Search Results (48)

With the rapid development of electrified railways in high-altitude regions, section insulators in catenary systems frequently experience gap breakdown and surface flashover under low atmospheric pressure conditions, posing serious threats to safe train operation. This paper investigates the discharge mechanisms of section insulators in high-altitude environments and conducts research on discharge characteristics under extremely non-uniform electric fields, along with structural optimization. First, the physical mechanisms of gap discharge and surface flashover in section insulators are analyzed. A three-dimensional electric field simulation model of the section insulator is established, and numerical analysis is performed to reveal the electric field distribution characteristics. The results indicate that the electric field is predominantly concentrated at the junction between metal electrodes and insulators, as well as at the tip of the arcing horn. The local maximum field strength reaches 3.84 × 10⁵ V/m, exceeding the corona inception field strength of air, which readily induces discharge. Subsequently, power frequency and lightning impulse discharge tests are conducted in both plain region and regions at an altitude of 4300 m. The results show that under high-altitude conditions, the power frequency breakdown voltage decreases by 28%, and the 50% lightning impulse breakdown voltage decreases by 42%. The discharge voltages under standard atmospheric conditions are obtained through correction. Finally, optimization schemes involving arcing horn structural modification and surface coating application are proposed. Adjusting the arcing horn angle to 55° and adding a grading ring structure with a radius of 70 mm reduces the local maximum field strength by 26%. After applying an RTV insulating coating, the field strength at the junction decreases by 35.9%, effectively enhancing the insulation performance of section insulators in high-altitude regions. Full article

Z-cut lithium niobate single crystal demonstrates considerable promise for contact-based ultrasonic nondestructive testing and structural health monitoring (SHM) transducers due to its high piezoelectric coefficients, strong electromechanical coupling capability, and environmentally friendly lead-free composition. As a simulation-based theoretical exploration, this study systematically investigates the impact of gap spacing and electrode width in concentric ring configurations on the resonant characteristics and pulse-echo response of ultrasonic transducers by establishing a parametrized finite element model. Numerical simulations reveal that electrode geometry plays a critical role in determining both the effective electromechanical coupling coefficient and echo signal strength. Optimizing the electrode ring width achieved an effective electromechanical coupling coefficient ($k_{\mathit{eff}}$) of 35.2%, while systematic enlargement of the electrode gap further enhanced this value to 50.8%. The study also demonstrates that optimized ring width and adjusted electrode spacing increased the echo signal’s peak-to-peak amplitude ($V_{pp}$) by factors of 4.94 and 2.03, respectively, compared to the poorest-performing configuration within each parameter group. This study establishes that precise design of concentric electrode configurations serves as an effective strategy for tuning lithium niobate ultrasonic transducer characteristics, providing critical design guidelines for developing high-performance ultrasonic transducers for solid medium coupling. Full article

(1) Background: Understanding neural dynamics during human movement is a core neuroscience objective, yet there are fundamental challenges to the collection of high-fidelity neuroelectric signals during motion. We investigated the effects of electroencephalography (EEG) electrode design for cleaning high-density EEG, using an electrical testbed that mimicked the human head. (2) Methods: We used a 60-channel high-density array of tripolar concentric ring electrodes and conventional disk electrodes to compare the recovery of simulated brainwave activity in the presence of electrical neck muscle artifacts during walking. Simulated brainwave activity consisted of randomly occurring sinusoidal bursts with unique frequency content within human EEG spectral bands (5–37 Hz). Electrical neck muscle activity was recorded from a human subject during walking and broadcast into the head phantom device at scaled surface recording amplitudes (0× 0.5× 0.67×, 1×, 1.5×, 2×). We compared the number and spatial distribution of detected neural sources among electrode channels based on spectral power. (3) Results: At low muscle activation amplitudes, conventional electrodes identified more spectral power peaks (p ≤ 0.01) among more electrodes (p < 0.05) compared to tripolar concentric ring electrodes, indicating poorer spatial selectivity. At greater muscle artifact amplitudes, conventional electrodes identified fewer neural spectral power peaks (p < 0.05) with lesser localization accuracy (p < 0.05) compared to tripolar concentric ring electrodes. (4) Conclusions: We identified improved myoelectric artifact removal from tripolar concentric ring electrode recordings compared to conventional electrodes, offering a promising approach for recovering high-fidelity electrocortical activity from human subjects during locomotion. Full article

