Search Results (73)

The stability of the intermediate rock wall in the blasting construction of bifurcated small-spacing tunnels directly affects the construction safety of the tunnel structure. Clarifying the damage characteristics of the intermediate rock wall has significant engineering value for ensuring the safe and efficient construction of bifurcated tunnels. Based on the Tashan North Road Expressway Tunnel Project, this paper investigated the damage characteristics of the intermediate rock wall in bifurcated tunnels under different blasting construction schemes, using numerical simulation methods to account for the combined effects of in situ stress and blasting loads. The results were validated using comparisons with the measured damage depth of the surrounding rock in the ramp tunnels. The results indicate that the closer the location is to the starting point of the bifurcated tunnel, the thinner the intermediate rock wall and the more severe the damage to the surrounding rock. When the thickness of the intermediate rock wall exceeds 4.2 m, the damage zone does not penetrate through the wall. The damage to the intermediate rock wall exhibits an asymmetric “U”-shaped distribution, with greater damage on the side of the trailing tunnel at the section of the haunch and sidewall, while the opposite is true at the section of the springing. During each excavation step of the ramp and main-line tunnels, the damage to the intermediate rock wall is primarily induced by blasting loads. As construction progresses, the damage to the rock wall increases progressively under the combined effects of blasting loads and the excavation space effect. In the construction of bifurcated tunnels, the greater the distance between the headings of the leading and trailing tunnels is, the less damage will be inflicted on the intermediate rock wall. Constructing the tunnel with a larger cross-sectional area first will cause more damage to the intermediate rock wall. When the bench method is employed, an increase in the bench length leads to a reduction in the damage to the intermediate rock wall. The findings provide valuable insights for the selection of construction schemes and the protection of the intermediate rock wall when applying the bench method in the construction of bifurcated small-spacing tunnels. Full article

During the excavation of the underground cavern at the Baihetan hydropower station, significant time-dependent deformation of the surrounding rock was observed, posing a serious challenge to the long-term stability control of the caverns. In this study, numerical models of the layered excavation for typical monitoring sections in the main and auxiliary powerhouses on both banks of the Baihetan hydropower station were established using a viscoplastic damage model. The time-dependent deformation responses of the surrounding rock during the entire underground cavern excavation process were successfully simulated, and the deformation and failure mechanisms of the surrounding rock during layered excavation were analyzed in combination with field monitoring data. The results demonstrate that the maximum stress trajectories at the right-bank powerhouse under higher stress conditions exceeded those at the left-bank powerhouse by 6 MPa after the powerhouse excavation. A larger stress difference caused stress trajectories to move closer to the rock strength surface, therefore making creep failure more likely to occur in the right bank. Targeted reinforcement in high-disturbance zones of the right-bank powerhouse reduced the damage progression rate at borehole openings from 0.295 per month to 0.0015 per month, effectively suppressing abrupt deformations caused by cumulative damage. These findings provide a basis for optimizing the excavation design of deep underground caverns. Full article

Abrasive waterjet technology is a promising sustainable and green technology for cutting underground structures. Abrasive waterjet usage in demolition promotes sustainable and green construction practices by reduction of noise, dust, secondary waste, and disturbances to the surrounding infrastructure. In this study, a numerical framework based on a coupled Smoothed Particle Hydrodynamics (SPH)–Finite Element Method (FEM) algorithm incorporating the Riedel–Hiermaier–Thoma (RHT) constitutive model is proposed to investigate the damage mechanism of concrete subjected to abrasive waterjet. Numerical simulation results show a stratified damage observation in the concrete, consisting of a crushing zone (plastic damage), crack formation zone (plastic and brittle damage), and crack propagation zone (brittle damage). Furthermore, concrete undergoes plastic failure when the shear stress on an element exceeds 5 MPa. Brittle failure due to tensile stress occurs only when both the maximum principal stress (σ₁) and the minimum principal stress (σ₃) are greater than zero at the same time. The damage degree ($\chi$) of the concrete is observed to increase with jet diameter, concentration of abrasive particles, and velocity of jet. A series of orthogonal tests are performed to analyze the influence of velocity of jet, concentration of abrasive particles, and jet diameter on the damage degree and impact depth (h). The parametric numerical studies indicates that jet diameter has the most significant influence on damage degree, followed by abrasive concentration and jet velocity, respectively, whereas the primary determinant of impact depth is the abrasive concentration followed by jet velocity and jet diameter. Based on the parametric analysis, two optimized abrasive waterjet configurations are proposed: one tailored for rock fragmentation in tunnel boring machine (TBM) operations; and another for cutting reinforced concrete piles in shield tunneling applications. These configurations aim to enhance the efficiency and sustainability of excavation and tunneling processes through improved material removal performance and reduced mechanical wear. Full article

