Search Results (17)

The parallel steel wires used in arch bridge suspenders experience random corrosion damage on their surfaces during service. Corrosion damage, including micro-cracks, pitting, and a combination of both, leads to significant stress concentration under axial loading, which affects the performance of the steel wires. The change in the stress field caused by surface damage alters the stress intensity factor at the crack tip, and the presence of adjacent crack tips significantly amplifies the stress intensity factor, thereby accelerating crack propagation. The development of small surface damages in the steel wires is difficult to control and observe through experiments. By utilizing finite element methods for simulation, it is possible to intuitively analyze the crack propagation process, the trend of stress changes at the crack tip, and the interaction between damages. Numerical simulation results based on Paris’ law indicate that corrosion pits have a certain impact on the stress intensity factor at the crack tip. The propagation process of coplanar double cracks is highly sensitive to the initial crack size and the distance between adjacent crack tips. When the crack spacing is less than the crack depth, the stress intensity factor at the adjacent crack tips exhibits significant amplification. Based on this phenomenon, the coplanar double-crack system can be simplified to a complete single crack for analysis. By comparing the fatigue life of the double-crack system with that of the equivalent single crack, the effectiveness of the simplification rule has been validated. Full article

The existence of cracks is a key factor affecting the strength of concrete. However, traditional numerical methods still have some limitations in the simulation of crack growth in fissured concrete structures. Based on this background, the numerical treatment method of particle failure in smoothed particle hydrodynamics (SPH) is proposed, and the generation method for concrete meso-structures under the smoothed particle hydrodynamics (SPH) framework is developed. The concrete meso-models under different pre-existing micro-fissure inclinations and bridge angles (the inner tip line of the double pre-existing micro-fissure is defined as a bridge, and the angle between the bridge and the horizontal direction is defined as the bridge angle) were established, and numerical simulations of the crack propagation processes of concrete structures under tensile stress were carried out. The main findings were as follows: The concrete meso-structures and the pre-existing micro-fissures all have great impacts on the final failure modes of concrete. The stress–strain curve of the concrete model presents four typical stages. Finally, the crack initiation and propagation mechanisms of fissured concrete are discussed, and the application of smoothed particle hydrodynamics (SPH) in crack simulations of fissured concrete is prospected. Full article

This article presents the design, analysis, and prototype testing of a four-degrees-of-freedom (4-DoFs) spatial pose adjustment system (SPAS) that achieves high-precision positioning with 4-DoFs (Z/Tip/Tilt/$\Theta$). The system employs a piezoelectric-driven amplification mechanism that combines a bridge lever hybrid amplification mechanism, a double four-bar guide mechanism, and a multi-level lever symmetric rotation mechanism. By integrating these mechanisms, the system achieves low coupling, high stiffness, and wide stroke range. Analytical modeling and finite element analysis are employed to optimize geometric parameters. A prototype is fabricated, and its performance is verified through testing. The results indicate that the Z-direction feed microstroke is 327.37 $\mathsf{\mu }$m, the yaw motion angle around the X and Y axes is 3.462 mrad, and the rotation motion angle around the Z axis is 12.684 mrad. The x-axis and y-axis motion magnification ratio can reach 7.43. Closed-loop decoupling control experiments for multiple-input-multiple-outputs (MIMO) systems using inverse kinematics and proportional-integral-derivative feedback controllers were conducted. The results show that the Z-direction positioning accuracy is ±100 nm, the X and Y axis yaw motion accuracy is ±2 $\mathsf{\mu }$rad, and the Z-axis rotation accuracy is ±25 $\mathsf{\mu }$rad. Due to the ZTT$\Theta$ mechanism, the design proved to be feasible and advantageous, demonstrating its potential for precision machining and micro-nano manipulation. Full article

The structure of a bridge has certain peculiarities, and its pile foundations are susceptible to uplift or settlement deformation due to various factors. This can result in bridge deck cracking, structural instability, tilting, and even irreversible damage, which significantly impacts the bridge’s stability and driving safety. This study focuses on the Shiyangtai No.1 Bridge and aims to investigate the factors that cause abnormal rise and fall deformations of bridge pile foundations. The study combines macro and micro analysis, physical characteristic testing of the overlying soil under the bridge pile foundation, and numerical simulation of the bridge pile foundation in the goaf. The study discusses in-depth the formation mechanism of the abnormal uplift of some pile foundations of the Shiyangtai No.1 Bridge based on the analysis of the factors influencing the abnormal rise and fall deformation of the bridge pile foundations at home and abroad. The expansive soil beneath the pile foundation is weak, and the force generated by the water expansion is insufficient to cause the pile foundation to rise to 309 mm. The results indicate that the pile foundation of the bridge is not affected by the expansion characteristics of the overlying soil. The collapse of the goaf roof generates double lateral thrust from the accumulation body at the bottom of the goaf and the upper collapse arch. This causes staggered bending uplift of the sandstone soil layer, resulting in upward squeezing pressure that causes the bridge pile foundation to rise. Therefore, the coal mining area is the main factor influencing the abnormal uplift of the pile foundation of the Shiyangtai No.1 Bridge. Full article