Environmental problems arising from conventional production models have posed a significant challenge in the search for renewable sources as raw materials for the production of everyday chemical compounds through more sustainable alternatives. The objective of the present work was the electrochemical synthesis of organic acids from the liquid of the natural and technical cashew nut shell (CNSLn and CNSLt), employing chronopotentiometry using a potentiostat and a graphite working electrode. Two concentrations (0.01–0.1% v/v) of CNSLn and CNSLt, two concentrations of NaOH as supporting electrolyte (0.125–2 M), and two current densities (40–60 mA/cm²) were tested in the experiments. Organic acids were detected and quantified by HPLC. To characterize the redox processes occurring in the constituents of CNSL, spectroelectrochemical analysis (FTIR–cyclic voltammetry), FTIR, and chronoamperometry were performed. The maximum concentrations obtained in the treatments were: acetic acid (828.86 mg/L), lactic acid (531.78 mg/L), and formic acid (305.4 mg/L), while other acids present in lower concentrations included oxalic, propionic, citric, and malonic acids. Voltammetry characterizations showed three irreversible oxidation processes in the anodic wave during the first cycle, indicating that the first process involved the formation of the phenoxy radical, the second process the formation of hydroquinones and benzoquinones, and the third process the cleavage of the aromatic ring and the aliphatic chain to form the organic acids. Furthermore, another oxidation pathway was observed, consisting of a fourth process in the second voltammetry cycle, corresponding to the nucleation of the phenoxy radical, evidenced as the formation of the C–O–C bond visible at 1050 cm⁻¹ in the infrared spectrum. From this route, a polymer was formed on the electrode surface, which limited the yield of organic acid synthesis. Finally, this research provides new insights in the field of electrochemistry, specifically in the synthesis of organic acids from CNSL as a renewable feedstock, with the novelty being the production of oxalic, propionic, citric, and malonic acids. Full article

Amitriptyline (AMT), a widely prescribed antidepressant, and its metabolites have emerged as significant environmental contaminants, posing substantial risks to aquatic organisms and human health. Systematic and in-depth investigations into advanced anode materials, coupled with a profound elucidation of their electrochemical mechanisms, are imperative for the development of efficacious technologies for AMT removal. In this study, a series of amorphous carbon-encapsulated zinc oxide (C@ZnO) modified anodes were systematically synthesized and incorporated into a persulfate-based electrochemical system (CZ-PS) to comprehensively elucidate the catalytic mechanisms and mass transfer efficiencies governing the degradation of AMT via electroperoxidation. Notably, the CZ-PS system achieved a 97.5% degradation for 5.0 mg/L AMT within 120 min under optimized conditions (200 C@ZnO electrode, pH 7.0, current density 20 mA/cm², PS concentration 0.5 mM), significantly outperforming the single PS system (37.8%) or the pure electrocatalytic system. Quenching experiments and EPR analysis confirmed hydroxyl radicals (•OH) and sulfate radicals (SO₄•⁻) as the dominant reactive species. Both acidic and neutral pH conditions were demonstrated to favorably enhance the electrocatalytic degradation efficiency by improving adsorption performance and inhibiting •OH decomposition. The system retained >90% degradation efficiency after 5 electrode cycles. Three degradation pathways and 13 intermediates were identified via UPLC–MS/MS analysis, including side-chain demethylation and oxidative ring-opening of the seven-membered ring to form aldehyde/carboxylic acid compounds, ultimately mineralizing into CO₂ and H₂O. It demonstrates strong engineering potential and provides a green, high-efficiency strategy for antibiotic wastewater treatment. Full article

