Search Results (13)

The optical remote sensors carried by the Jilin-1 KF02 series satellites have an imaging resolution better than 0.5 m and a width of 150 km. There are radiometric problems, such as stripe noise, vignetting, and inter-slice chromatic aberration, in their raw images. In this paper, a relative radiometric correction method based on temperature normalization is proposed for the response characteristics of sensors and the structural characteristics of optical splicing of Jilin-1 KF02 series satellites cameras. Firstly, a model of temperature effect on sensor output is established to correct the variation of sensor response output digital number (DN) caused by temperature variation during imaging process, and the image is normalized to a uniform temperature reference. Then, the horizontal stripe noise of the image is eliminated by using the sensor scan line and dark pixel information, and the vertical stripe noise of the image is eliminated by using the method of on-orbit histogram statistics. Finally, the method of superposition compensation is used to correct the vignetting area at the edge of the image due to the lack of energy information received by the sensor so as to ensure the consistency of the image in color and image quality. The proposed method is verified by Jilin-1 KF02A on-orbit images. Experimental results show that the image response is uniform, the color is consistent, the average Streak Metrics (SM) is better than 0.1%, Root-Mean-Square Deviation of the Mean Line (RA) and Generalized Noise (GN) are better than 2%, Relative Average Spectral Error (RASE) and Relative Average Spectral Error (ERGAS) are greatly improved, which are better than 5% and 13, respectively, and the relative radiation quality is obviously improved after relative radiation correction. Full article

This study reports new types of passive mode-locked Er-doped fiber laser (EDFL) based on a segment of doped fiber saturable absorber (DFSA) with Tm/Ho-doped fiber (THDF), Yb-doped fiber (YDF), and Er-doped fiber (EDF). By employing THDF-SA, a bright pulse sequence with a fundamental repetition rate of 17.86 MHz was obtained. In addition, various mode-locked output states, including dark pulses, dark–bright pulse pairs, bright–dark pulse pairs, and second-harmonic pulses, were obtained through polarization modulation and gain modulation, and the orthogonality of dark–bright pulses in both polarization directions was verified. Furthermore, using EDF-SA and YDF-SA, dark pulses and dark–bright pulses were obtained. A comparison of the three experiments revealed that THDF-SA effectively reduces the mode-locked threshold and improves the average output power. Compared with bright pulses, dark pulses offer several advantages such as resisting noise, increasing propagation speed, and suppressing nonlinear scattering (such as pulse-intrinsic Raman scattering); thus, the EDFL can find broad application in long-distance transmission, precision measurement, and other fields. Full article

The development of spectral sensors (SSs) capable of retrieving spectral information have opened new opportunities to improve several environmental and agricultural practices, e.g., crop breeding, plant phenotyping, land use monitoring, and crop classification. The SSs are classified as multispectral and hyperspectral (HS) based on the number of the spectral bands resolved and sampled during data acquisition. Large-scale applications of the HS remain limited due to the cost of this type of technology and the technical difficulties in hyperspectral data processing. Low-cost portable hyperspectral cameras (PHCs) have been progressively developed; however, critical aspects associated with data acquisition and processing, such as the presence of spectral discontinuities, signal jumps, and a high level of background noise, were reported. The aim of this work was to analyze and improve the hyperspectral output of a PHC Senop HSC-2 device by developing a general use methodology. Several signal gaps were identified as falls and jumps across the spectral signatures near 513, 650, and 930 nm, while the dark current signal magnitude and variability associated with instrumental noise showed an increasing trend over time. A data correction pipeline was successfully developed and tested, leading to 99% and 74% reductions in radiance signal jumps identified at 650 and 830 nm, respectively, while the impact of noise on the acquired signal was assessed to be in the range of 10% to 15%. The developed methodology can be effectively applied to other low-cost hyperspectral cameras. Full article

