Search Results (128)

This paper introduces a non-isolated ultra-high voltage gain topology using the combination of the coupled-inductor-based inverting buck-boost converter (IBB) and voltage multiplier (VM) structure. In the proposed converter, an ultra-high step-up voltage gain can be achieved with a small duty cycle thanks to a coupled inductor and VMs. The voltage stress and the losses of the switches in the proposed converter are even less than other conventional topologies. Unlike other coupled-inductor topologies, a large voltage spike caused by the leakage inductance of the coupled inductor is smoothed by the capacitor in the voltage multiplier. In addition, zero-voltage switching (ZVS) turn-on for the switches and zero-current switching (ZCS) turn-off for the diodes can be achieved with the energy stored in the leakage inductance. A 360 W (40 V/380 V) prototype converter is implemented to prove the advantages of the proposed converter, with a maximum efficiency of 98.4%. Full article

This study presents a pneumatic proportional pressure valve employing a silicon microfluidic chip (SMC) integrated with a V-shaped electrothermal microactuator, aiming to address the limitations of traditional solenoid-based valves in miniaturization and high-precision control. The SMC, fabricated via MEMS technology, leverages the thermal expansion of microactuator ribs to regulate pressure through adjustable orifices. A first-order transfer function between input voltage and displacement of the microactuator was derived through theoretical modeling and validated via COMSOL Multiphysics 5.2a simulations. Key geometric parameters of the actuator ribs—cross-section, number, inclination angle, width, span length and thickness—were analyzed for their influence on lever mechanism displacement, actuator displacement, static gain and time constant. AMESim 16.0-based simulations of single- and dual-chip valve structures revealed that increasing ζ shortens step-response rise time, while reducing τ improves hysteresis. Experimental validation confirmed the valve’s static and dynamic performance, achieving a step-response rise time of <40 ms, linearity within the 30–60% input voltage range, and effective tracking of sinusoidal control signals up to 8 Hz with a maximum pressure deviation of 0.015 MPa. The work underscores the potential of MEMS-based actuators in advancing compact pneumatic systems, offering a viable alternative to conventional solenoids. Key innovations include geometry-driven actuator optimization and dual-chip integration, providing insights into high-precision, low-cost pneumatic control solutions. Full article

By combining a coupled inductor with voltage multipliers, the voltage gain of a boost converter can be improved significantly. This method has good application prospects in renewable energy generation and in DC microgrids. A coupled inductor is the core component of the high step-up DC/DC converter and has serious impact on its performance. However, shortage in the methods used to design the coupled inductor have limited the applications of such converters. By analyzing the operating modes of the high step-up DC/DC converter with a three-winding coupled inductor combined with two voltage multipliers, accurate and simplified models of currents in the three windings are established. Furthermore, a design methodology for a multi-winding coupled inductor is put forward, in which a method of calculating the boost inductance and product areas (AP) and a method for selecting the magnetic core are established. The influence of winding arrangements and loss evaluations of the coupled inductor are also investigated. Finally, a 200 W prototype converter with an input of 20 V and output of 200 V is prepared and tested. The correctness of the current models of and design methods used on coupled inductor are verified. More important, the method proposed to design multi-winding coupled inductors can be applied to design high step-up DC/DC converters with different topologies. Full article

The transition to environmentally sustainable maritime operations has gained urgency with the International Maritime Organization’s (IMO) 2023 GHG reduction strategy, aiming for net-zero emissions by 2050. While alternative fuels like LNG and methanol serve as transitional solutions, lithium-ion battery energy storage systems (ESSs) offer a viable low-emission alternative. However, safety concerns such as thermal runaway, overcharging, and internal faults pose significant risks to marine battery systems. This study presents an AI-based fault prediction algorithm to enhance the safety and reliability of lithium-ion battery systems used in electric propulsion ships. The research employs a Long Short-Term Memory (LSTM)-based predictive model, integrating electrochemical impedance spectroscopy (EIS) data and voltage deviation analyses to identify failure patterns. Bayesian optimization is applied to fine-tune hyperparameters, ensuring high predictive accuracy. Additionally, a recursive multi-step prediction model is developed to anticipate long-term battery performance trends. The proposed algorithm effectively detects voltage deviations and pre-emptively predicts battery failures, mitigating fire hazards and ensuring operational stability. The findings support the development of safer and more reliable energy storage solutions, contributing to the broader adoption of electric propulsion in maritime applications. Full article

