Search Results (37)

Adhesive joints typically require high safety factors, as their mechanical performance is highly sensitive to environmental and manufacturing variations. Health monitoring can reduce these safety factors by continuously assessing the condition of the joint. While intrinsic and extrinsic sensing approaches exist, they are often based on periodic inspection or manual sensor integration, which limits their suitability for continuous in-service monitoring. This study investigates a novel sensor placement using additively manufactured strain sensors deposited by jet dispensing across the adhesive gap. Tensile lap-shear specimens were fabricated using CFRP (carbon-fiber-reinforced plastic) laminate, an epoxy adhesive, and silver-ink strain sensors placed internally within the joint and externally across the adhesive gap. Mechanical testing revealed that externally printed sensors produced an average resistance change of 65.3% near the failure stress of the adhesive joint, an order of magnitude higher than sensors embedded within the adhesive layer with 6.6% average resistance change. However, the average coefficient of variation increased as well, from 7.6% for internal to 32.6% for external. This sensor response exceeds reported environmentally induced variations in printed sensors and thus represents a promising candidate for condition monitoring. Further work is required to demonstrate actual damage detection capabilities and assess long-term stability under environmental and cyclic loading conditions. Full article

In hopper-based binder jetting 3D printing, a consistent powder dispensing rate from the hopper to the powder bed is essential for reliable printing. This study investigates the effects of adding a custom-built auto-stirrer to the hopper system on the consistency of powder dispensing rate for the ExOne Innovent+ binder jetting 3D printer (Desktop Metal, Burlington, MA, USA). The auto-stirrer incorporates rotating augers that actively agitate the powder in the hopper. Working together with the ultrasonic vibrator, the auto-stirrer facilitates consistent dispensing of powder through the hopper outlet. Experiments with algae powder demonstrated that adding the auto stirrer reduced fluctuations in dispensing rate by over 30% compared with the standard hopper. Statistical analysis confirmed that these improvements were significant (at a significance level of 0.05). These results indicate that integrating active mechanical agitation into hopper-based powder dispensing systems could help to achieve more consistent powder dispensing rates in hopper-based binder jetting 3D printing that uses cohesive powder feedstocks. Full article

Additive manufacturing is transforming high-frequency electronics prototyping by offering a sustainable and cost-effective alternative to traditional methods. This work addresses and demonstrates two areas: the use of 3D printing for millimeter-wave (mmWave) antennas, and chip-to-chip or chip-to-PCB interconnects. Both approaches facilitate reduced material waste. A 47 GHz series-fed microstrip patch array was printed on flexible Kapton using aerosol jet technology, showing performance comparable to etched arrays on Roger’s substrates. Crucially, the Kapton film can be peeled off after testing, allowing the reuse of expensive low-loss substrates. Therefore, this method supports rapid, low-waste prototyping. To address future chip-to-chip and chip-to-PCB mmWave interconnect limitations, XTPL’s Ultra-Precise Dispensing (UPD) was used to fabricate 3D-printed micro-interconnects. At 73 GHz, these interconnect structures achieved return loss better than 10 dB and insertion loss under 1 dB—outperforming traditional bondwires. Together, these results show 3D printing’s potential to enable sustainable, high-performance mmWave RF systems. Full article

This study investigates the effects of two process parameters (dispense delay and recoat speed) on green part density and powder bed density in binder jetting additive manufacturing using silicon carbide powder. These two process parameters control the amount of powder dispensed on the powder bed for each powder layer. Experiments were conducted at three levels of dispense delay (0.2, 1, and 5 s) and three levels of recoat speeds (5, 10, and 20 mm/s). The one-way Analysis of Variance (ANOVA) results reveal that both dispense delay and recoat speed have statistically significant effects on green part density and powder bed density. Experimental results show that increasing dispense delay or decreasing recoat speed leads to higher green part density and powder bed density. These findings provide useful insights into optimizing binder jetting additive manufacturing process parameters to achieve the desired green part density without employing powder bed compaction. Full article

