Electric mountain bikes (eMTBs) demand compact, high-torque motors capable of handling steep terrain and variable load conditions. Surface-mounted permanent magnet synchronous motors (SPMSMs) are widely used in this application due to their simple construction, ease of manufacturing, and cost-effectiveness. However, SPMSMs inherently lack reluctance torque, limiting their torque density and performance at high speeds. While interior PMSMs (IPMSMs) can overcome this limitation via reluctance torque, they require complex rotor machining and may compromise mechanical robustness. This paper proposes a surface-inset PMSM topology as a compromise between both approaches—introducing reluctance torque while maintaining a structurally simple rotor. The proposed motor features inset magnets shaped with a tapered outer profile, allowing them to remain flush with the rotor surface. This geometric configuration eliminates the need for a retaining sleeve during high-speed operation while also enabling saliency-based torque contribution. A baseline SPMSM design is first analyzed through finite element analysis (FEA) to establish reference performance. Comparative simulations show that the proposed design achieves a 20% increase in peak torque and a 33% reduction in current density. Experimental validation confirms these findings, with the fabricated prototype achieving a torque density of 30.1 kNm/m³. The results demonstrate that reluctance-assisted torque enhancement can be achieved without compromising mechanical simplicity or manufacturability. This study provides a practical pathway for improving motor performance in eMTB systems while retaining the production advantages of surface-mounted designs. The surface-inset approach offers a scalable and cost-effective solution that bridges the gap between conventional SPMSMs and more complex IPMSMs in high-demand e-mobility applications. Full article

The rapid development of 5G and next-generation wireless systems has increased the demand for antennas that support circular polarization (CP), wide frequency coverage, and a compact size. Achieving wideband CP performance in a low-profile and simple structure remains a key challenge for modern antenna designs. In response to this, this paper presents a compact wide-slot antenna with a single feed, offering a wide operational bandwidth and circularly polarized radiation. The proposed design is excited by a 50 Ohm microstrip feedline, and it is fabricated on an (54 × 50 × 1.6 mm³) FR4 dielectric substrate. On the bottom side of the dielectric substrate, the ground plane is engraved to form a square-shaped radiating slot. The shape of the tuning stub of the antenna is modified in order to attain a wide impedance bandwidth and an axial ratio bandwidth (ARBW). The modifications include inserting a rectangular strip and thin horizontal strips into the tuning stub after tapering its upper corner. On the other hand, the radiating slot is appended by two rectangular stubs. The radiation of the resulted structure has right-hand circular polarization (RHCP). The measured results of the proposed antenna show a −10 dB impedance bandwidth equal to 78% (2.65 GHz, 2.08–4.73 GHz), whereas its broadside 3 dB ARBW is 71.6% over the frequencies (2.31 GHz, 2.07–4.38 GHz), which is compatible with various wireless communication applications. Furthermore, the peak value of the measured gain is equal to 4.68 dB, and its value is larger than 2 dBi along the operational bandwidth of the antenna. Full article

This paper proposes a miniaturized design for a terahertz tri-mirror compact antenna test range (CATR) system, composed of a square-aperture paraboloid primary mirror with a side length of 0.2 m and two shaped mirrors with circular apertures of 0.06 m and 0.07 m in diameter. The design first employs the cross-polarization cancelation method based on beam mode expansion to determine the geometric configuration of the system, thereby enabling the structure to exhibit low cross-polarization characteristics. Subsequently, the shaped mirrors, with beamforming and wave-front control capabilities, are synthesized using dynamic ray tracing based on geometric optics (GO) and the dual-paraboloid expansion method. Finally, the strong edge diffraction effects induced by the small-aperture primary mirror are suppressed by optimizing the desired quiet-zone (QZ) field width, adjusting the feed-edge taper, and incorporating rolled-edge structures on the primary mirror. Numerical simulation results indicate that within the 100–500 GHz frequency band, the system’s cross-polarization level is below −40 dB, while the amplitude and phase ripples of the co-polarization in the QZ are, respectively, less than 1.6 dB and 10°, and the QZ usage ratio exceeds 70%. The designed CATR was manufactured and tested. The results show that at 183 GHz and 275 GHz, the measured co-polarization amplitude and phase ripples in the system’s QZ are within 1.8 dB and 15°, respectively. While these values deviate slightly from simulations, they still meet the CATR evaluation criteria, which specify QZ co-polarization amplitude ripple < 2 dB and phase ripple < 20°. The overall physical structure sizes of the system are 0.61 m × 0.2 m × 0.66 m. The proposed miniaturized terahertz tri-mirror CATR design methodology not only enhances the QZ characteristics but also significantly reduces the spatial footprint of the entire system, demonstrating significant potential for practical engineering applications. Full article