In this article, a new high step-up interleaved DC–DC converter is presented for renewable energy systems. The converter circuit is based on the interleaved two-phase boost converter and integrates a voltage-lift capacitor and a voltage multiplier cell. A high voltage gain of the converter can be achieved with a reasonable duty ratio and the voltage stresses of semiconductor devices are reduced. Because of low voltage stress, the switches with low on-resistance and the diodes with low forward voltage drops can be adopted to minimize the conduction losses. Additionally, the switching losses are reduced because the switches are turned on under zero-current switching (ZCS) conditions. Due to the existence of leakage inductances of the coupled inductors, the diode reverse-recovery problem is alleviated. Moreover, the leakage energy is recycled and the voltage spikes during switch turn-off are avoided. The parallel input architecture and interleaved operation reduce the input current ripple. The operating principles, steady-state characteristics, and design considerations of the presented converter are proposed in detail. Furthermore, a closed-loop control is designed to maintain a well-regulated output voltage despite variations in input voltage and output load. A prototype converter with a rated 1000 W output power is realized for demonstration. Finally, experimental results show the converter effectiveness and verify the theoretical analysis. Full article

This paper presents a low-power, fully differential, programmable gain amplifier (PGA) for ultrasound receiver analog front-ends (AFE). It consists of a programmable attenuator implemented by a capacitive voltage divider and a closed-loop amplifier based on a differential difference amplifier (DDA). A suitable sizing strategy provides orthogonal control over gain and bandwidth. The PGA was designed using a standard 180 nm CMOS process. The gain value can be set between −18 dB and +20 dB in 2 dB steps; the bandwidth can be programmed independently of gain, to values from 5 MHz to 20 MHz, in 5 MHz steps; it draws 600 µA from a 1.8 V supply line. It achieves a differential output swing of 0.8 V peak-to-peak differential with no more than 1.7% total harmonic distortion (THD) and an input-referred noise density of 22 nV/√Hz at 10 MHz, measured at the gain of 20 dB. The PGA exhibits high input impedance and low output resistance for easy integration within the AFE signal chain. The digitally controlled gain and bandwidth make this PGA suitable for ultrasound imaging applications requiring precise time gain compensation and adjustable frequency response and/or additional anti-aliasing filtering. Full article

Hybrid energy storage systems (HESSs) are essential for adopting sustainable energy sources. HESSs combine complementary storage technologies, such as batteries and supercapacitors, to optimize efficiency, grid stability, and demand management. This work proposes a semi-active HESS formed by a battery connected to the DC bus and a supercapacitor managed by a Sepic/Zeta converter, which has the aim of avoiding high-frequency variations in the battery current on any operation condition. The converter control structure is formed by an LQG controller, an optimal state observer, and an adaptive strategy to ensure the correct controller operation in any condition: step-up, step-down, and unitary gain. This adaptive LQG controller consists of two control loops, an internal current loop and an external voltage loop, which use only two sensors. Compared with classical PI and LQG controllers, the adaptive LQG solution exhibits a better performance in all operation modes, up to 68% better than the LQG controller and up to 84% better than the PI controller. Therefore, the control strategy proposed for this HESS provides a fast-tracking of DC-bus current, driving the high-frequency component to the supercapacitor and the low-frequency component to the battery. Thus, fast changes in the battery power are avoided, reducing the degradation. Finally, the system adaptability to changes up to 67% in the operation range are experimentally tested, and the implementation of the control system using commercial hardware is verified. Full article

This paper presents an isolated DC-DC converter with high voltage gain that features an advanced inter-built nanocrystalline-core medium-frequency transformer (NC-MFT). The isolated DC-DC converter with an NC-MFT is specifically designed for applications such as interconnect photovoltaic (PV) systems, DC microgrids, DC loads, and DC buses, where voltage gain is one of the essential issues to consider. The NC-MFT inside the DC-DC converter is designed with a new approach that not only provides isolation but also contributes to achieving high efficiency and a higher step-up ratio. The high efficiency of the converters contributes to the integration of PV systems into DC microgrids. The converter yields a high voltage conversion ratio of 16.17. The experimental results obtained at 41.8 V/676 V and 275 W for the prototype revealed high efficiency (95.63% at full load). The experimental results validate the theoretical analysis and simulation, confirming that the converter achieves the main objective of high voltage conversion and high efficiency. These results will contribute to the interest in the use of this type of energy and its impact on the reduction in CO₂ emissions. Full article

