Electric motors play a decisive role in electric vehicles by converting electrical energy into mechanical motion across various drivetrain components. However, failures in these motors can interrupt the motor function, with approximately 40% of these failures stemming from bearing issues. Key contributors to bearing degradation include shaft voltage, bearing current, and electric discharge material spalling current, especially in motors powered by inverters or variable frequency drives. This review explores the tribological and vibrational aspects of bearing currents, analyzing their mechanisms and influence on electric motor performance. It addresses the challenges faced by electric vehicles, such as high-speed operation, elevated temperatures, electrical conductivity, and energy efficiency. This study investigates the origins of bearing currents, damage linked to shaft voltage and electric discharge material spalling current, and the effects of lubricant properties on bearing functionality. Moreover, it covers various methods for measuring shaft voltage and bearing current, as well as strategies to alleviate the adverse impacts of bearing currents. This comprehensive analysis aims to shed light on the detrimental effects of bearing currents on the performance and lifespan of electric motors in electric vehicles, emphasizing the importance of tribological considerations for reliable operation and durability. The aim of this study is to address the engineering problem of bearing failure in inverter-fed EV motors by integrating electrical, tribological, and lubrication perspectives. The novelty lies in proposing a conceptual link between lubricant breakdown and damage morphology to guide mitigation strategies. The study tasks include literature review, analysis of bearing current mechanisms and diagnostics, and identification of technological trends. The findings provide insights into lubricant properties and diagnostic approaches that can support industrial solutions. Full article

In recent years, the rapid spread of electric vehicles (EVs) has intensified the competition to develop power units for EVs. In particular, improving the driving range of EVs has become a major topic, and in order to achieve this, many studies have been conducted on improving the efficiency of EV power units. In this study, we propose a multiple-inverter-drive permanent magnet synchronous motor based on an 8-pole, 48-slot structure, which is commonly used as an EV motor. The proposed motor is composed of two completely independent parallel inverters and windings, and intermittent operation is possible; that is, only one inverter and one parallel winding is used depending on the situation. In the proposed motor, we compare losses including stator iron loss, rotor iron loss, and magnet eddy current loss by PWM voltage inputs for some stator winding topologies, we show that the one-side winding arrangement is the most efficient during intermittent operation, and that it is more efficient than normal operation especially in the low-speed, low-torque range. Finally, through a vehicle-driving simulation considering the efficiency map including motor loss and inverter loss, we show that the intentional use of intermittent operation can improve electrical energy consumption. Full article

This paper presents a simulation framework for evaluating power flow, energy efficiency, thermal behavior, and energy consumption in electric vehicles (EVs) under standardized driving conditions. A detailed Simulink model is developed, integrating a lithium-ion battery, inverter, permanent magnet synchronous motor (PMSM), gearbox, and a field-oriented control strategy with PI-based speed and current regulation. The framework is applied to four standard driving cycles—UDDS, HWFET, WLTP, and NEDC—to assess system performance under varied load conditions. The UDDS cycle imposes the highest thermal loads, with temperature rises of 76.5 °C (motor) and 52.0 °C (inverter). The HWFET cycle yields the highest energy efficiency, with PMSM efficiency reaching 92% and minimal SOC depletion (15%) due to its steady-speed profile. The WLTP cycle shows wide power fluctuations (−30–19.3 kW), and a motor temperature rise of 73.6 °C. The NEDC results indicate a thermal increase of 75.1 °C. Model results show good agreement with published benchmarks, with deviations generally below 5%, validating the framework’s accuracy. These findings underscore the importance of cycle-sensitive analysis in optimizing energy use and thermal management in EV powertrain design. Full article