Mechanical amplifiers can enhance the travel range of piezoelectric actuators, thereby expanding the applications of these actuators. Various amplification mechanisms have been proposed for piezoelectric actuators with different design requirements. For instance, rhombus- and bridge-type amplification mechanisms are compact and can therefore be applied in many applications with size restrictions. However, the amplification ratio of a single-stage rhombus- or bridge-type mechanism is limited. In this study, a novel three-stage amplifier was developed to achieve a high amplification ratio while keeping the device compact. A piezoelectric actuator integrated with this amplifier had a travel range of 207.5 μm, an amplification ratio of 13.7, and dimensions of 33.5 mm × 34.2 mm × 10 mm. Moreover, this actuator was used to construct a compact jetting dispenser with dimensions of 69 mm × 72 mm × 20 mm. Experimental results suggested that this dispenser can generate uniform and stable droplets, confirming the practical utility of the developed piezoelectric actuator. Full article

This study provides a comprehensive comparison of two leading direct-write manufacturing technologies: Aerosol Jet Printing (AJP) and Micro Dispensing Technology (MDT). The investigation examines their capabilities, limitations, and performance characteristics for printing on both 2D and 3D substrates. The findings offer valuable insights into the suitability of each printing method for flexible electronics based on the morphology and electrical performance of the deposited inks. The results reveal distinct advantages for each technique: AJP excels in resolution, while nScrypt’s micro dispensing offers superior 3D conformality, greater material versatility, and higher throughput. Full article

In binder jetting additive manufacturing (BJAM), parts are fabricated layer by layer by depositing a liquid binder on selected regions of the powder bed. Powder particles in the hopper of the printer are dispensed onto the powder bed to form a layer of powder. Powder dispensing rate affects material usage and print quality. Too high dispensing rates can cause excessive powder dispensing, increasing powder waste, while too low dispensing rates may result in incomplete layer formation, leading to reduced density of printed parts. The present study investigates how ultrasonic vibration intensity and initial powder amount in the hopper affect powder dispensing rate in BJAM when using a bimodal powder. A set of experiments with full factorial design were conducted using three levels of ultrasonic vibration intensity (50%, 75%, and 100%) and three levels of initial powder amount (600 g, 1000 g, and 1400 g) in the hopper. The results show that both ultrasonic vibration intensity and initial powder amount, as well as their interaction, significantly influence powder dispensing rate. Powder dispensing rate was higher when ultrasonic vibration intensity was higher or initial powder amount was smaller. Increasing initial powder amount from 600 to 1400 g, resulted in a much bigger decrease in powder dispensing rate when ultrasonic vibration intensity was 50% than when ultrasonic vibration intensity was 100%. Full article

The binder jetting additive manufacturing process offers the ability to create three-dimensional parts layer by layer. However, using any powder that contains particles with different sizes, shapes, or densities can lead to powder segregation during the mixing, dispensing, and spreading steps of the binder jetting additive manufacturing process. Powder segregation can often lead to uneven powder distribution across the powder bed, potentially causing defects in final parts. Therefore, it is important to understand powder segregation in mixing, dispensing, and spreading. Reported studies on powder segregation in mixing were conducted primarily on pharmaceutical or food powder that have different properties compared to metal or ceramic powder used in binder jetting additive manufacturing. There is a need for a deep understanding of how mixing speed and mixing time affect powder segregation in the context of binder jetting additive manufacturing. This paper reports an experimental investigation using a two-variable, two-level full-factorial design to examine the main effects and interaction effect of mixing speed and mixing time on powder segregation in the mixing of Powder A and Powder B for binder jetting additive manufacturing. The results reveal that segregation was more severe at the high level of mixing speed and the high level of mixing time. These findings provide useful insights for selecting mixing variables and controlling segregation, essential for achieving high-quality printed parts in binder jetting additive manufacturing. Full article

