Rehabilitation devices such as actuated lower-limb exoskeletons can provide essential mobility assistance for pediatric patients with gait impairments. Enhancing their control systems under conditions of user variability and dynamic disturbances remains a significant challenge, particularly in active-assist modes. This study presents a human-in-the-loop control architecture for a pediatric lower-limb exoskeleton, combining outer-loop admittance control with robust inner-loop trajectory tracking via a non-singular terminal sliding-mode (NSTSM) controller. Designed for active-assist gait rehabilitation in children aged 8–12 years, the exoskeleton dynamically responds to user interaction forces while ensuring finite-time convergence under system uncertainties. To enhance adaptability, we augment the inner-loop control with a twin delayed deep deterministic policy gradient (TD3) reinforcement learning framework. The actor–critic RL agent tunes NSTSM gains in real-time, enabling personalized model-free adaptation to subject-specific gait dynamics and external disturbances. The numerical simulations show improved trajectory tracking, with RMSE reductions of 27.82% (hip) and 5.43% (knee), and IAE improvements of 40.85% and 10.20%, respectively, over the baseline NSTSM controller. The proposed approach also reduced the peak interaction torques across all the joints, suggesting more compliant and comfortable assistance for users. While minor degradation is observed at the ankle joint, the TD3-NSTSM controller demonstrates improved responsiveness and stability, particularly in high-load joints. This research contributes to advancing pediatric gait rehabilitation using RL-enhanced control, offering improved mobility support and adaptive rehabilitation outcomes. Full article

This study aimed to evaluate how wearable hip exoskeleton assistance affects phase-dependent gait stability in healthy adults using a novel visualization technique known as gait tube analysis. Hip exoskeletons offer significant potential to enhance human locomotion through joint torque augmentation, yet their effects on gait stability across the gait cycle remain underexplored. This study introduces gait tube analysis, a novel method for visualizing center of mass velocity trajectories in three-dimensional state space, to quantify phase-dependent gait stability under hip exoskeleton assistance. We analyzed data from ten healthy adults walking under twelve conditions (ten powered with varying torque magnitude and timing, one passive, and one unassisted), assessing variability via covariance-based ellipsoid volumes. Powered conditions, notably HighLater and HighLatest, significantly increased vertical variability (VT) during early-to-mid stance (10–50% of the gait cycle), with HighLater showing the highest mean ellipsoid volume (99,937 mm³/s³; z = 2.3). Conversely, the passive PowerOff condition exhibited the lowest variability (47,285 mm³/s³; z = –1.7) but higher metabolic cost, highlighting a stability-efficiency trade-off. VT was elevated in 11 of 12 conditions (p ≤ 0.0059), and strong correlations (r ≥ 0.65) between ellipsoid volume and total variability validated the method’s robustness. These findings reveal phase-specific stability challenges and metabolic cost variations induced by exoskeleton assistance, providing a foundation for designing adaptive controllers to balance stability and efficiency in rehabilitation and performance enhancement contexts. Full article

This study addresses gait reference trajectory tracking control in a 13-degree-of-freedom lower-limb rehabilitation robot, where patients exhibit nonlinear perturbations in lower-limb muscle groups and gait irregularities during exoskeleton-assisted walking. We propose a novel control strategy integrating iterative learning with RBF neural network-based sliding mode control, featuring a single hidden-layer pre-feedback architecture. The RBF neural network effectively approximates uncertainties arising from lower-limb muscle perturbations, while adaptive regulation through parameter simplification ensures precise torque tracking at each joint, meeting real-time rehabilitation requirements. MATLAB 2021 simulations demonstrate the proposed algorithm’s superior trajectory tracking performance compared to conventional sliding mode control, effectively eliminating control chattering. Experimental results show maximum angular errors of 1.77° (hip flexion/extension), 1.87° (knee flexion/extension), and 0.72° (ankle dorsiflexion/plantarflexion). The integrated motion capture system enables the development of patient-specific skeletal muscle models and optimized gait trajectories, ensuring both training efficacy and safety for spasticity patients. Full article

