Search Results (239)

Search Parameters:
Keywords = direct current (DC) switching

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
23 pages, 3246 KB
Article
SiC-Based LLC Resonant Converter for Level 3 EV Fast Charger: Design and Simulation
by Heriberto Adamas-Pérez, Mario Ponce-Silva, Pedro Javier García-Ramírez, Eligio Flores Rodríguez, Jesús Aguayo Alquicira and Susana Estefany De León-Aldaco
Eng 2026, 7(5), 227; https://doi.org/10.3390/eng7050227 - 9 May 2026
Viewed by 352
Abstract
The growing use of electric vehicles (EVs) requires fast charging solutions capable of delivering high power levels with greater efficiency and less impact on the power grid. This article presents the design and simulation of a Level 3 fast direct current (DC) charger [...] Read more.
The growing use of electric vehicles (EVs) requires fast charging solutions capable of delivering high power levels with greater efficiency and less impact on the power grid. This article presents the design and simulation of a Level 3 fast direct current (DC) charger for electric vehicles based on an LLC resonant DC-DC converter. The proposed architecture incorporates an isolated LLC resonant converter, selected for its soft switching capability, low switching losses, and reduced electromagnetic interference (EMI). The main contribution of this work is the design and simulation of a 50 kW LLC resonant converter developed specifically for a Level 3 DC fast charger for electric vehicles, a power level that, to the authors’ knowledge, has not been previously described in the current scientific literature using this topology. For the proposed converter, it has been proposed to use commercially available wide bandgap (WBG) semiconductor devices specifically made of silicon carbide (SiC). This allows for high switching frequency operation, lower conduction and switching losses, and higher power density. The key design parameters, component selection, and operating principles are analyzed in detail. Simulation results demonstrate high conversion efficiency, reduced switching stress, and stable operation under fast charging conditions, validating the suitability of the LLC topology for high-power electric vehicle charging applications. The proposed system offers a scalable and efficient solution that can contribute to the development of compact, grid-compatible DC fast charging stations, supporting the growing demand for electromobility infrastructure. Full article
Show Figures

Figure 1

14 pages, 29597 KB
Article
Backstepping Super-Twisting Sliding Mode Control for MMC-HVDC in Passive Networks
by Zerong Wang, Xinhong Wu, Hao Dong, Hao Huang and Yongxi Zhao
Energies 2026, 19(9), 2246; https://doi.org/10.3390/en19092246 - 6 May 2026
Viewed by 214
Abstract
Due to their superior harmonic profiles and minimal switching energy losses, modular multilevel converters (MMCs) have emerged as the primary topology for high voltage direct current (HVDC) applications. However, traditional Proportional–Integral (PI) control exhibits inferior dynamic performance using MMC-HVDC supplying power in the [...] Read more.
Due to their superior harmonic profiles and minimal switching energy losses, modular multilevel converters (MMCs) have emerged as the primary topology for high voltage direct current (HVDC) applications. However, traditional Proportional–Integral (PI) control exhibits inferior dynamic performance using MMC-HVDC supplying power in the passive networks. This study proposes a backstepping super-twisting sliding mode control strategy, which significantly improves the dynamic performance of the MMC-HVDC system and mitigates fluctuations in the DC side voltage. First, a mathematical model is established based on the topology of the modular multilevel HVDC transmission system. Then, utilizing the backstepping method, a virtual control law for the current inner loop is designed according to the mathematical model. Subsequently, the super-twisting sliding mode algorithm is introduced based on the backstepping method to form the backstepping super-twisting sliding mode control law. Finally, a comprehensive model is established within the Matlab/Simulink environment, and extensive simulation studies are carried out to evaluate the effectiveness the effectiveness and advantages of the proposed backstepping super-twisting sliding mode control under stable operation, grid voltage sag, and single-phase grounding fault conditions. Comparative evaluations verify that the introduced strategy effectively lowers the total harmonic distortion (THD) of the current and suppresses DC voltage ripples. Moreover, compared to the conventional PI method, the new approach provides enhanced transient robustness with noticeably reduced overshoot with considerably lower overshoot compared to traditional PI control, thereby providing a highly reliable and stable solution for MMC-HVDC systems supplying passive networks. Full article
(This article belongs to the Special Issue Modular Multilevel Converters: Technologies, Control and Applications)
Show Figures

