Search Results (156)

In recent years, unmanned aerial vehicles (UAVs) have increasingly become carrying platforms for Earth observation systems equipped with optical, microwave, and other types of sensors, primarily enabling high-resolution observations of above-ground targets. With the development of geophysical methods, bulky instruments originally designed for deep subsurface detection have been progressively miniaturized and made more lightweight, allowing their integration with civilian UAVs and opening new technological avenues for subsurface investigation. We have developed a semi-airborne transient electromagnetic system based on a UAV that is capable of simultaneously obtaining underground resistivity and polarization rate parameters. A survey was conducted over the M’sesa mining area in the Democratic Republic of the Congo. This is a mine pit that has been abandoned for over 50 years and has been flooded to form a lake, making it difficult to detect its deep mineralization potential using traditional ground-based methods. The results clearly delineate the spatial distribution of the Shangoluwe–M’sesa compressional fault and reveal a deep low-resistivity and high-chargeability zone, which provides clues for the exploration of deep deposits. This study will be of significant importance for accelerating the promotion and application of UAV-based semi-airborne electromagnetic exploration technologies. Full article

The safety and stability of underground coal mining are largely determined by the structural features of coal seams and surrounding rocks. Geological heterogeneities such as faults, fracture zones, and lithological variations strongly influence the distribution of rock pressure and the occurrence of geodynamic hazards. This highlights the need for reliable geophysical methods capable of identifying such zones under mining conditions. Electrical prospecting represents a promising diagnostic approach, as it is highly sensitive to changes in the physical properties of rocks. Unlike conventional geological mapping, it enables the detection of hidden structures and weakened zones often invisible to direct observation. Advances in instrumentation and data processing have further expanded the applicability of electrical methods in complex environments. This study introduces a methodology of electrical prospecting observations for the diagnosis of coal seams. The analysis focuses on conductivity anomalies that reflect tectonic disturbances, fracture systems, and lithological heterogeneities. Field investigations demonstrated the sensitivity of the method to local environmental variations. Comparison with geological records confirmed the validity of the approach: the identified anomalous zones correlated well with documented tectonic features. The methodology showed a stable performance and revealed potential for integration into mine monitoring systems. It allows the identification of areas associated with elevated rock pressure and possible geodynamic activity, thereby contributing to safer underground operations. In the longer term, electrical prospecting may be applied to other coal deposits, including those with a high gas content and complex structure. The development of automated interpretation tools and machine learning algorithms could further increase processing efficiency and improve predictive reliability. Overall, the results confirm that electrical prospecting in mining environments can become an effective instrument for enhancing safety and building more accurate geological–geophysical models of coal seams. Full article

Urban geophysical exploration faces significant hurdles due to strong electromagnetic interference and limited operational space, which restrict the efficiency and depth of traditional Electrical Resistivity Tomography (ERT). To overcome these limitations, this paper presents a novel ERT measurement and control system based on the Frequency Division Multiplexing (FDM) principle. Unlike conventional time-domain methods, this instrument synchronously transmits three independent AC signals at distinct frequencies. The acquisition station utilizes Fast Fourier Transform (FFT) to isolate specific frequency responses, enabling the simultaneous retrieval of apparent resistivity data for three different electrode spacings from a single transmission. The system architecture integrates low-power STM32 microcontrollers with an Android-based control terminal via Bluetooth, Wi-Fi, and NB-IoT technologies. This wireless design supports real-time current monitoring and cloud-based data synchronization. Experimental results demonstrate that the FDM operating mode significantly enhances data acquisition efficiency and anti-interference capability through frequency-domain separation. Controlled indoor and preliminary field tests indicate that FDM mode substantially improves acquisition efficiency through concurrent multi-channel measurement while effectively resolving target signals from noise. This study demonstrates the system’s technical feasibility and provides a practical foundation for future geophysical detection in time-constrained urban environments. Full article