In order to study the flexural fatigue resistance of calcium sulfate whisker-modified recycled fine aggregate concrete (RFAC), flexural fatigue cyclic loading tests at different stress levels (0.6, 0.7, and 0.9) considering a calcium sulfate whisker (CSW) admixture as the main influencing factor were designed. Furthermore, the fatigue life was analyzed, and fatigue equations were established using the three-parameter Weibull distribution function theory. In addition, the micro-morphology of CSW-modified recycled fine aggregate concrete was observed and analyzed through Scanning Electron Microscopy (SEM), and the strengthening and toughening mechanisms of CSW on recycled fine aggregate concrete were further explored. The test results demonstrate that the inclusion of recycled fine aggregate reduces the fatigue life of concrete, while the incorporation of CSW can effectively improve the fatigue life of the recycled fine aggregate concrete, where 1% of CSW modification can extend the fatigue life of recycled fine aggregate concrete by 56.5%. Furthermore, the fatigue life of concrete under cyclic loading decreases rapidly as the maximum stress level increases. Fatigue life equations were established with double logarithmic curves, and P-S-N curves considering different survival probabilities (p = 0.5, 0.95) were derived. Microscopic analyses demonstrate that the CSW has a “bridging” effect at micro-seams in the concrete matrix, delaying the generation and enlargement of micro-cracks in the concrete matrix, thus resulting in improved mechanical properties and flexural fatigue resistance of the recycled fine aggregate concrete. Full article

Remote and real-time displacement measurements are crucial for a successful bridge health monitoring program. Researchers have attempted to monitor the deformation of bridges using remote sensing techniques such as an accelerometer when a static reference frame is not available. However, errors accumulate throughout the double-integration process, significantly reducing the reliability and accuracy of the displacement measurements. To obtain accurate reference-free bridge displacement measurements, this paper aims to develop a real-time computing algorithm based on hybrid sensor data fusion and implement the algorithm via smart sensing technology. By combining the accelerometer and strain gauge measurements in real time, the proposed algorithm can overcome the limitations of the existing methods (such as integration errors, sensor drifts, and environmental disturbances) and provide real-time pseud-static and dynamic displacement measurements of bridges under loads. A wireless sensor, SmartRock, containing multiple sensing units (i.e., triaxial accelerometer and strain gauges) and a Micro Controlling Unit (MCU) were utilized for remote data acquisition and signal processing. A remote sensing system (with SmartRocks, an antenna, an industrial computer, a Wi-Fi hotspot, etc.) was deployed, and a laboratory truss bridge experiment was conducted to demonstrate the implementation of the algorithm. The results show that the proposed algorithm can estimate a bridge displacement with sufficient accuracy, and the remote system is capable of the real-time monitoring of bridge deformations compared to using only one type of sensor. This research represents a significant advancement in the field of bridge displacement monitoring, offering a reliable and reference-free approach for remote and real-time measurements. Full article

The Silurian strata in the Shunbei No. 5 fault zone have the characteristics of long open holes, easy leakage and complex leakage. In the early stages, plugging technologies and methods such as bridging plugging, cement, chemical consolidation and high-water-loss plugging have poor effects and low plugging efficiency. Plugging slurry directly prepared with drilling fluid has low filtration characteristics, and the main reason is that the plugging material cannot filter quickly after the fluid enters the fracture. Based on the basic principle of fast filtration, the main plugging fluid M-Fluid, the micro-elastic high-strength main plugging agent M-Block and the filling agent Filling-Seal have been developed. In combination with the water-loss and wall-building properties of the circulating drilling fluid after plugging, a fast plugging technology for fractured volcanic rock formation has been established. The laboratory evaluation experiment showed that the filtration rate increased rapidly with the increase of temperature, and the filtration rate was about 0.31~0.79 mL/s, while the filtration rate of the drilling fluid was 0.0067 mL/s under the same conditions. The pressure-bearing capacity of various plugging evaluation methods, such as the simulated fracture of a large-grain sand bed, artificial fracture of small core and full-size core and multi-form fracture of double core, all exceed 5 MPa, and the system has a good plugging effect for complex fractures. Full article

