This report is on Co and Ti substituted M-type barium and strontium hexagonal ferrites that are reported to be single phase multiferroics due to a transition from Neel type ferrimagnetic order to a spiral spin structure that is accompanied by a ferroelectric polarization in an applied magnetic field. The focus here is the nature of magnetoelectric (ME) interactions in the bilayers of ferroelectric PZT and Co and Ti substituted BaM and SrM. The ME coupling in the ferrite-PZT bilayers arise due to the transfer of magnetostriction-induced mechanical deformation in a magnetic field in the ferrite resulting in an induced electric field in PZT. Polycrystalline Co and Ti doped ferrites, Ba (CoTi)_x Fe_12−2xO_19, (BCTx), and Sr (CoTi)_x Fe_12−2xO₁₉ (SCTx) (x = 0–4) were found to be free of impurity phases for all x-values except for SCTx, which had a small amount of α-Fe₂O₃ in the X-ray diffraction patterns for x ≤ 2.0. The magnetostriction for the ferrites increased with applied filed H to a maximum value of around 2 to 6 ppm for H~5 kOe. BCTx/SCTx samples showed ferromagnetic resonance (FMR) for x = 1.5–2.0, and the estimated anisotropy field was on the order of 5 kOe. The magnetization increased with the amount of Co and Ti doping, and it decreased rapidly with x for x > 1.0. Measurements of ME coupling strengths were conducted on the bilayers of BCTx/SCTx platelets bonded to PZT. The bilayer was subjected to an AC and DC magnetic field H, and the magnetoelectric voltage coefficient (MEVC) was measured as a function of H and frequency of the AC field. For BCTx-PZT, the maximum value of MEVC at low frequency was ~5 mV/cm Oe, and a 40-fold increase at electromechanical resonance (EMR). SCTx–PZT composites also showed a similar behavior with the highest MEVC value of ~14 mV/cm Oe at low frequencies and ~200 mV/cm Oe at EMR. All the bilayers showed ME coupling for zero magnetic bias due to the magnetocrystalline anisotropy field in the ferrite that provided a built-in bias field. Full article

Avalanche hazard prediction remains a crucial task for mountainous regions worldwide. This study presents the development and field testing of a prototype automated avalanche hazard monitoring system designed for the East Kazakhstan region. The system integrates a snow avalanche station (including temperature, humidity, and pressure sensors; a magnetoelectric wind sensor; a data logger; and devices for autonomous operation), a temperature snow measuring rod, an API (application programming interface) service for storing weather and climate parameters in a database, and a web interface. Powered by autonomous solar energy solutions, the system ensures continuous, high-resolution monitoring of key environmental parameters. Using initial test datasets, we analyzed the specific strengths and weaknesses of the developed monitoring system using the example of one avalanche site. Avalanche prediction was performed using regression analysis (logistic regression). The evaluation of the model showed a high forecasting accuracy, with recognition rates exceeding 98%. The obtained regression coefficients can be used to predict avalanches based on meteorological data collected using the proposed equipment. The developed solution holds significant promise for improving avalanche risk management practices and can be expanded for broader application in both national and international contexts. Full article

Composites of ferromagnetic and ferroelectric phases are of interest for studies on mechanical strain-mediated coupling between the two phases and for a variety of applications in sensors, energy harvesting, and high-frequency devices. Nanocomposites are of particular importance since their surface area-to-volume ratio, a key factor that determines the strength of magneto-electric (ME) coupling, is much higher than for bulk or thin-film composites. Core–shell nano- and microcomposites of the ferroic phases are the preferred structures, since they are free of any clamping due to substrates that are present in nanobilayers or nanopillars on a substrate. This review concerns recent efforts on ME coupling in coaxial fibers of spinel or hexagonal ferrites for the magnetic phase and PZT or barium titanate for the ferroelectric phase. Several recent studies on the synthesis and ME measurements of fibers with nickel ferrite, nickel zinc ferrite, or cobalt ferrite for the spinel ferrite and M-, Y-, and W-types for the hexagonal ferrites were considered. Fibers synthesized by electrospinning were found to be free of impurity phases and had uniform core and shell structures. Piezo force microscopy (PFM) and scanning microwave microscopy (SMM) measurements of strengths of direct and converse ME effects on individual fibers showed evidence for strong coupling. Results of low-frequency ME voltage coefficient and magneto-dielectric effects on 2D and 3D films of the fibers assembled in a magnetic field, however, were indicative of ME couplings that were weaker than in bulk or thick-film composites. A strong ME interaction was only evident from data on magnetic field-induced variations in the remnant ferroelectric polarization in the discs of the fibers. Follow-up efforts aimed at further enhancement in the strengths of ME coupling in core–shell composites are also discussed in this review. Full article