The presence of acetaminophen (ACTP) in aquatic environments has become a significant concern due to its environmental persistence and the potential formation of toxic transformation products. This study systematically compares the performance of three electrochemical advanced oxidation processes (EAOPs), electro-oxidation (EO), electro-Fenton (EF), and solar photo-electro-Fenton (SPEF), for the degradation and mineralization of ACTP in aqueous media using boron-doped diamond (BDD) electrodes. Reactions were conducted under varying operational parameters, including current densities (15–60 mA cm⁻²), initial ACTP concentrations (10–30 mg L⁻¹), and Fe²⁺ dosages. In the SPEF system, natural sunlight was utilized as the source of UV-A irradiation (30–35 W m⁻²). Among the evaluated processes, SPEF exhibited the highest degradation efficiency, achieving up to 97% ACTP removal and 78% chemical oxygen demand (COD) reduction within 90 min. High-performance liquid chromatography (HPLC) analysis identified phenol and catechol as major intermediates, suggesting a degradation pathway involving hydroxylation, aromatic ring cleavage, and subsequent oxidation into low-molecular-weight carboxylic acids. Kinetic modeling revealed pseudo-first-order behavior, with a maximum rate constant of 0.0865 min⁻¹ under optimized conditions determined via Box–Behnken experimental design. Additionally, SPEF demonstrated enhanced energy efficiency (~0.052 kWh gCOD⁻¹) and improved oxidant regeneration under solar radiation, highlighting its potential as an environmentally friendly and cost-effective alternative for pharmaceutical wastewater treatment. These results support the implementation of SPEF as a sustainable strategy for mitigating the environmental impact of emerging contaminants, especially in regions with high solar availability and limited technological resources. Full article

Laboratory data from in-cell tests at and near open circuit potentials (OCV) and ex-situ H₂O₂ vapor exposure tests are used to develop a fluoride emission rate (FER) model for a state-of-the-art 12-µm thin, low equivalent weight, long-chain perfluorosulfonic acid (PFSA) ionomer membrane that is mechanically reinforced with expanded PTFE and chemically stabilized with 2 mol% cerium as an anti-oxidant. The anode FER at OCV linearly correlates with O₂ crossover from the cathode and the high yield of H₂O₂ at anode potentials, as observed in rotating ring disk electrode (RRDE) studies. The cathode FER may be linked to the energetic formation of reactive hydroxyl radicals (·OH) from the decomposition of H₂O₂ produced as an intermediate in the two-electron ORR pathway at high cathode potentials. Both anode and cathode FERs are significantly enhanced at low relative humidity and high temperatures. The modeled FER is strongly influenced by the gradients in water activity and cerium concentration that develops in operating fuel cells. Membrane stability maps are constructed to illustrate the relationship between the cell voltage, temperature, and relative humidity for FER thresholds that define H₂ crossover failure by chemical degradation over a specified lifetime. Full article

The detection of adrenaline (Adr) is essential for monitoring physiological and clinical conditions, including stress response, cardiovascular health, and neurological disorders. We present a novel glass-nanopipet electrode sensor based on a non-redox ion-transfer approach using ion transfer across two immiscible electrolyte solutions (ITIES). Two ionophores, dibenzo-24-crown-8 ether (DB24C8) and dibenzo-18-crown-6 ether (DB18C6), were evaluated for their ability to facilitate Adr transfer across aqueous/dichloroethane interfaces. Among these, DB24C8 demonstrated superior stability, attributed to its larger ring size and stronger complexation with Adr. We systematically studied Adr transfer in various media, including KCl, DI water, Millipore DI water, and Tris buffer, and constructed calibration curves based on peak potential shifts that follow a power-law relationship with Adr concentration. The sensor achieved a detection limit of 5 pM in Tris buffer using DB24C8 and 50 pM with DB18C6, both significantly lower than the physiological concentration of Adr. Furthermore, the effects of pH and ionic strength on the peak shifts were analyzed, revealing that pH changes had a more substantial impact compared to ionic strength variations. Importantly, while DB24C8 and DB18C6 are known to facilitate the transfer of other cations, such as potassium and calcium, our findings confirm that these cation transfers do not interfere with Adr detection. This innovative ITIES-based sensing platform offers ease of fabrication, robustness, and excellent potential for real-time, in vivo applications. It represents a significant advancement in electrochemical detection technologies, paving the way for practical applications in clinical and physiological settings. Full article

