Originally introduced in the 1960s by DISA Elektronik as a calibration tunnel for hot-wire anemometers, the Type 55D41 has now been reengineered into a versatile and modern aerodynamic test platform. While retaining key legacy components, such as the converging nozzle and the 55D42 power unit, the upgraded system features a redesigned modular test section with optical-grade quartz windows. This enhancement enables compatibility with advanced flow diagnostics and visualization methods, including PTV, DIC, and schlieren imaging. The modernized facility maintains the precision and flow stability that made the original design widely respected, while expanding its functionality to meet the demands of contemporary experimental research. Its architecture supports the aerodynamic characterization of micro-scale static pressure probes used in aerospace, propulsion, and micro gas turbine applications. Special attention is given to assessing the influence of probe tip geometry (e.g., conical, ogive), port positioning, and stem interference on measurement accuracy. Full article

Optimizing aerodynamic efficiency is crucial in competitive cycling, where aerodynamic resistance significantly limits performance. Devices like Notio have emerged to calculate the coefficient of drag area (C_DA) considering dynamic pressure data calculated by an integrated Pitot-static tube. This study aimed to evaluate the validity and reliability of Pitot-static tube calculations through wind speed (WS) data against a hot-wire anemometer (HWA). Sixty recordings were made, lasting 30 s each, in a closed-circuit wind tunnel at four different WS (≈30 to ≈60 km/h), and at five different yaw angles (0° to 20°). Initially, Notio showed WS 6.44% higher than HWA. The calibration process recommended by the Notio manufacturer reduced the differences to a non-significant 0.76%. Comparison of the WS of Notio calibrated and HWA only showed significant differences in the WS group of ≈60 km/h. There were no significant differences in the comparison of yaw angles groups. The reliability of Notio was worse than that of the HWA. In conclusion, Notio calibrated at a speed close to its use allows for reliable and accurate calculation of WS over a wide range of yaw angles under controlled wind tunnel conditions without the presence of a cyclist and bicycle. However, due to the influence of WS on aerodynamic drag, small errors in WS could translate into considerable values of C_DA for cycling performance. Full article

The gas phase flow field inside a cyclone separator is crucial to the particle separation process. Previous studies have paid attention to the steady-state characteristics of the gas phase flow field, while research on its dynamic characteristics remains insufficient. Meanwhile, cyclone separators often adopt different structural forms according to the process requirements, the evolution laws of the dynamic characteristics flow field within them are still not well understood. Therefore, in this study, a hot-wire anemometer (HWA) was employed to measure the instantaneous tangential velocity of the gas phase flow fields within different structural cyclone separators (cylinder type, cylinder–cone (no hopper), and cylinder–cone (with hopper)). Comparative analyses and discussions were conducted regarding the dynamic characteristic distribution rules of the flow field in the time domain and the frequency domain. The results revealed that the dimensionless tangential velocity distributions of different types of cyclone separators all conformed to the Rankine vortex structure. The instantaneous tangential velocity fluctuated with low frequency and high amplitude, and the low-frequency velocity fluctuation exhibited a transfer behavior along the radial direction. Compared with the cylinder–cone-type cyclone separator, the tangential velocity in the cylinder-type cyclone separator fluctuated more greatly, and its quasi-periodic behavior was also more obvious. The time-averaged tangential velocity, the tangential velocity fluctuation intensity (S_d), and the dominant fluctuation frequency all had obvious attenuation along the axial direction in the cylinder-type cyclone separator, while the above-mentioned parameters had no attenuation along the axial direction in cylinder–cone-type cyclone separators. Additionally, the backflow from the hopper of the cylinder–cone-type cyclone separator (with hopper) led to an increase in the instantaneous tangential velocity fluctuation intensity of the local flow field near the dust outlet, as well as the occurrence of the “double dominant frequencies” phenomenon. Full article

In this study, a disk-type bluff body was installed at the upper part of a nozzle exit, and the circular jet inside the nozzle was controlled using a dielectric barrier discharge (DBD) plasma actuator (DBD-PA). The effects of the changes in the excitation frequency of the jet induced by the DBD-PA on the jet diffusion were elucidated. The experiments included visualization of the jet cross-section, particle image velocimetry analysis, and velocity measurements using an I-type hot-wire anemometer. When the DBD-PA was driven at a specific burst frequency (900–1400 Hz), a lock-in phenomenon occurred, in which the frequency of vortices generated in the initial jet coincided with the burst frequency. This lock-in phenomenon suppressed the merging of vortices by generating vortices at regular intervals. When vortex merging was suppressed, the jet was less likely to be entrained into the recirculation flow generated by the bluff body, thereby increasing the downstream jet width and average flow rate. Full article

