Jujubes have a beautiful taste, and high nutritional and economic value. The planting area of dwarf and densely planted jujubes is large and shows an increasing trend; however, the mechanization level and efficiency of fresh jujube harvesting are low. For this reason, our research group conducted a study on mechanical harvesting technology for fresh jujubes. A pneumatic jujube harvester was designed. This harvester is composed of a self-regulating picking mechanism, a telescopic conveying pipe, a negative pressure generator, a cleaning mechanism, a double-chamber collection box, a single-door shell, a control assembly, a generator, a towing mobile chassis, etc. During the harvest, the fresh jujubes on the branches are picked under the combined effect of the flexible squeezing of the picking roller and the suction force of the negative pressure air flow. They then enter the cleaning mechanism through the telescopic conveying pipe. Under the combined effect of the upper and lower baffles of the cleaning mechanism and the negative-pressure air flow, the fresh jujubes are separated from impurities such as jujube leaves and branches. The clean fresh jujubes fall into the collection box. We considered the damage rate of fresh jujubes, impurity rate, leakage rate, and harvesting efficiency as the indexes, and the negative-pressure suction wind speed, picking roller rotational speed, and the inclination angle of the upper and lower baffles of the cleaning and selection machinery as the test factors, and carried out the harvesting test of fresh jujubes. The test results show that when the negative-pressure suction wind speed was 25 m/s, the picking roller rotational speed was 31 r/min, and the inclination angles of the upper and lower baffle plates for cleaning and selecting were −19° and 19.5°, respectively, the breakage rate of fresh jujube harvesting was 0.90%, the rate of impurity was 1.54%, the rate of leakage was 2.59%, and the efficiency of harvesting was 73.37 kg/h, realizing the high-efficiency and low-loss harvesting of fresh jujubes. This study provides a reference for the research and development of fresh jujube mechanical harvesting technology and equipment. Full article

To address the issues of bulky structure and complex transmission systems in current transplanters, a compact, electric-driven automatic transplanter was designed. Using pepper plug seedlings as the test subject, this study investigated plug tray dimensions and planting patterns. According to the design requirement that the width of the single-row transplanter must be less than 62.5 cm, a three-dimensional transplanter model was constructed. The transplanter comprises a coaxially installed dual-layer seedling conveying device and a sector-expanding automatic seedling picking and depositing device. The structural dimensions, drive configurations, and driving forces of the transplanter were also determined. Finally, the circuit and pneumatic system were designed, and the transplanter was assembled. Both bench and field tests were conducted to select the optimal working parameters. The test results demonstrated that the seedling picking and depositing mechanism met the required operational efficiency. In static seedling picking and depositing tests, at three transplanting speeds of 120 plants/min, 160 plants/min, and 200 plants/min, the success rates of seedling picking and depositing were 100%, 100%, and 97.5%, respectively. In the field test, at three transplanting speeds of 80 plants/min, 100 plants/min, and 120 plants/min, the transplanting success rates were 94.17%, 90.83%, and 88.33%, respectively. These results illustrate that the compact, electric-driven seedling conveying and picking and depositing devices meet the operational demands of automatic transplanting, providing a reference for the miniaturization and electrification of transplanters. Full article

To address the issue of poor film–soil separation in traditional subsoil residual film recovery machines, which leads to recovered film containing excessive soil, a film–soil conveying and separation device was designed. By establishing a mechanical model for the balanced conveyance of the film–soil composite, the range of conveyor chain inclination angles enabling stable transport was determined. Using RecurDyn 2023 simulation software, a sensitivity analysis was conducted on the effects of vibrating wheel speed, vibrating wheel mounting distance, and conveyor chain inclination angle on vibration characteristics. This analysis revealed that vibrating wheel speed and mounting distance have a significant impact on the vibrating mechanism. Based on the DEM–MBD (Discrete Element Method—Multi-Body Dynamics) coupling approach, a discrete element simulation model was built for the film–soil vibrating conveyor device, residual film, and soil. Using the primary conveyor chain speed, vibrating wheel speed, and mounting distance as experimental factors, and soil content rate and film leakage rate as experimental indicators, single-factor tests and a three-factor, five-level orthogonal rotational composite design test were performed. The results showed that, at a primary conveyor chain speed of 1.61 m/s, a vibrating wheel speed of 186.2 r/min, and a mounting distance of 688.2 mm, the soil content rate was 18.11% and the film leakage rate was 7.61%. The film–soil conveying and separation process was also analyzed via simulation. Field validation tests using the optimal parameter combination yielded relative errors of 3.43% and 5.51%, respectively, demonstrating effective film–soil separation. This research provides a theoretical foundation and equipment support for addressing residual film pollution in the cultivated layer of Xinjiang region. Full article

