Automotive NVH (Noise, Vibration, and Harshness) performance significantly impacts driving comfort and traffic safety. Vehicles exhibiting superior NVH characteristics are more likely to achieve consumer acceptance and enhance their competitiveness in the marketplace. In the development of automotive NVH performance, traditional vibration reduction methods have proven to be mature and widely implemented. However, due to constraints related to size and weight, these methods typically address only high-frequency vibration control. Consequently, they struggle to effectively mitigate vehicle body and component vibration noise at frequencies below 200 Hz. In recent years, acoustic metamaterials (AMMs) have emerged as a promising solution for suppressing low-frequency vibrations. This development offers a novel approach for low-frequency vibration control. Nevertheless, conventional design methodologies for AMMs predominantly rely on empirical knowledge and necessitate continuous parameter adjustments to achieve desired bandgap characteristics—an endeavor that entails extensive calculations and considerable time investment. With advancements in machine learning technology, more efficient design strategies have become feasible. This paper presents a tandem neural network (TNN) specifically developed for the design of AMMs. The trained neural network is capable of deriving both the bandgap characteristics from the design parameters of AMMs as well as deducing requisite design parameters based on specified bandgap targets. Focusing on addressing low-frequency vibrations in the back frame of automobile seats, this method facilitates the determination of necessary AMMs design parameters. Experimental results demonstrate that this approach can effectively guide AMMs designs with both speed and accuracy, and the designed AMMs achieved an impressive vibration attenuation rate of 63.6%. Full article

This study presents an analysis of the electromagnetic noise and vibration in a surface-mounted permanent magnet synchronous machine (SPMSM), focusing on their excitation sources. To investigate this, the excitation sources were identified through an analytical approach, and their effects on electromagnetic noise and vibration were evaluated using a finite element method (FEM)-based analysis approach. Additionally, an equivalent curved-beam model based on three-dimensional shell theory was applied to determine the deflection forces on the stator yoke, accounting for the tooth-modulation effect. The stator’s natural frequencies were derived through the characteristic equation in free vibration analysis. Modal analysis was performed to validate the analytically derived natural frequencies and to investigate stator deformation under the tooth-modulation effect across various vibration modes. Furthermore, noise, vibration, and harshness (NVH) analysis via FEM reveals that major harmonic components align closely with the natural frequencies, identifying them as primary sources of elevated vibrations. A comparative study between 8-pole–9-slot and 8-pole–12-slot SPMSMs highlights the impact of force variations on the stator teeth in relation to vibration and noise characteristics, with FEM verification. The proposed method provides a valuable tool for early-stage motor design, enabling the rapid identification of resonance operating points that may induce severe vibrations. This facilitates proactive mitigation strategies to enhance motor performance and reliability. Full article

Driven by the urgent demand for low-frequency vibration and noise control in engineering scenarios such as automobiles, acoustic metamaterials (AMs), as a new class of functional materials, have demonstrated significant application potential. This paper proposes a low-frequency band gap optimization design method for local resonance acoustic metamaterials (LRAMs) based on a multi-objective genetic algorithm. Within a COMSOL Multiphysics 6.2 with MATLAB R2024b co-simulation framework, a parameterized unit cell model of the metamaterial is constructed. The optimization process targets two objectives: minimizing the band gap’s deviation from the target and reducing the structural mass. A multi-objective fitness function is formulated by incorporating the band gap deviation and structural mass constraints, and non-dominated sorting genetic algorithm II (NSGA-II) is employed to perform a global search over the geometric parameters of the resonant unit. The resulting Pareto-optimal solution set achieves a unit cell mass as low as 26.49 g under the constraint that the band gap deviation does not exceed 2 Hz. The results of experimental validation show that the optimized metamaterial configuration reduces the peak of the low-frequency frequency response function (FRF) at 63 Hz by up to 75% in a car door structure. Furthermore, the simulation predictions exhibit good agreement with the experimental measurements, confirming the effectiveness and reliability of the proposed method in engineering applications. The proposed multi-objective optimization framework is highly general and extensible and capable of effectively balancing between the acoustic performance and structural mass, thus providing an efficient engineering solution for low-frequency noise control problems. Full article