The gas–phase flow field within a cyclone plays a critical role in the particle separation process. While previous research has primarily focused on the steady–state, time–averaged characteristics of this flow field, there has been limited investigation into its dynamic instability. This study seeks to address this gap by examining the dynamic instability of gas swirling flows in cyclones, offering new insights into their spatial and temporal dimensions. Numerical simulations were performed via large eddy simulation (LES) for the gas swirling flow in a reverse cyclone and tangential velocity was measured with a hot–wire anemometer (HWA). The model’s accuracy was validated against experimental data. The results demonstrate that the distributions of instantaneous tangential velocity and pressure exhibit spatial asymmetry and temporal instability across different sections of the cyclone. The dynamic instability of the gas swirling flow in the cyclone is the superposition of the spatial asymmetry and the temporal instability. These instabilities are more pronounced in the internal regions than the outer regions. Dynamic instability arises from the combined effects of rotational dynamics and wall curvature, leading to an eccentric rotation of the swirling center, particularly evident in the lower sections of the cyclone cone. This instability increases fluctuations in the instantaneous parameters, enhancing turbulence intensity and fine particle diffusion, and ultimately impairing both separation efficiency and particle size efficiency. Full article

Wet scrubbers are traditionally used as dedusting systems in waste incineration plants for wet flue gas treatment. Although these devices are not particularly performant at capturing submicron particles, which are associated with health and environmental hazards, their collection efficiency can be improved by optimizing operating conditions. This study presents the design methodology of a downscaled wet scrubber, constructed and implemented at a municipal waste incineration plant to be fed with real fumes, and to study its efficiency towards the removal of submicronic particles. The downscaled scrubber was designed to operate with flue gas at 200 °C, high humidity (1% RH), and an average total particle concentration of 200 mg/Nm³. A criterion of geometric, aerodynamic, and residence time similarities to an existing industrial scrubber was targeted. The height of the device was selected by matching the theoretical fractional particle collection efficiencies of the industrial and downscaled scrubbers. Featuring a cylindrical shape, the downscaled scrubber has a diameter of 0.3 m and a height of 2.5 m. It operates in co-current with water injected through four spray levels. Computational fluid dynamics simulations were conducted to analyze the gas flow structure within the device, and the results were validated by hot wire anemometer velocity measurements. Full article

Background: Nasal airway obstruction (NAO) is characterised by high resistance in the nasal cavity with a collapsible and narrowed upper airway and is an integral part of OSA pathophysiology. The literature demonstrates that the identification of high-risk OSA in the young adult population leads to the prevention of later health consequences. A nasoorospirometer is a prototype device that measures nasal capacity during inspiration. The basis for measurement is a Wheatstone bridge and a thermal anemometer. The parameters are recorded via hot wire anemometry (HTA) with velocity measurements in the airflow field. Therefore, this pilot study aimed to test the feasibility of the device by examining a young adult sample. The secondary aim was to determine whether subjective NAO correlates with nasal capacity and whether NAO corresponds with anthropometric parameters and individual risk of OSA. Methods: A group of 31 participants (mean age 24.9 years) underwent a thorough laryngological examination. The nasoorospirometer was used to measure objective NAO (nasal capacity), the NOSE scale was used to gain subjective NAO evaluation, and the Berlin Questionnaire for the risk of OSA. Results: A correlation analysis confirmed no significant associations between the subjective and objective measures (p > 0.05). Higher BMI and neck circumference are associated with lower NAO and higher nasal patency in the population of young adults (r: 0.32–0.45; p < 0.05). The risk of OSA showed no statistically significant association (p > 0.05). Conclusions: We presented three methods of NAO assessment: subjective participant evaluation, objective nasoosopirometry, and objective laryngological assessment. However, the use of a nasoorospirometer with anthropometric measures in young adults needs to be verified in future studies. Full article