Figure 1

28 pages, 13937 KB
Article
Investigation of Leakage Current Behaviour on Artificially Contaminated Insulators Under Superimposed HVDC Voltage Stress and Hybrid HVDC/HVAC Transmission Conditions
by Julian Hanusrichter and Frank Jenau
Energies 2026, 19(9), 2183; https://doi.org/10.3390/en19092183 - 30 Apr 2026
Viewed by 277
Abstract
High-voltage direct current (HVDC) transmission systems are increasingly used for long-distance power transmission and the integration of renewable energy sources. In such systems, outdoor insulators are exposed to combined electrical stresses, including steady DC voltage, transient overvoltages, and environmental contamination, which can significantly [...] Read more.
High-voltage direct current (HVDC) transmission systems are increasingly used for long-distance power transmission and the integration of renewable energy sources. In such systems, outdoor insulators are exposed to combined electrical stresses, including steady DC voltage, transient overvoltages, and environmental contamination, which can significantly influence leakage current behaviour and insulation performance. This work presents an experimental and numerical investigation of leakage currents on artificially contaminated polymer insulators under two application-relevant HVDC operating scenarios. The first scenario considers superimposed HVDC voltage with switching impulses and very slow front overvoltages, which may occur during fault conditions in converter-based HVDC systems. The second scenario investigates electromagnetic coupling effects in a hybrid HVDC/HVAC transmission line configuration, where AC and DC conductors are installed on the same tower. Artificial contamination layers with different morphologies and conductivities are applied to the insulator surface to reproduce realistic pollution conditions. Leakage currents are measured using a high-resolution acquisition system, and the results are supported with numerical simulations based on finite-element modelling. The results show that transient overvoltages significantly increase leakage current amplitude and duration, leading to increased electrical stress on contaminated insulators. In the hybrid transmission configuration, electromagnetic coupling between AC and DC paths induces additional current components in the DC leakage current. The presented results contribute to a better understanding of leakage current behaviour under realistic HVDC operating conditions and provide useful information for insulation assessment and condition monitoring of outdoor insulators in modern HVDC transmission systems. Full article
(This article belongs to the Section F1: Electrical Power System)
Show Figures

Figure 1

22 pages, 4749 KB
Article
A New Active Power Decoupling Cascaded H-Bridge Static Synchronous Compensator and Its Control Method
by Qihui Feng, Feng Zhu, Chenghui Lin, Xue Han, Dingguo Li and Weilong Xiao
Energies 2026, 19(8), 1818; https://doi.org/10.3390/en19081818 - 8 Apr 2026
Viewed by 349
Abstract
The cascaded H-bridge static synchronous compensator (STATCOM) has been widely employed in medium- and high-voltage reactive power compensation applications due to its high modularity, fast response speed, and direct grid connection capability. However, the DC-link voltage exhibits an inherent double-frequency ripple, which poses [...] Read more.
The cascaded H-bridge static synchronous compensator (STATCOM) has been widely employed in medium- and high-voltage reactive power compensation applications due to its high modularity, fast response speed, and direct grid connection capability. However, the DC-link voltage exhibits an inherent double-frequency ripple, which poses a serious challenge to power quality. Therefore, numerous Active Power Decoupling (APD) techniques have been proposed. However, existing schemes still exhibit certain limitations: independent APD topologies are associated with higher costs, whereas single bridge-arm multiplexed APD topologies are confronted with issues such as elevated DC-side voltage and increased current stress on the multiplexed arm. Consequently, comprehensive optimization is difficult to achieve in terms of the number of power devices, decoupling accuracy, level of capacitor multiplexing, and device stress. To address the above issues, this paper proposes a DC split capacitor (DC-SC)-based dual bridge-arm multiplexed cascaded H-bridge STATCOM with active power decoupling capability, along with its corresponding control method. By constructing a fundamental-frequency common-mode voltage on the decoupling capacitor, this method effectively suppresses the double-frequency ripple in the DC-side voltage and reduces the current stress on the switching devices. The simulation and experimental results have verified the correctness and effectiveness of the proposed topological structure and control method. Full article
Show Figures

