Search Results (16)

A battery charger for solid-state lithium battery packs was developed and implemented. The power stage used a phase-shifted full-bridge converter integrated with a current-doubler rectifier and synchronous rectification. Dual voltage and current control loops were employed to enable constant-voltage and constant-current charging modes. To improve the lifespan of the output filter capacitor, the current-doubler rectifier was adopted to effectively reduce output current ripple. During the initial start-up phase, as the charger transitions from constant-voltage to constant-current output mode, the use of proportional–integral control in the voltage and current loop error amplifiers may cause current overshoot during the step-rising phase, primarily due to the integral action. Therefore, this study incorporated fuzzy control, proportional control, and proportional–integral control strategies into the current-loop error amplifier. This approach effectively reduced the current overshoot during the step-rising phase, preventing the charger from mistakenly triggering the overcurrent protection mode. The analysis and design considerations of the proposed circuit topology and control loop are presented. Experimental results agree with theoretical predictions, thereby confirming the validity of the proposed approach. Full article

A full-bridge DC–DC converter with structure exchange is proposed to simulate battery charging based on an electronic load. The full-bridge phase-shift converter (FBPSC) uses an external resonant inductor and phase-shift control on the primary side to realize zero voltage switching (ZVS) above medium load. However, the energy of the resonant inductor is not enough to carry away the energy of the parasitic capacitance on the switch at light load, leading to the inability of ZVS as well as the circulating current problem due to the long duration of the primary-side circulating current. Consequently, in order to conquer such problems mentioned above, the structure exchange, with only the control strategy changed from the phase-shift control to the two-transistor forward control, is presented to increase the light-load efficiency remarkably. Furthermore, the number of inductors is reduced by using the center-tap structure on the secondary side compared to the current-doubler structure. In addition, the synchronous rectifier on the secondary side is used to further improve the overall efficiency of the converter. Full article

The LLC resonant converter is widely recognized as an effective solution for achieving high efficiency in high-frequency operations. This is primarily due to its ability to perform zero-voltage switching (ZVS) on primary switches and zero-current switching (ZCS) on secondary rectifier switches. However, implementing the secondary rectifier of an LLC resonant converter often requires the use of jumpers on the PCB to construct circuit topologies such as the center-tap rectifier (CTR), full-bridge rectifier, and voltage-doubler rectifier (VDR). In conventional VDR configurations, the source voltage of the high-side FET fluctuates according to the switching operation of the primary switch. This fluctuation necessitates auxiliary windings or bootstrap circuits to provide a floating voltage source, adding significant complexity to gate drive circuits in high-power-density applications. This complexity poses a major barrier to the practical adoption of VDRs. To address these challenges, this paper proposes a novel rectification circuit based on the VDR topology, specifically designed for LLC resonant converters, offering simplified gate drive circuitry and improved suitability for high-power-density applications. Full article

In this paper, the proposal for the performance optimization of the wireless power transfer (WPT) system is given. The solution is based on the alternative configuration of the secondary-side rectifier. It is represented by a diode rectifier with a current doubler. Compared to the bridge rectifier, two diodes are replaced by the inductors. Initially, a system analysis was performed to investigate the electrical behavior and find the most optimal conditions referred to as terms of efficiency performance at nominal power. Due to this requirement, the rectifier inductors must be designed accordingly to meet this condition. The experimental verification was realized as well, while the proposed solution was compared to other common alternatives of the secondary-side rectification. The load sensitivity analysis in terms of efficiency performance was realized as well to observe the system behavior for a wide operation range. From the results, it is seen that the proposed alternative of the secondary-side rectification of the WPT system gives promising results in terms of high operating efficiency. Full article

Forward converters have been broadly used in the power supply industry due to their simplicity, worthy efficiency, and low cost. A novel prototype soft-switched zero-voltage and zero-current ZVZC PWM DC-DC power converter with low voltage/current stresses is introduced for telecommunication power feeding in this paper. A new two-switch interleaved forward converter circuit is introduced to minimalize current circulation with no supplementary auxiliary snubber circuits. This converter circuit includes some outstanding benefits such as reduced components, improved efficiency, high power density and economic circuit configurations for high power conditioning applications. The simple operation principle is demonstrated on the basis of steady-state analysis. Furthermore, the effective feasibility of the proposed circuit topology is evaluated and verified practically for a 500 W–100 kHz prototype breadboard. The operation principle and steady-state characteristics are demonstrated from a theoretical point of view. To verify the practical effectiveness of the proposed power converter, a 500 W–100 kHz prototype converter using ultrafast IGBTs is implemented for a distributed telecommunication energy plant. The studied soft-switching converter is evaluated in comparison with the previously-proposed PWM converters in terms of voltage, current stresses, and operating efficiency. Full article