Recently, Fano resonance modulators and photonic crystal nanobeam cavities (PCNCs) have attracted more and more attention due to their superior performance, such as high modulation efficiency and high extinction ratio (ER). In this paper, a silicon Fano resonance Mach–Zehnder modulator (MZM) based on a single arm coupled with a PCNC is theoretically analyzed, designed, and numerically simulated. By optimizing the coupling length, lattice constant, coupling gap, and the number of holes in the mirror/taper region, the ER of our MZM can achieve 34 dB. When the applied voltage of the MZM is biased at 4.3 V and the non-return-to-zero on–off keying (NRZ-OOK) signal at a data rate of 10 Gbit/s is modulated, the sharpest asymmetric resonant peak and the most remarkable Fano line shape can be obtained around a wavelength of 1550.68 nm. Compared with the traditional nanobeam cavities, along with the varying radii, our PCNC design has holes with a fixed radius of 90 nm, which is suitable to be fabricated by a 180 nm passive silicon photonic multi-project wafer (MPW). Therefore, our compacted lab-on-chip, resonance-based silicon photonic MZM that is coupled with a PCNC has the advantages of superior performance and easy fabrication, which provide support for photonic integrated circuit designs and can be beneficial to various silicon photonic application fields, including photonic computing, photonic convolutional neural networks, and optical communications, in the future. Full article

This study investigates the mechanism behind the cavitation-induced noise in an automotive heater core and proposes a structural solution to eliminate it. Abnormal noise during cold-start conditions in a compact passenger vehicle was traced to cavitation in the heater core of the heating, ventilation, and air conditioning (HVAC) system. Controlled bench tests, in-vehicle measurements, and computational fluid dynamics (CFD) simulations were conducted to analyze flow behavior and identify the precise location and conditions for cavitation onset. Results showed that high flow rates and low coolant pressure generated vapor bubbles near the junction of the upper tank and outlet pipe, producing distinctive impulsive noise and vibration signals. Flow visualization using a transparent pipe and accelerometer data confirmed cavitation collapse at this location. CFD analysis indicated that the original geometry created a high-velocity, low-pressure region conducive to cavitation. A redesigned outlet with a tapered transition and larger diameter significantly improved flow conditions, raising the cavitation index and eliminating cavitation events. Experimental validation confirmed the effectiveness of the modified design. These findings contribute to improving the acoustic performance and reliability of automotive HVAC systems and offer broader insights into cavitation mitigation in fluid systems. Full article

Optical 3 dB power splitters are fundamental building blocks for advanced silicon photonic integrated circuits, with applications ranging from high-speed modulators to optical phased arrays and programmable photonic processors. However, 3 dB power splitters are commonly hampered by trade-offs in device dimensions, operation bandwidth, and fabrication technology. In this paper, we present a compact and ultra-broadband 3 dB power splitter based on segmented adiabatic tapered rib waveguides, with a length of 23.4 μm. The simulated splitter achieved an output transmission efficiency exceeding 48% over a large wavelength of 400 nm (1200–1600 nm). The power splitter was successfully fabricated on a commercial platform and exhibited excellent splitting ratios within 50 ± 3.8% and insertion losses below 0.38 dB over the range of 1260–1360 nm and 1525–1600 nm. Additionally, a high-speed Mach–Zehnder modulator based on the power splitter was built, demonstrating 40 Gbps NRZ signal modulations across both O-band and C-band. The proposed splitter and modulator are promising elements for large-scale and broadband integrated photonic systems. Full article