This research presents a method for improving the regenerative efficiency of interior permanent magnet synchronous motors (IPMSMs) used in traction applications such as electric vehicles. In conventional powertrain control, the maximum torque per ampere (MTPA) strategy is commonly applied in the constant-torque region. However, this approach does not account for the combined losses of both the motor and inverter. In this study, overall system efficiency is investigated, and an improved current combination is proposed to minimize total losses. The single switching method is employed in the inverter due to its simplicity and its ability to reduce inverter losses. Simulations incorporating both motor and inverter losses were performed for two driving conditions around the MTPA current point. The results show that the optimal current combination slightly deviates from the MTPA point and leads to a slight improvement in efficiency. Experimental results under the two steady-state driving torque and angular velocity conditions confirm that the optimized current combination enhances system efficiency. Furthermore, simulations based on the Urban Dynamometer Driving Schedule predict an increase in recovered energy of approximately 1%. The proposed control strategy is simple, easy to implement, and enables the powertrain to operate with highly efficient current references. Full article

Brushless DC motors are often used as traction motors in electric vehicles due to their high power density and efficiency. The dc-link electrolytic capacitor is the most vulnerable part of the brushless DC motor drive system, and it determines the reliability of the motor drive system. Therefore, it is of great importance to monitor the life of the dc-link electrolytic capacitor in the drive system. To carry out the lifetime monitoring of capacitors, a dc-link series switch circuit composed of diodes and power switching devices is introduced to calculate the capacitance value. The lifetime of the capacitor is then monitored in real time through this capacitance value. During normal steady-state operation of the motor, the control strategy of the inverter is switched. When the dc-link switch is turned off, the charging vector is used to charge the dc-link capacitor. Due to the presence of the diode and the dc-link switch, the energy charged to the dc-link by the motor can only flow into the capacitor and cannot be released immediately. Therefore, the capacitance value is calculated through the change in capacitor voltage and the capacitor current reconstructed from the three-phase currents of the motor. The feasibility of the method proposed in this paper is experimentally verified by building a brushless DC motor system. Full article

This paper presents a Space Vector Modulation (SVM) method with a novel zero vector distribution system for electrical vehicle drives with a six-phase induction motor working under the Direct Field-Oriented Control (DFOC) method. Different SVM methods are described and compared, and a new approach with long vectors only and a special zero vector distribution, that compensates for the third harmonic component is proposed. The DFOC method is described and the influence of the applied modulation method on six-phase motor currents is shown. Results of our experimental studies on the DFOC method are presented and discussed. The proposed modulation method for a six-phase Voltage Source Inverter can be applied in fault-tolerant electrical vehicles. Full article

Integrating the electric motor with a multi-speed transmission is an effective way to improve the efficiency and performance of battery electric vehicles (BEVs). This paper innovatively proposes a design method for matching a single-motor and dual-speed dual-clutch transmission (2-Speed Wet DCT) powertrain system and constructs a variable speed efficiency model (VSEM) and constant speed efficiency model (CSEM) for the inverter, motor, and transmission. Research shows that the design parameters of the motor and transmission significantly affect the optimal powertrain system. This study uses an enhanced NSGA-II multi-objective genetic algorithm to optimize the driving performance of energy efficiency and powertrain cost under two different acceleration times (10 s and 12 s), with the key parameters of the motor and transmission as optimization variables and dynamic indicators as constraints, and compares VSEM and CSEM. The optimization results indicate that VSEM have better energy-saving effects than CSEM, with the energy consumption reduced by 3.7% and 3.3% under the two driving performances, respectively. The Pareto frontier further confirms that, for multi-speed transmission systems in electric vehicles, matching a high-power, high-torque motor with a smaller transmission ratio powertrain can achieve higher energy efficiency and thus longer driving range. Additionally, this study quantifies the correlation between energy efficiency and powertrain cost using grey relational analysis (GRA), with a result of 0.77431. Full article