In September 2021, significant changes in the geophysical and geochemical parameters on Vulcano Island were recorded by the surveillance network activities and periodic surveys. Between October 2021 and June 2024, additional surveys were conducted to acquire LIDAR, thermal, and RGB datasets for the generation of Digital Terrain Models (DTMs), orthophotos, and fumarole field maps. These data were collected using DJI Matrice 300 UAS platforms. Precision positioning was ensured through a POS/NAV RTK georeferencing approach. The instrumentation included Genius R-Fans-16 and DJI Zenmuse L1 laser scanners for structural mapping, alongside Zenmuse H20T infrared cameras for the thermal detection of potential instabilities on the volcano flanks, focused on the northern area and summit of Gran Cratere La Fossa, and these were subsequently repeated in May 2022, October 2022, October 2023, and June 2024. Additionally, 3D reconstruction targeted morphological variations in unstable areas like the cone top, Forgia Vecchia, and the 1988 landslide site. In May 2022, anomalous degassing in the Eastern Bay led to increased gas and hydrothermal fluid emissions, causing water whitening in front of Baia di Levante. Optical-thermal monitoring, both on land and at sea, detected multiple hydrothermal gas streams, aiding in assessing the magnitude and areal extension of fumarolic fields. These findings contribute to establishing a comprehensive monitoring approach for understanding the volcanic unrest evolution cost-effectively and safely. Full article

EMFIT, also referred to as EMFi, is a ferroelectret film related to polyvinylidene fluoride (PVDF) sensors. It is an electroactive polymer (EAP) based on a polyolefin structure and consists of three layers of polyester film. Its application in geophysical monitoring has not been reported in the literature. At present, EMFIT is mainly employed in ballistocardiography and medical sleep monitoring, as developed by the manufacturer Emfit Ltd. (Vaajakoski, Finland). Within the multidisciplinary monitoring network of the National Institute for Earth Physics (NIEP), EMFIT is used as a pressure sensor in combination with infrasound transducers and microphones deployed in seismic areas. The primary aim of this study is to evaluate its suitability for detecting seismic noise that precedes earthquakes, generated by rock fracturing associated with crustal deformation. Although similar studies have been reported, they have not involved the use of EMFIT sensors. The novelty of this approach lies in the large surface area and mechanical flexibility of the material. Beyond seismic forecasting, the research also examines whether this type of sensor can contribute to seismic monitoring as a complement to conventional instruments such as accelerometers, seismometers, and microbarometers. Data analysis relies primarily on spectral time-series methods and incorporates measurements from other acoustic sensors (microphones and microbarometers) as well as a weather station. The working hypothesis is the potential correlation between the recorded data and the presence of enhanced noise prior to the detection of seismic waves by standard seismic sensors. The target area for this investigation is Vrancea, specifically the Vrâncioaia seismic station, where multidisciplinary monitoring includes infrasound, radon, thoron, soil temperature, and atmospheric electrical discharges. Preliminary tests suggest that the EMFIT sensor may function as a highly sensitive device, effectively serving as an “ear” for detecting ground noise. Full article

The geophysical techniques ground penetrating radar (GPR) and electrical resistivity tomography (ERT) are commonly used data collection methodologies in numerous disciplines, including archaeology. Many researchers are now, or will be in the future, associated with projects that use these geophysical techniques, but who are not well versed in the instrumentation, its function, related terminology, data interpretation, and outcomes. This entry outlines the general approach and background for completing this type of research, dissects the methodology from a completed geoarchaeological project that uses both GPR and ERT, and provides concise definitions and explanations for all facets of the methodology. Based on this methodology, 21 terms or concepts related to GPR are explained in detail, as are 26 terms or concepts related to ERT, and visual representations of some of the terms and concepts are further illuminated via 11 figures. There are also 133 references linked to the various concepts and terms presented in this entry. Full article

Both studies and conservation of mountain waters are essential because of the primary role of mountains as “natural water towers” for the preservation and optimized exploitation of water reserves. In particular, under climate change stresses which induce reductions in rain and snow precipitation, especially in areas with rain-snow transition zones, increasing knowledge of the geological setting and hydrogeological context of mountain springs is pivotal for their preservation and optimized exploitation. However, the complexity and remoteness of mountain waters make them difficult to conceptualize and analyse, both observationally and instrumentally. In this context, using detailed geological mapping and hydrogeological surveys, geophysical data can provide useful information on the subsurface setting. Electrical resistivity tomography (ERT) surveys are utilized in this work for the investigation of the Montellina Spring (MS), which is located in the low Dora Baltea Valley and represents a significant drinking water source in the alpine context. Geophysical surveys, complemented by specific geological and hydrogeological observations, allowed a detailed reconstruction of the water circuit that supplies the spring along an articulated buried glacial valley and a loose bedrock in a DSGSD (deep-seated gravitational slope deformation) environment. The methodological approach also provides the basis for its successful application in similar geological contexts. Full article