This paper presents a multifunctional battery-free wireless sensing node (SN) designed to monitor physical parameters (e.g., temperature, humidity and resistivity) of reinforced concrete. The SN, which is intended to be embedded into a concrete cavity, is autonomous and can be wirelessly powered thanks to the wireless power transmission technique. Once enough energy is stored in a capacitor, the active components (sensor and transceiver) are supplied with the harvested power. The data from the sensor are then wirelessly transmitted via the Bluetooth Low Energy (BLE) technology in broadcasting mode to a device configured as an observer. The feature of energy harvesting (EH) is achieved thanks to an RF-to-DC converter (a rectifier) optimized for a low power input level. It is based on a voltage doubler topology with SMS7630-005LF Schottky diode optimized at −15 dBm input power and a load of 10 kΩ. The harvested DC power is then managed and boosted by a power management unit (PMU). The proposed system has the advantage of presenting two different power management units (PMUs) and two rectifiers working in different European Industrial, Scientific and Medical (ISM) frequency bands (868 MHz and 2.45 GHz) depending on the available power density. The PMU interfaces a storage capacitor to store the harvested power and then power the active components of the sensing node. The low power digital sensor HD2080 is selected to provide accurate humidity and temperature measurements. Resistivity measurement (not reported in this paper) can also be achieved through a current injection on the concrete probes. For wireless communications, the QN9080 system-on-chip (SoC) was chosen as a BLE transceiver thanks to its attractive features: a small package size and extremely low power consumption. For low power consumption, the SN is configured in broadcasting mode. The measured power consumption of the SN in a deep-sleep mode is 946 µJ for four advertising events (spaced at 250 ms maximum) after the functioning of sensors. It also includes voltage offset cancelling functionality for resistivity measurement. Far-field measurement operated in an anechoic chamber with the most efficient PMU (AEM30940) gives a first charging time of 48 s (with an empty capacitor) and recharge duration of 27 s for a complete measurement and data transmission cycle. Full article

Low-power energy harvesting has been demonstrated as a feasible alternative for the power supply of next-generation smart sensors and IoT end devices. In many cases, the output of kinetic energy harvesters is an alternating current (AC) requiring rectification in order to supply the electronic load. The rectifier design and selection can have a considerable influence on the energy harvesting system performance in terms of extracted output power and conversion losses. This paper presents a quantitative comparison of three passive rectifiers in a low-power, low-voltage electromagnetic energy harvesting sub-system, namely the full-wave bridge rectifier (FWR), the voltage doubler (VD), and the negative voltage converter rectifier (NVC). Based on a variable reluctance energy harvesting system, we investigate each of the rectifiers with respect to their performance and their effect on the overall energy extraction. We conduct experiments under the conditions of a low-speed rotational energy harvesting application with rotational speeds of 5 rpm to 20 rpm, and verify the experiments in an end-to-end energy harvesting evaluation. Two performance metrics—power conversion efficiency (PCE) and power extraction efficiency (PEE)—are obtained from the measurements to evaluate the performance of the system implementation adopting each of the rectifiers. The results show that the FWR with PEEs of 20% at 5 rpm to 40% at 20 rpm has a low performance in comparison to the VD (40–60%) and NVC (20–70%) rectifiers. The VD-based interface circuit demonstrates the best performance under low rotational speeds, whereas the NVC outperforms the VD at higher speeds (>18 rpm). Finally, the end-to-end system evaluation is conducted with a self-powered rpm sensing system, which demonstrates an improved performance with the VD rectifier implementation reaching the system’s maximum sampling rate (40 Hz) at a rotational speed of approximately 15.5 rpm. Full article

An improved high step-down DC-DC converter for charging the batteries in an electric vehicle application is proposed in this paper. It adopts the topology of the conventional full-bridge converter, which has a coupled inductor current-doubler rectifier as the secondary side of the transformer. In addition, four power switches are driven using a phase-shifting technique. The proposed converter can achieve a high step-down voltage with low-voltage stress on the rectifier diodes. In addition, the coupled inductor current-doubler rectifier of the secondary side can reduce the ripple current and losses of the secondary side to achieve high efficiency. Furthermore, the proposed converter can overcome the drawbacks of the conventional full-bridge converter, such as switching loss caused by high switching frequency, duty-cycle loss, voltage stress, and numerous components, and can increase the efficiency with the soft-switching technique. A 600 W laboratory prototype of the proposed converter was manufactured. The results of the experiments performed with the prototype proved the effectiveness and validated the use of the proposed converter for better charging of electric vehicles. Full article

A new battery charger, based on a multiphase resonant converter, for a high-capacity 48 V LiFePO₄ lithium-ion battery is presented. LiFePO₄ batteries are among the most widely used today and offer high energy efficiency, high safety performance, very good temperature behavior, and a long cycle life. An accurate control of the charging current is necessary to preserve the battery health. The design of the charger is presented in a tight correlation with a battery model based on experimental data obtained at the laboratory. With the aim of reducing conduction losses, the general analysis of the inverter stage obtained from the parallel connection of N class D LC_pC_s resonant inverters is carried out. The study provides criteria for proper selection of the transistors and diodes as well as the value of the DC-link voltage. The effect of the leakage inductance of the transformer on the resonant circuit is also evaluated, and a design solution to cancel it is proposed. The output stage is based on a multi-winding current-doubler rectifier. The converter is designed to operate in open-loop operation as an input voltage-dependent current source, but in closed-loop operation, it behaves as a voltage source with an inherent maximum output current limitation, which provides high reliability throughout the whole charging process. The curve of efficiency of the proposed charger exhibits a wide flat zone that includes light load conditions. Full article

