3) three cylinders with heave plates (TCHP) in an equilateral triangle arrangement, and (4) the OC4 semi-sub. The drag coefficient (${\overline{C}}_d$) increases with increasing structural members and weakly varies with increasing $Re$. However, the viscous drag coefficient (${\overline{C}}_f$) decreases with increasing $Re$, and a reverse trend is seen in the case of the pressure drag coefficient (${\overline{C}}_p$), with pressure drag dominating over friction drag. Further, the contribution of individual members is observed to vary with $Re$. The contribution of cylinders towards ${\overline{C}}_d$ is higher than heave plates, showing that contributions directly depend on the aspect ratio of members. In the case of TCHP and OC4, the contribution of the rear members is higher than that of the leading members due to the strong wake effect of the former. Also, the braces and pontoons of OC4 have contributed substantially towards total ${\overline{C}}_d$, unlike the central cylinder, which has experienced low drag due to the wake effect of the front cylinder and heave plate. Also, flow visualisation has shown vortex cores, and recirculating flows in the near wake of the cylinders and under the heave plates. Recirculation zones under the heave plates lead to vertical pressure on the structures. This vertical pressure increases with the number of structural members and the vertical pressure coefficient (${\overline{C}}_v$), varying with $Re$ due to three-dimensionality in the wake. Further, this pressure varies across the bottom surfaces of structures. Analyses of the streamwise pressure coefficient have shown it is highest on the front surfaces of cylinders. The highest friction is on the top and sides of the heave plates, and there is considerable friction on the sides of the cylinder. Full article