This study introduces an integrated lower limb robotic orthosis with near-field electrospinning (NFES) piezoelectric sensors and a fuzzy logic-based gait phase detection system to enhance mobility assistance and rehabilitation. The exoskeleton incorporates embedded pressure sensors within the insoles to capture ground reaction forces (GRFs) in real-time. A fuzzy logic inference system processes these signals, classifying gait phases such as stance, initial contact, mid-stance, and pre-swing. The NFES technique enables the fabrication of highly oriented nanofibers, improving sensor sensitivity and reliability. The system employs a master–slave control framework. A Texas Instruments (TI) TMS320F28069 microcontroller (Texas Instruments, Dallas, TX, USA) processes gait data and transmits actuation commands to motors and harmonic drives at the hip and knee joints. The control strategy follows a three-loop methodology, ensuring stable operation. Experimental validation assesses the system’s accuracy under various conditions, including no-load and loaded scenarios. Results demonstrate that the exoskeleton accurately detects gait phases, achieving a maximum tracking error of 4.23% in an 8-s gait cycle under no-load conditions and 4.34% when tested with a 68 kg user. Faster motion cycles introduce a maximum error of 6.79% for a 3-s gait cycle, confirming the system’s adaptability to dynamic walking conditions. These findings highlight the effectiveness of the developed exoskeleton in interpreting human motion intentions, positioning it as a promising solution for wearable rehabilitation and mobility assistance. Full article

The application of lower-limb exoskeleton robots in rehabilitation is becoming more prevalent, where the precision of control and the speed of response are essential for effective movement tracking. This study tackles the challenge of optimizing both control accuracy and response speed in trajectory tracking for lower-limb exoskeleton hip robots. We introduce an optimization strategy that integrates the Sparrow Search Algorithm (SSA) with fuzzy Proportional-Integral-Derivative (PID) control. This approach addresses the inefficiencies and time-consuming process of manual parameter tuning, thereby improving trajectory tracking performance. First, recognizing the complexity of hip joint motion, which involves multiple degrees of freedom and intricate dynamics, we employed the Lagrangian method. This method is particularly effective for handling nonlinear systems and simplifying the modeling process, allowing for the development of a dynamic model for the hip joint. The SSA is subsequently utilized for the online self-tuning optimization of both the proportional and quantization factors within the fuzzy PID controller. Simulation experiments confirm the efficacy of this strategy in tracking hip joint trajectories during flat walking and standing hip flexion rehabilitation exercises. Experimental results from diverse test populations demonstrate that SSA-fuzzy PID control improves response times by 27.8% (for flat walking) and 30% (for standing hip flexion) when compared to traditional PID control, and by 6% and 2%, respectively, relative to fuzzy PID control. Regarding tracking accuracy, the SSA-fuzzy PID approach increases accuracy by 81.4% (for flat walking) and 80% (for standing hip flexion) when compared to PID control, and by 57.5% and 56.8% relative to fuzzy PID control. The proposed strategy significantly improves both control accuracy and response speed, offering substantial theoretical support for rehabilitation training in individuals with lower-limb impairments. Moreover, in comparison to existing methods, this approach uniquely tackles the challenges of parameter tuning and optimization, presenting a more efficient solution for trajectory tracking in exoskeleton systems. Full article

This study presents a method for the active control of a follow-up lower extremity exoskeleton rehabilitation robot (LEERR) based on human motion intention recognition. Initially, to effectively support body weight and compensate for the vertical movement of the human center of mass, a vision-driven follow-and-track control strategy is proposed. Subsequently, an algorithm for recognizing human motion intentions based on machine learning is proposed for human-robot collaboration tasks. A muscle–machine interface is constructed using a bi-directional long short-term memory (BiLSTM) network, which decodes multichannel surface electromyography (sEMG) signals into flexion and extension angles of the hip and knee joints in the sagittal plane. The hyperparameters of the BiLSTM network are optimized using the quantum-behaved particle swarm optimization (QPSO) algorithm, resulting in a QPSO-BiLSTM hybrid model that enables continuous real-time estimation of human motion intentions. Further, to address the uncertain nonlinear dynamics of the wearer-exoskeleton robot system, a dual radial basis function neural network adaptive sliding mode Controller (DRBFNNASMC) is designed to generate control torques, thereby enabling the precise tracking of motion trajectories generated by the muscle–machine interface. Experimental results indicate that the follow-up-assisted frame can accurately track human motion trajectories. The QPSO-BiLSTM network outperforms traditional BiLSTM and PSO-BiLSTM networks in predicting continuous lower limb motion, while the DRBFNNASMC controller demonstrates superior gait tracking performance compared to the fuzzy compensated adaptive sliding mode control (FCASMC) algorithm and the traditional proportional–integral–derivative (PID) control algorithm. Full article

The increasing demand for rehabilitation and walking assistive devices driven by aging populations has promoted the development of a novel hip joint structure. This design aims to enhance the functionality of lower limb exoskeletons by eliminating the kinematic mismatch with the human’s biological hip. The design utilizes three 1-DOF (Degree of Freedom) rotational joints to replicate natural hip movement. By integrating IMU data, motor compensation is dynamically made to facilitate a more natural gait. Experimental results indicate improved hip joint angles and enhanced user comfort, presenting a promising solution for better walking assistance for elderly individuals. Full article