Evaluating noise, vibration, and harshness (NVH) performance is crucial in vehicle development. However, NVH evaluation is often subjective and challenging to achieve through numerical simulation, and typically prototypes are required. Dynamic driving simulators are emerging as a viable solution for assessing NVH performance in the early development phase before physical prototypes are available. However, most current simulators can reproduce vibrations only in a single direction or within a limited frequency range. This paper presents a comprehensive design optimization approach to enhance the dynamic response of a full-spectrum driving simulator, addressing these limitations. Specifically, in complex driving simulators, vibration crosstalk is a critical and common issue, which usually leads to an inaccurate dynamic response of the system, compromising the realism of the driving experience. Vibration crosstalk manifests as undesired vibration components in directions other than the main excitation direction due to structural coupling. To limit the system crosstalk, a flexible multibody dynamics model of the driving simulator has been developed, validated, and employed for a global sensitivity analysis. From this analysis, it turns out that the bushings located below the seat play a crucial role in the crosstalk characteristics of the system and can be effectively optimized to obtain the desired performances. Bushings’ stiffness and locations have been used as design variables in a multiobjective optimization with the aims of increasing the direct transmissibility of the actuators’ excitation and, at the same time, reducing the crosstalk contributions. A surrogate model approach is employed for reducing the computational cost of the process. The results show substantial crosstalk reduction, up to 57%. The proposed method can be effectively applied to improve the dynamic response of driving simulators allowing for their extensive use in the assessment of vehicles’ NVH performances. Full article

In order to confront the challenge of efficiently evaluating interior wind noise levels in passenger vehicles during the early stages of shape design, this paper proposes a methodology for predicting interior wind noise. The methodology integrates vehicle shape features with a whale optimization Xception model (WOA-Xception). A nonlinear mapping model is constructed between the vehicle shape features and the wind noise level at the driver’s right ear. This model is constructed using key exterior parameters, which are extracted from wind tunnel test data under typical operating conditions. The exterior parameters include the front windshield, A-pillar, and roof. The key hyperparameters of the Xception model are adaptively optimized using the whale optimization algorithm to improve the prediction accuracy and generalization ability of the model. The prediction results on the test set demonstrate that the WOA-Xception model attains mean absolute percentage error (MAPE) values of 9.78% and 9.46% and root mean square error (RMSE) values of 3.73 and 4.06, respectively, for sedan and Sports Utility Vehicle (SUV) samples, with prediction trends that align with the measured data. A comparative analysis with traditional Xception, WOA-LSTM, and Long Short-Term Memory (LSTM) models further validates the advantages of this model in terms of accuracy and stability, and it still maintains good generalization ability on an independent validation set (mean absolute percentage error of 9.45% and 9.68%, root mean square error of 3.77 and 4.15, respectively). The research findings provide an efficient and feasible technical approach for the rapid assessment of in-vehicle wind noise performance and offer a theoretical basis and engineering references for noise, vibration, and harshness (NVH) optimization design during the early shape phase of vehicle development. Full article

The electrification of automobiles makes low-frequency road noise the main factor affecting the performance of automobile NVH (Noise, Vibration and Harshness). High-precision and high-efficiency road noise prediction results are the basis for NVH performance improvement and optimization. However, using the traditional TPA (transfer path analysis) method and CAE (Computer-Aided Engineering) method to analyze the road noise problem has the problems of complex transfer path, difficult acquisition of modeling parameters, long duration and high cost. Therefore, based on the road noise hierarchy constructed according to the road noise transmission path, the LSTM (Long Short-Term Memory) network is introduced to establish a data-driven prediction model, which effectively avoids the defects of the TPA method and CAE in analyzing road noise problems. Based on the LSTM prediction model, the AFW (adaptive feature weight) method is introduced to improve the model’s attention to the key features in the input data and finally improve the accuracy and robustness of the road noise prediction model. The results show that the accuracy (RMSE = 1.74 (dB)) and generalization ability (MAE = 2.60 (dB), $R^2$ = 0.924) of the AFW-LSTM model are better than other models. Full article

This paper evaluated the acoustic characteristics of electric vehicles (EVs) using both psychoacoustic and soundscape methodologies by analyzing three key psychoacoustic parameters: loudness, roughness, and sharpness. Through correlation analysis between perceived values and objective parameters, we identified specific sound sources requiring improvement, including vehicle body acoustics, wheel noise, and acceleration-related sounds. The relationship between comfort perception and acoustic parameters showed varying correlations: loudness (0.0411), roughness (2.3452), and sharpness (0.9821). Notably, the overall correlation coefficient of 0.5 suggests that psychoacoustic parameters alone cannot fully explain human comfort perception in EVs. The analysis of sound propagation revealed elevated vibration levels specifically in the driver’s seat area compared to other vehicle regions, identifying key targets for improvement. The research identified significant acoustic events at three key frequencies (50 Hz, 250 Hz, and 450 Hz), requiring in-depth analysis to determine their sources and understand their effects on the vehicle’s NVH characteristics. The study successfully validated its results by demonstrating that a combined approach using both psychoacoustic and soundscape parameters provides a more comprehensive understanding of passenger acoustic perception. This integrated methodology effectively identified specific areas needing acoustic refinement, including: frame vibration noise during rough road operation; tire-generated noise; and acceleration-related sound emissions. Full article