Figure 1

22 pages, 4405 KB
Article
Neural Network-Based Submodule Capacitance Monitoring in Modular Multilevel Converters for Renewable Energy Conversion Systems
by Mustapha Asnoun, Adel Rahoui, Koussaila Mesbah, Boussad Boukais, David Frey, Idris Sadli and Seddik Bacha
Electronics 2026, 15(7), 1486; https://doi.org/10.3390/electronics15071486 - 2 Apr 2026
Viewed by 480
Abstract
The widespread development of medium-voltage and high-voltage direct current transmission systems has highlighted the modular multilevel converter (MMC) as a crucial enabling technology. However, the overall performance and lifetime of the MMC strongly depend on the integrity of its submodules (SMs), making online [...] Read more.
The widespread development of medium-voltage and high-voltage direct current transmission systems has highlighted the modular multilevel converter (MMC) as a crucial enabling technology. However, the overall performance and lifetime of the MMC strongly depend on the integrity of its submodules (SMs), making online capacitance condition monitoring a critical requirement. Unlike recent related studies that rely on computationally heavy matrix-based algorithms or “black-box” artificial neural networks requiring massive offline training datasets, this paper proposes a parametric, adaptive linear neuron network. Mapped directly to the physical equations of the MMC, the method simultaneously exploits the arm current, SM switching state, and capacitor voltage to identify online parametric variations caused by aging or harsh conditions. The proposed scheme is fully non-intrusive, requiring no additional hardware sensors or signal injections, thereby reducing implementation complexity. The simulation results obtained in MATLAB/Simulink (vR2024b) demonstrate the method’s fast convergence and a quantified steady-state estimation error within ±1%. Furthermore, the estimator exhibits strong robustness under severe operating conditions, successfully maintaining accuracy during a 20% capacitance reduction, a 100% active power step variation, dc-link voltage fluctuations, measurement noise, grid unbalances, and harmonic perturbations. Full article
Show Figures

Figure 1

17 pages, 3231 KB
Article
An Analytical Model for DC-Link Capacitor Ripple Current in Multi-Phase H-Bridge Inverters
by Bo Wang and Huiying Tang
Processes 2026, 14(7), 1059; https://doi.org/10.3390/pr14071059 - 26 Mar 2026
Viewed by 687
Abstract
Ripple currents on the direct current (DC) bus in variable frequency drive (VFD) systems originate from motor load current fluctuations and the high-frequency switching of power devices. The resulting Joule heating within the DC-link capacitors is a primary driver of lifespan degradation. To [...] Read more.
Ripple currents on the direct current (DC) bus in variable frequency drive (VFD) systems originate from motor load current fluctuations and the high-frequency switching of power devices. The resulting Joule heating within the DC-link capacitors is a primary driver of lifespan degradation. To address the lack of systematic models for multi-phase H-bridge inverters and the over-design caused by empirical methods, this paper proposes a novel analytical method that incorporates the 2kπ/N phase difference of parallel units for precise ripple current quantification. First, a dynamic DC-link capacitor model is established based on a single-phase H-bridge inverter, and the expressions for the instantaneous, average, and root mean square (RMS) input currents are derived. Furthermore, by introducing the 2kπ/N phase difference (where k = 0, 1, …, N − 1) among N parallel H-bridge units, a universal analytical expression for the RMS input current and its harmonic spectrum in a multi-phase system is obtained. The analysis reveals that ripple current harmonics concentrate at 2m × fsw (where m is a positive integer and fsw is switching frequency) and their sidebands (2m × fsw ± fo, fo is output fundamental frequency), and the coupling influence of modulation index and power factor angle on ripple amplitude is quantitatively characterized. A 12 × 160 kW twelve-phase H-bridge inverter is taken as a case study, and MATLAB (v2023b) simulations and hardware experiments demonstrate that the theoretical calculations are in close agreement with the simulated and measured results, with the errors of input current harmonic amplitudes all below 5%. Compared with traditional empirical design, the proposed method reduces the capacitor volume and cost by approximately 15–20% while ensuring system reliability. This method is directly extensible to other multi-phase inverter topologies, providing a theoretical foundation for the accurate selection of DC-link capacitors. Full article
(This article belongs to the Special Issue Design, Control, Modeling and Simulation of Energy Converters)
Show Figures