Humans show micro-expressions (MEs) under some circumstances. MEs are a display of emotions that a human wants to conceal. The recognition of MEs has been applied in various fields. However, automatic ME recognition remains a challenging problem due to two major obstacles. As MEs are typically of short duration and low intensity, it is hard to extract discriminative features from ME videos. Moreover, it is tedious to collect ME data. Existing ME datasets usually contain insufficient video samples. In this paper, we propose a deep learning model, double-stream 3D convolutional neural network (DS-3DCNN), for recognizing MEs captured in video. The recognition framework contains two streams of 3D-CNN. The first extracts spatiotemporal features from the raw ME videos. The second extracts variations of the facial motions within the spatiotemporal domain. To facilitate feature extraction, the subtle motion embedded in a ME is amplified. To address the insufficient ME data, a macro-expression dataset is employed to expand the training sample size. Supervised domain adaptation is adopted in model training in order to bridge the difference between ME and macro-expression datasets. The DS-3DCNN model is evaluated on two publicly available ME datasets. The results show that the model outperforms various state-of-the-art models; in particular, the model outperformed the best model presented in MEGC2019 by more than 6%. Full article

As an important part of the DC micro-grid, DC solid-state transformers (DCSST) usually use a dual-loop control that combines the input equalization and output voltage loop. This strategy fails to ensure output equalization when the parameters of each dual active bridge (DAB) converter module are inconsistent, thus reducing the operational efficiency of the DCSST. To solve the above problems, a DCSST-balancing control strategy based on loop current suppression is presented. By fixing the phase-shifting angle within the bridge and adjusting the phase-shifting angle between bridges, the circulation current of each DAB converter module is reduced. Based on the double-loop control of the DAB, five controllers are nested outside each DAB submodule to achieve distributed control of the DCSST. The proposed control strategy can reduce the system circulation current with different circuit parameters of the submodules, ensure the balance of input voltage and output current of each submodule, and increase the robustness of the system. The simulation results verify the validity of the proposed method. Full article

A double-bridge shape is proposed as a novel flow channel cross-sectional shape of a membraneless microfluidic fuel cell, and its electrochemical performance was analyzed with a numerical model. A membraneless microfluidic fuel cell (MMFC) is a micro/nano-scale fuel cell with better economic and commercial viability with the elimination of the polymer electrolyte membrane. The numerical model involves the Navier–Stokes, Butler–Volmer, and mass transport equations. The results from the numerical model were validated with the experimental results for a single-bridge channel. The proposed MMFC with double-bridge flow channel shape performed better in comparison to the single-bridge channel shape. A parametric study for the double-bridge channel was performed using three sub-channel widths with the fixed total channel width and the bridge height. The performance of the MMFC varied most significantly with the variation in the width of the inner channel among the sub-channel widths, and the power density increased with this channel width because of the reduced width of the mixing layer in the inner channel. The bridge height significantly affected the performance, and at a bridge height at 90% of the channel height, a higher peak power density of 171%was achieved compared to the reference channel. Full article

The capillary action between two solid surfaces has drawn significant attention in micro-objects manipulation. The axisymmetric capillary bridges and capillary forces between a spherical concave gripper and a spherical particle are investigated in the present study. A numerical procedure based on a shooting method, which consists of double iterative loops, was employed to obtain the capillary bridge profile and bring the capillary force subject to a constant volume condition. Capillary bridge rupture was characterized using the parameters of the neck radius, pressure difference, half-filling angle, and capillary force. The effects of various parameters, such as the contact angle of the spherical concave gripper, the radius ratio, and the liquid bridge volume on the dimensionless capillary force, are discussed. The results show that the radius ratio has a significant influence on the dimensionless capillary force for the dimensionless liquid bridge volumes of 0.01, 0.05, and 0.1 when the radius ratio value is smaller than 10. The effectiveness of the theorical approach was verified using simulation model and experiments. Full article