Radar sensors are critical for obstacle detection and navigation, especially for automated driving. Using the use-case “printing of heating coils on the inside of the front housing (primary radome)” needed for de-icing in winter, it is demonstrated that additive manufacturing (AM) can provide economic and functional benefits for manufacturing of the sensors. AM will allow significant cost reduction by eliminating parts and simplifying the manufacturing process. Different AM technologies for the coils were investigated, first, by applying the conductive traces by fused deposition modeling (FDM), and, second, by printing copper particle-free inks and pastes. The metal layers were electrically and mechanically characterized using a profilometer to measure the trace dimension and a four-point probe to measure the resistance. It was revealed that low-cost conductive filaments with low resistivity and current carrying capacity are commercially still not available. The best option sourced was a copper–polyester-based filament with 6000 µΩcm after printing. Therefore, low-cost particle-free copper inks and commercial copper flake paste were selected to print the heating coil. The Cu particle-free inks were amine-based Cu (II) formate complexes, where the Cu exists in an ionic form. Using contactless printing processes such as ink-jet printing or pneumatic dispensing, the traces could be deposited onto the low-melting temperature (225 °C) polymeric radome structure. After printing, the material needed to be sintered to form the conductive copper traces. To avoid damaging the polymer radome during sintering, two different processes were investigated: low-temperature (<150 °C) sintering in an oven for 30 min or fast laser sintering. The sintered Cu layers achieved the following specific electric resistivities when slowly sintered in the oven: paste 4 µΩcm and ink 8.8 µΩcm. Using laser sintering, the ink achieved 3.2 µΩcm because the locally high temperature provides better sintering. Also, the adhesion was significantly increased to (5 B). Therefore, laser sintering is the preferred technology. In addition, it allows fast processing directly after printing. Commercial equipment is available where printing and laser sintering is integrated. The potential of low-cost copper material and the integration in additive manufacturing of electronic systems using radar sensors as an example are demonstrated in this paper. Full article

Sorting and dispensing distinct numbers of cellular aggregates enables the creation of three-dimensional (3D) in vitro models that replicate in vivo tissues, such as tumor tissue, with realistic metabolic properties. One method for creating these models involves utilizing Drop-on-Demand (DoD) dispensing of individual Multicellular Spheroids (MCSs) according to material jetting processes. In the DoD approach, a droplet dispenser ejects droplets containing these MCSs. For the reliable printing of tissue models, the exact number of dispensed MCSs must be determined. Current systems are designed to detect MCSs in the nozzle region prior to the dispensing process. However, due to surface effects, in some cases the spheroids that are detected adhere to the nozzle and are not dispensed with the droplet as expected. In contrast, detection that is carried out only after the droplet has been ejected is not affected by this issue. This work presents a system that can detect micrometer-sized synthetic or biological particles within free-falling droplets with a volume of about 30 nanoliters. Different illumination modalities and detection algorithms were tested. For a glare point projection-based approach, detection accuracies of an average of 95% were achieved for polymer particles and MCF-7 spheroids with diameters above 75 μm. For smaller particles the detection accuracy was still in the range of 70%. An approach with diffuse white light illumination demonstrated an improvement for the detection of small opaque particles. Accuracies up to 96% were achieved using this concept. This makes the two demonstrated methods suitable for improving the accuracy and quality control of particle detection in droplets for Drop-on-Demand techniques and for bioprinting. Full article

A confined plunging liquid jet reactor (CPLJR) is an unconventional efficient and feasible aerator, mixer and brine dispenser that operates under many operating conditions. Such operating conditions could be challenging, and hence, utilizing prediction models built on machine learning (ML) approaches could be very helpful in giving reliable tools to manage highly non-linear problems related to experimental hydrodynamics such as CPLJRs. CPLJRs are vital in protecting the environment through preserving and sustaining the quality of water resources. In the current study, the effects of the main parameters on the air entrainment rate, Q_a, were investigated experimentally in a confined plunging liquid jet reactor (CPLJR). Various downcomer diameters (D_c), jet lengths (L_j), liquid volumetric flow rates (Qj), nozzle diameters (d_n), and jet velocities (V_j) were used to measure the air entrainment rate, Q_a. The non-linear relationship between the air entrainment ratio and confined plunging jet reactor parameters suggests that applying unconventional regression algorithms to predict the air entrainment ratio is appropriate. In addition to the experimental work, machine learning (ML) algorithms were applied to the confined plunging jet reactor parameters to determine the parameter that predicts Q_a the best. The results obtained from ML showed that K-Nearest Neighbour (KNN) gave the best prediction abilities, the proportion of variance in the Q_a that can be explained by the CPLJR parameter was 90%, the root mean square error (RMSE) = 0.069, and the mean absolute error (MAE) = 0.052. Sensitivity analysis was applied to determine the most effective predictor in predicting Q_a. The Qj and V_j were the most influential among all the input variables. The sensitivity analysis shows that the lasso algorithm can create an effective air entrainment rate model with just two of the most crucial variables, Qj and V_j. The coefficient of determination (R²) was 82%. The present findings support using machine learning algorithms to accurately forecast the CPLJR system’s experimental results. Full article

