Search Results (40)

Trip faults are obviously increased by frequent lightning strikes, and increasing lightning trip-out seriously affects a system’s stability and power supply reliability. In this paper, the reasons for high lightning trip-out rates in electric power transmission lines are analyzed in detail from three perspectives, as follows: the substandard lightning resistance level, lightning complexity at a mid-point between towers, and the complexity of first and subsequent lightning stroke conditions. Experiments and simulations demonstrate that the solid-phase gas arc-extinguishing method has a strong ability to extinguish power–frequency continuous-current arcs and to protect against first and subsequent lightning strokes. Since the time taken by gas arc-extinguishing is much less than the response time of relay protection, trip accidents caused by lightning strikes can be avoided and the trip rates of lightning strikes can be reduced using this method. The case analysis and practical operation results show that the solid-phase gas arc-extinguishing lightning protection method can reduce the lightning trip-out rate by more than 90%, completely solve the problem of high lightning trip-out rates, and significantly improve the reliability of power supply. Full article

The asymmetric operation is a method that allows High and Extra-High Voltage (HV, EHV) power lines to function with one or two phases open. With the increasing share of Renewable Energy Sources (RES) in National Power Systems (NPS), they are becoming more volatile and less reliable due to decreasing inertia and other issues related to the integration and exploitation of the Inverter-Based Resources (IBR) (decreasing short-circuit ratio, different types of interactions, etc.). On the other hand, phase-to-ground faults are a common cause of tripping off power lines which affects the overall reliability of the power system. Thus, for power systems experiencing a decreasing trend in reliability and robustness, the asymmetrical operation of the power lines may enhance them. In this way, this article reviews the state of the art and new developments in the academic landscape regarding asymmetrical operation. The review is not, however, limited to HV and EHV systems, so it examines cases of asymmetric operation in Low and Medium Voltages (LV, MV) as well. The challenges and opportunities that this unique mode of operation imposes on power networks are also presented, providing a fresh reference for researchers looking to enter this topic. Full article

This paper proposes a sophisticated, fault-tolerant, and centralized secondary controller that is designed for inverter-based, islanded microgrids. The proposed controller enhances system resilience to unexpected network partitions, which typically occur due to the tripping of protective devices under fault conditions. In typical radially configured MGs, a line fault can cause protective devices to isolate the faulted line, thereby splitting the MG into two electrically independent sub-microgrids (SMGs), while retaining the existing communication and control framework. In contrast to traditional centralized and distributed secondary controllers, which often fail to restore the frequency to the nominal value (50 Hz) in split SMGs, the proposed controller exhibits exceptional performance. Through simulation studies on 6-bus and 13-bus islanded MG setups, the controller has not only demonstrated its ability to swiftly restore the nominal frequency in both SMGs within a few seconds (specifically 5 s), but also to ensure fair power distribution among the distributed generators (DGs) supplying the SMGs. This rapid frequency stabilization underscores the controller’s effectiveness in maintaining stable frequency levels immediately following a fault. In contrast, the use of traditional centralized and consensus controllers typically results in a frequency deviation of about 3 Hz from the nominal value in one of the SMGs during the microgrid’s partition. Full article

Due to the demand for temporary rapid grid connection in renewable energy power plants, the topology structure of T-connected power lines has been widely used in the power grid. In this three-terminal system, fault localization is difficult because of traditional impedance-based or traveling wave-based fault localization methods; the three-terminal data should be synchronized and communicated. Since different terminal assets belong to different enterprises, it is actually difficult to maintain good synchronization between them. Therefore, in practical applications, the fault location of T-connected power lines often fails. This article proposes a single terminal fault location method for a T-connection power line to address this issue. It is based on the fact that the local topology of the T-connected power line in the healthy phase remains unchanged during the fault-clearing process. It utilizes the sequential current and voltage data changes generated by the sequential tripping ping emitted by the circuit breaker from different terminals to describe the constant topology of the healthy phase as an equation and calculates the accurate fault location after solving the equation. The Levenberg–Marquardt algorithm was used to calculate fault distance and transition resistance, and the effectiveness of this method was verified through simulation. Full article

