Friction dampers based on the effects of dry friction are attractive to engineers because of their simple design, low manufacturing and maintenance costs, and high efficiency under heavy loads. This study proposes a new damper design based on an open shell with a deformable filler, with the shell cut along a cylindrical helical line. The key idea in developing the design was to use the bending effect of the shell in contact with the weakly compressible filler. Another idea was to use the frictional interaction between the filler and the open shell to obtain the required damping characteristics. The working hypothesis of this study was that, ceteris paribus, a change in the configuration of the shell cut would cause a change in the stiffness of the structure. To analyse the performance characteristics of the proposed damper and test the hypothesis put forward, a numerical model of the shell damper was built, and a boundary value problem was formulated and solved for the frictional interaction between the shell cut along the helical line and the weakly compressible filler, taking into account the dry friction forces between them. As a result, the strength, stiffness, and damping properties of the developed damper were investigated, and a comparative analysis of the new design with the prototype was carried out. It is predicted that the proposed friction damper will be used in the energy and construction industries, in particular in drilling shock absorbers for the oil and geothermal industries, as well as in earthquake-resistant structures. Full article

The vibration of turbine blades during the operation of jet engines is a serious and complex issue that has garnered significant attention. In practical jet engines, dry friction damping is commonly used to suppress blade vibrations due to its reliability and efficiency. The equivalent damping ratio of dry friction dampers is a crucial metric for evaluating their performance. However, calculating dry friction dampers’ damping ratio for actual structures involves nonlinear vibration calculations, which are challenging and often lack precision. A method combining simulation and experimentation to calculate the equivalent damping ratio of a structure is proposed. In a laboratory setting, the vibration response of turbine blades under centrifugal load and the damping effect of under-platform dampers were analyzed using oil excitation. The research results indicate that this method can effectively calculate the equivalent damping ratio of actual structures. The findings provide robust support for the design of under-platform dampers and the vibration analysis of turbine blades. Full article

To confirm the variation in damping ratio offered by dry friction dampers against structural vibration stress, this study developed a blade vibration response test system for capturing damping characteristic curves through both frequency sweep excitation and damping-freevibration methods. The damping-free vibration method demonstrates high efficiency, allowing for the acquisition of a complete damping ratio characteristic curve in a single experiment. Experimental findings indicate that the two contact surfaces on the triangular prism damper produce distinct damping effects, closely aligning with the predicted damping characteristic curves. The peak damping ratio was found to be independent of the centrifugal load of the damper; dampers with varying contact areas produce approximately similar damping characteristics; and the damping effect shows a positive correlation with the root extension length. Full article

One test rig comprising two blades and dual under-platform dampers (UPDs) was built to enhance the understanding of the dynamic response behavior of blades with dual UPDs. A turnbuckle was applied to enable the smooth and uninterrupted linear adjustment of the normal load on the dual UPDs. Non-contact vibration-response measurements were achieved through eddy-current displacement sensors. Contact excitation was employed using an electromagnetic exciter to determine the magnitude of the excitation load, which was measured using a force sensor mounted on the excitation rod. A feedback system was established to maintain a constant magnitude of the excitation force throughout the excitation process. The chosen experimental variables include the normal load, the amplitude of the excitation force, the effective contact area, and the position of the damper action. The frequency response function of the blade under various experimental parameters was obtained through frequency sweeping under sinusoidal excitation. The influence of each parameter on the dynamic characteristics of blades was studied. The results demonstrate that the double-layer damping system offers distinct advantages over its single-layer counterpart. The upper damping has a wider frequency-adjustment range and a lower resonance amplitude and takes a larger share of the damping efficiency. Full article