As open-pit mining extends to greater depths, slope stability is becoming a critical factor in ensuring safe production. This issue is particularly pronounced in geological settings with weak interlayers, where sudden slope failures are more likely to occur, demanding precise and reliable stability assessment methods. In this study, a typical open-pit slope with weak interlayers was investigated. Acoustic testing and ground-penetrating radar were employed to identify rock mass structural features and delineate loose zones, enabling detailed rock mass zoning and the development of numerical simulation models for stability analysis. The results indicate that (1) the slope exhibits poor overall integrity, dominated by blocky to fragmented structures with well-developed joints and significant weak interlayers, posing a severe threat to stability; (2) in the absence of support, the slope’s dissipated energy, displacement, and plastic zone volume all exceeded the failure threshold (Δ < 0), and the safety factor was only 0.962, indicating a near-failure state; after implementing support measures, the safety factor increased to 1.31, demonstrating a significant improvement in stability; (3) prior to excavation, the energy damage index (ds) in the 1195–1240 m platform zone reached 0.82, which dropped to 0.48 after reinforcement, confirming the effectiveness of support in reducing energy damage and enhancing slope stability; (4) field monitoring data of displacement and anchor rod forces further validated the stabilizing effect of the support system, providing strong assurance for safe mine operation. By integrating cusp catastrophe theory with energy-based analysis, this study establishes a comprehensive evaluation framework for slope stability under complex geological conditions, offering substantial practical value for deep open-pit mining projects. Full article

When deep-buried tunnels are excavated using the drill-and-blast method, the surrounding rock is subjected to combined cyclic blasting loads and excavation-induced stress unloading. Understanding the distribution characteristics of rock damage zones under these conditions is crucial for the design and safety of building-integrated underground structures. This study investigates the relationship between surrounding rock damage and in situ stress conditions through numerical simulation methods. A constitutive model suitable for simulating rock mass damage was developed and implemented in the LS-DYNA (version R12) code via a user-defined material model, with parameters determined using the Hoek–Brown failure criterion. A finite element model was established to analyze surrounding rock damage under cyclic blasting loads, and the model was validated using field data. Simulations were then carried out to explore the evolution of the damage zone under various stress conditions. The results show that with increasing hydrostatic pressure, the extent of the damage zone first decreases and then increases, with blasting-induced damage dominating under lower pressure and unloading-induced shear failure prevailing at higher pressure. When the hydrostatic pressure is less than 20 MPa, the surrounding rock stabilizes at a distance greater than 12.6 m from the tunnel face, whereas at hydrostatic pressures of 30 MPa and 40 MPa, this distance increases to 29.4 m. When the lateral pressure coefficient is low, tensile failure occurs mainly at the vault and floor, while shear failure dominates at the arch waist. As the lateral pressure coefficient increases, the failure mode at the vault shifts from tensile to shear. Additionally, when the horizontal stress perpendicular to the tunnel axis (σ_H) is less than the vertical stress (σ_v), variations in the axial horizontal stress (σ_h) have a significant effect on shear failure. Conversely, when σ_H exceeds σ_v, changes in σ_h have little impact on the extent of rock damage. Full article