A giant magnetoelectric coefficient has been discovered in laminated magnetoelectric composites incorporating piezoelectric and magnetostrictive layers, which reveals a high sensitivity in AC magnetic field detection under a DC bias field. However, the DC-biased magnetoelectric composites are not capable of detecting DC magnetic fields due to the interference with the DC signal to be measured. Here, we demonstrate a portable magnetoelectric gaussmeter based on torque effect that can detect both DC and AC magnetic fields. The proposed gaussmeter is equipped with a magnetoelectric sensor, a charge amplification module, a signal processing circuit, a power module, a data processing program, a display module, etc. The proposed gaussmeter indicates such performance indexes as an intensity range of 0~10 Oe, frequency range of DC~500 Hz, AC detection limit of 0.01 Oe, DC detection limit of 0.08 Oe, and frequency resolution of 1 Hz. Being powered by a power adapter (or a battery) of 5V 2A, the whole device system is pocket-size, low-cost, and highly portable, demonstrating its potential for magnetic field detection as a distributed sensor. Full article

In this work, a tachometer based on a Metglas/PZT/Metglas magnetoelectric (ME) composite was developed to achieve high-precision rotational speed measurement over a wide temperature range (−70 °C to 160 °C). The tachometer converts external magnetic signals into electrical signals through the ME effect and operates stably in extreme temperature environments. COMSOL Multiphysics software was used for simulation analysis to investigate the ME response characteristics of the composite in such environments. To evaluate the properties of the ME composite under different conditions, its response characteristics at various frequencies, DC bias, and temperatures were systematically investigated. A permanent magnet and a DC motor were used to simulate gear rotation, and the voltage output was analyzed by adjusting the position between the sensor and the DC motor. The results show that the measured values of the ME tachometer closely match the set values, and the tachometer demonstrates high measurement accuracy within the range of 480 to 1260 revolutions per minute (rpm). Additionally, the properties of the ME composite at different temperatures were examined. In the temperature range from −70 °C to 160 °C, the ME coefficients exhibit good regularity and stability, with the measured trend closely matching the simulation results, ensuring the reliability and accuracy of the ME tachometer. To verify its practicality, the measurement capability of the ME tachometer was comprehensively tested under extreme temperature conditions. The results show that in high-temperature environments, the tachometer can accurately measure speed while maintaining a high signal-to-noise ratio (SNR), demonstrating excellent anti-interference ability. The proposed ME tachometer shows promising application potential in extreme temperature conditions, particularly in complex industrial environments that require high reliability and precision. Full article

Using Green’s function theory and a microscopic model, the multiferroic properties of ${\mathrm{Co}}_4{\mathrm{Nb}}_2{\mathrm{O}}_9$ are investigated theoretically. There are some discrepancies in the discussion of the electric and dielectric behavior of CNO with and without external magnetic fields. We try to clarify them. It is observed that the polarization and the dielectric constant do not show a peak at the antiferromagnetic phase transition temperature $T_N$ without an external magnetic field h. But applying h, there appears a peak around the Neel temperature $T_N$, which increases with increasing h and then shifts to lower temperatures. The magneto-dielectric coefficient MD$(T,h)$ is also calculated. Moreover, the magnetization rises with an increasing external electric field below the Neel temperature. This shows strong magnetoelectric coupling in ${\mathrm{Co}}_4{\mathrm{Nb}}_2{\mathrm{O}}_9$. The obtained results are compared with the existing experimental data. There is a good qualitative agreement. Full article