Energy management strategies (EMSs) are a core technology in hybrid electric vehicles (HEVs) and have a significant impact on their fuel economy. Optimal solutions for EMSs in the literature usually focus on improving fuel efficiency by operating the engine within a high efficiency range, without considering the drivability, which is affected by noise–vibration–harshness (NVH) constraints at low vehicle speeds. In this paper, a dual-mode combustion engine was implemented in a plug-in series hybrid electric vehiclethat could operate efficiently either at low loads in homogeneous charge compression ignition (HCCI) mode or at high loads in spark ignition (SI) mode. An equivalent consumption minimization strategy (ECMS) combined with a dual-loop particle swarm optimization (PSO) algorithm was designed to solve the optimal control problem. A MATLAB/Simulink simulation was performed using a well-calibrated model of the target HEV to validate the proposed method, and the results showed that it can achieve a reduction in fuel consumption of around 1.3% to 9.9%, depending on the driving cycle. In addition, the operating power of the battery can be significantly reduced, which benefits the health of the battery. Furthermore, the proposed ECMS-PSO is computationally efficient, which guarantees fast offline optimization and enables real-time applications. Full article

This study investigates the efficiency and noise, vibration, and harshness (NVH) characteristics of electric vehicle (EV) powertrains based on three key Pulse Width Modulation (PWM) techniques: Space Vector PWM (SVPWM), Discontinuous PWM (DPWM), and Random PWM (RPWM). The objective is to evaluate the impact of these PWM techniques on inverter and motor efficiency, as well as their effects on NVH performance, particularly in relation to noise and vibration. Experiments were conducted across various speed and torque levels using a motor dynamo. The study reveals that DPWM provides the highest efficiency, outperforming SVPWM by up to 2.23%. However, DPWM introduces more noise due to increased total harmonic distortion (THD), negatively affecting NVH performance. SVPWM, on the other hand, offers a balanced trade-off between efficiency and NVH, while RPWM demonstrates comparable noise characteristics to SVPWM, with potential for broader harmonic distribution. The findings suggest that each PWM technique offers distinct advantages, and their selection should depend on the required balance between efficiency and NVH. Full article

This paper focuses on the novel and unique training provision of acoustics relevant for noise, vibration, and harshness (NVH), focused on the ISO-362 standard highlighting important design aspects for electric vehicles. A case study of the practical implementation of off-site vehicle testing supporting an acoustics module is described, detailing a time-constrained test for automotive pass-by-noise and tyre-radiated noise with speed. Industrial test standards are discussed, with education as a primary motivation. The connections between low-cost, accessible equipment and future electric vehicle acoustics are made. The paper contains a full equipment breakdown to demonstrate the ability to link digital data transfer, analogue-to-digital communication, telemetry, and acquisition skills. The benchmark results of novel pass-by-noise and tyre testing are framed around discussion points for assessments. Inexpensive Arduino Uno boards provide data acquisition with class 1 sound pressure meters, XBee radios provide telemetry to a vehicle, and a vehicle datalogger provides GPS position with CANBUS data. Data acquisition is triggered through the implementation of light gate sensors on the test track, with the whole test lasting 90 minutes. Full article

Torque ripple and radial electromagnetic (EM) vibration can lead to motor vibration and noise, which are crucial to the motor’s NVH (Noise, Vibration, and Harshness) performance. Researchers focus on two main aspects: motor body design and control strategy, employing various methods to optimize the motor and reduce torque ripple and radial EM vibration. Rotor notching and segmented rotor skewing are frequently used techniques. However, determining the optimal notch and skew strategy has been an ongoing challenge for researchers. In this paper, an 8-pole, 36-slot ISG motor is optimized using a combination of Q-axis and magnetic bridge notching (QMC notch) as well as segmented rotor skewing to reduce torque ripple and radial EM vibration. Three skewing strategies—step skew (SS), V-shape skew (VS), and zigzag skew (ZS)—along with four segmentation cases are thoroughly considered. The results show that the QMC notch significantly reduces torque ripple, while skewing designs greatly diminish radial EM vibrations. However, at 14 $f_e$, the EM vibration frequency is close to the motor’s third-order natural frequency, leading to mixed results in vibration reduction using skewing techniques. After a comprehensive analysis of all skewing strategies, four-segment VS and ZS are recommended as the optimal approaches. Full article