When developing deep subsurface infrastructure in areas with intense geothermal activity, the significant temperature gradient inevitably leads to low-temperature contraction and high-temperature expansion of the rock body, resulting in changes in the rock’s mechanical properties. These thermodynamic effects can easily lead to the destabilization and subsequent collapse of the rock. There exists a pressing necessity to methodically evaluate the surrounding rock stability encountered in deep underground engineering under the action of thermal-solid coupling. This study constructed a multi-physical field coupling nonlinear calculation model based on a high-precision three-dimensional finite difference method, systematically analyzed the interdependent effects between the original rock temperature and excavation-induced disturbance, and then analyzed the dynamic changes in temperature, stress, and displacement fields along with plastic zone of surrounding rock of the deep underground engineering under thermal-solid coupling. The results indicate that the closer to the excavation contour surface, the lower the surrounding rock temperature, while the temperature gradient increased correspondingly. The farther away from the excavation contour face, the closer the temperature was to the original rock temperature. As the original rock temperature climbed from 30 °C to 90 °C, the increment of vault displacement was 2.45 times that of arch bottom displacement, and the influence of temperature change on vault deformation was more significant. The horizontal displacement magnitudes at the different original temperatures followed the following order: sidewall > spandrel > skewback, and at an original rock temperature of 90 °C, the sidewall horizontal displacement reached 15.31 cm. With the elevation of the original rock temperature, the distribution range and concentration degree of the maximum and minimum principal stresses increased obviously, and both were compression-dominated. The types of plastic zones in the surrounding rock were mainly characterized by shear stress-induced yielding and tensile stress-induced damage failure. When the original rock temperature increased to 90 °C, the rock mass extending up to 1.5 m from the excavation contour surface formed a large area of damage zone. The closer the working face was to the monitoring section, the faster the temperature dropped, and the displacement changed in the monitoring section. The findings offer a theoretical basis for engineering practice, and it is of great significance to ensure the safety of the project. Full article

This paper investigates the repeated disturbance of weakly cemented overburden rock caused by closely spaced coal seam mining, focusing on the effect of water infiltration on the strength degradation of weakly cemented mudstone. The study compares the fissure and fissure distribution characteristics of the overburden rock under seepage conditions. It also examines the dynamic evolution of seepage parameters during repeated mining and their impact on the overburden rock’s bearing capacity and structural stability. The findings are as follows: (1) After water infiltration, the clay mineral content in weakly cemented mudstone decreases, leading to a significant reduction in strength, increased microcrack development, and a moisture content increase from 0% to 3.27%. Uniaxial compressive strength decreases by 59.83%. (2) In the absence of seepage effects, the fissure development zone in the overburden rock changes from a positive trapezoidal shape to an inverted trapezoidal one, with a water-conducting channel forming first on the setup entry side. When seepage is considered, the fissure development in the weakly cemented overburden rock significantly increases, and the location of large-scale fissure initiation and expansion is advanced by 80 m. (3) During coal seam mining, excavation of the upper seam reduces the pore water pressure in the roof, causing the region of reduced pore pressure to shift from a trapezoidal to an “M” shape. As mining progresses to the lower seam, a seepage channel forms near the setup entry and expands. (4) Under repeated mining conditions, seepage field evolution in the overburden rock triggers the migration and transmission of formation water and pore pressure. The sustained influence of fissure water infiltration and seepage pressure accelerates the development of the water flowing fracture zone. As the overburden rock experiences renewed fracturing and caving, secondary fissure formation intensifies the movement of formation water. Consequently, the bearing capacity and water-resistance properties of the overburden rock are gradually degraded, significantly increasing the extent of structural damage within weakly cemented mining overburden rock. Full article

Damage to tunnel lining significantly influences the stability of tunnels during operation, particularly under conditions of extra-high ground stress. This article investigates the stability of tunnel linings subjected to extra-high ground stress, providing an in-depth analysis of crack damage modes. A time-varying reliability model based on the structural performance function is proposed, which incorporates the effects of the plastic zone and the identified crack damage modes. The plastic zone and the distribution of the surrounding rock stress field throughout the excavation process were simulated, elucidating the relationship between vault displacement and stress release rate. The time-varying reliability model is employed to assess lining behavior under extremely high ground stress and to establish the patterns governing its service life. The findings of this study offer a crucial reference for further investigations into the time-varying reliability of tunnel linings in the context of extreme ground stress. Full article