Underplatform dampers (UPDs), a type of dry friction damper, are commonly used for vibration reduction of turbine blades. This study investigated the effect of UPDs on the forced torsional vibration response of turbine blades within a multi-blade system. Pre-stressed finite element modal analysis and the harmonic balance method were combined to calculate the forced torsional vibration responses of a system with and without UPDs. The experiments were then carried out on a rotating multi-blade system with and without UPDs, with a focus on the effect of mass stacking on damping performance. The results showed that the installation of underplatform dampers could increase the frequency corresponding to the maximum response of the blade torsional vibration and cause multiple peaks that varied in the vibration response based on the mass of the UPDs. With an appropriate normal force, the underplatform dampers could effectively reduce the blade torsional vibration by 68.9%. However, excessive normal force of UPDs could lead to multiple large vibration peaks, which should be avoided in engineering practice. Additionally, the numerical results for the forced torsional vibration response of the rotating multi-blade system with UPDs were relatively close to the experimental results, indicating that the calculation method could be effectively applied to the nonlinear prediction of forced vibrations of rotating blades with dampers. Full article

The results of a study of the contact interaction of an open shell and a chrome-plated shaft with elastomeric filler installed coaxially are presented. The considered contact system is a model of the original design of the shell damper of dry friction. The design feature is the following: the bearing link of the damper is a thin-walled cylindrical shell with a cut along the generatrix; the working body of the damper is elastomeric filler; a hollow chrome-plated shaft centers the damper elements and allows it to be used in technological processes with the presence of aggressive and abrasive-containing media. The mechanical-mathematical modeling of the behavior of the presented damper under the conditions of operational loads has been carried out. The idea of identifying the properties of a cut isotropic shell, which bends under the conditions of a nonaxisymmetric contact load, and a strongly orthotropic continuous shell is applied. As a result, dependences were obtained to determine the rigidity and the maximum allowable load of the damper. The effect of the coefficient of friction of the contact pairs elastomer-shell and elastomer-shaft on the damper performance properties has been studied. A technique for the quasi-static analysis of structural damping in non-mobile, non-conservative shell systems with deforming filler has been developed. The hysteresis loops of the damper under a nonmonotonic load are constructed, the dependence of the amount of dissipated energy on the cycle asymmetry coefficient is found. An analysis of the results obtained showed that the use of open shells in friction shock absorbers can significantly reduce their rigidity compared to solid shells and thereby reduce the resonant frequencies of the dynamic system. This circumstance makes such vibration isolators particularly attractive for use in superresonance vibrators as working modules of drilling shock absorbers and elastic hangers of sucker rods in oil and gas production. Full article

The elastohydrodynamic lubrication (EHL) oil film between contact interfaces acts as a spring or damper to reduce wear and vibration for frictional pairs. To analyze the dynamic behaviors of friction pairs in mechanical systems both effectively and accurately, the stiffness and damping parameters under EHL contact states are essential. The presented work develops a numerical model to investigate the EHL stiffness and damping characteristics based on the transient EHL system and elastic contact theory of line contact, in which the stiffness force is separated according to the relationship with approach distance of the contact body established in the steady process, and then the damping can be obtained. The results show that the stiffness force plays an increasingly important role over the applied load conditions while the damping effects is gradually weakened. EHL stiffness is obviously smaller than dry contact stiffness, but the discrepancy is decreasing with the increasing load. Moreover, the higher entrainment velocity, lubricant viscosity and larger curvature radii leads to smaller stiffness and damping. The elastic modulus generates little effect on dynamic characteristics when the load is light while dominates the maximum level of the contact stiffness. Full article

The purpose of this work is to explore the nonlinear vibration of a rub-impact Jeffcott rotor. In the first stage, the motion is not affected by the friction force, but in the second stage, the motion is influenced by the normal force and the friction force. The governing equations of the rotor of this model are derived in this paper. In consequence, there appears a difference between the two stages. We establish an approximate analytical solution for nonlinear vibrations corresponding to two stages with the mention of the location of jumps. The obtained results are compared with the numerical integration results. The steady-state response and the stability of the solutions are analytically determined for the two stages. The stability of a full annular rub solution is studied with the help of the Routh–Hurwitz criterion. Effects of different parameters of the system, the saddle-node bifurcation (turning points) and the Hopf bifurcation are presented. The main contribution lies in the analytical approximation solution based on the Optimal Auxiliary Functions Method. Full article