The paper presents some case spectral analysis of zero-sequence voltages and currents in an example industrial power distribution network. The network layout is based on typical power delivery networks in underground coal mines. Ground fault simulations have been made using an ATP/EMTP program. Due to the high environmental risks, the reliability of the protection relay operation related to their selectivity plays an important role. This paper tries to find the reasons for nonselective operation and unnecessary tripping in extensive mine cable networks, particularly with large power sources of higher-order harmonics. It was found that in transient states—due to the decaying oscillations occurring in complex RLC circuits—the results of short time measurements of the criterion values for ground fault protective relays can be overestimated (particularly for small values of ground resistance) and lead to nonselective tripping of a healthy cable line. Therefore, it might be advisable to increase the integration time used for measuring rms values. Also, if there is a significant level of higher harmonics in the industrial network generated by high-power converters, it should be noted that the higher harmonics of the ground fault current and currents measured by ground fault protection relays assume much higher values, which may also cause nonselective tripping. In this case, it may be advisable to use higher harmonic filters in the measuring circuits and to select a sufficiently high sampling frequency in the digital protective relays. Full article

Wind turbines are vulnerable to negative sequence current injection, the conventional automatic reclosing scheme for wind power outgoing lines, since we may inject negative sequence components into the system and reclose it without distinguishing the nature of the fault through rectification. Moreover, reclosing in permanent faults could induce a secondary impact on the system. To solve the above problems, an adaptive reclosing scheme for cross-line faults on double-circuit wind power outgoing lines with shunt reactors is proposed. Firstly, a new tripping strategy and a single-side partial-phase reclosing method are proposed for multiple types of outgoing line faults, while, simultaneously, phase-to-phase coupling loops are established. Secondly, the criteria of fault nature are established based on the fault phase shunt reactor current and fault phase voltage characteristics, and transient faults are rapidly and accurately distinguished from permanent ones according to the criteria. Finally, the theoretical derivation and simulation experiments are conducted on the PSCAD/EMTDC platform to demonstrate that the proposed adaptive reclosing method is applicable to avoid the injection of negative sequence currents into wind turbines. Meanwhile, the success rate of reclosing for wind power outgoing line is significantly improved and the continuity of power transmission on the wind farm(s) is ensured. Full article

After a transmission line is covered by ice in winter, ice-shedding and vibration occurs under special meteorological and external dynamic conditions, which leads to intense transmission line shaking. Transmission line ice-shedding and vibration often cause line flashover trips and outages. In January 2018, three 500 kV transmission lines, namely, the 500 kV Guanli line, the 500 kV Dushan line, and the 500 kV Guanqiao line, tripped and cut off due to ice-shedding and vibration in Anhui province, seriously threatening the safe operation of a large power grid. Current studies mainly focus on analyzing the influence factors and characteristics of line ice-shedding and investigating suppression measures, but they only analyze the correlation between each influencing factor and icing or shedding, and do not consider the coupling effects between multiple factors. In this paper, the key influencing factors and the probability distribution of transmission line ice-shedding were analyzed, and a multiple-factor coupling fault probability calculation model of line ice-shedding based on Copula function was proposed. The fault probability was calculated directly by considering multiple influence factors at the same time, which effectively overcame the error caused by multi-factor transformation in fuzzy membership degree and other methods. It provided an important decision-making basis for preventing and controlling transmission line ice-shedding faults. Full article

In order to improve the performance of an arc suppression coil grounding system in handling cross-line two-point successive grounding faults (CTSGs), the applicability of the transient quantity method and the steady-state quantity method for assessing CTSGs is analyzed. Then, a novel method for line selection for CTSGs was proposed, which comprehensively utilizes transient and steady-state information. Specifically, this method adopts a continuous line selection process, with priority given to the transient quantity method, and a supplementary line selection process, with priority given to the steady-state quantity method. After accurately selecting some faulty lines, such lines are tripped, and then, the process proceeds with continuous line selection again. When the number of cycles exceeds the set value, and the fault line cannot be completely cut off, they are tripped one by one according to the degree to which they are approaching the steady-state method criterion, from large to small. Furthermore, in response to the dramatic increase in computing volume that is caused by the continuous application of the transient method in on-site applications and the impact of current transformer accuracy on the steady-state method, this paper proposes corresponding solutions. PSCAD simulation, full-scale tests, and field recording data tests verify that this paper’s method can accurately detect a CTSG. Full article