In the present study, synthesis, conformational behavior, host–guest complex formation, and electrochemical properties of novel 6-substituted-2-ureido-4-ferrocenylpyrimidines were explored. A comprehensive NMR spectroscopic investigation was carried out to confirm the structure and conformational equilibrium of the ureidopyrimidines through studying the temperature- and concentration dependence of NMR spectra. Low-temperature NMR measurements were used to clarify structural changes inflicted by a 2,6-diaminopyridine guest. Association constant (K_assoc) values of host–guest complexes were calculated based on low-temperature titrations. It was shown that the introduction of a pyridin-2-yl substituent in the pyrimidine ring in host 10 induced a considerable change not only in the conformational equilibrium of the host itself but also in that of the host–guest complex. Geometries and relative stabilities of the conformers of host 10 as well as its host–guest complexes were determined by quantum chemical calculations. Electrochemical behavior of ureidopyrimidine hosts and host–guest complexes was investigated by cyclic voltammetry (CV) and linear sweep voltammetry (LSV) measurements. Two ureidopyrimidine derivatives were immobilized on the surface of spectral graphite electrodes, and their electrochemical response on the addition of 2,6-diaminopyridine was compared. These results also supported the importance of the pyridin-2-yl substituent in the efficient sensing of the guest. Full article

Electroencephalography (EEG) remains pivotal in neuroscience for its non-invasive exploration of brain activity, yet traditional electrodes are plagued with artifacts and the application of conductive paste poses practical challenges. Tripolar concentric ring electrode (TCRE) sensors used for EEG (tEEG) attenuate artifacts automatically, improving the signal quality. Hydrogel tapes offer a promising alternative to conductive paste, providing mess-free application and reliable electrode–skin contact in locations without hair. Since the electrodes of the TCRE sensors are only 1.0 mm apart, the impedance of the skin-to-electrode impedance-matching medium is critical. This study evaluates four hydrogel tapes’ efficacies in EEG electrode application, comparing impedance and alpha wave characteristics. Healthy adult participants underwent tEEG recordings using different tapes. The results highlight varying impedances and successful alpha wave detection despite increased tape-induced impedance. MATLAB’s EEGLab facilitated signal processing. This study underscores hydrogel tapes’ potential as a convenient and effective alternative to traditional paste, enriching tEEG research methodologies. Two of the conductive hydrogel tapes had significantly higher alpha wave power than the other tapes, but were never significantly lower. Full article

Ultrasonic focusing transducers have broad prospects in advanced ultrasonic non-destructive testing fields. However, conventional focusing methods that use acoustic concave lenses can disrupt the acoustic impedance matching condition, thereby adversely affecting the sensitivity of the transducers. In this paper, an active focusing planar ultrasonic transducer is designed and presented to achieve a focusing effect with a higher sensitivity. An electrode pattern consisting of multiple concentric rings is designed, which is inspired by the structure of Fresnel Zone Plates (FZP). The structural parameters are optimized using finite element simulation methods. A prototype of the transducer is manufactured with electrode patterns made of conductive silver paste using silk screen-printing technology. Conventional focusing transducers using an acoustic lens and an FZP baffle are also manufactured, and their focusing performances are comparatively tested. The experimental results show that our novel transducer has a focal length of 16 mm and a center frequency of 1.16 MHz, and that the sensitivity is improved by 23.3% compared with the conventional focusing transducers. This research provides a new approach for the design of focusing transducers. Full article

This paper is aimed at proposing a calculation model for the ground resistance of a grounding scheme servicing a high-voltage direct-current converter station. The method is based on the equivalence of current conduction and electric field from the grounding scheme through the surrounding medium. The grounding scheme is composed of three concentric ring electrodes supported by two horizontal conductors and eight vertical rods. The calculated ground resistance is $4.8 \Omega$ against the experimental value of $5 \Omega$ with an error of $4.2\%$. The calculated ground resistance value agrees reasonably well with that of $4.7 \Omega$ as obtained using CYMGRD software (version 7.0). The calculated surface-potential values over the ground surface agreed reasonably well with those measured experimentally, with an average deviation not exceeding $6.5\%$. This study is designed to investigate how ground resistance is decreased by the increase in the scheme parameters, including the rods’ diameter and length, as well as the radius of the inner and outer rings. The dependency of the ground resistance on the soil type is also investigated. Full article

