Search Results (134)

Some laser scanners utilize stepper motor-driven optomechanical assemblies to position the laser beam precisely during triangulation. In laser scanners such as the presented Technical Vision System (TVS), to enhance motion resolution, gear transmissions are implemented between the motor and the optical assembly. However, due to the customized nature of the mechanical design, errors in manufacturing or insufficient mechanical characterization can introduce deviations in the computed 3D coordinates. In this work, we present a novel method for estimating the degrees-per-step ratio at the output of the laser positioner’s transmission mechanism using a stereovision system. Experimental results demonstrate the effectiveness of the proposed method, which reduces the need for manual metrological instruments and simplifies the calibration procedure through vision-assisted measurements. The method yielded estimated angular resolutions of approximately 0.06° and 0.07° per motor step in the horizontal and vertical axes, respectively, key parameters that define the minimal resolvable displacement of the projected beam in dynamic triangulation. Full article

As metal mines advance into deep mining, the increase in tectonic stress and horizontal stress leads to a higher degree of joint and fissure development in roadway surrounding rocks, along with a significant rise in both the fragmentation degree of the rock mass and the support cost. This paper adopts field monitoring and numerical simulation methods to analyze the characteristics of mining-induced stress rotation after unloading due to deep roadway excavation in the Jinchuan mining area, and proposes corresponding surrounding rock control countermeasures and optimized schemes for the original support. The research results show that after the unloading caused by the excavation of deep roadway surrounding rock, the magnitudes and directions of the maximum, intermediate, and minimum principal stresses all exhibit a trend of slow change, followed by drastic change, and finally gradual stabilization. When the roadway advances to 4 m in front of the monitor section, the adjustment of the magnitude of principal stress of the surrounding rock is the most drastic. Moreover, as the working face moves away from the monitor section, the principal stress gradually stabilizes and becomes lower than the initial stress value. When the roadway advances to 6 m in front of the monitor section, the adjustment of the direction of the principal stress of the surrounding rock is the most drastic. The rotation angle of the maximum principal stress shows a trend of first increasing and then decreasing with the increase in the excavation step, while the rotation angles of the intermediate and minimum principal stresses show a trend of first decreasing and then increasing as the excavation step increases. Based on the spatial distribution characteristics of joints and fissures in the roadway surrounding rock, the sensitive area for the rotation of mining-induced stress direction is defined. By changing the advancing direction of the roadway, the rotation trajectory of the principal stress can be deviated from the sensitive area, thereby improving the self-stabilization ability of the roadway surrounding rock. It is proposed that asymmetric coupling support be adopted to reinforce the positions where the principal stress rotation of the rock mass around the anchorage is severe, which can effectively reduce the range of the plastic zone in the roadway surrounding rock. The research results provide new ideas for the surrounding rock control of deep roadways, as well as a theoretical basis for the design and optimization of roadway support parameters in similar mines. Full article

Hexaglide parallel manipulators are characterized by high accuracy and dynamic performance, which makes them suitable for industrial high-precision assembly tasks such as placement of electronic THT components on printed circuit boards. In this paper we describe an assembly system that comprises a Hexaglide manipulator with vertical ball screws, moving printed circuit boards relative to stationary THT components. We evaluate the effects of the manufacturing tolerances of machine parts, such as bar length tolerance, ball screw axis position uncertainty, and ball screw axis orientation uncertainty, on Hexaglide end-effector pose accuracy using a geometric simulation study based on stochastic tolerance sampling. In the investigated configuration and under standard industrial tolerances, bar length inaccuracy and axis position uncertainty lead to significant position and rotation deviations for the Hexaglide end-effector in the horizontal plane that need to be compensated for by control algorithms to enable THT assembly using the Hexaglide prototype. The geometric simulation method applied in this paper can be used by designers of Hexaglide machines to study and evaluate different machine configurations. Full article