Understanding the capabilities of quantum computer devices and computing the required resources to solve realistic tasks remain critical challenges associated with achieving useful quantum computational advantage. We present a study aimed at reducing the quantum resource overhead in quantum chemistry simulations using the variational quantum eigensolver (VQE). Our approach achieves up to a two-orders-of magnitude reduction in the required number of two-qubit operations for variational problem-inspired ansatzes. We propose and analyze optimization strategies that combine various methods, including molecular point-group symmetries, compact excitation circuits, different types of excitation sets, and qubit tapering. To validate the compatibility and accuracy of these strategies, we first test them on small molecules such as LiH and BeH₂, then apply the most efficient ones to restricted active-space simulations of methylamine. We complete our analysis by computing the resources required for full-valence, active-space simulations of methylamine (26 qubits) and formic acid (28 qubits) molecules. Our best-performing optimization strategy reduces the two-qubit gate count for methylamine from approximately 600,000 to about 12,000 and yields a similar order-of-magnitude improvement for formic acid. This resource analysis represents a valuable step towards the practical use of quantum computers and the development of better methods for optimizing computing resources. Full article

Many current 1 × 2 splitter couplers based on multimode interference (MMI) face difficulties such as significant back reflection and limited flexibility in waveguide segmentation at the output, which necessitate the addition of transitional structures like tapered waveguides or S-Bends. These limitations reduce their effectiveness as photonic data-center applications, where precise waveguide configurations are crucial. To address these challenges, we propose a novel nanoscale 1 × 2 angled multimode interference (AMMI) power splitter with silicon nitride (SiN) buried core and silica cladding. The innovative angled light path design improved performance by minimizing back reflections back to the source and by providing greater flexibility of waveguide interconnections, making the splitter more adaptable for data-center applications. The SiN core was selected due to its lower refractive index contrast with silica compared to silicon, which helps further reduce back reflection. The dimensions of the splitter were optimized using full vectorial beam propagation method (FV-BPM), finite-difference time domain (FDTD), and multivariable optimization scanning tool (MOST) simulations to support transmission across the O-band. Our proposed device demonstrated excellent performance, achieving an excess loss of 0.22 dB and an imbalance of <0.01 dB at the output ports at an operational wavelength of 1.31 µm. The total device length is 101 µm with a thickness of 0.4 µm. Across the entire O-band range (1260–1360 nm), the performance of the splitter presented excess loss of up to 1.57 dB and an imbalance of up to 0.05 dB. Additionally, back reflections at the operational wavelength were measured at −40.96 dB and up to −39.67 dB over the O-band. This silicon-on-insulator (SOI) complementary metal-oxide semiconductor (CMOS) compatible AMMI splitter demonstrates high tolerance for manufacturing deviations due to its geometric layout, dimensions, and material selection. Furthermore, the proposed splitter is well-suited for use in O-band transceiver systems and can enhance data-center optical networks by supporting high-speed, low-loss data transmission. The compact design and CMOS compatibility make this device ideal for integrating into dense, high-performance computing environments, ensuring reliable signal distribution and minimal power loss. The splitter can support multiple communication channels, thus enhancing bandwidth and scalability for next-generation data-center infrastructures. Full article