In recent years, the increasing number of patients with spinal cord injuries, strokes, and lower limb disabilities has led to the gradual development of rehabilitation-assisted exoskeleton robots. A critical aspect of these robots is their ability to accurately sense human movement intentions to achieve smooth and natural control. This paper describes research carried out on predicting the motion angles of human lower limb joints. Based on the design of a signal acquisition system for physiological muscle signals and inertial measurement unit (IMU) data, a hybrid neural network prediction model (QRTCN-BiLSTM) and a single neural network prediction model (QRBiLSTM) were constructed using quantile regression, temporal convolution network (TCN) and bidirectional long short-term memory network (BiLSTM), respectively. At the same time, 7-channel surface electromyographic signals (sEMG) and 12-channel IMU data from hip and knee joints were collected and input into the QRBiLSTM and QRTCN-BiLSTM models to unfold the training and analyze the comparison. The results show that the QRTCN-BiLSTM model can more accurately infer human movement intention and provide a more reliable and accurate prediction tool for human–robot interaction research in rehabilitation robotics. Full article

The demand for remote rehabilitation is increasing, opening up convenient and effective home-based therapy for the sick and elderly. In this study, we use AnyBody simulations to analyze muscle activity and determine key parameters for designing a rehabilitation exoskeleton, as well as selecting the appropriate motor torque to assist patients during rehabilitation sessions. The exoskeleton was designed with a PID control mechanism for the precise management of motor positions and joint torques, and it operates in both automated and teleoperation modes. Hip and knee movements are monitored via smartphone-based IMU sensors, enabling real-time feedback. Bluetooth communication ensures seamless control during various training scenarios. Our study demonstrates that remotely controlled rehabilitation systems can be implemented effectively, offering vital support not only during global health crises such as pandemics but also in improving the accessibility of rehabilitation services in remote or underserved areas. This approach has the potential to transform the way physical therapy can be delivered, making it more accessible and adaptable to the needs of a larger patient population. Full article

The motion control system of a lower-limb exoskeleton rehabilitation robot (LLERR) is designed to assist patients in lower-limb rehabilitation exercises. This research designed a motion controller for an LLERR-based on the Twin Delayed Deep Deterministic policy gradient (TD3) algorithm to control the lower-limb exoskeleton for gait training in a staircase environment. Commencing with the establishment of a mathematical model of the LLERR, the dynamics during its movement are systematically described. The TD3 algorithm is employed to plan the motion trajectory of the LLERR’s right-foot sole, and the target motion curve of the hip (knee) joint is deduced inversely to ensure adherence to human physiological principles during motion execution. The control strategy of the TD3 algorithm ensures that the movement of each joint of the LLERR is consistent with the target motion trajectory. The experimental results indicate that the trajectory tracking errors of the hip (knee) joints are all within 5°, confirming that the LLERR successfully assists patient in completing lower-limb rehabilitation training in a staircase environment. The primary contribution of this study is to propose a non-linear control strategy tailored for the staircase environment, enabling the planning and control of the lower-limb joint motions facilitated by the LLERR. Full article

Cycling stands as one of the most widely embraced leisure activities and serves purposes such as exercise, rehabilitation, and commuting. This study aimed to assess the feasibility of assisting three unimpaired participants (age: 34.0 ± 7.9 years, height: 1.86 ± 0.02 m, weight: 75.7 ± 12.7 kg) using the GuroX hip exoskeleton, originally designed for walking assistance, during cycling against a resistance of 1 W/kg. The performance evaluation employed a sweep protocol that manipulated the timing of the exoskeleton’s peak extension and flexion torque in addition to human-in-the-loop optimization to enhance these timings based on metabolic cost. Our findings indicate that with a peak assistance torque of approximately 10.3 Nm for extension and flexion, the GuroX substantially reduced the net metabolic cost of cycling by 31.4 ± 8.1% and 26.4 ± 14.1% compared to transparent and without exoskeleton conditions, respectively. This demonstrates the significant potential of a hip exoskeleton developed for walking assistance to profoundly benefit cycling. Additionally, customizing the assistance strategy proves beneficial in maximizing assistance. While we attribute the average motor power to be a major contributor to the reduced cycling effort, participant feedback suggests that user comfort and synchronization between the user and exoskeleton may have played integral roles. Further research should validate our initial findings by employing a larger participant pool in real-world conditions. Incorporating a more diverse set of parameters for the human-in-the-loop optimization could enhance individualized assistance strategies. Full article