We present a 320 × 240 CMOS image sensor (CIS) using the proposed hybrid-correlated multiple sampling (HMS) technique with an adaptive dual-gain analog-to-digital converter (ADC). The proposed HMS improves the noise characteristics under low illumination by adjusting the ADC gain according to the incident light on the pixels. Depending on whether it is less than or greater than 1/4 of the full output voltage range from pixels, either correlated multiple sampling or conventional-correlated double sampling (CDS) is used with different slopes of the ramping signals. The proposed CIS achieves 11-bit resolution of the ADC using an up-down counter that controls the LSB depending on the ramping signals used. The sensor was fabricated using a 0.11 μm CIS process, and the total chip area was 2.55 mm × 4.3 mm. Compared to the conventional CDS, the measurement results showed that the maximum dark random noise was reduced by 26.7% with the proposed HMS, and the maximum figure of merit was improved by 49.1%. The total power consumption was 5.1 mW at 19 frames per second with analog, pixel, and digital supply voltages of 3.3 V, 3.3 V, and 1.5 V, respectively. Full article

The efficient generation of high-quality random numbers is essential in the operation of cryptographic modules. The quality of a random number generator is evaluated by the min-entropy of its entropy source. The typical method used to achieve high min-entropy of the output sequence is an entropy accumulation based on a hash function. This is grounded in the famous Leftover Hash Lemma, which guarantees a lower bound on the min-entropy of the output sequence. However, the hash function-based entropy accumulation has slow speed in general. For a practical perspective, we need a new efficient entropy accumulation with the theoretical background for the min-entropy of the output sequence. In this work, we obtain the theoretical bound for the min-entropy of the output random sequence through the very efficient entropy accumulation using only bitwise XOR operations, where the input sequences from the entropy source are independent. Moreover, we examine our theoretical results by applying them to the quantum random number generator that uses dark shot noise arising from image sensor pixels as its entropy source. Full article

Images taken in low-light situations frequently have a significant quality reduction. Taking care of these degradation problems in low-light images is essential for raising their visual quality and enhancing high-level visual task performance. However, because of the inherent information loss in dark images, conventional Retinex-based approaches for low-light image enhancement frequently fail to accomplish real denoising. This research introduces DEGANet, a revolutionary deep-learning framework created particularly for improving and denoising low-light images. To overcome these restrictions, DEGANet makes use of the strength of a Generative Adversarial Network (GAN). The Decom-Net, Enhance-Net, and an Adversarial Generative Network (GAN) are three linked subnets that make up our novel Retinex-based DEGANet architecture. The Decom-Net is in charge of separating the reflectance and illumination components from the input low-light image. This decomposition enables Enhance-Net to effectively enhance the illumination component, thereby improving the overall image quality. Due to the complicated noise patterns, fluctuating intensities, and intrinsic information loss in low-light images, denoising them presents a significant challenge. By incorporating a GAN into our architecture, DEGANet is able to effectively denoise and smooth the enhanced image as well as retrieve the original data and fill in the gaps, producing an output that is aesthetically beautiful while maintaining key features. Through a comprehensive set of studies, we demonstrate that DEGANet exceeds current state-of-the-art methods in both terms of image enhancement and denoising quality. Full article

This paper verified through experiments that change in ambient temperature are the main cause of dark output noise drift. Additionally, the impact of dark output noise drift in fiber optic spectrometers on emissivity measurements has been investigated in this work. Based on an improved fiber optic spectrometer, two methods were proposed for characterizing and correcting the dark output noise offset in fiber optic spectrometers: the mean correction scheme and the linear fitting correction scheme. Compared to the mean correction scheme, the linear fitting correction scheme is more effective in solving the problem of dark output noise drift. When the wavelength is greater than 1600 nm, the calibration relative error of silicon carbide (SIC) emissivity is less than 0.8% by the mean correction scheme, while the calibration relative error of silicon carbide emissivity is less than 0.62% by the linear fitting correction scheme. This work solves the problem of dark output noise drift in prolonged measurement based on fiber optic spectrometers, improving the accuracy and reliability of emissivity and quantitative radiation measurement. Full article