With the increasing market demands for wearable and portable electronic devices, binary metal oxides (BMOs) with a remarkable capacity and good structure stability have been considered as a promising candidate for fabricating coplanar micro-supercapacitors (CMSCs), serving as the power source. However, the current fabrication methods for BMO microelectrodes are complex, which greatly hinder their further development and application in BMO CMSCs. Herein, the one-step fabrication of 2.5D CuMoO_x-based CMSCs (CuMoCMSCs) has been realized by numerically controlled electric discharge machining (NCEDM) for the first time. In addition, the controllable capacity of CuMoCMSCs has been achieved by adjusting the NCEDM-machining voltage. The CuMoCMSCs machined by a machining voltage of 60 V (CuMoCMSCs60) showed the best performance. The fabricated CuMoCMSCs60 with binary metal oxides could operate at an ultra-high scanning rate of 10 V s⁻¹, and gained a capacity of 40.3 mF cm⁻² (1.1 mA cm⁻²), which is more than 4 times higher than that of MoO_x-based CMSCs (MoCMSCs60) with a single metal oxide. This is because CuMoO_x BMOs materials overcome the poor electroconductivity problem of the MoO_x single metal oxide. This one-step and numerically controlled fabrication technique developed in this research opens a new vision for preparing BMO materials, BMO microelectrodes, and BMO microdevices in an environmental, automatic, and intelligent way. Full article

Silicon Photomultipliers (SiPMs) are single photon detectors that gained increasing interest in many applications as an alternative to photomultiplier tubes. In the field of space experiments, where volume, weight and power consumption are a major constraint, their advantages like compactness, ruggedness, and their potential to achieve high quantum efficiency from UV to NIR makes them ideal candidates for spaceborne, low photon flux detectors. During space missions however, SiPMs are usually exposed to high levels of radiation, both ionizing and non-ionizing, which can deteriorate the performance of these detectors over time. The goal of this work is to compare process and layout variation of SiPMs in terms of their radiation damage effects to identify the features that helps reduce the deterioration of the performance and develop the next generation of more radiation-tolerant detectors. To do this, we used protons and X-rays to irradiate several Near Ultraviolet High-Density (NUV-HD) SiPMs with small areas (single microcell, 0.2 × 0.2 mm² and 1 × 1 mm²) produced at Fondazione Bruno Kessler (FBK), Italy. We performed online current-voltage measurements right after each irradiation step, and a complete functional characterization before and after irradiation. We observed that the main contribution to performance degradation in space applications comes from proton damage in the form of an increase in primary dark count rate (DCR) proportional to the proton fluence and a reduction in activation energy. In this context, small active area devices show a lower DCR before and after irradiation, and we propose light or charge-focusing mechanisms as future developments for high-sensitivity radiation-tolerant detectors. Full article

Hybrid electric vehicles (HEVs) and fuel cell electric vehicles (FCEVs) utilize boost converters to gain a higher voltage than the battery. Interleaved boost converters are suitable for low input voltage, large input current, miniaturization, and high-efficiency applications. This paper proposes a novel linear quadratic integral (LQI) control for the interleaved boost converters. First, the small-signal model of the interleaved-boost converter is derived. In the proposed method, an output voltage and a current signal error between two-phase input currents are selected to control not only the output voltage but also a balance between two-phase input currents. Furthermore, steady-state characteristics in terms of the output voltage and the input current are demonstrated by experiments and simulations using an experimental apparatus with a rated power of 700 W. The validity of the proposed method’s tracking performance and load response is demonstrated by comparing it with that of the conventional PI control. The tracking performance of the LQI control for the 40 V step response has a ten times faster response than that of the PI control. Also, the experimental results demonstrate that the proposed method maintains a constant output voltage for a 300 W load step while the PI control varies by 10 V during 70 ms. Additionally, the proposed method has an excellent disturbance rejection. Full article