Leveling of the crane support platform plays a vital role in operational safety and lifting efficiency; it requires both precise horizontal positioning and the rational distribution of outrigger load. However, the current synchronous leveling methods mainly focus on displacement synchronization leveling while neglecting the control of outrigger load, resulting in the problem of individual outrigger overloading. To address this problem, a synchronous leveling control method with variable load constraints (SLCM-VLC) is proposed in this paper based on the framework of model predictive control. Firstly, the proposed method conducts independent outrigger modeling and decoupling of outriggers through adjacent cross-coupling; then a displacement synchronization controller (DSC) is designed to ensure efficient synchronous leveling. Secondly, a collaborative controller of displacement and force (DFCC) under variable load constraints is designed to overcome the limitations of traditional independent optimization. Subsequently, an extended state observer (ESO) is introduced to compensate for environmental disturbances and control deviations. Finally, the effectiveness of the proposed method is verified through a co-simulation using Matlab, Adams, and Solidworks. The results show that, compared with existing leveling control methods, the proposed method can achieve high precision and rapid leveling under smaller peak load, thereby extending the service life of the platform’s electric cylinders. Full article

This study proposes an enhanced integration framework for the global navigation satellite system (GNSS) and inertial navigation system (INS). The framework combines real-time differential GNSS corrections with an adaptive extended Kalman filter (EKF) to address positional accuracy and system robustness challenges in practical navigation scenarios. The proposed method dynamically compensates for positioning inaccuracies and sensor drift by integrating differential GNSS corrections to reduce errors and employing an adaptive EKF to address temporal synchronization discrepancies and misalignment angle deviations. Simulation and experimental results demonstrate that the framework keeps horizontal positioning error within 2 m and achieves a maximum accuracy improvement of 4.2 m compared to conventional single-point positioning. This low-cost solution ensures robust performance for practical autonomous navigation scenarios. Full article

Urban environments present substantial obstacles to GPS positioning accuracy, primarily due to multipath interference and limited satellite visibility. To address these challenges, we propose a novel weighting approach, referred to as the HK model, that enhances real-time GPS positioning performance by leveraging the variability of the signal-to-noise ratio (SNR), without requiring auxiliary sensors. Analysis of 24 h observational datasets collected across diverse environments, including open-sky (OS), city streets (CS), and urban canyons (UC), demonstrates that multipath-affected non-line-of-sight (NLOS) signals exhibit significantly greater SNR variability than direct line-of-sight (LOS) signals. The HK model classifies received signals based on the standard deviation of their SNR and assigns corresponding weights during position estimation. Comparative performance evaluation indicates that relative to existing weighting models, the HK model improves 3D positioning accuracy by up to 22.4 m in urban canyon scenarios, reducing horizontal RMSE from 13.0 m to 4.7 m and vertical RMSE from 19.5 m to 6.9 m. In city street environments, horizontal RMSE is reduced from 11.6 m to 3.8 m. Furthermore, a time-sequential analysis at the TEHE site confirms consistent improvements in vertical positioning accuracy across all 24-hourly datasets, and in terms of horizontal accuracy, in 22 out of 24 cases. These results demonstrate that the HK model substantially surpasses conventional SNR- or elevation-based weighting techniques, particularly under severe multipath conditions frequently encountered in dense urban settings. Full article

Purpose: This pilot study aimed to evaluate how deviations in X-ray tube head angulation and digital sensor alignment affect the radiographic measurement of the profile angle in CAD-CAM abutments. Materials and Methods: A mandibular model was used with five implant positions (central, buccal, and lingual offsets). Custom CAD-CAM abutments were designed with identical bucco-lingual direction contours and varying mesio-distal asymmetry for the corresponding implant positions. Periapical radiographs were acquired under controlled conditions by systematically varying vertical tube angulation, horizontal tube angulation, and horizontal sensor rotation from 0° to 20° in 5° increments for each parameter. Profile angles, interthread distances, and proximal overlaps were measured and compared with baseline STL data. Results: Profile angle measurements were significantly affected by both X-ray tube and sensor deviations. Horizontal tube angulation produced the greatest profile angle distortion, particularly in buccally positioned implants. Vertical x-ray tube angulations beyond 15° led to progressive underestimation of profile angles, while horizontal tube head rotation introduced asymmetric mesial–distal variation. Sensor rotation also caused marked interthread elongation, in some cases exceeding 100%, despite vertical projection being maintained. Profile angle deviations greater than 5° occurred in multiple conditions. Conclusions: X-ray tube angulation and sensor alignment influence the reliability of profile angle measurements. Radiographs with > 10% interthread elongation or crown overlap may be inaccurate and warrant re-acquisition. Special attention is needed when imaging buccally positioned implants. Full article