Improving the hardness and wear resistance of die cutting tools is an important issue in the study of the service life of die cutting equipment. Using laser cladding technology, nickel-based composite coatings with varying BiFeO₃ contents were prepared on a 45 steel substrate, because BiFeO₃ can have an effect on the dilution rate and microstructure of the sample; morover BiFeO₃ is a new type of multiferroic material with certain magneto-electric coupling effects which can be prepared for the study of added magnetic fields. The microstructure and morphology were characterized to determine the optimal BiFeO₃ content. Based on the optimal addition of BiFeO₃, a comparative analysis was conducted to investigate the effect of different magnetic field strengths under a composite energy field on the microstructure, hardness, and wear resistance of Ni-based WC cladding layers. The results show that the optimal addition of BiFeO₃ was 5 wt%. At this concentration, there were no significant porosity defects in the coating, and the dilution rate was appropriate (4.77%). Additionally, the interface bonding strength was also increased. With optimal BiFeO₃ addition, stirring with different magnetic field strengths was applied to the cladding layer, and the results show that the aspect ratio of the cladding layer gradually increased with increasing the alternating magnetic field strength. When the magnetic field strength in the composite energy field was 40 mT, the microstructure was fine and uniform, the hardness of the cladding layer reached the highest level, about 925.2 HV_1.0, the wear resistance was also the best, the friction coefficient of the cladding layer was about 0.54, and the width of the wear mark was about 0.53 mm. Full article

This report is on magneto-electric (ME) interactions in bulk composites with coaxial fibers of nickel–zinc ferrite and PZT. The core–shell fibers of PZT and Ni_1−xZn_xFe₂O₄ (NZFO) with x = 0–0.5 were made by electrospinning. Both kinds of fibers, either with ferrite or PZT core and with diameters in the range of 1–3 μm were made. Electron and scanning probe microscopy images indicated well-formed fibers with uniform core and shell structures and defect-free interface. X-ray diffraction data for the fibers annealed at 700–900 °C did not show any impurity phases. Magnetization, magnetostriction, ferromagnetic resonance, and polarization P versus electric field E measurements confirmed the ferroic nature of the fibers. For ME measurements, the fibers were pressed into disks and rectangular platelets and then annealed at 900–1000 °C for densification. The strengths of strain-mediated ME coupling were measured by the H-induced changes in remnant polarization P_r and by low-frequency ME voltage coefficient (MEVC). The fractional change in P_r under H increased in magnitude, from +3% for disks of NFO–PZT to −82% for NZFO (x = 0.3)-PZT, and a further increase in x resulted in a decrease to a value of −3% for x = 0.5. The low-frequency MEVC measured in disks of the core–shell fibers ranged from 6 mV/cm Oe to 37 mV/cm Oe. The fractional changes in P_r and the MEVC values were an order of magnitude higher than for bulk samples containing mixed fibers with a random distribution of NZFO and PZT. The bulk composites with coaxial fibers have the potential for use as magnetic field sensors and in energy-harvesting applications. Full article

Pure Bi₇Fe₃Ti₃O₂₁ ceramic material and gadolinium ion (Gd³⁺)-doped ones were prepared by solid-state reaction method using simple oxides. The findings of the XRD measurements confirmed the initial author’s assumption that the dopant ions substituted in perovskite blocks influenced the dimensions of the unit cell parameters. All obtained materials are single-phase and show an orthorhombic structure with the Fm2m space group. Microstructure studies show that the admixture gadolinium doping changes the microstructure of the base material, changing grain shapes from plate-like to rounded. The temperature dependences of the electric permittivity have shown the existence of a maximum, the temperature location of which depends on both the frequency and the concentration of Gd³⁺ ions. The highest values of electric permittivity were characteristic of the material with an admixture of Gd³⁺ ions in the amount of x = 0.6 (f = 1 kHz), and the lowest values were for material with x = 0.2 (f = 1 kHz). Studies of the magnetoelectric effect have shown that the strongest coupling between magnetic and electrical properties was demonstrated by a material doped with Gd³⁺ ions in the amount of x = 0.2, for which the magnetoelectric coupling coefficient is equal to α = 12.58·10⁻⁹ s/m. Full article