Figure 1

19 pages, 3434 KB
Article
Influence of the Ge–Chalcogenide Active Layer on Electrical Conduction in Self-Directed Channel Memristors
by Ahmed A. Taher and Kristy A. Campbell
Micromachines 2026, 17(4), 403; https://doi.org/10.3390/mi17040403 - 26 Mar 2026
Viewed by 773
Abstract
The self-directed channel (SDC) class of memristors employs a multilayer architecture that is designed to enable robust Ag ion conduction, long cycling lifetime, and thermal stability. While several layers contribute to mechanical and chemical reliability, two layers primarily govern the electrical behavior: the [...] Read more.
The self-directed channel (SDC) class of memristors employs a multilayer architecture that is designed to enable robust Ag ion conduction, long cycling lifetime, and thermal stability. While several layers contribute to mechanical and chemical reliability, two layers primarily govern the electrical behavior: the amorphous Ge–chalcogenide active layer that is adjacent to the bottom electrode and the overlying metal–chalcogenide source layer. In this work, we investigate how the variation in the chalcogen species in these two layers influences switching characteristics in the pre-write regime, both in the pristine state and after a write/erase cycle, as well as the conduction behavior at room temperature. The devices were fabricated using Ge-rich chalcogenides containing O, S, Se, or Te, combined with SnS, SnSe, or Ag2Se metal–chalcogenide layers. The DC current-voltage measurements were analyzed using the standard linearization approaches to examine whether the transport behavior in the pre-write regime exhibits characteristics that are associated with Ohmic, Schottky, Poole–Frenkel, or space charge limited conduction. These measurements specifically probe the pre-write region of the I-V curve, where early ionic redistribution and structural rearrangement precede the abrupt formation of the conductive channels responsible for the resistive switching. The results show that the chalcogen composition strongly affects the threshold voltage, the resistance window, and the onset of field-enhanced transport, reflecting the differences in ionic distribution and channel formation dynamics. The results indicate that transport evolves with a bias and a compliance current, transitioning between regimes that are influenced by the interface injection and bulk-limited conduction, depending on the material stack. These findings clarify the role of chalcogen chemistry in governing the SDC switching behavior and provide guidance for the material selection in application-specific device design. Full article
Show Figures

Figure 1

29 pages, 3670 KB
Article
Modelling Techniques of Proton Exchange Membrane Fuel Cells (PEMFC): Electrical Engineer’s View
by Nisitha Padmawansa, Kosala Gunawardane, Sahan Neralampitiyage and Dylan Lu
Energies 2026, 19(6), 1577; https://doi.org/10.3390/en19061577 - 23 Mar 2026
Viewed by 584
Abstract
Proton exchange membrane fuel cells (PEMFCs) play a key role in hydrogen-based energy systems; however, accurate and practical modelling remains challenging due to system nonlinearities, parameter variability, and degradation effects. This paper presents a low-complexity parameter estimation methodology for a simplified PEMFC equivalent [...] Read more.
Proton exchange membrane fuel cells (PEMFCs) play a key role in hydrogen-based energy systems; however, accurate and practical modelling remains challenging due to system nonlinearities, parameter variability, and degradation effects. This paper presents a low-complexity parameter estimation methodology for a simplified PEMFC equivalent circuit model using current-switching techniques. The approach enables direct extraction of key parameters, including internal resistance and capacitance, from transient voltage responses without requiring complex optimization or large datasets. Experimental validation was conducted using 100 W and 1 kW PEMFC systems under current loading and interruption conditions. The results demonstrate good agreement between measured and simulated voltage responses, with a maximum error below 10% and typical error levels in the range of ~1.4–3%. Compared to conventional mechanistic and data-driven models, the proposed method significantly reduces computational complexity and measurement requirements while maintaining high predictive accuracy. Moreover, the combination of the simplified equivalent circuit model with current-switching-based parameter estimation offers an effective and practical tool for electrical engineers, enabling real-time monitoring, control-oriented modelling, and seamless integration with power electronic systems. The proposed approach is particularly suitable for applications in DC microgrids and digital twin-based monitoring of hydrogen energy systems. Full article
(This article belongs to the Section A5: Hydrogen Energy)
Show Figures

