Beta-phase gallium oxide (β-Ga₂O₃) is a cutting-edge ultrawide bandgap (UWBG) semiconductor, featuring a bandgap energy of around 4.8 eV and a highly critical electric field strength of about 8 MV/cm. These properties make it highly suitable for next-generation power electronics and deep ultraviolet optoelectronics. Key advantages of β-Ga₂O₃ include the availability of large-size single-crystal bulk native substrates produced from melt and the precise control of n-type doping during both bulk growth and thin-film epitaxy. A comprehensive understanding of the fundamental growth processes, control parameters, and underlying mechanisms is essential to enable scalable manufacturing of high-performance epitaxial structures. This review highlights recent advancements in the epitaxial growth of β-Ga₂O₃ through various techniques, including Molecular Beam Epitaxy (MBE), Metal-Organic Chemical Vapor Deposition (MOCVD), Hydride Vapor Phase Epitaxy (HVPE), Mist Chemical Vapor Deposition (Mist CVD), Pulsed Laser Deposition (PLD), and Low-Pressure Chemical Vapor Deposition (LPCVD). This review concentrates on the progress of Ga₂O₃ growth in achieving high growth rates, low defect densities, excellent crystalline quality, and high carrier mobilities through different approaches. It aims to advance the development of device-grade epitaxial Ga₂O₃ thin films and serves as a crucial resource for researchers and engineers focused on UWBG semiconductors and the future of power electronics. Full article

The crystallographic-orientation relationship between GaN crystals grown via hydride vapor phase epitaxy (HVPE) on 6H-SiC was investigated. This study employed electron backscatter diffraction (EBSD) Kikuchi diffraction patterns and pole figures to identify this relationship and calculate lattice mismatches. Comparing the misorientation of GaN crystals on different substrates along the growth direction using EBSD mapping, we identify the strain in GaN based on crystallographic-orientation results. Raman spectroscopy results correlate residual stress in GaN with lattice mismatches, aligning with our previous works. Residual stress of GaN on different substrates identified using PL spectrum also confirmed these results. The HRXRD characterized the dislocation density of GaN crystals grown on these substrates. Full article

Hexagonal BN (h-BN) has emerged as an important ultrawide bandgap (UWBG) semiconductor (E_g~6 eV). The crystal growth technologies for producing semi-bulk crystals/epilayers in large wafer sizes and understanding of defect properties lag decades behind conventional III-nitride wide bandgap (WBG) semiconductors. Here we report probing of boron vacancy (V_B)-related defects in freestanding h-BN semi-bulk wafers synthesized by hydride vapor phase epitaxy (HVPE). A photocurrent excitation spectroscopy (PES) was designed to monitor the transport of photoexcited holes from deep-level acceptors. A dominant transition line at 1.66 eV with a side band near 1.62 eV has been directly observed, which matches well with the calculated energy levels of 1.65 for the V_B-H deep acceptor in h-BN. The identification of V_B complexes via PES measurement was further corroborated by the temperature-dependent dark resistivity and secondary ion mass spectrometry measurements. The results presented here suggested that it is necessary to focus on the optimization of V/III ratio during HVPE growth to minimize the generation of V_B-related defects and to improve the overall material quality of h-BN semi-bulk crystals. The work also provided a better understanding of how V_B complexes behave and affect the electronic and optical properties of h-BN. Full article

We analyze the effect of growth on non-(100) surfaces resulting from incomplete planarization of spalled GaAs wafers on the defect structure of GaAs solar cell layers grown by hydride vapor phase epitaxy (HVPE). Controlled spalling of (100)-oriented GaAs has the potential to reduce substrate costs for III-V epitaxy; however, it creates regularly faceted surfaces that may complicate the growth of high-quality III-V optoelectronic devices. We leverage the anisotropic growth rate of HVPE to planarize these faceted GaAs substrates, reducing the surface roughness and degree of faceting. We observe degraded solar cell performance and material quality in sample areas where facets are not completely removed. We used dark lock-in thermography and photoluminescence to identify recombination in areas that were not fully planarized. We used cathodoluminescence to identify the presence of extended defects in these regions, which are correlated with bandgap fluctuations in the material. We hypothesize that these defects were created by strain from compositional fluctuations in ternary alloys grown on the faceted surfaces. This work elucidates the potential issues of solar cells grown on faceted surfaces and builds understanding toward realizing high performance III-V photovoltaics with the cost-reduction potential of controlled spalling. Full article