The NVH (Noise, Vibration, and Harshness) characteristics of micro-motors used in vehicles directly affect the comfort of drivers and passengers. However, various factors influence the motor’s structural parameters, leading to uncertainties in its NVH performance. To improve the motor’s NVH characteristics, we propose a method for optimizing the structural parameters of automotive micro-motors under uncertain conditions. This method uses the motor’s maximum magnetic flux as a constraint and aims to reduce vibration at the commutation frequency. Firstly, we introduce the Pareto ellipsoid parameter method, which converts the uncertainty problem into a deterministic one, enabling the use of traditional optimization methods. To increase efficiency and reduce computational cost, we employed a data-driven method that uses the one-dimensional Inception module as the foundational model, replacing both numerical models and physical experiments. Simultaneously, the module’s underlying architecture was improved, increasing the surrogate model’s accuracy. Additionally, we propose an improved NSGA-III (Non-dominated Sorting Genetic Algorithm III) method that utilizes adaptive reference point updating, dividing the optimization process into exploration and refinement phases based on population matching error. Comparative experiments with traditional models demonstrate that this method enhances the overall quality of the solution set, effectively addresses parameter uncertainties in practical engineering scenarios, and significantly improves the vibration characteristics of the motor. Full article

This study examines the management of noise, vibration, and harshness (NVH) in electric vehicle (EV) powertrains, considering the challenges of the automotive industry’s transition to electric drivetrains. The growing popularity of electric vehicles brings new NVH challenges as the lack of internal combustion engine noise makes drivetrain noise more prominent. The key to managing NVH in electric vehicle powertrains is understanding the noise from electric motors, inverters, and gear systems. Noise from electric motors, mainly resulting from electromagnetic forces and high-frequency noise generated by inverters, significantly impacts overall NVH performance. This article details sources of mechanical noise and vibration, including gear defects in gear systems and shaft imbalances. The methods presented in the publication include simulation and modeling techniques that help identify and solve NVH difficulties. Tools like multi-body dynamics, the finite element method, and multi-domain simulation are crucial for understanding the dynamic behavior of complex systems. With the support of simulations, engineers can predict noise and vibration challenges and develop effective solutions during the design phase. This study emphasizes the importance of a system-level approach in NVH management, where the entire drivetrain is modeled and analyzed together, not just individual components. Full article

This paper describes the use of an electric drive as an acoustic actuator for active noise cancellation (ANC). In the presented application, the idea is to improve the noise, vibration, harshness (NVH) characteristics of passenger cars without using additional active or passive damper systems. Many of the already existing electric drives in cars are equipped with the required hardware components to generate noise and vibration, which can be used as compensation signals in an ANC application. To demonstrate the applicability of the idea, the electrical power steering (EPS) motor is stimulated with a control signal, generated by an adaptive feedforward controller, to reduce harmonic disturbances at the driver’s ears. As it turns out, the EPS system generates higher harmonics of the harmonic compensation signal due to nonlinearities in the acoustic transfer path using a harmonic excitation signal. The higher harmonics impair an improvement in the subjective hearing experience, although the airborne noise level of the harmonic disturbance signal can be clearly reduced at the driver’s ears. Therefore, two methods are presented to reduce the amplitude of the higher harmonics. The first method is to limit the filter weights of the algorithm to reduce the amplitude of the harmonic compensation signal. The filter amplitude limitation also leads to a lower amplitude of the higher harmonics, generated by the permanent magnet synchronous machine (PMSM). The second method uses a parallel structure of adaptive filters to actively reduce the amplitude of the higher harmonics. Finally, the effectiveness of the proposed ANC system is demonstrated in two real driving situations, where in one case a synthetic noise/vibration induced by a shaker on the front axle carrier is considered to be the disturbance, and in the other case, the disturbance is a harmonic vibration generated by the combustion engine. In both cases, the subjective hearing experience of the driver could be clearly improved using the EPS motor as ANC actuator. Full article

The sound insulation performance of an electric vehicle’s body system serves as a critical metric for evaluating the noise, vibration, and harshness (NVH) quality of the vehicle. The accurate and efficient prediction of sound insulation performance is foundational for undertaking noise reduction design and optimization. Current engineering practices predominantly rely on Computer-Aided Engineering (CAE) methodologies to address this challenge. However, inherent shortcomings such as low modeling efficiency and difficulty in ensuring prediction accuracy often characterize these approaches. In an effort to overcome these limitations, we propose a decomposition framework for predicting the sound insulation performance of the electric vehicle body system. This framework is established based on a comprehensive analysis of the noise transmission paths within the system. Subsequently, the support vector regression (SVR) method is introduced to construct a machine learning model specifically designed for predicting the sound insulation performance of the body system. This approach aims to mitigate the inherent weaknesses associated with the conventional CAE processes using a ‘data-driven’ paradigm. Furthermore, the Multiple Kernel Learning (MKL) method is used to enhance the processing efficacy of the SVR model. The proposed method is validated using practical application and testing on a specific electric vehicle. The results demonstrate commendable performance in terms of prediction accuracy and robustness. This research contributes to advancing the field by presenting a more effective and reliable approach to predicting the sound insulation performance of electric vehicle body systems, offering valuable insights for noise reduction strategies and optimization efforts in the automotive industry. Full article