Friction dampers are widely used in structural vibration suppression in various fields, such as aeronautics, astronautics, robotics, precision manufacturing, etc. Traditional friction dampers are mainly used in a passive way to optimize vibration suppression with an immutable pressure around certain excitation. In this manuscript, a hybrid control strategy by considering both the friction force in the active control law and a nonlinear velocity compensation force is put forward: First, the normal force applied on the friction damper was adjusted to ensure its vibration reduction effect under different excitation for a first passive control; second, the active control law was established by combining the dry friction force and the velocity control force in the state space; lastly, the stability of the nonlinear control law was determined by Lyapunov criterion. Numerical simulations were conducted on a three degree-of-freedom system (3-DOF) based on the proposed hybrid control strategy, to show the control efficiency in vibration suppression and economic efficiency in energy input into the system. Simulation results showed that the proposed control law could reduce the amplitude of the active control force by about 5% without degrading the control efficiency. Full article

The blisks and labyrinth seals in gas turbine engines are typical rotating periodic structures. Vibration problems will inevitably occur during the operation, which can easily lead to High Cycle Fatigue failure of the structure. Adding ring damper is an effective means of structural vibration reduction. The damper uses the dry friction of the contact surface to dissipate the vibration energy, improve the damping of the system, and then reduce the vibration response of the structure. The structures have a nodal diameter and modal shape, and the forced vibration often presents the characteristics of traveling wave. In this paper, an evaluation method for dry friction damping of ring damper under the axial component of traveling wave vibration is established. For the given vibration stress at the critical location, the equivalent damping ratio provided by the ring damper is calculated based on the friction energy dissipation and the damping characteristic curve that is the equivalent damping ratio varying with the vibration stress is obtained. This method can avoid calculating the nonlinear dry friction forced response and is suitable for the design stage. The damping of split ring dampers with rectangular section for one blisk and labyrinth seal is analyzed in this paper. It is shown that rotating speed, friction coefficient, section area and material density significantly influence the damping characteristics. There are many factors affecting the damping characteristics of the damping, so it is necessary to comprehensively consider various factors and multiple modes for vibration reduction design. Full article

A method called PCR (Platform Centered Reduction) is designed to more effectively perform complex iterative and nonlinear calculations required for the dynamic response of turbine blades damped by dry friction contacts between rigid dampers and airfoil-to-neck platform. The key feature of PCR is to represent all nonlinear forces on the blade platform by means of only six degrees of freedom at a point located within the platform volume, regardless of the number of damper–platform contact elements. Despite reducing the effort and computational time by more than one order of magnitude, the method proves to be fully accurate by a check against the corresponding nonlinear Finite Elements (FE) calculation. It is also shown that the limit exciting force, indicating the upper capability to dampen vibrations, can be calculated with a simple linear modal analysis. In order to search for the best blade–damper match, the preferred graph represents relevant bending stresses on the airfoil against excitation forces. A detailed application of the method concerns two significantly different blade sizes, by varying parameters such as neck length and damper centrifugal force. Finally, it is emphasized that a final check by a complete FE analysis is still possible as a purely linear solution fed by sets of contact forces previously determined through the PCR at any desired frequency and excitation. Full article

Helicopter tail rotors adopt a segmented driveline connected by flexible couplings, and dry friction dampers to suppress resonance. Modeling for this system can provide a basic foundation for parameter analysis. In this work, the lateral-torsional vibration equation of the shaft with continuous internal damping is established. The static and dynamic effects caused by flexible diaphragm couplings subject to parallel and angular misalignment is derived. A novel dual rub-impact model between the shaft and dry friction damper with multiple stages is proposed. Finally, a model of a helicopter tail rotor driveline incorporating all the above elements is formulated. Numerical simulations are carried out by an improved Adams–Bashforth method following the design flowchart. The dynamics of multiple vibration suppression, and the static and dynamic misalignment are analyzed to illustrate the accuracy and characteristics of the model. The coeffect of the rub impact and the misalignment on shafts and dampers are presented through the results of simulation and experiment. It provides an accurate and comprehensive mathematical model for the helicopter driveline. Response characteristics of multiple damping stages, static and dynamic misalignment, and their interaction are revealed. Full article