Muon detection technology is an innovative type of geophysical exploration method that uses the penetrating ability of cosmic ray muons to detect and image the internal density structure of targets, offering the advantage of non-destructive detection. However, the applied research on muon detection technology is still in its initial stage, with research gaps existing in aspects such as the selection of optimal field observation parameters for muon detection instruments and muon inversion theory. To improve observation efficiency, this paper studies how to select optimal observation parameters in muon detection technology and proposes a method for selecting optimal observation parameters based on FreeCAD modeling and the energy attenuation formula of muon rays after penetrating matter. Additionally, a density-length product calculation method based on the muon survival rate formula is established, using the muon survival rate formula to reflect muon flux attenuation and thereby perform density inversion of objects. For the first time, muon imaging technology is applied to the detection of the No. 2 Mausoleum of the XiXia Imperial Tombs, verifying that muon imaging technology can effectively identify density anomalies inside the mausoleum tower, providing key data support for the structural analysis and protection of the XiXia Imperial Tombs. This paper systematically studies muon observation and inversion theories, laying a foundation for relevant researchers conducting muon detection work in the future. Full article

For mineral exploration, an increasing number of geophysical instruments have adopted unmanned aerial vehicles (UAVs) as their carrier platforms. The effective fusion of multi-modal geophysical information will be conducive to further enhancing the reliability of exploration results. However, the integration degree of UAVs and geophysical equipment is still low, and the advantages of UAVs as robots have not been fully exploited. In addition, the existing fusion methods are still difficult to use to establish the spatial distribution model of ore-bearing rock. Therefore, we reviewed the development status of UAVs and the geophysical instruments. We believe that only by integrating the system, designing the observation plan in accordance with the requirements of the fusion method, and treating the hardware part as an external extension of the algorithm, can high-matching data be provided for fusion. Subsequently, we analyzed the progress of the fusion methods, leading us to believe that the cross-dimensional and cross-abstract-level issues are major challenges in the algorithm aspect. Meanwhile, the fusion should be carried out simultaneously with the generation of the ore-bearing rock model, that is, to establish an integrated system of fusion and generation. It is hoped that this research can promote the development of UAV-borne multi-modal observation technology. Full article

To enhance the resolution of shallow geological structure detection, this study developed a Controlled-Source wide frequency range Magnetotelluric Detector (called CSUMT) with a frequency range spanning from 1 Hz to 1 MHz, and conducted systematic field experiments in Fengxian County, Shaanxi Province. The CSUMT system employs a high-precision 24-bit analog-to-digital converter and is compatible with both inductive magnetic sensors and superconducting quantum interference device (SQUID) magnetic sensors, featuring wide bandwidth and high dynamic range. Comparative experiments with the commercial V8 instrument demonstrated high consistency in electric field, magnetic field, and apparent resistivity measurements, confirming the CSUMT system’s reliability in field applications. In addition, this study compared the performance of inductive and SQUID magnetic sensors in actual surveys, revealing that SQUID sensors exhibit lower noise and more stable data output, making them suitable for signal detection across a broader frequency range. The results validate the practicality of the CSUMT system in complex geological environments and provide experimental support for the appropriate selection of magnetic sensors. Full article

Electrical and seismic exploration are two widely used geophysical methods in geological surveys. They reflect different geophysical properties of underground rocks, but each method can only provide information from a single perspective of the rock structure’s physical parameters. As a result, relying on a single geophysical method can lead to ambiguous interpretations. To address this issue, this paper presents the development of a multi-functional, high-power, multi-channel, rolling, fast measurement system for combined electrical and seismic exploration. The system features the following capabilities: it can be used simultaneously for both electrical and seismic exploration; it supports high-power operation, with a transmission power of up to 10 kW during electrical exploration; it includes multiple measurement channels for rolling measurement and data acquisition, with a sampling rate of up to 100 ksps, significantly improving work efficiency and expanding the frequency range. The distance between channels can be selected from 1 to 20 m, greatly enhancing the system’s adaptability to various environments. Additionally, we have designed accompanying upper-level software that not only stores data internally but also displays waveforms in real-time on a computer for monitoring and control. The experimental results demonstrate that the instrument operates stably and meets the requirements for field exploration. Full article