Figure 1

38 pages, 11159 KB
Review
Hardware-Based Reduction of Submodule Capacitor Voltage Ripple in Modular MultiLevel Converters: A Critical Review
by Erdogan Dinc, Halise Kilicoglu, Alper Emre Ozden, Hakime Hanife Goren, Bei Liu, Paul Weston and Pietro Tricoli
Electronics 2026, 15(6), 1254; https://doi.org/10.3390/electronics15061254 - 17 Mar 2026
Viewed by 508
Abstract
This paper reviews circuit topologies in the literature that aim to suppress submodule (SM) capacitor-voltage ripple of modular multilevel converters (MMCs), since this low-frequency ripple largely determines the required SM capacitance and thus the overall converter volume, cost, and reliability. The circuit topologies [...] Read more.
This paper reviews circuit topologies in the literature that aim to suppress submodule (SM) capacitor-voltage ripple of modular multilevel converters (MMCs), since this low-frequency ripple largely determines the required SM capacitance and thus the overall converter volume, cost, and reliability. The circuit topologies covered in this review include high-frequency (HF) magnetic or switched power channels, transformerless active channel or bridging cells with mid-cell connections, hybrid-MMC and DC-bus management options, SM-level active power decoupling (APD) and active power filters (APF), and structural modifications. Physical power-channel topologies (HF magnetic or switched auxiliary paths) suppress the 2ω capacitor-voltage ripple by transferring the associated low-frequency ripple power to an auxiliary high-frequency path. Hybrid-MMC and direct-current (DC) bus management reduce the required capacitance with only a modest increase in hardware requirements. SM-level APD and APF cells transfer the ripple power into auxiliary storage. Structural and topological arrangements modify the converter architecture itself, leading to architectural simplification, passive attenuation, and a reduced need for measurement or balancing. The reviewed topologies are then compared in terms of ripple reduction, hardware complexity, additional components, cost, and control complexity, and the resulting evidence is synthesised into application-driven design trade-offs and selection guidelines. In addition, DC–DC MMC topologies are discussed separately in a contextual overview. Full article
Show Figures

Figure 1

22 pages, 21559 KB
Article
Memristor Models with Parasitic Parameters for Analysis of Passive Memory Arrays
by Valeri Mladenov and Stoyan Kirilov
Technologies 2026, 14(3), 166; https://doi.org/10.3390/technologies14030166 - 6 Mar 2026
Viewed by 834
Abstract
Memristors are valuable elements with very good memory and switching features. They have minimal power consumption, nano-scale sizes, and a possibility for integration with high-density Complementary Metal Oxide Semiconductor (CMOS) integrated circuits. They are applicable in neural networks, memory crossbars, and different electronic [...] Read more.
Memristors are valuable elements with very good memory and switching features. They have minimal power consumption, nano-scale sizes, and a possibility for integration with high-density Complementary Metal Oxide Semiconductor (CMOS) integrated circuits. They are applicable in neural networks, memory crossbars, and different electronic devices. This work considers some improved and existing models for memristors, functioning at high-frequency signals with a high speed and very good effectiveness. The main parasitic parameters—series resistance, capacitance, and small-signal direct current (DC) voltage and current shifting signals—are taken into account. An additional leakage conductance is analyzed as a parasitic component. The influence of the parasitic parameters on the normal functioning of memristor-based circuits is analyzed and evaluated at hard-switching and soft-switching modes. For investigations of the main characteristics of the considered models and their applicability in memory arrays, Linear Technology Simulation Program with Integrated Circuits Emphasis (LTSPICE) library models are generated and analyzed. The considered models operate at low-, middle- and high-frequency signals, clearly demonstrating the main properties of memristors. Their appropriate operation in passive memory arrays is analyzed and established. The proposed models have a 26% enhanced accuracy in fitting experimental i-v relations. They ensure good memory and switching properties for memory arrays. This work could be a suitable step towards the design and manufacturing of ultra-high-density memristor-based integrated chips. Full article
Show Figures