Images under low-light conditions suffer from noise, blurring, and low contrast, thus limiting the precise detection of objects. For this purpose, a novel method is introduced based on convolutional neural network (CNN) dual attention unit (DAU) and selective kernel feature synthesis (SKFS) that merges with the Retinex theory-based model for the enhancement of dark images under low-light conditions. The model mentioned in this paper is a multi-scale residual block made up of several essential components equivalent to an onward convolutional neural network with a VGG16 architecture and various Gaussian convolution kernels. In addition, backpropagation optimizes most of the parameters in this model, whereas the values in conventional models depend on an artificial environment. The model was constructed using simultaneous multi-resolution convolution and dual attention processes. We performed our experiment in the Tesla T4 GPU of Google Colab using the Customized Raw Image Dataset, College Image Dataset (CID), Extreme low-light denoising dataset (ELD), and ExDark dataset. In this approach, an extended set of features is set up to learn from several scales to incorporate contextual data. An extensive performance evaluation on the four above-mentioned standard image datasets showed that MSR-MIRNeT produced standard image enhancement and denoising results with a precision of 97.33%; additionally, the PSNR/SSIM result is 29.73/0.963 which is better than previously established models (MSR, MIRNet, etc.). Furthermore, the output of the proposed model (MSR-MIRNet) shows that this model can be implemented in medical image processing, such as detecting fine scars on pelvic bone segmentation imaging, enhancing contrast for tuberculosis analysis, and being beneficial for robotic visualization in dark environments. Full article

Ultraviolet-visible absorption spectroscopy is widely used to monitor water quality, and rapid optical signal detection is a key technology in the process of spectrum measurement. In this paper, an ultrafast spectrophotometer system that can achieve spectrum data acquisition in a single flash of the xenon lamp (within 200 ns) is introduced, and a real-time denoising method for the spectrum is implemented on a field programmable gate array (FPGA) to work cooperatively with the nanosecond spectrum acquisition system, in order to guarantee the quality of the spectrum signals without losing running speed. The hardware of the data acquisition and processing system are constructed on a Xilinx Spartan 6 FPGA chip and its peripheral circuit, including an analog to digital converter and a complementary metal-oxide-semiconductor transistor (CMOS) sensor’s diver circuit. An oversampling method that is suitable for the CMOS sensor’s output is proposed, which works on the CMOS sensor’s dark current noise and readout noise. Another moving-average filter method is designed adaptively, which works on the low-frequency component to filter out the residual spectrum noise of the spectrum signal. The implementation of the filter on the FPGA has been optimized by using a pipelined structure and dual high-speed random-access memory (RAM). As a result, the CMOS linear image sensor successfully captured the spectrum of xenon flash light at the readout clock frequency of 500 kHz and the processing manipulation to the full UV-Vis spectrum data was accomplished at a sub-microsecond speed performance. After the digital filter and oversampling technology were implemented, the coefficient of variation of the measurements reduced from 9.57% to 1.74%, while the signal noise ratio (SNR) of the absorption spectrum increased nine times, compared to the raw data of the CMOS sensor’s output. The tests towards different analyte samples were conducted, and the system shows good performance on distinguishing different concentrations of different analyte solutions on both ultra-violet and visible spectrum bands. The present work showcases the potential of the CMOS sensor’s technique for the fast detection of contaminated water containing nitrate and organic compounds. Full article

Photoacoustic imaging (PAI) combines optical contrast with ultrasound spatial resolution and can be obtained up to a depth of a few centimeters. Hand-held PAI systems using linear array usually operate in reflection mode using a dark-field illumination scheme, where the optical fiber output is attached to both sides of the elevation plane (short-axis) of the transducer. More recently, bright-field strategies where the optical illumination is coaxial with acoustic detection have been proposed to overcome some limitations of the standard dark-field approach. In this paper, a novel multiangle long-axis lateral illumination is proposed. Monte Carlo simulations were conducted to evaluate light delivery for three different illumination schemes: bright-field, standard dark-field, and long-axis lateral illumination. Long-axis lateral illumination showed remarkable improvement in light delivery for targets with a width smaller than the transducer lateral dimension. A prototype was developed to experimentally demonstrate the feasibility of the proposed approach. In this device, the fiber bundle terminal ends are attached to both sides of the transducer’s long-axis and the illumination angle of each fiber bundle can be independently controlled. The final PA image is obtained by the coherent sum of subframes acquired using different angles. The prototype was experimentally evaluated by taking images from a phantom, a mouse abdomen, forearm, and index finger of a volunteer. The system provided light delivery enhancement taking advantage of the geometry of the target, achieving sufficient signal-to-noise ratio at clinically relevant depths. Full article