In photovoltaic (PV) power generation, highly efficient III-V solar cells are promising for emerging mobile applications, such as vehicle-integrated PVs. Although hydride vapor phase epitaxy (HVPE) has received attention due to its lower fabrication costs, realization of high throughput performance while maintaining solar-cell characteristics using this growth method is essential. In this study, the effect of atmospheric-pressure triple-chamber HVPE growth conditions on GaAs solar-cell properties were carefully investigated in conjunction with defect analysis using deep-level transient spectroscopy (DLTS). Based on the analysis on GaAs reaction processes, the suppression of arsine thermal cracking in the HVPE hot-wall reactor was important to achieve fast GaAs growth using a low input V/III ratio. Moreover, the DLTS results revealed that the reduced input V/III ratio was effective in suppressing the generation of EL2 traps, which is a common GaAs midgap complex defect involving arsenic antisites. Although the EL2 trap density increased with the growth rate, the performance of GaAs solar cells that were grown under reduced arsine thermal cracking exhibited almost no considerable cell parameter deterioration at a growth rate of up to 297 μm/h. Consequently, a conversion efficiency of 24% with a high open-circuit voltage of 1.04 V was achieved for the cells that were grown at 200 μm/h. Full article

In this paper, the X-ray diffraction full width at half the maximum (XRD FWHM) of a 3.5 µm-thick hydride vapor phase epitaxy-aluminum nitride (HVPE-AlN) (002) face after high-temperature annealing was reduced to 129 arcsec. The tensile strain in the HVPE-AlN samples gradually released with the increasing annealing temperature. When the annealing temperature exceeded 1700 °C, an aluminum oxynitride (AlON) region was generated at the contact interface between HVPE-AlN and sapphire, and the AlON structure was observed to conform to the characteristics of Al5O6N by high-resolution transmission electron microscopy (HRTEM). A 265 nm light-emitting diode (LED) based on an HVPE-AlN template annealed at 1700 °C achieved a light output power (LOP) of 4.48 mW at 50 mA, which was approximately 57% greater than that of the original sample. Full article

Orientation-patterned gallium phosphide (OP-GaP) has been grown heteroepitaxially on OP gallium arsenide (GaAs) templates using hydride vapor phase epitaxy (HVPE). The effect of OP-GaAs template fabrication methods of epitaxial-inversion and wafer bonding on the heteroepitaxial OP-GaP growth has been investigated. OP-GaP layers with a growth rate of up to 35 µm/h and excellent domain fidelity were obtained. The growth rate and the domain fidelity have been revealed/studied by scanning electron microscope (SEM). In addition, we demonstrate that the crystalline quality of the individual domains, namely, the substrate-oriented domains (ODs) and the inverted domains (IDs), can be investigated by high-resolution x-ray diffraction reciprocal space mapping (HRXRDRSM), which can also indicate the domain fidelity. Attempts to increase the growth rate and improve the domain fidelity by increasing the III and V group precursors resulted in either an increase in the growth rate in the OP-GaP layers grown on epitaxial inversion OP-GaAs template at the expense of the domain crystalline quality and fidelity or an improvement in the crystalline quality of the domains at the expense of the growth rate in the OP-GaP layers grown on wafer-bonded OP-GaAs templates. In the case of OP-GaP grown on OP-GaAs templates prepared by epitaxial inversion, the crystalline quality of the ODs is better than that of the IDs, but it shows that the quality of the inverted layer in the template influences the quality and fidelity of the grown domains. To the authors’ knowledge, exploitation of HRXRDRSM studies on OP-GaP to establish the crystalline quality of its individual domains (ODs and IDs) is the first of its kind. OP-ZnSe grown on OP-GaAs templates has also been included in this study to further emphasize the potential of this method. We propose from this study that once the growth rate is optimized from SEM studies, HRXRDRSM analysis alone can be used to assess the structural quality and to infer the domain fidelity of the OP structures. Full article

In this paper, new aeromaterials are proposed on the basis of titania thin films deposited using atomic layer deposition (ALD) on a sacrificial network of ZnO microtetrapods. The technology consists of two technological steps applied after ALD, namely, thermal treatment at different temperatures and etching of the sacrificial template. Two procedures are applied for etching, one of which is wet etching in a citric acid aqua solution, while the other one is etching in a hydride vapor phase epitaxy (HVPE) system with HCl and hydrogen chemicals. The morphology, composition, and crystal structure of the produced aeromaterials are investigated depending on the temperature of annealing and the sequence of the technological steps. The performed photoluminescence analysis suggests that the developed aeromaterials are potential candidates for photocatalytic applications. Full article