The flow field characteristic is crucial for the separation process of cyclones, which includes time–mean and dynamic characteristics. The structural parameters of the cyclone have an important influence on the internal flow field characteristics, among which the cylinder diameter and vortex finder diameter are important structural parameters. This experimental study aimed to assess the effects of diameter parameters on the flow field characteristics of cyclones, especially the dynamic characteristics, which have received less attention in the literature. A hot wire anemometer (HWA) was employed in measuring the instantaneous tangential velocities in cyclones with different cylinder and vortex finder diameters. Time and frequency domain analyses of the measured data revealed that the diameter parameters of cyclones affected not only the distributions of the time–mean and instantaneous tangent velocities but also the intensity and dominant frequency of the instantaneous tangential velocity fluctuations. First, the maximum tangential velocity in the cyclone increased slightly when the cylinder diameter was increased and decreased significantly when the vortex finder diameter was increased. Second, the tangential velocity fluctuation intensity characterized by the standard deviation (S_d) increased on the same dimensionless axial section when the cylinder diameter was increased and the vortex finder diameter was decreased. It was also found that the increases in cylinder diameter and vortex finder diameter led to the dominant frequencies in the cyclone being reduced. Based on the results of this study, the dominant frequency calculation model for cyclones was improved. The conclusions presented in this study may provide valuable insights into the dynamic characteristics of flow fields in cyclones for future improvements to separation performance. Full article

Aimed at addressing the difficult problems existing in extremely low speed calibration facilities for hot-wire anemometers, where calibration accuracy is often insufficient and vulnerable to the contamination from temperature and humidity discrepancies between the calibration environment and the application environment, a calibration rig with a velocity range from 0.10 m/s to 1.0 m/s, an air temperature range of ambient temperature to 60 °C, and a humidity range from 20%RH to 80%RH was designed, developed, and constructed. The overall layout arrangement and the mechanical structure of the facility are illustrated. The master control system, the motion control system, the temperature and humidity control system are designed, tested and adjusted. The adjustment results are demonstrated and discussed. The analysis of the results reveals that the maximum velocity control error is 0.000989 m/s, satisfying the design target of 0.003 m/s; the corresponding maximum relative error is 0.241%, which is less than the design target of 0.4%; the maximum temperature control error is 0.9 °C, meeting the design target accuracy of 1 °C; the maximum humidity control error is 2.9%RH, which is below the design target of 4%RH. When the facility is applied to the calibration of a hot-wire anemometer, the maximum error of the fitting curves in modified King’s law is 0.02236 m/s, while that in Van der Hegge Zijnen’s formula is 0.023217 m/s, both of which satisfy the design target accuracy of 0.03 m/s. The maximum relative errors of fitting curves using the two formulas are 5.214% and 8.527%, respectively. Analysis of calibration data reveals that the discrepancy in temperature and humidity between application site and calibration site may bring errors that can reach up to 1.2676% per unit relative humidity discrepancy, and 5.672% per degree Celsius of temperature deviation, respectively. Full article

A detailed study of the gas-dynamic behaviour of both liquid and gas flows is urgently required for a variety of technical and process design applications. This article provides an overview of the application and an improvement to thermal anemometry methods and tools. The principle and advantages of a hot-wire anemometer operating according to the constant-temperature method are described. An original electronic circuit for a constant-temperature hot-wire anemometer with a filament protection unit is proposed for measuring the instantaneous velocity values of both stationary and pulsating gas flows in pipelines. The filament protection unit increases the measuring system’s reliability. The designs of the hot-wire anemometer and filament sensor are described. Based on development tests, the correct functioning of the measuring system was confirmed, and the main technical specifications (the time constant and calibration curve) were determined. A measuring system for determining instantaneous gas flow velocity values with a time constant from 0.5 to 3.0 ms and a relative uncertainty of 5.1% is proposed. Based on pilot studies of stationary and pulsating gas flows in different gas-dynamic systems (a straight pipeline, a curved channel, a system with a poppet valve or a damper, and the external influence on the flow), the applications of the hot-wire anemometer and sensor are identified. Full article

The paper focuses on the investigation of unsteady effects in shock wave/boundary layer interaction. The study was carried out using a flat plate model subjected to a free stream Mach number of 1.43 and a unit Reynolds number (Re₁) of 11.5 × 10⁶ 1/m. To generate two-dimensional disturbances in the laminar boundary layer upstream of the separation region, a dielectric barrier discharge was employed. The disturbances were generated within the frequency range of 500 to 1700 Hz. The Strouhal numbers based on the length of the separation bubble ranged from 0.04 to 0.13. The measurements were carried out using a hot-wire anemometer. Analysis of the data shows that disturbances in this frequency range mostly decay. The maximum amplitudes of perturbations were observed at frequencies of 1250 Hz and 1700 Hz. Full article