To address poor film pickup, incomplete soil–film separation, and high soil content in conventional residual film recovery machines, this study designed a belt-tooth type residual film recovery machine. Its core component integrates flexible belts with nail-teeth, providing both overload protection and efficient conveying. EDEM simulations compared film pickup performance across tooth profiles, identifying an optimal structure. Based on the kinematics and mechanical properties of residual film, a film removal mechanism and packing device were designed, incorporating partitioned packing belts to reduce soil content rate in the collected film. Using Box–Behnken experimental design, response surface methodology analyzed the effects of machine forward speed, film-lifting tooth penetration depth, and pickup belt inclination angle. Key findings show: forward speed, belt angle, and tooth depth (descending order) primarily influence recovery rate; while tooth depth, belt angle, and forward speed primarily affect soil content rate. Multi-objective optimization in Design-Expert determined optimal parameters: 5.2 km/h speed, 44 mm tooth depth, and 75° belt angle. Field validation achieved a 90.15% recovery rate and 5.86% soil content rate. Relative errors below 2.73% confirmed the regression model’s reliability. Compared with common models, the recovery rate has increased slightly, while the soil content rate has decreased by more than 4%, meeting the technical requirements for resource recovery of residual plastic film. Full article

This study investigates the interaction between airflow and low-density bulk particles within vertical screw conveyors and examines its impact on conveying performance. A combined simulation approach integrating the Discrete Element Method and Computational Fluid Dynamics was employed to model both single-phase particle flow and gas–solid two-phase flow. A periodic model was developed based on the structural characteristics of the conveyor. Particle motion dynamics under both single-phase and coupled two-phase conditions were analyzed using EDEM and coupled Fluent-EDEM simulations. The effects of key operational parameters, including screw speed, filling rate, and helix angle, on mass flow rate were systematically evaluated. A comprehensive performance index was established to quantify conveying efficiency, and its validity was confirmed through analysis of variance on the regression model. Finally, the response surface methodology was applied to optimize parameters and determine the optimal combination of screw speed and filling rate to enhance mass flow efficiency. The results indicate that the gas–solid two-phase flow model provides a more accurate representation of real-world conveying dynamics. Future research may extend the model to accommodate more complex material conditions. Full article

Objectives: The objective of this study was to assess the potential existence of shared semantics between linguistic (e.g., reading a sentence) and numerical information (e.g., performing an arithmetic operation). Methods: To evaluate this proposal, we devised a paradigm with blocks of two trials. In the first trial, participants were presented with sentences containing verbs that conveyed either an increase (e.g., “to give”) or a decrease (e.g., “to take away”). In the subsequent trial, participants were required to perform additions (e.g., 61 + 1) and subtractions (e.g., 52 − 4). We hypothesized that addition and subtraction would exhibit shared semantic processing with sentences denoting increase and decrease, respectively, resulting in cross-domain effects. Results: Participants exhibited enhanced speed and accuracy in addition problem-solving when preceded by increase sentences, whereas subtractions were solved with higher accuracy when preceded by decrease sentences. Moreover, these effects were found to be subject to modulation by the complexity of the numerical operation. Conclusions: The findings of this study support the hypothesis that there is a shared semantic processing between language and mathematics. Full article

The mismatch between the conveying capacity of sugarcane harvesters and the feeding amount is the main cause of blockages in the conveying system. To address this issue, this paper proposes a control system that integrates machine vision technology with a programmable logic controller (PLC). First, the YOLOv8n segmentation algorithm is combined with depth data to detect the cane intake amount. Then, through interactive experiments, the relationship between roller speeds and feeding amount is explored, and PLC control rules are established. The experimental results show that the system has an average detection error of 5.69%, an overall response time of 2 s, and the blockage rate at the maximum feeding amount is reduced from 17.76% (without control) to 4.32% (with control). Full article

Rural domestic waste slag is often used to prepare organic fertilizer, thereby improving the environment and saving resources. The mixing of the raw materials and fermentation bacteria is key to the preparation of organic fertilizers. In the organic fertilizer continuous conveying device designed in this study, a paddle was substituted for a screw blade for transporting the material to improve the mixing performance. A discrete element method (DEM) model was established for the device. The influences of the paddle rotational speed n and paddle angle α were studied. The simulation results showed that mixing performance was improved when the paddle angle α was 45° and the paddle rotational speed n was 75 rpm, with an RSD of 15.96%. The larger the paddle rotational speed n, the larger the average normal contact force, and the smaller the influence of the paddle angle α. In addition, the paddle rotational speed n and paddle angle α could affect the speed of the particles in all directions in the device. The trajectory of a single particle in the device was analyzed, and it was found that changing the paddle parameters could improve the path length and improve the mixing performance. The research results lay the foundation for designing reasonable paddle parameters. Full article