This study evaluates coordinate consistency in the static Korean Geodetic Datum 2002 (KGD2002) by comparing GNSS station positions derived independently from GAMIT/GLOBK and Bernese software. Using a nationwide network of approximately 3000 unified geodetic control points (UGCPs), we analyze horizontal coordinate differences (ΔN, ΔE) to identify regional patterns and potential systematic biases. The results indicate that both solutions are closely aligned with the official KGD2002 coordinates, generally within a few millimeters to sub-centimeter levels. However, small regional discrepancies are evident; for example, some provinces exhibit consistent mean northward or southward offsets on the order of 0.1–0.3 cm, and greater dispersions—up to 2 cm—are observed in peripheral regions such as Jeollanam. Notably, the Bernese solution demonstrates slightly tighter agreement, with lower standard deviations compared to GAMIT/GLOBK. The application of two distinct processing strategies within a unified static reference frame is a novel aspect of this study, revealing subtle differences attributable to network geometry, environmental factors, and software modeling approaches. The findings also underscore the limitations of KGD2002’s static nature, particularly its fixed epoch and lack of motion modeling. In response to these issues, this study discusses the rationale for transitioning to a dynamic geodetic reference frame, such as ITRF2020, to improve compatibility with international systems and account for ongoing crustal motions. Overall, the results provide a foundation for the future modernization of Korea’s spatial reference infrastructure and highlight the importance of adopting time-dependent datums in geodetic applications. Full article

The accuracy of identifying dynamic characteristics of super-tall buildings under typhoon conditions, as well as their correlation with the vibration amplitude, remains unclear, limiting the effective assessment of the structural performance and optimization of wind-resistant designs. To address this issue, the measured wind-generated vibration responses of Shanghai World Finance Center during the passage of Typhoon “Rumbia” were derived using data obtained from the health monitoring system of a super-tall building in Shanghai. The first and second inherent frequencies, as well as the damping ratio of the structure, were ascertained through the employment of the curve method and the standard deviation method. Based on this, a comparison and analysis were carried out regarding the variation patterns of the first and second inherent frequencies and the damping ratio with reference to the vibration amplitude. Vibration modes were identified using frequency domain analysis. The results of the natural frequency identification were compared to those from the Peak Picking method to see how well the curve method and the standard deviation method worked at finding modal parameters. Ultimately, an assessment of the super-tall building’s performance during the impact of the typhoon was conducted. The results demonstrate that the curve method and the standard deviation method can accurately identify the inherent frequency and damping ratio of the structure, with the curve method revealing a more pronounced regularity of the modal parameters. For the structure, in the horizontal and longitudinal directions, the first and second inherent frequencies exhibit a negative correlation with amplitude, while the damping ratio shows a positive correlation with amplitude. Moreover, as the floor level rises, the vibration modes in both directions of the structure steadily increase. During the impact of Typhoon “Rumbia”, the building’s performance complied with the requirements set by comfort standards. These analytical results not only provide valuable references for the wind-resistant design and vibration control of super-tall buildings but also offer critical support for condition assessment and damage identification within structural health monitoring systems. Full article