This article introduces a high-precision vertical pendulum tiltmeter with rapid deployment capability to improve the observation efficiency, practicality, and reliability of geophysical site tilt observation instruments. The system consists of a pendulum body, a triangular platform, a locking pendulum motor, a sealed cover, a ratio measurement bridge, a high-precision ADC, and an embedded data acquisition unit. The sensing unit adopts a vertical pendulum system suspended by a cross spring and a differential capacitance bridge measurement circuit, which can simultaneously measure two orthogonal directions of ground tilt. The pendulum is installed on a short baseline triangular platform, sealed as a whole with the platform, and equipped with a locking pendulum motor. When the pendulum is locked and packaged, it can withstand a 2 m free fall impact, with high reliability and easy use. It can be quickly deployed without the need for professional technicians. This article analyzes its various performance and technical indicators based on its application in the rapid deployment of the Zeketai seismic station in Xinjiang. It is of great significance for emergency response, mobile observation, base detection, anomaly verification, and other applications of ground tilt. Full article

Landslides present a significant global hazard, resulting in substantial socioeconomic losses and casualties each year. Traditional monitoring approaches, such as geodetic, geotechnical, and geophysical methods, have limitations in providing early warning capabilities due to their inability to detect precursory subsurface deformations. In contrast, the acoustic emission (AE) technique emerges as a promising alternative, capable of capturing the elastic wave signals generated by stress-induced deformation and micro-damage within soil and rock masses during the early stages of slope instability. This paper provides a comprehensive review of the fundamental principles, instrumentation, and field applications of the AE method for landslide monitoring and early warning. Comparative analyses demonstrate that AE outperforms conventional techniques, with laboratory studies establishing clear linear relationships between cumulative AE event rates and slope displacement velocities. These relationships have enabled the classification of stability conditions into “essentially stable”, “marginally stable”, “unstable”, and “rapidly deforming” categories with high accuracy. Field implementations using embedded waveguides have successfully monitored active landslides, with AE event rates linearly correlating with real-time displacement measurements. Furthermore, the integration of AE with other techniques, such as synthetic aperture radar (SAR) and pore pressure monitoring, has enhanced the comprehensive characterization of subsurface failure mechanisms. Despite the challenges posed by high attenuation in geological materials, ongoing advancements in sensor technologies, data acquisition systems, and signal processing techniques are addressing these limitations, paving the way for the widespread adoption of AE-based early warning systems. This review highlights the significant potential of the AE technique in revolutionizing landslide monitoring and forecasting capabilities to mitigate the devastating impacts of these natural disasters. Full article

A full-scale geophysical observatory in the North Caucasus, which was established to study volcanic activity in the Elbrus area, has been functioning for more than 10 years. Results of experimental studies performed at the observatory, located in the deep tunnel, are presented. Special attention is paid to the stability of metrologically significant parameters of precise information-measuring systems, taking into account different nature noises. Technical characteristics of installed geophysical instruments are given, and the principles of their operation are described. Examples of instrumental observations are also presented; for example, tidal deformations reflecting structural features of the geological environment in the area of the Elbrus volcanic edifice and associated with the presence of magmatic structures were investigated. It was shown that diurnal and semidiurnal harmonics observed in the microvariations of temperature can be caused, among other things, by the influence of tidal effects on the convective component of heat–mass transfer. Full article

As a type of widely used geophysical exploration equipment, artificial-source electromagnetic instruments are effectively used for resource and energy exploration due to their simple operation, deep-detecting depth, and higher resolution in the field, compared to natural-source electromagnetic instruments. However, after years of development, the current work is in a significant period. Due to the exploration requirement gradually shifting from shallow-surface to deep, traditional electromagnetic instruments are facing severe challenges. Over the course of the elaborate study by geophysicists in China, electromagnetic instruments have made innovative breakthroughs during recent years. The application in the deep exploration of artificial-source electromagnetic instruments has been further extended. By taking the time–frequency electromagnetic instrument, the low-temperature transient electromagnetic instrument, the surface electromagnetic prospecting instrument, and the wide-field electromagnetic instrument as examples, the purpose of this paper is to give a systematic introduction to the technical indicators and field applications. Then, an overview of the situation and progress of the instrument is given to help the readers understand the research directions. Finally, we offer the developing trends of the deep exploration artificial-source electromagnetic instrument. Full article