The operation of electric rice reaper binders in hilly and mountainous areas currently faces the challenges of poor conveying efficiency and high harvest losses caused by the large dispersion of rice stem posture angles. In this study, we propose a multiparameter collaborative optimization method for improving header structure in an effort to address these challenges. First, key parameters influencing lifting performance and their operational ranges were determined based on a theoretical analysis of the stem-lifting mechanism’s kinematic characteristics. A dynamic model simulating the header’s lifting process was developed by using the ADAMS multibody dynamics platform. Subsequently, we designed a quadratic regression orthogonal rotation combination experiment with three factors, i.e., the stem-lifting speed ratio coefficient, the cutter installation position, and the header tilt angle, using the stem-lifting angle as the evaluation metric. The variance in the experimental data was analyzed with Design-Expert 13.0, and response surface methodology (RSM) was applied to elucidate the parameter interaction effects. The optimal parameter combination was identified as a speed ratio coefficient of 2.14, a cutter installation position of 258.79 mm, and a header tilt angle of 62.63°, yielding a theoretical stem-lifting angle of 2.36°. Field validation tests demonstrated an actual stem-lifting angle of 2.44° (relative error: 3.39%) and a header loss rate of 0.59%, representing a 49.6% reduction compared with the pre-optimized design. These results confirm that the optimized header satisfies operational requirements for hilly terrain rice harvesting, providing both theoretical guidance and technical advancements for the design of low-loss harvesting machinery. Full article

Due to its good adaptability, the pneumatic conveying feeder has been widely developed and applied in recirculating aquaculture systems (RASs). Its important performances include the integrity of feed pellets and the feeding accuracy. The aim of this study was to design and evaluate a feed distribution device for a small-scale pneumatic conveying feeder. A cylindrical hopper with a feed capacity of 4 kg and a feed distribution device were designed based on theoretical calculations. The motion and force of feed pellets during the distribution process were studied using the discrete element method (DEM) simulation to evaluate the integrity of feed pellets. Additionally, to evaluate feeding accuracy, the effect of discharge disk rotational speed on single feeding quantity was studied using DEM simulations and experimental validations, as well as the effect of the proportion of feed pellets in the hopper. Results showed that the maximum force on feed pellets was 1.25 N during the distribution process. It was inferred that the feed pellets can be distributed without breaking based on their shear strength. When the rotational speed of the discharge disk was set at a maximum of 28 rpm, the relative error of single feeding quantity between simulation and actual experiments was 4.43%, and the single feeding mass was 62.74 g, suggesting an optimal speed. In addition, the average single feeding quantity ranged from 262 to 301 feed pellets at the different proportions of feed pellets in the hopper, and its coefficient of variation was 12.46%, which generally meets the distribution requirements of the small-scale feeder. This study provides a feed distribution device for a small-scale pneumatic conveying feeder and offers references for the relevant analysis of DEM simulation. Full article

This study analyses the dynamic impact between winter wheat grains (‘Memory’ cultivar) and a flat metal surface under normal collisions. Four moisture levels (7%, 10%, 13% and 16%) and impact velocities from 1.0 to 4.5 m·s⁻¹ were chosen to reflect conditions in agricultural machinery. A custom test rig—comprising a transparent drop guide, a high-sensitivity piezoelectric force sensor and a high-speed camera—recorded grain velocity by vision techniques and contact force at 1 MHz. Force–time curves were examined to evaluate restitution velocity, the coefficient of restitution (CoR) and the effect of moisture on elastic–plastic deformation. CoR decreased non-linearly as impact velocity rose from 1.0 to 5.0 m·s⁻¹, and moisture content increased from 7% to 16%, falling from ≈ 0.60 to 0.40–0.50. Grains with higher moisture struck at higher velocities showed greater plastic deformation, longer contact times and intensified energy dissipation, making them more susceptible to internal damage. The data provide validated reference values for discrete element method (DEM) calibration and will assist engineers in designing grain-handling equipment that minimises mechanical damage during harvesting, conveying and processing. Full article