An experimental investigation of the local flow field in a Wells turbine has been conducted, in order to produce a detailed analysis of the aerodynamic characteristics of the rotor and support the search for optimized solutions. The measurements were conducted with a hot-wire anemometer (HWA) probe, reconstructing the local three-dimensional flow field both upstream and downstream of a small-scale Wells turbine. The multi-rotation technique has been applied to measure the three velocity components of the flow field for a fixed operating condition. The results of the investigation show the local flow structures along a blade pitch, highlighting the location and radial extension of the vortices which interact with the clean flow, thus degrading the turbine’s overall performance. Some peculiarities of this turbine have also been shown, and need to be considered in order to propose modified solutions to improve its performance. Full article

The present article outlines a research investigation carried out in a wind tunnel setting aimed at augmenting comprehension of the excitation mechanism of stay cable vibration in arid conditions. A multitude of wind tunnel experiments were thoroughly scrutinized. The study commenced by conducting measurements of the stay cable vibration in conditions of steady flow. The flow angle was set at 45 degrees, and the inclination was set at 25 degrees. The wind velocities varied during the experiment. Additionally, an investigation into the flow field surrounding the stay cable’s was conducted in both vertical and horizontal directions. By utilizing two hot wire anemometers in the cable wake, an extensive database of flow field measurements was obtained. The experimental results revealed that the vibration characteristics of the stay cable under the arid conditions considered in this study aligned with findings reported in existing literature. Notably, a deeper comprehension of the excitation mechanism of a stay cable in a dry state was attained. This mechanism is closely associated with the inhibition of Karman vortices and the development of low-frequency vortices. At low wind speeds, Karman vortices predominated, resulting in small-amplitude vibrations. However, as the wind speed increased, the influence of Karman vortices diminished progressively, while the low-frequency vortices grew stronger. These low-frequency vortices exhibited high energy and a significant correlation with shedding along the stay cable, thereby inducing cable vibration in a dry environment. Full article

Vortex generators are devices that modify the wind behavior near the surface of wind turbine blades. Their use allows the boundary layer shedding transition zone to be varied. Bio-inspired design has been used to improve the efficiency of aerodynamic and hydrodynamic systems by creating devices that use shapes present in animals and plants. In this work, an experimental methodology is proposed to study the effect of bio-inspired vortex generators and their effect on the structural vibration of a blade. In addition, the wind wake generated by the blade with oscillating vortex generators at different oscillation frequencies is analyzed by means of a hot wire anemometer, obtaining appreciable vibration reduction results in the measured 3D acceleration signals for wind velocities between 10 and 15 m/s. Values of the spectral components of the wake velocity measured at higher tunnel wind velocities increase. Spectral variance is reduced at higher tunnel wind velocities. The system analyzed in this paper can contribute in the future to the construction of actuators for vibration compensation systems in wind turbines. Full article

Conical diffusers of various configurations are used in many kinds of technical equipment and manufacturing processes. Therefore, it is a relevant objective to obtain reliable experimental and mathematical data on the aerodynamic characteristics of diffusers. This article presents experimental data on the aerodynamics of stationary flows in a vertical conical diffuser when air is supplied through tubes with various cross sections (circle, square, and triangle). Instantaneous values of air flow velocity are measured with a constant-temperature hot-wire anemometer. Data are obtained on the velocity fields and turbulence intensity along the height and the diameter of the diffuser’s cylindrical part when air is supplied through tubes of various configurations. It is established that air supply through profiled tubes has a significant effect on the shape of the velocity field and turbulence intensity in a vertical conical diffuser. For example, higher values of turbulence intensity are typical of air supplied through profiled tubes (the differences reach 50%). A mathematical formulation (linear and exponential equations) of the change in the average speed and intensity of air flow turbulence along the height of the diffuser’s cylindrical part for various initial conditions and supply tube configurations is presented. The obtained findings will make it possible to refine mathematical models and update algorithms for engineering the design of diffusers for various engineering processes and pieces of technical equipment. Full article