A marine cable-conformal dual-band omnidirectional circularly polarized waveguide slot antenna is proposed for L/S-band (1.59–1.84 GHz/2.48–2.55 GHz) maritime satellite systems. Axially symmetric X-shaped slots enable dual-band operation with 14.6% impedance bandwidth (L-band) and axial ratio < 3 dB. A three-stage tapered coaxial feeding network achieves efficient matching (|S11| < −10 dB) across a BeiDou-1 uplink (1.61–1.6265 GHz) and downlink (2.4835–2.5 GHz), delivering 4.1 dBi peak omnidirectional gain at 1.6 GHz. The compact design (radial dimension ≤ 0.25λ) offers robust performance in harsh marine environments with integrated wideband, high-gain, and conformal capabilities. Full article

A sensitivity-enhanced temperature sensor based on a Mach–Zehnder interferometer (MZI) coated by polydimethylsiloxane (PDMS) film is proposed and investigated. The MZI with a compact size of 2.28 mm is fabricated by embedding a tapered single-mode fiber (SMF) between two multimode fibers (MMFs). Since PDMS has a higher thermo-optical coefficient than silica, the proposed sensor has better temperature sensing performance than the case without PDMS coating, which is demonstrated by simulation and experiment. The experimental results show that the sensitivity of the proposed sensor is as high as −1.06 nm/°C in the range from −5 °C to 45 °C. Full article

The rise of artificial intelligence (AI) necessitates ultra-fast computing, with on-chip terahertz (THz) communication emerging as a key enabler. It offers high bandwidth, low power consumption, dense interconnects, support for multi-core architectures, and 3D circuit integration. However, transitioning between different waveguides remains a major challenge in THz systems. In this paper, we propose a THz band mode converter that converts from a rectangular waveguide (RWG) (WR-0.43) in ${\mathrm{TE}}_{10}$ mode to a substrate-integrated waveguide (SIW) in ${\mathrm{TE}}_{20}$ mode. The converter comprises a tapered waveguide, a widened waveguide, a zigzag antenna, and an aperture coupling slot. The zigzag antenna effectively captures the electromagnetic (EM) energy from the RWG, which is then coupled to the aperture slot. This coupling generates a quasi-slotline mode for the electric field (E-field) along the longitudinal side of the aperture, exhibiting odd symmetry akin to the SIW’s ${\mathrm{TE}}_{20}$ mode. Consequently, the ${\mathrm{TE}}_{20}$ mode is excited in the symmetrical plane of the SIW and propagates transversely. Our work details the mode transition principle through simulations of the EM field distribution and model optimization. A back-to-back RWG ${\mathrm{TE}}_{10}{\mathrm{-to-TE}}_{10}$ mode converter is designed, demonstrating an insertion loss of approximately 5 dB over the wide frequency range band of 2.15–2.36 THz, showing a return loss of 10 dB. An on-chip antenna is proposed which is fed by a single higher-order mode of the SIW, achieving a maximum gain of 4.49 dB. Furthermore, a balun based on the proposed converter is designed, confirming the presence of the ${\mathrm{TE}}_{20}$ mode in the SIW. The proposed mode converter demonstrates its feasibility for integration into a THz-band high-speed circuit due to its efficient mode conversion and compact planar design. Full article

This article presents a printed antenna, designed with a fractal-shaped patch with fish-tail structured outer edges, a tapered feedline, and a rectangular notch-based defected partial ground structure (DPGS). The presented design has been printed on a FR-4 substrate, which has a dielectric constant of 4.4 and a loss tangent of 0.035. The overall dimension of the proposed antenna is 24 × 40 × 1.6 mm³. The proposed fractal antenna achieved dual broad-band functionality by maintaining the compact size of the radiator. The designed fractal radiator can operate at three distinct resonant frequencies (3.22, 7.64, and 9.41 GHz), covering two distinct frequency bands, extending from 2.5 to 4.2 GHz and 7 to 9.8 GHz. A thorough parametric analysis has been carried out using CST Studio suite 2019 licensed version to achieve better performance in terms of S₁₁ (dB), radiation efficiency, and gain over the operating frequency range. The operating bands fall within the S, C, and X bands to support sub-6GHz 5G and Radar applications at the microwave frequency range. Full article