In this paper, we propose an averaging pixel current adjustment technique for reducing fixed pattern noise (FPN) in the bolometer-type uncooled infrared image sensor. The averaging pixel current adjustment technique is composed of active pixel, reference pixel, and calibration circuit. Polysilicon resistors were used in each active pixel and reference pixel. Resistance deviation among active pixels integrated with the same resistance value cause FPN. The principle of the averaging pixel current adjustment technique for removing FPN is based on the subtraction of dark current of the active pixel from the dark current of the reference pixel. The subtracted current is converted into the voltage, which contains pixel calibration information. The calibration circuit is used to adjust the calibration current. After calibration, the nano-ampere current is output with small deviation. The proposed averaging pixel current adjustment technique is implemented by a chip composed of a pixel array, a calibration circuit, average current generators, and readout circuits. The chip was fabricated using a standard 0.35 μm CMOS process and its performance was evaluated. Full article

In free space optical communications, long-distance transmission leads to the attenuation of beacon light, where we adopt a quadrant detector (QD) to receive the weak signal. However, the background light interferes so strongly that the output signal-to-noise ratio (SNR) of QD is at a low level, which causes a decrease in accuracy of the direct detection method. This requires finding a new light spot detection method, so an improved detection method is proposed. Because the dark current noise and the background light noise are both white noise, we adopt a Kalman filter to estimate the real output of four electric signals of QD. Unfortunately, running these through an amplifier introduces some direct current (DC) offsets into the signals. In order to balance the effect of the DC offsets, we consider using the modulation method, where we employ a sine signal to modulate the intensity of the beacon light at the transmitting end, after which we can give an inverse gain to move the center of signals to near zero to eliminate the DC offsets when we calculate the data. In Kalman filtering, we use the peak values of the signals in every period after the analog to digital converter (ADC) as the elements of the measurement matrix. Experimental results show that even when QD output SNR is about −10 dB, the detection root-mean-square errors decrease by 51.5% using the improved detection method compared with the direct detection method. Moreover, Kalman filtering does not require a large amount of data, which means it works efficiently, can reduce the cost of hardware resources, and is available for the real-time calculation of spot position. Full article

In free space optical communication, a beacon light loses too much energy after a long-distance transmission and faces strong interference from background light. The beacon light illuminated on a quadrant detector (QD) is so weak that the output signal-to-noise ratio (SNR) of a QD is very low, which leads to a significant decrease in the accuracy of the direct position detection method. To solve this problem, an improved light spot position detecting method is proposed. Since the background light and the dark current noise are white noise, we could consider concentrating the energy of QD output signal at a certain frequency point to enhance the output SNR. Therefore, a cosine signal is used to modulate the intensity of a beacon light at the transmitting end. Then the QD output photocurrents are also cosine signals with the same frequency as the modulating signal. Putting the photocurrent signals into a cross-correlation operation with a reference signal, which is the same as the modulating signal, can enhance the QD output SNR at a certain frequency point. Unfortunately, the result of the classical cross-correlation is attenuated with increasing delay. It is hard to detect the amplitude of the classical cross-correlation result. So, we used cyclic cross-correlation to obtain a stable correlation result to detect its amplitude accurately. The experiment results show that even when the QD output SNR is less than −17 dB, the detection root-mean-square error of the proposed method is 0.0092 mm, which is a quarter of the direct position detection method. Moreover, this method only needs a small amount of data to accomplish the calculation and is especially suitable for real-time spot position detection. Full article