We present a novel and easy approach using a silicon-based impedance chip to determine the concentration of the given aqueous buffer solution. An accurate determination of the post-dilution concentration of the buffers is necessary for ensuring optimal buffer capacity, pH stability, and to assess solution reproducibility. In this study, we focused on phosphate buffer as the test liquid to achieve precise post-dilution concentration determinations. The impedance chip consisting of a top gold ring electrode, where a test volume of 20 μL to 30 μL of phosphate buffer was introduced for impedance measurements within the frequency range of 40 Hz to 1 MHz. For impedance investigation, we used phosphate buffers with three different pH values, and the impedance was measured after diluting the phosphate buffers to a concentration of 1.00 M, 0.75 M, 0.50 M, 0.25 M, 0.10 M, 0.05 M, and 0.01 M. In order to analyze the distinctive changes in the measured impedance, an equivalent circuit was proposed and modeled. From the impedance modeling, we report that the circuit parameter R_Au/Si showed exponential dependence on the concentration of phosphate buffer and no dependence on the pH values of the phosphate buffer and on the added volume inside the ring electrode. The proposed silicon-based impedance chip is quick and uses reduced liquid volume for post-dilution concentration measurements of buffers and has perspective applications in the pharmaceutical and biological domains for regulating, monitoring, and quality control of the buffers. Full article

In this work, a conductive hydrogel was successfully synthesized, taking advantage of the high number density of active amino and hydroxyl groups in carboxymethyl chitosan and sodium carboxymethyl cellulose. These biopolymers were effectively coupled via hydrogen bonding with the nitrogen atoms of the heterocyclic rings of conductive polypyrrole. The inclusion of another biobased polymer, sodium lignosulfonate (LS), was effective to achieve highly efficient adsorption and in-situ reduction of silver ions, leading to silver nanoparticles that were embedded in the hydrogel network and used to further improve the electro-catalytic efficiency of the system. Doping of the system in the pre-gelled state led to hydrogels that could be easily attached to the electrodes. The as-prepared silver nanoparticle-embedded conductive hydrogel electrode exhibited excellent electro-catalytic activity towards hydroquinone (HQ) present in a buffer solution. At the optimum conditions, the oxidation current density peak of HQ was linear over the 0.1–100 μM concentration range, with a detection limit as low as 0.12 μM (signal-to-noise of 3). The relative standard deviation of the anodic peak current intensity was 1.37% for eight different electrodes. After one week of storage in a 0.1 M Tris-HCl buffer solution at 4 °C, the anodic peak current intensity was 93.4% of the initial current intensity. In addition, this sensor showed no interference activity, while the addition of 30 μM CC, RS, or 1 mM of different inorganic ions does not have a significant impact on the test results, enabling HQ quantification in actual water samples. Full article

In this paper, we present an electric field analysis for the optimal structural design of lightning rods for high performance with a charge transfer system (CTS). In the case of a conventional rod that is produced with an empirical design and structure without quantitative data because the design is structurally very simple, only the materials and radius of curvature of the lightning rod to concentrate the electric field at the tip part of the rod are considered. Recently, the development of new types of lightning rods, such as early streamer emission (ESE) and charge transfer system (CTS), has been introduced through simulation analysis and experiments, but detailed specifications and information about the optimal design and structure have not been fully reported. In this paper, we performed an electric field analysis of the structures and materials for the optimal structural design of lightning rods with a function of CTS through computer software analysis with consideration for the radius of curvature, the size of corona ring, and optimal position (X-axis and Y-axis) of the floating electrode. For optimal structural design of lightning rods based on electric field analysis, we used a source of lightning voltage with 1.2/50 µs based on a double exponential equation. The results revealed that the electric field on the relaxation part decreases as the radius of curvature and corona ring increases. For the radius of curvature, the electric field first decreases and then increases with increasing radius of curvature and reaches a minimum at 7 mm and a maximum above 8 mm. For the case of the corona ring, the electric field decreases with increasing corona ring, and the optimal size of the corona ring was selected as 4 mm; the size of the 4 mm corona ring uniformly formed the electric field both at the tip part of the ground current collector and the corona ring. For the electric field concentration part, we found that the optimal X-axis position of the floating electrode and the Y-axis position between the ionizer conductor and floating electrode are 7 mm and 0.1 mm, respectively. These simulation results in this paper are expected to provide useful information for the design of optimized CTS-type lightning rods. Full article