Pediatric gait rehabilitation and guidance strategies using robotic exoskeletons require a controller that encourages user volitional control and participation while guiding the wearer towards a stable gait cycle. Virtual constraint-based controllers have created stable gait cycles in bipedal robotic systems and have seen recent use in assistive exoskeletons. This paper evaluates a virtual constraint-based controller for pediatric gait guidance through comparison with a traditional time-dependent position tracking controller on a newly developed exoskeleton system. Walking experiments were performed with a healthy child subject wearing the exoskeleton under proportional-derivative control, virtual constraint-based control, and while unpowered. The participant questionnaires assessed the perceived exertion and controller usability measures, while sensors provided kinematic, control torque, and muscle activation data. The virtual constraint-based controller resulted in a gait similar to the proportional-derivative controlled gait but reduced the variability in the gait kinematics by 36.72% and 16.28% relative to unassisted gait in the hips and knees, respectively. The virtual constraint-based controller also used 35.89% and 4.44% less rms torque per gait cycle in the hips and knees, respectively. The user feedback indicated that the virtual constraint-based controller was intuitive and easy to utilize relative to the proportional-derivative controller. These results indicate that virtual constraint-based control has favorable characteristics for robot-assisted gait guidance. Full article

Most lower limb rehabilitation robots are limited to specific training postures to adapt to stroke patients in multiple stages of recovery. In addition, there is a lack of attention to the switching functions of the training side, including left, right, and bilateral, which enables patients with hemiplegia to rehabilitate with a single device. This article presents an exoskeleton robot named the multistage hemiplegic lower-limb rehabilitation robot, which has been designed to do rehabilitation in multiple training postures and training sides. The mechanism consisting of the thigh, calf, and foot is introduced. Additionally, the design of the multi-mode limit of the hip, knee, and ankle joints supports delivering therapy in any posture and training sides to aid patients with hemiplegia in all stages of recovery. The gait trajectory is planned by extracting the gait motion trajectory model collected by the motion capture device. In addition, a control system for the training module based on adaptive iterative learning has been simulated, and its high-precision tracking performance has been verified. The gait trajectory experiment is carried out, and the results verify that the trajectory tracking performance of the robot has good performance. Full article

Exoskeleton robots hold promising prospects for rehabilitation training in individuals with weakened muscular conditions. However, achieving improved human–machine interaction and delivering customized assistance remains a challenging task. This paper introduces a muscle synergy-based human-in-the-loop (HIL) optimization framework for hip exoskeletons to offer more personalized torque assistance. Initially, we propose a muscle synergy similarity index to quantify the similarity of synergy while walking with and without the assistance of an exoskeleton. By integrating surface electromyography (sEMG) signals to calculate metrics evaluating muscle synergy and iteratively optimizing assistance parameters in real time, a muscle synergy-based HIL optimized torque configuration is presented and tested on a portable hip exoskeleton. Iterative optimization explores the optimal and suboptimal assistance torque profiles for six healthy volunteers, simultaneously testing zero torque and predefined assistance configurations, and verified the corresponding muscle synergy similarity indices through experimental testing. In our validation experiments, the assistance parameters generated through HIL optimization significantly enhance muscle synergy similarity during walking with exoskeletal assistance, with an optimal average of 0.80 ± 0.04 (mean ± std), marking a 6.3% improvement over prior assistive studies and achieving 96.4% similarity compared with free walking. This demonstrates that the proposed muscle synergy-based HIL optimization can ensure robotic exoskeleton-assisted walking as “natural” as possible. Full article

Lower limb exoskeletons and orthoses have been increasingly used to assist the user during gait rehabilitation through torque transmission and motor stability. However, the physical human-robot interface (HRi) has not been properly addressed. Current orthoses lead to spurious forces at the HRi that cause adverse effects and high abandonment rates. This study aims to assess and compare, in a holistic approach, human-robot joint misalignment and gait kinematics in three fixation designs of ankle-foot orthoses (AFOs). These are AFOs with a frontal shin guard (F-AFO), lateral shin guard (L-AFO), and the ankle modulus of the H2 exoskeleton (H2-AFO). An experimental protocol was implemented to assess misalignment, fixation displacement, pressure interactions, user-perceived comfort, and gait kinematics during walking with the three AFOs. The F-AFO showed reduced vertical misalignment (peak of 1.37 ± 0.90 cm, p-value < 0.05), interactions (median pressures of 0.39–3.12 kPa), and higher user-perceived comfort (p-value < 0.05) when compared to H2-AFO (peak misalignment of 2.95 ± 0.64 and pressures ranging from 3.19 to 19.78 kPa). F-AFO also improves the L-AFO in pressure (median pressures ranging from 8.64 to 10.83 kPa) and comfort (p-value < 0.05). All AFOs significantly modified hip joint angle regarding control gait (p-value < 0.01), while the H2-AFO also affected knee joint angle (p-value < 0.01) and gait spatiotemporal parameters (p-value < 0.05). Overall, findings indicate that an AFO with a frontal shin guard and a sports shoe is effective at reducing misalignment and pressure at the HRI, increasing comfort with slight changes in gait kinematics. Full article