Figure 1

30 pages, 7398 KB
Article
A Single-Stage Three-Phase AC-DC LLC Resonant Converter with Planar Magnetics and Trajectory-Based PFM Control
by Qichen Liu and Zhengquan Zhang
Electronics 2026, 15(5), 1095; https://doi.org/10.3390/electronics15051095 - 5 Mar 2026
Cited by 2 | Viewed by 637
Abstract
This paper proposes a single-stage three-phase AC-DC converter based on an LLC resonant topology utilizing a front-end matrix switch. Unlike traditional two-stage solutions, the proposed topology synthesizes a fluctuating equivalent DC voltage from the three-phase input, achieving direct power conversion with high efficiency. [...] Read more.
This paper proposes a single-stage three-phase AC-DC converter based on an LLC resonant topology utilizing a front-end matrix switch. Unlike traditional two-stage solutions, the proposed topology synthesizes a fluctuating equivalent DC voltage from the three-phase input, achieving direct power conversion with high efficiency. To maintain a stable DC output voltage against the time-varying input, a trajectory-based Pulse Frequency Modulation (PFM) control strategy is developed. By employing State-Plane Analysis (SPA), the operational trajectory is divided into four calculation segments, allowing precise derivation of the switching frequency and duty cycles for both boost and buck modes within a single line cycle. Furthermore, to improve power density and reduce parasitic parameters, a high-frequency planar inductor with interleaved windings and a planar transformer are designed for 500 kHz operation. A pipeline control architecture based on a single DSP is implemented to handle the complex real-time computations. A 500 W prototype is built and tested under 100 V input and 130 V output conditions. Experimental results demonstrate that the converter achieves a peak efficiency of 97%, a power factor of 0.99, and a grid current Total Harmonic Distortion (THD) of 3.95%, validating the effectiveness of the proposed topology and control scheme. Full article
(This article belongs to the Special Issue Innovative Technologies in Power Converters, 3rd Edition)
Show Figures

Figure 1

24 pages, 3677 KB
Article
Research on Early Aging Fault Identification of Photovoltaic DC Combiner System
by Yu Zou, Kailong Chen, Huawei He, Zile Li and Jiaxun Teng
Energies 2026, 19(5), 1273; https://doi.org/10.3390/en19051273 - 4 Mar 2026
Viewed by 336
Abstract
In order to detect typical faults in the photovoltaic Direct current (DC) system, this paper first compared and analyzed the frequency domain responses of two typical faults in the photovoltaic DC system at different insulation aging stages based on the early insulation aging [...] Read more.
In order to detect typical faults in the photovoltaic Direct current (DC) system, this paper first compared and analyzed the frequency domain responses of two typical faults in the photovoltaic DC system at different insulation aging stages based on the early insulation aging theory and the insulation aging characteristics of DC transmission cables. A fault identification method based on the harmonic trajectory of the primary and secondary switch frequencies for pole-to-pole short-circuit faults was proposed. The feasibility of this fault identification method was verified through the controller algorithm and combined with the hardware experimental platform. This method utilizes basic mathematical theorems, and the code configuration is easy to implement. At the same time, adjusting the sliding-window coefficient and the threshold coefficient can change the sensitivity and false-alarm rate of the algorithm, achieving different levels of fault-identification accuracy and leading to the best results. A 90% accuracy and a false-alarm rate lower than 10% can be achieved, opening up new ideas and methods for photovoltaic fault identification. Experimental results show that this method has a fast fault identification speed, with an identification time ranging from 10 to 20 ms, and can achieve different levels of identification accuracy by flexibly adjusting the control parameters. Full article
Show Figures

Figure 1

9 pages, 691 KB
Article
Electrical Properties and Performance Enhancement of AlGaN/GaN/Si HEMTs
by Hana Mosbahi, Mohammed Khalil Mohammed Ali and Malek Gassoumi
Micromachines 2026, 17(3), 297; https://doi.org/10.3390/mi17030297 - 27 Feb 2026
Viewed by 474
Abstract
This study presents a detailed electrical analysis of AlGaN/GaN/Si HEMTs grown by molecular beam epitaxy, using direct and pulse current, small-signal microwave, and deep-level transient spectroscopy (DLTS) techniques to investigate transport characteristics and defect-related effects. DC measurements revealed self-heating effects and leakage currents, [...] Read more.
This study presents a detailed electrical analysis of AlGaN/GaN/Si HEMTs grown by molecular beam epitaxy, using direct and pulse current, small-signal microwave, and deep-level transient spectroscopy (DLTS) techniques to investigate transport characteristics and defect-related effects. DC measurements revealed self-heating effects and leakage currents, while RF analysis highlighted the devices’ high-frequency capabilities alongside parasitic effects linked to deep-level traps. Pulsed I–V characterization demonstrated gate-lag and drain-lag behaviors associated with dynamic charge trapping. DLTS identified electron traps, emphasizing their critical role in device degradation and switching performance. The strong correlation between trap states and electrical behavior underlines the importance of defect control for enhancing efficiency and reliability. Full article
Show Figures