This paper introduces a loss-minimizing Model Predictive Control (MPC) strategy for induction motors in electric vehicle applications designed to track a specified speed reference. The proposed control incorporates three key features that enhance efficiency and minimize losses. Firstly, an inverter selection vector strategy minimizes electromagnetic torque ripple, additional inverter switching frequency, and computational cost. Secondly, every element in the proposed control is based on the induction motor model, including consideration for iron losses. Thirdly, the MPC stator flux reference is optimized for total electric loss minimization, given any electromagnetic torque and mechanical speed reference, with no additional computational cost. The loss-minimizing function is derived from the induction motor model and accounts for all motor losses, including iron losses. Its straightforward implementation and pre-computed algebraic form ensure easy integration into various systems while reducing real-time computational overhead. The proposed control is tested and compared to a classical MPC through dynamic case studies, demonstrating satisfactory results in reducing total electric losses and electromagnetic torque ripple. During testing for electric vehicle applications within relevant standardized urban driving cycles, the proposed control showcases excellent energy efficiency results, reducing total electric losses by 49% compared with classical MPC. Full article

Electromagnetic interference (EMI) is a key problem in the design of electric vehicle motor drive systems. Based on the system composition and conducted EMI mechanism, an equivalent circuit model including a motor, inverter, cable, and battery is established, and an optimized double closed-loop control strategy is proposed. Through the joint simulation platform of Simulink and Simplorer, the conduction EMI prediction model of a motor drive system is constructed. On this basis, a filter design method based on Π-type topology is proposed based on the 6 dB safety margin of reducing the interference limit. The simulation results show that the designed filter significantly suppresses the conducted EMI in the frequency band from 150 kHz to 30 MHz, and the interference peak is reduced by approximately 40 dBμV. The effectiveness of the model and filter is verified by experimental tests, and the electromagnetic compatibility (EMC) performance of the system is improved, which provides theoretical support and an engineering reference for the high-frequency interference suppression of the motor drive system. Full article

In this paper, a variable gear ratio for active steering systems with a double planetary gear configuration is presented to optimize the steering performance of commercial vehicles. First, a variable transmission ratio system with a dual-row planetary gear mechanism is developed in ADAMS/Car, where the steering mechanism’s transmission ratio can be adjusted according to different driving conditions, thereby improving the vehicle’s stability and sensitivity. Second, a new type of dual-inverter permanent magnet synchronous motor (DPMSM) has been designed to solve the power limitation problem in the electric drive steering of commercial vehicles. Finally, the step steering and lane change driving scenarios are chosen for co-simulation using ADAMS/Car and MATLAB to evaluate the proposed method’s effectiveness. The co-simulation results show that the proposed variable transmission ratio and control strategy can effectively improve the steering sensitivity and stability of commercial vehicles. Full article

In a converter of actual working condition, the change in the current and voltage of the power device will cause the junction temperature to fluctuate greatly. This device is subjected to high thermal stress due to the change in the junction temperature. Therefore, it is necessary to adopt junction temperature control to reduce or smooth the junction temperature fluctuation, so as to realize the junction temperature control and improve the reliability of the device. At present, the methods for the junction temperature control of power devices have certain limitations and there are few active thermal management methods proposed for SiC device characteristics. In this paper, a method for realizing the smooth control of the junction temperature of a SiC device based on the conduction loss adjustment of the body diode for the SiC device has been proposed, considering that the conduction loss of the body diode is greater than the conduction loss of the SiC MOSFET. The conduction time of SiC MOSFET body diode was adjusted. By adjusting the conduction loss of the SiC MOSFET device, the fluctuation range of the junction temperature of the SiC MOSFET device was controlled, the smooth control of the junction temperature of the SiC device was realized, and the thermal stress of the device was reduced. Full article