The search for novel materials with enhanced characteristics for the advancement of flexible electronic devices and energy harvesting devices is currently a significant concern. Multiferroics are a prominent example of energy conversion materials. The magnetoelectric conversion in a flexible composite based on a piezopolymer layer and a magnetic elastomer layer was investigated. The study focused on investigating the dynamic magnetoelectric effect in various configurations of external alternating and constant homogeneous magnetic fields (L-T and T-T configurations). The T-T geometry exhibited a two orders of magnitude higher coefficient of the magnetoelectric effect compared to the L-T geometry. Mechanisms of structure bending in both geometries were proposed and discussed. A theory was put forward to explain the change in the resonance frequency in a uniform external field. A giant value of frequency tuning in a magnetic field of up to 362% was demonstrated; one of the highest values of the magnetoelectric effect yet recorded in polymer multiferroics was observed, reaching up to 134.3 V/(Oe∙cm). Full article

In the present work, we have synthesized rare-earth ion modified Bi_4−xRE_xTi₂Fe0_.7Co_0.3O_12−δ (RE = Dy, Sm, La) multiferroic compounds by the conventional solid-state route. Analysis of X-ray diffraction by Rietveld refinement confirmed the formation of a polycrystalline orthorhombic phase. The morphological features revealed a non-uniform, randomly oriented, plate-like grain structure. The peaks evident in the Raman spectra closely corresponded to those of orthorhombic Aurivillius phases. Dielectric studies and impedance measurements were carried out. Asymmetric complex impedance spectra suggested the relaxation of charge carriers belonging to the non-Debye type and controlled by a thermally activated process. Temperature-dependent AC conductivity data showed a change of slope in the vicinity of the phase transition temperature of both magnetic and electrical coupling natures. Based on the universal law and its exponent nature, one can suppose that the conduction process is governed by a small polaron hopping mechanism but significant distortion of TiO₆ octahedral. The doping of the A-sites with rare-earth element ions and changes in the concentrations of Fe and Co ions located on the B-sites manifested themselves in saturated magnetic hysteresis loops, indicating competitive interactions between ferroelectric and canted antiferromagnetic spins. The magnetic order in the samples is attributed to pair-wise interactions between adjacent Fe³⁺–O–Fe³⁺, Co^2+/3+–O–Co^3+/2+, and Co^2+/3+–O–Fe³⁺ ions or Dzyaloshinskii–Moriya interactions among magnetic ions in the adjacent sub-lattices. As a result, enhanced magnetoelectric coefficients of 42.4 mV/cm-Oe, 30.3 mV/cm-Oe, and 21.6 mV/cm-Oe for Bi_4−xDy_xTi₂Fe0_.7Co_0.3O_12−δ (DBTFC), Bi_4−xLa_xTi₂Fe0_.7Co_0.3O_12−δ (LBTFC), and Bi_4−xSm_xTi₂Fe0_.7Co_0.3O_12−δ (SBTFC), respectively, have been obtained at lower magnetic fields (<3 kOe). The strong coupling of the Aurivillius compounds observed in this study is beneficial to future multiferroic applications. Full article

Acoustically actuated magnetoelectric (ME) antennas utilize acoustic wave resonance to complete the process of receiving and transmitting signals, which promotes the development of antenna miniaturization technology. This paper presents a bilayer magnetostrictive/AlN ME laminated antenna. The proposed laminated antenna uses the FeGa/FeGaB bilayer materials as magnetostrictive materials, which combine the advantages of soft magnetic properties of FeGa and the low loss of FeGaB. First, multiphysics modeling and analysis are performed for the proposed ME laminated antenna by finite element method (FEM). The positive/inverse ME effects and the influences of the volume ratio of the FeGa/FeGaB bilayer on the antenna performance are studied. The results show that the output voltage and ME coefficient of the FeGa/FeGaB bilayer magnetostrictive material with a volume ratio of 1:1 are 3.97 times and 195.8% higher than that of the single FeGaB layer, respectively. The eddy current loss is 52.08% lower than that of single-layer FeGa. According to the surface equivalence principle, the far-field radiation process is simulated. The results show that the gain of the ME antenna is 15 dB larger than that of the same-size micro-loop antenna, and the gain of the ME antenna is about −44.9 dB. The improved performance and magnetic tunability of the proposed bilayer magnetostrictive materials make ME antennas excellent candidates for portable devices and implantable medical devices. Full article