To reveal the influence of ultra-close coal seams mining on surrounding rock disturbance, PFC^2D is introduced to establish a simplified particle flow model of strata in the deeply buried mine, the damage and stress evolution characteristics of the surrounding rock were studied based on double coal seam mining. The results show that after the model excavation, the fracture length of the rock strata reached an accuracy of 97% compared with the theoretical calculation results, showing a good match with the theoretical calculations and the initial stress level obtained by the subsequent model monitoring is consistent with the measured value. The primary and secondary key layers are broken as a result of mining the higher coal seam, the siltstone interlayer is unaffected while the bottom coal seam is partially harmed, and there is noticeable extrusion damage between the rocks. Meanwhile, the damage to the rocks inside the gob is only becoming worse as a result of mining the lower coal seam. While the surrounding rock of the upper coal seam mining exhibits clear stress redistribution features in three zones, the lower coal seam mining creates a local and multi-point high-stress distribution. The siltstone interlayer’s stress variation is essentially identical to that of the surrounding rock. The extrusion state among rocks is related to the porosity of the shattered surrounding rock area. The siltstone interlayer is pressured during the upper coal seam mining, but it maintains its integrity, only collapsing during the lower coal seam mining. Though the siltstone interlayer can retain the necessary integrity of support before the lower coal seam mining, its internal stress is unstable which should be paid attention to when designing the support scheme during the mining period. Full article

To investigate the failure mechanisms of roadway-surrounding rock in the wind oxidation zone, where the rock experiences instability under cyclic excavation-induced loading and unloading, this study conducted experiments leveraging acoustic emission analysis, scanning electron microscopy, and a digital image correlation (DIC) system. The research focused on grouting reinforcement under varying gradation indices, examining its mechanical properties, deformation characteristics, and microscopic structure post-failure. Results show that as the gradation index increases, the peak strength of the grouted solid exhibits a non-linear trend, initially decreasing to a minimum of 9.40 MPa (a 40.4% drop) before rising again to a maximum of 15.76 MPa. The hysteresis loop observed follows a pattern of ‘sparse–dense–sparse’. Additionally, the acoustic emission cumulative ringing count demonstrates a three-stage pattern of ‘rising–active–quiet’, with a similar initial decrease followed by an increase correlated with the gradation index. Using digital image correlation (DIC) technology, the study revealed the crack development characteristics of the grouting reinforcement. Higher gradation indices lead to wider localization zones, more extensive crack propagation, and greater damage. Microstructural analysis showed that PVA enhances the formation of hydration products, fostering stronger adhesion between these products and the cement matrix. This leads to a denser and more uniform microstructure, thereby enhancing the macroscopic strength of the samples. It provides a basis for practical mining engineering applications of grouting reinforcement of roadways in wind oxidation zones. Full article

The growth of rock structural surfaces makes the deformation and stability analysis of rock pits more complex and challenging than that of soil pits. To investigate the damage mechanism of this foundation and provide ideas for foundation support, the paper constructed a simplified model by approximate plane analysis and dimensionless analysis of the similarity principle. The physical model was constructed from a mixture of materials, and then foundation excavation and loading tests were completed. The strain value of the strain gauges increased in stages in the range of 0–250. Excavation of the structural surface resulted in an increased number of deformation mutations. This type of rocky foundation damage underwent three stages: overburden crack development, cumulative deformation of the S-S, and collapse of the sliding body. Furthermore, numerical simulations corresponding to the physical model tests were set and used to validate and complement the physical tests. When the line loads reached 70.83 kN/m and 127.5 kN/m, the plastic zone of the structural surface was completely penetrated and the sliding body collapsed. The results of the studies can serve as a useful reference and guide for the excavation and support design of real-world rock foundation projects that are similar. Full article