In this paper, two kinds of miniaturization methods for designing a compact wideband tapered slot antenna (TSA) using either fan-shaped structures only or fan-shaped and stepped structures were proposed. First, a miniaturization method appending the fan-shaped structures, such as quarter circular slots (QCSs), half circular slots (HCSs), and half circular patches (HCPs), to the sides of the ground conductor for the TSA was investigated. The effects of appending the QCSs, HCSs, and HCPs sequentially on the input reflection coefficient and gain characteristics of the TSA were compared. The compact wideband TSA using the first miniaturization method showed the simulated frequency band for a voltage standing wave ratio (VSWR) less than 2 of 2.530–13.379 GHz (136.4%) with gain in the band ranging 3.1–6.9 dBi. Impedance bandwidth was increased by 29.7% and antenna size was reduced by 39.1%, compared to the conventional TSA. Second, the fan-shaped structures combined with the stepped structures (SSs) were added to the sides of the ground conductor to further miniaturize the TSA. The fan-shaped structures based on the HCSs and HCPs were appended to the ground conductor with the QCSs and SSs. The compact wideband TSA using the second miniaturization method had the simulated frequency band for a VSWR less than 2 of 2.313–13.805 GHz (142.6%) with gain in the band ranging 3.0–8.1 dBi. Impedance bandwidth was increased by 37.8% and antenna size was reduced by 45.9%, compared to the conventional TSA. Therefore, the increase in impedance bandwidth and the size reduction effect of the compact wideband TSA using the second miniaturization method were better compared to those using the first method. In addition, sidelobe levels at high frequencies decreased while gain at high frequencies increased. A prototype of the compact wideband TSA using the second miniaturization method was fabricated on an RF-35 substrate to validate the simulation results. The measured frequency band for a VSWR less than 2 was 2.320–13.745 GHz (142.2%) with measured gain ranging 3.1–7.9 dBi. Full article

A spacecraft power processing unit (PPU) is utilized to convert power from solar arrays or electric batteries to the payload, including electric propulsion, communication equipment, and scientific instruments. Currently, a high-voltage converter is widely applied to the spacecraft PPU to improve power density and save launch weight. However, the high voltage level poses challenges such as high step-down ratios and high power losses. To achieve less conduction loss, a SiC-based T-type three-level (TL) $LLC$ resonant converter is proposed. To further broaden the gain range and achieve high step-down ratios, a variable frequency and adjustable phase-shift (VFAPS) modulation scheme is proposed. Meanwhile, the steady-state time-domain model is established to elaborate the operation principles and boundary conditions for soft switching. Furthermore, the optimal resonant element design considerations have been elaborated to achieve wider gain range and facilitate easier soft switching. Furthermore, the numerical solutions for switching frequency and phase shift (PS) angle under each specific input could be figured out. Finally, the effectiveness of this theoretical analysis is demonstrated via a 500-W experimental prototype with 650∼950-V input and constant output of 48-V/11-A. Full article

This paper presents a first-order noise-shaping (NS) successive approximation register (SAR) analog-to-digital converter (ADC) with a process, (supply) voltage, and temperature (PVT)-insensitive closed-loop integrator and data-weighted averaging (DWA). The use of a cascode floating inverter amplifier (FIA)-type dynamic amplifier with high gain enables an aggressive noise transfer function while minimizing the power consumption associated with the use of an active filter. In the proposed ADC, the residue is generated by a capacitive digital-to-analog converter (CDAC) employing DWA, which is made possible by employing a second CDAC, which operates after the SAR operation is completed. The proposed ADC is designed with a 28 nm CMOS process with 1 V power supply. The simulation results show that the ADC achieves the SNDR of 71.2 dB and power consumption of 228 μW when operated with a sampling rate of 80 MS/s and oversampling ratio (OSR) of 10. The Schreier figure-of-merit (FoM) is 173.6 dB, and Walden FoM is 9.6 fJ/conversion-step. Full article

Many applications, such as photovoltaic systems, uninterruptible power supplies, and automobile headlamps, need a high step-up DC–DC converter without isolation. The conventional boost converter has the advantages of simple topology and easy control. However, it has some shortcomings, such as insufficient step-up voltage ratio and poor efficiency when operating at large duty-cycle conditions. One of the popular topologies used to overcome these problems is the coupled-inductor boost converter. It utilizes the turn ratio of the coupled inductor to realize a higher step-up voltage ratio. The drawback is that the leakage inductance of the coupled inductor causes a huge voltage spike when the power switches are turned off. Moreover, because coupled inductors are characterized by their large volume and high profile, a conventional coupled-inductor boost converter is unsuited for photovoltaic systems, such as the solar microinverter. This study proposes a novel high-step-up boost converter to solve these problems. This proposed converter uses dual coupled inductors instead of the conventional coupled-inductor boost converter. The secondary side of the coupled inductor is connected in series to increase the step-up voltage ratio. The proposed converter utilizes active clamping to achieve zero-voltage switching (ZVS) for suppressing voltage spike and improving conversion efficiency. In addition, low-profile designs can be fulfilled easily for solar microinverters. The proposed converter and its control method are introduced. The operation principle, circuit characteristics, and circuit analysis are presented. A prototype converter with 300 W output power 25–40 VDC input voltage and 200 VDC output voltage was tested. All functions, including high step-up voltage ratio, ZVS, and active clamping, were achieved, and the highest efficiency was around at 94.7%. Full article