In this study, the potential of employing SiN_x (silicon nitride) waveguide platforms to enable the use of liquid-crystal-based phase shifters for on-chip optical modulators was thoroughly investigated using 3D-FDTD (3D finite-difference time-domain) simulations. The entire structure of liquid-crystal-based Mach–Zehnder interferometer (MZI) optical modulators, consisting of multi-mode interferometer splitters, different tapering sections, and liquid-crystal-based phase shifters, was systematically and holistically investigated with a view to developing a compact, wideband, and CMOS-compatible (complementary metal-oxide semiconductor) bias voltage optical modulator with competitive modulation efficiency, good fabrication tolerance, and single-mode operation using the same SiN_x waveguide layer for the entire device. The trade-off between several important parameters is critically discussed in order to reach a conclusion on the possible optimized parameter sets. Contrary to previous demonstrations, this investigation focused on the potential of achieving such an optical device using the same SiN_x waveguide layer for the entire device, including both the passive and active regions. Significantly, we show that it is necessary to carefully select the phase shifter length of the LC-based (liquid crystal) MZI optical modulator, as the phase shifter length required to obtain a π phase shift could be as low as a few tens of microns; therefore, a phase shifter length that is too long can contradictorily worsen the optical modulation. Full article

LNOI devices have emerged as prominent contributors to photonic integrated circuits (PICs), benefiting from their outstanding performance in electro-optics, acousto-optics, nonlinear optics, etc. Due to the physical properties and current etching technologies of LiNbO₃, slanted sidewalls are typically formed in LNOI waveguides, causing polarization-related mode hybridization and crosstalk. Despite the low losses achieved with fabrication advancements in LNOI, such mode hybridization and crosstalk still significantly limit the device performance by introducing polarization-related losses. In this paper, we propose a vertically etched LNOI construction. By improving the geometrical symmetry in the waveguides, vertical sidewalls could adequately mitigate mode hybridization in common waveguide cross sections. Taking tapers and bends as representatives of PIC components, we then conducted theoretical modeling and simulations, which showed that vertical etching effectively exempts devices from polarization-related mode crosstalk. This not only improves the polarization purity and input mode transmittance but also enables lower polarization-related losses within more compact structures. As a demonstration of fabrication feasibility, we innovatively proposed a two-step fabrication technique, and successfully fabricated waveguides with vertical sidewalls. Such vertical etching technology facilitates the development of next-generation high-speed modulators, nonlinear optical devices, and other advanced photonic devices with lower losses and a smaller footprint, driving further innovations in both academic research and industrial applications. Full article

We propose and demonstrate an integrated optical switch that leverages an optical phased array (OPA) and an on-chip metalens, highlighting its potential for efficient and scalable beam switching across multiple ports within a compact footprint. The device consists of an input multimode interference (MMI) coupler, a phase modulator (PM) array, a beam-transformation region featuring an on-chip metalens layer, and a tapered waveguide array serving as the output ports. The PM array, engineered to effectively manipulate multiple phases for a waveguide array using a single voltage, utilizes metal strips of varying lengths to streamline operation. The on-chip metalens, characterized by varying slot lengths, facilitates the wavefront manipulation of the fast Fourier transform, resulting in beam deflection with a focusing length of 20 µm. The simulated validation of the proposed compact optical switch demonstrated efficient beam deflection, yielding a 1 × 8 beam switching at a wavelength of 1550 nm. Combinations of diverse OPAs and metalens configurations resulted in potential scalability, allowing for the realization of optical switches with pathway numbers ranging from 4 to 16. This development of a metalens-assisted optical switch on a compact chip presents significant practical implications for enhancing data transmission efficiency and scalability in photonic integrated circuits. Full article