Figure 1

21 pages, 6455 KB
Article
Design and Implementation of a Three-Phase Buck-Boost Split-Source Inverter (BSSI)
by Yasameen Sh. Abdulhussein and Ayhan Gün
Electronics 2026, 15(4), 808; https://doi.org/10.3390/electronics15040808 - 13 Feb 2026
Viewed by 463
Abstract
The integration of renewable energy sources, including photovoltaic (PV) and fuel cell (FC) systems, into AC grids has attracted immense research interest in recent times. Furthermore, incorporating these renewable sources of energy into medium-voltage grids is garnering increased attention because of the obvious [...] Read more.
The integration of renewable energy sources, including photovoltaic (PV) and fuel cell (FC) systems, into AC grids has attracted immense research interest in recent times. Furthermore, incorporating these renewable sources of energy into medium-voltage grids is garnering increased attention because of the obvious benefits of medium-voltage integration at elevated power levels. Photovoltaic applications entail the arrangement of solar panels capable of outputting voltages up to 1.5 kV; nonetheless, fuel cells display restricted output voltage, with a maximum market range of 400 to 700 V. Hence, the efficient integration of renewable energy sources into low-voltage or medium-voltage grids demands the utilization of a step-up direct current (DC–DC) inverter and a converter for connection to the alternating current (AC) grid, in which an efficient step-up converter is critical for the medium-voltage grid. Therefore, this study presents a three-phase buck-boost split-source inverter (BSSI) that resolves the constrained output voltage of the fuel cells. This study focuses on modifying the configuration of a conventional three-phase split-source inverter (SSI) circuit by adding a few components while maintaining the inverter’s modulation. This novel circuit design enables the reduction in voltage strains on the inverter switch components and improves DC-link use in relation to a traditional SSI configuration. For an 800 bus, maximal voltage stress on the primary inverter switches is lowered when compared with the standard SSI that delivers entire DC-bus voltage to switches. A rectifier-based model is employed to simulate the behavior of a renewable energy source. Combining these advantages with the conventional modulation of the inverter offers a more effective design. The buck-boost split-source inverter (BSSI) was analyzed using three distinct modulation techniques: the sinusoidal pulse-width modulation scheme (SPWM), the third-harmonic injected pulse-width modulation (THPWM) scheme, and space vector modulation (SVM). The proposed analysis was validated through MATLAB-SIMULINK and practical outcomes on a 5.0 kW model. The practical and SIMULINK data were found to be closely aligned with the analysis. The circuit developed in this study also ensures efficient DC-to-AC conversion, specifically with regard to low-voltage sources, like fuel cells or photovoltaic (PV) systems. Full article
(This article belongs to the Special Issue Electric Power Systems and Renewable Energy Sources)
Show Figures

Graphical abstract

15 pages, 6451 KB
Article
Full-Bridge Intermediate-Frequency Converter with Low Voltage and Current Stress on Auxiliary Switching Devices
by Shilong Gao, Wu Chen, Haixi Zhao and Chenyang Liu
Energies 2026, 19(3), 852; https://doi.org/10.3390/en19030852 - 5 Feb 2026
Viewed by 460
Abstract
The DC converter constitutes a pivotal component within medium-voltage direct current (MVDC) collection systems, performing functions such as voltage boosting, isolation, and power transmission. To accommodate the demand for high-capacity DC converters in MVDC collection systems for new energy sources, a full-bridge medium-frequency [...] Read more.
The DC converter constitutes a pivotal component within medium-voltage direct current (MVDC) collection systems, performing functions such as voltage boosting, isolation, and power transmission. To accommodate the demand for high-capacity DC converters in MVDC collection systems for new energy sources, a full-bridge medium-frequency converter featuring low voltage and current stress on auxiliary switching devices is proposed. Based on the principles of dual-transformer configuration and component sharing, this converter employs a half-bridge circuit and a full-bridge circuit sharing two switching devices. Utilizing mixed-frequency modulation, the full-bridge main circuit operates at medium frequency to transmit the majority of power, while the half-bridge auxiliary circuit regulates overall power and voltage through high-frequency chopping control. This achieves zero-current switching for the medium-frequency switching devices across the entire load range, significantly reducing switching losses in the converter. This paper details the converter’s operating principles and analyzes key parameter design methodologies. Finally, a 240–6000 V/7200 W prototype was constructed to validate the proposed converter’s performance. Full article
Show Figures

Figure 1