Electric Vehicles (EVs) are set to play a crucial role in the energy transition. Although EVs offer significant environmental benefits, their technology still faces major challenges related to performance optimization, energy efficiency improvement, and cost reduction. A key point to address these challenges is the accurate identification of the speed/torque operating points of the drive systems. However, this identification is generally achieved using mechanical sensors, which are fragile, bulky, and expensive. This paper aims to develop, implement, and validate a speed/torque observer in real time based on the Extended Kalman Filter (EKF) approach for an EV equipped with an Open-End Winding Induction Motor with Dual Inverter (OEWIM-DI). The implementation of the EKF is based on the state modeling of the OEWIM-DI, enabling the observation of the torque and speed using voltage and current measurements. The validation of this approach is conducted experimentally on the FPGA and DS1104 boards. The results show that this approach offers excellent performance in terms of accuracy, stability, and real-time response speed. These results suggest that the proposed method could significantly contribute to the advancement of EV technology by providing a more robust and cost-effective alternative to traditional mechanical sensors while improving the overall efficiency and performance of EV drive systems. Full article

This paper presents a novel driving torque control strategy for the front and rear independently driven electric vehicle (FRIDEV) to reduce energy consumption and enhance vehicle stability. The strategy is built on a comprehensive vehicle model that integrates vertical load transfer, tire slip dynamics, and an electric system model that accounts for losses in induction motors (IMs), permanent magnet synchronous motors (PMSMs), inverters, and batteries. The torque control problem is framed with a nonlinear model predictive control (MPC) method, utilizing state-space equations as representations of vehicle dynamics. The optimization targets adjust in real-time based on road traction conditions, with the slip rate of front and rear wheels determining the torque control strategy. Active slip control is applied when slip rates exceed critical thresholds, while under normal conditions, torque distribution is optimized to minimize energy losses. To enable online real-time implementation, an improved sparrow search algorithm (SSA) is designed. Simulations in MATLAB/Simulink confirm that the proposed online strategy reduces energy consumption by 2.3% under the China light-duty vehicle test cycle-passenger cars (CLTC-P) compared to a rule-based strategy. Under low-adhesion conditions, the proposed online strategy effectively manages slip ratios, ensuring stability and performance. Improved SSA also enhances computational efficiency by approximately 44%–52%, making the online strategy viable for real-time applications. Full article

The motor characteristics control method using the winding changeover technique can improve the matching ratio between the most frequent operating point of electric vehicle (EV) and the motor’s high-efficiency operating point, thereby enhancing the overall average efficiency of the drive system. This technology reduces back electromotive force and winding resistance by adjusting the effective number of motor winding turns according to the EV’s operating speed, ultimately improving the average efficiency. In this paper, we propose a winding changeover circuit and control method that maximizes the average efficiency in the main driving regions to extend the driving range per charge and improve the fuel efficiency of EVs. The proposed circuit is constructed using thyristor switching devices, offering the advantage of relatively lower overall system losses compared to conventional circuits. Due to the characteristics of the thyristor switching devices used in the proposed circuit, seamless winding changeover is possible during motor operation. Additionally, no extra snubber circuits are required, and the relatively low switch losses suggest the potential for improved efficiency and lightweight design in EV drive systems. To verify the proposed winding changeover circuit and control scheme, experiments were conducted using a dynamometer with an 80 kW permanent magnet motor, inverter, and the developed prototype of the winding changeover circuit. Full article

The fuel economy of electric vehicles (EVs) is an important factor in determining the competitiveness of EVs. Since the fuel economy is affected by the efficiency of an e-powertrain composed of a motor and inverter, it is necessary to select a high-efficiency topology for the e-powertrain. In this paper, a novel topology of e-powertrains to improve the fuel economy of EVs is proposed. The proposed topology aims to improve the system efficiency by integrating open-end winding (OEW) and winding changeover (WC). The proposed OEW-PMSM with WC enables to drive a permanent magnet synchronous motor (PMSM) in four different modes. Each mode can increase inverter efficiency and motor efficiency by changing motor parameters and maximum modulation index. In this paper, the system efficiency of the proposed topology was evaluated using electromagnetic finite element analysis and a loss model of power semiconductors. In addition, the vehicle simulations were performed to evaluate the fuel economy of the proposed topology, thereby proving the superiority of the proposed topology compared with the conventional PMSM. Full article