In the present work, a new method of growing layers of three main crystal modifications of Ga₂O₃, namely α-phase, ε-phase, and β-phase, with thickness of 1 µm or more was developed. The method is based on the use of two approaches, namely a combination of Ga₂O₃ growth using the hydride vapor-phase epitaxy (HVPE) method and the use of a silicon crystal with a buffer layer of dislocation-free silicon carbide as a substrate. As a result, Ga₂O₃ gallium oxide layers of three major Ga₂O₃ crystal modifications were grown, namely, α-phase, ε-phase, and β-phase. The substrate temperatures and precursor flux values at which it is possible to grow only α-phase, only ε-phase, or only β-phase without a mixture of these phases were established. It was found that the metastable α- and ε-phases change into the stable β-phase when heated above 900 °C. Experimentally obtained Raman and ellipsometric spectra of α-phase, ε-phase, and β-phase of Ga₂O₃ are presented. The theoretical study of the Raman spectra and the dependences of dielectric function on photon energy for all three phases was carried out. The vibrations of Ga₂O₃ atoms corresponding to the main lines of the Raman spectrum of the α-phase, ε-phase, and β-phase were simulated by density functional methods. Full article

In this work, the growth mechanism of aluminum nitride (AlN) epitaxial films by hydride vapor phase epitaxy (HVPE) on silicon carbide (SiC) epitaxial layers grown on silicon (110) substrates is investigated. The peculiarity of this study is that the SiC layers used for the growth of AlN films are synthesized by the method of coordinated substitution of atoms. In this growth method, a part of the silicon atoms in the silicon substrate is replaced with carbon atoms. As a result of atom substitution, the initially smooth Si(110) surface transforms into a SiC surface covered with octahedron-shaped structures having the SiC(111) and SiC($11\overline{1}$) facets. The SiC(111)/($11\overline{1}$) facets forming the angle of 35.3° with the original Si(110) surface act as “substrates” for further growth of semipolar AlN. The structure and morphology of AlN films are investigated by X-ray diffraction (XRD), scanning electron microscopy (SEM), reflection high-energy electron diffraction (RHEED) and Raman spectroscopy. It is found that the AlN layers are formed by merged hexagonal microcrystals growing in two directions, and the following relation is approximately satisfied for both crystal orientations: AlN($10\overline{1}3$)||Si(110). The full-width at half-maximum (FWHM) of the X-ray rocking curve for the AlN($10\overline{1}3$) diffraction peak averaged over the sample area is about 20 arcmin. A theoretical model explaining the presence of two orientations of AlN films on hybrid SiC/Si(110) substrates is proposed, and a method for controlling their orientation is presented. Full article

We have investigated the effect of high-temperature nitridation and buffer layer on the semi-polar aluminum nitride (AlN) films grown on sapphire by hydride vapor phase epitaxy (HVPE). It is found the high-temperature nitridation and buffer layer at 1300 °C are favorable for the formation of single (10–13) AlN film. Furthermore, the compressive stress of the (10–13) single-oriented AlN film is smaller than polycrystalline samples which have the low-temperature nitridation layer and buffer layer. On the one hand, the improvement of (10–13) AlN crystalline quality is possibly due to the high-temperature nitridation that promotes the coalescence of crystal grains. On the other hand, as the temperature of nitridation and buffer layer increases, the contents of N-Al-O and Al-O bonds in the AlN film are significantly reduced, resulting in an increase in the proportion of Al-N bonds. Full article

Aluminum nitride (AlN) films were grown on the m-plane sapphire by high-temperature hydride vapor phase epitaxy (HVPE). The effect of high-temperature nitridation on the quality of AlN film was studied. The high-temperature nitridation is favorable for the formation of semi-polar single (10$\overline{1}$3) orientation AlN film, the quality of which shows strong dependence on the nitridation temperature. The full width at half maximum of X-ray diffraction for (10$\overline{1}$3) AlN film was only 0.343° at the optimum nitridation temperature of 1300 °C. It is found that the nano-holes were formed on the surface of substrates by the decomposition of sapphire in the process of high-temperature nitridation, which is closely related to the quality improvement of AlN. At the critical nitridation temperature of 1300 °C, the average size of the nano-holes is about 70 nm, which is in favor of promoting the rapid coalescence of AlN micro-grains in the early stages. However, the size of nano-holes will be enlarged with the further increase of nitridation temperature, which begins to play a negative role in the coalescence of AlN grains. As a result, the grain size will be increased and extended to the epilayer, leading to the deterioration of the AlN film. Full article