Magnetoelectric (ME) sensors cannot effectively detect broadband magnetic field signals due to their narrow bandwidth, and existing readout circuits are unable to vary the bandwidth of the sensors. To expand the bandwidth, this paper introduces a negative-feedback readout circuit, fabricated by introducing a negative-feedback compensation circuit based on the direct readout circuit of the ME sensor. The negative-feedback compensation circuit contains a current amplifier, a feedback resistor, and a feedback coil. For this purpose, a Metglas/PVDF/Metglas ME sensor was prepared. Experimental measurements show that there is a six-fold difference between the maximum and minimum values of the ME voltage coefficients in the 6–39 kHz frequency band for the ME sensor without the negative-feedback compensation circuit when the sensor operates at the optimal bias magnetic field. However, the ME voltage coefficient in this band remains stable, at 900 V/T, after the charge amplification of the direct-reading circuit and the negative-feedback circuit. In addition, experimental results show that this negative-feedback readout circuit does not increase the equivalent magnetic noise of the sensor, with a noise level of 240 pT/√Hz in the frequency band lower than 25 kHz, 63 pT/√Hz around the resonance frequency of 30 kHz, and 620 pT/√Hz at 39 kHz. This paper proposes a negative-feedback readout circuit based on the direct readout circuit, which greatly increases the bandwidth of ME sensors and promotes the widespread application of ME sensors in the fields of broadband weak magnetic signal detection and DBS electrode positioning. Full article

This article is devoted to the theory of the converse magnetoelectric (CME) effect for the longitudinal, bending, longitudinal-shear, and torsional resonance modes and its quasi-static regime. In contrast to the direct ME effect (DME), these issues have not been studied in sufficient detail in the literature. However, in a number of cases, in particular in the study of low-frequency ME antennas, the results obtained are of interest. Detailed calculations with examples were carried out for the longitudinal mode on the symmetric and asymmetric structures based on Metglas/PZT (LN); the bending mode was considered for the asymmetric free structure and structure with rigidly fixed left-end Metglas/PZT (LN); the longitudinal-shear and torsional modes were investigated for the symmetric and asymmetric free structures based on Metglas/GaAs. For the identification of the torsion mode, it was suggested to perform an experiment on the ME structure based on Metglas/bimorphic LN. All calculation results are presented in the form of graphs for the CME coefficients. Full article

A mesoscopic model for a polymer-based magnetoelectric (ME) composite film is developed. The film is assumed to consist of a piezoelectric polymer matrix of the PVDF type filled with CFO-like single-domain nanoparticles. The model is treated numerically and enables one to obtain in detail the intrinsic distributions of mechanical stress, polarization and electric potential and helps to understand the influence of the main configurational parameters, viz., the poling direction and the orientational order of the particle magnetic anisotropy axes on the electric response of the film. As the model is fairly simple—it uses the RVE-like (Representative Volume Element) approach with a single-particle cell—the results obtained are rather of qualitative than quantitative nature. However, the general conclusions seem to be independent of the particularities of the model. Namely, the presented results establish that the customary ME effect in composite films always comprises at least two contributions of different origins, viz., the magnetostrictive and the magnetoactive (magnetorotational) ones. The relative proportion between those contributions is quite movable depending on the striction coefficient of the particles and the stiffness of the polymer matrix. This points out the necessity to explicitly take into account the magnetoactive contribution when modeling the ME response of composite films and when interpreting the measurements on those objects. Full article