Because traditional electronics cannot directly use the alternating output voltage and current provided by electric field energy harvesters, harvesting systems require additional regulating and conditioning circuits. In this field, this work presents a conditioning circuit, called serial switch-only rectifier (SSOR) for low-voltage electric field energy harvesting (EFEH) applications. The proposed approach consists of a tubular topology harvester mounted on the outer jacket of a 230 V three-wires electrical cable (neutral, ground, and phase), in which terminals are connected to SSOR. We compare SSOR performance with classic electronic approaches, such as a full-bridge rectifier and voltage doubler. Experimental findings showed that the gathered energy by a 1 m cylindrical harvester increased in approximately 73.3% using the SSOR as a power management circuit. Experimental findings showed that the gathered energy by a 1 m cylindrical harvester increase in approximately 73.3% using the SSOR as a power management circuit. This increase is principally due to the fact that a serial bidirectional switch disconnects the harvester from the rest of the management circuit, enhancing the charge collection process. Although simulated results disclosed that SSOR increased collected energy for smaller-scale harvesters (experimental tests obtained using a 10 cm cylindrical harvester), additional losses in bidirectional switch reduced its performance. In addition, we introduce a comprehensive analysis of EFEH systems based on SSOR according to the mains frequency for future power systems. Full article

A novel circuit topology for an on-board battery charger for plugged-in electric vehicles (PEVs) is presented in this paper. The proposed on-board battery charger is composed of three H-bridges on the primary side, a high-frequency transformer (HFT), and a current doubler circuit on the secondary side of the HFT. As part of an electric vehicle (EV) on-board charger, it is required to have a highly compact and efficient, lightweight, and isolated direct current (DC)–DC converter to enable battery charging through voltage/current regulation. In this work, performance characteristics of full-bridge phase-shift topology are analyzed and compared for EV charging applications. The current doubler with synchronous rectification topology is chosen due to its wider-range soft-switching availability over the full load range, and potential for a smaller and more compact size. The design employs a phase-shift full-bridge topology in the primary power stage. The current doubler with synchronous recitation is placed on the secondary. Over 92% of efficiency is achieved on the isolated charger. Design considerations for optimized zero-voltage transition are disused. Full article

This paper presents a resonant converter with the benefits of wide output voltage, wide soft switching characteristics for power devices and high circuit efficiency. Since the series resonant circuit is adopted on the primary side, the power switches are turned on under zero voltage switching and power diodes on the secondary side can be turned off under zero current switching. To overcome the drawback of narrow voltage operation range in the conventional resonant converter, full-bridge rectifier and voltage-doubler rectifier topologies are employed on the secondary side for low-voltage output and high-voltage output applications. Therefore, the voltage rating of power devices on the secondary side is clamped at output voltage, rather than two times output voltage, in the center-tapped rectifier circuit. Synchronous power switches are used on the secondary side to further reduce the conduction losses so that the circuit efficiency can be further improved. To verify the theoretical analysis and circuit performance, a laboratory prototype with 1 kW rated power was built and tested. Full article

A dc-dc converter with asymmetric pulse-width modulation is presented for medium voltage applications, such as three-phase ac-dc converters, dc microgrid systems, or dc traction systems. To overcome high voltage stress on primary side and high current rating on secondary side, three dc-dc circuits with primary-series secondary-parallel structure are employed in the proposed converter. Current doubler rectifiers are used on the secondary side to achieve low ripple current on output side. Asymmetric pulse-width modulation is adopted to realize soft switching operation for power switches for wide load current operation and achieve high circuit efficiency. Current balancing cells with magnetic component are used on the primary side to achieve current balance in each circuit cell. The voltage balance capacitors are also adopted on primary side to realize voltage balance of input split capacitors. Finally, the circuit performance is confirmed and verified from the experiments with a 1.44 kW prototype. Full article

It is widely accepted to examine and explain the functioning of the standard “Current Doubler Rectifier” as strictly symmetrical according to the electrical current through the two inductances. The present work challenges this consideration and proposes a new version of the electrical circuit diagram where the current symmetry is improved. The proposed circuit is called the “Improved Current Doubler Rectifier”. Full article

In this paper, a direct current (dc) converter with the abilities of bidirectional power transfer and soft switching characteristics is studied and implemented. The circuit schematic of the developed dc converter is built by a half-bridge converter and a center-tapped rectifier with synchronous rectifier. Under forward power transfer, a half-bridge circuit is controlled to regulate the low-voltage side at a stable value. For backward power transfer, a center-tapped rectifier with synchronous rectifier is regulated to control the high-voltage side at the desired voltage value, and the half-bridge circuit is operated as a voltage doubler rectifier. Active power devices are operated at zero-voltage switching using a series resonant technique on the high-voltage side with frequency modulation and inductive load operation. The practicability of the developed converter is established from experiments with a laboratory prototype circuit. Full article