In seeding operations, fermented seeds with weak surface energy tend to experience problems such as adhesion, seed leakage, and clogging on the seeder’s end. To improve seed distribution uniformity, a three-stage spiral seeding device with “seed filling, transport, and dispersing” functions was designed. Kinematic and dynamic models of fermented seeds under spiral conveying conditions were developed to analyze the motion and force characteristics of the seeds under various working states. A discrete element method (DEM) and multi-body dynamics (MBD) coupled simulation model was established, along with a comprehensive evaluation system for seed distribution uniformity and seeding effectiveness. The influence of spiral speed, pitch, and forward speed of the seeding operation on seed dispersion uniformity and operational efficiency was studied, and optimal structural and operational parameters for the spiral seeder were selected. A prototype of the spiral seeding device was fabricated, and field seeding tests were conducted. The results showed that when the seeder’s rotational speed was 12 r/min, the pitch was 63 mm, and the forward speed of seeder was 3.5 km/h, the seed distribution uniformity index reached 84.53%, with excellent seeding effectiveness and a comprehensive evaluation index of 92.26%. The field application demonstrated good performance, significantly improving both the operational reliability and efficiency of the spiral seeding device. Full article

After undergoing peeling-machine operations, skinned garlic cloves affect subsequent processing, and their manual removal is harmful to health. In this paper, an intelligent garlic-clove-removal test bench was designed, which mainly included a hopper, lifter, vibration conveyor, conveyor belt, visual system, removal robot, control cabinet, frame, etc. A technical method based on machine vision technology to distinguish whether or not garlic cloves had a skin was explored to ensure that the test bench could complete the recognition of the skinned garlic cloves, and to check that the test bench could also complete the removal of skinned garlic cloves. Tests were carried out to check the success rate of machine vision and the removal robot, and to optimize the parameters of the test bench. The results showed that the average success rate of machine vision was 99.15%, and the average success rate of the removal robot was 99.13%. The results also showed that the order of the three factors influence index was the conveying speed, the conveying volume, and the removal period. The regression analysis showed that when the conveying speed was 0.1 m·s⁻¹, the grasping period was 1.725 s, the conveying volume was 104.4 kg·h⁻¹, the qualified rate of the finished product was 97.15%, and the verification test result was 97.02%, which had no significant difference from the analysis result. The research results of this paper are conducive to the development of intelligent detection technology of garlic cloves, and to the development of garlic-planting technology and deep processing technology. Full article

Aiming at addressing the problems that step-by-step sugarcane defoliation equipment cannot control, including the feeding amount of sugarcane, which is prone to clogging and needs to be fed manually, a sorting and conveying device for the front end of defoliation equipment was designed. A simulation model was created using ADAMS 2020 software to examine the impact of the cane collection plate’s inclination angle and the sprocket wheel’s rotational speed on the percentage of sorting three canes in a one-factor test. A two-factor three-level test was conducted by choosing an inclination angle of 25° to 35° and a sprocket speed of 24 to 28 r/min. According to the ANOVA results, the percentage of sorting three canes was significantly impacted by the sprocket’s rotational speed, the inclination angle of the cane collection plate, and the interaction between the two variables. Based on the interaction effect study, the best combination to affect the percentage of sorting three canes is a sprocket rotational speed of 24 r/min and a collection plate inclination angle of 35°. Finally, a physical prototype test validated the simulation data, and the results revealed that the percentage of sorting three canes in the physical prototype is 80.56%, with a relative inaccuracy of 8.4%. Full article

To address the issue of the single-crop adaptability of current head-forming leafy vegetable harvesters in China—which limits their ability to harvest multiple vegetable varieties—a universal cabbage–Chinese cabbage harvesting platform was designed. This design was based on the statistical analysis of the physical and planting parameters of major cabbage and Chinese cabbage varieties in Jiangsu and Zhejiang provinces. The harvesting platform adopts a modular design, enabling the harvesting of both Chinese cabbage and cabbage by replacing specific components and adjusting relevant parameters. Through the theoretical analysis of key components, the specific parameters of each part were determined, and a soil-trough harvesting test was conducted. The results of the Chinese cabbage harvesting test showed that at a forward speed of 1 km·h⁻¹ and a conveyor belt speed of 60 RPM, the platform achieved optimal performance, with an extraction success rate of 86.7%, a clamping and conveying success rate of 92.3%, and an operational damage rate of 6.7%. The cabbage soil-trough harvesting test results indicated that when the extraction roller speed was 100 RPM, the conveyor belt speed was 60 RPM, and the forward speed was 1 km·h⁻¹, the extraction and feeding success rate reached 93.3%, the conveying success rate was 100%, and the operational loss rate was 6.7%, representing the best overall performance. This study provides theoretical support and references for the design of universal harvesters for head-forming leafy vegetables. Full article