The current work introduces a new semi-floating ring bearing (SFRB) system developed for improving the rotordynamic and vibration performance of automotive turbochargers (TCs) at extreme operation conditions, such as high temperature, severe external force excitation, and large rotor imbalance. The new bearing design replaces outer oil films, i.e., squeeze film dampers (SFDs), in TC SFRBs with wire mesh dampers (WMDs). This SFRB configuration integrating WMDs aims to implement reliable mechanical components, as an inexpensive and simple alternative to SFDs, with consistent and superior damping capability, as well as predictable forced performance. Since WMDs are in series with the inner oil films of SFRBs, experimentally determined force coefficients of WMDs are of great importance in the design process of TC rotor-bearing systems (RBSs). Presently, the measurements of applied static load and ensuing deflection determine the structural stiffnesses of the WMDs. The WMD damping parameters, including dissipated energy, loss factor, and dry friction coefficient, are estimated from the area of the distinctive local hysteresis loop of the load versus WMD displacement data recorded during consecutive loading-unloading cycles as a function of applied preload with a constant amplitude of motion. The changes in WMD loss factor and dry friction coefficient due to increases in preload are more significant for the WMDs with lower density. The present work shows, to date, the most comprehensive measurements of static load characteristics on the WMDs for application into small automotive TCs. More importantly, the extensive test measurements of WMD deflection versus increasing static loads will aid to anchor predictions of future computation model. Full article

Dry friction dampers are widely used to reduce vibration. The forced vibration response of a simplified turbine blade with a new kind of under-platform dry friction dampers is studied in this paper. The model consists of a clamped blade as two rigidly connected beams and two dampers in the form of masses which are allowed to slide along the blade platform in the horizontal direction and vibrate with the blade platform in the vertical direction. The horizontal and vertical vibrations of the two dampers, and the horizontal and transverse platform vibrations are coupled by friction at the contact interfaces which is assumed to follow the classical discontinuous Coulomb’s law of friction. The vertical motion of the dampers leads to time-varying contact forces and can cause horizontal stick-slip motion between the contact surfaces. Due to the relative horizontal motion between the dampers and the blade platform, the vertical contact forces and the resultant friction forces act as moving loads. The Finite Element (FE) method and Modal Superposition (MS) method are applied to solve the dynamic response, together with an algorithm that can capture nonsmooth transitions from stick to slip and slip to stick. Quasi-periodic vibration is found even under harmonic excitation. Full article

In order to improve the energy dissipation of the masonry infilled frame structure while decreasing the stiffening and strengthening effects of the infill panels, a new dry stacked panel (DSP) semi-interlocking masonry (SIM) infill panel has been developed. In this paper, the material properties of DSP and a traditional unreinforced masonry (URM) panel have been evaluated experimentally. A series of cyclic tests were performed to investigate the cyclic behaviour of the reinforcement concrete (RC) frame with different infill panels. The failure modes, damage evolution, hysteretic behaviour, stiffness degradation and energy dissipation were compared and analysed. We concluded that DSP is capable of significantly improving the seismic energy dissipation due to its hysteretic behaviour when the frame is in elastic stage without increasing the stiffness of the frame. Therefore, DSP or SIM panels can be considered as frictional dampers. Based on the experimental results, the influence of DSP was examined. Using the parallel model, the hysteretic loops of DSP subjected to different load cases were achieved. The typical full hysteretic loop for DSP could be divided into three distinct stages of behaviour: packing stage, constant friction stage and equivalent strut stage. The connection between the panel and the frame had a great effect on the transferring of different mechanical stages. The constant friction stage was verified to provide substantial energy dissipation and benefits to the ductility of the structure, which, therefore, is suggested to be prolonged in reality. Full article