In this paper, a long short-term memory (LSTM)-based method with a multi-input tensor approach is used for the classification of events that affect the power quality (PQ) in power systems with distributed generation sources. The considered events are line faults (one line, two lines, and three lines faulted), islanding events, sudden load variations, and generation tripping. The proposed LSTM-based method was trained and tested using the signals produced by the events simulated in a study system with distributed generation sources via PSCAD^®. Then, noise with different levels was added to the testing set for a thorough assessment, and the results were compared with other well-known methods such as convolutional and simple recurrent neuronal networks. The LSTM-based method with multi-input proved to be effective for event classification, achieving remarkable classification performance even in noisy conditions. Full article

This research paper addresses the issue of enhancing the operational availability of NPC three-level converter-based high-voltage direct current (HVDC) transport systems during alternating current (AC) grid fault conditions. During short-circuit faults in power transmission lines, voltage sags can occur, causing fluctuations in the DC link voltage of converter systems. These voltage sags have the potential to induce a reversed power flow and trip the VSC-HVDC transmission system. The objective of this paper is to develop a nonlinear control technique that investigates the fault ride-through (FRT) capability of VSC-HVDC transmission system characteristics during voltage sag events. To achieve this, we conduct semi-experimental investigations using Processor-in-the-Loop (PIL) simulations and analyze the results. Symmetrical and asymmetrical voltage sag events with different remaining voltages are applied to an AC grid, and their effects are observed for varying durations. The proposed nonlinear control technique aims to mitigate the impact of voltage sags on the operational availability of HVDC transport systems. By analyzing the semi-experimental results, we aim to gain insights into the FRT capability of the VSC-HVDC transmission system. Full article

In power systems, distance relays are commonly employed as the primary protection for transmission lines, and their operation is of utmost importance. Power swings are a type of phenomenon that can lead to improper functioning of conventional distance relays, posing a threat to the uninterrupted flow of electrical power. The occurrence of a power swing disrupts the impedance measured by the relay, causing it to deviate from the normal load condition and enter the relay tripping zones. This research paper introduces a novel method based on the Prony method for extracting current waveform components, enabling fault detection during power swings. Subsequently, the proposed method’s accuracy is assessed through simulations implemented on a nine-bus power system, involving three-phase current signal processing and the application of the proposed algorithm. Various fault scenarios encompassing varying fault distances from the relay position, fault resistances, and power angles within the 9-bus system are simulated to encompass a wide range of fault environments. The simulation results demonstrate the effectiveness of the proposed algorithm in detecting all types of faults, including symmetrical and asymmetrical faults, during power swings. Full article

At present, the global energy demand keeps rising due to population growth. Therefore, large numbers of photovoltaics (PV) are being integrated with power systems. Solar PV’s installed power capacity is poised to surpass that of coal by 2027, becoming the largest in the world. The integration of PV has changed the direction of the power flow. Under these circumstances, the changed magnitudes and directions of fault current may result in maloperations and non-operations of conventional relays. In this work, a simple and reliable current selective tripping protection scheme is proposed, which is based on the direct communication between overcurrent protective devices on both sides of the line. Through logical programming of the operation information of each protection, the fault location is detected, and the instantaneous trip is realized. The simulation analysis of PSCAD/EMTDC shows that the protection scheme can reliably detect and isolate faults happening at the feeder and bus under different fault conditions; besides, it has good performance in detecting certain resistance grounding faults. The proposed protection scheme can effectively solve the problems caused by PV systems penetration and improve system safety. Full article