When excavating tunnels and underground openings with the drill-and-blast method, minimizing excavation overbreak is vital, as it reduces the costs associated with excavation stability, mucking, and rock support. Overbreak in excavations not only causes safety concerns but also increases the cost of construction and completion time. This paper proposes a contour blasting design in which the parameters are optimized based on the rock’s structural properties. Numerical modeling was used to identify the possible damage zones of rock with a change of the seismic load due to blasting. The results were used as input for the design of the proposed contour blasting with a low-brisance explosive. Experimental blasting tests were conducted at the Akbakai mine, located in Kazakhstan, and the performance of the design was examined. The proposed contour blasting was compared with the standard blasting method. The results indicated that the cross-section of excavation with the conventional blasting method varied between 10.5 and 12.1 m², indicating an overbreak between 17 and 34%. However, with the suggested contour blasting, the overbreak was less than 13%. It was concluded that charging contour boreholes with low-brisance explosives is an effective method of reducing overbreak due to excessive explosive loads on the contour massif, which can improve the safety and profitability of mining operations. Full article

The application of blasting in modern engineering construction is prized for its speed, efficiency, and cost-effectiveness. However, the resultant vibrations can have significant adverse effects on surrounding buildings and residents. The challenge of optimizing blasting procedures to satisfy excavation needs while minimizing vibration impacts is a critical concern in blasting excavation. This research addresses this challenge through the development of a 3D simulation and analysis model for an underground pumped storage power plant in East China, utilizing the LS-DYNA finite element analysis software. To explore the influence of charging structures on rock fragmentation and vibration propagation, three distinct blasting programs were formulated, each featuring varied configurations within the machinery room. The analysis revealed that the adoption of an optimized charging structure can significantly decrease damage to the protective layer by approximately 40%, while also reducing the impact on the upstream and downstream side walls by 27.25% and 12.03%, respectively, without compromising the efficacy of the main blast zone. Moreover, the vibration velocities at the remote measurement point were found to be reduced across multiple directions, indicating effective control of the vibration effects. The post-implementation of the optimized blasting strategy at the site, the assessment of the retained surrounding rock integrity, and the impact on protected structures demonstrated that the proposed solution met satisfactory outcomes. This study underscores the potential of simulation-based optimization in managing vibration risks during blasting operations, offering a valuable tool for engineers and practitioners in the field of underground construction. Full article

The bedding structure of layered tunnels has a significant impact on the evolution of excavation damage, yet research on the relevant evolution mechanisms is scarce. In view of this, this paper develops a mesh-free numerical method to simulate the progressive damage process of tunnel excavation and proposes a method for applying stress boundaries within the SPH framework. Through this method, simulations of tunnel excavation damage under different bedding dip angles and stress ratios are conducted. The results show that the following: in the simulation of excavation damage of a tunnel without bedding structures, specific areas around the tunnel exhibit characteristics of tensile–shear composite failure and shear failure, verifying the rationality of the algorithm; under different bedding dip angles, a damage zone is first generated around the tunnel, and shear cracks appear at the tangent of the bedding plane and the tunnel, with the damage degree being the largest when α = 30° and the smallest when α = 45°; and under different stress ratios, the damage starts around the tunnel, continuously evolves, and finally forms a failure zone inside the bedding plane joints tangent to the tunnel, and the damage degree increases with the increase in the stress ratio. This study discusses the damage mechanisms under different calculation schemes and provides a reference for understanding the excavation damage mechanisms of layered tunnels. Full article

Coastal underground engineering projects are prone to seawater intrusion during blasting operations, posing significant risks to the safety of construction personnel and the structural integrity of the projects. To ensure the safety of blasting operations in areas at risk of seawater intrusion, this study focuses on a section of a coastal tunnel that is at risk of such intrusion. Using fracture mechanics theory and silo theory analysis methods, the minimum safe distance between the workface and the fault to prevent seawater intrusion is determined. Numerical simulations are employed to analyze the dynamic response of the surrounding rock and the attenuation of vibrations as blasting excavation progresses near the fault-controlled zone. This study also explores the impact of dynamic excavation on fault stability. By employing a regression analysis, this study establishes quantitative relationships between the amount of explosive used and the peak particle velocity (PPV) at different distances, as well as between the range of rock damage and PPV at various distances. This analysis allows for the determination of a safe PPV threshold to prevent seawater intrusion in the fault-controlled area. The accuracy of the computational model is validated using field-measured data. Finally, an optimized blasting design and strategy based on electronic detonator initiation are proposed for the control area, ensuring construction safety. This study provides theoretical and technical references for achieving safe and efficient blasting excavation in coastal underground engineering projects. Full article