Multi-material additive manufacturing (AM) attempts to utilize the full benefits of complex part production with a comprehensive and complementary material spectrum. In this context, this research article presents new processing strategies in the field of polymer- and metal-based multi-material AM. The investigation highlights the current progress in powder-based multi-material AM based on three successfully utilized technological approaches: additive and formative manufacturing of hybrid metal parts with locally adapted and tailored properties, material-efficient AM of multi-material polymer parts through electrophotography, and the implementation of UV-curable thermosets within the laser-based powder bed fusion of plastics. Owing to the complex requirements for the mechanical testing of multi-material parts with an emphasis on the transition area, this research targets an experimental shear testing set-up as a universal method for both metal- and polymer-based processes. The method was selected based on the common need of all technologies for the sufficient characterization of the bonding behavior between the individual materials. Full article

Hydrogen–gasoline hybrid refueling stations can minimize construction and management costs and save land resources and are gradually becoming one of the primary modes for hydrogen refueling stations. However, catastrophic consequences may be caused as both hydrogen and gasoline are flammable and explosive. It is crucial to perform an effective risk assessment to prevent fire and explosion accidents at hybrid refueling stations. This study conducted a risk assessment of the refueling area of a hydrogen–gasoline hybrid refueling station based on the improved Accident Risk Assessment Method for Industrial Systems (ARAMIS). An improved probabilistic failure model was used to make ARAMIS more applicable to hydrogen infrastructure. Additionally, the accident consequences, i.e., jet fires and explosions, were simulated using Computational Fluid Dynamics (CFD) methods replacing the traditional empirical model. The results showed that the risk levels at the station house and the road near the refueling area were 5.80 × 10⁻⁵ and 3.37 × 10⁻⁴, respectively, and both were within the acceptable range. Furthermore, the hydrogen dispenser leaked and caused a jet fire, and the flame ignited the exposed gasoline causing a secondary accident, considered the most hazardous accident scenario. A case study was conducted to demonstrate the practicability of the methodology. This method is believed to provide trustworthy decisions for establishing safe distances from dispensers and optimizing the arrangement of the refueling area. Full article

In this study, a compliant amplifier powered by a piezoelectric stack is designed to meet high-performance dispensing operation requirements. By studying the issue of low frequency bandwidth on the traditional bridge-type amplifier mechanism, we propose a displacement amplifier mechanism, hybrid bridge-lever-bridge (HBLB), that enhances its dynamic performance by combining the traditional bridge-type and lever mechanism. A guiding beam is added to further improve its output stiffness with a guaranteed large amplification ratio. An analytical model has been developed to describe the full elastic deformation behavior of the HBLB mechanism that considers the lateral displacement loss of the input end, followed by a verification through a finite element analysis (FEA). Results revealed that the working principle of the HBLB optimizes the structural parameters using the finite element method. Finally, a prototype of the displacement amplifier was fabricated for performance tests. Static and dynamic test results revealed that the proposed mechanism can reach a travel range of 223.2 $\mathsf{\mu }$m, and the frequency bandwidth is 1.184 kHz, which meets the requirements of a high-performance piezo jet dispenser. Full article

In this article, we present an approach to fabricate conductive tracks on polymer substrates. Here, a digital printing process is used together with subsequent processing by a laser. For this purpose, a silver flake-based composite is printed onto a polycarbonate substrate using a jet-dispensing process. The printed tracks are then cured using a pyrometer-controlled laser beam source. The fabricated samples are analyzed for electrical resistivity and the cross-sectional area of the conductive tracks and compared to conventionally oven-cured samples. Four-point measurements and an optical measurement method are used for this purpose. Based on the resulting resistance, two different process regimes can be observed for the laser curing process. By using a laser instead of an oven for post-treatment, the achieved resistance of the conductive tracks can be reduced by a factor of 2. Moreover, the tracks produced in this way are more reproducible in terms of the resistance that can be achieved. Full article