Lipoteichoic acid (LTA) is a cell wall component of Gram-positive bacteria. Limited data suggest that LTA is beneficial for bone regeneration in vitro. Thus, we used a mouse model of femoral defects to explore the effects of LTA on bone healing in vivo. Micro-computed tomography analysis and double-fluorochrome labeling were utilized to examine whether LTA can accelerate dynamic bone formation in vivo. The effects of LTA on osteoblastogenesis and osteoclastogenesis were also studied in vitro. LTA treatment induced prompt bone bridge formation, rapid endochondral ossification, and accelerated healing of fractures in mice with femoral bone defects. In vitro, LTA directly enhanced indicators of osteogenic factor-induced MC3T3-E1 cell differentiation, including alkaline phosphatase activity, calcium deposition and osteopontin expression. LTA also inhibited osteoclast activation induced by receptor activator of nuclear factor-kappa B ligand. We identified six molecules that may be associated with LTA-accelerated bone healing: monocyte chemoattractant protein 1, chemokine (C-X-C motif) ligand 1, cystatin C, growth/differentiation factor 15, endostatin and neutrophil gelatinase-associated lipocalin. Finally, double-fluorochrome, dynamic-labeling data indicated that LTA significantly enhanced bone-formation rates in vivo. In conclusion, our findings suggest that LTA has promising bone-regeneration properties. Full article

A three-axis accelerometer with a double L-shaped beams structure was designed and fabricated in this paper, consisting of a supporting body, four double L-shaped beams and intermediate double beams connected to two mass blocks. When applying acceleration to the accelerometer chip, according to the output voltage changes of three Wheatstone bridges constituted by twelve piezoresistors on the roots of the beams, the corresponding acceleration along three axes can be measured based on the elastic force theory and piezoresistive effect. To improve the characteristics of the three-axis accelerometer, we simulated how the width of the intermediate double beams affected the characteristics. Through optimizing the structure size, six chips with different widths of intermediate double beams were fabricated on silicon-on-insulator (SOI) wafers using micro-electromechanical systems (MEMS) technology and were packaged on printed circuit boards (PCB) by using an electrostatic bonding process and inner lead bonding technology. At room temperature and V_DD = 5.0 V, the resulting accelerometer with an optimized size (w = 500 μm) realized sensitivities of 0.302 mV/g, 0.235 mV/g and 0.347 mV/g along three axes, with a low cross-axis sensitivity. This result provides a new strategy to further improve the characteristics of the three-axis accelerometer. Full article

In this paper, we present our work developing a family of silicon-on-insulator (SOI)–based high-g micro-electro-mechanical systems (MEMS) piezoresistive sensors for measurement of accelerations up to 60,000 g. This paper presents the design, simulation, and manufacturing stages. The high-acceleration sensor is realized with one double-clamped beam carrying one transversal and one longitudinal piezoresistor on each end of the beam. The four piezoresistors are connected to a Wheatstone bridge. The piezoresistors are defined to 4400 Ω, which results in a width-to-depth geometry of the pn-junction of 14 μm × 1.8 μm. A finite element method (FEM) simulation model is used to determine the beam length, which complies with the resonance frequency and sensitivity. The geometry of the realized high-g sensor element is 3 × 2 × 1 mm³. To demonstrate the performance of the sensor, a shock wave bar is used to test the sensor, and a Polytec vibrometer is used as an acceleration reference. The sensor wave form tracks the laser signal very well up to 60,000 g. The sensor can be utilized in aerospace applications or in the control and detection of impact levels. Full article

Dual-frequency Global Positioning System (GPS) Real-time Kinematics (RTK) has been proven in the past few years to be a reliable and efficient technique to obtain high accuracy positioning. However, there are still challenges for GPS single-frequency RTK, such as low reliability and ambiguity resolution (AR) success rate, especially in kinematic environments. Recently, multi-Global Navigation Satellite System (multi-GNSS) has been applied to enhance the RTK performance in terms of availability and reliability of AR. In order to further enhance the multi-GNSS single-frequency RTK performance in terms of reliability, continuity and accuracy, a low-cost micro-electro-mechanical system (MEMS) inertial measurement unit (IMU) is adopted in this contribution. We tightly integrate the single-frequency GPS/BeiDou/GLONASS and MEMS-IMU through the extended Kalman filter (EKF), which directly fuses the ambiguity-fixed double-differenced (DD) carrier phase observables and IMU data. A field vehicular test was carried out to evaluate the impacts of the multi-GNSS and IMU on the AR and positioning performance in different system configurations. Test results indicate that the empirical success rate of single-epoch AR for the tightly-coupled single-frequency multi-GNSS RTK/INS integration is over 99% even at an elevation cut-off angle of 40°, and the corresponding position time series is much more stable in comparison with the GPS solution. Besides, GNSS outage simulations show that continuous positioning with certain accuracy is possible due to the INS bridging capability when GNSS positioning is not available. Full article