This study introduces an innovative GNSS-based monitoring system designed to evaluate deformation in mining headframes, effectively addressing the limitations of traditional methods, such as inadequate real-time capabilities and complex data processing requirements. The research was conducted at the Liuzhuang Mine in Anhui Province, China, where a monitoring network was established, consisting of one reference station and eight GNSS stations strategically positioned on sheave platforms and structural supports. Over a period of 66 days, high-frequency 3D deformation data were collected and processed using advanced methodologies, including cubic spline interpolation, generalized extreme studentized deviate (GESD) outlier removal, and Gaussian filtering. Spatiotemporal analysis, employing the “base state with amendments” model, indicated that 90% of the deformations (ΔX, ΔY, ΔH) were confined within ±8 mm, with more significant fluctuations observed near the sheave wheels due to mechanical stress. Correlation analysis identified the distance to the sheave wheel as the primary factor influencing horizontal deformation, with Pearson correlation coefficients exceeding 0.67, while vertical settlement remained stable. Risk thresholds, derived from statistical fluctuations, demonstrated that 99.2% of the data fell within safe limits during validation. In comparison to traditional approaches, the GNSS system delivers enhanced precision, real-time functionality, and a decreased field workload. This study presents a scalable framework for assessing headframe safety and guides the optimization of sensor placement in analogous mining settings. It is proposed that future integration with multi-source sensors, such as inertial navigation systems, will further augment monitoring robustness. Full article

In response to the challenge of low detection and positioning accuracy for safflower corollas during field operations, we propose a deep learning-based object detection and positioning algorithm called the Mobile Safflower Detection and Position Network (MSDP-Net). This approach is designed to overcome issues related to the small size of safflower corollas and their tendency to be occluded in complex agricultural environments. For object detection, we introduce an improved YOLO v5m model, referred to as C-YOLO v5m, which integrates a Convolutional Block Attention Module (CBAM) into both the backbone and neck networks. This modification enhances the model’s ability to focus on key features, resulting in increases in the precision, recall, and mean average precision of 4.98%, 4.3%, and 5.5%, respectively. For spatial positioning, we propose a mobile camera-based method in which a binocular camera is mounted on a translation stage, enabling horizontal movement that maintains optimal positioning accuracy and mitigates occlusion issues. Field experiments demonstrate that this mobile positioning method achieves a success rate of 93.79% with average deviations of less than 3 mm in the X, Y, and Z directions. Moreover, comparisons with five mainstream object detection algorithms reveal that MSDP-Net offers superior overall performance, making it highly suitable for safflower corolla detection. Finally, when applied to our self-developed safflower harvesting robot, 500 indoor trial tests achieved a harvest success rate of 90.20%, and field tests along a 15 m row confirmed a success rate above 90%, thereby validating the effectiveness of the proposed methods. Full article

Wind energy’s crucial role in global sustainability necessitates efficient wind turbine maintenance, traditionally hindered by labor-intensive, risky manual inspections. UAV-based inspections offer improvements yet often lack adaptability to dynamic conditions like blade pitch and wind. To overcome these limitations and enhance inspection efficacy, we introduce the Dynamic Trajectory Adaptation Method (DyTAM), a novel approach for automated wind turbine inspections using UAVs. Within the proposed DyTAM, real-time image segmentation identifies key turbine components—blades, tower, and nacelle—from the initial viewpoint. Subsequently, the system dynamically computes blade pitch angles, classifying them into acute, vertical, and horizontal tilts. Based on this classification, DyTAM employs specialized, parameterized trajectory models—spiral, helical, and offset-line paths—tailored for each component and blade orientation. DyTAM allows for cutting total inspection time by 78% over manual approaches, decreasing path length by 17%, and boosting blade coverage by 6%. Field trials at a commercial site under challenging wind conditions show that deviations from planned trajectories are lowered by 68%. By integrating advanced path models (spiral, helical, and offset-line) with robust optical sensing, the DyTAM-based system streamlines the inspection process and ensures high-quality data capture. The dynamic adaptation is achieved through a closed-loop control system where real-time visual data from the UAV’s camera is continuously processed to update the flight trajectory on the fly, ensuring optimal inspection angles and distances are maintained regardless of blade position or external disturbances. The proposed method is scalable and can be extended to multi-UAV scenarios, laying a foundation for future efforts in real-time, large-scale wind infrastructure monitoring. Full article