The unprecedented transformation of contemporary power systems, mainly evidenced by the high penetration of renewable energy generation and the shift from passive to active, bi-directional smart grids, has put an extraordinary burden on power system operation and control. The uncertainties created by the two aforementioned factors greatly propel the necessity of more accurate and robust system monitoring. Concurrently, an ever-increasing amount of electronics-based power generation makes frequency stability a major challenge to power system operation and control due to the vastly diminishing system inertia. As a crucial part of system control, frequency monitoring is utilized to identify potential stability issues and eventually prevent cascading power outages and blackouts. This paper proposes a dynamic state estimation (DSE) methodology that employs deep learning (DL) techniques based on feed-forward artificial neural networks (ANN) to accurately predict power system disturbances in terms of frequency disturbance events (FDE) caused by line outages, load/generation tripping events, and various types of faults. The proposed methodology was tested on a test grid model with high penetration of renewable generation, using an open-source data generator. It was concluded that DL-based DSE can be successfully utilized in the FDE detection process to improve frequency monitoring and control, and to maintain optimal performance, stability, and security of power systems. Full article

Single-stage grid-interfaced PV topologies have challenges with high grid fault currents, despite being more efficient, simpler to implement, and less expensive than two-stage ones. In such systems, a single inverter is required to perform all grid-interface tasks. i.e., maximum power point tracking (MPPT), DC voltage stabilization, and grid current control. This necessitates a hardware-based fault current limitation solution rather than a software-based one to avoid adding to the inverter’s control complexity and to mitigate the implications of PV system tripping. Therefore, in this study, a dual-functional non-superconducting saturated-core inductor-based (SCI) reactor is proposed to be applied at the output of a single-stage PV inverter. It involves two operation modes: a grid pre-fault mode where it filters the line current, hence minimizing its THD, and a grid-fault mode where it acts as a fault current limiter (FCL). Controlling the DC saturation current flowing into its control winding terminals alters the core magnetization of the SCI to vary its impedance between a low value during normal utility operation and a maximal value during faults. Consequently, the system is protected against inverter failures or unnecessary circuit-breaker tripping, which preserves service continuity and reduces system losses. Moreover, compared to existing FCLs, the proposed topology is an appealing candidate in terms of cost, size, reliability, and harmonic filtering ability. The bi-functionality and usefulness of the proposed reactor are confirmed using simulation and experimental results. Full article

The integration of Distributed Generators (DGs) into distribution systems (DSs) leads to more reliable and efficient power delivery for customers. However, the possibility of bi-directional power flow creates new technical problems for protection schemes. This poses a threat to conventional strategies because the relay settings have to be adjusted depending on the network topology and operational mode. As a solution, it is important to develop novel fault protection techniques to ensure reliable protection and avoid unnecessary tripping. In this regard, Total Harmonic Distortion (THD) can be used as a key parameter for evaluating the grid’s waveform quality during fault events. This paper presents a comparison between two DS protection strategies that employ THD levels, estimated amplitude voltages, and zero-sequence components as instantaneous indicators during the faults that function as a kind of fault sensor to detect, identify, and isolate faults. The first method uses a Multiple Second Order Generalized Integrator (MSOGI) to obtain the estimated variables, whereas the second method uses a single SOGI for the same purpose (SOGI-THD). Both methods rely on communication lines between protective devices (PDs) to facilitate coordinated protection. The effectiveness of these methods is assessed by using simulations in MATLAB/Simulink considering various factors such as different types of faults and DG penetrations, different fault resistances and fault locations in the proposed network. Moreover, the performance of these methods is compared with conventional overcurrent and differential protections. The results show that the SOGI-THD method is highly effective in detecting and isolating faults with a time interval of 6–8.5 ms using only three SOGIs while requiring only 447 processor cycles for execution. In comparison to other protection methods, the SOGI-THD method exhibits a faster response time and a lower computational burden. Furthermore, the SOGI-THD method is robust to harmonic distortion, as it considers pre-existing harmonic content before the fault and avoids interference with the fault detection process. Full article