GaN layers on sapphire substrates were prepared by using metal organic vapor phase epitaxy (MOVPE) combined with an in-situ ${\mathrm{H}}_2$ etching process for the purpose of later self-separation of thick GaN crystals produced by hydride vapor phase epitaxy (HVPE) on such substrates. The etching process results in deep pits and long voids that formed on the surface and along the lower interface between GaN and sapphire, respectively. The pits, which were investigated by SEM analysis, can be modified in their aspect ratio and density by controlling the etching parameters. Using a proper set of in-situ etching parameters, a seed layer with internal voids can be prepared, which is suitable for HVPE overgrowth and the self-separation process. The quality of the in-situ-etched seed GaN layer and overgrown GaN crystal were characterized by X-ray diffraction (XRD) and defect selective etching (DSE). With the aid of atomic force microscopy (AFM) in tapping mode, the interface morphology of the separated GaN crystal was analyzed. The crystal quality of the separated HVPE-GaN crystal is comparable to the crystal grown on untreated GaN MOVPE-seed, which did not separate from the sapphire substrate. The introduced technique to promote the crystal separation during the HVPE process has no obvious drawback on the quality of the grown GaN crystals. Using this technique, the self-separation occurs more gently due to a weakened interface between GaN/sapphire. The conventional separation from an untreated seed by pure thermomechanical action results in higher mechanical forces on the crystal and consequently much higher risk of crystal breakage. Full article

Among the different semiconductors, GaN provides advantages over Si, SiC and GaAs in radiation hardness, resulting in researchers exploring the development of GaN-based radiation sensors to be used in particle physics, astronomic and nuclear science applications. Several reports have demonstrated the usefulness of GaN as an α-particle detector. Work in developing GaN-based radiation sensors are still evolving and GaN sensors have successfully detected α-particles, neutrons, ultraviolet rays, x-rays, electrons and γ-rays. This review elaborates on the design of a good radiation detector along with the state-of-the-art α-particle detectors using GaN. Successful improvement in the growth of GaN drift layers (DL) with 2 order of magnitude lower in charge carrier density (CCD) (7.6 × 10¹⁴/cm³) on low threading dislocation density (3.1 × 10⁶/cm²) hydride vapor phase epitaxy (HVPE) grown free-standing GaN substrate, which helped ~3 orders of magnitude lower reverse leakage current (I_R) with 3-times increase of reverse breakdown voltages. The highest reverse breakdown voltage of −2400 V was also realized from Schottky barrier diodes (SBDs) on a free-standing GaN substrate with 30 μm DL. The formation of thick depletion width (DW) with low CCD resulted in improving high-energy (5.48 MeV) α-particle detection with the charge collection efficiency (CCE) of 62% even at lower bias voltages (−20 V). The detectors also detected 5.48 MeV α-particle with CCE of 100% from SBDs with 30-μm DL at −750 V. Full article

Magnetron sputter epitaxy (MSE) offers several advantages compared to alternative GaN epitaxy growth methods, including mature sputtering technology, the possibility for very large area deposition, and low-temperature growth of high-quality electronic-grade GaN. In this article, we review the basics of reactive sputtering for MSE growth of GaN using a liquid Ga target. Various target biasing schemes are discussed, including direct current (DC), radio frequency (RF), pulsed DC, and high-power impulse magnetron sputtering (HiPIMS). Examples are given for MSE-grown GaN thin films with material quality comparable to those grown using alternative methods such as molecular-beam epitaxy (MBE), metal–organic chemical vapor deposition (MOCVD), and hydride vapor phase epitaxy (HVPE). In addition, successful GaN doping and the fabrication of practical devices have been demonstrated. Beyond the planar thin film form, MSE-grown GaN nanorods have also been demonstrated through self-assembled and selective area growth (SAG) method. With better understanding in process physics and improvements in material quality, MSE is expected to become an important technology for the growth of GaN. Full article