Background and Objectives: The purpose of this study was to evaluate the outcome of lateral rectus (LR) muscle resection for new-onset or worsening esotropia after medial orbital wall decompression in patients with thyroid eye disease. Materials and Methods: This retrospective observational study included 20 patients. Preoperative and postoperative measurements of ocular deviation angles and fields of binocular single vision (BSV) were performed one day before and three months after surgery. Surgical success was defined as postoperative horizontal ocular deviation ≤ 5° and BSV including the primary position. Factors influencing a reduction in the esodeviation angle were analyzed using univariate and multivariate linear regression analyses. Results: Eighteen patients (90.0%) were deemed as successful surgical cases. The esodeviation angle decreased from 19.4 ± 11.2° to 1.0 ± 2.6°. In multivariate analysis, a reduction in the esodeviation angle was correlated with the presence of dysthyroid optic neuropathy (p = 0.027), amounts of LR muscle resection in mild eyes (p = 0.014), and amounts of additional medial rectus muscle recession in severe eyes (p < 0.001). Conclusions: LR muscle resection showed a high success rate in correcting new-onset or worsening esotropia which developed after medial orbital wall decompression. Several factors influencing a reduction in the esodeviation angle were found. Full article

To achieve automation at the inner corner guard installation station in a steel coil packaging production line and enable automatic docking and installation of the inner corner guard after eye position detection, this paper proposes a binocular vision method based on deep learning for eye position detection of steel coil rolls. The core of the method involves using the Mask R-CNN algorithm within a deep-learning framework to identify the target region and obtain a mask image of the steel coil end face. Subsequently, the binarized image of the steel coil end face was processed using the RGB vector space image segmentation method. The target feature pixel points were then extracted using Sobel edges, and the parameters were fitted by the least-squares method to obtain the deflection angle and the horizontal and vertical coordinates of the center point in the image coordinate system. Through the ellipse parameter extraction experiment, the maximum deviations in the pixel coordinate system for the center point in the u and v directions were 0.49 and 0.47, respectively. The maximum error in the deflection angle was 0.45°. In the steel coil roll eye position detection experiments, the maximum deviations for the pitch angle, deflection angle, and centroid coordinates were 2.17°, 2.24°, 3.53 mm, 4.05 mm, and 4.67 mm, respectively, all of which met the actual installation requirements. The proposed method demonstrates strong operability in practical applications, and the steel coil end face position solving approach significantly enhances work efficiency, reduces labor costs, and ensures adequate detection accuracy. Full article

In this study, a Boussinesq-type wave model, namely FUNWAVE-TVD, was employed to explore solitary wave processes over coral atolls in two horizontal dimensions. First, a typical solitary wave propagation process over an idealized atoll in a field scale is simulated and analyzed. Then the effects of reef flat water depth, reef flat width, reef surface roughness, fore-reef slope, and lagoon water depth on the distribution of maximum surface elevations over atolls are investigated. Moreover, the effect of a channel on the reef flat is also studied. It is found that during solitary wave propagation, the coral reefs of an atoll can provide effective shelter for the lagoon inside; however, there will be an area of wave height enhancement near the lagoon edge at the lee side of an atoll. The maximum surface elevations over the entire atoll increase significantly with the rise in reef flat water depth, or reduced reef flat width and reef surface roughness, while the lagoon water depth and fore-reef slope have minimal influence. As the reef flat water depth increases or the reef surface roughness decreases, the extent of the wave height enhancement area at the lee side also undergoes an expansion. The presence of a channel in the reef flat mainly leads to two regions of increased wave height. The more the position of the channel deviates from the front of the atoll, the smaller the increase effect and range of the two regions will be. As the channel width increases, the increase effect and range of the two regions will also increase. Full article
